Sencor SES 7015CH Automatic Espresso Maker User Manual

- 1 -

03/2020

EN Automatic Espresso Maker

Translation of the original manual

SES 7015CH

- 2 -

03/2020

Automatic Espresso Maker

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

■ This appliance may not be used by children. Keep the appliance

and its power cord away from children.

■ The appliance may be used by persons with reduced physical,

sensory or mental capabilities or with a lack of experience and

knowledge, if they are supervised or have been instructed

to use the appliance in a safe manner and understand the

potential dangers.

■ Children must not play with the appliance.

■ In the event that the power cord is damaged, have it repaired

at a professional service centre to prevent causing a dangerous

situation. It is forbidden to use the appliance if it has a damaged

power cord.

■ Keep the appliance and its accessories in clean condition.

Clean and maintain it according to the instructions in chapter

Cleaning and maintenance. Never wash the appliance under

running water or submerge it in water or another liquid.

Warning:

Incorrect use may lead to injuries.

■ Always disconnect the appliance from the power supply when

leaving it without supervision and before assembly, disassembly

or cleaning.

■ This appliance is designed for household use only. It is not

intended for use in locations such as:

– kitchens in stores; offices and other workplaces;

– in agriculture;

- 3 -

03/2020

– guests of hotels, motels and other accommodation locations;

– in bed and breakfast establishments.

Warning:

Take care that water is not poured on the power plug.

Attention: Hot surface.

When using the appliance, its accessible surfaces may

heat up. Do not touch the hot surface.

■ Before connecting the appliance to a power socket, check that the rated voltage on its rating label matches the electrical voltage in the power socket.

■ Connect the appliance only to a properly grounded socket. For safety reasons, we do not recommend using multi-socket adapters or extension cords.

■ Do not place the appliance on window sills, kitchen sink drainboards or unstable surfaces. Always place it on a stable, even and dry surface.

■ Do not place the appliance on or near an electrical or gas stove, or in the vicinity of an open flame.

■ Never use the appliance in the near vicinity of a bath, shower or swimming pool.

■ Use the appliance only for the purpose for which it was designed.

■ Use the appliance according to the instructions in the user‘s manual. Otherwise, injuries, damage to the appliance or a dangerous situation may result.

■ Only use the appliance with the original accessories that came with it.

■ To ensure sufficient air circulation, free space of at least 15 cm must be maintained around and above the appliance when it is running.

■ Only use the top surface of the appliance for warming cups. Do not use it as a storage rack.

■ Fill the water tank with clean cold water. Do not pour hot water or other liquids into it or place any items inside it.

■ Before turning on the appliance, check that:

■ – the drip tray together with the grate is installed in position;

■ – the water tank is filled with a sufficient amount of water and is properly installed in position. The water level must not exceed the water level mark.

■ When operating the appliance, be especially careful to avoid scalding by boiling water or steam.

■ The hot water function must not be used continuously, no more than one full water tank at a time.

■ Regularly inspect the water level in the water tank when using the appliance. When the water level falls below the minimum water level mark, add water. Before adding

water, first turn the appliance off and disconnect it from the power socket.

■ Use the built-in-in coffee grinder only for grinding coffee beans. Do not use it for any other purposes.

■ Ensure that no hair or other items enter the grinder while it is grinding. The coffee bean hopper lid should always be properly closed unless one is refilling coffee beans

or setting the fineness of the grind.

■ To protect the pump from damage, the appliance is equipped with a built-in thermal fuse that will disengage it when it runs empty. In the event that such a situation

occurs, disconnect the power cord from the power socket and allow the appliance to cool down for at least 30 minutes. Then you may continue using it.

■ Do not move the appliance with a coffee cup located on the drip tray grate or with cups located on the cup warming surface.

■ Make sure that the power cord does not come into contact with a hot surface.

■ Disconnect the appliance from the power socket by gently pulling the plug of the power cord, and not the power cord itself. Otherwise, this could damage the power

cord or the socket.

■ The appliance is equipped with a removable power cord. If the power cord is damaged, it must replaced with a new original power cord.

■ Do not submerge the appliance, the power cord or the power plug in water or in any other liquid.

■ Prevent the power cord and power plug from coming into contact with water or another liquid.

■ Make sure that the removable power cord does not come into contact with water or moisture.

■ To avoid the danger of injury by electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs performed at an authorised service

centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality warranty.

