Steam Iron
User's manual
EN
EN-1
SSI 5420RD
SSI 5421TQ
2019 05/2019
Prior to using this appliance, please read the user's manual thoroughly, even in cases, when one has
already familiarised themselves with previous use of similar types of appliances. Only use the appliance
in the manner described in this user's manual. Keep this user's manual in a safe place where it can be
easily retrieved for future use.
We recommend saving the original cardboard box, packaging material, purchase receipt and
responsibility statement of the vendor and warranty card for at least the duration of the legal liability
for unsatisfactory performance or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.
Translation of the original manual
EN-2
EN
Steam Iron
SSI 5420RD / SSI 5421TQ
2019 05/2019
TABLE OF CONTENTS
IMPORTANT SAFETY NOTICE ............................................................ 3
DESCRIPTION OF THE STEAM IRON ....................................................... 5
PREPARATION BEFORE IRONING ......................................................... 6
USING THE STEAM IRON ............................................................... 6
TIPS FOR QUALITY IRONING ............................................................ 8
MAINTENANCE AND CLEANING ......................................................... 8
STORAGE ............................................................................ 9
TECHNICAL SPECIFICATIONS ............................................................ 9
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS . . 9
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT ............................... 9
Steam Iron
SSI 5420RD / SSI 5421TQ
EN
EN-3
2019 05/2019
IMPORTANT SAFETY NOTICE
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may be used by children 8 years of age and
older and by persons with physical or mental impairments or by
inexperienced persons, if they are properly supervised or have
been informed about how to use the product in a safe manner
and understand the potential dangers.
• Children must not play with the appliance. Cleaning and
maintenance performed by the user must not be performed by
unsupervised children.
• In the event that the power cord is damaged, have it repaired
at a professional service centre to prevent causing a dangerous
situation. It is forbidden to use the appliance if it has a damaged
power cord.
• The iron may be used only on a stable, even surface. This also
applies for putting down the iron. When putting the iron down
on to the stand, check that the surface on which the stand is
located is stable.
• The water tank lid must not be open when ironing.
• The iron must not be used if it has fallen on the floor, exhibits
visible signs of damage or if it is leaking.
• The iron must not be left within the reach of children younger
than 8 years of age, when it is connected to mains electricity or
while it is cooling down.
• The iron must not be left without supervision when connected to
a power socket.
• Always disconnect the iron from the power socket when leaving it
without supervision, when filling up or emptying the water tank
and when you have finished using it. Turn off the steam function
before disconnecting the iron from the power socket.
• This iron is designed for home use.
• Do not use the iron in an industrial environment or outdoors.
• Before connecting the iron to a power socket check that the
EN-4
EN
Steam Iron
SSI 5420RD / SSI 5421TQ
2019 05/2019
nominal voltage stated on the rating label matches the electrical
voltage in the socket.
• The iron must not be left without supervision if it is connected to
an electrical power socket.
• The iron may be used only on a stable surface. This also applies
for putting down the iron. When putting the iron down on to
the stand, check that the surface on which the stand is located is
stable.
• Never iron clothing on a body.
• Do not touch the hot ironing surfaces. Otherwise, this could cause
burns.
• Always disconnect the iron from the power socket before filling
or emptying the water tank, before putting it away for a short
time or after finishing using it. Turn off the steam function before
disconnecting the iron from the el. power socket.
• Prior to cleaning or any other handling of the iron that you have
disconnected from the power socket, allow the soleplate to cool
down.
• To avoid potential injury by electrical shock, do not clean the
iron under running water, do not spray it with water and do not
submerge it in water or any other liquid.
• The iron must not be used if it has fallen on the floor, exhibits
visible signs of damage or if it is leaking.
• Ensure that the power cord does not come into contact with
water or a heated surface.
• Do not disconnect the iron from the power socket by pulling on
the power cord. This could damage the power cord or the power
socket. Disconnect the cord from the power socket by gently
pulling the plug of the power cord.
• To avoid the danger of injury by electrical shock, do not repair
the iron yourself or make any adjustments to it. Have all repairs
or adjustments performed at an authorised service centre. By
tampering with the product you risk voiding your legal rights
arising from unsatisfactory performance or quality warranty.
Steam Iron
SSI 5420RD / SSI 5421TQ
EN
EN-5
2019 05/2019
DESCRIPTION OF THE STEAM IRON
A
8
9
0
qa
qs
1
3
4
5
6
7
2
1 Handle
2 Indicator light showing that the set
temperature is being maintained
3 Steam boost button
4 Water spray button
5 Continuous steam control lever
6 Filling opening cap on the water tank
7 Spray nozzle
8 360° swivel power cord end
9 Temperature dial
serves to regulate the temperature.
