Washing Machine
user manual
WA52J8060A*
WA52J8700A*
Imagine the possibilities
Thank you for purchasing this Samsung product.
This manual is made with 100% recycled paper.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 1 2015/1/3 13:56:31
English - 2
contents
insTalling your washer
10
10 Unpacking your washer
10 Overview of your washer
11 Basic location requirements
11 Electrical
11 Grounding
11 Water
12 Drain facility
12 Flooring
12 Location considerations
12 Alcove or closet installation
13 Required dimensions for Installation
13 Important note to installer
operaTing insTrucTions
17
17 Loading your washer
17 Getting started
washing a load of laundry
18
18 Overview of the control panel
20 Child Lock [
]
21 Sound
21 Garment Plus
21 My Cycle
21 Delay End
22 Pre Soak
22 AquaJet
TM
22 Eco Plus
22 Mist Shower
22 Smart Care
23 Washing clothes using the cycle selector
23 ATC (Auto Temperature Control)
24 Prewash : Water Jet & Built-in sink
(WA52J8700A*)
25 Detergent use
25 Features
mainTaining your washer
28
28 Cleaning the exterior
28 Cleaning the interior
28 Storing your washer
28 Preserving the top cover and the front frame
29 Cleaning the dispensers
30 Self Clean
TroubleshooTing
31
31 Check these solutions if your washer…
33 Information codes
appendix
35
35 Fabric care chart
36 Cycle chart
38 Helping the environment
38 Declaration of conformity
38 Specification
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 2 2015/1/3 13:56:31
English - 3
safety information
Congratulations on your new Samsung Washer. This manual contains important
information on the installation, use, and care of your appliance. Please take time
to read this manual to take full advantage of your washer’s many benefits and
features.
WhAt you need to knoW About sAfety instructions
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, and operating your washer.
importAnt sAfety symbols And precAutions
What the icons and signs in this user manual mean:
warning
Hazards or unsafe practices that may result in severe personal injury
or death.
To reduce the risk of fire, explosion, electric shock, or personal injury
when using your washer, follow these basic safety precautions:
cauTion
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
these warning icons are here to prevent injury to you and others.
please heed them explicitly.
After reading this section, keep it in a safe place for future reference.
Read all instructions before using the appliance.
saVe These insTrucTions
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 3 2015/1/3 13:56:31
English - 4
warning: To reduce the risk of fire, electric shock, or injury to persons when using your
appliance, follow basic precautions, including the following:
1. Read all instructions before using the appliance.
2. Do not wash or dry articles that have been previously cleaned in, washed in, soaked
in, or spotted with gasoline, dry-cleaning solvents, other flammable or explosive
substances as they give o vapors that could ignite or explode.
3. Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is used near children.
4. Before the appliance is removed from service or discarded, remove the lid of the
washing or drying compartment.
5. Do not reach into the appliance if the drum is moving.
6. Do not install or store this appliance where it will be exposed to the weather.
7. Do not tamper with the controls.
8. Do not repair or replace any part of the appliance or attempt any servicing unless it is
specifically recommended in the user-maintenance instructions or in published user-
repair instructions that you understand and have the skills to carry out.
9. Do not add gasoline, dry-cleaning solvents, or other flammable or explosive substances
to the wash water. These substances give o vapors that could ignite or explode.
10. Under certain conditions, hydrogen gas may be produced in a hot water system that
has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the
hot water system has not been used for 2 weeks or more, before using a washer or
combination washer-dryer, turn on all hot water faucets and let the water flow from
each for several minutes. This will release any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during this time.
state of california proposition 65 warnings:
warning: This product contains chemicals known to the State of California to cause
cancer and reproductive toxicity.
saVe These insTrucTions
safety information
WArninG
WArninG
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 4 2015/1/3 13:56:31
English - 5
criticAl instAllAtion WArninGs
Plug the power cord into an AC 120 V / 60 Hz/wall socket rated at 15 amps or higher. Use
the socket for this appliance only. In addition, do not use an extension cord.
- Sharing a wall socket with other appliances, using a power strip, or extending the power
cord may result in electric shock or fire.
- Do not use an electric transformer. It may result in electric shock or fire.
- Ensure that the power voltage, frequency, and current match the product’s
specifications. Failing to do so may result in electric shock or fire.
Have this appliance installed by a qualified technician or service company.
- Failing to do so may result in electric shock, fire, an explosion, problems with the
product, or injury.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Failing to do so may result in electric shock or fire.
Plug the power plug into the wall socket in the right direction so that the cord runs towards
the floor.
- If you plug the power plug into the socket in the opposite direction, the electric wires
within the cable may be damaged and this may result in electric shock or fire.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
- Improper grounding may result in electric shock, fire, an explosion, or problems with the
product.
- Never plug the power cord into a socket that is not grounded correctly. Make sure the
socket you use is grounded in accordance with local and national codes.
Do not install this appliance near a heater or flammable material.
Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to
direct sunlight or water (rain drops).
Do not install this appliance in a location where gas may leak.
- This may result in electric shock or fire.
Plug the power plug into the wall socket firmly. Do not use a damaged power plug,
damaged power cord, or loose wall socket.
- This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord,
insert the power cord between objects, or push the power cord into the space behind the
appliance.
- This may result in electric shock or fire.
Do not pull the power cord when unplugging the power plug.
- Unplug the power plug by holding the plug.
- Failing to do so may result in electric shock or fire.
If the power plug or power cord are damaged, contact your nearest service center.
saVe These insTrucTions
WArninG
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 5 2015/1/3 13:56:31
English - 6
instAllAtion cAutions
Position the appliance so that the power plug is easily accessible.
- Failing to do so may result in electric shock or fire due to electric leakage.
Install your appliance on a level and hard floor that can support its weight.
- Failing to do so may result in abnormal vibrations, noise, or problems with the product.
Unplug the power plug when the appliance is not being used for long periods of time or
during a thunder/lightning storm.
- Failing to do so may result in electric shock or fire.
criticAl usAGe WArninGs
If the appliance is flooded, cut the power immediately and contact your nearest service
center.
If the appliance emits a strange noise, a burning smell, or smoke, unplug the power plug
immediately and contact your nearest service center.
- Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area
immediately. Do not turn any appliance or light on or o.
- Do not use a ventilating fan.
- A spark may result in an explosion or fire.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or
other flammable or explosive substances.
- This may result in electric shock, fire, or an explosion.
Do not force the washer lid open while the washer is operating (high-temperature washing/
drying/spinning).
- Water flowing out of the washer may cause burns or cause the floor to be slippery.
This may result in injury.
- Forcing the lid open can damage the product or cause injury.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the
washer before using it.
Do not insert your hand under the washer.
- This may result in injury.
safety information
saVe These insTrucTions
WArninG
cAution
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 6 2015/1/3 13:56:31
English - 7
Do not touch the power plug with wet hands.
- This may result in electric shock.
Do not turn the appliance o by unplugging the power plug while the washer is in operation.
- Plugging the power plug into the wall socket again may cause a spark and result in
electric shock or fire.
Keep all packaging materials well out of the reach of children, as packaging materials can
be dangerous to children.
- If a child places a bag over their head, the child may suocate.
Do not let children or infirm persons use this washer unsupervised.
- Failing to do so may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washer while it is operating.
- This may result in injury.
Do not attempt to repair, disassemble, or modify the appliance yourself.
- Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
- If you need to repair or reinstall the appliance, contact your nearest service center.
- Failing to do so may result in electric shock, fire, problems with the product, or injury.
If any foreign substance such as water enters the appliance in any area other than the tub,
unplug the power plug and contact your nearest service center.
- Failing to do so may result in electric shock or fire.
If the water supply hose comes loose from the faucet and floods the appliance, unplug the
power plug.
- Failing to do so may result in electric shock or fire.
usAGe cAutions
If the washer is contaminated by a foreign substance such as detergent, dirt, food waste,
etc., unplug the power plug and clean the washer using a damp, soft cloth.
- Failing to do so may result in discoloration, deformation, damage or rust.
The clear portion of the lid can be broken by a strong impact. Take care when using the
washer.
- If the clear portion is cracked or broken, it may result in injury.
After a water supply failure or when reconnecting the water supply hose, open the faucet
slowly.
Open the faucet slowly after a long period of non-use.
