Air Sterilizer User Manual
* Thank you so much for purchasing Trustech Air Sterilizer.
* Please read the manual read before use.
24H Online After-Sales:
✉
trustech@afterservice.vip
☎ +1（855）620 5858
Introduction
This sterilizer equips ultraviolet disinfection and air circulation technology. The
disinfection machine is made of a filter, a UVC sterilizer, and an air circulation motor.
Sterilizer applies with the UVC light for disinfection and sterilization of indoor air.
Activated carbon filter works for removing odor, dirty gas, and particles, like pollen, dust,
and viruses, effectively fresh the air.
Features
1. Disinfection effect: Killing ≥99.9% of bacteria, viruses, mold spores, algae.
2. Activated Carbon Filter: Activated carbon filter works for removing odor, gas, and
particles, like pollen, dust, and viruses, effectively fresh the air. For a better radiation
intensity with less dust.
3. High-intensity ultraviolet disinfection: UVC ultraviolet radiation over 100 W/m
2
.
Ultraviolet light destroys germs & viruses that can build up on the filter, reducing the
re-circulation of germs.
4. Safety: The disinfection sterilizer apply to physical disinfection methods, no harmful
gases and substances are generated during the filtering.
Performance:
Model
APF-20M
Applicable scope
≤ 645
ft
²
Circulating air volume（CFM）
≥ 18 ft³/min
Rated voltage
120V
Rated frequency
60Hz
Power
14W
Irradiance inside the machine
≥ 100 W/m
2
UV light that out of the machine
≤ 0.01 W/m
2
Working Volume
≤ 59dB
Any Doubts? ✉ trustech@afterservice.vip
24H Online After-Sales:
✉
trustech@afterservice.vip
☎
+1
（
855
）
620 5858
How to start：Switch On/Off behind the machine
Air Outlet
Case
Foot Pad
On/Off Switch
Any Doubts? ✉ trustech@afterservice.vip
Back
Forward
Disinfection Process
Caution
These warnings apply to the appliance, and also where applicable, to all tools,
accessories, chargers or main adaptor.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
1. Prohibited to LOOK at the ultraviolet lamp during working.
2. Prohibited to expose the body under ultraviolet rays during working. In case that
being irradiated burns.
3. Please check whether the local voltage is suitable before first use. This sterilizer works
for 120V.
4. Suitable for dry location ONLY. Do not use at swimming pool or bathtub, or any wet
surfaces, do not expose to water or rain.
5. Do not handle any part of the plug or appliance with wet hands.
6. Do not use for sterilizing inflammable or explosive materials, or in the environment
with severe dust and oil pollution.
7. Use only as described in Trustech sterilizer Manual. Do not carry out any maintenance
other than that shown in this manual, or advised by the Trustech Hotline.
8. Do not put any object into the inlet or outlet grilles. Do not use with any opening
blocked; keep free of dust, lint, hair, and anything that may reduce airflow.
9. Unplug before cleaning or carrying out any maintenance.Use dry cloth or soft brush
for cleaning.
10. Turn off all controls before unplugging. Unplug from the socket when not in use for
extended periods. To avoid a tripping hazard, safely coil the cable.
11. Do not operate any appliance with a damaged cable or plug. If the supply cable is
damaged it must be replaced by Trustech in order to avoid a hazard.
12. The sterilizer must be placed on a flat floor.
13. The sterilizer should be at least 1.5 meters away from the fire source and ignition
source and avoid direct sunlight.
14. Do not unplug by pulling on the cable. To unplug, grasp the plug, not the cable. The
use of an extension cable is not recommended.
15. Prohibited to dismantle the machine, and no modification of the machine in any
form, so as to avoid danger.
16. Slight sound possibly generates when just switch on.
17. Do not use and store the product in wet or dusty places for long, in case that the
case corrosion or leakage due to moisture or other accidents.
18. Please contact the local after-sales center first once the product goes wrong.
Any Doubts?
✉
trustech@afterservice.vip
Cleaning and Maintenance
1. Please clean the product when not in use for extended periods.
And Packed them back to the original package in a dry location after all the parts dried.
2. Cut off the power supply before cleaning. Not to clean until the motor stop.
3. Do not use gasoline, toluene, or other solvents for cleaning. Wash the out case with
water, or slightly wipe it by soft cloth with a little neutral solvent.
4. All the standby units can be used only after dried.
Trouble-Shooting
Malfunction
Reason
Solution
Can’t turn on
1. The socket isn’t plugged in
2.
Poor connection
Try again plug in the socket
and make sure well connected
2. The switch isn’t turn on
Switch on the machine
3. Case Damage
1. Send to the repair point
2. Contact After-sales center
Can’t shut down
1. The switch isn’t turn off
Switch off the machine
2. Product Damage
1. Send to the repair point
2. Contact After-sales center
24H Online After-Sales:
✉
trustech@afterservice.vip
☎ +1（855）620 5858
Any Doubts? ✉trustech@afterservice.vip
WARRANTY
TRUSTECH warrants this product against defects in materials and/or workmanship under
normal use for a period of ONE (1) YEAR from the date of purchase by the original
purchaser (“Warranty Period”). If a defect arises and a valid claim is received within the
Warranty Period, at its options
TRUSTECH will either 1) repair the defect at no charge, using new replacement parts, or
2) replace the product with a new product that in same functions, or provide
corresponded price credit.
Any replacement parts or products provided by TRUSTECH, assumes the remaining
warranty of the original product. When the warranty service active, the original product
must be returned to TRUSTECH and becomes TRUSTECH’ s property.
E-mail TRUSTECH Online Warranty Service at trustech@afterservice.vip
Please provided:
1. Order Number of this product
2. Product Problems (You can provide pictures or videos to showing the disorder)
3. Replacement receiving address, if you would like to a replacement.
This warranty does not apply to:
a) damage caused by failure to follow instructions relating to product’s use or the
installation of components;
b) damage caused by accident, abuse, misuse, fire, floods, earthquake or other external
causes;
c) damage caused by service performed by who is not a representative of TRUSTECH;
d) accessories used in conjunction with a covered product;
e) a product or part that has been modified to alter functionality or capability;
f) items intended to be periodically replaced by the purchaser during the normal life
of the product including, without limitation, batteries or light bulbs;
g) any product sold “as is” including, without limitation, floor demonstration models
and refurbished items;
h) a product that is used commercially or for a commercial purpose.
24H Online After-Sales:
✉
trustech@afterservice.vip
☎ +1（855）620 5858
Any Doubts? ✉ trustech@afterservice.vip
CONTACT US
Thank you for choosing TRUSTECH product.
For any customer product questions or honor your warranty, please write to
trustech@afterservice.vip Our usual response time is within 12 hours!
Please provide:
1. Order Number of this product for Registration to extend the Warranty by 6
months.
2. Product Problems (You can provide pictures or videos to showing the disorder)
3. Replacement receiving Address, if you would like to a replacement.
Any Doubts? ✉ trustech@afterservice.vip
