INcsb069_US
800-118
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Air Fryer
- FOR INDOOR HOUSEHOLD USE ONLY-
USING INSTRUCTION
1
INTRODUCTION
This all now Hot-air fryer provides an easy and healthy way of preparing your favorite
ingredients. By using hot rapid air circulation and a top grill, it is able to make numerous
dishes. The best part is that the Hot-air fryer heats food at all directions and most of the
ingredients do not need any oil.
SAVE THESE INSTRUCTIONS
This appliance is not intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed
including the following:
1. Read all instructions.
2. Do not touch hot surfaces.
3. To protect against electric shock do not immerse cord, plugs, or base in water or other
liquid.
4. WARNING: This electrical appliance contains a heating function. Surfaces, also
different than the functional surfaces, can develop high temperatures. Since
temperatures are differently perceived by different persons, this equipment shall be used
with CAUTION. The equipment shall be touch only at intended handles and gripping
surfaces, and use heat protection like gloves or similar. Surfaces other than intended
gripping surfaces shall get sufficiently time to the cool down before getting touched.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting
on or
taking off parts.
6. Type Y: If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
7. The use of accessory attachments not recommended by the appliance manufacturer
may cause injuries.
8. Do not use outdoors
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.
12. Always attach plug to appliance first, then plug cord in the wall outlet. To disconnect,
turn any control to "off," then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children unless
they are old than 8 and supervised.
15. Keep the appliance and its cord out of reach of children less than 8 years.
16. The appliances are not intended to be operated by means of an external timer or
separate remote-control system.
2
Specification Feature:＆
-----Voltage:120V ~60Hz
-----Wattage: 1700W
-----Capacity of basket: 6.5 L
-----Adjustable temperature: —400170℉ ℉
----- Timer:0-30 min
General description (Fig.1)
1. Timer knob
2. Temperature control knob
3. Heating indicator lamp
4. Basket
5. Basket release button
6. Basket handle
7. Power indicator lamp
8. Main housing
9. Pot
10.Air outlet
11. Main cord (Electrical cord)
Fig. 1
Fig. 2 Fig. 3 Fig. 4
3
Fig. 5 Fig. 6
Fig. 7 Fig. 8
Important！
Danger
-This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised.
-Keep the appliance and its cord out of reach of children less than 8 years.
-Never immerse the housing, which contains electrical components and the heating
elements, in water nor rinse it under the tap.
-Do not let any water or other liquid enter the appliance to prevent electric shock.
-Always put the ingredients to be fried in the basket, to prevent it from coming into
contact with the heating elements.
-Do not cover the air inlet and the air outer openings while the appliance is operating.
-Do not fill the pot with oil as this may cause a fire hazard.
-Never touch the inside of the appliance while it is operating.
The temperature of accessible surfaces may be high when the appliance is operating.
WARNING
- Check if the voltage indicated on the appliance fits the local mains voltage.
- Do not use the appliance if there is any damage on plug, mains cord or other parts.
- Do not go to any unauthorized person to replace or fix damaged main cord.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control panel with wet hands.
- Do not place the appliance against a wall or against other appliances. Leave at least
10 cm free space on the back and sides and 10cm free space above the appliance.
4
- Do not place anything on top of the appliance.
- Do not use the appliance for any other purpose than described in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air outlet openings, Keep your
hands and face at a safe distance from the steam and from the air outlet openings.
Also be careful of hot steam and air when you remove the pot from the appliance.
-Any accessible surfaces may become hot during use (Fig.2)
- Immediately unplug the appliance if you see dark smoke coming out of the appliance.
Wait for the smoke emission to stop before you remove the pot from the appliance.
Caution
- Ensure the appliance in placed on a horizontal, even and stable surface.
- This appliance is designed for household use only. It may not suitable to be safely used
in environments such as staff kitchens, farms, motels, and other non-residential
environments. Nor is it intended to be used by clients in hotels, motels, bed and
breakfasts and other residential environments.
- If the appliance is used improperly or for professional or semi-professional purposes or
it is not used according to the instructions in the user manual, the guarantee becomes
invalid and we could refuse any liability for damage caused.
-Always unplug the appliance while not using.
-The appliance needs approximately 30 minutes to cool down for handle or cleaning
safely.