- The air pressure in the water supply hose or the water pipe may result in damage to a
part or in water leakage.
If a drain error occurs during an operation, check if there is a draining problem.
- If the washer is used when it is flooded because of a draining problem, it may result in
electric shock or fire due to electric leakage.
Do not insert your hand under the washer.
- This may result in injury.
saVe These insTrucTions
cAution
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 7 2015/1/3 13:56:32
English - 8
Insert the laundry into the washer completely so that laundry does not get caught in the lid.
- If laundry gets caught in the lid, it may result in damage to the laundry or the washer, or
result in water leakage.
Ensure that the faucet is turned o when the washer is not being used.
- Ensure that the water supply hose connectors are properly tightened.
- Failing to do so may result in property damage or injury.
Open the faucet and check if the water supply hose connector is firmly tightened and that
there is no water leaking before using the product.
- If the water supply hose connectors are loose, it may result in water leakage.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
- This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
- As well as being harmful to humans, it may also result in electric shock, fire, or problems
with the product.
Do not place an object that generates a electromagnetic field near the washer.
- This may result in injury due to a malfunction.
Since the water drained during a high-temperature wash or drying cycle is hot, do not touch
the water.
- This may result in burns or injury.
For waterproof fabrics, only use the WATERPROOF cycle.
- Do not use other cycles for waterproof fabrics.
* This may result ininjury or damage to the washer, walls, floor, or clothing due to
abnormal vibrations.
- Set the temperature and spin according to the attached care label.
Do not operate the washer when the detergent dispenser is removed.
- This may result in electric shock or injury due to water leakage.
Do not insert your hand into the detergent dispenser after opening it.
- This may result in injury as your hand may be caught.
safety information
saVe These insTrucTions
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 8 2015/1/3 13:56:32
English - 9
Do not place any non-laundry objects, such as shoes, food waste, or animals into the
washer.
- This can cause abnormal vibrations that can damage the washer, and, in the case of
pets, cause severe injury or death.
Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.
- This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams, or lotions usually found in skincare
shops or massage clinics.
- This may result in the rubber seal becoming deformed and water leakage.
Do not leave metal objects (safety pins, hair pins, etc.) or bleach in the tub for long periods
of time.
- This may cause the tub to rust.
- If rust appears on the surface of the tub, apply a neutral cleansing agent to the surface
and use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly in the tub and do not wash, rinse, or spin laundry
contaminated by dry cleaning detergent.
- This may result in spontaneous combustion or ignition due to heat from the oxidation of
the oil.
Do not use hot water from water cooling/heating devices.
- This may result in problems with the washer.
Do not use natural hand-washing soap in the washer.
- If it hardens and accumulates inside the washer, it may cause problems with the
product, discoloration, rust, or bad odors.
Do not wash large laundry items such as bedding in the washing net.
- Failing to do so may result in injury due to abnormal vibrations.
- Place smaller items, such as lace socks and lingerie in the washing net.
Do not use hardened detergent.
- If it accumulates inside the washer, it may result in water leakage.
Do not wash throw rugs or doormats.
- If you wash throw rugs or doormats, the sand will accumulate inside the washer. It may
result in error such as no draining.
criticAl cleAninG instructions
Do not clean the appliance by spraying water directly onto it.
Do not use the strong acid cleaning agent.
Do not use benzene, paint thinner, or alcohol to clean the appliance.
- This may result in discoloration, deformation, damage, electric shock, or fire.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
- Failing to do so may result in electric shock or fire.
saVe These insTrucTions
WArninG
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 9 2015/1/3 13:56:32
English - 10
installing your washer
unpAckinG your WAsher
Unpack your washer and inspect it for shipping damage. Make sure you have received all the items
shown below. If your washer was damaged during shipping, or you do not have all of the items, contact
1-800-SAMSUNG (1-800-726-7864).
To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.
Packing materials can be dangerous to children; Keep all packing material (plastic bags, polystyrene,
etc.) well out of children’s reach.
When unpacking the washing machine, 2 person collaboration is needed. To remove the cushion
bottom of the packing materials, forward dumping is strictly prohibited.
overvieW of your WAsher
parts supplied
hose guide user manual book plastic zip hose tie water intake cap
Tools needed
wrench flat screwdriver level
parts not supplied
• Ifyouloseanaccessoryandwanttopurchaseareplacement,contactthe
Samsung service center (1-800-SAMSUNG (1-800-726-7864)).
• Thedesignofthepartsandaccessoriesmaydierfromthepicturesabove.
Their design is subject to change without notice for product improvement.
• Donotreuseoldhoses.Onlyusenewwatersupplyhoseswhenyouinstallthe
washing machine. Old water supply hoses can leak or burst causing flooding
and property damage.
• Conrmthattherearerubberwashersinsideeachcouplingofthewater
supply hoses.
water supply hoses
adjustable legs
drain hose
control panel
lid
power cord
warning
cauTion
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 10 2015/1/3 13:56:33
English - 11
bAsic locAtion requirements
Electrical
• 120 Volt 60 Hz 15 AMP fuse or circuit breaker.
• Individual branch circuit serving only your Washer is recommended.
• Your Washer is equipped with a power cord.
NEVER USE AN EXTENSION CORD.
Grounding
ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE.
This appliance must be grounded. In the event of malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a path of least resistance for electric current.
This appliance is equipped with a power cord having a three-prong grounding plug for use in a
properly installed and grounded outlet.
The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
An improperly connected equipment-grounding conductor can increase the risk of electrical
shock. Check with a qualified electrician or serviceman if you are not sure whether the
appliance is properly grounded. Do not modify the plug provided with the appliance – if it
does not fit the outlet, have a proper outlet installed by a qualified electrician.
IMPORTANT SAFETY PRECAUTIONS
• To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring and
grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No.
70 Latest Revision and local codes and ordinances. It is the personal responsibility of the
appliance owner to provide adequate electrical service for this appliance.
NEVER CONNECT THE GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES, OR
HOT WATER PIPES.
Water
To correctly fill your Washer in the proper amount of time, water pressure of 20 to 116psi (137 to
800kPa) is required.
Water pressure less than 20 psi may cause water valve failure, or may not allow the water valve
to shut o completely, or may extend the fill time beyond what your Washer controls allow,
causing your Washer to turn o. A time limit is built into the controls to prevent flooding in your
home if a hose becomes loose.
The water faucets must be within 4 feet / 122 cm to the back of your Washer to match the inlet
hoses provided with your Washer.
Accessory inlet hoses are available in various lengths up to 10 feet / 275 cm for faucets that
are further away from the back of your Washer.
To avoid the possibility of water damage:
• Have water faucets easily accessible.
• Turn o faucets when the washer is not in use.
• Periodically check that there is no leakage from the water inlet hose fittings.
CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS.
01 installing your washer
cauTion
warning
cauTion
warning
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 11 2015/1/3 13:56:33
English - 12
Drain facility
The recommended height of the standpipe is 39 in / 99 cm. The drain hose must be routed
through the drain hose clip to the standpipe. The standpipe must be large enough to accept the
outside diameter of the drain hose. The drain hose is attached to the washer at the factory.
Flooring
For best performance, you must install your washer on a solidly constructed floor. Wood floors
may need to be reinforced to minimize vibration and/or unbalanced load situations. Carpeting
and soft tile surfaces are contributing factors to vibration which can cause your washer to move
slightly during the spin cycle.
Never install your washer on a platform or weakly supported structure.
Location considerations
Do not install your washer in areas where water may freeze, since your washer will always retain
some water in its water valve, pump, and hose areas. Frozen water can damage the belts, the
pump, hoses, and other components.
Alcove or closet installation
MINIMUM CLEARANCES FOR CLOSET AND ALCOVE INSTALLATIONS:
Sides – 1 in / 25 mm
Rear – 6 in / 152 mm
Closet Front – 2 in / 51 mm
TOP - 21 in / 533 mm
Gap between end of water valve and the wall
- Case 1. Assemble supply hose after installing : Over 3.9 in (10 cm).
- Case 2. Assemble supply hose before installing : Over 2.8 in (7cm).
If the washer and dryer are installed together, the closet front must have at least a 72 in² (465 cm²)
unobstructed air opening. Your washer alone does not require a specific air opening.
A. Recessed area
B. Side view - closet or confined area
installing your washer
2 in.
(5.1 cm)
6 in.
