Model: SGR-PPS1200-3
1200W Portable Power Station
Emergency Power Source
User Manual
— 1 —
Thank you for purchasing this 1200W portable power station.
This portable power station has a powerful battery capacity of 1008Wh,
supporting AC wall outlets, solar panels and vehicle charging ways, and is
designed to keep your electronic devices powered while on the go.
It comes with AC outlets, 12V DC output ports, 12V car port, Type-C port and
fast charging USB ports 3.0 for your convenience. Perfectly for outdoor travel,
it is compatible with most electronic devices such as drones, laptops, lights,
smart phones, tablets and cameras.
You can charge your electrical or digital devices with this unit in case of a
power failure or when you are out or on a road trip.
It also works as an emergency power kit. Especially, it’s suitable for locations
that are prone to severe weather patterns and natural disaster related power
failures including typhoons, floods, hurricanes, earthquakes, forest fires,
snowstorms and low-temperature disaster-prone areas.
The power station is also suitable for camping and works well in keeping
outdoor electrical appliances charged for uses such as night time power
supply, medical power supply and general household electricity storage.
Before using our power station, please read the following instructions carefully:
1. This power station has a built in lithium battery which is highly sensitive to
high temperature - Keep it away from heat sources like direct fire or any heat
sources.
2. Keep away from moisture or water.
3. Do not disassemble microwave, puncture, incinerate or insert foreign objects
into the power station.
4. Do not crush, bend, shred, drop or place heavy objects on top of the device.
5. Do not use the product if damaged or punctured.
6. Always be prepared - Charge the unit every three months also if it is not used.
1*User Manual
Warm Tips:
Preface
Package Contents
1*AC Power Cord
1*Car Cigarette Cable 1*MC4 Cable
1 2 3
4
Model: SGR-PPS1200-3
1200W Portable Power Station
Emergency Power Source
User Manual
— 2 —
Battery Capacity
AC Input Charging
Car Input Charging
Solar Input Charging
Output Port
LED Light
Safety Protection
Operation Temperature
Battery Cycle Life
Pass-Through Charging
Weight
0~40℃(32~104℉)
2500 times, SOH≥70%
Support
13kg/28.6lbs
2W Max, 3 Levels(L/M/H adjustable), SOS function
AC Output Waveform
Pure Sine Wave
Short-Circuit
Over-Current
Over-Voltage
Low-Voltage
Over-Load
Over-Temperature
AC output*4: 110V±10%, 60Hz±5, 1200W, Peak 2400W
1*Cigarette Lighter, 2*DC5521 Rated Output
13.8V/10A（Total 10A Max）
LiFePO4 1008Wh±5%(45Ah/22.4V)
AC100~120V 700W Max
DC12V~24V/10A Max
DC12V~60V/10A 400W Max
Technical Specification
USB-A1: 2*5V2.4A AUTO
USB-A2: 2*QC18W Max,
(5V3A&9V2A&12V1.5A QC3.0)
USB-C: 2*PD60W Max,
(5V3A&9V3A&12V3A&15V3A&20V3A PD3.0)
— 3 —
1. Press the power button or any other port button to turn on the unit. When
not using certain ports, it is best to turn them off to conserve power.
2. Read the LCD screen to know which port is turned on.
3. Plug in your gear.
4. Your unit supports full pass-through charging so you can charge your
power station and run your gear at the same time.
*The circuit protector is an electrical safety switch designed to protect your
unit from damage caused by over-current or short circuit. When the AC
output exceeds 15A or 1500W, it will trip automatically. Press it once to reset
the unit after these symptoms cleared.
Using Your 1200W Power Station
Product Diagram
Cooling Fan
120VAC/60Hz/15A MAX
Circuit Protector
125VAC/15A
LED Button
LED
ON/OFF
Button
AC Button
USB Button
DC Input
12-60V
HandleHandle
DC12V/10A
DC Output
12V/3A*2
AC output
1200W Max
USB-C PD60W*2
USB-A QC3.0*2
USB-A 5V 2.4A*2
DC Button
AC Charging
Mode Switch
— 4 —
LCD Display
*The remaining usage time depends on the real-time output wattages of the
loaded devices.
The remaining hours tells the remaining charge/discharge time. It will prioritize
displaying the remaining discharge time when charging and discharging
simultaneously.
