Danby DCR032KA1WDB 91 litre Compact Refrigerator User Manual

OWNER’S MANUAL

Distributed by Exertis (UK) Ltd.

Technology House, Magnesium Way, Hampton, Burnley, England, BB12 7BF

2018.09.06

COMPACT REFRIGERATOR

Owner’s Manual...............................1 - 7

MODEL

DCR032KA1WDB

DCR032KA1BDB

1

SAFETY REQUIREMENTS

DANGER: Risk of ﬁ re or explosion. Flammable

refrigerant used. Do not puncture refrigerant tubing.

• Do not use mechanical devices to defrost

refrigerator.

• Ensure that servicing is done by factory

authorized service personnel, to minimize

product damage or safety issues.

• Consult repair manual or owner’s guide before

attempting to service this product. All safety

precautions must be followed.

• Dispose of properly in accordance with federal

or local regulations.

• Follow handling instructions carefully.

WARNING: Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear

of obstruction.

WARNING: Do not use mechanical devices or other

means to accelerate the defrosting process, other

than those recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: Do not use electrical appliances inside

the food storage compartments of the appliance,

unless they are of the type recommended by the

manufacturer.

CAUTION: Children should be supervised to ensure

that they do not play with the appliance.

DANGER: Risk of child entrapment. Before throwing

away an old appliance:

• Remove the door or lid.

• Leave shelves in place so that children may not

easily climb inside.

This appliance is intended to be used in household

and similar applications such as:

• Staff kitchen areas in shops, ofﬁ ces and other

working environments;

• Farm houses and by clients in hotels, motels and

other residential type environments;

• Bed and breakfast type environments;

• Catering and similar non-retail applications.

SAFETY REQUIREMENTS

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall not

be made by children without supervision.

Do not store explosive substances such as aerosol

cans with a ﬂ ammable propellant in this appliance.

GROUNDING INSTRUCTIONS

This appliance must be grounded. Grounding

reduces the risk of electrical shock by providing an

escape wire for the electrical current.

This appliance has a cord that has a grounding

wire with a 3-prong plug. The power cord must be

plugged into an outlet that is properly grounded.

If the outlet is a 2-prong wall outlet, it must be

replaced with a properly grounded 3-prong wall

outlet. The serial rating plate indicates the voltage

and frequency the appliance is designed for.

WARNING - Improper use of the grounding

plug can result in a risk of electric shock.

Consult a qualiﬁ ed electrician or service agent

if the grounding instructions are not completely

understood, or if doubt exists as to whether the

appliance is properly grounded.

Do not connect your appliance to extension

cords or together with another appliance in the

same wall outlet. Do not splice the power cord.

Do not under any circumstances cut or remove the

third ground prong from the power cord. Do not

use extension cords or ungrounded (two prongs)

adapters.

If the power supply cord is damaged, it must be

replaced by the manufacturer, its service agent or

similar qualiﬁ ed person in order to avoid hazard.

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS!

LOCATION

• Two people should be used when moving the

appliance.

• Remove interior and exterior packaging prior to

installation. Wipe the outside of the appliance

with a soft, dry cloth and the inside with a

lukewarm wet cloth.

• Place the appliance on a ﬂ oor that is strong

enough to support it when it is fully loaded.

• Do not place the appliance in direct sunlight or

near sources of heat, such as a stove or heater,

as this can increase electrical consumption.

Extreme cold ambient temperatures may also

cause the appliance to perform improperly.

• Do not use the appliance near water, for

example in a wet basement or near a sink.

• This appliance is intended for household use

only. It is not designed for outside installation,

including anywhere that is not temperature

controlled (garages, porches, vehicles, etc.).

• Before connecting the appliance to a power

source, let it stand upright for approximately

6 hours. This will reduce the possibility of a

malfunction in the cooling system from handling

during transportation.

• This appliance is 44.9 cm (18.9 inches) wide

by 84 cm (33.1 inches) high by 48.1 cm

(18.9 inches) deep. Make sure that you leave

the minimum amount of space between the

appliance and all surrounding walls and vents.

• Allow 12.7 cm (5 inches) of space between the

back, sides and top of the appliance and all

adjacent walls.

• This appliance is intended for free-standing

installation only and is not intended to be

built into a cabinet or counter. Building in this

appliance can cause it to malfunction.

FEATURES

1. Freezer Compartment with Door

2. Thermostat Dial and Push Button Defrost

3. Drip Tray

4. Glass Shelves

5. Magnetic Gasket: Tight ﬁ tting door seal keeps

all the cooling power locked inside.

6. CANSTOR™ Door Liner: Holds 355ml cans of

pop, juice, or beer.

7. Bottle Rack: For tall, small and medium cans or

jars.

8. Leveling Leg: Adjust so the unit is level.

2

INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS

Consumer Helpline: 0300 303 3904

3

OPERATING INSTRUCTIONS

Consumer Helpline: 0300 303 3904

TEMPERATURE SELECTION

The temperature of the appliance can be adjusted

by turning the thermostat dial.

