Refrigerator
User manual (freezer only)
RZ32*
Free Standing Appliance
Untitled-6 1 2021-11-29 5:49:19
English2
Contents
Contents
Safety information
3
Important safety symbols and precautions: 6
Severe warning signs for transportation and site 7
Critical installation warnings 7
Installation cautions 11
Critical usage warnings 12
Usage warning 16
Usage cautions 17
Cleaning cautions 19
Critical disposal warnings 20
Additional tips for proper usage 21
Saving Energy Tips 22
This appliance is intended to be used in household and similar applications such as 23
Instructions about the WEEE 24
Installation
25
Refrigerator at a glance 25
Step-by-step installation 26
Operations
31
Feature panel 31
Special features 33
Maintenance
38
Door reversal 38
Handle and care 47
Cleaning 50
Replacement 51
Troubleshooting
52
General 52
Do you hear abnormal sounds from the refrigerator? 54
Appendix
56
Safety Instruction 56
Install Instruction 56
Temperature Instruction 57
Information for model and ordering spare parts 60
Untitled-6 2 2021-11-29 5:49:19
English 3
Safety information
• Before using your new Samsung Refrigerator, please read
this manual thoroughly to ensure that you know how to
operate the features and functions that your new appliance
offers safely and efciently.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or those who lack experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision. Children
aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• Warnings and Important Safety Instructions in this manual
do not cover all possible conditions and situations that
may occur.
It is your responsibility to use common sense, caution,
and care when installing, maintaining, and operating your
appliance.
Safety information
Untitled-6 3 2021-11-29 5:49:19
Safety information
English4
Safety information
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual and
not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
• In order to avoid the creation of a ammable gas-air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used.
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer. The room must be 1 m³
in size for every 8 g of R-600a refrigerant inside the
appliance. The amount of refrigerant in your particular
appliance is shown on the identication plate inside the
appliance.
• Refrigerant squirting out of the pipes could ignite or cause
an eye injury. When refrigerant leaks from the pipe, avoid
any naked ames and move anything ammable away
from the product and ventilate the room immediately.
- Failing to do so may result in re or explosion.
• It is hazardous for anyone other than an Authorised
Service Person to service this appliance.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• To avoid contamination of food, please respect the
following instructions:
- Opening the door for long periods can cause a
signicant increase of the temperature in the
compartments of the appliance.
Untitled-6 4 2021-11-29 5:49:19
English 5
Safety information
- Clean regularly surfaces that can come in contact with
food and accessible drainage systems.
- Clean water tanks if they have not been used for 48 h;
ush the water system connected to a water supply if
water has not been drawn for 5 days.
- Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
- Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making icecream and
making ice cubes.
- One-, two- and three-star compartments are not suitable
for the freezing of fresh food.
- If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
Warning; Risk of re / ammable materials
Untitled-6 5 2021-11-29 5:49:19
Safety information
English6
Safety information
Important safety symbols and precautions:
Please follow all safety instructions in this manual. This
manual uses the following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal
injury, property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal
injury and/or property damage.
NOTE
Useful information that helps users understand or benet
from the refrigerator.
These warning signs are here to prevent injury to you and
others.
Please follow them carefully.
After reading this section, keep it in a safe place for future
reference.
Untitled-6 6 2021-11-29 5:49:19
English 7
Safety information
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should
be taken to ensure that no parts of the refrigerating circuit
are damaged.
- Refrigerant leaking from the pipe work could ignite
or cause an eye injury. If a leak is detected, avoid any
naked ames or potential sources of ignition and air
the room in which the appliance is standing for several
minutes.
- This appliance contains a small amount of isobutane
refrigerant (R-600a), a natural gas with high
environmental compatibility that is, however, also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place
where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an
electric shock or re.
• Do not place this refrigerator in direct sunlight or expose it
to the heat from stoves, room heaters, or other appliances.
Untitled-6 7 2021-11-29 5:49:19
Safety information
English8
Safety information
• Do not plug several appliances into the same multiple
power strip. The refrigerator should always be plugged
into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s
rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause
a re hazard from overheated wires.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion
damage along its length or at either end.
• Do not bend the power cord excessively or place heavy
objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, insert the power cord
between objects, or push the power cord into the space
behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
• Never unplug your refrigerator by pulling on the power
cord. Always grip the plug rmly and pull straight out from
the outlet.
- Damage to the cord may cause a short-circuit, re, and/
or electric shock.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
Untitled-6 8 2021-11-29 5:49:19
English 9
Safety information
• Do not install this appliance near a heater or inammable
material.
• Do not install this appliance in a location where gas may
leak.
- This may result in an electric shock or re.
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you
use it.
• Connect the power plug in the proper position with the
cord hanging down.
- If you connect the power plug upside down, the wire
can get cut off and cause a re or electric shock.
• Make sure that the power plug is not crushed or damaged
by the back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts
the packing materials on his or her head.
• The appliance must be positioned so that the plug is
accessible after installation.
- Failing to do so may result in an electric shock or re
due to electric leakage.
• Do not install this appliance in a humid, oily or dusty
location, in a location exposed to direct sunlight and water
(rain drops).