(The remaining time may has errors and the data is for reference only.)
Solar Panel Input Indicator
LED Indicator
Remaining Battery
Percentage
Input Power Indicator
Remaining Usage Time or
Remaining Charging Time(Hour)
Output Power
AC Output Indicator
UPS Function Indicator
DC Output Indicator
USB Output Indicator
Input Power
Charging Mode Indicator(Q,N,S)
Output Power Indicator
Temperature Warning
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
— 5 —
To avoid forgetting to turn off the output during use that results in battery
consumption, the unit will turn to Auto-Sleep Mode when no device is
connected or the connected device is less than or equal to a certain value.
When without charging, and the AC&DC&USB outputs≤2W, the device will
automatically shut down after 1 hour.
Auto-Sleep Mode:
Ways to Recharge
1.AC Wall Charging
2.DC Vehicle Charging
Please connect the unit directly to the vehicle plug-in cigarette lighter port
via the car charging cable.
12V Car Charging
7-8 Hours
24V Car Charging
3.5-4.5 Hours
Cigarette lighter MUST be fully inserted into the lighter port of the machine.
S: Silent Charging Mode
7-8 Hours
N: Normal Charging Mode
4-5 Hours
Q: Quick Charging Mode
1.5-2 Hours
Please plug the unit into the standard wall outlet and start charging.
This power station supports Quick/Normal/Silent charging modes. The default charging mode
of the unit is “N”charging mode. Press the AC Charging button to switch these 3 charging
modes.
— 6 —
3.Solar Charging
Note: Please make sure your solar panels comply with Open Circuit Voltage of DC12-60V.
The Max Solar Input Power of the power station is 400W.
We recommend a 200W-400W solar panel with the voltage of DC12V-60V.
6.6-7.6 hours (in full sun)
1*200W Solar Panel
3.3-4.3 hours (in full sun)
2*200W Solar Panel
Never use higher than DC 60V to recharge this power station.
ONLY use solar panels with compatible voltage.
UPS
UPS Bypass Mode: Connect the power station with the AC power, then turn on the
AC output, and the ‘UPS’”AC“ will be on display. When on this mode, the AC
power will directly support the loads on AC output ports and charge the unit.
The UPS Bypass Mode prioritizes providing AC output power, then the excess power
will supply for charging the power station.
Note: Max. output power: 1200W.
The AC inverter is disabled under UPS Bypass Mode. The unit won’t enter this mode
unless connecting with AC power AND turning on the AC output.
— 7 —
Emergency:
The power station can be used as an emergency power supply during power
failures. It is especially suitable for locations that are prone to severe weather
patterns and natural disasters including floods, hurricanes, earthquakes,
forest fires, and snowstorms.
Outdoor Activities:
Camping, outdoor celebrations, fishing, climbing, outdoor photography,
RC helicopter and drone charging, farming and bird watching.
Home Backup:
Home and office electrical device charging, energy-saving lamps, television,
mini refrigerators, holiday decoration lights, printers, laptops, fans and smart
mobile phones.
Usage
NOTES:
1.Run time=1008Wh*90%(conversion rate)/Your device's power(Watts).
2.Support all electronic devices less than 1200 Watts.
3.It is recommended to use a DC port instead of an AC outlet to power your CPAP machine.
4.*The usage time for refrigeration machines with compressors mainly depends on temperature
setting and start frequency of compressors, it’s usually lasting longer time than certain reference
time.
5.The above charging times are calculated as a reference guide only. The actual usage time
will depend on the power of the connected devices.
Usage time of devices
Projector
6 Hrs
(150W)
*Mini Cooler
18 Hrs+
(50W)
Blender
3 Hrs
(300W)
Coffee Maker
1 Hrs
(800W)
Washer
1.8 Hrs
(500W)
Hand Drill
1.5 Hrs
(600W)
*Refrigerator
9 Hrs+
(100W)
Microwave
1 Hrs
(900W)
CPAP
22.6 Hrs
(40W)
TV
10 Hrs
(90W)
— 8 —
1. How long will the SGR-PPS1200-3 run my device?
Running time=1008*90%(conversion rate)/Device Rated Power. Eg.
If you run a 800W microwave oven, the running time is: 1008Wh x 90% / 800W ≈ 1.1hrs.
The actual working time may vary based on various circumstances.
