BARISTA KIT
DESCRIPTION
Water tank
Cap
Double espresso
adapter ring
8g filter basket
(with lid)
16g filter basket
(with lid)
Coffee tamper
Water tank mount
Espresso cup
INSTRUCTIONS
1
2
3
5
6
4
Unscrew the cap from the
barista kit, and take out the
double espresso adapter ring.
Unscrew the portafilter from
the Nanopresso.
Screw the portafilter into the
double espresso adapter ring.
Add the coffee grounds (16g) into
the filter basket. Use the tamper
to level and compress the espresso
ground.
90°
Put the filter basket filled
with ground on the top of
the main body.
Screw back tightly the
portafilter with adapter
ring into the main body.
9
Place water tank on level
and stable surface to fill it.
MAX LEVEL 80ml
MIN LEVEL 50ml
Unscrew the water tank.
For step 7 to 10, you can use the water tank
of your choice (small or large)
Screw tightly the main body
onto the water tank.
Add the boiling water
into the water tank.
10
11 12
Avoid burning yourself.
Unlock the piston from
its travel position.
7 8
Unclips the cup if needed.
Do not unclips the cup if the
water tank is filled with hot water.
Hold the Nanopresso with two hands, as
showed above. Start pumping above a cup.
Pump slowly until all coffee come out.
1
2
3
Unscrew the nozzle.
Unclip the nozzle part.
coffee menu
Single Espresso 50ml 30ml8gr.
16gr.
16gr.
Double Espresso
X2 16gr.
X2 8gr.
2 Double Espresso
Lungo
2 Single Espresso
water tank
filter basket
in cup
80ml 60ml
150ml 120ml
100ml
150ml
X2 30ml
X2 55ml
(Maximum) (Maximum)
FOR BEST RESULTS
Use the Nanopresso in non-pressurized mode as
instructed below :
In non-pressurized mode you may want to use little
finer coffee grind.
NANOPRESSO BARISTA KIT
What to drink?
Remove the small black silicon part located inside the long
spring. Reassemble the noozle. Take care to not lose that small
black part.
+
WARNING
Do not put any Nanopresso Barista kit parts into
dishwasher.
CLEANING
It's important to respect and clean regularly your
machine and its accessories. A good maintenance
will allow you to use your Nanopresso for many years.
After each use clean the parts under running water.
Let them dry separately.
INTENDED USE
The Barista kit accessory is only compatible with the
Nanopresso. The Barista kit is intended to a personal
use. It is not suitable for commercial, professional,
collective or industrial use.
Use of the Barista kit in any manner other than as
directed herein could cause harm to persons and void
the warranty. Wacaco Company Limited will not be
responsible for injury or damage resulting from
improper use.
WARRANTY
Wacaco Company Limited warrants the
Barista kit
against defects that are due to faulty materials or
workmanship for a period of 12 months
from the date of purchase. This warranty is not
transferable and does not entitle to compensation
in cash. Wacaco Company Limited disclaims all
responsibility for incidental or consequential
damages caused by use of this appliance.
This warranty does not cover :
Damage resulting from improper use, abuse,
neglect, commercial use or any other use of this
appliance not found in this printed manual.
Damage of an aesthetic nature, damage due to
corrosion or gradual deterioration.
Any disassembly or repairs done by unauthorized
persons will void the warranty.
For any repair or exchange, the cost of return is at
your expense. If your
Barista kit
fails within one
year, please contact your Wacaco local distributor
or support@wacaco.com directly for repair or
exchange.
