ENG This user manual includes detailed usage instructions
for your camera. Please read this manual thoroughly.
USER
MANUAL
1
Copyright information
•
Camera specications or contents of this manual may be changed
without prior notice due to upgrade of camera functions.
•
You are not allowed to reuse or distribute any part of this manual
without prior permission.
•
We recommend using your camera within the country where you
purchase it.
•
Use this camera responsibly and adhere to all laws and regulations
concerning its use.
PlanetFirst represents Samsung Electronics' commitment to
sustainable development and social responsibility through
eco-driven business and management activities.
•
Microsoft Windows and the Windows logo are registered trademarks of
the Microsoft Corporation.
•
Mac and Apple App Store are registered trademarks of the Apple
Corporation.
•
Google Play Store is a registered trademark of Google, Inc.
•
Adobe, the Adobe logo, Photoshop and Lightroom are either registered
trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries.
•
microSD™, microSDHC™, and microSDXC™ are registered trademarks of
the SD Association.
•
HDMI, the HDMI logo, and the term “High
Denition Multimedia Interface” are
trademarks or registered trademarks of HDMI
Licensing LLC.
•
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered
trademarks of the Wi-Fi Alliance.
•
Trademarks and trade names used in this manual are the property of
their respective owners.
2
Health and safety information
Prevent damage to subjects’ eyesight.
Do not use the ash in close proximity (closer than 1 m/3 ft) to people or
animals. If you use the ash too close to your subject’s eyes, this can cause
temporary or permanent eyesight damage.
Keep your camera away from small children and pets.
Keep your camera and all accessories out of the reach of small children
and animals. Small parts may cause choking or serious injury if swallowed.
Moving parts and accessories may present physical dangers as well.
Do not expose the camera to direct sunlight or high
temperatures for an extended period of time.
Prolonged exposure to sunlight or extreme temperatures can cause
permanent damage to your camera’s internal components.
Avoid covering the camera with blankets or clothes.
The camera may overheat, which may distort the camera or cause a re.
Do not handle the power supply cable or go near the charger
during a thunderstorm.
This may result in electric shock.
Always comply with the following precautions and usage tips to avoid
dangerous situations and ensure peak performance of your camera.
Warning—situations that could cause injury to yourself
or others
Do not disassemble or attempt to repair your camera.
This may result in electric shock or damage to the camera.
Do not use your camera near ammable or explosive gases
and liquids.
This may cause a re or explosion.
Do not insert ammable materials into the camera or store
these materials near the camera.
This may cause a re or electric shock.
Do not handle your camera with wet hands.
This may result in electric shock.
3
Health and safety information
If liquid or foreign objects enter your camera, immediately
disconnect all power sources, such as the battery or AC adapter,
and then contact a Samsung service center.
Comply with any regulations that restrict the use of a camera in
a certain area.
•
Avoid interference with other electronic devices.
•
Turn o the camera when in an aircraft. Your camera can cause
interference with aircraft equipment. Follow all airline regulations and
turn o your camera when directed by airline personnel.
•
Turn o the camera near medical equipment. Your camera can interfere
with medical equipment in hospitals or health care facilities. Follow all
regulations, posted warnings, and directions from medical personnel.
Avoid interference with pacemakers.
Maintain the distance between this camera and all pacemakers to avoid
potential interference, as recommended by the manufacturer and research
groups. If you have any reason to suspect that your camera is interfering
with a pacemaker or other medical device, turn o the camera immediately
and contact the manufacturer of the pacemaker or medical device for
guidance.
Caution—situations that could cause damage to your
camera or other equipment
Remove the batteries from your camera when storing it for an
extended period of time.
Installed batteries may leak or corrode over time and cause serious
damage to your camera.
Use only authentic, manufacturer-recommended,
Lithium-ion replacement batteries. Do not damage or heat the
battery.
Inauthentic, damaged, or heated batteries may cause a re or personal
injury.
Use only Samsung-approved batteries, chargers, cables and
accessories.
•
Using unauthorized batteries, chargers, cables or accessories can cause
batteries to explode, damage your camera, or cause injury.
•
Samsung is not responsible for damage or injuries caused by
unapproved batteries, chargers, cables or accessories.
Use the battery only for its intended purpose.
Misusing the battery may cause a re or electric shock.
4
Health and safety information
Do not touch the ash while it res.
The ash is very hot when red and may burn your skin.
When you use the AC adapter, turn o the camera before you
disconnect the power to the AC adapter.
Failing to do so may result in re or electric shock.
Disconnect the AC adapter from the wall socket when not in
use.
Failing to do so may result in re or electric shock.
Do not use a damaged power supply cable, AC adapter, or
loose outlet when you charge batteries.
This may cause a re or electric shock.
Do not allow the AC adapter to come in contact with the +/-
terminals on the battery.
This may cause a re or electric shock.
Do not drop or subject the camera to strong impacts.
Doing so may damage the screen or external or internal components.
Exercise caution when you connect cables and install batteries
and memory cards.
If you force the connectors, improperly connect cables, or improperly
install batteries and memory cards, you can damage ports, connectors,
and accessories.
Keep cards with magnetic strips away from the camera case.
Information stored on the card may be damaged or erased.
Never use a damaged battery, or memory card.
This may result in electric shock or camera malfunction or cause a re.
Do not place the camera in or near magnetic elds.
Doing so may cause the camera to malfunction.
Do not use the camera if the screen is damaged.
If the glass or acrylic parts are broken, visit a Samsung service center to
have the camera repaired.
5
Health and safety information
Check that the camera is operating properly before use.
The manufacturer takes no responsibility for any loss of les or damage
that may result from camera malfunction or improper use.
You must plug the small end of the USB cable into your
camera.
If the cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
Do not expose the lens to direct sunlight.
This may discolor the image sensor or cause it to malfunction.
If the camera overheats, remove the battery and allow it to
cool down.
•
Prolonged usage of the camera may overheat the battery and raise
the internal temperature of the camera. If the camera stops operating,
remove the battery and allow it to cool down.
•
High internal temperatures may result in noise in your photos. This is
normal and does not aect your camera’s overall performance.
Avoid interference with other electronic devices.
Your camera emits radio frequency (RF) signals that may interfere
with unshielded or improperly shielded electronic equipment, such as
pacemakers, hearing aids, medical devices, and other electronic devices in
homes or vehicles. Consult the manufacturers of your electronic devices
to solve any interference problems you experience. To prevent unwanted
interference, use only Samsung-approved devices or accessories.
Use your camera in the normal position.
Avoid contact with your camera’s internal antenna.
Data transference and your responsibilities
•
Data transferred via WLAN could be leaked, so avoid transferring
sensitive data in public areas or on open networks.
•
The camera manufacturer is not liable for any data transfers that infringe
on copyrights, trademarks, intellectual property laws, or public decency
ordinances.
6
Icons used in this manual
Icon Function
Additional information
Safety warnings and precautions
[ ]
Camera buttons. For example, [Shutter] represents the shutter
button.
( )
Page number of related information
→
The order of options or menus you must select to perform a step;
for example: Touch 1
→ Quality (represents touch 1, and
then touch Quality).
*
Annotation
7
Contents
Chapter 1
My Camera
Getting started ............................................................................................ 28
Unpacking.................................................................................................................... 28
Camera layout .............................................................................................. 29
Using the DIRECT LINK button ................................................................................ 31
Using the command dial ........................................................................................... 32
Inserting the battery and memory card ................................................. 33
Removing the battery and memory card ........................................................... 33
Charging the battery and turning on your camera .............................. 34
Charging the battery................................................................................................ 34
Turning on your camera ......................................................................................... 34
Performing the initial setup ...................................................................... 35
Selecting a mode ......................................................................................... 36
Accessing a Mode screen ....................................................................................... 36
Mode description ...................................................................................................... 36
Rearranging icons ..................................................................................................... 37
Selecting functions (options) ................................................................... 38
Using m .............................................................................................................. 38
Using the Smart panel ............................................................................................. 39
Using the touch screen .............................................................................................. 40
Tips
Concepts in Photography
Shooting postures....................................................................................... 13
Holding the camera ..................................................................................................... 13
Standing photography ............................................................................................... 14
Crouching photography ............................................................................................ 14
Aperture ........................................................................................................ 15
Aperture value and the depth of eld .................................................................. 16
Shutter speed ............................................................................................... 17
ISO sensitivity .............................................................................................. 18
How the aperture setting, shutter speed, and ISO sensitivity
control exposure ......................................................................................... 19
Correlation between focal length, angle, and perspective ................ 20
Depth of eld ............................................................................................... 21
What controls out-of-focus eects? ....................................................................... 21
Optical preview ............................................................................................................. 23
Composition ................................................................................................. 23
Rule of Thirds .................................................................................................................. 23
Photos with two subjects .......................................................................................... 24
Flash ............................................................................................................... 25
Flash guide number ..................................................................................................... 25
Bounce Photography .................................................................................................. 26
8
Contents
Display icons ................................................................................................ 41
In Shooting mode ..................................................................................................... 41
Capturing photos ........................................................................................................ 41
Recording videos ......................................................................................................... 42
About the level gauge ............................................................................................... 42
In Playback mode ...................................................................................................... 43
Viewing photos ............................................................................................................ 43
Playing videos ............................................................................................................... 43
Changing the information displayed ................................................................. 44
Lenses ............................................................................................................ 45
Lens layout ................................................................................................................... 45
Locking or unlocking the lens ................................................................................. 46
Lens markings ............................................................................................................ 49
Accessories ................................................................................................... 50
External ash layout ................................................................................................. 50
Connecting the external ash ................................................................................. 51
GPS module layout (optional) .............................................................................. 53
Attaching the GPS module .................................................................................... 53
Shooting modes .......................................................................................... 55
Auto mode ................................................................................................................... 55
Smart mode................................................................................................................. 57
Using the Best Face mode ........................................................................................ 58
Capturing panoramic photos .................................................................................. 59
Program mode ........................................................................................................... 61
Program Shift ................................................................................................................ 61
Aperture Priority mode ........................................................................................... 62
Shutter Priority mode .............................................................................................. 63
Manual mode.............................................................................................................. 64
Using the Bulb function ............................................................................................ 64
Custom mode ............................................................................................................. 65
Saving a custom mode .............................................................................................. 65
Selecting a custom mode ......................................................................................... 65
Recording a video ..................................................................................................... 66
Using i-Function ........................................................................................................ 67
Using Z ............................................................................................................... 69
3D mode ....................................................................................................................... 70
Available functions by shooting mode ............................................................. 71
9
Contents
Chapter 2
Shooting Functions
Size and Resolution .................................................................................... 74
Photo size ..................................................................................................................... 74
Quality ........................................................................................................................... 75
ISO sensitivity .............................................................................................. 76
White Balance .............................................................................................. 77
Customizing preset White Balance options ....................................................... 78
Picture Wizard (photo styles) .................................................................... 80
Smart Filter ................................................................................................... 81
AF mode ........................................................................................................ 82
Single AF ....................................................................................................................... 83
Continuous AF ............................................................................................................ 83
Manual focus ............................................................................................................... 84
AF area ........................................................................................................... 85
Selection AF ................................................................................................................ 85
Multi AF ......................................................................................................................... 86
Face detection AF ...................................................................................................... 86
Self-Portrait AF ........................................................................................................... 87
Touch AF ........................................................................................................ 88
Touch AF ....................................................................................................................... 88
Tracking AF .................................................................................................................. 88
One touch shot .......................................................................................................... 89
Focus assist ................................................................................................... 90
MF Assist ....................................................................................................................... 90
Focus Peaking ............................................................................................................. 90
Measuring the exposure value of the focus area ........................................ 91
Framing mode ............................................................................................. 92
Optical Image Stabilization (OIS) ............................................................. 93
Drive (shooting method) ........................................................................... 94
Single ............................................................................................................................. 94
Continuous .................................................................................................................. 94
Burst ............................................................................................................................... 95
Timer .............................................................................................................................. 95
Auto Exposure Bracketing (AE Bracket) ............................................................. 96
White Balance Bracketing (WB Bracket) ............................................................ 96
Picture Wizard Bracketing (P Wiz Bracket) ........................................................ 97
Metering ........................................................................................................ 98
Multi ............................................................................................................................... 98
Spot ................................................................................................................................ 99
Center-weighted ....................................................................................................... 99
Dynamic Range ......................................................................................... 100
Flash ............................................................................................................. 101
Reducing the red-eye eect ............................................................................... 102
Adjusting the ash intensity .............................................................................. 102
Exposure compensation .......................................................................... 104
Exposure lock ............................................................................................. 105
Video functions ......................................................................................... 106
Movie size.................................................................................................................. 106
Movie quality ........................................................................................................... 106
Multi Motion ............................................................................................................ 107
Fader ........................................................................................................................... 107
Voice ............................................................................................................................ 108