- 4 -

03/2020

7 8 9 10

2 3 4 5 6

- 5 -

03/2020



- 6 -

03/2020

Automatic Espresso Maker

User'smanual

■

Prior to using this appliance, please read the user’smanual thoroughly, even in cases,

when one has already familiarised themselves with previous use of similar types of

appliances. Only use the appliance in the manner described in this user’smanual.

Keep this user’smanual in asafe place where it can be easily retrieved for future

reference.

■ We recommend saving the original cardboard box, packaging material, purchase

receipt and responsibility statement of the vendor or warranty card for at least the

duration of the legal liability for unsatisfactory performance or quality. In the event

of transportation, we recommend that you pack the appliance in the original box

from the manufacturer.

DESCRIPTION OF THE APPLIANCE

A1 1.1-litre water tank

A2 Coffee bean hopper lid

A3 150-gram coffee bean hopper

Agrinder with adjustable grinding

fineness is located inside.

A4 Control panel with display

A5 Removable power cord

A6 Brewing unit

A7 Service access door

A8 Coffee and hot water spout

its height is adjustable.

A9 Coffee grounds container

A10 Inner drip tray

A11 Outer drip tray

DESCRIPTION OF THE TOUCH CONTROL PANEL WITH DISPLAY

B1 Insufficient water in the water tank

signal or water tank not installed

signal

B2 Insufficient amount of coffee beans

in the coffee bean hopper signal

B3 Full coffee grounds container

signal (indicator is lit)

the inner drip tray / coffee grounds

container is not correctly installed

signal (indicator is flashing)

B4 Brewing unit not installed correctly

signal (indicator is lit) or service

access door is open or incorrectly

installed signal (indicator is

flashing)

B5 Descaling required signal

(indicator is lit) or

descaling process is running signal

(indicator is flashing)

B6 Drain internal lines function is

running

B7 On/Off touch button

B8 Dispense hot water touch button

B9 Prepare espresso coffee touch

button

B10 Prepare lungo coffee touch button

BEFORE FIRST USE OF THE APPLIANCE

1. Remove all packaging materials from the appliance and remove any protective

lm, promotional tags or labels.

2. Install the appliance on an even, dry and clean surface. Take out the water tank

A1, rinse it out with clean water with the addition of asmall amount of neutral

dishwashing detergent. Then rinse it out thoroughly using clean water, dry it and

put it back in its place. Properly attach the outer drip tray A11 to the appliance.

Wipe the outer surface of the appliance with alightly dampened cloth and then

wipe it thoroughly dry.

3. Fully unwind the removable power cord A5 and connect it to the corresponding

socket at the rear of the appliance.

4. To ensure the optimal lifetime of the appliance, before using it for the rst time, it

is necessary to allow the internal components to rinse out with hot water several

times. For this purpose, use button B8 as described in chapter Operating the

appliance.

FILLING THE WATER TANK

1. Grasp the water tank A1 by its lid. It also serves as acarry handle. Lift it up and

remove it from the rear part of the appliance.

2. Fill the water tank A1 with clean water up to the maximum water mark (see g. C1)

and insert it back into the appliance. Make sure that the water tank A1 is properly

installed in its place.

Note:

The water that you pour into the water tank A1 should ideally be at room temperature

(approximately 25 °C). Water that is too cold, could negatively aect the nal taste of

the coee beverage.

Attention:

The water tank A1 has amaximum capacity of 1.1 litres of water. Do not

overll it.

Never ll the water tank A1 with warm or hot water, sparkling water or

other liquids such as, for example, milk. This could damage the appliance.

Never ll the water tank A1 by pouring in the water while it is inserted

inside the appliance (see g. C2). There is a danger of splashing the

appliance or overlling the water tank A1.

3. Do not leave water in the water tank A1 for longer than one day. For brewing

quality fresh coee, it is necessary to always use fresh water. Otherwise, the avour

of the resulting beverage may be negatively aected.

FILLING THE COFFEE BEAN HOPPER

1. Remove the coee bean hopper lid A2.

2. Pour roasted coee beans into the coee bean hopper A3 and close the lid A2.

Do not leave the lid of the coee bean hopper A2 open, otherwise, the coee

beans will lose their aroma more quickly.

Attention:

The coee bean hopper A2 has amaximum capacity of 150 g of coee

beans. Do not overll it.

