Owner’s Manual
Ranges
Self-Cleaning Radiant
164D4290P069 49-80111 08-01 JR
Safety Instructions . . . . . . . 2–6
Operating Instructions
Clock and Timer . . . . . . . . . . .13
Oven . . . . . . . . . . . . . . . . .10–18
Sabbath Feature . . . . . . . . . . .15
Self-Cleaning . . . . . . . . . .17, 18
Thermostat . . . . . . . . . . . . . .16
Timed Baking & Roasting . . .14
Surface Units . . . . . . . . . . . . 7–9
Care and Cleaning
Broiler Pan & Grid . . . . . . . . . 22
Control Knobs . . . . . . . . . . . . 19
Glass Cooktop . . . . . . . . . . 23, 24
Lift-Off Oven Door . . . . . . . . . 20
Light . . . . . . . . . . . . . . . . . . . . 22
Shelves . . . . . . . . . . . . . . . . . . 21
Troubleshooting Tips . . . 25–28
Consumer Support
Consumer Support . . Back Cover
Product Registration . . . . . 29, 30
Warranty . . . . . . . . . . . . . . . . . 31
GEAppliances.com
Write the model and serial
numbers here:
Model # ________________
Serial # ________________
You can find them on a label
behind the storage drawer on
the front of the range frame.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire,
electric shock, or to prevent property damage, personal injury, or loss of life.
All ranges can tip and injury could result.
To prevent accidental tipping of the range, attach it to the wall and floor by installing the Anti-Tip
device supplied.
To check if the device is installed and engaged properly, remove the kick panel or storage drawer
and inspect the rear leveling leg. Make sure it fits securely into the slot.
If you pull the range out from the wall for any reason, make sure the device is properly
engaged when you push the range back against the wall. If it is not, there is a possible risk of
the range tipping over and causing injury if you or a child stand, sit or lean on an open door.
Please refer to the Anti-Tip device information in this manual. Failure to take this precaution
could result in tipping of the range and injury.
WARNING
ANTI-TIP DEVICE
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
GEAppliances.com
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause cancer, birth defects or other reproductive
harm, and requires businesses to warn customers of potential exposure to such substances.
The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during
the cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation
fan or hood.
Fluorescent light bulbs contain mercury. If your model has a surface light, you must recycle the
fluorescent light bulb according to local, state and federal codes.
When using electrical appliances, basic safety precautions should be followed, including the following:
■Use this appliance only for its intended
purpose as described in this Owner’s
Manual.
■Be sure your appliance is properly
installed and grounded by a qualified
installer in accordance with the provided
installation instructions.
■ Have the installer show you the location
of the circuit breaker or fuse. Mark it for
easy reference.
■ Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.
■ Before performing any service, disconnect
the range power supply at the household
distribution panel by removing the fuse or
switching off the circuit breaker.
■ Do not leave children alone—children
should not be left alone or unattended in
an area where an appliance is in use. They
should never be allowed to sit or stand on
any part of the appliance.
■ Do not allow anyone to climb, stand or
hang on the door, storage drawer or
cooktop. They could damage the range
and even tip it over, causing severe
personal injury.
SAFETY PRECAUTIONS
3
4
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
■ Do not store flammable materials in an
oven or near the cooktop.
■
CAUTION:
Items of interest to
children should not be stored in cabinets
above a range or on the backsplash of a
range—children climbing on the range
to reach items could be seriously injured.
■ Never wear loose-fitting or hanging
garments while using the appliance.
Be careful when reaching for items stored
over the range. Flammable material could
be ignited if brought in contact with hot
surface units or heating elements and may
cause severe burns.
■ Use only dry pot holders—moist or damp
pot holders on hot surfaces may result in
burns from steam. Do not let pot holders
touch hot surface units or heating
elements. Do not use a towel or other
bulky cloth in place of pot holders.
■ Do not use water on grease fires. Never
pick up a flaming pan. Turn the controls
off. Smother a flaming pan on a surface
unit by covering the pan completely with
a well-fitting lid, cookie sheet or flat tray.
Use a multi-purpose dry chemical or
foam-type fire extinguisher.
■Flaming grease outside a pan can be put
out by covering it with baking soda or,
if available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■Flame in the oven can be smothered
completely by closing the oven door and
turning the oven off or by using a multi-
purpose dry chemical or foam-type fire
extinguisher.
■ For your safety, never use your appliance
for warming or heating the room.
■ Do not let cooking grease or other
flammable materials accumulate in or
near the range.
■ Do not touch the surface units, the
heating elements or the interior surface
of the oven. These surfaces may be hot
enough to burn even though they are
dark in color. During and after use, do not
touch, or let clothing or other flammable
materials contact the surface units, areas
nearby the surface units or any interior
area of the oven; allow sufficient time for
cooling first.
■Potentially hot surfaces include the
cooktop, areas facing the cooktop, oven
vent opening, surfaces near the opening,
crevices around the oven door.
■
REMEMBER:
The inside surface of the oven
may be hot when the door is opened.
■ Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
■ Keep the hood and grease filters clean
to maintain good venting and to avoid
grease fires.
■ Teach children not to play with the
controls or any other part of the range.
■ Always keep dish towels, dish cloths, pot
holders and other linens a safe distance
from your range.
■ Always keep wooden and plastic utensils
and canned food a safe distance from
your range.
■ Always keep combustible wall coverings,
curtains or drapes a safe distance from
your range.
WARNING!
SAFETY PRECAUTIONS
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F. and poultry
to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against
foodborne illness.
COOK MEAT AND POULTRY THOROUGHLY…
Do not operate the oven or cooktop controls if the glass is broken. Food splatter or cleaning solution
may penetrate a broken control panel and create a risk of electrical shock. Contact a qualified
technician immediately should your glass control panel become broken.
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
GEAppliances.com
Use proper pan size—select cookware having flat bottoms large enough to cover the surface unit
heating element. The use of undersized cookware will expose a portion of the surface unit to direct
contact and may result in ignition of clothing. Proper relationship of cookware to surface unit will also
improve efficiency.
■Never leave the surface units unattended
at high heat settings. Boilovers cause
smoking and greasy spillovers that may
catch on fire.
■Only certain types of glass, glass ⁄ceramic,
earthenware or other glazed containers are
suitable for cooktop service; others may
break because of the sudden change in
temperature.
■To minimize the possibility of burns,
ignition of flammable materials and
spillage, the handle of a container
should be turned toward the center of
the range without extending over nearby
surface units.
■Always turn the surface units off before
removing cookware.
■When preparing flaming foods under the
hood, turn the fan on.
■Use care when touching the cooktop. The
glass surface of the cooktop will retain heat
after the controls have been turned off.
■Keep an eye on foods being fried at high
or medium high heat settings.
■Foods for frying should be as dry as
possible. Frost on frozen foods or moisture
on fresh foods can cause hot fat to bubble
up and over the sides of the pan.
■Use little fat for effective shallow or deep
fat frying. Filling the pan too full of fat can
cause spillovers when food is added.
■If a combination of oils or fats will be used
in frying, stir together before heating, or as
fats melt slowly.
■Always heat fat slowly, and watch as it heats.
■Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
■Avoid scratching the glass cooktop.
The cooktop can be scratched with items
such as sharp instruments, rings or other
jewelry, and rivets on clothing.
■Do not operate the radiant surface units if
the glass is broken. Spillovers or cleaning
solution may penetrate a broken cooktop
and create a risk of electrical shock.
Contact a qualified technician immediately
should your glass cooktop become broken.
■Never use the glass cooktop surface as
a cutting board.
■Do not place or store items that can melt
or catch fire on the glass cooktop, even
when it is not being used.
■Be careful when placing spoons or other
stirring utensils on glass cooktop surface
when it is in use. They may become hot
and could cause burns.
■Clean the cooktop with caution. If a wet
sponge or cloth is used to wipe spills on a
hot surface unit, be careful to avoid steam
burns. Some cleaners can produce
noxious fumes if applied to a hot surface.
NOTE:
We recommend that you avoid
wiping any surface unit areas until they
have cooled and the indicator light has
gone off. Sugar spills are the exception
to this. Please see the
Cleaning the glass
cooktop
section.
■When the cooktop is cool, use only the
recommended cleaning cream to clean
the cooktop.
■To avoid possible damage to the cooking
surface, do not apply cleaning cream to
the glass surface when it is hot.
■After cleaning, use a dry cloth or paper
towel to remove all cleaning cream
residue.
■Read and follow all instructions and
warnings on the cleaning cream labels.
■Large scratches or impacts to glass
doors or cooktops can lead to broken
or shattered glass.
RADIANT SURFACE UNITS
5
6
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
■ Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
■ Keep the oven vent unobstructed.
■ Keep the oven free from grease buildup.
■ Place the oven shelf in the desired position
while the oven is cool. If shelves must be
handled when hot, do not let pot holder
contact the heating elements.
■ When using cooking or roasting bags in
the oven, follow the manufacturer’s
directions.
■ Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching
hot surfaces of the door or oven walls.
■ Do not use the oven to dry newspapers.
If overheated, they can catch on fire.
■ Do not use the oven for a storage area.
Items stored in an oven can ignite.
■ Do not leave paper products, cooking
utensils or food in the oven when not
in use.
■ Do not use aluminum foil to line oven
bottoms, except as suggested in this
manual. Improper installation of
aluminum foil may result in a risk of
electric shock or fire.
Stand away from the range when opening the oven door. Hot air or steam which escapes can cause
burns to hands, face and/or eyes.
Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven. Residue from oven cleaners will damage the inside
of the oven when the self-clean cycle is used.
WARNING!
OVEN
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
■Do not clean the door gasket. The door
gasket is essential for a good seal. Care
should be taken not to rub, damage or
move the gasket.
■Before self-cleaning the oven, remove the
broiler pan, grid and other cookware.
■Be sure to wipe up excess spillage before
starting the self-cleaning operation.
■If the self-cleaning mode malfunctions,
turn the oven off and disconnect the
power supply. Have it serviced by a
qualified technician.
■Clean only parts listed in this Owner’s
Manual.
SELF-CLEANING OVEN
Using the surface units.
GEAppliances.com
Throughout this manual, features and appearance may vary from your model.
How to Set
Push the knob in and turn in either
direction to the setting you want.
A
HOT COOKTOP
indicator light will glow
when any radiant element is turned on,
and will remain on until the surface is
cooled to approximately 150°F.
Indicator light will:
■
come on when the unit is hot to the touch.
■
stay on even after the unit is turned off.
■
glow until the unit is cooled to approximately
150°F.
The
WM
(warm) setting (on some
models) on the right
REAR
surface unit
keeps already heated food warm until
ready to serve.
Dual Surface Unit Control Knob
(on some models)
The dual surface unit has 2 cooking sizes to select
from so you can match the size of the unit to the
size of the cookware you are using.
To use the small (5 or 6 inch) surface
unit, push in the
SMALL BURNER
portion
of the switch above the control knob.
To use the large (8 or 9 inch) surface
unit, push in the
LARGE BURNER
portion
of the switch above the control knob.
At both OFF and HI the control clicks
into position. You may hear slight
clicking sounds during cooking,
indicating the control is maintaining
your desired setting.
Be sure you turn the control knob to
OFF when you finish cooking.
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
Using the Warming Zone
(on some models)
The
WARMING ZONE
, located in the back
center of the glass surface, will keep hot,
cooked food at serving temperature.
Always start with hot food. Do not use
to heat cold food. Placing uncooked or
cold food on the
WARMING ZONE
could
result in food-borne illness.
Push and turn the control knob to any
desired setting.
For best results, all foods on the
WARMING ZONE
should be covered with
a lid or aluminum foil. When warming
pastries or breads, the cover should be
vented to allow moisture to escape.
Always use potholders or oven mitts when
removing food from the
WARMING ZONE
,
as cookware and plates will be hot.
CAUTION:
Do not warm food on the
WARMING ZONE for more than two hours.
NOTE:
The surface warmer will not glow red like
the cooking elements.
A
HOT
surface indicator light will glow
when the glass surface is hot and will
remain on until the surface is cool
enough to touch. Lower settings may not
heat the glass surface enough to cause the
HOT
surface indicator light to come on.
A
WARMING ZONE
indicator light will
glow when the unit is on.
■
Do not use plastic wrap to cover food. Plastic
may melt onto the surface and be very difficult
to clean.
■
Use only cookware recommended for
top-of-range cooking.
7
WARMER GUIDE
SETTING FOOD
(Low) Bread/Pastries
(Medium) Chocolate/Butter
(Medium) Sauces, Stews,
Cream Soups
(Medium) Vegetables
(High) Soups (liquid)
(High) Tea or Coffee
The Warmer Guide is for reference
only and the SETTING that you
need will depend on the amount
and type of food, the starting
temperature of the food, and the
length of the holding time.
8
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the surface units.
Throughout this manual, features and appearance may vary from your model.
Never cook directly on the glass.
Always use cookware.
About the radiant surface units…
The radiant cooktop features heating
units beneath a smooth glass surface.
NOTE: A slight odor is normal when a new
cooktop is used for the first time. It is caused by
the heating of new parts and insulating materials
and will disappear in a short time.
NOTE: On models with light colored glass
cooktops, it is normal for the cooking zones to
change color when hot or cooling down. This is
temporary and will disappear as the glass cools
to room temperature.
The surface unit will cycle on and off to
maintain your selected control setting.
It is safe to place hot cookware on the
glass surface even when the cooktop
is cool.
Even after the surface units are turned
off, the glass cooktop retains enough
heat to continue cooking. To avoid
over-cooking, remove pans from the
surface units when the food is cooked.
Avoid placing anything on the surface
unit until it has cooled completely.
■
Water stains (mineral deposits) are removable
using the cleaning cream or full strength white
vinegar.
■
Use of window cleaner may leave an
iridescent film on the cooktop. The cleaning
cream will remove this discoloration.
■
Don’t store heavy items above the cooktop.
If they drop onto the cooktop, they can cause
damage.
■
Do not use the surface as a cutting board.
