Refer to Product Safety Manual for Safety Statements
Complete Owner’s Manual available online
Manual Operation
To cook food using a specic entered time and power level:
1. Open oven door and place food in oven. Close door.
2. Press TIME ENTRY
pad and enter cooking time.
3. Press a power level pad to change power level if desired (some
models).
• COOK LEVEL displays with the power setting.
4. If stage cooking is desired, press TIME ENTRY
pad and repeat steps
2 through 4.
5. Press START
pad.
6. At end of cooking cycle oven beeps and shuts off.
Programming Items
1. Open oven door.
2. Press and hold pad 1 for approximately 5 seconds.
3. Press pad to be reprogrammed.
4. Enter cooking time by using the number pads.
5. Press a power level
pad to change power level if desired.
6. If stage cooking is desired, press TIME ENTRY
pad.
• Display briey shows the stage number.
• Display changes to cook time and power level for the next stage.
7. Enter cook time and power level as in steps 4 and 5 (some models).
• To enter another cooking stage for that pad, press TIME ENTRY
pad
again.
• Up to four different stages can be programmed (some models).
8. Press START
pad to set new programming changes to the pad.
NOTE: T
o discard changes, press STOP/RESET pad or close oven door.
Quick Start Reference Guide
So...how do I use it? (Electronic Control)
X2 Programming
To change the cooking factor:
1. Open oven door.
2. Press and hold pad 1 for
approximately 5 seconds.
3. Press pad to be reprogrammed.
4. Press the X2 pad.
5. Press a numbered pad to
change the cooking factor.
• Cooking factor can be set from
10% to 100%.
• Default is 80%.
• Pad 5 would change the
cooking factor to 50%.
6. Press START
pad to save
changes.
X2 Pad
1. Open oven door and place food in oven. Close door.
2. Press X2 pad.
3. Press desired preprogrammed pad or pad sequence.
4. Oven begins cooking. Displayed cooking time is the total of original
cooking time and added X2 time.
Preprogrammed
Pads
To cook food using
preprogrammed cooking
sequences:
1. Open oven door and place food
in oven. Close door.
2. Press desired pad.
3. Oven begins to cook.
4. At end of cooking cycle oven
beeps and shuts off.
The switching operation of this microwave oven can cause voltage uctuations on the supply line. The operation of this oven under
unfavorable voltage supply conditions can have adverse effects. This device is intended for the connection to a power supply system
with a maximum permissible system impedance Zmax of 0.2 Ohms at the interface point of the user’s supply. The user has to
ensure that this device is connected only to a power supply system which fullls the requirement above. If necessary, the user
can ask the public power supply company for the system impedance at the interface point.
Oven Wall Clearances
A—For North American (UL/CSA) models, allow at least
2” (5.1 cm) of clearance around top of oven. For
International (50 Hz) models, allow at least 12” (30
cm) of clearance around top of oven. Proper air
ow around oven cools electrical components. With
restricted air ow, oven may not operate properly and
life of electrical parts is reduced.
B—Allow at least 2” (5.1 cm) between air discharge on
back of oven and back wall.
C—Allow at least 2” (5.1 cm) of clearance around sides
of oven.
C
A
B
