With the Celestron StarSense Autoguider, using a Celestron telescope
for astroimaging has never been easier. This all-in-one accessory can
help with every aspect of telescope alignment and tracking. With your
new StarSense Autoguider (SSAG), you can:
• Automatically align your equatorial or altazimuth telescope to the night
sky in just a few minutes. Once aligned, your telescope will fi nd and
center objects with enhanced pointing accuracy.
• Guide your telescope accurately during long astroimaging exposures
without any additional alignment required (not even polar alignment).
• Quickly and accurately polar align your equatorial mount, if desired.
Please read this manual before setting up and using your StarSense
Autoguider. You can fi nd the most current version of this instruction
manual on the StarSense Autoguider product page at celestron.com.
WARNING – Never point the StarSense Autoguider at the Sun! Doing
so will damage SSAG’s image sensor. This damage is not covered under
your warranty. Keep SSAG’s cover cap on during the day.
TABLE OF CONTENTS
1. Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
2. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
3. Controlling your StarSense Autoguider . . . . . . . . . . . . . . . . . . . . . . .3
4. Using SSAG with NexStar+ Hand Control . . . . . . . . . . . . . . . . . . . . .3
5. Using SSAGE with CPWI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6. Focusing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
7. Status LED Ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
8. Using Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
9. Updating SSAG’s Internal Software with CFM . . . . . . . . . . . . . . . . .10
10. Updaing SSAG’s Internal Software
and Live View via Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
11. Troubleshooting and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
12. Specifi cations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1. Parts List
A. StarSense Autoguider with cover cap
B. Large bracket (pre-installed on StarSense Autoguider)
C. Large bracket base
D. AUX cable
E. Phillips head screws (2)
F. Large bracket base thumbscrews (2)
G. Hex key
H. Small bracket
INSTRUCTION MANUAL
Model # 94008
A
B
D
C
E F G H
Fig. 1:
2. Installation
StarSense Autoguider connects to your optical tube using one of the two
supplied brackets (i.e., the large bracket or the small bracket). Use the
large bracket with Schmidt-Cassegrain, EdgeHD, and RASA telescopes
with 5” or more of aperture (Fig. 2).
Large bracket
Large
bracket base
Fig. 2: The large bracket and base connect SSAG to Celestron Schmidt-
Cassegrain, EdgeHD, and RASA telescopes 5” or larger.
Use the small bracket with other telescopes that have a standard dovetail
base for a fi nderscope (Fig. 3).
Small
bracket
Standard
fi nder base
Fig. 3: If your telescope already has a standard fi nder base, you can use the small
bracket to mount SSAG on your telescope.
If you are using a telescope smaller than 5” in aperture, and your
telescope does not have a standard dovetail base you must purchase a
standard dovetail base from a third-party supplier.
ENGLISH
See product page at celestron.com for other language versions of this instruction manual.
Consultez la page produit sur celestron.com pour les autres versions linguistiques de ce manuel d’instructions
Siehe die Produktseite auf celestron.com für andere Sprachversionen dieser Bedienungsanleitung.
Consultare la pagina relativa al prodotto su celestron.com per le versioni in altre lingue del presente manuale di istruzioni.
Consulte la página del producto en celestron.com para ver las versiones en otros idiomas de este Manual de instrucciones.