,,,,
,,,,,,,,
,,,,,,,,,,,
,,,,,,,,,,
,,,,,,,
,,,
SURFACE
COOKING
,,,,
,,,,,,,,
,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,
,,,,,,,
,,,
OFF CENTER
Always place the pan in the center of
the surface unit you are cooking on.
Do not slide cookware across the
cooktop because it can scratch the
glass—the glass is scratch resistant,
not scratch proof.
,,
,,,,,
,,,,,,,,,
,,,,,,,,,,,
,,,,,,,,,,
,,,,,,,
,,,,
DRAGGING
Temperature Limiter
Every radiant surface unit has a
temperature limiter.
The temperature limiter protects the
glass cooktop from getting too hot.
The temperature limiter may cycle the
units off for a time if:
■
The pan boils dry.
■
The pan bottom is not flat.
■
The pan is off center.
■
There is no pan on the unit.
9
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
Selecting types of cookware.
GEAppliances.com
The following information will help you choose cookware which will give good performance on glass cooktops.
Stainless Steel:
recommended
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop, but can be removed if cleaned
immediately. Because of its low melting
point, thin weight aluminum should not
be used.
Copper Bottom:
recommended
Copper may leave residues which can
appear as scratches. The residues can be
removed, as long as the cooktop is
cleaned immediately. However, do not let
these pots boil dry. Overheated metal can
bond to glass cooktops. An overheated
copper bottom pot will leave a residue
that will permanently stain the cooktop
if not removed immediately.
Porcelain Enamel Covered Cast Iron:
recommended
As long as the cookware is covered
completely with porcelain enamel, this
cookware is recommended. Caution is
recommended for cast iron cookware
that is not completely covered with
smooth porcelain enamel, as it may
scratch the glass ceramic cooktop.
Glass-ceramic:
usable, but not recommended
Poor performance. May scratch the
surface.
Stoneware:
usable, but not recommended
Poor performance. May scratch the
surface.
Home Canning Tips:
Be sure the canner is centered over the
surface unit.
Make sure the canner is flat on the
bottom.
Use recipes and procedures from
reputable sources. These are available
from manufacturers such as Ball
®
and
Kerr
®
and the Department of Agriculture
Extension Service.
To prevent burns from steam or heat,
use caution when canning.
Check pans for flat bottoms by
using a straight edge.
Pans with rounded, curved, ridged
or warped bottoms are not
recommended.
Use only flat-bottomed woks.
Wok Cooking
We recommend that you use only a flat-bottomed
wok. They are available at your local retail store.
Do not use woks that have support rings.
Do not use round bottom woks. You
could be seriously burned if the wok
tipped over.
10
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the oven controls.
Throughout this manual, features and appearance may vary from your model.
Oven Control, Clock and Timer Features and Settings
COOK TIME ON/OFF Pad
Press this pad and then press the
HOUR
and
MIN.
pads to set the amount of time
you want your food to cook. Turn the
Oven Temperature knob to the desired
temperature. The oven will shut off when
the Cook Time has run out.
TIMER ON/OFF Pad
Press this pad to select the timer feature.
AUTOMATIC OVEN Light
This lights anytime the oven has been
programmed to automatically turn on
or off.
HOUR and MIN. Pads
These pads allow you to set times up to
11 hours and 59 minutes.
As a safety feature, this oven will automatically shut off
after 12 hours. On models with touch pad clock controls this
feature may be deactivated to allow the oven to be left on
for more than 12 hours. To deactivate or reactivate the
Automatic Oven Shut-Off, press and hold both the MIN.
+/– pads for about 4 seconds.
OVEN ON Light
Glows anytime the oven is heating. The
light will flash when the oven automatically
turns off to remind you to turn the Oven
Temperature knob to
OFF.
Oven Temperature Knob
Turn this knob to the setting you want. (On
some models, you must push the knob in
before turning.) The temperature will be
displayed to indicate setting. Display will
change back to time after a few seconds.
PREHEATED Light
Glows when the oven reaches your selected
temperature.
On some models, opening the oven door will not
automatically turn the oven light on. You may use
the oven light switch to turn the light on and off.
CLEAN Light
Glows when the oven is in the self-clean
cycle. After the self-clean cycle, the light will
flash. Unlatch the door and turn the Oven
Temperature knob to
OFF.
Do not lock the oven door with the latch during cooking.
The latch is used for self-cleaning only.
TEMP RECALL
Press the – pad above
TEMP RECALL
to
display the selected oven temperature.
Display
Shows the time of day and the time set
for the timer.
If “F— and a number or letter” flash in the display
and the oven control signals, this indicates a function
error code.
If your oven was set for a timed oven operation and a
power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there has
been a power outage.
CLOCK Pad
Press this pad before setting the clock.
START TIME ON/OFF Pad
Press this pad and the
HOUR
and
MIN.
pads to delay the starting of your oven
up to 11 hours and 59 minutes.
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
Using the oven.
GEAppliances.com
To avoid possible burns, place the shelves in the desired position before you turn the oven on.
Before you begin…
The shelves have stops, so that when
placed correctly on the supports, they will
stop before coming completely out, and
will not tilt.
When placing and removing cookware,
pull the shelf out until it stops.
To remove a shelf,
pull it toward you,
tilt the front end up and pull it out.
To replace,
place the end of the shelf
(stop-locks) on the support, tilt up the
front and push the shelf in.
CAUTION: When you are using the shelf in the
lowest position (A), you will need to use caution
when pulling the shelf out. We recommend that
you pull the shelf out several inches and then,
using two pot holders, pull the shelf out by
holding the sides of it. The shelf is low and you
could be burned if you place your hand in the
middle of the shelf and pull all the way out. Be
very careful not to burn your hand on the door
when using the shelf in the lowest position (A).
The oven has 6 shelf positions.
How to Set the Oven for Baking or Roasting
Turn the Oven Temperature knob
to the temperature you desire.
On some models, you must push the
knob in before turning.
Check food for doneness at
minimum time on recipe. Cook
longer if necessary.
Turn the Oven Temperature knob
to
OFF
when cooking is complete.
Type of Food Shelf Position
Frozen pies (on cookie sheet) D
Angel food cake A
Bundt or pound cakes C or D
Biscuits, muffins, brownies, C or D
cookies, cupcakes,
layer cakes, pies
Casseroles C or D
Turkey A
Preheating and Pan Placement
Preheat the oven if the recipe calls for it.
Preheating is necessary for good results
when baking cakes, cookies, pastry and
breads.
To preheat, set the oven at the correct temperature.
The control will beep when the oven is preheated
and the display will show your set temperature.
This will take approximately 6–10 minutes.
Baking results will be better if baking
pans are centered in the oven as much as
possible. If baking with more than one
pan, place the pans so each has at least
1 to 1
1
⁄2″ of air space around it. If baking
four cake layers at the same time, place
two layers on rack B and two layers on
rack D. Stagger the pans on the rack so
one is not directly above the other.
Aluminum Foil
You can use aluminum foil to line the
broiler pan and broiler grid. However,
you must mold the foil tightly to the grid
and cut slits in it just like the grid.
Without the slits, the foil will prevent fat
and meat juices from draining into the
broiler pan. The juices could become
hot enough to catch on fire. If you
do not cut the slits, you are essentially
frying, not broiling.