- Deteriorated insulation of electrical parts may cause an
electric shock or re.
• If any dust or water is in the refrigerator, pull out power
plug and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
Untitled-6 9 2021-11-29 5:49:19
Safety information
English10
Safety information
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with
the product, or injury.
• You need to remove all the protective plastic lm before
you initially plug the product in.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or repair
any part of the appliance. Power leakages can cause
severe electric shock.
• Never use gas pipes, telephone lines, or other potential
lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage
from the refrigerator.
- This may result in an electric shock, re, explosion, or
problems with the product.
• Plug the power plug into the wall socket rmly. Do not use
a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
• If the power cord is damaged, have it replaced
immediately by the manufacturer or one of its service
agents.
• The fuse on the refrigerator must be changed by a
qualied technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
Untitled-6 10 2021-11-29 5:49:19
English 11
Safety information
• When positioning the appliance, ensure the supply cord is
not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it
on a at surface.
- Keep the ventilation space in the appliance enclosure or
mounting structure clear of obstructions.
• Allow the appliance to stand for 2 hours before loading
foods after installation and turning on.
• We strongly recommend you have a qualied technician or
service company install the refrigerator.
- Failing to do so may result in an electric shock, re,
explosion, problems with the product, or injury.
• Overload on any one door may fell the refrigerator,
causing physical injury.
Untitled-6 11 2021-11-29 5:49:19
Safety information
English12
Safety information
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet
hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as
chopsticks, etc.) into the bottom or the back of the
refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances
(benzene, thinner, propane gas, alcohol, ether, LP gas, and
other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not
play with the appliance.
- Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the
area.
Untitled-6 12 2021-11-29 5:49:19
English 13
Safety information
• Do not let children hang on the door or door bins. A
serious injury may occur.
• Do not let children go inside the refrigerator. They could
become trapped.
• Do not insert your hands into the bottom area under the
appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientic materials,
or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must
not be stored in the refrigerator.
• Do not place or use electrical appliance inside
the refrigerator/freezer, unless they are of a type
recommended by the manufacturer.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service
center.
• If any dust or water is in Refrigerator, pull out power plug
and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter
inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or
personal injury.
Untitled-6 13 2021-11-29 5:49:20
Safety information
English14
Safety information
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and
cause personal injury or material damage.
• Do not spray volatile material such as insecticide onto the
surface of the appliance.
- As well as being harmful to humans, it may also result
in an electric shock, re, or problems with the product.
• Do not use or place any substances sensitive to
temperature such as ammable sprays, ammable objects,
dry ice, medicine, or chemicals near or inside of the
refrigerator.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odours.
- This may result in an electric shock or re.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance. This may
result in an electric shock, re, problems with the product,
or injury. Do not put a container lled with water on the
appliance.
- If spilled, there is a risk of re or electric shock.
• Do not use mechanical devices or any other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Never stare directly at the UV LED lamp for long periods of
time.
- This may result in eye strain due to the ultraviolet rays.
Untitled-6 14 2021-11-29 5:49:20
English 15
Safety information
• Do not put freezer shelf in upside down. Shelf stopper
could not work.
- It may cause a personal injury because of glass shelf
drop.
• Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the area.
• If a gas leak is detected, avoid any naked ames or
potential sources of ignition, and air the room in which the
appliance is standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Use only the LED Lamps provided by the manufacturer or
its service agents.
• Bottles should be stored tightly together so that they do
not fall out.
• This product is intended only for the storage of food in a
domestic environment.
• Do not attempt to repair, disassemble, or modify the
refrigerator yourself.
- Unauthorized modications can cause safety problems.
To reverse an unauthorized modication, we will charge
the full cost of parts and labor.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled,
contact your nearest service center.
- Failing to do so may result in an electric shock, re,
problems with the product, or injury.
Untitled-6 15 2021-11-29 5:49:20
Safety information
English16
Safety information
• If the interior or exterior LED lamp has gone out, contact
your nearest service center.
• If the refrigerator emits a burning smell or smoke, unplug
the refrigerator immediately and contact your Samsung
Electronics service center.
- Failing to do so may result in an electric or re hazards.
• Pull the power plug out of the socket before changing the
interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light,
contact a Samsung service center.
• If the product is equipped with LED lamps, do not
disassemble the Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or
loose wall socket.
- This may result in an electric shock or re.
Usage warning
WARNING
• Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
Untitled-6 16 2021-11-29 5:49:20
English 17
Safety information
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
Usage cautions
CAUTION
• Do not re-freeze frozen foods that have thawed
completely. Do not place carbonated or zzy drinks in
the freezer compartment. Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the glass may break and
cause personal injury.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of
the refrigerator as this can obstruct free air circulation
in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers
before putting it into the refrigerator.
- Do not place glass bottles or carbonated beverages
into the freezer. They can freeze and break. Broken
beverage containers can cause injury.
- Please observe maximum storage times and expiration
dates of frozen goods.
• Do not place glass or bottles or carbonated beverages into
the freezer.
- The container may freeze and break, and this may
result in injury.
