www.comfortzoneproducts.com
Save These Instructions
Features:
• ON/OFF Switch with Speed Settings
• Adjustable Vertical Tilt
• Maximum Air Movement
• All Metal Construction
• Metal Fan Blades
• Safety Grilles
• 120V A.C. / 60Hz.
CZHV18B Series
18" High Velocity Fan
2
2
www.comfortzoneproducts.com
INTENDED USE:
This product is intended for indoor residential and ofce use only,
not for industrial or other commercial applications. Use only with
electrical wiring that is in good working order and that meets
applicable codes and ordinances. If you have any questions
whether your wiring is adequate, consult a qualied electrician.
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word "WARNING" to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
IMPORTANT INSTRUCTIONS
As with all electrical appliances, basic safety precautions should
always be followed to reduce the risk of electric shock, re, or
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
re or injury to persons.
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non‑combustible, level surface.
• Always unplug fan when not in use, when moving from place
to place, when assembling or disassembling parts, and before
cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non‑window models).
• Do not operate the fan with blade guards or any safety device
removed.
• Avoid the use of extension cords due to risk of re. If an
extension cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from trafc
area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the
fan. Doing so may cause electric shock and/or re hazard.
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
READ & SAVE THESE
INSTRUCTIONS
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
ooded basements.
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
combustible materials or ammable gases or sources of heat.
DO NOT USE in areas where gasoline, paint or ammable
materials are used or stored. To prevent a possible re, do not
block air intakes or exhaust in any manner. Do not insert or allow
foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock, re, or damage the fan.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code.
CAUTION: TO PREVENT ELECTRIC SHOCK,
this product has a three prong grounded plug that must be
inserted into a matching properly grounded outlet to reduce
the risk of electrical shock. Do not attempt to defeat this safety
feature.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, do not use this product with any
solid‑state speed control device.
DO NOT operate any fan with a damaged cord or plug or after
fan malfunctions, has been dropped or damaged in any manner.
Do not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact Comfort Zone
®
Customer Service by telephone or
mail for information and assistance.
DO NOT run power cord under carpeting. DO NOT cover cord
with throw rugs, runners or the like. Arrange cord away from
trafc area where it will not be tripped over. Avoid the use of
extension cords due to risk of re. If an extension cord must
be used, the cord must be minimum 14 AWG and rated not
less then 1875 watts. Do not use an extension cord unless the
plug can be completely inserted into its receptacle. Unplug
the fan when not in use. Do not operate fan with its ventilation
obstructed.
3
3
www.comfortzoneproducts.com
USAGE:
Fan Operation: Always operate the fan in the upright position
following all instructions and recommendations listed in this
manual.
Fan Location: Place the fan in the area of the room that will
provide proper fan cooling.
Fan Connection: Plug fan directly into 120 volt A.C., 60 Hz wall
outlet. Be sure plug ts tightly in outlet. A loose connection may
cause overheating and damage to the plug or fan.
Note: To prevent overloading a circuit, do not plug the fan into a
circuit that is servicing other electrical needs.
Turning Fan On: Place fan on stable level surface. Plug fan into
properly grounded outlet. To start the fan, turn the switch from
the OFF position to the desired fan speed.
Turning Fan Off: To turn the fan off, turn the switch from the
current fan speed setting to the off position. Remove plug from
outlet.
Adjusting Fan Tilt: To adjust the tilt angle, use supplied knob
wrench to loosen the adjustment screw. After adjustment,
retighten the adjustment screw. Save knob wrench for future use.
Fan Cradle Assembly: Simple assembly is required to use this
fan.
1. Align Cradle Base (packed separately) with support brackets
attached to fan body sides. Note: you may need to ex the
parts to make them align properly.
2. Insert support bracket into opening of Cradle Base. Press
spring loaded button down to allow it to insert into Cradle
Base, see Fig 1.
3. Press support bracket into Cradle Base until spring button
protrudes out open hole in Cradle Base, see Fig. 2.
4. Repeat above process for opposite side of fan.
Fig 1
Spring
Button
Cradle
Base
Fig 2
Support
Bracket
Spring
Button
4
4
www.comfortzoneproducts.com
Rev. 09/16/21
LIMITED WARRANTY
This unit is guaranteed to the original retail purchaser
against defects in quality or workmanship for a
period of one year from the date of original purchase.
If this unit fails because of a manufacturing defect
within 30 days of purchase, return the unit, with your
receipt, to the retailer. After 30 days, but within the
warranty period, if the unit was purchased within the
continental United States, return it, freight prepaid,
to World and Main for repair or replacement. If the
unit was purchased outside the continental United
States, return the unit to the place of purchase. This
warranty does not cover damage caused by misuse,
abuse, overheating or alteration. Repairs made by
anyone other than World and Main are not covered in
this warranty. World and Main will not be held liable
for any losses due to neglectful operation. All implied
warranties, including the warranties of merchantability
and of tness of purpose, if applicable, are hereby
limited in duration to the period of one year from the
date of original retail purchase. Some states do not
allow limitations on how long an implied warranty
lasts, so the above limitations may not apply to you.
Incidental or consequential damages arising from a
breach of either express or implied warranties are
hereby disclaimed and excluded. Some states do
not allow the exclusion of limitation of incidental or
consequential damages, so this limitation or exclusion
may not apply to you. Upon the expiration of this
warranty all such liability will terminate. No other
warranties are expressed or implied.
This warranty gives you specic legal rights, and you
may also have other rights which vary from state to
state. No informal dispute settlement mechanisms
are available. This limited warranty is given in lieu of
all other warranties.
Manufactured for:
World and Main (Cranbury), LLC
324A Half Acre Rd.
Cranbury, NJ 08512 USA
800‑221‑6895
www.comfortzoneproducts.com
CARE AND MAINTENANCE:
Cleaning: CAUTION‑Before cleaning the fan be sure to
disconnect power cord from the plug. Unscrew and remove
front grille only. Clean the grille and fan blade surface with a
clean damp cloth. Do not use harsh chemical or abrasive
cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES IN
WATER. Replace front grille before fan use. Allow fan to dry
completely before use. Periodic grille cleaning with a vacuum
will prevent dust build up. The motor does not require any
interior maintenance, cleaning or lubrication.
Maintenance: The Internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN
PLACE. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR
BECOME DAMAGED IN ANY WAY.
STORAGE: Keep original package for storage of the fan. Coil
and tie the power cord to avoid damage during storage.
Note: Some models come with a plug where you can replace a
fuse. If your model has this, please read and follow the below
instructions to replace the fuse.
This product employs overload protection (fuse). A blown fuse
indicates an overload or short‑circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per
the user servicing instructions (follow product marking for
proper fuse rating) and check the product. If the replacement
fuse blows, a short‑circuit may be present and the product
should be discarded or returned to an authorized service facility
for examination and/or repair.
Fuse Replacement:
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on top of
attachment plug towards blades. See Fig. 2.
3. Remove fuse carefully. Use a small tool to pry the end of the
fuse from holder cavity. Be careful not to break glass window.
4. Replace fuse. WARNING: Risk of re. Replace fuse only with
identical 2.5 or 5.0 Amp, 125 Volt fuse (3.6mm x 10mm).
Besure fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
Fig 1 Fig 2 Fig 3
Slide Cover to Open