The thicker, darker part of the blue line is the coldest

setting.

The thinner, lighter part of the blue line is the

warmest setting.

The “0” position will turn off the cooling function.

Internal temperature of the appliance can vary

based on ambient temperature, the quantity of items

stored and how frequently the door is opened.

LEVELING INSTRUCTIONS

There is an adjustable leg on the bottom of the

appliance that can be turned up or down to ensure

that the appliance is level.

1. Turn the leveling leg counter-clockwise as far as

it will go, until the top of the foot is touching the

bottom of the cabinet.

2. Slowly turn the leveling leg clockwise until the

appliance is level.

DEFROSTING THE APPLIANCE

This refrigerator is equipped with a “Push Button”

defrost system. To activate the defrost cycle, push

the red defrost button located on the center of

the thermostat dial. The defrost cycle is initiated

immediately.

When defrosting is complete, the red button will

release and the refrigerator will resume normal

operating conditions.

Note: If the red defrost button is pressed

accidentally, it is not possible to manually deactivate

the defrost cycle. The defrost cycle must be allowed

to run its course.

Defrosting the refrigerator should take place

whenever ice build-up inside the freezer

compartment reaches 6 mm (1/4”) thick. Defrosting

may take a few hours, depending on the amount of

accumulated ice and ambient indoor temperature.

To speed up the defrosting process, remove all

frozen foods from the freezer section and leave the

door open for a short period of time.

Monitor the refrigerator closely during the defrosting

process to avoid water spilling and causing damage

to ﬂ ooring or counter tops.

Important: Remember to close the refrigerator

door before the defrost cycle terminates and

normal operating conditions resume. The drip tray

should be in position directly below the freezer

compartment to catch condensed water during

defrosting.

Note: Never use sharp or pointed instruments to

remove ice from the freezer compartment. The

freezer compartment contains refrigerated gas

lines and if accidentally pierced it will render the

refrigerator inoperable and void the manufacturers

warranty. Do not allow the refrigerator to continue

operation if the freezer compartment is pierced.

OPERATING INSTRUCTIONS

4

Consumer Helpline: 0300 303 3904

DOOR REVERSAL INSTRUCTIONS

If the appliance is placed on its back or side for any

length of time during this process, it must be allowed

to remain upright for 6 hours before plugging it in

to avoid damage to the internal components.

1. Remove the three screws from the back of the

worktop, lift the back of the worktop and pull

it toward the front of the appliance to remove

it. Remove the worktop hinge hole cover from

the left side of the worktop and move it to the

hinge hole on the right side of the worktop.

See ﬁ gure 1.

2. Remove the screw from the door spindle cover

and remove the upper right hinge and door

from the chassis. Remove the door spindle from

the upper right hinge. See ﬁ gure 2.

3. Remove the lower hinge hole cover from the

bottom left side of the door and move it to the

bottom right side of the door. See ﬁ gure 3.

4. Remove the adjustable foot and the two screws

holding the bottom hinge. Move the bottom

hinge to the left side of the chassis and install

with the screws. Install the adjustable foot on the

left side of the appliance and move the solid foot

to the right side of the appliance. See ﬁ gure 4.

5. The upper left hinge is in the accessory bag

inside the appliance. Install the door spindle

on the upper left hinge. Install the upper left

hinge and door onto the chassis. Install the door

spindle cover with a screw. Reinstall the worktop

by laying it on top of the appliance and pushing

it toward the back until it clicks into place and

then reinstall the three screws at the back. See

ﬁ gure 5.

Note: When reinstalling the door, ensure that the

top of the door is level with the top of the chassis

and that the rubber gasket makes a good seal with

the chassis all the way around.

Note: Images are for instructional purposes only.

Your unit may appear slightly different.

A. Worktop Hinge Hole Cover

B. Worktop

C. Door Hinge Hole Cover

D. Door Spindle Cover

E. Door Spindle

F. Lower Hinge Hole Cover

1

2

3

4

5

CLEANING

Ensure the appliance is unplugged before cleaning.

• To clean the inside of the appliance, use a soft

cloth and a solution of a tablespoon of baking

soda to one quart of water or a mild soap

solution or some mild detergent.

• Wash removable shelves in a mild detergent

solution, then dry and wipe with a soft cloth.

• Clean the outside with a soft, damp cloth and

some mild detergent.

• It is important to keep the area clean where the

door seals against the cabinet. Clean this area

with a soapy cloth. Rinse with a damp cloth and

let dry.

Note: Do not use cleaners containing ammonia or

alcohol on the appliance. Ammonia or alcohol can

damage the appearance of the appliance. Never

use any commercial or abrasive cleaners or sharp

objects on any part of the appliance.

POWER FAILURE

Most power failures are corrected within a few

hours and should not affect the temperature of your

appliance if you minimize the number of times the

door is opened. If the power is going to be off for

a longer period of time, take the proper steps to

protect your contents.

Note: Wait 3 to 5 minutes before attempting

to restart the refrigerator if operation has been

interrupted.