Wind cut .................................................................................................................... 108
10
Contents
Chapter 3
Playback/Editing
Searching and managing les ................................................................ 110
Viewing photos ....................................................................................................... 110
Viewing image thumbnails ................................................................................. 110
Viewing les by category .................................................................................... 111
Viewing les as a folder ........................................................................................ 111
Protecting les ........................................................................................................ 112
Lock/Unlock all les .................................................................................................. 112
Deleting les ............................................................................................................ 113
Deleting a single le ................................................................................................. 113
Deleting multiple les .............................................................................................. 113
Deleting all les .......................................................................................................... 113
Viewing photos .......................................................................................... 114
Enlarging a photo .................................................................................................. 114
Viewing a slide show ............................................................................................. 114
Auto rotating ........................................................................................................... 115
Creating a print order (DPOF) ............................................................................ 115
Playing videos ............................................................................................ 116
Trimming a video during playback .................................................................. 116
Capturing an image during playback ............................................................. 117
Editing photos ........................................................................................... 118
Cropping a photo ................................................................................................... 118
Rotating a photo .................................................................................................... 119
Resizing photos....................................................................................................... 119
Adjusting your photos .......................................................................................... 120
Retouching faces .................................................................................................... 121
Reducing red-eye ................................................................................................... 121
Applying Smart Filter eects .............................................................................. 122
Chapter 4
Wireless network
Connecting to a WLAN and conguring network settings ............... 124
Connecting to a WLAN ......................................................................................... 124
Setting network options ......................................................................................... 125
Manually setting the IP address ........................................................................... 125
Using the login browser....................................................................................... 125
Network connection tips ..................................................................................... 126
Entering text ............................................................................................................ 127
Saving les to a smart phone automatically ....................................... 128
Sending photos or videos to a smart phone ....................................... 129
Using a smart phone as a remote shutter release .............................. 131
Using Auto Backup to send photos or videos ..................................... 133
Installing the program for Auto Backup on your PC.................................. 133
Sending photos or videos to a PC .................................................................... 133
Sending photos or videos via email ...................................................... 135
Changing email settings ...................................................................................... 135
Storing your information ........................................................................................ 135
Setting an email password ..................................................................................... 136
Changing the email password .............................................................................. 137
Sending photos or videos via email ................................................................ 137
Using photo or video sharing websites ................................................ 139
Accessing a website .............................................................................................. 139
Uploading photos or videos............................................................................... 140
Using Samsung Link to send les .......................................................... 141
Uploading photos to online storage ............................................................... 141
Viewing photos or videos on devices that support Samsung Link ...... 142
Sending photos using Wi-Fi Direct ........................................................ 144
11
Contents
Chapter 6
Connecting to external devices
Viewing les on an HDTV or 3D TV ........................................................ 158
Viewing les on an HDTV .................................................................................... 158
Viewing les on a 3D TV ....................................................................................... 159
Transferring les to your computer ....................................................... 160
Transferring les to your Windows OS computer ....................................... 160
Connecting the camera as a removable disk ................................................... 160
Disconnecting the camera (for Windows XP) .................................................. 161
Transferring les to your Mac OS ...................................................................... 161
Using programs on a computer ............................................................. 163
Installing programs from the provided CD ................................................... 163
Available programs when using i-Launcher .................................................... 163
Using i-Launcher .................................................................................................... 163
Requirements for Windows OS ............................................................................. 163
Requirements for Mac OS ....................................................................................... 164
Opening i-Launcher .................................................................................................. 164
Using Multimedia Viewer ........................................................................................ 165
Downloading the rmware .................................................................................... 166
Downloading the PC Auto Backup program ................................................... 166
Installing Adobe Photoshop Lightroom ........................................................ 167
Using Adobe Photoshop Lightroom ............................................................... 167
Chapter 5
Camera settings menu
User settings ............................................................................................... 146
ISO Customizing ..................................................................................................... 146
ISO Step ......................................................................................................................... 146
Auto ISO Range .......................................................................................................... 146
Noise Reduction ..................................................................................................... 146
Bracket Set ................................................................................................................ 147
DMF (Direct Manual Focus) ................................................................................ 147
Color space ............................................................................................................... 148
Distortion Correct .................................................................................................. 149
Save as Custom Mode .......................................................................................... 149
iFn Customizing ...................................................................................................... 149
User Display .............................................................................................................. 149
Key Mapping ............................................................................................................ 150
Grid Line .................................................................................................................... 151
AF Lamp ..................................................................................................................... 151
Setting ......................................................................................................... 152
12
Contents
Before contacting a service center ........................................................ 181
Camera specications .............................................................................. 184
Glossary ....................................................................................................... 189
Optional accessories ................................................................................. 195
Index ............................................................................................................ 197
FCC notice ................................................................................................... 200
Chapter 7
Appendix
Error messages .......................................................................................... 169
Maintaining the camera........................................................................... 170
Cleaning the camera ............................................................................................. 170
Camera lens and display ......................................................................................... 170
Image sensor ............................................................................................................... 170
Camera body ............................................................................................................... 170
Using or storing the camera ............................................................................... 171
Inappropriate places to use or store the camera ........................................... 171
Using on beaches or shores ................................................................................... 171
Storing for extended period of time ................................................................... 171
Using the camera with caution in humid environments ............................ 172
Other cautions ............................................................................................................ 172
About memory card .............................................................................................. 173
Supported memory card ........................................................................................ 173
Memory card capacity ............................................................................................. 174
Cautions when using memory cards .................................................................. 176
About the battery .................................................................................................. 177
Battery specications ............................................................................................... 177
Battery life .................................................................................................................... 178
Low battery message ............................................................................................... 178
Notes about using the battery .............................................................................. 178
Cautions about using the battery ........................................................................ 179
Notes about charging the battery ....................................................................... 179
Notes about charging with a computer connected...................................... 180
Handle and dispose of batteries and chargers with care ............................ 180
13
Concepts in Photography
Holding the camera
Hold the camera with your right hand and place you right index nger on
the shutter button. Place your left hand under the lens for support.
Shooting postures
A correct posture for stabilizing the camera is necessary for taking a good
photo. Even if you hold a camera correctly, the wrong posture can cause
the camera to shake. Stand up straight and remain still to maintain a
steady base for your camera. When shooting with a slow shutter speed,
hold your breath to minimize body movement.
14
Concepts in Photography
Standing photography
Compose your shot; stand up straight with your feet shoulder-length
apart, and keep your elbows pointed down.
Crouching photography
Compose your shot, crouch with one knee touching the ground, and keep
a straight posture.
15
Concepts in Photography
Aperture
The aperture, a hole that controls the amount of light that enters the
camera, is one of the three factors that determine the exposure. The
aperture housing contains thin, metal plates that open and close to let
light through the aperture and into the camera. The size of the aperture
is closely related to the brightness of a photo: the larger the aperture, the
brighter the photo; the smaller the aperture, the darker the photo.
Aperture sizes
Minimum aperture Medium aperture Maximum aperture
Darker photo
(aperture opened slightly)
Brighter photo
(aperture opened wide)
The size of the aperture is represented by a value known as an “F-number.”
The f-number represents the focal length divided by the diameter of the
lens. For example, if a lens with a 50 mm focal length has an f-number of
F2, the diameter of the aperture is 25 mm. (50 mm/25 mm=F2) The smaller
the f-number, the greater the size of the aperture.
The opening in the aperture is described as the Exposure Value (EV).
Increasing the Exposure Value (+1 EV) means the amount of light doubles.
Decreasing the Exposure Value (-1 EV) means the amount of light halves.
You can also use the exposure compensation feature to ne-tune the
amount of light by subdividing exposure values into 1/2, 1/3 EV, and so on.
+1 EV
F1.4 F2 F2.8 F4 F5.6 F8
-1 EV
Exposure Value Steps
16
Concepts in Photography
Aperture value and the depth of eld
You can blur or sharpen the background of a photo by controlling the
aperture. It is closely related to the depth of eld (DOF), which can be
expressed as small or large.
A photo with a large DOF A photo with a small DOF
The aperture housing contains several blades. These blades move together and
control the amount of light passing through the center of the aperture. The
number of blades also aects the shape of light when shooting night scenes. If
an aperture has an even number of blades, light divides into an equal number
of sections. If the number of blades is odd, the number of sections is double the
number of blades.
For example, an aperture with 8 blades divides light into 8 sections and an
aperture with 7 blades into 14 sections.
7 blades 8 blades
17
Concepts in Photography
Shutter speed
Shutter speed refers to the amount of time it takes to open and close the
shutter, and it is an important factor in the brightness of a photo, as it
controls the amount of light which passes through the aperture before it
reaches the image sensor.
Usually, the shutter speed is manually adjustable. The measurement of the
shutter speed is known as the “Exposure Value” (EV), which is marked in
intervals of 1 s, 1/2 s, 1/4 s, 1/8 s, 1/15 s, 1/1000 s, 1/2000 s, and so on.
Exposure
+1 EV
-1 EV
1s 1/2 s 1/4 s 1/8 s 1/15 s 1/30 s
Shutter Speed
Therefore, the faster the shutter speed, the less light will be let in. Likewise,
the slower the shutter speed, the more light will be let in.
As the photos below illustrate, a slow shutter speed allows more time
to let light in, so the photo becomes brighter. On the other hand, a fast
shutter speed allows less time to let light in and the photo becomes
darker and more easily freezes subjects in motion.
0.8 s 0.004 s
18
Concepts in Photography
ISO sensitivity
The exposure of an image is determined by the sensitivity of the camera.
This sensitivity is based on international lm standards, known as ISO
standards. On digital cameras, this sensitivity rating is used to represent
the sensitivity of the digital mechanism that captures the image.
ISO sensitivity doubles as the number doubles. For example, an
ISO 200 setting is capable of capturing images at twice the speed of an
ISO 100 setting. However, higher ISO settings can result in “noise”—small
specks, spots, and other phenomena in a photo that give the shot a noisy
or dirty appearance. As a general rule, it is best to use a low ISO setting
to prevent noise in your photos, unless you are shooting in darkened
environments or at night.
Changes in the quality and brightness according to ISO sensitivity
Because a low ISO sensitivity means the camera will be less sensitive to
light, you need more light to have an optimal exposure. When using a low
ISO sensitivity, open the aperture more or reduce the shutter speed to
allow more light to enter the camera. For example, on a sunny day when
light is abundant, a low ISO sensitivity does not require a slow shutter
speed. However, in a dark place or at night, a low ISO sensitivity will
result in a blurry photo. Therefore, it is recommended to increase the ISO
sensitivity by a moderate amount.
A photo captured with a tripod and
high ISO sensitivity
A blurred photo with a low ISO sensitivity
19
Concepts in Photography
How the aperture setting, shutter speed,
and ISO sensitivity control exposure
The aperture setting, shutter speed, and ISO sensitivity are closely
interconnected in photography. The aperture setting controls the opening
that regulates the light that enters the camera, while the shutter speed
determines the length of time that light is allowed to enter. ISO sensitivity
determines the speed at which the lm reacts to light. Together, these
three aspects are described as the triangle of exposure.
A change in shutter speed, aperture value, or ISO sensitivity can be oset
by adjustments to the others to maintain the amount of light. The results,
however, change according to the settings. For example, shutter speed is
useful in expressing movement, aperture can control the depth of eld,
and ISO sensitivity can control the graininess of a photo.
Settings Results
Aperture
value
Wide aperture
= more light
Narrow aperture
= less light
Wide = small depth of eld
Narrow = large depth of eld
Settings Results
Shutter speed
Fast speed
= less light
Slow speed
= more light
Fast = still
Slow = blurry
ISO sensitivity
High sensitivity
= more sensitive to light
Low sensitivity
= less sensitive to light
High = more grainy
Low = less grainy
20
Concepts in Photography
Correlation between focal length, angle,
and perspective
Focal length, which is measured in millimeters, is the distance between
the middle of the lens to its focal point. It aects the angle and perspective
of captured images. A short focal length translates into a wide angle,
which allows you to capture a wide shot. A long focal length translates
into a narrow angle, which allows you to capture telephoto shots.
Short focal length
wide shot
wide angle
wide-angle lens
Long focal length
telephoto shot
narrow angle
telephoto lens
Look at these photos below and compare the changes.
20 mm angle 50 mm angle 200 mm angle
Normally, a lens with a wide angle is suitable for shooting landscapes and a lens
with a narrow angle is recommended for shooting sports events or portraits.
21
Concepts in Photography
Depth of eld
Portraits or still-life photos mostly acclaimed by people are the ones on
which the background is out of focus so the subject looks pronounced.
Depending on the focused areas, a photo can be blurred or sharpened.
This is called ‘a low DOF’ or ‘a high DOF’.
The depth of eld is the focused area around the subject. Therefore, a
small DOF signies that the focused area is narrow and a large DOF means
the focused area is wide.
A photo with a small DOF, which stresses the subject and makes the rest
of it blurred, can be obtained by using a telescope lens or selecting a low
aperture value. Conversely, a photo with a large DOF which shows all the
elements on the photo sharply focused can be achieved by using a wide
angle lens or selecting a high aperture value.
Small Depth of Field Large Depth of Field
What controls out-of-focus eects?
DOF depends on aperture value
The wider the aperture is (namely the lower the aperture value), the lower
the DOF becomes. Under the condition where the other values including
shutter speed and ISO sensitivity are equal, a low aperture value leads to a
photo with a low DOF.
50 mm F5.7 50 mm F22
22
Concepts in Photography
DOF depends on focal length
The longer the focal length is, the lower the DOF gets. A telescope lens
with a longer focal length than a telescope lens with a short focal length is
better to capture a photo of a low DOF.
A photo captured with a 20 mm
telescope lens
A photo captured with a 100 mm telescope
lens
DOF depends on the distance between the subject and the
camera
The shorter the distance between the subject and the camera is, the lower
the DOF gets. Therefore, taking a photo close to a subject can result in a
photo of low DOF.
A photo captured with a 100 mm telescope lens
A photo captured close to the subject
23
Concepts in Photography
Optical preview
You can touch the Custom button on the screen to view the optical
preview before capturing a photo. The camera adjusts the aperture to the
predened settings and shows the results on the screen. Set the Custom
button to Optical Preview. (p. 150)
F
Composition
It is fun to capture a photo of the beauty of world with a camera. No
matter how the world is beautiful, however, a poor composition cannot
capture the beauty of it.
When it comes to composition, it is very important to prioritize subjects.
Composition in photography means arranging objects in a photo. Usually,
abiding by the rule of thirds leads to a good composition.
Rule of Thirds
To use the rule of thirds, divide the image into a 3x3 pattern of equal
rectangles.