Untitled-6 17 2021-11-29 5:49:20
Safety information
English18
Safety information
• Do not place carbonated or zzy drinks in the freezer
compartment. Do not put bottles or glass containers in the
freezer.
- When the contents freeze, the glass may break and
cause personal injury and property damage.
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd
party on this nished appliance are not covered
under Samsung warranty service, nor is Samsung
responsible for safety issues that result from 3rd party
modications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic
bag, the refrigerator can be over cooled.
• Wipe excess moisture from the inside and leave the doors
open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply,
you should wait for at least ve minutes before plugging it
back in.
• When the refrigerator got wet by water, pull out the power
plug and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or
property damage.
• Be careful that your ngers are not caught in.
• If the refrigerator is ooded, make sure to contact your
nearest service center.
- There is a risk of electric shock or re.
Untitled-6 18 2021-11-29 5:49:20
English 19
Safety information
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator to remove
bad odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the
appliance, unplug the power plug and contact your nearest
service center.
- Failing to do so may result in an electric shock or re.
• Use a clean, dry cloth to remove any foreign matter or dust
from the power plug blades. Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto
it.
• Do not use benzene, thinner, or Clorox, Chloride for
cleaning.
- They may damage the surface of the appliance and may
cause a re.
• Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
- Failing to do so may result in an electric shock or re.
Untitled-6 19 2021-11-29 5:49:20
Safety information
English20
Safety information
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product
in an environmentally friendly manner.
• Ensure that none of the pipes on the back of the
refrigerator are damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the freezer to see which refrigerant is used for
your refrigerator. If this refrigerator contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/
door seals and door latch so that small children or
animals cannot become trapped inside. Children should
be supervised to ensure that they do not play with the
appliance. If trapped inside, a child may get hurt or
suffocate to death.
- If trapped inside, the child may become injury and
suffocate to death.
• Cyclopentane is used in the insulation. The gases in the
insulation material require a special disposal procedure.
Please contact your local authorities in regard to the
environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
- If a child places a bag over his or her head, the child
could suffocate.
Untitled-6 20 2021-11-29 5:49:20
English 21
Safety information
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your
electric company and ask how long the failure is going to
last.
- Most power failures that are corrected in an hour or two
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings
while the power is off.
- Should the power failure last more than 24 hours,
remove and discard all frozen food.
• The refrigerator might not operate consistently (frozen
contents can thaw or temperatures can become too
warm in the frozen food compartment) if sited for an
extended period of time in a location where ambient air
temperatures are constantly below the temperatures for
which the appliance is designed.
• In case of particular foods, keeping it under refrigeration
can have a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts,
wrap the frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed
completely.
Untitled-6 21 2021-11-29 5:49:20
Safety information
English22
Safety information
Saving Energy Tips
• Install the appliance in a cool, dry room with adequate
ventilation. Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat (a radiator, for
example).
• Not to block any vents and grilles is recommended for
energy efciency.
• Allow warm food to cool down before placing it in the
appliance.
• Put frozen food in the refrigerator to thaw. You can then
use the low temperatures of the frozen products to cool
food in the refrigerator.
• Do not keep the door of the refrigerator open for too long
when putting food in or taking food out. The shorter the
time the door is open, the less frost build-up you’ll have in
the freezer.
• It is recommended to install the refrigerator with clearance
to the back and sides. This will help reduce power
consumption and keep your energy bills lower.
• For the most efcient use of energy, please keep the all
inner ttings such as baskets, drawers, shelves on the
position supplied by manufacturer.
Untitled-6 22 2021-11-29 5:49:20
English 23
Safety information
This appliance is intended to be used in household
and similar applications such as
• staff kitchen areas in shops, ofces and other working
environments;
• farm houses and by clients in hotels, motels and other
residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
Untitled-6 23 2021-11-29 5:49:20
Safety information
English24
Safety information
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government ofce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
For information on Samsung’s environmental commitments
and product regulatory obligations, e.g. REACH, WEEE or
Batteries, visit our sustainability page available via
www.samsung.com
(For products sold in European countries and in the UK only)
Untitled-6 24 2021-11-29 5:49:20
English 25
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and to
prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with the local regulations.
• To prevent electric shock, unplug the power cord before servicing or replacements.
Refrigerator at a glance
The actual image and provided parts of the refrigerator may differ, depending on the
model and the country.
01
03
02
04
07
05
06
01 Door bin
02 Top shelf cover *
03 Freezer shelf
04 Freezer drawer
05 Slim Ice Maker *
06 Ice cube bin *
07 Bottom drawer
* applicable models only
NOTE
• For best energy efciency, make sure all of shelves, drawers, and baskets are placed in
their original position.
Installation
Untitled-6 25 2021-11-29 5:49:20
Installation
English26
Installation
Step-by-step installation
STEP 1 Select a site
Site requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for opening and closing the door
• Away from a heat source
• Room for maintenance and servicing
• Temperature range: between 10 °C and 43 °C
Clearance
See the following gures and tables for space requirements for installation.