Never ll the coee bean hopper A3 with ground or instant coee,

caramelised or otherwise specially modied coee beans, cocoa beans or

other items that could result in damage to the appliance.

CONTROLLING THE FINENESS OF GROUND COFFEE

1. Use the grinding neness regulator located inside the coee bean hopper A3 to

set the grinding neness of the coee beans in 5 levels, see gure D.

2. Turning the regulator towards the position marked with the plus symbol sets

acoarser grind, and turning it in the opposite direction sets aner grind.

3. The neness of the grind is set only while the grinder is running. Otherwise, you

could damage your appliance. For darker coee beans, we recommend setting

acoarser grind, for lighter coloured coee beans, we recommend aner grind.

4. If the brewed coee is owing out very slowly, it means that the coee grains are

too nely ground and it is necessary to set acoarser grind. On the other hand, if

the brewed coee is owing out too fast, it means that the coee grains are too

coarsely ground and it is necessary to set aner grind.

RECOMMENDATIONS FOR PURCHASING AND STORING

COFFEE

■ To reduce the storage time, purchase coffee beans in smaller packages.

■

Use fresh roasted coffee beans with amarked roasting date and consume them

within 3 weeks of the roasting date.

■ Store coffee beans in acool, dark and dry location, ideally in an air-tight container.

OPERATING THE APPLIANCE

1. Make sure that the power cord connector A5 is connected to the appliance.

Connect the power cord plug A5 to apower socket. Make sure that the water tank

A1 is relled with fresh water and that the coee bean hopper A3 is lled with

asucient quantity of coee beans and that the appliance is properly assembled.

Note:

When relling water and coee beans, always follow the instructions provided in

chapter Filling the water tank and Filling the coee bean hopper.

2. To start the appliance, press touch button B7. When button B7 is pressed, the

appliance will switch to the stand-by mode.

3. Place acup, mug or glass underneath the spout A8. Set the height of the spout

A8 by sliding it up or down depending on the size of your cup, mug or glass. If the

cup or glass is too tall, you may remove the outer drip tray A11. After removing

the cup or glass, return the drip tray A11 to its place.

4. Based on your preference, you can prepare either acup of espresso or lungo

coee. To start brewing your favourite cup of coee, press touch button B9 or

B10. The respective touch button will start ashing and the spout A8 will be lit.

This signalises that the coee brewing process has started. The end of the process

is signalled by the light on the button and spout A8 turning o. Your coee is now

ready to be served.

Note:

If your coee owed out too slow or too fast, when preparing the next cup of coee,

adjust the grinder settings according to the instructions contained in the chapter

Controlling the neness of ground coee. The adjusted neness of the grind will

become apparent after the next two cups of coee.

5. Press the hot water dispense button B8 to start the hot water dosing process.

Button B8 will start ashing and the spout A8 will be lit. This signals that hot

water is being dispensed. As soon as button B8 and the spout light A8 turn o,

the dispensing of hot water is complete. Now you may remove the cup, mug or

glass lled with hot water.

6. When you have nished using the appliance, turn it o by pressing button B7. Then

clean it out according to the instructions in chapter Cleaning and maintenance.

In the event that you do not turn o the appliance, to save power it will turn itself

o automatically as described in chapter Setting amode.

USER SETTINGS

1. The amount of coee or hot water can be regulated in the range from 25 to 250ml.

2. Set the volume by pressing and holding down the respective button B9, B10 or

B8 during the coee extraction process or while the hot water is being dispensed.

As soon as the required amount of coee or hot water is in the cup, mug or glass,

release the respective button. After releasing the button, 2 beeps will be sounded.

This signals that the amount of coee or hot water has been stored in memory.

3. To reset to default settings, proceed according to the instructions in chapter

Setting amode.

SETTING AMODE

■

The appliance can be set to an ECO mode, afast mode or the default factory settings.

In ECO mode, greater power savings are achieved. In the fast mode, the coffee is

prepared faster than with the default factory settings.

- 7 -

03/2020

ECO mode Fast mode Default

settings

Spout light A8 No Yes Yes

Pre-brew function* Yes No Yes

Automatic shut-o time 10 minutes 30 minutes 20 minutes

Option to save amount of

espresso / hot water to memory

Yes Yes Yes / Reset to

default settings

*Note:

The pre-brew function means that the ground coee is rst moistened with asmall

amount of water. This will cause the coee to swell and thereby when it is subsequently

fully brewed, its avour will be developed fully, and its aromatic compounds and essential

oils will be fully extracted.

