C112V/C115V/C215V
CM10V/CM12V/CM15V
C112VA /C115VA
CW115V/CW118V/CW218V
Owner’
s Manual
Thank you for choosing the YAMAHA speaker system.
In order to take maximum advantage of the speaker’s
features and ensure maximum performance and longev-
ity, please read this manual carefully before using the
speaker system. Keep the manual in a safe place for
future reference.
Bedien
ungsanleitung
Wir be
glückwünschen Sie zum Kauf dieses YAMAHA
-Lautsprechersystems. Damit Sie die Ausstattungen die-
ses Lautsprechersystems optimal nutzen können, und
um maximale Leistung und Lebensdauer sicherzustel-
len, lesen Sie bitte vor der Inbetriebnahme diese Anlei-
tung sorgfältig durch. Bitte bewahren Sie diese Bedie-
nungsanleitung gut auf, um bei Bedarf darauf zurück-
greifen zu können.
Mode d’emploi
Nous v
ous remercions d’avoir acheté les enceintes
YAMAHA. Pour obtenir les performances optimales de
vos enceintes et garantir une longévité maximale, lisez
attentivement ce mode d’emploi avant d’utiliser les
enceintes. Conservez-le en lieu sûr pour pouvoir vous y
référer ultérieurement.
Man
ual de instrucciónes
Gracias por escoger el sistema de altavoces YAMAHA.
A fin de aprovechar al máximo las características de los
altavoces y obtener un rendimiento y durabilidad ópti-
mos, lea atentamente este manual antes de utilizar el
sistema. Guarde este manual en un lugar seguro para
futuras consultas.
このたびは、ヤマハ製品をお買い求めいただきま
して、まことにありがとうございます。
スピーカーを安全にご使用いただき、優れた性能
を十分に生かして末永くご愛用いただくために、
この取扱説明書をご使用の前に必ずお読みくださ
い。お読みになったあとは保証書とともに保管し
てください。
取取
取取
扱扱
扱扱
説説
説説
明明
明明
書書
書書
SPEAKER SYSTEM
SUBWOOFER
Hyo1.fm Page 1 Tuesday, February 14, 2006 9:33 AM
2
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep this manual in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical
shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
• Do not open the device or attempt to disassemble the inter-
nal parts or modify them in any way. The device contains
no user-serviceable parts. If it should appear to be mal-
functioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.
• Do not expose the device to rain, use it near water or in
damp or wet conditions, or place containers on it contain-
ing liquids which might spill into any openings.
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage
to the device or other property. These precautions include, but are not limited to, the following:
• If you use a stand, check the stand’s specifications and
make sure that it is sturdy enough to support the weight of
the speaker. You may need to limit the number of people
around the placed stand, in order to avoid toppling the
device or causing damage to the internal components.
• If you use speaker stands, be sure to keep the following
cautions.
– Use the speaker stands with their legs fully opened.
– Mount only one speaker on each speaker stand.
– Tighten fastening screws securely.
– Remove the speakers from the stands before moving
the stands or adjusting their height.
– Add weight such as sand bags around the stand legs to
prevent them from falling over.
– Use the stand at a maximum height of 140cm (55").
• If you use a metal socket of the CW115V/CW118V sub-
woofer to allow mounting of a satellite speaker, use a pole
shorter than 90cm (35.4") with an outer diameter of 35mm
(1-3/8").
• When transporting or moving the device, always use two or
more people.
• Before moving the device, remove all connected cables.
• Do not use the speaker’s handles for suspended installa-
tion. Doing so can result in damage or injury.
• Do not expose the device to excessive dust or vibrations,
or extreme cold or heat (such as in direct sunlight, near a
heater) to prevent the possibility of panel disfiguration or
damage to the internal components.
• Do not place the device in an unstable position where it
might accidentally fall over.
• Before connecting the device to other devices, turn off the
power for all devices. Before turning the power on or off for
all devices, set all volume levels to minimum.
• Use only speaker cables for connecting speakers to the
speaker jacks. Use of other types of cables may result in
fire.
• Be sure to observe the amplifier’s rated load impedance
(see page 4), particularly when connecting speakers in
parallel. Connecting an impedance load outside the ampli-
fier’s rated range can damage the amplifier.