CARE & MAINTENANCE

VACATION

• Short vacations: Leave the appliance operating

during vacations of less than three weeks.

• Long vacations: If the appliance will not be used

for several months, remove all items and turn

off the appliance. Clean and dry the interior

thoroughly. To prevent odor and mold growth,

leave the door open slightly, blocking it open if

necessary.

MOVING

• Make sure the appliance is empty.

• Secure the shelves with tape.

• Secure the door with tape.

• Turn the adjustable foot up to the base to avoid

damage.

• Protect the outside of the appliance with a

blanket or similar item.

• Be sure the appliance stays in the upright

position during transportation.

• If the appliance is placed on its back or side

during transportation, upon reaching the

destination, allow it to remain upright for 6

hours before plugging in to avoid damage to

internal components.

DISPOSAL

This marking indicates that this product should

not be disposed with other household wastes

throughout the EU. To prevent possible harm to the

environment or human health from uncontrolled

waste disposal, recycle it responsibly to promote

the sustainable reuse of material resources. To

return your used device, please use the return and

collection systems or contact the retailer where the

product was purchased. They can take this product

for environmental safe recycling.

5

Consumer Helpline: 0300 303 3904

PROBLEM POSSIBLE CAUSE

No power • A fuse may be blown or the circuit breaker

tripped

• Plug not fully inserted into the wall outlet

Internal temperature not cold enough • Temperature setting is too warm

• Door is not shut properly or opened excessively

• Recently added a large quantity of warm food

to the cabinet

• Close proximity to heat source or direct sunlight

• Ambient temperature or humidity is very high

Appliance runs continuously • Temperature setting is too cold

• Door not shut properly or opened excessively

• Recently added a large quantity of warm food

to the cabinet

• Close proximity to heat source or direct sunlight

• Ambient temperature or humidity is very high

TROUBLESHOOTING

6

Danby Consumer Care

Phone: 0300 303 3904

Email: danby@ukwarranty.com

Appliance warranty registration: https://danby.warrantyonline.co.uk

Information in this manual is subject to change without notice.

Consumer Helpline: 0300 303 3904

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First Year

During the rst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s

option, at no charge to the ORIGINAL purchaser.

To obtain

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any app liance

Service

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at

their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Serv ice” below.

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

must be performed by a qualied service technician.

If service is performed on the units by anyone other than an authorized service depot, or the unit is used for commercial appli cation, all

obligations of Danby under this warranty shall be void.

Boundaries of

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

In Home Service

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualied and certif ied for

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t he

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c ontents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m ade or intended by Danby or its

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio ns, representations or guarantees

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no t be responsible for any damages

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o f the unit and by the purchase of

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert y caused by the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con ditions

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, oods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out door application).

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

AUTHORIZED SERVICE DEPOT.

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

04/09

1-800-263-2629

Warranty Service

In-home

WARRANTY

Congratulations on the purchase of your new Danby product.

This appliance comes with a 2 year warranty.

Please call 0300-303-3904 to register your product and receive full

terms and conditions.

This quality product is warranted to be free from manufacturer’s defects in material and

workmanship, provided that the unit is used under the normal operating conditions intended

by the manufacturer. This warranty is available only to the person to whom the unit was

originally sold by a Danby Products authorized dealer.

TERMS OF WARRANTY

During the ﬁrst twenty-four (24) months, any functional parts of this product found to be

defective will be repaired or replaced, at warrantor’s option, at no charge to the original

purchaser.

EXCLUSIONS

Save as herein provided, by Danby, there are no other warranties, conditions, representations

or guarantees, express or implied, made or intended by Danby or its authorized distributors

and all other warranties, conditions, representations or guarantees, including any warranties,

conditions, representations or guarantees under any Sale of Goods Act or like legislation or

statute is hereby expressly excluded. Save as herein provided, Danby shall not be responsible

for any damages to persons or property, including the unit itself, howsoever caused or any

consequential damages arising from the malfunction of the unit and by the purchase of the

unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim

for damages to persons or property caused by the unit.

There are no express warranties other than those on the face here of and described above.

No warranties whether expressed or implied, including but not limited to, any implied

warranties of merchantability or ﬁtness for a particular purpose, shall extend beyond the

respective warranty periods provided above. This warranty does not affect the consumer’s

legal rights under applicable National legislation.

Service administered by UK Warranty Limited

Paciﬁca House, Rainton Business Park

Houghton Le Spring, England, DH4 5RA

danby.warrantyonline.co.uk

0300-303-3904

08/18

NOTES:

__________________________________________________________________________________________

NOTES:

__________________________________________________________________________________________

NOTES:

__________________________________________________________________________________________

MODEL

Printed in China

Distributed by Exertis (UK) Ltd.

Technology House, Magnesium Way, Hampton, Burnley, England, BB12 7BF

DCR032KA1WDB

DCR032KA1BDB

Danby DCR032KA1WDB 91 litre Compact Refrigerator

Product's Documents

User Manual

Specifications

Danby DCR032KA1WDB Questions and Answers