C
B
A
Depth “A” 688
Width “B” 595
Overall Height “C” 1853
(unit : mm)
Untitled-6 26 2021-11-29 5:49:20
English 27
Installation
01
03
05
06
07
08
04
02
01 more than 50 mm recommended
02 more than 12 mm recommended
03 105°
04 175.5
05 765.5
06 575
07 2.5
08 1194
(unit : mm)
NOTE
The measurements in the table may differ, depending on the measuring method.
STEP 2 Spacing (applicable models only)
1. Open the door and locate the provided
spacers (x2).
2. Unpack both spacers and attach them
to the rear of the refrigerator as shown.
They help ventilate air to the rear wall
and save power consumption.
Untitled-6 27 2021-11-29 5:49:20
Installation
English28
Installation
STEP 3 Flooring
• The surface to install the refrigerator
must support a fully loaded refrigerator.
• To protect the oor, put a large piece
of cardboard on each foot of the
refrigerator.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to, use a thick paper or cloth such
as old carpet along the movement path.
Untitled-6 28 2021-11-29 5:49:21
English 29
Installation
STEP 4 Adjust the leveling legs
CAUTION
• The refrigerator must be leveled on a at, solid oor. Failing to do so can cause damage
to the refrigerator or physical injury.
• Leveling must be performed with an empty refrigerator. Make sure no food items
remain inside the refrigerator.
• For safety reasons, adjust the front side a little higher than the rear side.
The refrigerator can be leveled using the front legs that have a special screw (leveler) for
leveling purposes. Use a at-head screwdriver for leveling.
To adjust the height of the left side:
Insert a at-head screwdriver into the
leveler of the front left leg. Turn the
leveler clockwise to raise, or turn it
counterclockwise to lower.
To adjust the height of the right side:
Insert a at-head screwdriver into the
leveler of the front right leg. Turn the
leveler clockwise to raise, or turn it
counterclockwise to lower.
Untitled-6 29 2021-11-29 5:49:21
Installation
English30
Installation
STEP 5 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Remove the PE foam sheet on each shelf corner, which is attached to protect the
refrigerator during transportation.
2. Plug the power cord into the wall socket to turn the refrigerator on.
3. Open the door, and check if the interior light lights up.
4. Set the temperature to the lowest, and wait until the refrigerator reaches the set
temperature. Now the refrigerator is ready for use.
NOTE
When the refrigerator powers on, the alarm will sound. To turn off the alarm, press
Freezer.
STEP 6 Final check
When installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from the
wall or the cabinet.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when you
open the door.
Untitled-6 30 2021-11-29 5:49:21
English 31
Operations
Feature panel
01 02 03 04
01 Temp. / Mode select 02 Power Freeze
03 Door Alarm 04 Lock
01 Temp. / Mode select
Temp.
Press to set the desired temperature.
• In Freezer mode, you can set the temperature between -15 °C and
-23 °C. (Default temperature is -19 °C)
• In Fridge mode, you can set the temperature between 7 °C and 1 °C.
(Default temperature is 3 °C)
Mode select
Press for 3 seconds to switch the mode between Freezer and Fridge.
• Freezer indicator turns on when Freezer mode is selected.
• Fridge indicator turns on when Fridge mode is selected.
WARNING
• Do not put glass bottles containing liquid in the freezer. When cancelling Fridge mode,
the glass bottles may break or burst in the freezer.
• Make sure to remove frozen food from the freezer before enabling the Fridge mode.
Frozen foods melt and spoil as the temperature increases (Freezer mode changes to
Fridge mode).
• Make sure to remove chilled foods from the freezer before disabling the Freezer mode.
Chilled foods may freeze as the temperature decreases (Fridge mode changes to Freezer
mode).
NOTE
If you want to use Fridge mode, it is strongly recommended to use plastic containers to
store food, especially vegetables.
Operations
Untitled-6 31 2021-11-29 5:49:21
Operations
English32
Operations
02 Power Freeze (3 sec)
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed.
The freezer keeps running at full speed for 50 hours and then returns
to the previous temperature.
• To activate Power Freeze, press and hold
Power Freeze for 3
seconds. The LED indicator on the left side of the button lights up,
and the refrigerator will speed up the freezing process.
• To deactivate, press and hold Power Freeze for 3 seconds again.
The freezer returns to the previous temperature setting.
• To freeze large amounts of food, activate Power Freeze for at least
20 hours before putting food in the freezer.
NOTE
• Using Power Freeze increases power consumption. Make sure you
turn it off and return to the previous temperature if you do not
intend to use it.
• To quickly freeze large quantities of food, remove the drawers and
use the provided shelf.
03 Door Alarm
Door Alarm
You can set the alarm for a reminder. If the door is left open for more
than 2 minutes, the alarm will sound with the LED indicator on the left
side of the button blinking.
You can toggle to enable and disable the alarm by pressing
Door
Alarm.
04 Lock (3 sec)
Lock
To prevent accidental manipulation, press and hold Lock for 3 seconds
to activate the Lock. All controls will be disabled with the LED
indicator on the left side of the button on.
To deactivate, press and hold again for 3 seconds. The controls will be
enabled as normal.
Untitled-6 32 2021-11-29 5:49:21
English 33
Operations
Special features
The actual image and special functions of your refrigerator may differ depending on the
model and the country.