Do not use aluminum foil on the bottom of
the oven.
Never entirely cover a shelf with
aluminum foil. This will disturb the heat
circulation and result in poor baking.
A smaller sheet of foil may be used to
catch a spillover by placing it on a lower
shelf several inches below the food.
Cut slits in the foil just like the grid.
Center baking pans in the oven
11
12
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the oven.
To avoid possible burns, place the shelves in the desired position before you turn the oven on.
How to Set the Oven for Broiling
Place the meat or fish on the broiler
grid in the broiler pan.
Follow suggested shelf positions in
the
Broiling Guide.
If your range is connected to 208 volts, rare
steaks may be broiled by preheating the broiler
and positioning the oven shelf one position
higher.
Use
LO Broil
to cook foods such as
poultry or thick cuts of meat thoroughly
without over-browning them.
Turn the Oven Temperature knob
to
BROIL.
On some models, you must push the
knob in before turning.
When broiling is finished, turn the
Oven Temperature knob to
OFF.
Leave the door open to the broil
stop position. The door stays open
by itself, yet the proper temperature
is maintained in the oven.
Quantity and/ Shelf First Side Second Side
Food or Thickness Position Time (min.) Time (min.) Comments
Ground Beef 1 lb. (4 patties) D 13 8 Space evenly.
1
/2 to
3
/4″ thick
4 lbs. (12 patties) D 15 11
Beef Steaks
Rare†
3
/4 to 1″ thick F 6 4 Steaks less than
3
/4″
Medium 1 to 1
1
/2 lbs. E 8 6 thick are difficult
Well Done E 10 8 to cook rare.
Slash fat.
Rare† 1
1
/2″ thick D 10 8
Medium 2 to 2
1
/2 lbs. D 15 10–12
Well Done E 20 20
Chicken 1 whole cut up C 25 25 Brush each side with
2 to 2
1
⁄2 lbs., melted butter.
split lengthwise Broil skin-side-down
Breast C 25 15 first.
Bakery Product
Bread (toast) 2 to 4 slices E 3 1 Space evenly. Place
English Muffin 2 (split) F 3-4 English muffins cut-
side-up and brush
with butter if desired.
Lobster Tails 2–4 C 18–20 Do not Cut through back of
turn shell. Spread open.
over. Brush with melted
butter before broiling
and after half of
broiling time.
Fish Fillets 1 lb. (
1
/4 to
1
/2″ thick) E 5 5 Handle and turn very
carefully. Brush with
lemon butter before
and during cooking,
if desired.
Salmon
Steaks 2 (1″ thick) E 10 5 Turn carefully. Do not
Fillets 2 (
1
/2 to
3
/4″ thick) E 10 turn skin side down.
Ham Slices
1
/2″ thick D 6 6
(precooked) 1″ thick D 8 8
Pork Chops 2 (
1
/2″ thick) D 10 10 Slash fat.
Well Done 2 (1″ thick) about 1 lb. D 15 15
Lamb Chops
Medium 2 (1″ thick) about 10 E 7 4 Slash fat.
Well Done to 12 oz. E 10 9
Medium 2 (1
1
/2″ thick) about 1 lb. E 9 6
Well Done E 14 10
Broiling Guide
The size, weight, thickness,
starting temperature,
and your preference
of doneness will affect
broiling times. This guide
is based on meats at
refrigerator temperature.
† The U.S. Department of
Agriculture says “Rare beef is
popular, but you should know that
cooking it to only 140°F. means
some food poisoning organisms
may survive.” (Source: Safe Food
Book. Your Kitchen Guide. USDA
Rev. June 1985.)
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
13
Using the clock and timer.
GEAppliances.com
Not all features are on all models.
To Set the Clock
The clock must be set to the correct time
of day for the automatic oven timing
functions to work properly. The time of
day cannot be changed during a timed
baking or self-cleaning cycle.
Press the
CLOCK
pad.
Press the
HOUR
and
MIN.
pads until
the time of day shows in the display.
Make sure the clock is set to the
correct time of day.
To Set the Timer
Press the
TIMER ON/OFF
pad. Press the
HOUR
and
MIN.
pads until
the amount of time you want shows
in the display. The timer will start
automatically within a few seconds
of releasing the pad.
The timer is a minute timer only.
The timer does not control oven
operations.
The maximum setting on the timer is
11 hours and 59 minutes.
End of Cycle Tones
Clear the tones by pressing the pad of the
function you are using.
or
To Reset the Timer
If the display is still showing the time
remaining, you may change it by pressing
the
HOUR
and
MIN.
pads until the time
you want appears in the display.
If the remaining time is not in the display,
recall the remaining time by pressing the
TIMER ON/OFF
pad and then pressing the
HOUR
and
MIN.
pads until the new time
you want shows in the display.
To Cancel the Timer
Press the
TIMER ON/OFF
pad twice.
To Black-Out the Clock
If you have several clocks in your kitchen,
you may wish to black-out the time of day
display of your range. If so, press the
CLOCK
pad.
Press the CLOCK pad twice to retain the time of
day after a black-out.
Although you cannot see it, the clock
maintains the correct time of day. It will
reappear for the duration of any function
that displays a Start Time or Cook Time.
Press the
CLOCK
pad again to bring back
the display.
14
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the timed baking and roasting features.
Do not latch the oven door during timed cooking. The latch is used for self-cleaning only.
NOTE: Foods that spoil easily–such as milk, eggs, fish, stuffings, poultry and pork–should not be allowed to sit for
more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
How to Set an Immediate Start and Automatic Stop
The oven will turn on immediately and cook for a
selected length of time. At the end of the cooking
time the oven will turn off automatically.
Press the
COOK TIME ON/OFF
pad.
Using the
HOUR
and
MIN.
pads,
enter the length of cooking time.
Turn the Oven Temperature knob
to the desired temperature.
On some models, you must push the
knob in before turning.
The display will show the cooking time
remaining. When the oven reaches the
set temperature, a tone sounds.
When the oven automatically turns
off the
AUTOMATIC OVEN
light will flash
and the oven will signal. Turn the oven
control to
OFF
to stop the flashes and
signal.
How to Set a Delayed Start and Automatic Stop
You can set the oven control to delay-start the
oven, cook for a specific length of time and then
turn off automatically.
Make sure the clock shows the correct
time of day.
Press the
START TIME ON/OFF
pad.
Using the
HOUR
and
MIN.
pads,
enter the time you want cooking
to start.
Press the
COOK TIME ON/OFF
pad.
Using the
HOUR
and
MIN.
pads,
enter the length of cooking time.
Turn the Oven Temperature knob
to the desired temperature.
On some models, you must push the
knob in before turning.
When the oven automatically turns off
the
AUTOMATIC OVEN
light will flash
and the oven will signal. Turn the oven
control to
OFF
to stop the flashes and
signal.
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
15
Using the Sabbath Feature.
(Designed for use on the Jewish Sabbath and Holidays) (On some models)
GEAppliances.com
The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning,
or Delay Start cooking.
NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door
is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on the
control panel, the oven light may be turned on and left on.
How to Set for Regular Baking/Roasting
Make sure the clock shows the correct time of day
and the oven is off.