• Always turn AC power to the power amplifier on last in any
audio system to avoid speaker damage. When turning
power off, the power amplifier should be turned off first for
the same reason.
• Do not use the device for a long period of time at a high or
uncomfortable volume level, since this can cause perma-
nent hearing loss. If you experience any hearing loss or
ringing in the ears, consult a physician.
• Do not operate the device if the sound is distorting. Pro-
longed use in this condition could cause overheating and
result in fire.
Do not open Water warning
Location Connections
Handling caution
3
ENGLISH
• In any system using two or more speakers, be sure to match
the connection polarities of all speakers to the amplifier(s) –
e.g. always connect “+” to “+” and “-” to “-”. If the polarities
are not properly matched the speakers will be driven out of
phase and the sound will suffer.
• Use only Neutrik NL4FC plugs for connecting Speakon con-
nectors.
* Illustrations in this manual are for explanatory purposes
only, and may not match the actual appearance of the prod-
uct during operation.
* Company names and product names used in this Owner’s
Manual are trademarks or registered trademarks of their
respective owners.
This product, when used in combination
with amplification and/or additional loud-
speakers, may be capable of producing
sound levels that could cause permanent
hearing loss.
DO NOT operate at high volume levels or at
a level that is uncomfortable. If you experi-
ence any discomfort or ringing in the ears, or
suspect an hearing loss, you should consult
an audiologist.
To protect your speakers
When choosing a power amplifier to use with your speakers,
make sure that its power output matches the speakers’ power
capacity (refer to the Specifications on page 7). Even if the
amplifier’s power output is lower than the speakers’ PGM
(program) power capacity, the speakers may be damaged
when clipping of a high input signal occurs.
The following may cause damage to speakers:
• Feedback caused when using a microphone.
• Continuous high sound pressure level produced by elec-
tronic instruments.
• Continuous high-power output distorted signals.
• Popping noises caused by turning on equipment, or by
connecting or disconnecting system components while the
amplifier is turned on.
Poly Switch
All full-range loudspeakers are fitted with a self-resetting
poly switch that protects the high-frequency driver from
damage caused by excessive power.
If a loudspeaker cabinet loses high-frequency output, imme-
diately remove power from the unit and wait for two to three
minutes. They should allow the poly switch to reset. Re-
apply power and check the performance of the high-fre-
quency driver before continuing with the power reduced to a
level that does not cause the poly switch to interrupt the sig-
nal.
On the CW115V/CW118V/CW218V subwoofer, the Poly
Switch protects the woofer and a similar routine should be
followed if its output is lost.
Yamaha cannot be held responsible for damage caused by
improper use or modifications to the device.
4
Connecting the Speakers
■ Phone Plug Wiring
Phone plugs for connection to the phone jack inputs should be wired as
shown to the right. Be sure to use proper speaker cable — NOT shielded
instrument or line cable — for all speaker connections.
■ Neutrik Speakon NL4FC Plug Wiring
If you will be using the Neutrik connectors for speaker input,
wire the plugs as shown to the right. Be sure to use proper speaker
cable — NOT shielded instrument or line cable — for all speaker
connections.
■ Full-range Connection
Each speaker (except for the C112VA/ C115VA) features four input/parallel connectors—two 1/4” phone jacks and
two Neutrik Speakon NL4MP connectors. Use either a phone jack or a Speakon connector to receive input from your
sound system/power amplifier. One of the spare connectors can be used to parallel-connect an additional speaker
(keeping in mind the impedance considerations mentioned below).
Impedance Considerations
When connecting speakers in parallel be sure to check the rated load impedance of the power amplifier. Most power
amplifiers are capable of safely driving speakers with minimum impedance of 8 ohms or 4 ohms. A pair of paral-
lel-connected 8-ohm speakers have a total impedance of 4 ohms. Two 8-ohm speakers can safely be paralleled on one
output. 4-ohm speakers, however, should not be parallel-connected with other speakers. These models can be con-
nected in parallel, however, if you are using a power amplifier that can safely drive load impedances of 2 ohms or
lower. Check your speaker impedance on page 7.