Slim Ice Maker (applicable models only)
01
02
03
04
05
01 Water bin
02 Ice maker lever
03 Ice bucket
04 Ice tray
05 Ice tray cover
NOTE
If you do not intend to make ice, remove the Slim Ice Maker to secure more room for
storage. In this case, you can use the ice bucket as a multipurpose storage bin.
Untitled-6 33 2021-11-29 5:49:21
Operations
English34
Operations
To dispense ice manually
1. Pull up the handle of the water bin to
open, and then ll the bin with water up
to the max line. Gently close the bin so
that water does not drop or leak.
CAUTION
• Do not exceed the max line. Excessive
water causes the ice to jam and not
dispense well.
• Use only potable water. Other liquids,
such as green tea or milk may not
dispense well.
• Gently close the water bin. Otherwise,
the water may drop or leak.
NOTE
• If you encounter a water leak, open the
water bin and check if the water bin’s
passage to the ice tray is frozen. If this
is the case, pour lukewarm water into
the water bin up to the max line. Let the
passage melt.
• It is recommended to clean the water
bin’s passage to the ice tray on a regular
basis because the passage is likely to
freeze.
2. Check if the ice freezes completely. Only
when the ice has frozen completely, pull
up the ice maker lever. Then, the ice
tray rotates and dispenses ice to the ice
bucket.
CAUTION
• Do not pull up the lever until the ice has
frozen completely. Half-frozen ice may
jam and damage the ice bucket.
Untitled-6 34 2021-11-29 5:49:21
English 35
Operations
1
2
3. To dispense ice, slightly lift up the ice
bucket and tilt to the front.
CAUTION
• Do not tilt without lifting the ice bucket. The ice bucket may break.
• Do not pour water directly into the ice bucket for ice making. The ice bucket may break.
• Do not leave the freezer door open. The ice in the ice bucket melts and jams.
• In case of a power failure, make sure to empty the ice bucket before making ice.
• Use only potable water.
NOTE
• The ice cubes may not dispense at once, depending on the ice state. In this case, try
pulling the lever several times.
• If the ice does not dispense because an excessive amount of water was lled, remove
the ice tray and empty. If this issue continues, uninstall the Slim Ice Maker unit and
empty.
Untitled-6 35 2021-11-29 5:49:21
Operations
English36
Operations
To open the top shelf cover (applicable models only)
1. Fully pull up the front end of the top
shelf cover.
2. Then, push the cover inwards to the end.
NOTE
• To remove or put an item from the freezer, you must fold up the top shelf cover rst.
• The top shelf cover is removable. You can remove it if you do not intend to use it.
Untitled-6 36 2021-11-29 5:49:22
English 37
Operations
To secure more storage space (applicable models only)
If you need more storage space, remove
the top shelf cover and all 4 drawers and
insert the provided shelf (see the gure)
in the inner bottom of the main unit. Then,
remove the Slim Ice Maker.
NOTE
• Removal of the top shelf cover and the
drawers does not affect thermal and
mechanical characteristics of the freezer.
• A declared storage volume of the
freezer is based on the conditions where
the top shelf cover and all the drawers
are removed and the provided shelf is
inserted.
Untitled-6 37 2021-11-29 5:49:22
English38
Maintenance
Door reversal
WARNING
• The warranty does not cover reversal failure or property damage occurring due to
unapproved agencies.
• Make sure that the refrigerator is disconnected from the power source before reversing
the door.
• You must wait for at least an hour after door reversal is complete. This is to prevent any
electric shock that could occur.
• Reversing the door must be performed by Samsung-approved servicing personnel at
your own expense because this kind of servicing is not covered by the Warranty.
CAUTION
The door is heavy. Have at least two people work on the door reversal. Otherwise, it may
cause a personal injury.
Tools required (not provided)
Phillips screwdriver Flat-head
screwdriver
Adjustable wrench 8 mm socket
wrench
(for bolts)
Accessories
The accessories below may differ in appearance depending on the model.
Top-right door hinge Top-left door cover Top-right door hinge cover
CAUTION
Throughout the entire reversal procedure, keep all the small parts (screws, caps, etc.) of the
refrigerator away from children or infants for safety reasons.
Maintenance
Untitled-6 38 2021-11-29 5:49:22
English 39
Maintenance
Step-by-step instructions
A
1. Use a at-head screwdriver to remove
the top-left door hinge cover (A).
NOTE
Keep the removed part in a safe place for
later use.
B
2. Use a socket wrench (8 mm) to remove
the screws fastening the top-left door
hinge (B).
B
3. Lift the top-left door hinge (B) to
remove it.
NOTE
Keep the removed part in a safe place for
later use.
Untitled-6 39 2021-11-29 5:49:22
Maintenance
English40
Maintenance
4. Lift the door to remove it from the
bottom hinge.
CAUTION
The door is heavy. To prevent damage or
injury, use caution while removing the
door.
C
5. Remove the top-right door cover (C)
from the door.
NOTE
Keep the removed part in a safe place for
later use.
R
6. Attach the provided top-left door cover
(R) to the door.
Untitled-6 40 2021-11-29 5:49:23
English 41
Maintenance
E
F
7. On the bottom of the door, remove the
door cam riser (E) and the door stopper
(F) in that order.