0 Self-Clean button
for removing limescale deposits
qa Water tank with a capacity of 260 ml
qs Ceramic soleplate
qd Water container (not shown)
EN-6
EN
Steam Iron
SSI 5420RD / SSI 5421TQ
2019 05/2019
PREPARATION BEFORE IRONING
Sort the laundry according to international symbols shown on the textiles or according to the fabric types.
SYMBOL FABRIC TYPE SETTING THE TEMPERATURE DIAL
Synthetics
(nylon, polyamide, polyester, etc.)
●
low temperature
Silk – wool
●●
medium temperature
Cotton – linen
●●● to MAX
high temperature
Fabric, that should not be ironed
USING THE STEAM IRON
• Check that the iron is disconnected from the power socket.
• Wipe the soleplate Aqs with a lightly damp cloth before first use and then wipe dry.
1. FILLING THE WATER TANK
1.1 Prior to filling the water tank Aqa, check that the iron is disconnected from the power socket and that
the temperature dial A9 is set to the MIN position.
1.2 Set the continuous steam control lever A5 to the position marked by the symbol
.
1.3 Fill the included container Aqd with water. Use distilled water or tap water (soft to medium water hardness).
If water in your area is hard or very hard (more than 14 °dH / 2,5 mmol/l), we recommend that you use 1
part of distilled water and 1 part of tap water.
1.4 Place the iron in the upright position. Flip open the filling opening cap on the water tank A6. Use one
hand to hold the handle A1 and tilt the iron so that the soleplate Aqs is at an angle of about 45° relative
to the surface on which the iron is located. Then slowly pour the water from the container Aqd through
the filling opening into the water tank Aqa while making sure that the water level does not exceed the
maximum mark on the water tank Aqa.
1.5 Put the iron back into the upright position and close the water tank filling opening cap A6.
2. SETTING THE TEMPERATURE DIAL
2.1 Place the iron upright on an even and stable surface.
2.2 Insert the power cord into an electric power socket.
2.3 Set the temperature dial A9 according to the type of fabric that you wish to iron, see chapter Preparation
before ironing. The indicator light A2 will be lit. This signals that the soleplate Aqs is heating up. When
the soleplate Aqs heats up to the set temperature, the indicator light A2 will turn off. The iron is now
ready for ironing.
Steam Iron
SSI 5420RD / SSI 5421TQ
EN
EN-7
2019 05/2019
Note:
During first use, a weak cracking sound caused by the expanding plastic may be heard. This is an
entirely normal event, which will disappear in a short time.
While ironing, the indicator light A2 will intermittently turn on and off. This indicates that the
set temperature is being maintained.
First iron the laundry that requires the lowest temperature. This will save you time because the
soleplate Aqs heats up faster than it cools down.
If you are ironing at a high temperature and then set a lower temperature, wait until the soleplate
cools down.
3. CONTINUOUS STEAM FUNCTION
3.1 Set or turn off the continuous steam output using the continuous steam lever A5.
3.2 If you wish to iron with steam, the water tank Aqa must be filled with water and the temperature dial A9
must be set in the range from ●●● to MAX, which is suitable only for certain types of textile materials, see
chapter Preparation before ironing. Use the continuous steam lever A5 to select weaker ● or stronger
●● steam output.
3.3 If the continuous steam function is set at the same time as the temperature dial A9 is set to low ●
or medium temperature ●●, then water may drip from the soleplate Aqs. For this reason, the iron is
equipped with the Drip-Stop system, which automatically stops the steam process when the temperature
dial A9 is not set to a high enough temperature and so prevents potential dripping from the steam outlets.
Note:
The iron continuously emits steam only if you hold it in a horizontal position. You can stop the
release of steam by standing the iron upright.
3.4 If you wish to iron without the continuous steam function, set the lever A5 to the position marked by
the symbol
.
Attention:
Do not use the steam function for silk and synthetics so as not to damage the surface
of the fabric.
4. STEAM BOOST FUNCTION
4.1 Press the steam boost button A3 to generate a strong flow of steam which can even out even very
crumpled up textiles.
4.2 Only use the steam boost function when the temperature dial A9 is set in the range ●●● to MAX. In
order to use this function, the water tank Aqa must be filled with water. If the indicator light A2 is lit,
wait until it turns off and only then press the steam boost button A3. Wait at least 5 seconds before
pressing the button A3 again.
4.3 The steam boost function can also be used when vertical ironing textiles (e.g. curtains, garments hanging
on coat hangers, etc.).
Attention:
Do not use the steam boost function for silk and synthetics so as not to damage the
surface of the fabric.