To compose photos that best emphasize the subject, make sure the
subject is located at one of the corners of the center rectangle.
24
Concepts in Photography
Using the rule of thirds will create photos with stable and compelling
compositions. Below are a few examples.
Photos with two subjects
If your subject is in one corner of the photo, it creates an unbalanced
composition. You can stabilize the photo by capturing a second subject in
the opposite corner to balance the weight of the photo.
Subject 1
Subject 2
Subject 1
Subject 2
Unstable Stable
When taking landscape photos, centering the horizon will create an
unbalanced eect. Give more weight to the photo by moving the horizon
up or down.
Subject 1
Subject 2
Subject 1
Subject 2
Unstable Stable
25
Concepts in Photography
Flash
Light is one of the most important components in photography. It’s not
easy, however, to have an enough amount of light anytime and anywhere.
Making use of a ash allows you to optimize light settings and create a
variety of eects.
Flash, also known as strobe or speed light, helps to create adequate
exposure in low-light conditions. It is also useful in light-abundant
situations. For example, ash can be used in compensating the exposure
of a subject’s shadow or capturing clearly both the subject and the
background in backlit conditions.
Before correction After correction
Flash guide number
The model number of a ash refers to the ash’s power, and the maximum
amount of light created is represented by a value known as a “guide
number.” The bigger the guide number, the more light is emitted from the
ash. The guide number is achieved by multiplying the distance from the
ash to the subject and the aperture value when the ISO sensitivity is set
to 100.
Guide number = Flash to Subject Distance X Aperture value
Aperture value = Guide number / Flash to Subject Distance
Flash to Subject Distance = Guide number / Aperture value
Therefore, if you know the guide number of a ash, you can estimate an
optimum ash to subject distance when setting the ash manually. For
example, if a ash has a guide number of GN 20 and is 4 meters away from
the subject, the optimal aperture value is F5.0.
26
Concepts in Photography
Bounce Photography
Bounce photography refers to the method of bouncing light o of the
ceiling or walls so that the light spreads evenly over the subject. Normally,
photos captured with ash may appear unnatural and cast shadows.
Subjects in photos captured with bounce photography cast no shadows
and look smooth due to evenly spread light.
Chapter 1
My Camera
Learn about your camera’s layout, display icons, lens, optional accessories,
and basic functions.
My Camera
28
Getting started
Unpacking
Check your product box for the following items.
Camera
(including the body cap and hot-shoe
cover)
AC adapter/USB cable Rechargeable battery External ash
Software CD-ROM
(User manual included)
Adobe Photoshop Lightroom DVD-ROM Quick Start Guide Strap
•
The illustrations may dier from your actual items.
•
You can purchase optional accessories at a retailer or a Samsung service center. Samsung is not responsible for any
problems caused by using unauthorized accessories. For information about accessories, refer to page 195.
My Camera
29
Camera layout
No. Name
1
Command dial
• In the Smart panel: Move to a desired
option or adjust a selected option.
• In Shooting mode: Access a Mode
screen in Shooting mode or adjust
shutter speed, aperture value, or
exposure value in some shooting
modes.
• In Playback mode: View thumbnails
or enlarge/reduce a photo.
2
DIRECT LINK button: Start a preset Wi-Fi
function. (p. 31)
3
Internal antenna
* Avoid contact with the internal
antenna while using the wireless
network.
4
Microphone
5
Hot-shoe
6
Hot-shoe cover
7
Eyelet for camera strap
No. Name
8
Image sensor
9
Speaker
10
NFC tag
11
Lens release button
12
Lens mount
13
Lens mount index
14
AF-assist light/Timer lamp
15
Power switch
16
Shutter button
1
2
3
5
7
9
10
11
12
13
14
6
4
8
7
16
15
4
My Camera > Camera layout
30
No. Name
1
Video recording button
Start recording a video.
2
Status lamp
Indicate the status of the camera.
• Blinking: When saving a photo, shooting a video, sending data to a computer, connecting to
WLAN, or sending a photo.
• Steady: When there is no data transfer between the camera and a computer, or the battery is
charging.
3
Mode button
Access the Mode screen. (p. 36)
4
Playback button
Enter Playback mode.
5
USB and shutter release port
Connect the camera to a computer or shutter release. Use a shutter release cable with a tripod to
minimize camera movement.
6
HDMI port
7
Battery chamber/Memory card cover
Insert a memory card and battery.
8
Display
Touch the screen to select a menu or an option. (p. 38)
9
Tripod mount
1
2
3
4
8
9
5
6
7
My Camera > Camera layout
31
Setting the DIRECT LINK button
You can select a Wi-Fi function to launch when you press [DIRECT LINK].
(p. 150)
To set a DIRECT
LINK option,
In Shooting mode, touch
→
5
→
Key Mapping
→
DIRECT LINK
→
an option.
Using the DIRECT LINK button
You can turn on the Wi-Fi feature conveniently by pressing [DIRECT LINK].
Press [DIRECT LINK] again to return to the previous mode.
My Camera > Camera layout
32
Exposure value
Using the command dial
You can adjust options such as aperture value, shutter speed, or exposure
value with the command dial in some shooting modes. Press the
command dial, and then rotate it clockwise or anti-clockwise.
You can also adjust some options with the command dial in the Smart
panel. In the Smart panel, rotate the command dial to move to a desired
option, press the command dial to select it, and then rotate the command
dial to adjust the selected option.
E.g. Adjusting the exposure value in Program mode
To adjust the
exposure value,
On the Mode screen, touch Expert
→
Program
→
press the
command dial twice to select the exposure value
→
rotate the
command dial to adjust.
My Camera
33
Inserting the battery and memory card
Learn how to insert the battery and an optional memory card into the
camera.
Memory card
Insert a memory card with the gold-
colored contacts facing down.
Rechargeable battery
Insert the battery with the Samsung logo
facing up.
Removing the battery and memory card
Rechargeable battery
Battery lock
Slide the lock up to release the
battery.
Memory card
Push the card gently until it
disengages from the camera, and
then pull it out of the slot.
While the status lamp of the camera is blinking, do not remove the memory card
or battery. Doing so may damage the data stored on the memory card or your
camera.
My Camera
34
Charging the battery and turning on your camera
Charging the battery
Before you use the camera for the rst time, you must charge the battery.
Plug the small end of the USB cable into your camera, and then plug the
other end of the USB cable into the AC adapter.
Status lamp
• Red light on: Charging
• Red light o: Fully charged
• Red light blinking: Error
•
Use only the AC adapter and USB cable supplied with your camera. If you use
another AC adapter, the camera battery may not charge or work properly.
•
You can charge the battery with the USB cable only when the camera is turned
o.
Turning on your camera
Set the Power switch to ON.
•
To turn your camera o, set the Power switch to OFF.
•
The initial setup screen appears when you turn on the camera for the
rst time. (p. 35)
ON
OFF
My Camera
35
Performing the initial setup
When you turn on your camera for the rst time, the initial setup screen
appears. The language is preset for the country or region where the
camera is sold. You can change the language as desired.
1
Touch Time Zone.
2
Drag the option list up or down, and then touch a time zone.
Time Zone
[GMT +00:00] London
[GMT -01:00] Cape Verde
[GMT -02:00] Mid-Atlantic
[GMT -03:00] Buenos Aires, Sao Paulo
[GMT -03:30] Newfoundland
3
Touch Date & Time.
4
Touch the up or down arrows to set an option.
Date & Time
Year Month Day Hr Min DST
•
The screen may dier depending on the language selected.
5
Touch .
6
Touch Date Type
→
a date type.
7
Touch Time Type
→
a time type.
8
Touch to nish the initial setup.
My Camera
36
Selecting a mode
Select various modes and functions on the Mode screen.
Accessing a Mode screen
In Shooting or Playback mode, press [h]. Press [h] again to return to
the previous mode. You can also rotate the command dial to access a
Mode screen in Shooting mode.
Auto
Smart
Expert
Wi-Fi
Touch an icon to select a mode or function.
Mode description
Mode Description
Auto
Capture a photo with a scene mode selected automatically by
the camera. (p. 55)
Smart
Capture a photo with options that are preset for a specic
scene. (p. 57)
Expert
• Program: Capture a photo with settings you have adjusted
manually except the shutter speed and aperture value.
(p. 61)
• Aperture Priority: Set the aperture value manually while
the camera automatically selects an appropriate shutter
speed. (p. 62)
• Shutter Priority: Set the shutter speed manually while the
camera automatically selects an appropriate aperture value.
(p. 63)
• Manual: Adjust both the aperture value and the shutter
speed manually. (p. 64)
• Custom: Create your own shooting modes by adjusting
options and saving them. (p. 65)
My Camera > Selecting a mode
37
Rearranging icons
To change how icons appear on the sub-mode screen of Smart mode or
Expert mode, touch
(Grid View) or (List View) in the upper left corner
of the screen. If you selected List View, drag the option list up or down, or
rotate the mode dial on the screen, and then touch an icon.
<List View> <Grid View>
Mode Description
Wi-Fi
• MobileLink: Send photos or videos to a smart phone.
(p. 129)
• Remote Viewnder: Use a smart phone as a remote shutter
release and see a preview on your smart phone of an image
from your camera. (p. 131)
• Auto Backup: Send photos or videos that you captured
with the camera to a PC wirelessly. (p. 133)
• Email: Send photos or videos stored on the camera via
email. (p. 135)
• SNS & Cloud: Upload photos or videos to le sharing
websites. (p. 139)
• Samsung Link: Upload photos to Samsung Link online
storage or view les on other Samsung Link supported
devices. (p. 142)
My Camera
38
Selecting functions (options)
Select menus or options by gently touching an item on the screen with
your ngertip.
Using m
Touch on the screen, and then change shooting options or
settings.
E.g. Selecting the photo size in Program mode
1
On the Mode screen, touch Expert
→
Program.
2
Touch .
3
Touch 1
→
Photo Size.
AutoShare
Photo Size
Quality
ISO
White Balance
Picture Wizard
4
Drag the option list up or down, and then touch an option.
•
If you touch , a pop-up window with information on features and
settings will be displayed.
AutoShare
Photo Size
Quality
ISO
White Balance
Picture Wizard
5472x3648 (3:2)
3888x2592 (3:2)
2976x1984 (3:2)
1728x1152 (3:2)
5472x3080 (16:9)
Photo Size
5
Touch to switch to Shooting mode.
My Camera > Selecting functions (options)
39
Using the Smart panel
Touch on the screen to access some functions such as Exposure,
ISO, and White Balance.
E.g. Adjusting the exposure value in Program mode
1
On the Mode screen, touch Expert
→
Program.
2
Touch .
3
Touch EV.
•
You can also adjust some options by dragging the dial on the
screen with your nger. Alternatively, rotate the command dial to
move to a desired option, press the command dial to select it, and
then rotate the command dial to adjust the selected option.
EV : 0.0
4
Drag the dial on the screen, and then touch to adjust
the option.
•
You can also rotate the command dial to adjust the option. (p. 32)
EV : 0.0
My Camera > Selecting functions (options)
40
Using the touch screen
Do not use sharp objects, such as pens or pencils, to touch the screen. You can
damage the screen.
Touching: Touch an icon to select a menu or an option.
Dragging: Touch and hold an area on the screen, and then drag
your nger.
AutoShare
Photo Size
Quality
ISO
White Balance
Picture Wizard
Flicking: Gently ick your nger across the screen.
•
The touch screen may not recognize your inputs if you touch multiple items
at the same time.
•
When you touch or drag the screen, discolorations may occur. This is not a
malfunction, but a characteristic of the touch screen. Touch or drag lightly to
minimize the discolorations.
•
The touch screen may not work properly if you use the camera in extremely
humid environments.
•
The touch screen may not work properly if you apply screen protection lm
or other accessories to the screen.
•
Depending on the viewing angle, the screen may appear dim. Adjust the
brightness or viewing angle to improve the resolution.
My Camera
41
Display icons
Capturing photos
F
1
2
3
London
1. Shooting information
Icon Description
Shooting mode
Current date
Current time
GPS activated*
London
Location information*
Memory card not inserted**
Auto exposure lock (p. 105)
Available number of photos
• : Fully charged
• : Partially charged
• (Red): Empty (recharge
the battery)
Icon Description
Auto focus frame
Spot metering area
Camera shake
Manual focus scale
Level gauge (p. 42)
Histogram (p. 150)
Focus
Shutter speed
Aperture value
Exposure adjustment value
ISO sensitivity (p. 76)
* These icons appear when you attach an optional GPS
module.
** Photos that were captured without inserting a memory
card cannot be transferred to a memory card or a computer.
2. Shooting options
Icon Description
Photo size
RAW le
Drive mode
Flash (p. 101)
Flash intensity adjustment
Metering (p. 98)
AF mode (p. 82)
Icon Description
Focus area
Face detection
White Balance (p. 77)
White Balance micro adjustment
Optical Image Stabilization (OIS) (p. 93)
Dynamic Range (p. 100)
Z on
Z ratio
Smart Filter
3. Shooting options (Touch)
Icon Description
F
Custom button (p. 150)
Change Smart mode***
AutoShare
Touch AF options
Display type button
Shooting options
Smart panel
*** This icon appears only when you select Smart mode.
The icons displayed will change according to the
mode you select or the options you set.
In Shooting mode
My Camera > Display icons
42
2. Shooting options
Icon Description
Video size
AF mode (p. 82)
Metering (p. 98)
White Balance (p. 77)
Optical Image Stabilization (OIS)
(p. 93)
White Balance micro adjustment
Fader (p. 107)
Multi Motion (p. 107)
Voice recording o (p. 108)
The icons displayed will change according to the
mode you select or the options you set.