- Use a Phillips screwdriver to remove
the screw fastening each part.
8. Fasten the door stopper (F) and the
door cam riser (E), in that order, to the
opposite side of the door.
- Use a Phillips screwdriver to fasten
each part with the screw.
G
H
9. Carefully lay the refrigerator down.
10. Remove the bottom hinge (G).
- Use a socket wrench (8 mm) to
remove the screws fastening the
bottom hinge (G).
11. Turn the leveling leg (H)
counterclockwise to remove it.
L
J
M
a
K
12. Use a socket wrench (8 mm) to remove
the screw (J).
13. Use an adjustable wrench to remove the
shaft nut (K).
NOTE
Loosen the leveler (a) if necessary when
removing the shaft nut (K).
14. Use a Phillips screwdriver to remove the
hinge shaft (L).
15. Remove the hinge cam riser (M).
L
J
M
K
16. Place the hinge cam riser (M) on the
opposite side of the bottom hinge.
17. Use a Phillips screwdriver to fasten the
hinge shaft (L).
18. Use an adjustable wrench to fasten the
shaft nut (K).
19. Use a socket wrench (8 mm) to fasten
the screw (J).
Untitled-6 41 2021-11-29 5:49:23
Maintenance
English42
Maintenance
G
H
20. Attach the bottom hinge (G) to the
opposite side.
- Use a socket wrench (8 mm) to fasten
the bottom hinge (G) with the screws.
21. Attach the leveling leg (H) to the
opposite side.
22. Carefully stand the refrigerator back up.
N
23. Use a at-head screwdriver to remove
the screw cover (N).
24. Use a Phillips screwdriver to remove the
screw.
25. Use a Phillips screwdriver to fasten the
screw into the hole on the opposite side.
Untitled-6 42 2021-11-29 5:49:23
English 43
Maintenance
N
26. Attach the screw cover (N) to the
opposite side.
27. Put the door back on the bottom hinge.
P
28. Insert the provided top-right door hinge
(P) into the door.
P
29. Use a socket wrench (8 mm) to fasten
the top-right door hinge (P) with the
screws.
Untitled-6 43 2021-11-29 5:49:24
Maintenance
English44
Maintenance
Q
30. Attach the provided top-right door
hinge cover (Q).
31. Detach the door gasket.
1
2
32. Turn the door gasket 180°, and then
reattach it to the door.
Untitled-6 44 2021-11-29 5:49:24
English 45
Maintenance
Reversing the door handle position
1. Remove the handle covers.
2. Use a Phillips screwdriver to remove the
screws and detach the handle.
3. Use a at-head screwdriver to remove
the hole caps from the opposite side of
the door.
4. Insert the hole caps into the holes from
which you detached the handle.
Untitled-6 45 2021-11-29 5:49:24
Maintenance
English46
Maintenance
5. Place the handle on the opposite side
of the door, aligning the holes on the
handle and the door.
6. Use a Phillips screwdriver to attach the
handle with the screws.
7. Attach the handle covers.
Untitled-6 46 2021-11-29 5:49:24
English 47
Maintenance
Handle and care
Shelves
Slightly lift up the rear side of the shelf to
pull out.
Door bins
Slightly lift up and pull out the door bin.
CAUTION
To prevent accidents, empty the door bins
before removing.
Top shelf cover (applicable models only)
1
2
1. Push the right side of the cover inwards
to unhook the cover.
2. Then, pull up the cover to the front to
remove.
Untitled-6 47 2021-11-29 5:49:25
Maintenance
English48
Maintenance
Slim Ice Maker (applicable models only)
NOTE
• When cleaning the component parts of the Slim Ice Maker such as the water bin, ice
bucket, and ice tray, make sure they are completely dry after cleaning.
• When cleaning the Slim Ice Maker unit, make sure to completely dry the inner and outer
parts of the unit after cleaning. Incomplete dryness may cause the ice maker lever to
fail. In this case, dry the Slim Ice Maker completely for 2-3 days. Then, try again.
To remove the parts
Water bin
Fully open the water bin, and then pull out.
ice tray
1. Open the ice tray cover to reveal the ice
tray.
2. Slightly pull out the left side of the ice
tray, and then pull out the other side to
remove.
Untitled-6 48 2021-11-29 5:49:25
English 49
Maintenance
Slim Ice Maker
1. Remove the multipurpose bin rst,
which is immediately above the Slim Ice
Maker.
2. While holding the marked area on either
side of the Slim Ice Maker unit with both
hands, lift up the unit and pull out to the
front.
To reinsert the parts
Water bin
Fit either side of the water bin into the
corresponding hook on the water bin
housing. Make sure to t until you hear a
clicking sound.
Untitled-6 49 2021-11-29 5:49:25
Maintenance
English50
Maintenance
Cleaning
Interior and exterior
WARNING
• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning
purposes. They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause an electric shock.
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord.
2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord.
Untitled-6 50 2021-11-29 5:49:25
English 51
Maintenance
Replacement
LED Lamps
To replace the lamps of the refrigerator, contact a local Samsung service center.
