27 IN. (69 CM) GAS WASHER/DRYER
INSTALLATION INSTRUCTIONS
WASHER/DRYER SAFETY
Table of Contents
WASHER/DRYER SAFETY.............................. 1
INSTALLATION INSTRUCTIONS.................... 3
Tools and Parts ............................................. 3
Alternate Parts............................................... 3
Location Requirements ................................ 3
Drain System................................................. 4
Electrical Requirements ................................ 5
Gas Supply Requirements............................ 5
Venting Requirements................................... 6
Remove Shipping Strap................................ 7
Install Leveling Legs...................................... 7
Connect the Drain Hose................................ 7
Connect the Inlet Hoses ............................... 8
Secure the Drain Hose.................................. 9
Plan Vent System.......................................... 9
Install Vent System...................................... 10
Level Washer/Dryer..................................... 10
Make Gas Connection ................................ 11
Connect Vent .............................................. 11
Complete Installation .................................. 12
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't
follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
When discarding or storing your old clothes dryer, remove the door.
SAVE THESE INSTRUCTIONS
8542750