Press and hold
both
the
MIN. +
AND
-
pads,
at the same time
, until the display
changes.
Press and hold
either
the
MIN. +
OR
-
pad until the display changes, then
release the pad. If
SAb
appears in the
display, go to the next step. If
SAb
is not
in the display, continue to press, hold
and release the pad until
SAb
appears.
Turn the Oven Temperature knob
to the desired temperature between
warm (
WM
) and 550°. The display will
show ⊃.
After a random delay period of
approximately 30 seconds to 1 minute,
⊃ will appear in the display
indicating that the oven is baking or
roasting. If ⊃ does not appear in
the display, reset the temperature.
To adjust the oven temperature, turn the
Oven Temperature knob to the desired
temperature.
NOTE:
The
COOK TIME ON/OFF
pad is active
during the Sabbath feature.
⊃
⊃
How to Set for Timed Baking/Roasting - Immediate Start and Automatic Stop
Make sure the clock shows the correct time of day
and the oven is off.
Press and hold
both
the
MIN. +
AND
-
pads,
at the same time
, until the display
changes.
Press and hold
either
the
MIN. +
OR
-
pad until the display changes, then
release the pad. If
SAb
appears in the
display, go to the next step. If
SAb
is not
in the display, continue to press, hold
and release the pad until
SAb
appears.
Press the
COOK TIME ON/OFF
pad.
Immediately enter the length of cooking
time, using the
HOUR
and
MIN
. pads.
The cooking time that you entered will
be displayed.
Turn the Oven Temperature knob to
the desired temperature. The display will
show ⊃.
After a random delay period of
approximately 30 seconds to 1 minute,
⊃ will appear in the display
indicating that the oven is baking or
roasting. If ⊃ does not appear in
the display, reset the temperature.
To adjust the oven temperature, turn the
Oven Temperature knob to the desired
temperature.
When cooking is finished, the display will
change from ⊃ to ⊃, indicating that the
oven has turned
OFF
but is still set in Sabbath.
Remove the cooked food.
⊃
⊃
⊃
How to Exit the Sabbath Feature
Turn the Oven Temperature knob
to
OFF
.
If the oven is cooking, wait for a random
time delay of approximately 30 seconds
to 1 minute until only ⊃ is in the display.
Press and hold
both
the
MIN. +
AND
-
pads,
at the same time
, until the display
changes.
Press and hold
either
the
MIN. +
OR
-
pad until the display changes, then
release the pad. Continue to press, hold
and release the pad until
ON
or
OFF
appears for your preference of 12 hour
automatic oven shut-off.
ON
indicates
that the 12 hour automatic oven shut-off
is turned on and
OFF
indicates that the
12 hour automatic oven shut-off is
turned off.
Press the
CLOCK
pad to return to the
time of day.
NOTE:
If a power outage occurred when the
oven was in Sabbath mode, the oven will
automatically turn off and the oven control
must be reset.
16
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Adjust the oven thermostat—Do it yourself!
You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks
to become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat
yourself.
Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.
These thermometers may vary 20–40°F.
To Adjust the Thermostat
Put the Oven Temperature knob in
the
OFF
position.
Press and hold the
HOUR +/–
pads
for 5 seconds until the display
changes.
Before display changes back, press
the
HOUR +/–
pads to increase or
decrease the temperature in 5
degree increments.
The oven temperature can be adjusted
up as much as 35°F. or down as much
as 35°F.
If the oven adjustment is set cooler
than the factory setting a minus sign (–)
and the adjusted temperature will appear
in the display.
Wait several seconds for the control
to automatically set and return to its
previous setting.
NOTE: This adjustment will not affect the
broiling or the self-cleaning temperatures. The
adjustment will be retained after a power failure.
The type of margarine will affect baking performance!
Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat). If you
decrease the fat, the recipe may not give the same results as with a higher fat product.
Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the fat
content of a spread product, the more noticeable these differences become.
Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low fat spreads, on the
other hand, contain less fat and more water. The high moisture content of these spreads affects the texture and flavor
of baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing at least
70% vegetable oil.
17
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
Using the self-cleaning oven.
GEAppliances.com
Never force the latch handle. Forcing the handle will damage the door lock mechanism.
Before a Clean Cycle
We recommend venting your kitchen
with an open window or using a
ventilation fan or hood during the first
self-clean cycle.
Remove the shelves, broiler pan, broiler
grid, all cookware and any aluminum foil
from the oven.
The oven shelves can be self-cleaned,
but they will darken, lose their luster
and become hard to slide.
Soil on the front frame of the range and
outside the gasket on the door will need
to be cleaned by hand. Clean these areas
with hot water, soap-filled steel-wool pads
or cleansers such as Soft Scrub
®
. Rinse
well with clean water and dry.
Do not clean the gasket. The fiberglass
material of the oven door gasket cannot
withstand abrasion. It is essential for the
gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Wipe up any heavy spillovers on the oven
bottom.
Make sure the oven light bulb cover is in
place and the oven light is off.
IMPORTANT:
The health of some birds is
extremely sensitive to the fumes given off
during the self-cleaning cycle of any
range. Move birds to another well
ventilated room.
Wipe up heavy soil on the oven
bottom.
How to Set the Oven for Cleaning
Latch the door.
Turn the Oven Temperature knob
to
CLEAN.
On some models, you must push the
knob in before turning.
Clean cycle time is normally 4 hours
and 20 minutes. On models with
COOK
TIME
and
START TIME
pads, you can
change the clean time to between
3 hours and 5 hours, 59 minutes by using
the
HOUR
and
MIN.
pads. The display will
show the clean time counting down.
When the
CLEAN
light flashes, slide the
latch handle to the left, and turn the
Oven Temperature knob to
OFF.
To stop a clean cycle,
turn the Oven
Temperature knob to
OFF.
Wait until the
oven has cooled and unlatch the door.
■ While the oven is self-cleaning, you
can press the
CLOCK
pad to display
the time of day. To return to the clean
countdown, press the
COOK TIME
ON/OFF
pad.
18
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Using the self-cleaning oven.
How to Delay the Start of Cleaning
Make sure the clock shows the correct
time of day.
Latch the door.
Turn the Oven Temperature knob
to
CLEAN.
On some models, you must push the
knob in before turning.
Press the
START TIME ON/OFF
pad.
Press the
HOUR
and
MIN.
pads to set
the time cleaning will start.
When the
CLEAN
light flashes, slide
the latch handle to the left as far as it
will go and turn the Oven Temperature
knob to
OFF.
After a Clean Cycle
You may notice some white ash in the
oven. Wipe it up with a damp cloth after
the oven cools.
If white spots remain, remove them with a soap-
filled steel wool pad and rinse thoroughly with a
vinegar and water mixture.
These deposits are usually a salt residue
that cannot be removed by the clean
cycle.
If the oven is not clean after one clean
cycle, repeat the cycle.
■ You cannot set the oven for cooking
until the oven is cool enough for the
door to be unlatched.
■ If the shelves become hard to slide,
apply a small amount of vegetable oil or
cooking oil to a paper towel and wipe
the edges of the oven shelves with the
paper towel.
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
19
Care and cleaning of the range.