2. Is lithium-ion battery the same as LiFePO4? Which battery is better for a solar
generator or power station?
No, there are a few differences in performance, chemical composition, and
longevity between lithium-ion and LiFePO4 batteries. Both are safe and reliable
choice for solar generator and power station. They have a longer lifespan and
can charge most homes efficiently. But LiFePO4 batteries have a longer lifespan,
enhanced safety and increased thermal stability.
3. What is the life expectancy?
It is rated for 2500 full charge cycles. After that, you will have about 70% of your
original capacity, charge-discharge cycles SOH≥70%. TIP: Please leave ≥30% battery
quantity on LCD and then charge the power station soon which can use longer.
4. Can I charge it with solar panels from other manufacturers?
Yes. Open circuit voltage: 12-60V/10A, Total solar input: 400W Max, our power
generator is built in M20 input port. We recommend ALLWEI 200W Solar Panel.
5. Why does the power station has Autp-Sleep Mode?
To avoid battery consumption due to not turning off the output after used, the unit
will switch to the Auto-Sleep Mode. Whe the unit detects that no device is
connected or the connected devices are ≤ 2W, it will automatically shut
off after 1 hour.
Set up time to 1 hour or 12 hours by long pressing "USB" button for 5 seconds. Please
check the time on the LCD screen within 5 seconds after hearing the buzzer sounds.
It shows the set standby time.
6. How to reset the power station when over-load protection?
If your device watts is beyond the 1200W, it will trigger over-load protection.
Please press the "Circuit Protector" Button on the back of the battery to reset
the power station.
7. Is the battery has UPS Function?
Yes. The 1200W Power Station has Uninterruptible Power Supply (UPS) function.
When wall outlet is interrupted, UPS will supply 110V AC power to the load in less
than 10ms, which is faster, safer and more intelligent than ordinary power stations.
FAQS and Solutions
— 9 —
Maintenance and Storage
1.When not using the unit for extended periods of time, power off the unit and disconnect the
AC adapter from the outlet.
2.Charge the unit to 80% capacity every 3-6 months for long-term storage.
3.When the battery capacity drops to 20%, recharge the power station in time to extend the
battery life.
4.Clean the unit with a dry cloth gently and carefully.
5.DO NOT stack anything on top of the unit either in storage or in use.
6.Store it in a dry and cool place with temperature range between -20℃~60℃,
and humidity 20%~85%RH.
7.Avoid contact with corrosive substances fire and heat sources.
Common Trouble Shooting
Unit can not charging from
AC wall outlets
AC charging fault
1.Please ensure to use original AC Power Cord.
2.Please check if the AC wall plug is correct
connection.
If not solved,Please contact our after-sales
service.
1.Please ensure solar charging connection
is correct under user manual.
2.Please ensure connected solar panel
specification is meet specified standard.
3.Please ensure solar panel charging under
sunlight environment.
4.If not solved,Please contact our
after-sales service.
Resolve the problem by pulling out plug or
remove electrical devices,the product can
recover itself after re-start.
If not solved,Please contact our after-sales
service.
DC solar charging faultUnit can not charging from
solar panel
LCD Screen icon flash
"AC"
"DC"
"USB"
Over-current protection
Short circuit protection
Over-voltage protection
Low-voltage protection
Over-Load protection
High-temperature warning Power station can recover itself after
battery cooled.
High-temperature icon
continuous appears
Failure Description Types Solutions
Warranty & Customer Service Support
Thanks for purchasing our 1200W portable emergency power station. The portable power station
is covered a warranty of 5 years from the date of its original purchasing. The warranty covers
material and manufacturing defects prior to being shipped to third parties. This warranty does
not apply: Any defects or damages caused by misuse of products, unauthorized modification,
dis-assembly or operation not in accordance with the official instructions or manuals.
If you have any after-sales questions or need further technical assistance, please feel free to
contact the email：
a) Do not overcharge the internal battery. See instruction manual.
b) Do not smoke, strike a match or cause a spark in the vicinity of the
POWER STATION.
c) Only charge the internal battery in a well ventilated area.
d) Risk of Electric Shock. Connect only to properly grounded outlets.
e) Risk of Injury to Persons. Do not use this product if the power cord or the
battery cables are damaged in any way.
f) Keep away from moisture or water. Do not use outdoors on rainy days.
CAUTION