5. WATER SPRAY FUNCTION
• The water spray function can be used at any ironing temperature. Make sure that there is water in the
water tank Aqa and to spray textiles using the spray nozzle A7 press the spray button A4.
EN-8
EN
Steam Iron
SSI 5420RD / SSI 5421TQ
2019 05/2019
Note:
We do not recommend using the spraying function on silk and synthetics.
6. TURNING OFF
• When you have finished using it, set the continuous steam control lever A5 to the position marked with
the symbol
and turn the temperature dial A9 to the MIN position. Disconnect the power cord from
the power socket and allow the soleplate Aqs to cool down. When the soleplate Aqs has cooled down,
pour out the water from the water tank Aqa into a sink.
TIPS FOR QUALITY IRONING
• Do not fill the washing machine drum with too much laundry, otherwise it will be overly crumpled up.
You can also avoid overly crumpled laundry by setting a lower spin drying speed.
• If you are ironing fabrics from blended materials (e.g. 40% wool and 60% synthetic material), set the
temperature dial according to the material which is ironed at a lower temperature.
• If you do not know the composition of the fabric, identify the suitable temperature dial setting by ironing
a piece of the fabric from the underside. Start by setting the temperature dial at a low temperature and
gradually increase it until the ideal temperatures is achieved.
• Never iron over places that have sweat marks or other stains. The high temperature fixes the stain,
making it difficult to remove.
• To avoid silk, wool and synthetic fabrics from being shiny after ironing, iron them from the underside.
• Some materials are easier to iron when they are lightly damp.
• Spray fine fabrics with the spray before ironing them or iron them under a lightly damp wiping cloth.
MAINTENANCE AND CLEANING
Cleaning the exterior parts of the iron
• Before cleaning, make sure that the continuous steam control lever A5 is set to position , the
temperature dial A9 is turned to the MIN position and the power cord is disconnected from the power
socket. Allow the soleplate Aqs to cool down. Flip open the cap A6 and then empty out the water tank
Aqa into a sink. Close the cap A6 again.
• Wipe the soleplate Aqs and the outer surface of the iron with a lightly dampened cloth. Then wipe
everything dry.
• Do not use metal items, petrol, solvents or abrasive cleaning products, etc. for cleaning to avoid
damaging the surface. Do not submerge the iron in water.
Removing limescale deposits
• For the removal of limescale deposits from the inner part of the soleplate Aqs, the iron is equipped with a Self-Clean
function. Use the Self-Clean function regularly at least once every 14 days.
• Make sure that the continuous steam control lever A5 is set to position
and that the iron is disconnected from the
power socket. Fill the tank Aqa with water up to approximately half its capacity. Do not add vinegar or other limescale
removers into the water. Connect the iron to a power socket. Set the temperature dial A9 to maximum and wait until
the indicator light A2 turns off. Disconnect the iron from the el. power socket and hold it in a horizontal position
above the sink. Press the Self-Clean button A0 and hold it down. Steam and hot water will start to be emitted from the
soleplate Aqs. At the same time also limescale deposits from the inner parts of the soleplate Aqs will be removed. Gently
move the iron from side to side until the water tank Aqa is completely empty. After emptying it out, release the button
A0. If the soleplate Aqs is very soiled, you can repeat this process once more.
• After completing the Self-Clean process, reconnect the iron to the power socket and allow it to heat up to maximum
temperature in order to dry out the soleplate Aqs. Iron over a piece of unneeded fabric to remove water stains that
formed on the soleplate Aqs during the cleaning process. Then set the temperature dial A9 to the MIN position,
disconnect the iron from the power socket and allow it to cool down. Finally, wipe the soleplate Aqs using a clean cloth.
Steam Iron
SSI 5420RD / SSI 5421TQ
EN
EN-9
2019 05/2019
STORAGE
• Store the iron in the upright position in a clean and dry place out of reach of children.
TECHNICAL SPECIFICATIONS
Rated voltage .........................................................................................................................................220−240 V
Rated frequency .........................................................................................................................................50/60 Hz
Rated power input ......................................................................................................................................2200 W
Changes to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or electronic
products must not be added to ordinary municipal waste. For proper disposal,
renewal and recycling hand over these appliances to determined collection points.
Alternatively, in some European Union states or other European countries you
may return your appliances to the local retailer when buying an equivalent new
appliance. Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human health, which
could result from improper waste disposal. Ask your local authorities or collection
facility for more details. In accordance with national regulations penalties may be
imposed for the incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This appliance meets all the basic requirements of EU directives related to it.
EN-10
EN
Steam Iron
SSI 5420RD / SSI 5421TQ
2019 05/2019
