Installation
Instructions
Instructions en franqais : ................ 4
Instrucciones en espa5ol: ............... 8
Pedestal Models
White Pedestal SPSD157JWW
Metallic Gold SPSD157JMG
Metallic Vermillion SPSDI57JMV
For Washer Model: WPDH8800
For Drger Models: DPVH880EJ, DPVH8800GJ
BEFORE YOU BEGIN
Read these instructions completelg
and cerefullg.
• IMPORTANT - Savetheseinstructions
for local inspector's use.
• IMPORTANT-Observeallgoverning
codes and ordinances.
• Note to Consumer - Keep these instructions
with gour Owner's Manual for future reference.
• Completion time - i to 2 hours
• Proper installation is the responsibilitg
of the installer.
• Product failure due to improper installation is not
covered under the Warrantg.
_, CAUTION - Duetothesizeandweight
of these products, and to reduce the risk of
personal injury or damage to the product, TWO
PEOPLEARE REQUIRED FOR PROPERINSTALLATION.
• Seewasher and drger installation instructions for
additional installation requirements and guidelines.
TOOLS YOU WILL NEED
PhillipsHead
Screwdriver
9/16" Open End Wrench
or Adjustable Wrench
8 mm Socket Wrench
INSTALLATION PREPARATION
Remove the packaging.
The Drawer divider is taped at the top of the
shipping carton. Remove the divider and set aside
for final installation.
Flatten the product carton to use as a pad
to lag the washer or drger down on its side.
Continue using the carton to protect the finished floor
in front of the installation location.
KIT CONTENTS
4 Support Pads
4 Mounting Screws
Drawer Divider
[] REMOVE THE LEVELING LEGS
[] Carefullg lag the washer or drger on its side
to access the leveling legs on the bottom
of the appliance.
IMPORTANT: Do not leg the washer or drger
on its back! Do not remove the shipping bolts
on the back side of the washer. The bolts must
remain in place until the washer is returned
to on upright position.
[] Use an open-end wrench to remove the
washer or drger leveling legs.
1