Automatic switch-off
This appliance is equipped with a timer, when the timer has counted down to 0, the
appliance produces a bell sound and switches off automatically. To switch off the
appliance manually, turn the timer knob anticlockwise to 0.
Before first use
1. Remove all packaging materials
2. Remove any stickers or labels from the appliance
3. thoroughly clean the basket and pan with hot water, some washing-up liquid and a
non-abrasive sponge.
4.Wipe inside and outside of the appliance with a moist cloth.
This is an oil-free fryer that works on hot air, do not fill the pan with oil or frying fat.
Preparing for use
1. Place the appliance on a stable, horizontal and even surface.
Do not place the appliance on non-heart-resistant surface.
2. Place the shelf in the pan (Fig.4).
3. Pull the cord from the storage compartment which locates on the bottom of the
appliance.
Do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance, the airflow will be disrupted and affects the
hot air frying result.
WARNING: This product is equipped with a polarized plug (one blade is
wider than the other blade). To reduce the risk of electrical shock, this
plug is intended to fit into a polarized outlet only on way. If the plug does
not fit fully into the outlet, reverse the plug. lf the plug still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any
way.
ONLY FOR USA PLUG
5
Using the appliance
The oil-free can prepare a large range of ingredients. The recipe booklet included helps
you get to know the appliance.
Hot air frying
1. The power cord is plugged into the socket.
2. Carefully pull the pan out of the Hot-air fryer (Fig.3)
3. Put the ingredients on the shelf. (Fig.5)
4. Slide the pan back into the Hot-air fryer (Fig 6)
Noting to carefully align with the guides in the body of the fryer.
Never use the pan without the basket in it.
Caution: Do not touch the pan during and sometime after use, as it gets very hot.
Only hold the pan by the handle.
5.Determine the required preparation time for the ingredient (see section 'Settings' in
this chapter).
6. To switch on the appliance, turn the timer knob to the required preparation time (Fig.7)
7.Turn the temperature control knob to the required temperature. See section 'Settings'
in this chapter to determine the right temperature (Fig.8).
Add 3 minutes to the preparation time when the appliance is cold.
Note: If you want, you can also let the appliance preheat without any ingredients
inside. In that case, turn the timer knob to more than 3 minutes and wait until the
heating-up light goes out (after approx. 3 minutes). Then fill the basket and turn
the timer knob to the required preparation time.
a. The timer starts counting down the set preparation time.
b. During the hot air frying process, the working light comes on and goes out from time
to time. This indicates that the heating element is switched on and off to maintain the
set temperature.
c. Excess oil from the ingredients is collected on the bottom of the pan.
8.Some ingredients require shaking halfway through the preparation time (see section
“Settings” in this chapter). To shake the ingredients, pull the pan out of the appliance by
the handle and shake it. Then slide the pan back into the I fryer.
Tip: If you set the timer to half the preparation time, you hear the timer bell when you
have to shake the ingredients. However, this means that you have to set the timer again
to the remaining preparation time after shaking.
9. When you hear the timer bell, the set preparation time has elapsed. Pull the pan out of
the appliance and place it on the trial framework.
Note: You can also switch off the appliance manually. To do this, turn the time control
knob to 0.
10. Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the pan back into the appliance and set
the timer to a few extra minutes.
11. To remove ingredients (e.g. fries), pull the pan out of the Hot-air fryer and place it on
trial framework.
Do not turn the basket upside down with the pan still attached to it, as any excess
oil that has collected on the bottom of the pan will leak onto the ingredients.
The pan and the ingredients are hot and hot fryer. Depending on the type of the
ingredients in the I fryer, steam may escape from the pan.
6
12. Empty the shelf into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, lift the ingredients out of the basket by a pair
of tongs.
13. When a batch of ingredients is ready, the Hot-air fryer is instantly ready for preparing
another batch.
Settings
This table below will help you to select the basic settings for the ingredients.
Note: Keep in mind that these settings are indications. As ingredients differ in origin,
size, shape as well as brand, we cannot guarantee the best setting for your ingredients.
Because the Rapid Air technology instantly reheats the air inside the appliance instantly
Pull the pan briefly out of the appliance during hot air frying barely disturbs the process.
Tips
- Smaller ingredients usually require a slightly shorter preparation time than larger
ingredients.
