TO BE REMOVED BY THE CUSTOMER AFTER INSTALLATION IS COMPLETE
[]
[]
[] INSTALLATION CHECKOFF UST
Doors Ice Maker
[] HandIesare secure and tight
[] Door seals completely to cabinet on all sides
[] Freezer door is level across the top
[] House water supply connected to refrigerator
[] No water leaks present at att connections - recheck in 24 hours
[] Ice Maker is turned ON.
Leveling Final Checks
[] Refrigerator is level, side to side and tilted 1/4" (6mm) front to back
[] Toe grille is properly attached to refrigerator
[] Cabinet is setting solid on atl corners
Electrical Power
House power turned on
Refrigerator plugged in
[] Shipping material removed
[] Fresh Food and Freezer controls set
[] Crisper Humidity controls set
[] Registration Card sent in
f
Tools You Will Need:
Phillips'' head
3/5"
Fke@
)
1
4
HAND TRUCKING
• Load refrigerator from side of cabinet
only.
• Do not run retaining straps over
handles.
• Do not over-tighten retaining straps.
• Never use refrigerator handles to
move the refrigerator.
• Remove tape from doors only after
unit is in place.
INSTALLATION CLEARANCES
Allow the following clearances for ease of installation,
proper air circulation, and plumbing and electrical
connections:
• Sides & Top.......... 3/8"
• Back ....................... 1"
NOTE: If you are installing your refrigerator beside a wall,
leave 1/2" minimum between hinges and wall to allow for
the door to swing open.
7
Ensure icemaker to turned ON.
8
Plugi
2SHIPPING MATERIAL
2 PIECESOF TAPE
1 SHELF SPACER
TOE GRILLE
2 PIECESOF ,r_AM
AND TAPE
2 PIECESOF TAPE_
1 PIECE OF TAPE
2 PIECESOF TAPE_
4PIECESOF TAPE_
2PIECESOF TAPE
2 PIECESOF FOAM _
iiiilXii!i X _ R:i
1PIECEOFTAPE
1PIECEOFTAPE
2 PIECESOFTAPE
2PIECESOFTAPE
k, Remove Shipping material. (Features may vary per model.)
5LEVELING AND ADJUSTING
All four corners of refrigerator must rest firmly on a solid
floor. Your refrigerator has adjustable rollers to help level it
and to adjust the doors. ....
To level cabinet or change door height:
1. Remove toe grille.
2. Use a screwdriver,3/8"wrench, or nutdriver toadjust the
rollers.Toraisecabinet, tum screw clockwise.To lower
cabinet,tum screwcounterclockwise.
3
reverse osmosis system is not recommended.
When changing CONTROLS, wait 24 hours
before making additional adjustments.
:(U(%J%J%J%J%J%J ¸ :@: @ (U(%J%J%J%J%J%J%J%J%Rk
If you need to remove the
doors to get your refrigerator
into the house please see
"Door Removal and Reversal
Instructions" in your Use &
Care Manual
_, See "Normal Operating Sights & Sounds" in the Use & Care Manualso
you understand the sounds you may hear once your refrigerator is
running.
Please read entire Use & Care Manualto become aware of important
safety instructions and to become familiar witrh your new refrigerator.
Send in Registration card to register your refrigerator.
Congratulations! You are ready to enjoy your new refrigerator.
IF YOU ARE DISSATISFIED WITH THE INSTALLATION, PLEASE CALL THE STORE YOU PURCHASED IT FROM. P/N: 240568300