(15.2 cm)
29.3 in.
(74.4 cm)
B
21 in.
(53.3 cm)
Case 1. 3.9 in. (10 cm)
Case 2. 2.8 in. (7 cm)
A
1 in.
(2.5 cm)
1 in.
(2.5 cm)
27.0 in.
(68.6 cm)
27.0 in.
(68.6 cm)
1 in.
(2.5 cm)
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 12 2015/1/3 13:56:33
English - 13
Required dimensions for Installation
importAnt note to instAller
Please read the following instructions carefully before installing your washer.
These instructions should be retained for future reference.
We recommend you hire a professional to install this washer.
Installation Flow chart
sTep 1 Selecting a Location
Before you install the washer, make sure the location:
• Hasahard,levelsurfacewithoutcarpetingorooringthatmayobstructventilation.
• Isawayfromdirectsunlight.
• Hasadequateventilation.
• Isnotexposedtofreezingtemperatures(temperaturesunder32°For0°C).
• Isawayfromheatsourcessuchasoilorgas.
• Hasenoughspacesothatthewasherdoesn’trestonitspowercord.
27.0 in.
(68.6 cm)
45.7 in.
(116.0 cm)
39.2 in.
(99.5 cm)
29.3 in.
(74.4 cm)
45.7 in.
(116.0 cm)
59.8 in.
(152.0 cm)
Closet or Door
48 in.² *
(310 cm²)
24 in.² *
(155 cm²)
3 in.
(7.6 cm)
3 in.
(7.6 cm)
*required spacing
Selecting
a location
Removing the
shipping bolts
(*Drum only)
Adjusting the
levelling feet
Connecting the water
and the drain
[Running a test cycle]
Run a test cycle(Rinse+Spin)
with small amount of laundary
(about 4~5 Towels)
Running
a Calibration
mode
Powering your
washing machine
Finish the
installation
Does a
Laundary machine
Vibrate?
No
Yes
Please check again before steps.
01 installing your washer
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 13 2015/1/3 13:56:34
English - 14
sTep 2
Connecting the water and the drain
connecting the water supply hose
Before installing the water supply hoses, make sure there are
rubber gaskets inside the fittings at both ends of each new
water hose. Installing the water supply hoses without rubber
gaskets can cause water leakage.
When you initially install the washer, be sure to use new hoses.
Failing to do so may result in a water leakage or overflow and
may damage your property.
Do not connect multiple water supply hoses together to
increase the length of the supply hose. Hoses connected this
way can leak and the leakage can cause electrical shock. If a
hose is too short, replace the hose with a longer, high pressure
hose.
1. Connect the ends of the water supply hoses to the HOT and COLD faucets.
2. Tighten the fittings by hand until they are snug, and then tighten them an
additional two-thirds of a turn with a wrench.
When you fasten the fittings, do not fasten them too tightly or apply
tape or sealant to the faucets or water supply intakes. This can
damage the fittings.
After you have connected the water supply hoses to the faucets,
ensure that they are connected correctly by pulling the water supply
hoses downwards
3. Place the unconnected ends of the hoses into a bucket and open
the faucets connected to the two water supply hoses for 10 or 15
seconds to remove any foreign substances from the hoses. Close the
faucets before continuing.
4. Connect the ends of the water supply hoses to the water supply
intake connections at the back of the washer.
The water supply hose connected to the HOT faucet must be
connected to the hot water supply intake and the water hose
connected to the COLD faucet must be connected to the COLD
water supply intake.
5. Tighten the fittings by hand until they are snug, and then tighten them
an additional two-thirds of a turn with a wrench.
To ensure the correct water usage, connect both the HOT and
COLD water faucets. If either or both are not connected, an
“4C” (no fill) error can occur.
If you do not want to use the HOT water supply hose, insert
the water intake cap into the HOT water supply intake hole. In
this case, you must select the Tap Cold option for the water
temperature. If you select the Tap Cold option, all the lamps for
the water temperature options are turned o.
Confirm that the water supply hoses are not twisted or bent. If
the hoses are twisted or bent, the hoses can leak and cause
electric shock due to the water leakage.
6. Turn on the HOT and COLD water supplies and check all the water
supply intake connections and the faucets for water leaks.
installing your washer
rubber washer
coupling
cold hot
cauTion
cauTion
cauTion
cauTion
cauTion
cauTion
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 14 2015/1/3 13:56:35
English - 15
Connecting the drain hose
The end of the drain hose can be positioned in
three ways:
over the edge of a wash basin
Secure the guide to the side of the basin wall
with a hook or to the tap with a piece of string to
prevent the drain hose from moving.
in a standpipe or laundry tub
The standpipe must be no shorter than 39 in (99
cm) and no longer than 96 in (245cm).
Make sure that the connection between the
drain hose and the standpipe is not airtight.
Connect the hose guide within 4 in (10cm)
from the end of the drain hose. If the drain hose is
extended more than 4 in (10cm) beyond the end of the
hose guide, mold or microorganisms could spread to the
inside of the washer.
The Drain Hose can be installed to a 96 in (245cm)
maximum, but the draining capability can be reduced
at this height. It can cause the washer to have an odor
because of remaining water in the drain system.
If the drain hose is installed below 39 in (99cm), water
can be drained in cycles due to a siphon phenomenon. It
causes the washer to display a “4C” error code.
sTep 3
Leveling your washer
See if the washer is level by checking the position of the tub:
1. Slide the washer into position.
2. Open the lid of the washer, and pour the water into the tub to
just below the pulsator level.
3. If the washer is level, the pulsator is positioned at the center of the
water as shown in the figure. If not, level your washer by turning the
front leveling feet clockwise or counterclockwise as necessary.
Turn the front leveling feet clockwise to raise the washer, and
counterclockwise to lower the washer.
01 installing your washer
laundry tub standpipe
hose
retainer
Tie
strap
39” min
(99 cm)
96” max
39” min
loosen lock
pulsator
adjustable legs
(three)
1RPRUHWKDQ
LQFP
+RVH*XLGH
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 15 2015/1/3 13:56:36
English - 16
sTep 4
Powering your washer
Plug the power cord into a 3-prong, well grounded 120 volt 60
Hz approved electrical outlet protected by a 15-amp fuse or
comparable circuit breaker.
Your washer is grounded through the third prong of the power
cord when plugged into a three-prong grounded electrical
outlet.
test run
Make sure that you install your washing machine correctly
by running the rinse+spin cycle after the installation is
complete.
sTep 5
Running a test cycle
Run a test cycle as follows to check if your washer is properly installed.
1. Load about 6 pounds of laundry into the tub.
2. Press the power button to turn on your washer.
3. Select the Rinse+Spin cycle by turning the cycle selector.
4. Press the start/pause button to start the test cycle.
5. The washer should not rock or vibrate excessively when water is supplied or when washing
or spinning, and should drain well during the spin cycle.
If water leaks while water is being supplied or drained, check the water connections. Refer
to the “Connecting the water and the drain” section on pages 14~15 for instructions.
If the washer rocks and vibrates excessively, level your washer again. Refer to the “Leveling
your washer” section on page 15 for instructions.
sTep 6
Calibration Mode
Your Samsung washing machine detects the laundry weight automatically.
For more accurate weight detection, please run Calibration Mode after the installation.
To run Calibration Mode, follow these steps:
1. Remove laundry or any contents in the machine.
2. Press the Temp. and Delay End buttons more 3 seconds when the power is switched on.
3. Press the Start/Pause button to activate “Calibration Mode”.
4. The spin drum rotates clockwise approximately 2 minute.
5. When “Calibration Mode” is finished, “End” appears on the display, and the machine
automatically turns o. The washing machine is now ready for use.
installing your washer
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 16 2015/1/3 13:56:36
English - 17
operating instructions
warning: To reduce the risk of fire, electric shock, or injury to persons when using your appliance,
follow basic precautions, including the following:
loAdinG your WAsher
• You can fill the tub with dry, unfolded clothes, but DO NOT
OVERLOAD the tub any more than 3/4 full.
• Overloading may reduce washing eciency, cause excess
wear, and possibly cause creasing or wrinkling of the load.
• Wash delicate items such as bras, hosiery, and other lingerie
in the Delicates cycle with similar lightweight items.
