Tripp Lite SUINT1500LCD1U SmartOnline 1500VA 1440W 208/230V Double-Conversion UPS - 5 Outlets, Network Card Option, LCD, USB, DB9, 1U Rack

Owner's Manual

For SUINT1500LCD1U. Also, The document are for others Tripp Lite models: SUINT2000LCD1U

PDF File Manual, 156 pages, Read Online | Download pdf file

Owner’s Manual

SmartOnline

True On-Line

Single-Phase 1U UPS Systems

with Pure Sine Wave Output

Models: SUINT1500LCD1U, SUINT2000LCD1U

(Series Numbers: AG-03AC, AG-0569)

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

SAVE THIS MANUAL

This manual contains important instructions and warnings that you should follow

during the installation, operation, storage and maintenance of this product.

Failure to heed these instructions and warnings will void the warranty.

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Español 32 • Français 63 • Русский 94 • Deutsch 125

Loading ...

File type: PDF

File name: 81799738_suint1500lcd1u-new.pdf

File size: 3.47 MB

File Language: English, French, Spanish, German, Russian

Pages: 156

Author: Tripp Lite

File created: 2023-11-23

Published: 2023-11-27

Updated: 2023-12-12

Download File

Specifications

Brand: Tripp Lite

Model: SUINT1500LCD1U

Category: Computing

Nominal Input Voltage(s) Supported: 200V AC; 208V AC; 220V AC; 230V AC; 240V AC

Nominal Input Voltage Description: 230V factory default

Input Frequency: 50 / 60 Hz

Power Factor (Input): 0.98 minimum (full load, nominal input voltage)

Power Factor: .96

Nominal Voltage Details: 230V factory-default nominal voltage

Output Voltage Regulation (Line Mode): +/- 3%

Output Voltage Regulation (Economy Line Mode): +/- 10%

Output Voltage Regulation (Battery Mode): +/- 3%

Included Output Power Cables: Includes 2 C13 to C14 power cables

Output AC Waveform (Battery Mode): Pure Sine wave

Nominal Output Voltage(s) Supported: 200V; 208V; 220V; 230V; 240V

Battery Type: Valve Regulated Lead Acid (VRLA)

DC System Voltage (VDC): 48

UPS Power Module Dimensions (hwd, in.): 1.73 x 17.32 x 27.950

UPS Power Module Weight (kg): 20.50

UPS Power Module Weight (lbs.): 45.19

Battery Mode Heat Dissipation (BTU/Hr) @ Full Load: 799

UPS Input Connection Type: C14 inlet

Product Compliance: CE (Europe); FCC Part 15 Class A (USA); RoHS

UPS Input Cord Length (ft.): 6

Output Capacity (VA): 1500

Output Capacity (kVA): 1.5

Output Capacity (Watts): 1440

Output Capacity (kW): 1.44

Rack Height: 1U

Minimum Required Rack Depth (inches): 31

Primary UPS Depth (mm): 710

Primary UPS Height (mm): 44

Primary UPS Width (mm): 440

Shipping Dimensions (hwd / in.): 6.10 x 22.83 x 32.68

Shipping Weight (lbs.): 52.91

Unit Dimensions (hwd / in.): 1.730 x 17.320 x 27.950

Unit Weight (lbs.): 45.190

Runtime Full Load (min.): 3 min. (1440W)

Runtime Half Load (min.): 10 min. (720W)

UPS AC Suppression Response Time: Instantaneous

EMI / RFI AC Noise Suppression: Yes

AC Suppression Response Time: Instantaneous

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: 5° to 122°F (-15° to 50°C)

Relative Humidity: 0% to 95%, non-condensing

AC Mode Efficiency Rating (100% Load): 89%

AC Economy Mode Efficiency Rating (100% Load): 98%

Audible Noise: 65 dBA at 1m front side

Operating Elevation (m): Up to 1000m above sea level with de-rating

UPS Housing Material: Steel

View in the file: Full Specifications