GEAppliances.com
Be sure all controls are off and all surfaces are cool before cleaning any part of the range.
If your range is removed for cleaning, servicing or any reason, be sure the anti-tip
device is re-engaged properly when the range is replaced. Failure to take this
precaution could result in tipping of the range and cause injury.
How to Remove Packaging Tape
To assure no damage is done to the finish
of the product, the safest way to remove
the adhesive left from packaging tape on
new appliances is an application of a
household liquid dishwashing detergent,
mineral oil or cooking oil.
Apply with a soft cloth and allow to soak.
Wipe dry and then apply an appliance
polish to thoroughly clean and protect
the surface.
NOTE: The plastic tape (on some models) must
be removed from all chrome trim. It cannot be
removed if it is baked on.
Control Knobs
To Remove:
Be sure the knob is in the
OFF
position.
Pull straight off the stem. Using a
piece of string can make removing
the knob easier. Slip the string
under and around the knob,
pull straight out.
Wash the knob thoroughly with warm soapy
water. Dry completely with a soft cloth. DO NOT
let the knob soak.
To Replace:
Check the back of the knob.
The molded rib of the knob is
designed to fit perfectly onto the
knob stem.
Align the molded rib to the clear
groove in the knob stem. Push the
knob back as far as it will go.
Molded rib
Spring clip
Clear groove in
stem
Control Panel
■ Clean up splatters with a damp cloth.
■ You may also use a glass cleaner.
■ Remove heavier soil with warm
soapy water.
■ Do not use abrasives of any kind.
Storage Drawer Removal
To remove the drawer:
Pull the drawer out until it stops.
Lift the front of the drawer until
the stops clear the guides.
Remove the drawer.
To replace the drawer:
Place the drawer rails on the guides.
Push the drawer back until it stops.
Lift the front of the drawer and
push back until the stops clear the
guides.
Lower the front of the drawer and
push back until it closes.
Stop guide
Rail
20
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Care and cleaning of the range.
Lift-Off Oven Door
The oven door is removable for easier
access to the light bulb.
Do not lift the door by the handle.
To remove the door:
Fully open the door.
Each hinge has a hinge lock. Using
a tool, pull the hinge locks down
against the door frame.
Firmly grasp the door
at the top
sides.
Close the door to the stop position.
Lift the door up and pull straight
out.
To replace the door:
Firmly grasp the door
at the top
sides. This is critical.
Approach the range with the door
angled in a vertical position.
Guide the hinges into the slots.
Push door in firmly while opening.
Once in position, open the door
completely. Push the hinge locks
back in towards the front frame.
To clean the inside of the door:
■ Because the area inside the gasket is
cleaned during the self-clean cycle, you
do not need to clean this by hand.
■ The area outside the gasket and
the door liner can be cleaned with a
soap-filled steel wool or plastic pad, hot
water and detergent. Rinse well with a
vinegar and water solution.
To clean the outside of the door:
■ Use soap and water to thoroughly
clean the top, sides and front of the
oven door. Rinse well. You may also use
a glass cleaner to clean the glass on the
outside of the door. Do not let water
drip into the vent openings.
■ If any stain on the door vent trim is
persistent, use a soft abrasive cleaner
and a sponge-scrubber for best results.
■ Spillage of marinades, fruit juices,
tomato sauces and basting materials
containing acids may cause
discoloration and should be wiped up
immediately. When surface is cool,
clean and rinse.
■ Do not use oven cleaners, cleaning
powders or harsh abrasives on the
outside of the door.
The gasket is designed with a gap
at the bottom to allow for proper air
circulation.
Do not rub or clean the door
gasket—it has an extremely low
resistance to abrasion.
If you notice the gasket becoming
worn, frayed or damaged in any
way or if it has become displaced
on the door, you should have it
replaced.
Pull the hinge locks down to the
unlocked position.
Unlocked
position
Locked position
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
21
GEAppliances.com
Painted Surfaces
Painted surfaces include the sides, top of
backguard and the drawer front.
Clean these with soap and water or
a vinegar and water solution.
Do not use commercial oven cleaners,
cleaning powders, steel wool or harsh
abrasives on any painted surface.
Oven Vent
The oven vent is located behind the right rear
surface unit.
This area could become hot during
oven use.
It is normal for steam to come out
of the vent and moisture may collect
underneath it when the oven is in use.
The vent is important for proper air circulation.
Never block this vent.
Oven Shelves
Clean the oven shelves with an abrasive
cleanser or steel wool. After cleaning,
rinse the shelves with clean water and dry
with a clean cloth.
NOTE: The oven shelves may be cleaned in the
self-cleaning oven. However, the shelves will
darken in color, lose their luster and become hard
to slide if cleaned during the self-cleaning cycle.
To make the shelves slide more easily
apply a small amount of vegetable oil
or cooking oil to a paper towel and wipe
the edges of the oven shelves with the
paper towel.
22
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Care and cleaning of the range.
Oven Light Replacement
CAUTION: Before replacing your oven
light bulb, disconnect the electrical
power to the range at the main fuse or
circuit breaker panel.
Be sure to let the light cover and bulb
cool completely.
To remove the cover:
Hold a hand under the cover so it
doesn’t fall when released. With
fingers of the same hand, firmly
push back the wire cover holder.
Lift off the cover.
Do not remove any screws to remove
the cover.
Replace bulb with a 40-watt
appliance bulb.
To replace the cover:
Place it into groove of the light
receptacle. Pull wire forward to
the center of the cover until it
snaps into place.
Connect electrical power to
the range.
Broiler Pan & Grid
Do not clean the broiler pan or grid in a
self-cleaning oven.
After broiling, remove the broiler pan
from the oven. Remove the grid from the
pan. Carefully pour out the grease from
the pan into a proper container.
Wash and rinse the broiler pan and grid
in hot water with a soap-filled or plastic
scouring pad.
If food has burned on, sprinkle the grid
with detergent while hot and cover with
wet paper towels or a dishcloth. Soaking
the pan will remove burned-on foods.
Both the broiler pan and grid may be
cleaned with a commercial oven cleaner.
Both the broiler pan and grid can also be
cleaned in a dishwasher.
Do not store a soiled broiler pan and grid
anywhere in the range.
After broiling, remove the broiler
pan from the oven.
Wire cover holder.
Oven Heating Elements
Do not clean the bake element or the broil
element. Any soil will burn off when the
elements are heated.
To clean the oven floor, gently lift
the bake element. Clean with warm
soapy water.
Allow the cooktop to cool.
Spread a few drops of Cerama
Bryte
®
to the entire burned residue
area.
Hold the razor scraper at
approximately a 45° angle against
the glass surface and scrape the
soil. It will be necessary to apply
pressure to the razor scraper in
order to remove the residue.
Keep a small amount of cream on
the residue as you scrape.
After scraping with the razor
scraper, use the Scotch-Brite
®
blue pad to remove any
remaining residue.
For additional protection, after
all residue has been removed,
polish the entire surface with
Cerama Bryte
®
and a paper towel.
NOTE: Razor blade is packed inverted for
safety reasons. Prior to use, the blade must be
rotated and reinserted into slot. Do not use
a dull or nicked blade.