• When washing big bulky items or a few smaller items that
don’t fill the tub completely – a rug, a pillow, stued toys, or one or two sweaters, for example – add a
few towels to improve spin performance.
• Do not insert bulky items except for Bedding in this cycle.
During the spin cycle, the washer may add additional water to redistribute the clothes and correct an
imbalance inside the drum.
• When washing heavily soiled loads, do not overload your washer to ensure good cleaning results.
• To add a forgotten item:
1. Press the start/pause button to pause the washer.
2. Wait for the door to unlock automatically, and then open the door.
3. Add the item, close the door, and then press the start/pause button. The cycle will resume.
GettinG stArted
1. Load your washer.
2. Add liquid (or powder) detergent and additives to the dispenser (see pages 24~26).
3. Select the appropriate cycle and options for the load (see pages 18~23).
4. Close the lid.
5. Press the start/pause button.
6. The Wash Indicator light illuminates.
7. The estimated cycle time will appear in the display.
The time may fluctuate to indicate the time remaining in the cycle.
The actual time required for a cycle may dier from the estimated time in the display depending on the
water pressure, water temperature, detergent, and laundry.
8. Before your washer starts to fill, it will make a series of clicking noises to check the door lock and do a
quick drain.
• When the cycle is complete, the Door Lock light will go out and “End” will appear in the display.
• Pressing the power button cancels the cycle and stops your washer.
•
The Wash, Rinse, and Spin indicator lights will illuminate during those portions of the cycle.
02 operating instructions
WArninG
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 17 2015/1/3 13:56:36
English - 18
washing a load of laundry
overvieW of the control pAnel
cycle selector
Select the appropriate cycle for the type of load.
The cycle you select determines the tumble pattern and spin speed
for the cycle.
To minimize wrinkling of laundry, select the Perm Press cycle.
normAl - For most fabrics including cottons, linens, and normally
soiled garments.
super speed - Lightly soiled and small loads.
brilliAnt Whites - Lightly soiled and small loads.
colors/dArks - For brightly or dark colored casual garments.
heAvy duty - For sturdy, colorfast fabrics and heavily soiled
garments.
Active WeAr - Use this cycle to wash exercise wear such as
sports jerseys, training pants, shirts/tops and other performance
clothing. This cycle provides eective soil removal with gentle action
for special fabric care.
perm press - For wash-and-wear, synthetic fabrics, and lightly to
normally soiled garments.
deep steAm (WA52J8700A*) - For heavily soiled, colorfast
garments, this cycle provides a high washing temperature and steam
and is eective for cleaning stains.
sAnitiZe (WA52J8700A*) - For heavily soiled, colorfast garments.
WAterproof - For waterproof, water-resistant items.
Do not wash waterproof items and non-waterproof items together.
For waterproof, water-resistant items. (less than 14lbs)
quick WAsh - For lightly soiled garments needed quickly. (another
sentence all delete)
4
3
5
1
6
7
8
62
WA52J8060A*
WA52J8700A*
1
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 18 2015/1/3 13:56:37
English - 19
beddinG - For bulky items such as blankets and sheets. When you
are washing comforters, use liquid detergent.
delicAtes - For sheer fabrics, bras, lingerie, silks, and other
handwash-only fabrics. For best results, use liquid detergent.
spin - Drains the water and spins at a high speed.
rinse + spin - Use for loads that need rinsing only or to add rinse-
added fabric softener to a load.
display
Provides instructions and diagnostics while keeping you updated on the cycle
status and time remaining.
Temp. selection
button
Press the button repeatedly to cycle through the dierent water temperature
options.
extra hot (WA52J8700A*) - Heavily soiled, colorfast items. Only available
with the Sanitize cycle.
hot - Whites and heavily soiled, colorfast items.
Warm - Colorfast items.
eco Warm - Moderately soiled, colorfast items; most wrinkle-free items.
cold - Brightly colored, very lightly soiled items.
tap cold - Cold water with no warm water added.
If you select the Tap Cold option, all the lamps for the water
temperature options are turned o.
spin selection
button
Press the button repeatedly to cycle through the dierent spin speed options.
extra high - Removes more water from loads during spin.
high - Use for underwear, t-shirts, jeans, and sturdy cottons.
medium - Use for jeans, wrinkle-free or wash-and-wear items, and
synthetics.
low - Use for delicate items needing a slow spin speed.
no spin - Drains your washer without spinning. Use for extremely delicate
items that cannot tolerate any spin.
soil level
selection button
Press the button to select the soil level/washing time.
(Light ▼ Normal
▲ Heavy)
heavy - For heavily soiled loads.
▲
normal - For moderately soiled loads. This setting is best for most loads.
▼
light - For lightly soiled loads.
select cycle
option
Press these buttons to select dierent cycle options.
AquaJet
tm
deep clean – Improve washing performance through longer
AquaJet spray action. Water Level can be adjusted.
extra rinse - Change from spray rinse mode to deep rinse mode, and rinse
once again.
eco plus – To increase your energy savings on your wash cycles. (Less hot
water consumption)
fabric softener - Add an additional rinse at the end of the cycle to more
thoroughly remove laundry additives and perfumes.
my cycle - Press and hold for 3 seconds to Save. Create and/or use a cycle
you create with customized temperature, spin, soil level, option, etc.
delay end - Delay the End of any cycle for up to 19 hours in one-hour
increments. Displayed hour indicates the time the wash will be ended.
self clean - Use to clean dirt and bacteria from the drum. Regular use (after
every 20 washes) is recommended. No detergent or bleach is needed.
pre soak - It adds 15 minutes soaking time at the start of the wash cycle for
better stain removal.
start/pause
selection button
Press to pause and restart cycles.
power button
Press once to turn your washer on. Press again to turn your washer o. If
the washer is left on for more than 10 minutes without any buttons being
pressed, the power automatically turns o.
7
03 washing a load of laundry
2
3
4
5
6
8
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 19 2015/1/3 13:56:37
English - 20
Child Lock [ ]
Child Lock prevents children from playing with your washer.
Activating the Child Lock function
Press and hold the spin and soil level buttons simultaneously for approximately 3 seconds.
• When you activate the Child Lock function, the “Child Lock [
]” lamp blinks.
Using the Child Lock function
If the lid is opened when the Child Lock function is on, “dC” is displayed and an alarm sounds.
• If the water level in the tub is above the safe water level, “dC” is displayed on the LED display
and the washing machine starts to drain water by force after 30 seconds.
• If the water level in the tub is above the safe water level and the Child Lock function is turned
on while the door is open, “CL” is displayed on the LED display even if the power of the
washing machine is turned o and the washing machine drains water by force.
• Even if the power of the washing machine is turned o, if the lid is opened while the water
level in the tub is above the Reset water level, “CL” is displayed on the LED display without
the alarm sounding and the washing machine starts to drain water. When the draining
operation finishes, the power is automatically turned o again.
• You have activated the Child Lock function while the washing machine is running, the Start/
Pause button will not work.
• After the compulsory drain, the “CL” code display blinks at 1 second intervals and the
product enters the “CL” mode. (When the product is in the “CL” mode, only the power
button works.)
• To cancel the “CL” mode, you need to turn the power o and then on again.
• To cancel the “dC” mode, deactivate the Child Lock function. To deactivate the Child Lock
function, press and hold the spin and the soil level buttons simultaneously for at least
3seconds.
adding laundry when child lock is on
• Toaddlaundry,deactivatetheChildLockfunction.TodeactivatetheChildLock
function, press and hold the spin and the soil level buttons simultaneously for at least
3seconds. See “Pause Option” on page 23 for additional details.
Deactivating the Child Lock function
Press and hold both the spin and soil level buttons simultaneously for approximately
3seconds.
• When you deactivate the Child Lock function, the “Child Lock [
]” is turned o.
• The Child Lock function prevents children or the infirm from accidently operating the washer
and injuring themselves.
• Ifachildentersthewashingmachine,thechildmaybecometrappedandsuocate.
• OnceyouhaveactivatedtheChildLockfunction,itcontinuesworkingevenifthepower
is turned o.
• Forcingthelidopencanresultininjuryordamagetotheproduct.
To add laundry after you have activated the Child Lock function, you must first deactivate
the Child Lock function.
cauTion
warning
washing a load of laundry
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 20 2015/1/3 13:56:38
English - 21
Sound
The Sound O function can be selected during all cycles.