WARNING
• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can
cause an electric shock.
Lamp (Light Source)
This product contains a light source of energy efciency class <G>.
The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or
control gear(s) in the product, contact a local Samsung service centre.
For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the
Samsung website (http://www.samsung.com), go to Support > Support home, and then
enter the model name.
For detailed instructions on dismantling lamp(s) and/or control gear(s), simply follow the
replacement instruction reached as described above.
Door panel
You can select the door panel you prefer for your BESPOKE refrigerator. Purchase the
door panel at a Samsung retail store or Samsung website (www.samsung.com), and an
authorized installer will install the panel for you. (Available place to purchase the door
panel may vary depending on the country.)
CAUTION
• Disassembling or assembling the door panel on your own may result in product damage
or personal injury. If you nd any problems with the door panel, contact a Samsung
service center.
• A service fee may be charged for panel replacement even within the warranty period.
Pair installation
Use the installation accessories provided with the fridge (RR models) for pair or kitchen t
installation. The installation accessories are not in the freezer (RZ models).
Untitled-6 51 2021-11-29 5:49:25
English52
Troubleshooting
Before calling for service, review the checkpoints below. Any service calls regarding
normal situations (No Defect Cases) will be charged to users.
General
Temperature
Symptom Possible causes Solution
The freezer does
not operate.
The freezer
temperature is
warm.
• The power cord is not
plugged in properly.
• Properly plug in the power
cord.
• Temperature control is not
set correctly.
• Set the temperature lower.
• The refrigerator is located
near a heat source or direct
sunlight.
• Keep the refrigerator away
from direct sunlight or a
heat source.
• Not enough clearance
between refrigerator and
sides/rear.
• We recommend that the gap
between the refrigerator and
nearby walls (or cabinets) is
more than 50 mm.
• The refrigerator is
overloaded. Food is blocking
the refrigerator vents.
• Do not overload the
refrigerator. Do not allow
food to block ventilation.
The freezer is over-
cooling.
• Temperature control is not
set correctly.
• Set the temperature higher.
The interior wall
is hot.
• The refrigerator has heat-
proof piping in the interior
wall.
• To prevent condensation
from forming, the
refrigerator has heat-proof
piping in the front corners.
If the ambient temperature
rises, this equipment may
not work effectively. This is
not a system failure.
Troubleshooting
Untitled-6 52 2021-11-29 5:49:26
English 53
Troubleshooting
Odors
Symptom Possible causes Solution
The refrgierator has
odors.
• Spoiled food.
• Clean the refrigerator and
remove any spoiled food.
• Food with strong odors.
• Make sure strong smelling
food is wrapped airtight.
Frost
Symptom Possible causes Solution
Frost around the
vents.
• Food is blocking the vents.
• Make sure no food blocks
the refrigerator vents.
Frost on interior
walls.
• Door is not closed properly.
• Make sure food does not
block the door. Clean the
door gasket.
Fruits or vegetables
are frozen.
• Fruits or vegetables are
stored in the Fresh/Chef
Zone.
• The Fresh/Chef Zone is only
for meat/sh.
Condensation
Symptom Possible causes Solution
Condensation forms
on the interior
walls.
• If the door is left open,
moisture enters the
refrigerator.
• Remove the moisture and do
not open the door for a long
time.
• Food with high moisture
content.
• Make sure food is wrapped
airtight.
Untitled-6 53 2021-11-29 5:49:26
Troubleshooting
English54
Troubleshooting
Do you hear abnormal sounds from the refrigerator?
Before calling for service, review the checkpoints below. Any service calls related to
normal sounds will be charged to the user.
These sounds are normal.
• When starting or ending an operation, the refrigerator may make sounds similar to a
car engine igniting. As the operation stabilizes, the sounds will decrease.
Clicking!
or Chirping!
Buzzing!
• While the fan is operating, these sounds may occur. When the refrigerator reaches the
set temperature, no fan sound will occur.
SSSRRR!
Whir!
• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds.
HiSS!
Untitled-6 54 2021-11-29 5:49:26
English 55
Troubleshooting
• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing
bubbling sounds.
Bubbling!
• As the refrigerator temperature increases or decreases, plastic parts contract and
expand, creating knocking noises. These noises occur during the defrosting cycle or
when electronic parts are working.
Cracking!
• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds
may occur.
• Due to pressure equalizing when opening and closing the refrigerator door, whooshing
sounds may occur.
Untitled-6 55 2021-11-29 5:49:26
English56
Appendix
Safety Instruction
• For the most efcient use of energy, please keep the all inner ttings such as baskets,
drawers, shelves and ice cube tray on the position supplied by manufacturer.
• This refrigerating appliance is not intended to be used as a built-in appliance.
Install Instruction
For refrigerating appliances with climate class
Depending on the climate class, This refrigerating appliance is intended to be used at
ambient temperatures range as specied following table.
The climate class can be found on the rating plate. The product may not operate properly
at temperatures outside of the specic range.
You can nd climate class on label inside of your refrigerator
Effective temperature range
The refrigerator is designed to operate normally in the temperature range specied by its
class rating.