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
23
Cleaning the glass cooktop.
GEAppliances.com
Burned-On Residue
WARNING: DAMAGE to your glass surface
may occur if you use scrub pads other than
BLUE Scotch-Brite
®
Multi-Purpose No Scratch
scrub pads by 3M.
Allow the cooktop to cool.
Spread a few drops of Cerama
Bryte
®
to the entire burned residue
area.
Using the Scotch-Brite
®
blue pad,
rub the residue area, applying
pressure as needed.
If any residue remains, repeat the
steps listed above as needed.
For additional protection, after
all residue has been removed,
polish the entire surface with
Cerama Bryte
®
and a paper towel.
The RAZOR SCRAPER is available
through our Parts Center. See
instructions under “To Order Parts”
section on next page.
NOTE: Razor blade is packed
inverted for safety reasons. Prior
to use, the blade must be rotated
and reinserted into slot. Do not
use a dull or nicked blade.
Heavy, Burned-On Residue
Scotch-Brite
®
Multi-Purpose
No Scratch blue scrub pad
Normal Daily Use Cleaning
ONLY use the recommended cleaning
cream, Cerama Bryte
®
, on the glass
cooktop. Other creams may not be as
effective.
To maintain and protect the surface of
your glass cooktop, follow these steps:
Before using the cooktop for the
first time, clean it with the cooktop
cleaning cream. This helps protect
the top and makes clean-up easier.
Daily use of the cooktop cleaning
cream will help keep the cooktop
looking new.
Shake the cleaning cream well.
Apply a few drops of the cream
directly to the cooktop.
Use a paper towel or sponge to
clean the entire cooktop surface.
NOTE: It is very important that you DO NOT
heat the cooktop until it has been cleaned
thoroughly.
Clean your cooktop after
each spill.
24
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Cleaning the glass cooktop.
Turn off all surface units. Remove
hot pans.
Wearing an oven mitt:
a. Use the razor scraper to move
the spill to a cool area on the
cooktop.
b. Remove the spill with
paper towels.
Any remaining spillover should be
left until the surface of the cooktop
has cooled.
Don’t use the surface units again
until all of the residue has been
completely removed.
NOTE: If pitting or indentation in the glass
surface has already occurred, the cooktop
glass will have to be replaced. In this case,
service will be necessary.
Damage from Sugary Spills and Melted Plastic
Our testing shows that if
you are cooking high sugar
mixtures such as jelly or
fudge and have a spillover,
it can cause permanent
damage to the glass surface
unless the spillover is
immediately removed.
Be careful not to slide pots and
pans across your cooktop. It will
leave metal markings on the
cooktop surface.
These marks are removable
using the cleaning cream with a
Scotch-Brite
®
blue pad and/or
razor scraper.
If pots with a thin overlay of
aluminum or copper are allowed
to boil dry, the overlay may leave
black discoloration on the
cooktop.
This should be removed
immediately before heating again
or the discoloration may be
permanent.
WARNING: Carefully check the bottom of
pans for roughness that would scratch
the cooktop.
Metal Marks and Scratches
To order Cerama Bryte
®
cream and
the razor scraper, please call our
toll-free number:
National Parts Center 800-626-2002.
Cerama Bryte
®
Cream . . . . . . .# WX10X300
Razor Scraper . . . . . . . . . . . . .# WX5X1614
Kit . . . . . . . . . . . . . . . . . . . . . .# WB64X5027
(Kit includes cream and razor scraper)
To Order Parts
Glass surface – potential for permanent damage
.
To clean the cooktop seal around the
edges of the glass, lay a wet cloth on it
for a few minutes, then wipe clean
with nonabrasive cleaners.
Cooktop Seal
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
25
Before You Call For Service…
GEAppliances.com
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Surface units will not
Improper cookware • Use pans which are flat and match the diameter
maintain a rolling boil
being used. of the surface unit selected.
or cooking is not
fast enough
Surface units do
A fuse in your home may be • Replace the fuse or reset the circuit breaker.
not work properly
blown or the circuit breaker
tripped.
Cooktop controls • Check to see the correct control is set for the surface
improperly set. unit you are using.
Scratches (may appear
Incorrect cleaning • Scratches are not removable. Tiny scratches will become
as cracks) on cooktop
methods being used. less visible in time as a result of cleaning.
glass surface
Cookware with rough bottoms • To avoid scratches, use the recommended cleaning
being used or coarse particles procedures. Make sure bottoms of cookware are clean
(salt or sand) were between before use, and use cookware with smooth bottoms.
the cookware and the surface
of the cooktop.
Cookware has been slid
across the cooktop surface.
Areas of discoloration
Food spillovers not cleaned • See the
Cleaning the glass cooktop
section.
on the cooktop
before next use.
Hot surface on a model • This is normal. The surface may appear discolored
with a light colored when it is hot. This is temporary and will disappear
glass cooktop. as the glass cools.
Plastic melted
Hot cooktop came into • See the
Glass surface—potential for permanent damage
to the surface
contact with plastic placed section in the
Cleaning the glass cooktop
section.
on the hot cooktop.
Pitting (or indentation)
Hot sugar mixture spilled • Call a qualified technician for replacement.
of the cooktop
on the cooktop.
Frequent cycling
Improper cookware • Use only flat cookware to minimize cycling.
off and on of
being used.
surface units
The display goes
Power surge. • Disconnect power at the fuse box or circuit breaker
blank or indicator
for at least 10 seconds. Turn power on and power
lights come on when
up your range. If the indicator lights are still on,
range is not in use
call for service.
Clock and timer do
Plug on range is not completely • Make sure electrical plug is plugged into a live, properly
not work
inserted in the electrical outlet. grounded outlet.
A fuse in your home may • Replace the fuse or reset the circuit breaker.
be blown or the circuit
breaker tripped.
Oven controls improperly set. • See the
Using the clock and timer
section.
26
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Before You Call For Service…
Troubleshooting Tips
Problem Possible Causes What To Do
Oven light does
Light bulb is loose or defective. • Tighten or replace the bulb.
not work
Switch operating • Call for service.
light is broken.
Oven will not work
Plug on range is not • Make sure electrical plug is plugged into a live, properly
completely inserted in grounded outlet.
the electrical outlet.
A fuse in your home may • Replace the fuse or reset the circuit breaker.
be blown or the circuit
breaker tripped.
Oven controls improperly set. • See the
Using the oven
section.
Door left in the • If necessary, allow the oven to cool then unlock
locked position. the door.
Food does not bake
Oven controls improperly set. • See the
Using the oven
section.
or roast properly
Shelf position is incorrect or • See the
Using the oven
section.
the shelf is not level.
Incorrect cookware or • See the
Using the oven
section.
cookware of improper
size being used.
Oven thermostat needs • See the
Adjust the oven thermostat—Do it yourself!
adjustment. section.
Food does not
Oven controls improperly set. • Make sure you turn the knob all the way to the
broil properly BROIL
position.
Door not open to the • See the
Using the oven
section.
broil stop position as
recommended.
Improper shelf position • See the
Broiling Guide.
being used.
Cookware not suited • Use the broiling pan and grid that came with your range.
for broiling.