HOT(+) COLD(–)
2– (NO USE)
2+ (NO USE)
1+ : HOT(+)
1– :COLD (–)
Neutrik NL4FC connector
MIXING
CONSOLE
GRAPHIC
EQUALIZER
SPEAKER
SYSTEMS
L
R
L
R
SPEAKER
SYSTEMS
POWER
AMPLIFIER
L
R
5
ENGLISH
■ Subwoofers and the P-Series Power Amplifiers
Adding subwoofers to speaker systems like the one shown in the diagram can provide superior dynamic range and
overall sound quality. After inputting the line-level audio from the preamplifier or mixing console into the Yamaha
P-series power amplifiers (P7000S/P5000S/P3500S/P2500S), the separate frequency bands are outputted from the
amplifiers.
PARALLEL LOW CUT
FREQUENCY=90Hz
FREQUENCY=90Hz
A
SUBWOOFER
SUBWOOFER
B
LOW CUT
A
B
A
B
A
B
PARALLEL
P-SERIES
POWER AMPLIFIERS
P-SERIES
POWER AMPLIFIERS
SUBWOOFER
SUBWOOFER
SPEAKER
SYSTEM
SPEAKER
SYSTEM
TWO-CHANNEL
GRAPHIC
EQUALIZER
MIXING
CONSOLE
6
Suspended and Bracket Installation
■ Suspended Installation
The C112VA and C115VA can be used in suspended “flying”
rigs by using an appropriate suspension wire.
1. Replace the bolts with the supplied eyebolts (3/8") as shown
in the diagram, and then suspend the speaker using an
appropriate wire.
2. The speaker angle can be adjusted for optimum coverage by
adjusting the lengths of the suspension wires, but the down-
ward tilt angle must be less than 45 degrees, as shown in the
diagram.
■ Bracket Installation
The C112VA has bracket-mounting screws on the top, bottom,
and sides of the speaker enclosure. The C112VA can be
mounted on a wall or ceiling using the optional brackets listed
below.
• Consult an installation expert to arrange for installation or construction work.
• Choose suspension wire, an installation location, and mounting hardware that are strong enough to support the
weight of the speaker.
• Some fittings may deteriorate over extended periods of time due to wear or corrosion. For safety the installation
should be checked thoroughly at regular intervals.
Yamaha cannot be held responsible for damage or injury caused by insufficient strength of the support structure or improper
installation.
• Use only the supplied eyebolts.
• Use two or more eyebolts for suspended installa-
tion. Always use the eyebolts marked .
• Do not suspend a speaker from another suspended
speaker.
Bolts
Bolts
Eyebolts
Eyebolts
Maximum
45
Degrees
Bracket Model
Wall bracket BWS251-300, BWS251-400
Ceiling bracket BCS251
Baton bracket BBS251
• Use only the specified screws (W5/16")
to attach the bracket to the speaker.
The mounting screws are installed on the speaker
when it leaves the factory. Refer to the instruc-
tion manual supplied with your bracket for
installation details.
Screws (W5/16")
7
ENGLISH
Specifications
Model CM10V C112V C112VA CM12V C115V C115VA CM15V C215V
Enclosure
Bass Reflex Type
Speaker Unit
LF
10" cone 12" cone 15" cone 15" cone × 2
HF
1" V.C.driver 2" V.C.driver
Frequency Response
70Hz-20kHz 60Hz-16kHz 55Hz-16kHz 42Hz-16kHz
Power Capacity
NOISE*
125W 175W 250W 500W
PGM
250W 350W 500W 1000W
MAX
500W 700W 1000W 2000W
Nominal Impedance
8Ω 4Ω
Sensitivity
96dB SPL
(1W, 1m)
97dB SPL (1W, 1m) 99dB SPL (1W, 1m)
99dB SPL
(1W, 1m)
Nominal Dispersion
Horizontal
40˚ 90˚ 90˚ 40˚ 90˚ 90˚ 40˚ 90˚
Vertical
60˚ 40˚ 40˚ 90˚ 40˚ 40˚ 90˚ 40˚
Crossover Frequency
1.8kHz 2kHz 1.7kHz 1.5kHz
Input Connectors
1/4" Phone Jack × 2,
Neutrik Speakon NL4MP × 2
Barrier Strip
Terminal
1/4" Phone Jack × 2,
Neutrik Speakon NL4MP × 2
Barrier Strip
Terminal
1/4" Phone Jack × 2,
Neutrik Speakon NL4MP × 2
Dimensions (W × H × D)
556 × 349
× 273mm
416 × 628
× 329mm
416 × 620
× 329mm
628 × 410
× 339mm
485 × 715
× 373mm
485 × 707
× 373mm
715 × 479
× 339mm
491 × 1163
× 593mm
Weight
13.3Kg 21.3Kg 21.8Kg 21.8Kg 30.3Kg 29.9Kg 28.8Kg
55.0Kg
Included Accessories
——
Eyebolt
(3/8") × 4
——
Eyebolt
(3/8") × 4
——
Model CW115V CW118V CW218V
Enclosure
Bass Reflex Type
Speaker Unit
15" cone 18" cone 18" cone × 2
Frequency Response
35Hz-2kHz 30Hz-2kHz
Power Capacity
NOISE*
250W 300W 600W
PGM
500W 600W 1200W
MAX
1000W 1200W 2400W
Nominal Impedance
8Ω 4Ω
Sensitivity
95dB SPL (1W, 1m) 96dB SPL (1W, 1m) 98dB SPL (1W, 1m)
Recommended Crossover Frequency
90Hz, 12dB/oct.