Class Symbol
Ambient Temperature range (°C)
IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be affected by
the ambient temperature, the door-opening frequency, and the location of the refrigerator.
We recommend adjusting the temperature settings as appropriate.
Untitled-6 56 2021-11-29 5:49:26
English 57
Temperature Instruction
Recommended Temperature
The optimal temperature setting for food storage:
• Freezer: -19 °C
• Fridge of Freezer: 3 °C
NOTE
The optimal temperature setting of each compartment depends on the ambient
temperature. Above optimal temperature is based on the ambient temperature of 25 °C.
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps
running at full speed for 50 hours and then returns to the previous temperature. To freeze
large amounts of food, activate Power Freeze for at least 20 hours before putting food in
the freezer.
NOTE
When you use this function the energy consumption of the refrigerator will increase.
Remember to turn it off when you don’t need it and return the freezer to your original
temperature setting.
How to store for best preservation (applicable models only)
Cover foods to retain moisture and prevent them from picking up odors from other foods.
A large pot of food like soup or stew should be divided into small portions and put in
shallow containers before being refrigerated. A large cut of meat or whole poultry should
be divided into smaller pieces or placed in shallow containers before refrigerating.
Untitled-6 57 2021-11-29 5:49:26
Appendix
English58
Placement of Foods
Shelves
Shelves should be adjustable to accommodate a variety of
packages.
Specialized compartment
(applicable models only)
Sealed crisper drawers provide an optimal storage
environment for fruits and vegetables. Vegetables require
higher humidity conditions while fruits require lower
humidity conditions.
Crispers are equipped with controls devices to control
the humidity level. (*Depending on model and options)
An adjustable temperature meat drawer maximizes the
storage time of meats and cheeses.
Stored on the door
Don’t store perishable foods in the door. Eggs should
be stored in the carton on a shelf. The temperature of
the storage bins in the door uctuate more than the
temperature in the cabinet. Keep the door closed as much
as possible.
Freezer Compartment
You can store frozen food, make ice cubes and freeze fresh
food in the freezer compartment.
NOTE
Freeze fresh, undamaged food only. Keep food which is to be frozen away from food
which is already frozen. To prevent food from losing its avour or drying out, place in
airtight containers.
Refrigerator & Freezer Storage Chart
The freshness longevity depends on temperature and exposure to moisture. Since product
dates aren't a guide for safe use of a product, consult this chart and follow these tips.
Milk products
Product Refrigerator Freezer
Milk 1 week 1 month
Butter 2 weeks 12 months
Ice cream - 2-3 weeks
Natural cheese 1 month 4-6 months
Cream cheese 2 weeks Not recommended
Yogurt 1 month -
Untitled-6 58 2021-11-29 5:49:26
English 59
Meat
Product Refrigerator Freezer
Fresh roasts, steaks, chops 3-4 days 2-3 months
Fresh ground meat, stew
meat
1-2 days 3-4 months
Bacon 7 days 1 month
Sausage, Raw from pork,
beef, turkey
1-2 days 1-2 months
Poultry / Eggs
Product Refrigerator Freezer
Fresh poultry 2 days 6-8 months
Poultry salad 1 day -
Eggs, Fresh in shell 2-4 weeks Not recommended
Fish / Seafood
Product Refrigerator Freezer
Fresh sh 1-2 days 3-6 months
Cooked sh 3-4 days 1 month
Fish salad 1 day Not recommended
Dried or pickled sh 3-4 weeks -
Fruits
Product Refrigerator Freezer
Apples 1 month -
Peaches 2-3 weeks -
Pineapple 1 week -
Other fresh fruit 3-5 days 9-12 months
Untitled-6 59 2021-11-29 5:49:27
Appendix
English60
Vegetables
Product Refrigerator Freezer
Asparagus 2-3 days -
Broccoli, Brussels sprouts,
green peas, mushrooms
3-5 days -
Cabbage, cauliower, celery,
cucumbers, lettuce
1 week -
Carrots, beets, radishes 2 weeks -
Information for model and ordering spare parts
Model information
To access energy labelling information about this product on the European Product
Registry for Energy Labelling (EPREL), scan QR-Code on the energy label.
You can nd QR-Code on the energy label in your product box.
Part information
• The minimum period during which spare parts, necessary for the repair of the
appliance, are available
- 7 Years thermostats, temperature sensors, printed circuit boards and light sources,
door handles, door hinges, trays, baskets (boxes or drawers)
- 10 Years door gaskets
• The minimum duration of the guarantee of the refrigerating appliance offered by the
manufacturer 24 Months.
• Relevant information for ordering spare parts, directly or through other channels
provided by the manufacturer, importer or authorized representative
• You can nd professional repair information on http://samsung.com/support.
You can nd user servicing manual on http://samsung.com/support.
Untitled-6 60 2021-11-29 5:49:27
Memo
Untitled-6 61 2021-11-29 5:49:27
Memo
Untitled-6 62 2021-11-29 5:49:27
Memo
Untitled-6 63 2021-11-29 5:49:27
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
Country Contact Center Web Site
UK 0333 000 0333 www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/za/support
DA68-04131L-02
Untitled-6 64 2021-11-29 5:49:27