- A larger amount of ingredients only requires a slightly longer preparation time, a
smaller amount of ingredients only requires a slightly shorter preparation time.
- Shaking smaller ingredients halfway through the preparation time optimizes the end
result and can help prevent unevenly fried ingredients.
- Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the Hot-air
fryer within a few minutes after you added the oil.
- Do not prepare extremely greasy ingredients such as sausages in the Hot-air fryer.
- Snacks that can be prepared in an oven can also be prepared in the Hot-air fryer
- The optimal amount for preparing crispy fries is 500 grams.
- Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also
requires a shorter preparation time than home-made dough.
- Place a baking tin or oven dish in the Hot-air fryer basket if you want to bake a cake or
quiche or if you want to fry fragile ingredients or filled ingredients
-You can also use the Hot-air fryer to reheat ingredients. To reheat ingredients, set the
temperature to 300℉ for up to 10 minutes.
7
Note: Add 3 minutes to the preparation time when you start frying while the Hot-air fryer
is still cold.
Cleaning
Clean the appliance after every use.
The pan and the non-stick coating basket. Do not use metal kitchen utensils or
abrasive cleaning materials to clean them, as this may damage the non-stick
coating.
1. Remove the mains plug from the wall socket and let the appliance cool down.
Note: Remove the pan to let the Hot-air fryer cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the pan and basket with hot water, some washing-up liquid and a non-abrasive
sponge.
You can use degreasing liquid to remove any remaining dirt.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with
some washing-up liquid. Put the basket in the pan and let the pan and the basket soak
for approximately 10 minutes.
4 Clean the inside of the appliance with hot water and non-abrasive sponge.
5 Clean the heating element with a cleaning brush to remove any food residues.
Storage
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry.
Environment
Do not throw away the appliance with the normal household waste when it is exhausted,
but hand it in at an official collection point for recycling. By doing this, you help to
preserve the environment
8
Troubleshooting
problem
Possible cause
Solution
The Hot-air fryer
does not work
The appliance is not
plugged in.
The appliance is not
plugged in.
Put the mains plug in an earthed wall
socket.
Set the timer key to the required
preparation time to switch on the
appliance.
The ingredients
fried with the air
fryer are not done.
The amount of
ingredients in the
basket is too big.
The set temperature
is too low.
The preparation time
is too short.
Put smaller batches of ingredients in
the basket. Smaller batches are fried
more evenly.
Set the temperature key to the
required temperature setting (see
section 'settings' in chapter 'Using the
appliance').
Set the timer to the required preparation
time (see section 'Settings' in chapter'
Using the appliance').
The ingredients
are fried unevenly
in the air fryer.
Certain types of
ingredients need to
be shaken halfway
through the
preparation time.
Ingredients that lie on top of or across
each other (e.g. fries) need to be
shaken halfway through the
preparation time. See section 'Settings'
in chapter 'Using the appliance'.
White smoke
comes out of the
appliance.
You are preparing
greasy ingredients.
When you fry greasy ingredients in the
air fryer, a large amount of oil will leak
into the pot. The oil produces white
smoke and the pot may heat up more
than usual. This does not affect the
appliance or the end result.
The pot still contains
grease residues
from previous use.
White smoke is caused by grease
heating up in the pan. make sure you
clean the pan properly after each use.
I cannot slide the
pan into the
appliance
properly.
There are too much
ingredients in the pot.
Do not fill the pot beyond the MAX
indication.
The pot is not placed
in the pot correctly.
Push the pot again in the correctly
direction.
Fried snacks are
not crispy when
they come out of
the air fryer.
You used a type of
snacks meant to be
prepared in a
traditional deep fryer.
Use oven snacks or lightly brush some
oil onto the snacks for a crispier result.
9
Fresh fries are
fried unevenly in
the air fryer.
You did not use the
right potato type.
You did not rinse the
potato sticks properly
before you fried them.
Use fresh potatoes and make sure
they stay firm during frying.
Rinse the potato sticks properly to
remove starch from the outside of the
sticks.
Fresh fries are not
crispy when they
come out of the air
fryer.
The crispiness of the
fries depends on the
amount of oil and
water in the fries.
Add slightly more oil for a crispier
result.
Make sure you dry the potato sticks
properly before you add the oil.
Cut the potato sticks smaller for a
crispier result.