About the level gauge
The level gauge helps you align the camera with
the horizontal and vertical lines on the display.
If the level gauge is not level, calibrate the level
gauge using the Horizontal Calibration function.
(p. 152)
Vertical
Horizontal
▲ Level ▲ Unlevel
You cannot use the level gauge when you shoot
in portrait orientation.
Recording videos
1
2
1. Shooting information
Icon Description
Shooting mode
Current recording time/Available
recording time
• : Fully charged
•
: Partially charged
• (Red): Empty (recharge the
battery)
Cancel Touch AF
Pause or resume recording
Shutter speed
Aperture value
Exposure value
ISO sensitivity (p. 76)
My Camera > Display icons
43
In Playback mode
Viewing photos
London
Information
Mode
F No
Shutter
ISO
Metering
Flash
Focal Length
White Balance
EV
Photo Size
Date
Icon Description
Continuously captured le
Current le/The total number of les
Folder number - File number
File with location information
London
Location information
RAW le
Protected le
Print information added to le (p. 115)
3D le
Display type button
Playback/Editing menu
Delete les
Edit photos
Trim a video
View image thumbnails
1
2
3
London
No. Description
1
Captured photo
2
RGB histogram (p. 150)
3
Shooting mode, Metering, Flash,
White Balance, Aperture value,
Shutter speed, ISO, Focal length,
Exposure value, Photo size, Date,
Location information
Playing videos
Icon Description
Playback speed
Multi Motion
Current playback time
Video length
Capture an image
/
View previous le/Scan backward. (Each
time you touch the scan backward icon,
you change the scan speed in this order:
2X, 4X, 8X.)
/
Pause or resume playback.
Stop playback and return to the
previous screen.
/
View next le/Scan forward. (Each time
you touch the scan forward icon, you
change the scan speed in this order:
2X, 4X, 8X.)
Adjust the volume or mute the sound.
My Camera > Display icons
44
Changing the information displayed
Touch on the screen repeatedly to change the display type.
Mode Display type
Shooting
• Display shooting options at the right of the display,
Custom button, AutoShare button, Touch AF button,
Display type button and basic shooting information
(Shooting mode, Shutter speed, Aperture value, Exposure
value, ISO sensitivity, AEL).
• Display all information about shooting including
histogram, date, and time. (p. 150)
• Hide information about shooting except basic shooting
information, Custom button, and Display type button.
• Basic shooting information, Custom button, AutoShare
button, Touch AF button, Display type button, and the
level gauge.
Playback
• Basic information
• Display all information about the current le.
• Display all information about the current le including
RGB histogram.
My Camera
45
Lenses
You can purchase optional lenses made exclusively for your NX series
camera.
Learn about the functions of each lens and select one that suits your needs
and preferences.
Lens layout
SAMSUNG 20-50 mm F3.5-5.6 ED II lens (example)
7
1
2
3
5
6
4
No. Description
1
Lens mount index
2
Zoom lock switch
3
Lens
4
Focus ring (p. 90)
5
i-Function button (p. 67)
6
Zoom ring
7
Lens contacts
My Camera > Lenses
46
Locking or unlocking the lens
To lock the lens, pull and hold the zoom lock switch away from the camera
body and rotate the zoom ring as shown in the illustration.
To unlock the lens, rotate the zoom ring as shown in the illustation until
you hear the click.
You cannot capture a photo when the lens is locked.
My Camera > Lenses
47
SAMSUNG 18-55 mm F3.5-5.6 OIS III lens (example)
1
2
3
5
4
67
8
No. Description
1
Lens mount index
2
Zoom ring
3
Focus ring (p. 90)
4
Lens hood mount index
5
Lens
6
i-Function button (p. 67)
7
AF/MF switch (p. 82)
8
Lens contacts
When not using the lens, attach the lens cap and lens mount cover to protect
the lens from dust and scratches.
My Camera > Lenses
48
SAMSUNG 16 mm F2.4 lens (example)
5
2
1
4
3
No. Description
1
i-Function button (p. 67)
2
Lens mount index
3
Focus ring (p. 90)
4
Lens
5
Lens contacts
SAMSUNG 45 mm F1.8 [T6] 2D/3D (example)
6
2
1
3
4
5
No. Description
1
i-Function button (p. 67)
2
Lens mount index
3
Focus ring (p. 90)
4
Lens
5
2D/3D switch (p. 70)
6
Lens contacts
My Camera > Lenses
49
No. Description
1
Aperture value
A range of supported aperture values. For example, 1:3.5–6.3 means
the maximum aperture value range from 3.5 to 6.3.
2
Focal length
The distance from the middle of the lens to its focal point (in
millimeters). This gure is expressed in a range: minimum focal length
to maximum focal length of the lens.
Longer focal lengths result in narrower angles of view and the subject
is magnied. Shorter focal lengths result in wider angles of view.
3
ED
ED stands for Extra-low Dispersion. Extra-low dispersion glass is
eective in minimizing chromatic aberration (a distortion that occurs
when a lens fails to focus all colors to the same convergence point).
4
OIS (p. 93)
Optical Image Stabilization. Lenses with this feature can detect
camera shake and eectively cancel out the movement inside the
camera.
5
Ø
The lens diameter. When you attach a lter to the lens, make sure that
the diameters of the lens and the lter are the same.
Lens markings
Find out what the numbers on the lens signify.
SAMSUNG 18-200 mm F3.5-6.3 ED OIS lens (example)
1
2345
My Camera
50
Accessories
You can use accessories including external ash and GPS module that can
help you capture better and more convenient photos.
For more information about optional accessories, refer to the manual for
each accessory.
•
The illustrations may dier from the actual items.
•
You can purchase Samsung-approved accessories at a retailer or a Samsung
service center. Samsung is not responsible for damage caused by using
another manufacturer's accessories.
External ash layout
SEF8A (example)
1
2
3
No. Description
1
Bulb
2
Hot-shoe fastening dial
3
Hot-shoe connection
My Camera > Accessories
51
Connecting the external ash
1
Remove the hot-shoe cover from the camera.
2
Mount the ash by sliding it into the hot-shoe.
3
Lock the ash into place by turning the hot-shoe fastening dial
clockwise.
4
Lift up the ash for use.
My Camera > Accessories
52
•
You can capture a photo with a ash that is not fully charged, but it is
recommended to use a fully charged ash.
•
Refer to the optional accessories page for available external ashes. (p. 195)
•
The available options may dier depending on the shooting mode.
•
There is an interval between two bursts of the ash. Do not move until the
ash res a second time.
•
SEF8A may not be compatible with other NX series cameras.
•
For more details about optional ashes, refer to the user manual for the ash.
Use only Samsung-approved ashes. Using incompatible ashes may damage
your camera.
SEF220A (example) (optional)
2
1
3
4
5
6
7
8
9
No. Description
1
Display icons
2
READY lamp/Test button
3
MODE button
4
Flash release button
5
Power button
6
Battery cover
7
Bulb
8
TELE/WIDE mode switch
9
Hot-shoe connection
My Camera > Accessories
53
GPS module layout (optional)
1
2
3
4
5
No. Description
1
Status lamp
2
Power button
3
Hot-shoe fastening dial
4
Hot-shoe connection
5
Battery cover
Attaching the GPS module
1
Remove the hot-shoe cover from the camera.
2
Mount the GPS module by sliding it into the hot-shoe.
My Camera > Accessories
54
3
Lock the GPS module into place by turning the hot-shoe
fastening dial towards LOCK.
4
Press the power button of the GPS module.
My Camera
55
Shooting modes
Two simple shooting modes—Auto and Smart mode—help you capture
photos with numerous automatic settings. Additional modes allow for
greater customization of settings.
Auto mode
In Auto mode, the camera recognizes surrounding conditions and
automatically adjusts factors that contribute to exposure, including
shutter speed, aperture value, metering, White Balance, and exposure
compensation. As the camera controls most of the functions, some
shooting functions are limited. This mode is useful for capturing quick
snapshots with the least amount of adjustment.
1
On the Mode screen, touch Auto.
2
Align your subject in the frame.
3
Half-press [Shutter] to focus.
•
The camera selects a scene. An appropriate scene icon appears at
the screen.
My Camera > Shooting modes
56
Recognizable scenes
Icon Description
Landscapes
Scenes with bright white backgrounds
Landscapes at night
Portraits at night
Landscapes with backlighting
Portraits with backlighting
Portraits
Close-up photos of objects
Close-up photos of text
Sunsets
Indoors, dark
Partially lit
Close-up with spot lighting
Portraits with spot lighting
Blue skies
Icon Description
Forested areas typically consist of green-colored subjects
Close-up photos of colorful subjects
Camera is stabilized on a tripod and the subject is not moving for a
certain period of time. (when shooting in the dark)
Actively moving subjects
Fireworks (when using a tripod)
4
Press [Shutter] to capture the photo.
•
The camera may detect dierent scenes, even the same subjects, depending
on external factors such as camera shake, lighting, and distance to the
subject.
•
If the camera does not recognize an appropriate scene mode, it uses the
default settings for the Auto mode.
•
Even if it detects a face, the camera may not select a portrait mode
depending on the subject's position or lighting.
•
Even if you use a tripod, the camera may not detect the tripod mode ( ) if
the subject is moving.
•
The camera consumes more battery power, because it changes settings often
to select appropriate scenes.
My Camera > Shooting modes
57
Smart mode
In Smart mode, you can capture photos with options that are preset for a
specic scene.
1
On the Mode screen, touch Smart.
2
Touch a scene.
•
To select another scene in Shooting mode, touch on the screen,
and then touch a mode from the list.
Option Description
Beauty Face
Capture a portrait with options to hide facial
imperfections.
Best Face
Capture multiple photos and replace faces to
create the best possible image.
Landscape
Capture still-life scenes and landscapes.
Macro
Capture small or close-up subjects.
Option Description
Action Freeze
Capture subjects moving at high speed.
Rich Tones
Capture a photo with vibrant colors.
Panorama
Capture a wide panoramic scene in a single photo.
Waterfall
Capture scenes with waterfalls.
Silhouette
Capture subjects as dark shapes against a light
background.
Sunset
Capture scenes at sunset, with natural-looking
reds and yellows.
Night
Capture multiple photos in low light conditions
without a ash. The camera combines them to
create a single image that is brighter and has less
blurring.
Fireworks
Capture scenes with reworks.
Light Trace
Capture scenes with the light trailing in low-light
conditions.
Creative Shot
Capture photos with eects applied automatically.
3
Half-press [Shutter] to focus, and then press [Shutter] to
capture.
My Camera > Shooting modes
58
Using the Best Face mode
In Best Face mode, you can capture multiple photos and replace faces to
create the best possible image. Use this mode to select the best image for
each individual when capturing group photos.
1
On the Mode screen, touch Smart
→
Best Face.
2
Align your subject in the frame, and then half-press [Shutter]
to focus.
3
Press [Shutter] to capture the photo.
•
The camera captures 5 photos consecutively.
•
The rst photo is set as the background image.
•
The camera automatically detects faces after shooting.
4
Touch a face to replace.
5
Touch the best image from the 5 faces that were captured.
•
Repeat steps 4 and 5 to replace the rest faces of the photo.
•
The icon will appear on the image that the camera recommends.
6
Touch to save the photo.
•
Use a tripod to prevent your camera from shaking.
•
The resolution is set to 5.9M or smaller.
My Camera > Shooting modes
59
Capturing panoramic photos
Capture a 2D or 3D panoramic photo. Captured 3D panoramic photos can
be viewed only on a 3D TV or 3D monitor.
1
On the Mode screen, touch Smart
→
Panorama.
2
Touch
→
1
→
Panorama
→
Live Panorama or 3D.
3
Touch to return to Shooting mode.
4
Press and hold [Shutter] to start shooting.
5
With [Shutter] pressed, slowly move the camera in the
direction you selected.
•
In 3D Panorama mode, you can capture a scene only in horizontal
directions.
•
An arrow toward the direction of motion is displayed, and the entire
shooting image is displayed in the preview box.
•
When the scenes are aligned, the camera captures the next photo
automatically.
6
When you are nished, release [Shutter].
•
The camera will automatically save the shots into one photo.
•
If you release [Shutter] while shooting, the panoramic shooting
stops and photos that have been captured are saved.
My Camera > Shooting modes
60
•
The resolution varies depending on the panoramic photo you captured.
•
In Panorama mode, some shooting options are not available.
•
The camera may stop shooting due to the shooting composition or the
subject's movement.
•
In Panorama mode, your camera may not capture the entire last scene if you
stop moving the camera to improve the photo quality. To capture the entire
scene, move your camera slightly beyond the point where you want the
scene to end.
•
In 3D Panorama mode, your camera may not capture the very beginning or
end of a scene due to the nature of the 3D eect. To capture the entire scene,
move slightly beyond the beginning and end points you want to capture.
•
Photos captured with the 3D function are saved in JPEG (2D) and MPO (3D)
formats. On your camera's display, you can view only JPEG les.
•
To view 3D les, connect your camera to a 3D TV or 3D monitor with an
optional HDMI cable. While viewing, wear proper 3D glasses.
•
Capturing photos in 3D Panorama mode may result in a less pronounced 3D
eect than those captured with a 3D lens. To increase the 3D eect, attach
the optional 3D lens and use 3D mode. (p. 70)
•
For best results when capturing panoramic photos, avoid the following:
-
moving the camera too quickly or too slowly
-
moving the camera too little to capture the next image
-
moving the camera at irregular speeds
-
shaking the camera
-
shooting in dark places
-
capturing moving subjects nearby
-
shooting conditions where the brightness or color of light is changing
•
Photos taken are automatically saved, and shooting is stopped under the
following conditions:
-
if you change the shooting direction while shooting
-
if you move the camera too rapidly
-
if you don't move the camera
My Camera > Shooting modes
61
Program mode
The camera automatically adjusts shutter speed and aperture value so that
an optimal exposure value can be achieved.