1. In the stand-by mode, press and hold down button B7 for 5 seconds. Button B7

will start ashing and at the same time other buttons will also be ashing or lit

depending on the mode that is set.

Button B8 Button B9 Button B10

ECO mode Lit Flashing Flashing

Fast mode Flashing Lit Flashing

Default settings Flashing Flashing Lit

2. To set the ECO mode, press button B8, to set the fast mode press button B9 and

to reset to default settings, press button B10. After setting amode, 2 beeps will

be made. In the event that you attempt to set amode that is already set, the

appliance will not react to the button being pressed.

3. If you do not wish to change the mode settings, press button B7 once more, or

wait 5 seconds until the appliance automatically switches back to the stand-by

mode.

CLEANING AND MAINTENANCE

Everyday cleaning and maintenance

■

Timely cleaning and maintenance is very important for operating the appliance

and extending its lifetime.

■ Before cleaning, turn off the appliance, disconnect it from the power socket and

allow it to cool down.

■ Remove the outer drip tray A11. Empty out all its contents over asink, and wash it

using clean water and then dry it thoroughly.

■ Slide out the inner drip tray A10 with the coffee grounds container A9. Empty out

the coffee grounds container A9 and wash it with clean water. Then dry it thoroughly.

Empty out the inner drip tray A10 and if dirty, wipe it with aclean dampened cloth

and then dry it thoroughly.

■ Install the inner drip tray A10, coffee grounds container A9 and the outer drip tray

A11 back in their place.

■ Slide out and remove the service access door A7. Press the brewing unit release

button and take out the brewing unit A6. Wash it under running water and dry

it out thoroughly.

■

Install the brewing unit A6 properly in its place and attach the service access door A7.

■ In the event that the appliance will not be used again on the same day, empty out

the contents of the water tank A1 and put it back in its place.

■

Once amonth, it is recommended to thoroughly clean out the water tank A1 using

asoft cloth and asolution of water and neutral kitchen detergent. Then thoroughly

rinse out the water tank A1 with clean water, dry it and put it back in its place.

■ Only clean the coffee bean hopper A3 with aclean, dry cloth or paper towel. Do

not clean it with water.

■ To clean the outer surface of the appliance, use aclean, lightly dampened cloth.

Then wipe everything so that it is thoroughly dry. Do not use solvents, steel wool,

abrasive cleaning agents, etc. to clean the appliance.

■

Do not submerge the appliance or its power cord in water and do not wash it

under running water.

Self-Clean function

■

When indicator B5 lights up during operation, it is necessary to start the Self-

Clean function.

■

The appliance will work best when the Self-Clean function is used regularly, at least

once per month, or more frequently based on the hardness of the water that is

used. This will extend its lifetime and improve power efficiency because limescale

deposits negatively affect electricity consumption.

■

Fill the water tank A1 all the way to the maximum water mark according to the

instructions contained in chapter Filling the water tank.

■

Add descaling agents specially intended for descaling espresso machine type

appliances into the water tank A1. These agents can normally be purchased in

specialised electrical appliance stores or in online stores. Follow the instructions

on the manufacturer’spackaging when dosing the purchased descaling agent.

Attention:

For descaling, do not use vinegar, etc. Otherwise, the appliance could be

damaged.

■ Under the spout A8, place acontainer with acapacity of at least 1.1l.

■

In the stand-by mode, simultaneously press and hold down buttons B7 and B9

for 5 seconds. Abeep is made and indicator B5 and touch button B9 will flash.

■ To start the self cleaning process, press button B9.

Note:

In the event that you wish to return to the stand-by mode at this stage, press button B7.

■ The progress of the self cleaning procedure is signalled by indicator B5. Take care

to prevent scalding by hot water or the escaping steam. Do not interrupt the

process in this phase.

■

Once the water in the water tank A1 is used up, indicator B1 and button B9 will start

flashing. Empty out the remaining contents of the water tank A1 and fill it up to the

maximum water mark with clean water. When the filled water tank A1 is inserted

back into the appliance, indicator B1 will turn off.

■ Empty out the contents of the container under the spout A8 and put it back in its

place. To complete the self cleaning process, press button B9.

■

When the self cleaning process is complete, the appliance will turn off automatically.

