HIGH VELOCITY TILT DRUM FAN
MODEL HVD-24CS
OWNER'S MANUAL
READ & SAVE THESE INSTRUCTIONS
621-1739
Adjust the desired speed by rotating the switch knob
(3-speed) --- 0 Stop 1 Low 2 Medium 3 High
Tilt the fan head up or down for desired direction of air flow.
1
3
8
7
9
2
4
5 6
REPLACEMENT PARTS LIST
PART # DESCRIPTION
1
2
3
4
5
6
7
8
9
Fan Blade
Motor
Capacitor
Switch
Switch Box
Switch Knob
Split Pin
Wheel
Rubber Feet
If you have any problems, operaon quesons or comments about this
product, contact us toll free at 1-888-372-8518 from 7:00 a.m. to 4:00 p.m. PST,
Monday to Friday or email us at customerservice@masterforce.info
NOW YOU CAN REGISTER ONLINE
www.masterforce.info