This mode is useful when you want to capture shots of constant exposure
while being able to adjust other settings.
1
On the Mode screen, touch Expert
→
Program.
2
Set the desired options.
•
For a list of options, refer to "Shooting Functions". (p. 73)
3
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
Program Shift
Program Shift function lets you adjust the shutter speed and aperture
value while the camera maintains the same exposure. In Shooting mode,
press the command dial once, and then rotate it anti-clockwise to decrease
the shutter speed and increase the aperture value. Conversely, press the
command dial once, and then rotate it clockwise to increase the shutter
speed and decrease the aperture value.
My Camera > Shooting modes
62
Aperture Priority mode
In Aperture Priority mode, the camera automatically calculates shutter
speed according to the aperture value you choose.
You can adjust the depth of eld (DOF) by changing the aperture value.
This mode is useful for taking portraits, owers, or landscape shots.
Large Depth of Field Small Depth of Field
1
On the Mode screen, touch Expert
→
Aperture Priority.
2
Press the command dial once, and then rotate it to the left or
right to adjust the aperture value.
3
Set the desired options.
•
For a list of options, refer to "Shooting Functions". (p. 73)
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
In low-light settings, you may need to increase the ISO sensitivity to prevent
blurred photos.
My Camera > Shooting modes
63
Shutter Priority mode
In Shutter Priority mode, the camera automatically adjusts the aperture
value according to the shutter speed you choose. This mode is useful for
capturing photos of fast-moving subjects or for creating tracer eects in a
photo.
For example, set the shutter speed to over 1/500 s to freeze the subject.
To make the subject appear blurred set the shutter speed to below 1/30 s.
Slow shutter speed Fast shutter speed
1
On the Mode screen, touch Expert
→
Shutter Priority.
2
Press the command dial once, and then rotate it to the left or
right to adjust the shutter speed.
3
Set the desired options.
•
For a list of options, refer to "Shooting Functions". (p. 73)
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
In order to compensate for the reduced amount of light allowed by fast shutter
speeds, open the aperture and let in more light. If your photos are still too dark,
increase the ISO value.
My Camera > Shooting modes
64
Manual mode
Manual mode lets you adjust the shutter speed and aperture value
manually. In this mode, you can fully control the exposure of your photos.
This mode is useful in controlled shooting environments, such as a studio,
or when it is necessary to ne-tune camera settings. The Manual mode is
also recommended for shooting night scenes or reworks.
1
On the Mode screen, touch Expert
→
Manual.
2
Press the command dial to select the shutter speed or the
aperture value.
3
Rotate the command dial to adjust the shutter speed or the
aperture value.
4
Set the desired options.
•
For a list of options, refer to "Shooting Functions". (p. 73)
5
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
Using the Bulb function
Use the Bulb function to shoot night scenes or the night sky. While you are
pressing [Shutter], the shutter is left open so you can create moving light
eects.
To use a Bulb,
Completely rotate the command dial clockwise to Bulb
→
press and hold [Shutter] for the desired time.
•
If you set a high ISO value or open the shutter for a long time, image noise
may increase.
•
Drive options, ash, and One touch shot cannot be used with the Bulb
function.
•
The Bulb function is available only in Manual mode.
•
Use a tripod and shutter release to prevent your camera from shaking.
•
The longer you open the shutter, the longer it takes to save a photo. Do not
turn the camera o while the camera saves a photo.
•
If you use this function for a long time, use a fully charged battery.
My Camera > Shooting modes
65
Custom mode
Custom mode lets you create your own shooting modes by adjusting
options and saving them.
Saving a custom mode
1
On the Mode screen, touch Expert
→
Program, Aperture
Priority, Shutter Priority, or Manual.
2
Set shooting options.
•
For a list of options, refer to "Shooting Functions". (p. 73)
3
Touch
→
5
→
Save as Custom Mode.
•
You can also touch
→
.
4
Touch a location to save (C1, C2, or C3).
•
You can overwrite the settings if an old mode is saved to the same
location.
5
Touch .
Selecting a custom mode
1
On the Mode screen, touch Expert
→
Custom.
2
Touch a mode
→
.
•
To select another custom mode, touch
→
1
→
Custom Mode
→
a mode.
•
You can change the shooting options in the selected custom mode, and save
them as a new custom mode.
•
To reset a custom mode, touch
→
1
→
Reset Custom Mode
→
the custom mode.
My Camera > Shooting modes
66
Recording a video
In Shooting mode, you can record Full HD videos (1920X1080) by pressing
(Video recording). The camera lets you record a video up to 29 minutes
and 59 seconds in length at 30, 24, or 15 fps, and saves the les in
MP4 (H.264) format. The maximum recording time when you select
is
20 minutes. 24 fps is available only with 1920X810.
15 fps is available only with some Smart Filter options. The sound is
recorded via the camera's microphone.
You can set the exposure by adjusting the aperture value and shutter
speed for the mode you selected. The camera automatically focuses on
the subject that you touch on the screen when shooting a movie. When
you touch the Touch AF cancel button (
), the camera will switch to
continuous autofocus. When the AF/MF switch on the lens is set to MF, you
cannot use the Touch AF feature.
Touch Fader to fade in or out a scene. You can also select Voice, Wind Cut,
or other options to set recording options. (p. 108)
1
On the Mode screen, touch Auto, Smart, or Expert
→
Program, Aperture Priority, Shutter Priority, Manual, or
Custom.
•
This feature may not work in some modes.
2
Set the desired options.
3
Press (Video recording) to start recording.
4
Press (Video recording) again to stop.
•
H.264 (MPEG-4 part10/AVC) is the latest video coding format established
in 2003 collaboratively by ISO-IEC and ITU-T. Since this format uses a high
compression rate, more data can be saved in less memory space.
•
If you have the image stabilizer option on when shooting a movie, the
camera may record the image stabilizer sound.
•
The zoom sound or other lens sounds may be recorded if you adjust the lens
while recording a video.
•
When using an optional video lens, the autofocus noise is not recorded.
•
If you remove the camera lens while recording a movie, the recording will be
interrupted. Do not change the lens while recording.
•
If you attach an external microphone while recording a movie, sound will not
be recorded through the external microphone. (The previous settings are
maintained.) If you remove the external microphone while recording a movie,
sound will not be recorded. Turn o the camera before attaching or removing
the external microphone.
My Camera > Shooting modes
67
•
If you change the shooting angle of the camera suddenly while shooting a
movie, the camera may not be able to record images accurately. Use a tripod
to minimize camera shake.
•
The camera supports only the Multi AF function when recording a video. You
cannot use any other focus area setting functions, such as Face Detection AF.
•
When the size of a movie le exceeds 4 GB, the camera automatically stops
recording even if the maximum recording time (29 minutes and 59 seconds)
has not been reached.
•
If you use a slow writing memory card, the recording of your movie can
be interrupted because the card cannot process data at the rate the video
is being shot. If this occurs, replace the card with a faster memory card or
reduce the video size (for example, from 1280X720 to 640X480).
•
When formatting a memory card, always format using the camera. If you
format on another camera or a PC, you can lose les on the card or cause a
change in the capacity of the card.
•
When you press the video recording button, Z turns o.
•
While recording a video in the same ISO sensitivity, the screen may be darker
than taking a photo. Adjust the ISO sensitivity.
•
When you record a video in Program, Aperture Priority, or Shutter Priority,
ISO is automatically set to Auto.
Using i-Function
When you use the i-Function button on an i-Function lens, you can
manually select and adjust shutter speed, aperture value, exposure value,
ISO sensitivity, and White Balance on the lens.
1
On the Mode screen, touch Expert
→
Program, Aperture
Priority, Shutter Priority, or Manual.
2
Press [i-Function] on the lens to select a setting.
•
You can also press [i-Function], and then drag the screen to select
a setting.
My Camera > Shooting modes
68
3
Adjust the focus ring to select an option.
•
You can also rotate the command dial or drag the screen to select
an option.
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
Available options
Shooting mode Program Aperture Priority Shutter Priority Manual
Aperture
-O -O
Shutter Speed
-- OO
ISO
OO OO
EV
OO O-
White Balance
OO OO
Z
OO OO
•
To select items to appear when you press [i-Function] on the lens in Shooting
mode, touch
→
5
→
iFn Customizing
→
an item.
•
This function is not available when you set 3D Auto Mode in 3D mode.
My Camera > Shooting modes
69
Using Z
The Z allows you to zoom in on a subject with less degradation of
photo quality than the Digital zoom. However, the photo resolution may
change compared to when you zoom in by rotating the zoom ring.
1
On the Mode screen, touch Expert
→
Program, Aperture
Priority, Shutter Priority, or Manual.
2
Press [i-Function] on the lens to select Z.
•
You can also press [i-Function], and then drag the screen.
3
Adjust the focus ring to select a zoom ratio.
•
You can also rotate the command dial or drag the screen to select
an option.
•
Photo resolution varies according to the zoom ratio if you use the
Z.
3:2 16:9 1:1
x1.2
4560X3040 (13.9M) 4560X2568 (11.7M) 3040X3040 (9.2M)
x1.4
3888X2592 (10.1M) 3888X2184 (8.5M) 2592X2592 (6.7M)
x1.7
3264X2176 (7.1M) 3264X1840 (6.0M) 2176X2176 (4.7M)
x2
2736X1824 (5.0M) 2736X1536 (4.2M) 1824X1824 (3.3M)
These gures are based on the maximum resolution at each image ratio.
4
Half-press [Shutter] to focus, and then press [Shutter] to
capture the photo.
•
Z is not available when you capture burst shots.
•
Z is not available when you capture photos in the RAW le format.
•
Z is deactivated when you record videos by pressing the video
recording button.
•
This function is not available when you set 3D Auto Mode in 3D mode.
My Camera > Shooting modes
70
3D mode
You can capture 3D photos or videos with an optional 3D lens. 3D mode
is always on, regardless of the camera mode. To start a pre-dened Wi-Fi
function, press [DIRECT LINK]. Some Wi-Fi features may not be available.
SAMSUNG 45 mm F1.8 [T6] 2D/3D lens (example)
Set the 2D/3D switch on the lens to 3D, and then capture a photo or video
1.5-5 m away from the subject.
•
To use auto 3D options that enable the camera to set shooting options
automatically depending on shooting conditions in 3D mode, touch
→
1
→
3D Auto Mode
→
On.
•
Available shooting options dier compared to other shooting modes.
•
You can select either 4.1M (2688X1512) or 2.1M (1920X1080) photo size.
•
The video resolution is set to .
•
Videos recorded in 3D may be dark or playback may be jittery.
•
Shooting in low temperatures may result in color distortion in images and
may consume more battery power.
•
You may not be able to shoot properly in conditions below 8.5 LV/900 lux. For
best results, capture photos in places with sucient light.
•
When you photograph objects that contain polarizing material, such as a
display, sunglasses, or a polarizing lter, or use the polarizing material with
your lens, the images may appear dark or the 3D eect may not be applied
properly.
•
Use a tripod to prevent your camera from shaking.
•
If you rotate or tilt the camera vertically while shooting, the 3D eect may not
be applied properly. Capture images with the camera in the normal position.
•
If you shoot in uorescent lighting or capture images displayed by projectors
or TVs, the images may appear black due to the icker eect.
•
In 3D mode, the Enlarge x8 option of MF Assist may not be available.
•
The camera's display shows 3D videos only in 2D.
•
Photos captured with the 3D function are saved in JPEG (2D) and MPO (3D)
formats. On your camera's display, you can view only JPEG les.
•
To view 3D les, connect your camera to a 3D TV or 3D monitor with an
optional HDMI cable. While viewing, wear proper 3D glasses.
•
You cannot use the ash in 3D mode.
My Camera > Shooting modes
71
Available functions by shooting mode
For details about shooting functions, see Chapter 2. Press a shortcut for each function.
Function Auto Smart Program Aperture Priority Shutter Priority Manual 3D
Photo Size (p. 74)
OOOOOOO
Quality (p. 75)
-
OOOOO
-
ISO (p. 76)
--
OOOOO
White Balance (p. 77)
--
OOOO
-
Picture Wizard (p. 80)
--
OOOO
-
Smart Filter (p. 81)
--
OOOO
-
AF Mode (p. 82)
-
OOOOOO
AF Area (p. 85)
-
OOOOO
-
Touch AF (p. 88)
OOOOOOO
MF Assist (p. 90)
OOOOOOO
Focus Peaking (p. 90)
OOOOOO
-
Link AE to AF Point (p. 91)
--
OOOO
-
Framing Mode (p. 92)
--
OOOO
-
O: The option is available. Some options may be limited or may not be changeable.
-: The option is not available.
My Camera > Shooting modes
72
Function
Auto Smart Program Aperture Priority Shutter Priority Manual 3D
OIS (Anti-Shake) (p. 93)
OOOOOOO
Drive (Continuous/Burst/Timer/
Bracketing) (p. 94)
OOOOOOO
Metering (p. 98)
--
OOOO
-
Dynamic Range (p. 100)
--
OOOO
-
Flash (p. 101)
OOOOOO
-
Exposure compensation (p. 104)
--
OOO
--
Exposure lock (p. 105)
--
OOO
--
O: The option is available. Some options may be limited or may not be changeable.
-: The option is not available.
Chapter 2
Shooting Functions
Learn about the functions you can set in Shooting mode.
You can enjoy more customized photos and videos by using the shooting functions.
Shooting Functions
7474
Sh
ooting FunctionsShooting Functions
Photo size
As you increase the resolution, your photo or video will include more
pixels, so it can be printed on larger paper or displayed on a larger screen.