Garment Plus
You can add or take out laundry items even after the wash has started, as long as the “Garment
plus” light is on. Pushing the start/pause button unlocks the lid. If you open the lid and want to
continue the wash cycle, close the lid, and then press the start/pause button.
If you have activated the Child Lock, you must deactivate it first. See page 20.
My Cycle
Lets you save a custom wash cycle (temperature, spin, soil level, etc.) and then recall and use it with one
button convenience.
To save a cycle and selected options as your My Cycle, follow these steps:
1. Press the power button.
2. Select a cycle using the cycle selector.
3. After cycle selection, set each option.
See the “Cycle Chart” on page 35 for available option settings with each cycle.
4. You can then store the selected cycle and options by pressing and holding the my cycle button
for longer than 3 seconds. The cycle and options you select will be displayed the next time you
choose the My Cycle function.
5. Press the My Cycle button to load and use the saved My Cycle options. The “My Cycle” light will
indicate activation. Also, the chosen course and option lights will flicker.
You can change the My Cycle settings by repeating the process above.
The last saved settings will be displayed the next time you choose the My Cycle function.
If you press My Cycle and release it within 3 seconds, the previously saved cycle and options
appear. If you press and hold My Cycle for 3 second or longer, the currently set cycle and
options are saved and the LED blinks for 3 seconds.
Delay End
You can set the washing machine to start your wash automatically at a later time, by choosing a delay
time.
The hour displayed indicates the time at which the wash will be ended.
1. Set your wash cycle.
2. Press the delay end button repeatedly until the delay time is set.
3. Press the start/pause button. The “Delay End” indicator will be lit, and the clock will begin
counting down until it reaches the set time.
4. To cancel a Delay End function, press the power button and then turn the washing machine on
again.
03 washing a load of laundry
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 21 2015/1/3 13:56:38
English - 22
Pre Soak
Use this function when the laundry is heavily contaminated or stained. This function improves the
wash performance by adding a Pre Soak cycle.
- If you select this function, the total cycle time is increased by 15 minutes.
- When the Pre Soak cycle starts, the washing machine repeats a wash cycle after supplying
water and then performs a 15-minute soak cycle.
- When the Pre Soak cycle is complete, the configured wash cycle starts without draining
water.
AquaJet
TM
With a strong spray and soapy water recirculated by the AquaJet™ pump, laundry can be more
gently and thoroughly cleaned than in conventional Top Loads.
- AquaJet™ Deep Clean: If AquaJet™ Deep Clean mode is selected, washing performance
can be further improved by the additional spray action. Sucient water quantity can be ensured
by adjusting the water level.
cycles
aquaJet
Tm
deep clean
NORMAL, SUPER SPEED, BRILLIANT WHITES, COLORS/
DARKS, HEAVY DUTY, SANITIZE (WA52J8700A*), DEEP
STEAM (WA52J8700A*), ACTIVE WEAR, PERM PRESS,
RINSE+SPIN
Available
WATERPROOF, QUICK WASH, BEDDING, DELICATES, SPIN Not Available
Eco Plus
This function sets the temperature somewhat lower than the typical washing cycle and extends
the wash time slightly. With laundry time slightly extended, it’s possible to keep the same level
of washing performance with cooler water. This function reduces energy consumption and
maintains the quality of the wash.
Mist Shower
Mist Shower sprays water from a nozzle that is independent of the main water supply system. It
states that is soaks the laundry with water from the beginning of the
rinse cycle and ensures an eective wash, but it’s not part of the wash
cycle, it’s part of the rinse cycle, so this needs to state that it ensures
an eective RINSE.
(The Mist Shower function may not work if there is too large of a load
in the machine.)
Smart Care
This function enables you to check the status of the washing machine using a smartphone.
1. To enable the Smart Care function, press and hold the Pre Soak key for 3 seconds after
turning the power on or when an error occurs.
• Theerrorcodehistoryisdeletedafteryouusethisfunction.
2. The Smart Care indicator is lit on the display.
3. Run the Smart Care app on your smart phone.
• Android:
Galaxy S series, Galaxy Note series. (Other devices may not be normal operation).
Supported OS : Android 2.2 or higher
• iOS:
iPhone series
Supported OS : iOS 4.3 or higher
4. Focus your smart phone’s camera on the display panel of the washing machine.
5. If the smart phone’s camera is focused on the display panel of the washing machine,
the panel and error message is automatically recognized and the error type and
countermeasures are displayed on the smart phone.
blue round object located
left to detergent dispenser
washing a load of laundry
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 22 2015/1/3 13:56:38
English - 23
6. If the smartphone fails to recognize the error code more than twice, please enter the
error code displayed on the display panel of the washer manually into the Smart Care
app.
Downloading the Smart Care app
• DownloadtheSamsungLaundryAppintoyourmobilephonefromtheAndroidmarket
or Apple App store. (Search word : Samsung Smart Washer/Dryer)
Precautions when using Smart Care
• Iflightfromalightbulb,uorescentbulb,orlampisreectedonthedisplaypanelof
the washing machine, the smartphone may not be able to recognize the panel or error
message easily.
• Ifyouholdthesmartphoneattoolargeananglerelativetothefrontofthedisplaypanel,
it may not be able to recognize the error code. For best results, hold the smartphone so
that the front of the panel and the smartphone are parallel or nearly parallel.
Washing clothes using the cycle selector
Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control”
automatic control system. When you select a wash program, the machine will set the correct
temperature, washing time, and washing speed.
1. Press the power button.
2. Open the lid.
3. Load the articles of clothing one at a time loosely into the drum, without overfilling it.
4. Add liquid (or powder) detergent, softener, and/or bleach (if necessary) to the appropriate
compartments. See pages 24~26.
5. Close the lid.
6. Use the Cycle Selector to select the appropriate cycle according to the type of material:
NORMAL, HEAVY DUTY, COLORS/DARKS, PERM PRESS, ACTIVE WEAR, SUPER SPEED,
BRILLIANT WHITE, WATERPROOF, BEDDING, QUICK WASH, DELICATES, SPIN, and
RINSE+SPIN. The relevant indicators will illuminate on the control panel.
7. At this time, you can control the wash temperature, the number of rinse cycles, the spinning
speed, and the delay time by pressing the appropriate option button.
8. Press the start/pause button on the Cycle Selector and the wash will begin. The process
indicator will light up and the remaining time for the cycle will appear in the display.
Pause Option
To remove or add laundry items, follow these steps:
1. Press the start/pause button to unlock the lid.
The lid cannot be opened when the water is too HOT.
2. Remove or add laundry items.
3. Close the lid, and then press the start/pause button to restart the wash.
If you have Child Lock on, you must deactivate it first. See page 21.
When the cycle is finished:
After the total cycle has finished, the power will turn o automatically.3
1. Open the lid.
2. Remove laundry.
Atc (Auto temperAture control)
ATC is the control function that the washer controls water temperature with temperature sensor (thermistor).
Because there are numerous water temperatures depending on the customer’s environments (cold
areas, warm areas, various water temperatures, settings of heater temperature, etc.), ATC function in
our washer maintains the certain level of wash temperature to output the best washing performance at
each cycle.
If you select normal cycle, this cycle is the regulation and UL cycle. Since new washers must reduce
the amount of energy usage as a first priority, customers will notice more cold water entering the
washer. But, this is normal, not a problem.
In this regulation cycle, Hot temperature is similar to acceptable adult bath-water temperature and
warm temperature is similar to comfortable swimming-pool water temperature.
If customers want to wash clothes in specific water temperatures, customers should choose a dierent
cycle at each temperature (Hot/Warm/Eco Warm).
03 washing a load of laundry
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 23 2015/1/3 13:56:38
English - 24
preWAsh : WAter Jet & built-in sink (WA52J8700A*)
Water Jet and Built-in sink help you hand-wash before the washing machine starts operation. Water Jet
is available only when the door is open with the water level set to less than High. For prewashing, use the
Built-in sink that is designed to facilitate the hand-wash.
1. With the door open, lower the Built-in sink, and put
clothes to prewash on it.
2. Press Water Jet to supply water to the Built-in sink, and
hand-wash.
• Ifyouwanttohand-washwhilethemachineisoperating,
press Start/Pause to stop operation, and then follow steps 1-2
above.
