SOLAR LED LAWN LIGHT (VT-984)
INSTALLATION INSTRUCTION
This marking indicates that this product should
not be disposed of with other household wastes.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best.The warranty is valid for 3 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. This
product is warranted for manufacturing defects only.!
! WARNING
1. Installation must be performed by a qualified person.
2. The light source of this luminaire is not replaceable, when the light source reaches its end of life
the whole luminaire should be replaced.
3. Replace any cracked protective shield.
4. Don't immerse in the water
5. Luminaire cannot be installed in low-lying areas, so as not to soak.
INSTALLATION DIAGRAM:
INSTALLATION INSTRUCTION
1. Drill the holes in the ground.
2. Dig the plastic into the hole.
3. Fix the plate onto the ground and tighten the screws
SWITCH FUNCTION:
Press 1st time: to change the color into Warm White or Manually switch on the light
Press 2nd time: to change the color into White
Press 3rd time: to switch off the light
OPERATING MODES:
• At the dusk, automatically turn on the light to 100% brightness. (up to 12 hours)
• At the dawn, light will automacally turns off
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
TECHNICAL DATA:
SKU 2891
LUMENS 110LM
NO. OF LEDs
24 Pcs
BEAM ANGLE 170°
DIMENSION 15x15x94cm
BATTERY CAPACITY
AC: 3.7V, 2200mAh, 18650 Li
SOLAR PANEL DATA:
SOLAR PANEL WATTS
2W, DC: 5.5V
CHARGING TIME 5-6 Hours
WORKING TIME 3-12 Hours
SOLAR PANEL
3
YEARS
WARRANTY
*
IP65
RATING
PRESS 1 TIME: WW
PRESS 2 TIME: W
PRESS 3 TIME: DW
PRESS 4 TIME: OFF
Non-replaceable light source
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