When you use a high resolution, the le size will also increase. Select a low
resolution for photos that will be displayed in a digital picture frame or
uploaded to the web.
To set the size,
In Shooting mode, touch
→
1
→
Photo Size
→
an option.
Icon Size Recommended for
5472x3648 (3:2) Printing on A1 paper.
3888x2592 (3:2) Printing on A2 paper.
2976x1984 (3:2) Printing on A3 paper.
1728x1152 (3:2) Printing on A5 paper.
5472x3080 (16:9)
Printing on A1 paper or viewing on an
HDTV.
3712x2088 (16:9)
Printing on A3 paper or viewing on an
HDTV.
2944x1656 (16:9)
Printing on A4 paper or viewing on an
HDTV.
1920x1080 (16:9)
Printing on A5 paper or viewing on an
HDTV.
3648x3648 (1:1) Printing a square photo on A1 paper.
2640x2640 (1:1) Printing a square photo on A3 paper.
2000x2000 (1:1) Printing a square photo on A4 paper.
1024x1024 (1:1) Printing a square photo on A5 paper.
Available options may dier depending on shooting conditions.
Size and Resolution
75
Shooting Functions > Size and Resolution
Quality
The camera saves photos in either the JPEG or RAW format.
Photos captured by a camera are often transformed to the JPEG format
and stored in the memory according to the settings of the camera at the
time of shooting. RAW les are not transformed to the JPEG format and are
stored in the memory without any changes.
RAW les have the le extension “SRW”. To adjust and calibrate exposures,
White Balances, tones, contrasts, and colors of the RAW les, or to convert
them into JPEG or TIFF format, use the Adobe Photoshop Lightroom
program found on the supplied DVD-ROM.
Ensure you have enough space on the memory card to save photos in the
RAW format.
To set the quality,
In Shooting mode, touch
→
1
→
Quality
→
an option.
Icon Format Description
JPEG
Super Fine:
• Compressed for the best quality.
• Recommended for printing in large size.
JPEG
Fine:
• Compressed for better quality.
• Recommended for printing in normal size.
Icon Format Description
JPEG
Normal:
• Compressed for normal quality.
• Recommended for printing in small size or
uploading to the web.
RAW
RAW:
• Save a photo without data loss.
• Recommended for editing after shooting.
RAW+JPEG
RAW + S.Fine: Save a photo in both the JPEG
(S.Fine quality) and RAW format.
RAW+JPEG
RAW + Fine: Save a photo in both the JPEG (Fine
quality) and RAW format.
RAW+JPEG
RAW + Normal: Save a photo in both the JPEG
(Normal quality) and RAW format.
Available options may dier depending on shooting conditions.
Shooting Functions
7676
Sh
ooting FunctionsShooting Functions
The ISO sensitivity value represents the sensitivity of camera to light.
The larger the ISO value, the more sensitive the camera is to light.
Consequently, by selecting a higher ISO sensitivity value, you can capture
photos in dim or dark places at faster shutter speeds. However, this may
increase electronic noise and result in a grainy photo.
To set ISO sensitivity,
In Shooting mode, touch
→
1
→
ISO
→
an
option.
Examples
ISO 100 ISO 400
ISO 800 ISO 3200
•
Increase the ISO value in places where ash use is prohibited. You can capture
a clear photo by setting a high ISO value without having to secure more light.
•
Use the Noise Reduction function in order to reduce the visual noise that can
appear on photos of a high ISO value. (p. 146)
•
Available options may dier depending on the shooting conditions.
ISO sensitivity
Shooting Functions
7777
Sh
ooting FunctionsShooting Functions
White Balance represents the light source that inuences on the color of a
photo.
The color of a photo depends on the type and quality of the light source.
If you want the color of your photo to be realistic, select an appropriate
lighting condition to calibrate the White Balance, such as Auto WB,
Daylight, Cloudy, Tungsten, or adjust color temperature manually.
You can also adjust color for the preset light sources so that the colors of
the photo match the actual scene under mixed lighting conditions.
To set the White
Balance,
In Shooting mode, touch
→
1
→
White Balance
→
an option
→
.
Icon Description
Auto WB: Use automatic settings depending on the lighting
conditions.
Daylight: Select when taking outdoor photos on a sunny day. This
option results in photos closest to the natural colors of the scene.
Cloudy: Select when taking outdoor photos on a cloudy day or in
shadows. Photos captured on cloudy days tend to be more bluish
than on sunny days. This option osets that eect.
Fluorescent White: Select when shooting under a daylight
uorescent lamp. Especially for white uorescent light with a color
temperature of about 4,200K.
Fluorescent NW: Select when shooting under a daylight
uorescent lamp. Especially for white uorescent light of very
white hues with a temperature of about 5,000K.
Fluorescent Daylight: Select when shooting under a daylight
uorescent lamp. Especially for white uorescent light of slightly
bluish hue with a temperature of about 6,500K.
Tungsten: Select when taking indoor photos under incandescent
bulbs or halogen lamps. Incandescent tungsten bulbs tend to have
a reddish hue. This option osets that eect.
Flash WB: Select when using a ash.
Custom Set: You can manually set the White Balance by touching
, and then shooting a white sheet of paper. Fill the spot
metering circle with the paper and set the White Balance.
White Balance
78
Shooting Functions > White Balance
Icon Description
Color Temperature: Manually adjust the color temperature of
the light source. Color temperature is a measurement in degrees
Kelvin that indicates the specic type of light source. As the color
temperature increases, the color distribution becomes cooler.
Alternatively, as the color temperature decreases, the color
distribution becomes warmer. Touch
, and then adjust the
color tempertature.
Clear sky
Fluorescent H
Fluorescent L
Cloudy
Halogen lamp
Daylight
Tungsten
Candle light
Available options may dier depending on shooting conditions.
Customizing preset White Balance options
You can also customize preset White Balance options.
To customize
preset options,
In Shooting mode, touch
→
1
→
White Balance
→
an option
→
→
touch an area on the screen
→
touch
.
White Balance : Daylight
79
Shooting Functions > White Balance
Examples
Auto WB Daylight
Fluorescent Daylight Tungsten
Shooting Functions
8080
Sh
ooting FunctionsShooting Functions
Picture Wizard lets you apply dierent photo styles to your photo to create
various looks and emotional moods. You can also create and save your
own photo styles by adjusting color, saturation, sharpness, and contrast for
each style.
There is no rule for which style is suitable in which conditions. Experiment
with dierent styles and nd your own settings.
To set a photo style,
In Shooting mode, touch
→
1
→
Picture Wizard
→
an option
→
.
Examples
Standard Vivid Portrait
Landscape Forest Retro
Cool Calm Classic
•
You can also adjust the value of the preset style settings. Select a Picture
Wizard option, touch
, and then adjust color, saturation, sharpness,
or contrast.
•
To customize your own picture wizard, select , , or , touch ,
and then adjust the color, saturation, sharpness, and contrast
•
Picture Wizard options cannot be set with Smart Filter options at the same
time.
Picture Wizard (photo styles)
Shooting Functions
8181
Sh
ooting FunctionsShooting Functions
Smart Filter lets you apply special eects to your photos. You can select
various lter options to create special eects that are dicult to be
achieved with normal lenses.
To set Smart Filter
options,
In Shooting mode, touch
→
1
→
Smart Filter
→
an option
→
.
Option Description
O
No eect
Vignetting
Apply the retro-looking colors, high contrast, and strong
vignette eect of Lomo cameras.
Miniature
Apply a tilt-shift eect to make the subject appear in
miniature.
Colored Pencil
Apply a colored pencil painting eect.
Watercolor
Apply a watercolor painting eect.
Wash drawing
Apply a washed-out eect.
Oil Sketch
Apply oil sketching eect.
Ink Sketch
Apply ink sketching eect.
Acryl
Apply an acryl painting eect.
Option Description
Negative
Apply a negative lm eect.
Red
Desaturate all colors but red.
Green
Desaturate all colors but green.
Blue
Desaturate all colors but blue.
Yellow
Desaturate all colors but yellow.
Smart lter options cannot be set with Picture Wizard options at the same time.
Smart Filter
Shooting Functions
8282
Sh
ooting FunctionsShooting Functions
AF mode
Learn how to adjust the camera’s focus according to the subjects.
You can select a focusing mode appropriate to the subject among Single
Auto Focus, Continuous Auto Focus, and Manual Focus. The AF function is
activated when you press [Shutter] halfway. In the MF mode, you have to
rotate the focus ring on the lens to focus manually.
In most cases, you can have a focus by selecting Single AF. Fast moving
subjects or subjects of a color similar to the background are dicult to
focus. Select an appropriate focusing mode for such instances.
If your lens has an AF/MF switch, you must set the switch according to
the selected mode. Set the switch to AF when you select Single AF or
Continuous AF. Set the switch to MF when you select Manual Focus.
When your lens has no AF/MF switch, select an AF mode from the camera
menu.
To set the auto
focus mode,
In Shooting mode, touch
→
1
→
AF Mode
→
an option.
The available options may dier depending on the lens in use.
83
Shooting Functions > AF mode
Single AF
Single AF is appropriate for shooting a still subject. When you press
[Shutter] halfway, the focus xes in the focus area. The area turns green
when the focus is achieved.
Continuous AF
While you are pressing [Shutter] halfway, the camera continues to
automatic focusing. Once the focus area is xed on the subject, the subject
is always in focus even when moving. This mode is recommended for
shooting a person on a bicycle, a running dog, or a car racing scene.
84
Shooting Functions > AF mode
Manual focus
You can manually focus on a subject by rotating the focus ring on the
lens. The MF Assist function lets you easily achieve a focus. While you are
rotating the focus ring, the focus area is magnied. When you use the
Focus Peaking function, the color you selected appears on the focused
subject. This mode is recommended for shooting an object similar in color
to the background, a night scene, or reworks.
If you use this function, you cannot set Touch AF, AF Area, and Link AE to AF
Point options.
Shooting Functions
8585
Sh
ooting FunctionsShooting Functions
The AF area function changes the positions of the focus area.
Generally, cameras focus on the nearest subject. When there are a lot of
subjects, however, unwanted subjects can be in focus. In order to prevent
unwanted subjects from being in focus, change the focus area so that
a desired subject is in focus. You can get a clearer and sharper photo by
selecting an appropriate focus area.
To set the auto
focus area,
In Shooting mode, touch
→
1
→
AF Area
→
an option.
•
Available options may dier depending on shooting conditions.
•
When the AF/MF switch is set to MF, you cannot change the AF area from the
shooting menu.
•
When you use the Face Detection AF option, the camera focuses on the area
with the white frame automatically.
•
Depending on the Picture Wizard options, Face Detection may not be
eective.
•
When you set manual focus, Face Detection may not be available.
•
Face Detection may not be eective when:
-
the subject is far from the camera
-
it is too bright or too dark
-
the subject is not facing the camera
-
the subject is wearing sunglasses or a mask
-
the subject’s facial expression changes drastically
-
the subject is backlit or the lighting conditions are unstable
Selection AF
You can set the focus on an area you want. Apply an out-of-focus eect to
make the subject more distinguishable.
The focus on the photo below was repositioned and resized so that it ts
the subject’s face.
To resize the focus area, in Shooting mode, touch
→
AF Size.
Touch
or to adjust the size of the focus area. You can also rotate the
command dial. Alternatively, in Shooting mode, pinch your ngers together
or spread them apart on the focus area.
AF area
86
Shooting Functions > AF area
Multi AF
The camera displays a green rectangle in places where focus is set
correctly. The photo is divided into two or more areas, and the camera
obtains focus points of each area. It is recommended for scenery photos.
When you press [Shutter] halfway, the camera displays the focus areas as
shown in the photo below.
Face detection AF
The camera focuses on human faces preferentially. Faces of up to
10 people can be detected. This setting is recommended for shooting a
group of people.
When you press [Shutter] halfway, the camera focuses on faces as shown
in the photo below. In cases of shooting a group of people, the camera
displays the focus on the nearest person’s face in white and the rest of the
people’s faces in gray.
87
Shooting Functions > AF area
Self-Portrait AF
It can be dicult to check whether your face is in focus when you are
taking a self-portrait. When this function is on, the beep from the camera
gets faster when your face is located at the center of the composition.
Shooting Functions
8888
Sh
ooting FunctionsShooting Functions
Tracking AF
Tracking AF allows you to track and automatically focus on your subject,
even when the subject is moving or when you change the shooting
composition.
White frame: Your camera is
tracking the subject.
Green frame: Your subject is
in focus when you half-press
[Shutter].
Red frame: Your camera failed to
focus.
Focus on the subject or capture a photo by touching on the screen.
To set Touch AF,
In Shooting mode, touch
→
1
→
Touch AF
→
an option.
Available options may dier depending on the shooting conditions.
Touch AF
Touch AF allows you to focus on the subject that you touch on the screen.
Touch AF
89
Shooting Functions > Touch AF
One touch shot
You can capture a photo with the touch of your nger. As you touch on a
subject, the camera focuses on the subject automatically and captures a
photo.
•
If you do not select a focus area, the Auto Focus function does not work.
•
Tracking a subject may fail when:
-
the subject is too small
-
the subject moves excessively
-
the subject is backlit or you are shooting in a dark place
-
colors or patterns on the subject and the background are the same
-
the subject includes horizontal patterns, such as blinds
-
the camera shakes excessively
•
When tracking fails, the feature will be reset.
•
If the camera fails to track the subject, the focus area will be reset.
•
If the camera fails to focus, the focus frame will change to red and the focus
will be reset.
Shooting Functions
9090
Sh
ooting FunctionsShooting Functions
In the manual focus mode, you have to rotate the focus ring on the lens to
focus. When you use the MF Assist function or the Focus Peaking function,
you can achieve a clearer focus. This function is only available on a lens
that supports manual focus.