Input Connectors
1/4" Phone Jack × 2, Neutrik Speakon NL4MP × 2
Dimensions (W × H × D)
500 × 607 × 528
mm
605 × 720 × 637
mm
1217 × 574 × 655
mm
Weight
32.5Kg 43.0Kg 74.5Kg
C112V/C112VA /C115V/C115VA CM10V/CM12V/CM15V C215V
CW115V/CW118V CW218V
Unit: mm
Specifications and descriptions
in this owner’s manual are for
information purposes only.
Yamaha Corp. reserves the right
to change or modify products or
specifications at any time with-
out prior notice. Since specifica-
tions, equipment or options may
not be the same in every locale,
please check with your Yamaha
dealer.
*: EIA RS-426
33
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
Technical Data/Kennlinien/Données techniques/Datos técnicos
■
Frequency Response/Impedance
• CM10V • C115V/CM15V/C115VA
• C112V/CM12V/C112VA • C215V
• CW115V • CW118V
• CW218V
10k1k100
20
4
8
16
FREQUENCY(Hz)
RESPONSE(dB)
60
70
80
90
100
110
10k1k100
20
4
8
16
FREQUENCY(Hz)
RESPONSE(dB)
60
70
80
90
100
110
10k
4
1k100
20
60
70
80
90
100
110
8
16
FREQUENCY(Hz)
RESPONSE(dB)
10k1k100
20
2
4
8
FREQUENCY(Hz)
RESPONSE(dB)
60
70
80
90
100
110
16
10k1k100
20
4
8
16
FREQUENCY(Hz)
RESPONSE(dB)
60
70
80
90
100
110
10k
4
1k100
20
60
70
80
90
100
110
8
16
FREQUENCY(Hz)
RESPONSE(dB)
10k
4
1k100
20
60
70
80
90
100
110
8
16
FREQUENCY(Hz)
RESPONSE(dB)
2
ClubV.book Page 33 Tuesday, February 14, 2006 9:16 AM
34
■
Horizontal Directivity
• CM10V
• C112V/CM12V/C112VA
• C115V/CM15V/C115VA
• C215V
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
50
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0°
120°
90°
50
50
6
0°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
ClubV.book Page 34 Tuesday, February 14, 2006 9:16 AM
35
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
■
Vertical Directivity
• CM10V
• C112V/CM12V/C112VA
• C115V/CM15V/C115VA
• C215V
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
15
0°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300°
270
°
2
4
0
°
210
°
180
°
1
5
0°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90
°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
50
°
120°
90
°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
15
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 500Hz
• 1kHz
• 2kHz
0°
330
°
300
°
270
°
2
4
0
°
210
°
180
°
1
5
0
°
120°
90°
50
50
6
0
°
30°
40 40302010030 20 10 0
• 4kHz
• 8kHz
• 16kHz
ClubV.book Page 35 Tuesday, February 14, 2006 9:16 AM
For details of products, please contact your nearest Yamaha
representative or the authorized distributor listed below.
Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou
au distributeur le plus proche de vous figurant dans la liste suivante.
Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten
Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen
Bestimmungsländern erhältlich.
Para detalles sobre productos, contacte su tienda Yamaha más cercana
o el distribuidor autorizado que se lista debajo.