•IfyouopenboththedoorandtheBuilt-insink,lowertheBuilt-
in sink manually for prewashing.
• DonotabuseWaterJet.ExcessiveuseofWaterJetincreases
water consumption.
•Whenrunningwatertothetub,dothatgently.Otherwise,
water may overflow the tub.
washing a load of laundry
cauTion
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 24 2015/1/3 13:56:38
English - 25
deterGent use
Your washer is designed to use high eciency (HE) detergents.
• For the best cleaning results, use a high eciency detergent such as
Tide HE, Wisk HE, Cheer HE or Gain HE*. High eciency detergents
contain suds suppressors that reduce or eliminate suds. When fewer
suds are produced, the load tumbles more eciently and cleaning is
maximized.
Regular detergent is not recommended. Use HE detergents only.
Reducing the amount of detergent may reduce the quality of cleaning. It is important to pre–treat
stains, sort carefully by color and soil level, and avoid overloading.
* Brand names are trademarks of their respective manufacturers.
feAtures
Automatic dispenser
Your washer has separate compartments for dispensing detergent and color-safe bleach and
fabric softener. Add all laundry additives to their respective compartments before starting your
Washer.
The automatic dispenser MUST ALWAYS be in place before you start your washer.
DO NOT open the automatic dispenser when your washer is running.
• Never exceed the manufacturer’s recommendations when adding detergent.
• This compartment holds liquid detergent for the main wash cycle, which is added to the
load at the beginning of the cycle.
• When using powdered detergent, remove the liquid detergent compartment from the
detergent drawer. The washer will not dispense powdered detergent from the liquid
detergent compartment.
To add detergent to the automatic dispenser:
1. Open the dispenser drawer.
2. Load the recommended amount of liquid (or powder) detergent into the detergent
compartment before you start your wash.
3. Close the drawer slowly and smoothly to avoid spilling, splashing, or premature dispensing of
the contents.
It is normal for a small amount of water to remain in the
dispenser compartments at the end of the cycle.
Do not put chlorine bleach in the dispenser drawer.
03 washing a load of laundry
warning
liquid detergent
compartment
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 25 2015/1/3 13:56:39
English - 26
washing a load of laundry
Loading the Liquid (or Powder) detergent compartment
1. Pour the recommended amount of laundry detergent
directly into the detergent compartment before starting
your washer.
2. If you are using color-safe bleach, add it with the detergent
to the detergent compartment.
When adding color-safe bleach with detergent, it is best if
both laundry products are in the same form – liquid.
When using powdered detergent, remove the liquid
detergent compartment from the detergent drawer. The
washer will not dispense powdered detergent from the
liquid detergent compartment.
Loading the Bleach compartment (WA52J8060A*)
(Liquid chlorine bleach only)
1. Add chlorine bleach to the bleach compartment.
DO NOT exceed the MAX FILL line.
• Avoid splashing or over–filling the compartment.
• Your washer automatically dispenses bleach into the
tub at the appropriate time.
2. The dispenser automatically dilutes liquid chlorine bleach
before it reaches the wash load.
• Never pour undiluted liquid chlorine bleach directly
onto the load or into the tub. It is a powerful chemical
and can cause fabric damage, such as weakening of
the fibers or color loss, if not used properly.
• If you prefer to use color–safe, non–chlorine bleach,
add it to the appropriate detergent compartment.
DO NOT pour color–safe bleach into the Bleach compartment.
Loading the Bleach compartment (WA52J8700A*)
(Liquid chlorine bleach only)
Add chlorine bleach to the bleach compartment.
DO NOT exceed the bleach compartment.
- Avoid splashing or over–filling the compartment.
• Neverpourundilutedliquidchlorinebleachdirectly
onto the load or into the tub. It is a powerful chemical
and can cause fabric damage, such as weakening of
the fibers or color loss, if not used properly.
• Ifyouprefertousecolor–safe,non–chlorinebleach,
add it to the appropriate detergent compartment.
DO NOT pour color–safe bleach into the Bleach
compartment.
liquid detergent
compartment
bleach
compartment
bleach
compartment
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 26 2015/1/3 13:56:39
English - 27
Loading the Fabric softener compartment
1. Pour the recommended amount of liquid fabric softener
into the softener compartment.
For smaller loads, use less than one capful.
2. Dilute the fabric softener with water until it reaches MAX
FILL in the compartment.
3. The dispenser automatically releases liquid fabric softener
at the proper time during the rinse cycle.
• Use the softener compartment ONLY for liquid fabric
softeners.
• DO NOT use the Downy Ball* in the fabric softener
compartment with this washer. It will not add fabric
softener at the appropriate time.
Use the detergent compartment.
• Do not use liquid fabric softener that is too sticky as it may not mix with the water
suciently.
* Brand names are trademarks of their respective manufacturers.
03 washing a load of laundry
fabric softener
compartment
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 27 2015/1/3 13:56:39
English - 28
maintaining your washer
cleAninG the exterior
Turn o the water faucets after finishing the day’s washing.
This will shut o the water supply to your washer and prevent the unlikely possibility of damage from
escaping water. Leave the lid open to allow the inside of your washer to dry out.
Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.
Clean the following as recommended:
Control Panel – Clean with a soft, damp cloth. Do not use abrasive powders or cleaning pads. Do not spray
cleaners directly on the panel.
cleAninG the interior
Clean the interior of your washer periodically to remove any dirt, soil, odor, mold, mildew, or bacterial
residue that may remain in your washer as a result of washing clothes.
Failure to follow these instructions may result in unpleasant conditions, including odors and/or permanent
stains on your washer or laundry.
Hard water deposits may be removed, if needed. Use cleaners labeled “Washer safe”.
storinG your WAsher
Washers can be damaged if water is not removed from hoses and internal components before storage.
Prepare your washer for storage as follows:
• Select the Quick Wash cycle and add bleach to the automatic dispenser. Run your washer through the
cycle without a load.
• Turn the water faucets o and disconnect the inlet hoses.
• Unplug your washer from the electrical outlet and leave your washer lid open to let air circulate inside the
drum.
• If your washer has been stored in below–freezing temperatures, allow time for any leftover water in your
washer to thaw out before use.
preservinG the top cover And the front frAme
Do not place any heavy or sharp objects or a detergent box on the washing machine. They can scratch or
damage the top cover of the unit.
Since the entire washing machine has a high-gloss finish, the surface can be scratched or damaged.
Avoid scratching or damaging the surface when using the washing machine.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 28 2015/1/3 13:56:39
English - 29
cleAninG the dispensers
The automatic dispenser may need to be cleaned periodically due to laundry additive buildup.
1. Pull the dispenser drawer straight back until it stops.
2. Push the ends of each side of the case at the same time.
When you feel the ends push, pull out the dispenser
drawer.
3. Remove the inserts from the 3 compartments. Rinse the
inserts and the drawer with warm water to remove traces
of accumulated laundry products.
4. To clean the drawer opening, use a small, non-metal
brush to clean the recess. Remove all residue from the
upper and lower parts of the recess.
5. Return the inserts to the proper compartments and
replace the drawer. By placing the dispenser drawer rail
on top of the compartment rail (Tilt the dispenser
drawer downward and insert it.), and then push the
drawer in firmly and slowly.
04 maintaining your washer
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 29 2015/1/3 13:56:40
English - 30
self cleAn
Self Clean is a self-cleaning cycle that removes mold
that may occur inside the washing machine.
1. Press the power button.
2. Select the self clean cycle.
• Once the self clean cycle is
selected, the only function that can be
set is Delay End.
3. Press the start/pause button.
• If you press the start/pause button,
Self Clean begins.
• Using Self Clean, you can clean the drum without using a cleansing agent.
• Never use Self Clean when laundry is in the washing machine. This may cause damage to
the laundry or a problem with the washing machine.
the self clean Auto indicator function
• If the “self clean” indicator is lit after a wash, it
indicates that tub (drum) cleaning is required. In
this case, remove the laundry from the washing
machine, turn the power on, and clean the drum by
running Self Clean.
• If you do not run Self Clean, the “self clean”
indicator turns o. However, the “self clean”
indicator will light again after two washes. Not
running Self Clean at this point will not cause a problem with the washing machine.
