SMART
GREATER CONTROL AT THE SITE WITH TWO RELAYS THAT CAN BE
CONTROLLED INDIVIDUALLY OR TOGETHER.
INCREASED CONVENIENCE WITH CODES THAT CAN BE PROGRAMMED
USING 4 OR 5 DIGITS AND ACTIVATE ONE OR BOTH RELAYS.
STORES DATABASE INFORMATION IN MEMORY WHEN THE POWER
GOES OUT, ENSURING IMMEDIATE STARTUP AND OPERATION WHEN
POWER IS RESTORED.
RELIABLE
ENGINEERED TO BE WEATHER-RESISTANT AND HIGHLY
VANDAL-RESISTANT WITH A WELL-CRAFTED LOOK FOR INTERIOR OR
EXTERIOR USE.
EXCELLENT VISIBILITY DAY OR NIGHT WITH RECESSED SIDE-LIT
METAL KEYPAD.
SECURE
PREVENTS UNAUTHORIZED ENTRY BY DISABLING KEYPAD FOR 3
MINUTES IF AN UNAUTHORIZED USER HAS ATTEMPTED TOO MANY
INCORRECT ENTRY CODES. THE SYSTEM CAN BE PROGRAMMED TO
PERMIT FROM 1 TO 10 ATTEMPTS PRIOR TO ENGAGING THE LOCKOUT.
PRODUCT GUIDE MK500GS
MINIKEY ACCESS CONTROL SYSTEM
Self-Contained Keypad System for Door and Gated Entrances.
MINIKEY ACCESS CONTROL SYSTEM
MK500GS
TOTAL SOLUTION ACCESSORIES:
STAND-ALONE
ACCESS SYSTEM
Compact for
easy installation
K
E
Y
F
E
A
T
U
R
E
PED42 / PED64
GOOSENECK PEDESTAL
42 in. pad mount or 64 in. in-ground
pedestal 2x2 in. square pipe, black
powdered coat finish 11 ga. Steel.
MG1300
LIFTMASTER ELITE SERIES
®
Maglock 12/24VDC with Junction Box
features 1,300 lbs. holding force.
MK500GS
MINIKEY ACCESS CONTROL SYSTEM
© 2018 LiftMaster. All Rights Reserved.
300 Windsor Drive, Oak Brook, IL 60523
LiftMaster.com
LMPAENPGMINI 0118
STANDARD SPECS.
SHIPPING WEIGHT (in lbs.)
CARTON (1)
- 12.25" W x 11.12" H x 7.5" D
- Keypad System
- Power Supply
- Instruction Manual
SHIPPING.
6.0
For Support Tools and Training Videos, Visit
LiftMasterTraining.com
For More Information, Visit
LiftMaster.com/AccessControl
Sales Support: 800.282.6225
Technical Support Center: 800.528.2806
LiftMasterDealer.CustHelp.com/App/Ask
WARRANTY
- 1-Year Limited
RELAYS
- (1) Main Unit
- (1) Auxiliary
CAPABILITIES
- 500 Entry Codes
- Variable Entry Code Length – can be programmed
using 4 or 5 digits and can activate a single relay
or both relays.
- Two Relays, one for the main unit and one auxiliary
relay to support status inputs up to 500 feet from
the main unit.
- Relays can be controlled individually or together.
- Programmable Relay Times – each relay may be
programmed independently to activate from
2 to 255 seconds.
- Time Clock Input feature makes it possible to use a
dealer-supplied time clock to prevent entry to the
facility at a specified time.
- Lightning Protection – inputs and power connections
contain some protection against typical voltage
spikes. However, in an area where lightning is
prevalent, external surge suppressors should be
used to minimize damage to the system.
POWER
- 12VAC or 13.5VDC
MECHANICS
- Grained Stainless Steel - Surface Mount
DIMENSIONS
- Surface Mount:
4.5" W x 4.5" H x 3.5" D
MASTERFUL ENGINEERING.
4.5"
4.5"
3.5"