Manual Development Group
© 2003 Yamaha Corporation
WK60300 Published 09/2018 YJHI-W-D0
Yamaha Pro Audio global website
https
://www.yamaha.com/proaudio/
Yamaha Downloads
https://download.yamaha.com/
Head Office/Manufacturer: Yamaha Corporation 10-1, Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650, Japan
(For European Countries) Importer: Yamaha Music Europe GmbH Siemensstrasse 22-34, 25462 Rellingen, Germany
CANADA
Yamaha Canada Music Ltd.
135 Milner Avenue, Toronto, Ontario,
M1S 3R1, Canada
Tel: +1-416-298-1311
U.S.A.
Yamaha Corporation of America
6600 Orangethorpe Avenue, Buena Park, CA 90620,
U.S.A.
Tel: +1-714-522-9011
MEXICO
Yamaha de México, S.A. de C.V.
Av. Insurgentes Sur 1647 Piso 9, Col. San José
Insurgentes, Delegación Benito Juárez, México,
D.F., C.P. 03900, México
Tel: +52-55-5804-0600
BRAZIL
Yamaha Musical do Brasil Ltda.
Rua Fidêncio Ramos, 302 – Cj 52 e 54 – Torre B – Vila
Olímpia – CEP 04551-010 – São Paulo/SP, Brazil
Tel: +55-11-3704-1377
ARGENTINA
Yamaha Music Latin America, S.A.,
Sucursal Argentina
Olga Cossettini 1553, Piso 4 Norte,
Madero Este-C1107CEK,
Buenos Aires, Argentina
Tel: +54-11-4119-7000
PANAMA AND OTHER LATIN
AMERICAN COUNTRIES/
CARIBBEAN COUNTRIES
Yamaha Music Latin America, S.A.
Edif. Torre Banco General, Piso 7, Urbanización
Marbella, Calle 47 y Aquilino de la Guardia,
Ciudad de Panamá, República de Panamá
Tel: +507-269-5311
THE UNITED KINGDOM/IRELAND
Yamaha Music Europe GmbH (UK)
Sherbourne Drive, Tilbrook, Milton Keynes,
MK7 8BL, U.K.
Tel: +44-1908-366700
GERMANY
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-303-0
SWITZERLAND/LIECHTENSTEIN
Yamaha Music Europe GmbH, Branch
Switzerland in Thalwil
Seestrasse 18a, 8800 Thalwil, Switzerland
Tel: +41-44-3878080
AUSTRIA/BULGARIA/
CZECH REPUBLIC/HUNGARY/
ROMANIA/SLOVAKIA/SLOVENIA
Yamaha Music Europe GmbH
Branch Austria
Schleiergasse 20, 1100 Wien, Austria
Tel: +43-1-60203900
POLAND
Yamaha Music Europe GmbH
Sp.z o.o. Oddział w Polsce
ul. Wielicka 52, 02-657 Warszawa, Poland
Tel: +48-22-880-08-88
MALTA
Olimpus Music Ltd.
Valletta Road, Mosta MST9010, Malta
Tel: +356-2133-2093
NETHERLANDS/BELGIUM/
LUXEMBOURG
Yamaha Music Europe Branch Benelux
Clarissenhof 5b, 4133 AB Vianen, The Netherlands
Tel: +31-347-358040
FRANCE
Ya m ah a M u s i c E u ro p e
7 rue Ambroise Croizat, Zone d'activités de Pariest,
77183 Croissy-Beaubourg, France
Tel: +33-1-6461-4000
ITALY
Yamaha Music Europe GmbH, Branch Italy
Via Tinelli N.67/69 20855 Gerno di Lesmo (MB),
Italy
Tel: +39-039-9065-1
SPAIN/PORTUGAL
Yamaha Music Europe GmbH Ibérica, Sucursal
en España
Ctra. de la Coruña km. 17,200, 28231
Las Rozas de Madrid, Spain
Tel: +34-91-639-88-88
GREECE
Philippos Nakas S.A. The Music House
19th klm. Leof. Lavriou 190 02 Peania – Attiki,
Greece
Tel: +30-210-6686168
SWEDEN/FINLAND/ICELAND
Yamaha Music Europe GmbH Germany filial
Scandinavia
JA Wettergrensgata 1, 400 43 Göteborg, Sweden
Tel: +46-31-89-34-00
DENMARK
Yamaha Music Denmark,
Fillial of Yamaha Music Europe GmbH, Tyskland
Generatorvej 8C, ST. TH. , 2860 Søborg, Denmark
Tel: +45-44-92-49-00
NORWAY
Yamaha Music Europe GmbH Germany -
Norwegian Branch
Grini Næringspark 1, 1332 Østerås, Norway
Tel: +47-6716-7800
CYPRUS
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-303-0
RUSSIA
Yamaha Music (Russia) LLC.
