4.1 SCOPE
Straight cutting or scroll cutting on mild steel up to 1.2mm thick. Any other use other than that it
was designed for is considered misuse.
4.2 SPECIFICATION
Stock no. ................................................................................................................................. 70833
Part no. ..........................................................................................................................DAT-ABSSG
Strokes per minute ......................................................................................................... 10,000s/min
Working air pressure ...................................................................................................90psi (6.2bar)
Average air consumption......................................................................................................... 2.5cfm
Min. air line size (inner Ø) ................................................................................................
3
⁄
8
" (10mm)
Air inlet ....................................................................................................................................
1
⁄
4
"BSP
Sound pressure level* .......................................................................................................TBCdB(A)
Sound power level** ..........................................................................................................TBCdB(A)
Vibration level.......................................................................................................................TBCm/s
2
Weight (air tool only)................................................................................................................ 0.64kg
Warning!
● Wear safety glasses and ear defenders.
* Continuous A-Weighted Sound Pressure Level at the workstation in accordance to prEN ISO 15744:1999
and declared according to EN ISO 4871.
** A-Weighted Sound Power Level in accordance to prEN ISO 15744:1999 and declared according to EN
ISO 4871.
⁄
⁄