Aluminum foil used on the • See the
Using the oven
section.
broiling pan and grid has
not been fitted properly and
slit as recommended.
In some areas the power • Preheat the broil element for 10 minutes.
(voltage) may be low.
• Broil for the longest period of time recommended in
the
Broiling Guide.
Oven temperature
Oven thermostat • See the
Adjust the oven thermostat—Do it yourself!
too hot or too cold
needs adjustment. section.
27
Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Problem Possible Causes What To Do
Power outage,
Power outage or surge. • Some models will automatically resume their setting
clock flashes
once the power is restored. On models with a clock,
you must reset the clock. If the oven was in use, you
must reset it by turning the Oven Temperature knob
back to
OFF,
setting the clock and resetting any
cooking function.
Storage drawer
Rear drawer support is • Reposition the drawer. See the
Storage Drawer
is crooked
on top of the guide rail.
Removal
instructions in the
Care and cleaning of your
range
section.
Storage drawer
Power cord may be • Reposition the drawer and power cord. See the
won’t close
obstructing drawer
Storage Drawer Removal
instructions in the
Care and
in the lower back
cleaning of your range
section.
of the range.
Rear drawer support is • Reposition the drawer. See the
Storage Drawer Removal
on top of the guide rail. instructions in the
Care and cleaning of your range
section.
Oven will not self-clean
The oven temperature • Allow the range to cool to room temperature and reset
is too high to set a the controls.
self-clean operation.
Oven controls improperly set. • Make sure you turn the control knob all the way to the
CLEAN
position.
Oven door is not in • Make sure you move the door latch handle all the
the locked position. way to the right.
Oven starts a self-clean
Oven door locked during • Turn the Oven Temperature knob to
OFF.
Allow the
cycle when you wanted
cooking. oven to cool. Never force the door latch handle.
to bake, roast or broil
“Crackling” or
This is the sound of the • This is normal.
“popping” sound
metal heating and cooling
during both the cooking
and cleaning functions.
Excessive smoking
Excessive soil. • Turn the Oven Temperature knob to
OFF.
Open
during a clean cycle
the windows to rid the room of smoke. Wait until
the
CLEAN
light goes off. Wipe up the excess soil
and reset the clean cycle.
Oven door will
Oven too hot. • Allow the oven to cool below locking temperature.
not unlock
CLEAN light flashes
Oven controls not • Move the door latch handle to the right before
properly set. setting the Oven Temperature knob to
CLEAN.
GEAppliances.com
28
Problem Possible Causes What To Do
Oven not clean after
Oven controls not • See the
Using the self-cleaning oven
section.
a clean cycle
properly set.
Oven was heavily soiled. • Clean up heavy spillovers before starting the clean
cycle. Heavily soiled ovens may need to self-clean
again or for a longer period of time.
Oven makes
This is the sound of the • This is normal.
clicking noise
heating element turning
off and on during
cooking functions.
CLEAN light is on
The oven door was • Turn the Oven Temperature knob to
OFF.
Allow the
when you want to cook
accidentally locked. oven to cool. Then move the latch to the far left.
Never force the door latch handle.
“F— and a number
You have a function • Turn the Oven Temperature knob to
OFF.
Put the oven
or letter” flash in
error code. back into operation.
If the function code repeats. • Disconnect all power to the range for at least
30 seconds and then reconnect power. If the
function error code repeats, call for service.
The display goes blank
Power surge. • Disconnect power at the fuse box or circuit breaker
or indicator lights come
for at least 10 seconds. Turn power on and power
on when range is not
up your range. If the indicator lights are still on,
in use
call for service.
The clock is in the • See the
Using the clock and timer
section.
black-out mode.
Oven door will
Oven too hot. • Turn the Oven Temperature knob to
CLEAN.
not lock
The glowing oven cleaning light after the knob is
turned indicates the oven is too hot from previous
use. To cool the oven, open the door wide, and allow
the oven to cool. After the oven has cooled, close
the door and slide the latch handle all the way to
the right.
“Burning” or “oily”
This is normal in a new • To speed the process, set a self-clean cycle
odor emitting from
oven and will disappear for a minimum of 3 hours. See the
Using the
the vent
in time.
self-cleaning oven
section.
Strong odor
An odor from the insulation • This is temporary.
around the inside of the
oven is normal for the first
few times the oven is used.
Before You Call For Service…
Troubleshooting Tips
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
29
General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
GE Service Protection Plus
™
GE, a name recognized worldwide for quality and dependability, offers you
Service Protection Plus
™
—comprehensive protection on all your appliances—
No Matter What Brand!
Benefits Include:
• Backed by GE
• All brands covered
• Unlimited service calls
• All parts and labor costs included
• No out-of-pocket expenses
• No hidden deductibles
• One 800 number to call
You will be completely satisfied with our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker
coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable
household products are protected against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁
Cut here
30
Consumer Product Ownership Registration
Important
Mail
Today!
General Electric Company
Louisville, Kentucky
GEAppliances.com
First
Name
Mr. ■■ Ms. ■■ Mrs. ■■ Miss ■■
Street
Address
City
State
Date Placed
In Use
Month
Day
Year
Zip
Code
Apt. #
Last
Name
Phone
Number
_
_
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Important: If you did not get a registration card with your
product, detach and return the form below to
ensure that your product is registered, or register
online at GEAppliances.com.
1
23
Model Number Serial Number
✁
Cut here
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a safety modification.
After mailing the
registration below,
store this document
in a safe place. It
contains information
you will need should
you require service.
Our service number is
800.GE.CARES
(800.432.2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
Model Number Serial Number
E-mail Address*
* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important
communications from GE Appliances (GEA).
■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.
31
Safety Instructions
Operating Instructions
Safety Instructions
Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
GE Electric Range Warranty.
■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused,
or used for other than the intended purpose or
used commercially.
■Damage to the glass cooktop caused by use of cleaners
other than the recommended cleaning creams.
■Damage to the glass cooktop caused by hardened
spills of sugary materials or melted plastic that
are not cleaned according to the directions in
the Owner’s Manual.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
What GE Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
For The Period Of: GE Will Provide:
One Year Any part
of the range which fails due to a defect in materials or workmanship. During this
From the date of the full one-year warranty,
GE will also provide,
free of charge,
all labor and in-home service to
original purchase
replace the defective part.
Five Years A replacement glass cooktop
if it should crack due to thermal shock, discolor, crack at the
From the date of the
rubber seal between the glass cooktop and the porcelain edge, or if the pattern wears off.
original purchase
A replacement radiant surface unit
if it should burn out.
During this
limited additional four-year warranty,
you will be responsible for any labor
or in-home service.
All warranty service provided by our Factory Service
Centers, or an authorized Customer Care
®
technician.
To schedule service, on-line, 24 hours a day, contact us
at GEAppliances.com, or call 800-GE-CARES.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
Printed in the United States
Consumer Support.
GE Appliances Website
GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts
™
”
your questions, and so much more...
Schedule Service
GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal
business hours.
Real Life Design Studio
GEAppliances.com
GE supports the Universal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties
GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories
GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause
unsafe operation.
Contact Us
GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance
GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