• Although the Self Clean Auto Indicator appears once a month or so, the frequency may dier
depending on the number of times the washing machine is used.
cAution
maintaining your washer
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 30 2015/1/3 13:56:41
English - 31
troubleshooting
check these solutions if your WAsher…
problem soluTion
Will not start. • Make sure the lid is closed.
• Make sure your washer is plugged in.
• Make sure the water source faucets are open.
• Make sure to press the Start/Pause button to start your Washer.
• Make sure Child Lock is not activated. See page 20.
• Before your washer starts to fill, it will make a series of clicking noises
to check the lid lock and do a quick drain.
• Check the fuse or reset the circuit breaker.
has no water or not enough
water.
• Turn both faucets on fully.
• Straighten the water inlet hoses.
• Disconnect hoses and clean the screens. Hose filter screens may be
clogged.
• You use the optimum water required for cleaning, but if you use the
Niagara Wash cycle, you are using more water than compared to the
Normal cycle. The cycle then proceeds to the Normal cleaning and
rinse levels.
has detergent remaining
in the automatic dispenser
after the wash cycle is
complete.
• Make sure your washer is running with sucient water pressure.
vibrates or is too noisy. • Make sure your washer is set on a level surface. If the surface is not
level, adjust your washer’s feet to level the appliance.
• Make sure your washer is not touching any other object.
• Make sure the laundry load is balanced.
stops • Plug the power cord into a live electrical outlet.
• Check the fuse or reset the circuit breaker.
• Close the lid and press the Start/Pause button to start your washer.
For your safety, your washer will not spin unless the lid is closed.
• Before your washer starts to fill, it will make a series of clicking noises
to check the lid lock and do a quick drain.
• There may be a pause or soak period in the cycle. Wait and it may
start.
• Check the screens on the inlet hoses at the faucets for obstructions.
Clean the screens periodically.
05 troubleshooting
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 31 2015/1/3 13:56:41
English - 32
troubleshooting
problem soluTion
fills with the wrong
temperature water.
• Turn both faucets on fully.
• Make sure the temperature selection is correct.
• Make sure the hoses are connected to the correct faucets.
Flush water lines.
• Disconnect the hoses and clean the screens. The hose filter screens
may be plugged.
• As your washer is filling, the water temperature may change as
the automatic temperature control feature checks incoming water
temperature. This is normal.
• While your washer is filling, you may notice just hot and/or just
cold water going through the dispenser when you have selected
cold or warm wash temperatures. This is a normal function of the
automatic temperature control feature as your washer determines the
temperature of the water.
lid locked or will not open. • Press the Start/Pause button to stop your washer.
• It may take a few moments for the lid lock mechanism to disengage.
does not drain and/or spin. • Check the fuse or reset the circuit breaker.
• Straighten the drain hoses. Eliminate kinked hoses. If there is a drain
restriction, call for service.
• Close the lid and press the Start/Pause button. For your safety, your
washer will not spin unless the lid is closed.
load is too wet at the end
of the cycle.
• Use the High spin speed.
• Use high eciency detergent to reduce over–sudsing.
• The Load is too small. Very small loads (one or two items) may
become unbalanced and not spin out completely.
leaks water. • Make sure all hose connections are tight.
• Make sure the end of the drain hose is correctly inserted and secured
to the drainage system.
• Avoid overloading.
• Use high eciency detergent to prevent over–sudsing.
has excessive suds. • Use high eciency detergent to prevent over-sudsing.
• Reduce the detergent amount for soft water, small or lightly soiled
loads.
• Non-HE detergent is NOT recommended.
has an odor. • Check your Detergent . Excessive suds collect in nooks and crannies
and cause mold.
• Run cleansing cycles to sanitize the machine periodically. (Self Clean)
• Dry the interior of your washer after the total cycle has finished.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 32 2015/1/3 13:56:41
English - 33
informAtion codes
The Washer may display information codes to help you understand what is occurring with your Washer better.
code symbol meaning soluTion
1c
The Water Level sensor is not
working properly.
When the washer displays
the “1C” code, the washer do
draining for 3 minutes. During
this time, the Power button is
inoperative.
Call for service.
4c
Your Washer has tried to fill but
was unsuccessful.
Check if the hot water supply
hose is connected.
When the washer displays
the “4C” code, the washer do
draining for 3 minutes. During
this time, the Power button is
inoperative.
Make sure the water faucets are open all the
way. Check for kinked hoses.
Check the inlet screens on the fill hoses.
If you use a Flood Safety Device, then please
remove the device and connect the water hoses
directly to the unit.
You must connect the hot water supply hose
because hot water is supplied by the Auto
Temperature Control (A.T.C.) function.
5c
Your washer is not draining. It can
also mean that the unit senses a
small clog while draining.
Do the following:
1) Turn o the unit and turn it on again.
2) Select only the Spin Cycle.
3) Press the Start/Pause to drain the water.
If it still does not drain, call for service.
lc
Your Washer has tried to fill but
has not reached the proper water
level.
When the washer displays
the “LC” code, the washer do
draining for 3 minutes. During
this time, the Power button is
inoperative.
Call for service.
ub
Unbalanced load prevented your
Washer from spinning.
Redistribute the load, press the Start/Pause
button.
dc
Lid is open when washer is
running.
Close the lid tightly and restart the cycle. If the
code reappears, call for service.
dc1
Your washer failed to lock the lid. Close the lid tightly and restart the cycle. If the
code reappears, call for service.
The door will not unlock. Make sure the lid is firmly closed.
Push the Power button to turn o your washer,
then turn it on again. If the code reappears, call
for service.
bC2
Jammed Key. Call for service.
05 troubleshooting
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 33 2015/1/3 13:56:41
English - 34
code symbol meaning soluTion
3c
Motor not running properly. Restart the cycle pressing the Start/Pause
button. If the code reappears, call for service.
AC
Communication error between
SUB PBA and MAIN PBA.
Call for service.
8C
8C2
Mems sensor problem. Call for service.
tc1
Temperature sensor problem. Restart the cycle.
If the code reappears, call for service.
oc
A fault is detected in the water
level sensor.
Call for service.
4c2
This occurs when the temperature
exceeds 50, for over 8 seconds in
the Wool and Delicates course.
Call for service.
pc
When position of the clutch can’t
be detected.
Call for service.
pc1
After position of the clutch is
detected, if the signal of the clutch
hall goes wrong, occurs error.
Call for service.
For any codes not listed above, call 1–800–726–7864 (1–800–SAMSUNG).
troubleshooting
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 34 2015/1/3 13:56:41
English - 35
appendix
fAbric cAre chArt
The following symbols provide garment care direction. The Clothing care labels include symbols for
washing, bleaching, drying and ironing, or dry cleaning when necessary. The use of symbols ensures
consistency among garment manufacturers of domestic and imported items. Follow care label directions to
maximize garment life and reduce laundering problems.
wash cycle special instructions
warning symbols for
laundering
Normal Line Dry/ Hang to Dry Do Not Wash
Permanent Press /
Wrinkle Resistant /
Wrinkle Control
Drip Dry Do Not Wring
Gentle/Delicates Dry Flat Do Not Bleach
Hand Wash heat setting Do Not Tumble Dry
Water temperature**
High
No Steam (added to
iron)
Hot Medium Do Not Iron
Warm Low dryclean
Cold Any Heat Dry Clean
bleach
No Heat/Air Do Not Dry Clean
Any Bleach (when
needed)
iron-dry or steam
temperatures
Line Dry/ Hang to Dry
Only Non-Chlorine
(color-safe)
Bleach (when needed)
High Drip Dry
Tumble Dry Cycle Medium Dry Flat
normal
Low
Permanent Press/
Wrinkle Resistant/
Wrinkle Control
Gentle/ Delicates
** The dot symbols represent appropriate wash water temperatures for various items. The temperature range for
Hotis105°-125°F/41°-52°C,forWarm85°-105°F/29°-41°CandforCold60°-85°F/16°-29°C.
(Washwatertemperaturemustbeaminimumof60°F/16°Cfordetergentactivationandeectivecleaning.)
The clothes washer can not ensure these temperatures because the actual temperature of the water entering
your washer depends on water heater settings and regional water supply temperatures. For example, cold
waterenteringthehomeinthenorthernstatesduringwintermaybe40°F/4°Cwhichistoocoldforeective
cleaning. In this situation, you will need to adjust the water temperature by selecting a warm setting, adding
some hot water to the MAX FILL line, or using your Washer’s heating option, if available.
