Front Panel Installation
INSTALL MOUNTING PANEL
Remove protective material from the front panel assembly.
Place the assembly on a protected work surface then
remove one screw from the bottom of the assembly. Refer
to the illustrations below. Separate the mounting panel from
the assembly then install the front mounting panel using six
8–32 x
3
/8" hex head screws. Insert rubber bumpers, round
side facing the warming drawer, onto the mounting panel.
FRONT PANEL WITH STAINLESS HANDLE
1 Slide the top lip of the front panel over the front mounting
panel. Insert three 8–18 x
1
/2" screws through the top rear
of the front panel. Refer to the illustration below.
2 Insert the remaining three screws into the bottom of the
front panel.
FRONT PANEL WITH BLACK HANDLE
1 Slide the side anges of the front panel over the front
mounting panel. Insert three 8–18 x
1
/2" screws through
the top rear of the front panel. Refer to the illustration
below.
2 Insert the remaining three screws into the bottom rear of
the front panel.
Warming Drawer Front Panel Installation
wolfappliance.com 800.222.7820
page 1 of 1
823486 REV-B 12/2013
TOP LIP
Front panel with stainless
handle.
Front panel with black handle.
Bottom screw removal.
Mounting panel installation.