Room 37, entrance 7, bld. 7, Kievskaya street,
Moscow, 121059, Russia
Tel: +7-495-626-5005
OTHER EUROPEAN COUNTRIES
Yamaha Music Europe GmbH
Siemensstrasse 22-34, 25462 Rellingen, Germany
Tel: +49-4101-3030
Ya m ah a M u s i c G u l f F Z E
JAFZA-16, Office 512, P.O.Box 17328,
Jebel Ali FZE, Dubai, UAE
Tel: +971-4-801-1500
TURKEY
Yamaha Music Europe GmbH
Merkezi Almanya Türkiye İstanbul Şubesi
Mor Sumbul Sokak Varyap Meridian Business
1.Blok No:1 113-114-115
Bati Atasehir Istanbul, Turkey
Tel: +90-216-275-7960
OTHER COUNTRIES
Ya m ah a M u s i c G u l f F Z E
JAFZA-16, Office 512, P.O.Box 17328,
Jebel Ali FZE, Dubai, UAE
Tel: +971-4-801-1500
THE PEOPLE’S REPUBLIC OF CHINA
Yamaha Music & Electronics (China) Co.,Ltd.
2F, Yunhedasha, 1818 Xinzha-lu, Jingan-qu,
Shanghai, China
Tel: +86-400-051-7700
INDIA
Yamaha Music India Private Limited
P-401, JMD Megapolis, Sector-48, Sohna Road,
Gurgaon-122018, Haryana, India
Tel: +91-124-485-3300
INDONESIA
PT. Yamaha Musik Indonesia (Distributor)
Yamaha Music Center Bldg. Jalan Jend. Gatot
Subroto Kav. 4, Jakarta 12930, Indonesia
Tel: +62-21-520-2577
KOREA
Yamaha Music Korea Ltd.
11F, Prudential Tower, 298, Gangnam-daero,
Gangnam-gu, Seoul, 06253, Korea
Tel: +82-2-3467-3300
MALAYSIA
Yamaha Music (Malaysia) Sdn. Bhd.
No.8, Jalan Perbandaran, Kelana Jaya, 47301
Petaling Jaya, Selangor, Malaysia
Tel: +60-3-78030900
SINGAPORE
Yamaha Music (Asia) Private Limited
Block 202 Hougang Street 21, #02-00,
Singapore 530202, Singapore
Tel: +65-6740-9200
TAIWAN
Yamaha Music & Electronics Taiwan Co.,Ltd.
2F., No.1, Yuandong Rd., Banqiao Dist.,
New Taipei City 22063, Taiwan (R.O.C.)
Tel: +886-2-7741-8888
THAILAND
Siam Music Yamaha Co., Ltd.
3, 4, 15, 16th Fl., Siam Motors Building,
891/1 Rama 1 Road, Wangmai,
Pathumwan, Bangkok 10330, Thailand
Tel: +66-2215-2622
VIETNAM
Yamaha Music Vietnam Company Limited
15th Floor, Nam A Bank Tower, 201-203 Cach
Mang Thang Tam St., Ward 4, Dist.3,
Ho Chi Minh City, Vietnam
Tel: +84-8-3818-1122
OTHER ASIAN COUNTRIES
http://asia.yamaha.com/
AUSTRALIA
Yama h a M usi c A u str a l i a Pt y. L td .
Level 1, 80 Market Street, South Melbourne,
VIC 3205, Australia
Tel: +61-3-9693-5111
COUNTRIES AND TRUST
TERRITORIES IN PACIFIC OCEAN
http://asia.yamaha.com/
NORTH AMERICA
CENTRAL & SOUTH AMERICA
EUROPE
AFRICA
MIDDLE EAST
ASIA
OCEANIA
PA5 2