MF Assist
In the manual focus mode, you can enlarge the scene and easily adjust the
focus while rotating the focus ring.
To set the manual
focus assist,
In Shooting mode, touch
→
1
→
MF Assist
→
an option.
* Default
Option Description
O
Do not use the MF Assist function.
Enlarge x5*
The focus area is magnied by 5 times when you rotate the
focus ring.
* Default
Option Description
Enlarge x8
The focus area is magnied by 8 times when you rotate the
focus ring.
Focus Peaking
In the manual focus mode, the color you selected appears on the focused
subject to help you focus while rotating the focus ring.
To set Focus
Peaking options,
In Shooting mode, touch
→
1
→
Focus Peaking
→
an option.
* Default
Option Description
Level
Set a sensitivity for detecting the focused subject.
(O, High, Normal*, Low)
Color
Set a color to appear on the focused subject.
(White*, Red, Green)
Focus assist
91
Shooting Functions > Focus assist
Measuring the exposure value of the focus
area
When this function is turned on, the camera automatically sets an optimal
exposure by calculating the brightness of the focus area. This function
is only available when you select Spot metering or Multi metering, and
Selection AF.
To set this
function,
In Shooting mode, touch
→
1
→
Link AE to AF
Point
→
an option.
Shooting Functions
9292
Sh
ooting FunctionsShooting Functions
Framing mode
When you adjust the aperture value or shutter speed, the exposure
changes according to the settings, so the display may darken. With this
function on, the brightness of the display is constant regardless of the
settings, so you can better frame your shot.
To use Framing
Mode,
In Shooting mode, touch
→
1
→
Framing Mode
→
an option.
Shooting Functions
9393
Sh
ooting FunctionsShooting Functions
Use the Optical Image Stabilization (OIS) function to minimize camera
shake. OIS may not be available with some lenses.
Camera shake tends to occur in dark places or when shooting indoors.
In such cases, the camera uses slower shutter speeds in order to increase
the amount of light taken in, which can result in a blurry photo. You can
prevent this situation by using the OIS function.
If your lens has an OIS switch, you have set the switch to ON to use the OIS
function.
To set OIS options,
In Shooting mode, touch
→
1
→
OIS (Anti-Shake)
→
an option.
* Default
Icon Description
O: The OIS function is o. (This option may not be available with
some lenses.)
Mode 1*: The OIS function is applied only when you press
[Shutter] in full or half.
Mode 2: The OIS function is on.
Optical Image Stabilization (OIS)
Without OIS correction With OIS correction
•
OIS may not function properly when:
-
you move your camera to follow a moving subject
-
there is too much camera shake
-
the shutter speed is slow (for example, when you select Night in
Smart mode)
-
the battery is low
-
you capture a close-up shot
•
If you use the OIS function with a tripod, your images may be blurred by
the vibration of the OIS sensor. Deactivate the OIS function when you use a
tripod.
•
If the camera is hit or dropped, the display will be blurry. If this occurs, turn o
the camera, and then turn it on again.
•
Use the OIS function only when needed because the function consumes
more battery power.
•
To set an OIS option on the menu, set the OIS switch on your lens to ON.
•
This option may not be available with some lenses.
•
O may not be available with some lenses.
Shooting Functions
9494
Sh
ooting FunctionsShooting Functions
You can set the shooting method such as Continuous, Burst, Timer and so
on.
Select Single to capture one photo at a time. Select Continuous or Burst
to shoot fast moving subjects. Select AE Bracket, WB Bracket, or P Wiz
Bracket to adjust exposure, White Balance, or apply Picture Wizard eects.
You can also select Timer to capture a photo of yourself.
To set the shooting
method,
In Shooting mode, touch
→
1
→
Drive
→
an
option
→
.
Available options may dier depending on shooting conditions.
Single
Capture one photo whenever you press [Shutter]. Recommended for
general conditions.
Continuous
Continuously capture photos while you are pressing [Shutter]. You can
capture up to 5 photos (Continuous Normal) or 8 photos (Continuous
High) per second.
If you select Continuous High, the noise reduction function is not available.
Drive (shooting method)
95
Shooting Functions > Drive (shooting method)
Burst
Consecutively capture up to 10 shots per second (3 seconds), 15 shots per
second (2 seconds), or 30 shots per second (1 second) when you press
[Shutter] once. It is recommended for shooting the rapid motion of fast
moving subjects such as racing cars.
•
To set the number of shots, in Shooting mode, touch
→
1
→
Drive
→
Burst
→
→
the number of shots
→
.
•
The photo size is set to 5M.
•
It may take longer to save a photo.
•
You cannot use the ash with this option.
•
Shutter speed must be faster than 1/30 second.
•
Photos captured with this option may be slightly enlarged when saving.
•
You cannot set an ISO option higher than ISO 3200.
•
This option cannot be used with the RAW le format and is not available
when the photo quality is set to RAW.
Timer
Capture a photo with a delay of 2 to 30 seconds. The delay is adjustable in
increments of 1 second.
To set the delay, in Shooting mode, touch
→
1
→
Drive
→
Timer
→
→
a delay
→
.
96
Shooting Functions > Drive (shooting method)
Auto Exposure Bracketing (AE Bracket)
When you press [Shutter], the camera captures 3 consecutive photos: the
original, one a step darker, and one a step lighter. Use a tripod to prevent
blurry photos as the camera captures three photos continuously. You can
adjust the settings in Bracket Set menu.
Exposure -2
Original
Exposure +2
To set a bracketing option, in Shooting mode, touch
→
5
→
Bracket Set
→
an option.
White Balance Bracketing (WB Bracket)
When you press [Shutter], the camera captures 3 consecutive photos:
the original and two more with dierent White Balance settings. The
original photo is captured when you press [Shutter]. The other two are
automatically adjusted according to the White Balance you have set. You
can adjust the settings in Bracket Set menu.
WB-2
Original
WB+2
•
This option cannot be used with the RAW le format and is not available
when the photo quality is set to RAW.
•
To set a bracketing option, in Shooting mode, touch
→
5
→
Bracket Set
→
an option.
97
Shooting Functions > Drive (shooting method)
Picture Wizard Bracketing (P Wiz Bracket)
When you press [Shutter], the camera captures three consecutive photos,
each with a dierent Picture Wizard setting. The camera captures a photo
and applies the three Picture Wizard options you have set to the image
captured. You can select three dierent settings in Bracket Set menu.
Vivid
Standard
Retro
•
This option cannot be used with the RAW le format and is not available
when the photo quality is set to RAW.
•
To set a bracketing option, in Shooting mode, touch
→
5
→
Bracket Set
→
an option.
Shooting Functions
9898
Sh
ooting FunctionsShooting Functions
The metering mode refers to the way in which a camera measures the
quantity of light.
The camera measures the amount of light in a scene, and in many of its
modes, uses the measurement to adjust various settings. For example,
if a subject looks darker than its actual color, the camera captures an
overexposed photo of it. If a subject looks lighter than its actual color, the
camera captures an underexposed photo of it.
The brightness and overall mood of the photo can also be aected by how
the camera measures the amount of light. Select an appropriate setting for
a shooting condition.
To set a metering
option,
In Shooting mode, touch
→
1
→
Metering
→
an option.
Multi
The Multi mode calculates the amount of light in multiple areas. When
light is sucient or insucient, the camera adjusts the exposure by
averaging the overall brightness of the scene. This mode is suitable for
general photos.
Metering
99
Shooting Functions > Metering
Spot
The Spot mode calculates the amount of light in the center. When you
capture a photo in conditions where there is a strong backlight behind a
subject, the camera adjusts the exposure so as to shoot a subject correctly.
For example, when you select the Multi mode in a strong backlight
condition, the camera calculates that the overall amount of light is
abundant, which results in a darker photo. The Spot mode can prevent this
situation as it calculates the amount of light in a designated area.
The subject is in bright color while the background is dark. The Spot mode
is recommended for a situation like this where a huge dierence in the
exposure exists between a subject and a background.
Center-weighted
The Center-weighted mode calculates a broader area than the Spot mode
does. It sums up the amount of light in the center portion of the shot
(60–80 %) and that of the rest of the shot (20–40 %). It is recommended
for situations where there is a slight dierence in brightness between a
subject and a background or an area of the subject is large compared to
the overall composition of the photo.
Shooting Functions
100100
Sh
ooting FunctionsShooting Functions
This function automatically corrects the loss of bright detail that can occur
due to shading dierences in the photo.
To set Smart Range
options,
In Shooting mode, touch
→
1
→
Dynamic Range
→
an option.
Without Dynamic Range eect With Dynamic Range eect
Icon Description
O: Do not use Dynamic Range.
Smart Range+: Correct the loss of bright detail.
You cannot set ISO 100.
HDR: Capture 2 photos with dierent exposures, and then
combine them to create a single image automatically.
You cannot set an ISO option higher than ISO 3200.
Dynamic Range
Shooting Functions
101101
Sh
ooting FunctionsShooting Functions
Flash
In order to capture a realistic photo of a subject, the amount of light
should be constant. When the light source varies, you can use a ash and
supply a constant amount of light. Select appropriate settings according to
a light source and a subject.
To set ash options,
In Shooting mode, touch
→
1
→
Flash
→
an option
→
.
Icon Description
O: Do not use the ash.
Smart Flash: The camera automatically adjusts the brightness
of the ash according to the amount of light in the surrounding
environment.
Auto: The ash automatically res in dark places.
Auto Red-eye: The ash automatically res and reduces red-eyes.
Fill in: The ash res whenever you capture a photo. (Brightness is
automatically adjusted.)
Fill-in Red: The ash res whenever you capture a photo and
reduces red-eyes.
Icon Description
1st Curtain: The ash res
immediately after the shutter opens.
The camera captures a photo of a
subject earlier in an action sequence
clearly.
Ball moving direction
2nd Curtain: The ash res just
before the shutter closes. The
camera captures a photo of a
subject later in an action sequence
clearly.
Ball moving direction
•
The available options may dier depending on shooting conditions.
•
There is an interval between two bursts of the ash. Do not move until the
ash res a second time.
•
If you select O, the ash does not re even when an external ash is
attached.
Use only Samsung-approved ashes. Using incompatible ashes may damage
your camera.
102
Shooting Functions > Flash
Adjusting the ash intensity
When the ash is on, adjust the ash intensity +/-2 levels.
To set the ash
intensity,
In Shooting mode, touch
→
Flash
→
an option
→
→
Drag the slider or touch +/- to adjust the intensity
→
touch
.
Flash : 0
Reducing the red-eye eect
If the ash res when you capture a photo of a person in the dark, a red
glow may appear in the eyes. To reduce the red-eye eect, select Auto
Red-eye or Fill-in Red.
Without red-eye reduction With red-eye reduction
If the subject is too far from the camera or moves when the rst ash res, red-
eyes may not be reduced.
103
Shooting Functions > Flash
•
You can also touch
→
1
→
Flash
→
an option
→
, in
Shooting mode to access the ash intensity menu.
•
Adjusting the flash intensity may not be eective when:
-
the subject is too close to the camera
-
you set a high ISO sensitivity
-
the exposure value is too big or too small
•
In some shooting modes, you cannot use this function.
•
If you attach an intensity-adjustable external ash to the camera, the intensity
settings of the ash will be applied.
•
If the subject is too close when you use the ash, some light may be blocked,
resulting in a dark photo. Ensure that the subject is within the recommended
range, which varies by lens.
•
When a lens hood is attached, the light from the ash can be blocked by the
hood. Remove the hood to use the ash.
Shooting Functions
104104
Sh
ooting FunctionsShooting Functions
The camera automatically sets the exposure by measuring the levels of
light from the photo’s composition and the position of a subject. If the
exposure set by the camera is higher or lower than you expected, you can
adjust the exposure value manually. The exposure value is adjustable in ±3
increments. The camera displays the exposure warning in red for each step
beyond ±3 range.
To adjust the exposure value, press the command dial twice, and then
rotate it while the exposure value is selected. You can also adjust the
exposure value by touching
→
EV, and then dragging the dial on
the screen.
You can check the exposure value by the position of the exposure level
indicator.
Exposure level
indicator
Increased exposure
(brighter)
Decreased exposure
(darker)
Exposure warning
Standard exposure index
-2
Original
+2
Exposure compensation
Shooting Functions
105105
Sh
ooting FunctionsShooting Functions
When you cannot achieve an appropriate exposure because of a strong
color contrast, lock the exposure, and then capture a photo.
To lock the exposure value, adjust the photo’s exposure, and then touch
the custom button.
After locking the exposure, aim the lens where you desire, and then press
[Shutter].
•
Set a function of the custom button to AEL to lock the current exposure
value. (p. 150)
•
This feature is not available in Manual mode.
Exposure lock
Shooting Functions
106106
Sh
ooting FunctionsShooting Functions
The functions available for video are explained below.
Movie size
Set the movie size.
To set movie size
options,
In Shooting mode, touch
→
6
→
Movie Size
→
an option.
Icon Size Recommended for
1920X1080 (30 fps) (16:9) View on a Full HDTV.
1920X1080 (15 fps) (16:9)
View on a Full HDTV. (Available only
with some Smart Filter options.)
1920X810 (24 fps)
(Approx. 2.35:1)
View on an HDTV.
1280X720 (60 fps) (16:9) View on an HDTV.
1280X720 (30 fps) (16:9) View on an HDTV.
640X480 (30 fps) (4:3) View on a TV.
320X240 (30 fps) (4:3)
Post on a website using the wireless
network (30 seconds maximum).
Movie quality
Set the Movie quality.
To set movie
quality options,
In Shooting mode, touch
→
6
→
Movie Quality
→
an option.
