2L PAINT TANK
INSTRUCTION MANUAL
2L PAINT TANK
01
NEED HELP? CONTACT US!
Have product questions? Need technical suppo? Please feel free to contact us:
02
WARNING!
Additional safety instructions for paint tanks
1. Read This Manual
This manual contains proper operating instructions for this paint tank.
2. Design Modications
Do not modify the tank design or construction. Drilling into the tank or altering its
design, could weaken the tank.
3. Cleaning and Maintenance
Clean and d the tank and lid according to the instructions in this manual. Make
sure all pos are free of hardened paint or other materials that could inteace
the movement of air. Improper cleaning could allow pressure to rise to dangerous
levels.
4. Reactive Chemicals
Do not use acids, caustic solutions, or halogenated hydrocarbon solvents. These
chemicals can corrode the lid gasket and safety valve seal, impairing the ability of
the tank to hold pressure.
5. Safety Valve Modications
Do not adjust the safety valve to change its pressure setting or defeat its
function. Tampering with the safety valve could raise tank pressure to dangerous
levels.
Caution
No list of Safety Guidelines is complete, because eve work environment is
dierent. Always place safety at rst place. Failure to use this tool could result
in serious personal injuries.
TANK TROUBLESHOOTING
03
Symptom
Air escaping from
regulator po.
Pressure dropping
slowly on regulator.
Fluid or air leak
at lid gasket.
Paint tends to settle
rapidly in tank.
Gauge not registering
air pressure.
Safety valve Popping
out.
Possible Cause
1. Broken or damaged
diaphragm in tank
regulator.
1. Diy or worn valve
seat in regulator.
2. Loose air ttings
leaking air.
1. Defective lid gasket.
2. Wing screw loose.
3. Di or foreign object
between gasket and rim.
1. Paint not mixed or
thinned suciently.
1. Air pressure tuned o.
2. Defective pressure
gauge.
1. Tank pressure too high.
2. Defects safety valve.
Solution
1. Replace tank
regulator.
1. Replace tank regulator.
2. Tighten loose air
ttings or remove
and re-install with
new pipe thread tape.
1. Replace lid gasket.
2. Tighten wing screws
evenly.
3. clean rim and gasket.
1. Mix or thin paint
according to
manufacturer’s
instructions.
1. Tum air pressure on.
2. Replace pressure
gauge.
1. Reduce tank pressure
to 25-30 psi.
2. Replace safety valve.
Lift
Air Inlet Hose
Lid
2L Tank
Fluid Outlet
Air Inlet
Air Hose
Fluid Hose
Air Inlet
Paint Tank
Air Compressor Spay Gun
Air Regulator
Fluid Inlet Hose
Spray Gun
04
EC REP: EUREP GmbH Unterlettenweg 1a, 85051 Ingolstadt
Germanyeurep@eurep-gmbh.com +49 841 8869 7744
Made in China
E-mail: CustomerSeice@vevor.com
Manufacturer: Wenling Sanjiafu Hardware Facto Co., Ltd.
ADD: No. 2 Plant Industrial Zone, Shenqiao village, Muyu, Zeguo Town, Wenling City, Zhejiang Province.
Disposal: This product is subject to the provision of european Directive 2012/19/EC.
The symbol showing a wheelie bin crossed through indicates that the product
requires separate refuse collection in the European Union. This applies to the
product and all accessories marked with this symbol. Products marked as such may
not be discarded with normal domestic waste, but must be taken to acollection
point for recycling electrical and electronic devices.