06 appendix
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 35 2015/1/3 13:56:41
English - 36
cycle chArt
Use this chart to set the best cycle and options for you laundry.
WA52J8060A* (
: factory setting,
: selectable)
course
Temp. spin soil level
h w ew c Tc eh h m l ns h
▲
n
▼
l
normal
super speed
brillianT whiTes
colors/darKs
heaVy duTy
acTiVe wear
perm press
waTerproof
QuicK wash
bedding
delicaTes
spin
rinse+spin
self clean
course
options
aquaJet
Tm
deep clean
extra rinse
eco plus
fabric
softener
my cycle delay end
pre soak
normal
super speed
brillianT whiTes
colors/darKs
heaVy duTy
acTiVe wear
perm press
waTerproof
QuicK wash
bedding
delicaTes
spin
rinse+spin
self clean
Temp. spin soil level
h: Hot
w: Warm
ew: Eco Warm
c : Cold
Tc : Tap Cold
eh: Extra High
h: High
m: Medium
l: Low
ns: No Spin
h: Heavy
▲
n: Normal
▼
l: Light
appendix
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 36 2015/1/3 13:56:42
English - 37
cycle chArt
Use this chart to set the best cycle and options for you laundry.
WA52J8700A* (
: factory setting,
: selectable)
course
Temp. spin soil level
eh h w ew c Tc eh h m l ns h
▲
n
▼
l
normal
super speed
brillianT whiTes
colors/darKs
heaVy duTy
acTiVe wear
perm press
saniTiZe
deep sTeam
waTerproof
QuicK wash
bedding
delicaTes
spin
rinse+spin
self clean
course
options
aquaJet
Tm
deep clean
extra rinse
eco plus
fabric
softener
my cycle delay end
pre soak
normal
super speed
brillianT whiTes
colors/darKs
heaVy duTy
acTiVe wear
perm press
saniTiZe
deep sTeam
waTerproof
QuicK wash
bedding
delicaTes
spin
rinse+spin
self clean
Temp. spin soil level
eh: Extra Hot
h: Hot
w: Warm
ew: Eco Warm
c : Cold
Tc : Tap Cold
eh: Extra High
h: High
m: Medium
l: Low
ns: No Spin
h: Heavy
▲
n: Normal
▼
l: Light
06 appendix
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 37 2015/1/3 13:56:42
English - 38
helpinG the environment
• Your washer is manufactured from recyclable materials. If you decide to dispose of it, please observe
local waste disposal regulations. Cut o the power cord so that the appliance cannot be connected
to a power source. Remove the lid so that animals and small children cannot get trapped inside the
appliance.
• Do not exceed the detergent quantities recommended in the detergent manufacturers’ instructions.
• Use stain removal products and bleaches before the wash cycle only when necessary.
• Save water and electricity by only washing full loads (the exact amount depends upon the program used).
declArAtion of conformity
This appliance complies with UL2157.
specificAtion
Type Top loading washer
dimensions div inches (cm)
A.
height
45.7”(116.0)
b. Width
27.0”(68.6)
c. height with lid open
59.8”(152.0)
d. depth
29.3”(74.4)
waTer pressure 20-116 psi (137-800 kPa)
neT weighT 65.0 kg (143.3 lb)
spin reVoluTion 1100 rpm
power consumpTion WAshinG 120 V 700 W
spin 120 V 400 W
drAin 120 V 80 W
appendix
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 38 2015/1/3 13:56:42
English - 39
warranty (U.S.A)
samsung washer
limiTed warranTy To original purchaser
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:
One (1) year part and labor, Two (2) years Control Board Parts (Part Only), Three (3) years stainless tub part
(Part Only), Five (5) years washing motor part (Part Only), Ten (10) years washing DD motor part (Part Only).
This limited warranty begins on the original date of purchase, and is valid only on products purchased and
used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem
determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized
service center. The original dated bill of sale must be presented upon request as proof of purchase to
SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the
warranty period at no charge, subject to availability within the contiguous United States. In-home service is
not available in all areas.
To receive in-home service, product must be unobstructed and accessible to the service agent. If service
is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized
service center.
SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein,
with new or reconditioned parts or products if found to be defective during the limited warranty period
specified above. All replaced parts and products become the property of SAMSUNG and must be returned
to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90)
days, whichever is longer.This limited warranty covers manufacturing defects in materials and workmanship
encountered in normal, noncommercial use of this product and shall not apply to the following: damage
that occurs in shipment; delivery and installation; applications and uses for which this product was not
intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect,
fire, water, lightning, or other acts of nature or God; use of products, equipment, systems, utilities, services,
parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied
or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical
line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions,
maintenance and environmental instructions that are covered and prescribed in the instruction book;
product removal and reinstallation; problems caused by pest infestations. This limited warranty does not
cover problems resulting from incorrect electric current, voltage or supply, light bulbs, house fuses, house
wiring, cost of a service call for instructions, or fixing installation errors. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 39 2015/1/3 13:56:42
English - 40
EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS
OR IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR
PURPOSE.
NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT
TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS
OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY
TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED,
AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE
PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS,
DAMAGE, OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR
PROPERTY ARISING OUT OF THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT. THIS LIMITED
WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS
PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
samsung electronics america, inc.
85 challenger road
ridgefield park, nJ 07660
1-800-samsung (726-7864)
www.samsung.com/us/support
Visits by a Service Engineer to explain functions, maintenance or installation is not
covered by warranty.
Please contact your Samsung call agent for help with any of these issues.
warranty (U.S.A)
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 40 2015/1/3 13:56:42
English - 41
warranty (CANADA)
samsung washer
limiTed warranTy To original purchaser
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:
One (1) year part and labor, Ten (10) years washing DD motor (Part only).
This limited warranty begins on the original date of purchase, and is valid only on products purchased
and used in the Canada. To receive warranty service, the purchaser must contact SAMSUNG for problem
determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized
service center. The original dated bill of sale must be presented upon request as proof of purchase to
SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the
warranty period at no charge, subject to availability within the Canada. In-home service is not available in all
areas.
To receive in-home service, product must be unobstructed and accessible to the service agent. If service
is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized
service center.
SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein,
with new or reconditioned parts or products if found to be defective during the limited warranty period
specified above. All replaced parts and products become the property of SAMSUNG and must be returned
to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90)
days, whichever is longer.This limited warranty covers manufacturing defects in materials and workmanship
encountered in normal, noncommercial use of this product and shall not apply to the following: damage
that occurs in shipment; delivery and installation; applications and uses for which this product was not
intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect,
fire, water, lightning, or other acts of nature or God; use of products, equipment, systems, utilities, services,
parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied
or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical
line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions,
maintenance and environmental instructions that are covered and prescribed in the instruction book;
product removal and reinstallation; problems caused by pest infestations. This limited warranty does not
cover problems resulting from incorrect electric current, voltage or supply, light bulbs, house fuses, house
wiring, cost of a service call for instructions, or fixing installation errors. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 41 2015/1/3 13:56:42
English - 42
EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS
OR IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR
PURPOSE.
NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT
TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS
OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY
TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED,
AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE
PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS,
DAMAGE, OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR
PROPERTY ARISING OUT OF THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT. THIS LIMITED
WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS
PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific rights, and you may also have other rights, which vary from province to
province.
To obtain warranty service, please contact SAMSUNG at:
samsung electronics canada inc.
2050 derry road west
mississauga, ontario l5n 0b9 canada
1-800-samsung (726-7864)
www.samsung.com/ca/support (english)
www.samsung.com/ca_fr/support (french)
warranty (CANADA)
Visits by a Service Engineer to explain functions, maintenance or installation is not
covered by warranty.
Please contact your Samsung call agent for help with any of these issues.
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 42 2015/1/3 13:56:42
memo
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 43 2015/1/3 13:56:42
QUESTIONS OR COMMENTS?
country call or VisiT us online aT
U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support
CANADA 1-800-SAMSUNG (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
MEXICO 01-800-SAMSUNG (726-7864) www.samsung.com/mx/support
Code No. DC68-03133Y_EN
Scan this with your smartphone
WA8000J_WA52J8060AW_USER MANUAL_DC68-03133Y.indd 44 2015/1/3 13:56:42