Manual cleaning (ushing the spout)

■

We recommend that you always clean the coffee spout when you have finished

using it. It is also recommended to do this when the appliance has not been used

for an extended period of time.

■

In the stand-by mode, simultaneously press and hold down buttons B7 and B8

for 5 seconds.

■

The light on buttons B8, B9 andB10 will turn off. Asmall amount of water will

flow out of the spout, which will flush it out. Water will flow into the drip tray A11.

Attention:

Avoid coming into contact with hot water.

■

After finishing the manual clean, the appliance will switch back to the stand-by

mode.

Drain internal lines

■

It is recommended to drain the internal lines when you plan on not using the

appliance for and extended period of time, before transporting it, etc.

■ In the stand-by mode, simultaneously press and hold down buttons B7 and B10

for 5 seconds. Indicator B6 will start flashing.

■ Remove the water tank A1 from the appliance. Indicator B6 will be lit. This signals

that the draining of the internal lines is running.

Note:

If you press button B7 before taking out the water tank A1, you will return back to

the stand-by mode.

■

When the internal line draining process is complete, the appliance will turn off

automatically.

- 8 -

03/2020

TROUBLESHOOTING

Problem Cause Solution

The appliance is

not working.

It is not connected

to apower socket.

Connect it to aworking power socket

and press button B7.

Check that the power cord A5 is

properly connected to the socket in the

appliance and that the plug is properly

inserted in the power socket.

There is no

response when

abutton is pressed

or the response is

delayed.

Electromagnetic

interference of

the appliance is

occurring.

The touch panel is

soiled.

Turn off the appliance and turn it back

on again after several minutes.

Turn off the appliance, disconnect it

from the power socket and clean the

panel using aclean, lightly dampened

cloth and then thoroughly wipe it dry.

Coffee is not warm

enough.

Cups have not

been warmed up.

The brewing unit

A6 is too cold.

Warm up the cups.

Flush out the spout three times before

brewing coffee.

Coffee is not

flowing out the

spout.

The coffee spout is

soiled.

Regularly clean the coffee spout

according to the instructions in chapter

Cleaning and maintenance.

The first cup

does not taste

particularly good.

There is an

insufficient

amount of ground

coffee inside the

brewing unit A6.

Dispose of the first coffee that you

brewed. The next cup will now be in

order.

The coffee lacks

froth.

The coffee beans

are not fresh.

Use fresh coffee beans or try using

adifferent brand of coffee.

The touch buttons

are not sufficiently

sensitive.

The touch buttons

are not pressed

properly.

It is necessary to use the appliance from

the front. Press the bottom part of the

icon of the touch button.

The appliance

heats up for too

long.

The appliance is

soiled by limescale

deposits.

Descale it according to the instructions

in chapter Cleaning and maintenance.

The water tank

A1 is removed

or it is running

out of water, but

the respective

indicator is

not signalling

anything.

The area around

the connector at

the bottom of the

water tank A1 is

damp or wet.

Thoroughly dry out any moisture or

water in the vicinity of the connector.

TECHNICAL SPECIFICATIONS

Rated voltage range ...................................................................................................... 220−240 V

Rated frequency.................................................................................................................50–60 Hz

Rated power input ..................................................................................................1 235–1 470 W

Noise level ........................................................................................................................... 75 dB(A)

The declared noise emission level of the appliance is 75 dB(A), which represents a level

A of acoustic power with respect to a reference acoustic power of 1 pW.

We reserve the right to change text and technical specications.

INSTRUCTIONS AND INFORMATION REGARDING THE

DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at asite designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC

EQUIPMENT

This symbol on products or original documents means that used

electric or electronic products must not be added to ordinary

municipal waste. For proper disposal, renewal and recycling hand

over these appliances to determined collection points. Alternatively,

in some European Union states or other European countries you may

return your appliances to the local retailer when buying an equivalent

new appliance.

Correct disposal of this product helps save valuable natural resources

and prevents potential negative eects on the environment and

human health, which could result from improper waste disposal. Ask your local

authorities or collection facility for more details.

In accordance with national regulations penalties may be imposed for the incorrect

disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic appliances, ask your retailer or supplier

for the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product,

request the necessary information about the correct disposal method from the local

council or from your retailer.

This product meets all the basic requirements of EU directives related

to it.

Sencor SES 7015CH Automatic Espresso Maker

Product's Documents

User Manual

Specifications

Sencor SES 7015CH Questions and Answers
