TURBO GEAR DRIVE 2PATTERN SPRINKLER
94134EDAMZ
Hose Connection Nut
• Watering dia. up to 62ft (19m); coverage up to 3,020 sq. ft. (284 sq. m.) max
• Whisper quiet operation for early morning watering
• 2 spray patterns (full jet and gentle fountain) are suitable for various
watering needs
• Sleek, low-profile design combined with “H” shaped base for stability and
durability
• Easy to move and place anywhere in the yard
• 360-degree coverage with easy-to-adjust tabs to modify your watering range
wherever you move the sprinkler. Water a full or partial circle from 5° to 360°
• Convenient turning head to select spray pattern
• Flow control knob with built-in water filter blocks sediment and dirt while
providing water pressure adjustments
Our Turbo Gear Drive 2-Pattern Sprinkler provides convenient watering of owers and lawns with two easy-to-select
watering patterns. Choose between a full jet and a gentle fountain spray pattern to meet all your watering needs. Adjust
the water pressure right at the sprinkler using the ow control knob. The sliding tabs let you control the spray angle and
water an area of 5 degrees all the way to 360 degrees for both full and partial circular coverage. The built-in water lter
blocks sediment and dirt from clogging the sprinkler.
The sleek, low-prole design combined with the “H” shaped base provides for a stable and durable platform to water your
lawns. Easily move the sprinkler anywhere in your yard to water right where you need it.
Features & Benets
Quick Connect Adapter ts
all standard garden hoses
2 spray patterns to meet all your watering
needs – Full Jet and Gentle Fountain
Wide ”H” shape platform
design for added stability
Adjustable spray coverage - sliding tabs
change the spray angle from 5° to 360°
Water ow control knob with
easy-to-clean removable lter
Coverage Control
Sliding tabs allow for easy
spray angle adjustments from 5° to 360°
Flow Control
Flow control knob adjusts
overall watering area
284m²
3020 sq.ft
Coverage Area
Up To
CLICK!
Full Jet or Gentle Fountain watering patterns
Pattern Selector
Connect the adapter to the base of the sprinkler. Attach the lockable quick connect to the end of the hose and
simply snap in the hose to the sprinkler to begin using.
Set-Up with Quick Connect
Cleaning and Maintenance:
If the sprinkler water pressure is low, you may need to clean the built-in
lter. Simply pull the ow control knob and remove the lter. Rinse under
cold water. Then re-insert the lter into the sprinkler.
The Quick Connect Adapter (2 pcs) and Hose
Connector with Water Stop (1 pc) simplify your
watering experience. Simply attach the connector
at the end of your hose. Then, connect the
adapters to your watering tools. Interchange
various tools in a snap without turning o the
water as the adapter will stop the water ow. No
more kinking or hose twisting as the adapter
allows the hose to swivel 360 degrees.
A
C
A B C D
B
D
Quick and easy connections to 5/8-inch and
1/2-inch garden hoses, sprinklers, nozzles, and/or
any other garden watering tools
UNLOCK
LOCK
UNLOCK
LOCK
Twist-and-lock
mechanism prevents
accidental disconnection
CAUTION
-For outdoor use with cold water only
-Do not spray near electrical connections
-When not in use, rinse the tool with water to remove most of the dirt, dry your tool, and store indoors
This product can expose you to chemicals including styrene, which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov
Simply attach the gear driver sprinkler to your hose.
Basic Set-Up
LOCK
WATER
+
How To Clean