Icon Extension Description
MP4 (H.264) Normal: Record videos in normal quality.
MP4 (H.264) HQ: Record videos in high quality.
Video functions
107
Shooting Functions > Video functions
Multi Motion
Set the playing speed of a video.
To set playing
speed options,
In Shooting mode, touch
→
6
→
Multi Motion
→
an option.
Icon Description
x0.25: Record a video and play it at 1/4 normal speed. (Available
only with 640x480 or 320x240)
x0.5: Record a video and play it at 1/2 normal speed. (Available
only with 1280x720 (30 fps), 640x480, or 320x240)
x1: Record a video and play it at normal speed.
x5: Record a video and play it at 5X normal speed.
x10: Record a video and play it at 10X normal speed.
x20: Record a video and play it at 20X normal speed.
•
If you select an option other than x1, sound will not be recorded.
•
The available options may dier depending on shooting conditions.
Fader
You can fade in or fade out a scene using the fader function on the camera
without having to do it on a PC. Set the fade in option to gradually fade in
at the start of the scene. Set the fade out option to gradually fade out the
scene. Use the function appropriately and add dramatic eects on your
videos.
To set fader
options,
In Shooting mode, touch
→
6
→
Fader
→
an option.
Icon Description
O: Fader function not used.
In: Scene gradually fades in.
Out: Scene gradually fades out.
In-out: The fader function is applied at the start and end of the
scene.
When you use the fader function, it may take longer to save a le.
108
Shooting Functions > Video functions
Voice
Sometimes, a muted video is more appealing than the one with sound.
Turn the voice o to record a muted video.
To set voice
options,
In Shooting mode, touch
→
6
→
Voice
→
an option.
Wind cut
When you record videos in noisy environments, unintended sounds can
be recorded in videos. In particular, severe wind noise recorded in videos
distracts you from enjoying your videos. Use the Wind Cut function to
remove some surrounding noise in addition to wind noise.
To reduce wind
sound,
In Shooting mode, touch
→
6
→
Wind Cut
→
an option.
Chapter 3
Playback/Editing
Learn about how to play back and edit photos and videos.
Refer to chapter 6 for editing les on a PC.
110
Playback/Editing
Learn how to view photo and video thumbnails and how to protect or
delete les.
If you perform no operations for a while, information and icons on the screen
disappear. When you operate the camera again, they will reappear.
Viewing photos
1
Press [z].
•
The most recent le you captured will be displayed.
2
Drag the image left or right to scroll through les.
You may not be able to edit or play back les that were captured with other
cameras, due to unsupported sizes or codecs. Use a computer or another device
to edit or play back these les.
Viewing image thumbnails
In order to search for photos and videos you want, convert to the
thumbnail view. The thumbnail view displays multiple images at a time
so that you can easily look through items you wish to nd. You can also
classify and display les by category, such as date, le type or location.
Rotate the command dial to select the thumbnail view mode.
Searching and managing les
111
Playback/Editing > Searching and managing les
Viewing les by category
1
In the thumbnail view, touch
→
z
→
Filter
→
a category.
•
You can also touch to select a category.
* Default
Option Description
All*
View les normally.
Date
View les by the date they were saved.
Type
View les by the le type.
Location
View les by the place they were saved. (Only the
photos captured with an optional GPS module have
the location information.)
2
Touch a list to open it.
3
Touch a le to view in the single image view.
4
Touch to return to the previous view.
Viewing les as a folder
Continuous and burst shots appear as a folder. Selecting a folder will play
back all photos automatically. Deleting a folder will delete all photos in the
folder.
1
In Playback mode, drag the image left or right to move to a
desired folder.
•
The camera will automatically play back photos in the folder.
2
Touch the folder on the screen to open the folder.
3
Drag the image left or right to move to another le.
4
Touch to return to Playback mode.
112
Playback/Editing > Searching and managing les
Protecting les
Protect your les from accidental deletion.
1
In Playback mode, touch
→
z
→
Protect
→
Select.
2
Touch / to scroll to a le, and then touch the check box.
•
Touch the check box again to cancel your selection.
3
Touch .
You cannot delete a protected le.
Lock/Unlock all les
Lock or unlock all les.
1
In Playback mode, touch
→
z
→
Protect
→
All.
2
Touch an option.
Option Description
Lock
Lock all les.
Unlock
Unlock all les.
Cancel
Return to the previous menu.
113
Playback/Editing > Searching and managing les
Deleting les
Delete les in Playback mode and secure more space on your memory
card. Protected les are not deleted.
Deleting a single le
You can select a single le and delete it.
1
In Playback mode, select a le, and then touch .
2
When the pop-up message appears, touch Ye s .
Deleting multiple les
You can select multiple les and delete them.
1
In Playback mode, touch
→
z
→
Delete
→
Select.
•
Alternatively, in thumbnails view, touch and then select les
to delete.
2
Touch / to scroll to a le, and then touch the check box.
•
Touch the check box again to cancel your selection.
3
Touch .
4
When the pop-up message appears, touch Ye s .
Deleting all les
You can delete all les on the memory card at once.
1
In Playback mode, touch
→
z
→
Delete
→
All.
2
When the pop-up message appears, touch Ye s .
114
Playback/Editing
Enlarging a photo
You can enlarge photos when viewing them in Playback mode. You can
also use the Trim function to extract the portion of the image displayed on
the screen and save it as a new le.
Magnied area
Drag the screen to see another part
of the photo.
Rotate the command dial to enlarge a photo.
Icon Description
Return to the original view.
Crop the photo (the camera will save it as a new le).
You can also pinch your ngers together or spread them apart on the screen
to reduce or enlarge a photo. The screen responds more slowly than when you
use the command dial.
Viewing a slide show
You can view photos in a slide show, apply various eects to the slide
show, and play background music.
1
In Playback mode, touch
→
z
→
Slide Show Options.
2
Select a slide show eect option.
•
Skip to step 3 to start a slide show with no eects.
* Default
Option Description
Play Mode
Set whether or not to repeat the slide show.
(One Play*, Repeat)
Interval
Set the interval between photos. (1 sec*, 3 sec, 5 sec,
10 sec)
Music
Set background audio.
Eect
• Set a scene change eect between photos.
• Touch O to cancel eects.
Viewing photos
115
Playback/Editing > Viewing photos
3
Touch .
4
Touch Start Slide Show.
5
View the slide show.
•
Touch to pause.
•
Touch again to resume.
•
Touch to stop the slide show and return to Playback mode.
•
Touch to adjust the volume level.
Auto rotating
With Auto Rotate on, the camera automatically rotates photos you have
captured vertically so they t the screen horizontally.
To set auto rotate
options,
In Playback mode, touch
→
z
→
Auto Rotate
→
an option.
Creating a print order (DPOF)
DPOF (Digital Print Order Format) lets you set the number of copies to be
printed.
The camera saves the DPOF information in the MISC folder of your memory
card. If you have set DPOF information for your images, you can take the
memory card to a digital printing shop for printing. You cannot set the
print order of RAW format les.
Photos with dimensions that are wider than the paper may be cut o
on the left and right edges. Ensure that your photo dimensions are
compatible with the paper you select.
1
In Playback mode, select a photo, and then touch .
2
Touch z
→
DPOF.
3
Touch / to set the number of copies.
•
To select another photo, touch / .
4
Touch .
116
Playback/Editing
In Playback mode, you can play a video, capture an image from a video, or
crop a video to save as another le.
Video viewing controls
Icon Description
/
View previous le/Scan backward. (Each time you touch the
icon while playing the video, you change the scan speed in
this order: 2X, 4X, 8X.)
/
Pause or resume playback.
Stop playback and return to the previous screen.
/
View next le/Scan forward. (Each time you touch the icon
while playing the video, you change the scan speed in this
order: 2X, 4X, 8X.)
Adjust the volume or mute the sound.
You can also pinch your ngers together or spread them apart on the screen to
reduce or enlarge a photo. Rotate again to scan more quickly (2X, 4X, 8X).
Trimming a video during playback
1
In Playback mode, scroll to a video, and then touch .
2
Touch to start playing the video.
3
Touch at the point where you want the trimming to begin.
4
Touch .
5
Touch to resume playing the video.
6
Touch at the point where you want the trimming to end.
7
Touch .
8
Touch to trim a video.
•
You can adjust the scene to be cropped by dragging the handles
that appear on the progress bar.
9
When the pop-up message appears, touch Ye s .
•
You cannot trim a video recorded in 3D mode.
•
The original video should be at least 10 seconds long.
•
The camera will save the edited video as a new le and leave the original
video intact.
Playing videos
117
Playback/Editing > Playing videos
Capturing an image during playback
1
While viewing a video, touch at the point where you want to
capture an image.
2
Touch .
•
You cannot capture an image from a video recorded in 3D mode.
•
The resolution of the captured image will be the same as the original video.
•
The captured image is saved as a new le.
118
Playback/Editing
Perform photo editing tasks, such as resizing, rotating, or reducing red-eye
eects. Edited photos are saved as new les under dierent le names.
Photos captured in some modes cannot be edited with the Image Edit
function.
To edit images,
In Playback mode, scroll to a photo, and then touch .
•
You can also edit images in Playback mode by selecting a photo, and then
touching
→
Edit Image.
•
Some images may not be edited with the Image Edit function. In this case, use
a supplied image editing software.
•
The camera will save edited photos as new les.
•
When you edit photos, the camera will automatically convert them to a lower
resolution. Photos that you rotate or resize manually are not automatically
converted to a lower resolution.
•
You cannot edit photos while viewing les as a folder. Open the folder and
select a photo to edit each photo.
Cropping a photo
1
Touch
→
.
2
Drag the corners of the box to adjust the size of the area.
3
Drag the box to move the location of the area.
4
Touch .
5
Touch to save.
Editing photos
119
Playback/Editing > Editing photos
Rotating a photo
1
Touch
→
.
2
Touch an option.
Rotate : Right 90°
3
Touch .
4
Touch to save.
•
You can also rotate a photo in Playback mode by touching
→
z
→
Rotate
→
a desired option
→
.
•
The camera will overwrite the original le.
Resizing photos
Change the size of a photo and save it as a new le.
1
Touch
→
.
2
Touch an option.
Resize : 10.1M 3:2
3
Touch .
4
Touch to save.
Available resize options dier depending on the original size of the photo.
120
Playback/Editing > Editing photos
Adjusting your photos
You can correct captured photos by adjusting the brightness, contrast, or
saturation.
1
Touch .
2
Touch an option.
Option Description
Original
Original (Reset to the original image)
Auto adjustment
Adjust brightness, contrast, or saturation
automatically
Brightness
Adjust brightness
Contrast
Adjust contrast
Saturation
Adjust saturation
RGB adjustment
Adjust RGB values
Color Temperature
Adjust color temperature
Exposure
Adjust exposure
Hue
Adjust hues
3
Drag the slider or touch +/- to adjust the option.
•
If you selected Auto adjustment, skip to step 4.
4
Touch .
5
Touch to save.
121
Playback/Editing > Editing photos
Retouching faces
1
Touch
→
.
2
Drag the slider or touch +/- to adjust the option.
•
As the number increases, the skin tone becomes brighter and
smoother.
3
Touch .
•
To cancel correction, touch .
4
Touch to save.
Reducing red-eye
1
Touch
→
.
2
Touch .
•
To cancel correction, touch .
3
Touch to save.
122
Playback/Editing > Editing photos
Applying Smart Filter eects
Apply special eects to your photos.
1
Touch
→
an option.
Smart Filter : Vignetting
Option Description
O
No eect
Vignetting
Apply the retro-looking colors, high contrast,
and strong vignette eect of Lomo cameras.
Miniature
Apply a tilt-shift eect to make the subject
appear in miniature.
Colored Pencil
Apply a colored pencil painting eect.
Watercolor
Apply a watercolor painting eect.
Wash drawing
Apply a washed-out eect.
Option Description
Oil Sketch
Apply oil sketching eect.
Ink Sketch
Apply ink sketching eect.
Acryl
Apply an acryl painting eect.
Negative
Apply a negative lm eect.
Red
Desaturate all colors but red.
Green
Desaturate all colors but green.
Blue
Desaturate all colors but blue.
Yellow
Desaturate all colors but yellow.
2
Touch .
3
Touch to save.
Chapter 4
Wireless network
Learn how to connect to wireless local area networks (WLANs) and use functions.
124
Wireless network
Connecting to a WLAN and conguring network settings
Learn to connect via an access point (AP) when you are in a range of a
WLAN. You can also congure network settings.
Connecting to a WLAN
1
On the Mode screen, touch Wi-Fi
→
Auto Backup, Email,
SNS & Cloud, or Samsung Link.
2
Touch
→
Wi-Fi Setting.
•
In some modes, follow the on-screen instructions until the Wi-Fi
Setting screen appears.
•
The camera automatically searches for available AP devices.
3
Touch an AP.
Refresh
Samsung1
Samsung2
Samsung3
Samsung4
•
Touch Refresh to refresh connectable APs.
•
Touch Add wireless network to add an AP manually. Your AP name
must be in English to add the AP manually.
Icon Description
Ad hoc AP
Secured AP
WPS AP
Signal strength
Open network setting options.
•
When you select a secured AP, a pop-up window appears. Enter the
required passwords to connect to the WLAN. For information about
entering text, refer to "Entering text". (p. 127)
•
When a login page appears, refer to "Using the login browser".
(p. 125)
•
When you select an unsecured AP, the camera will connect to the
WLAN.
•
If you select a WPS prole supported AP, touch
→
WPS PIN
connection, and then enter a PIN on the AP device. You can also
connect to a WPS prole supported AP by touching
→
WPS
button connection on the camera, and then pushing the WPS
button on the AP device.
125
Wireless network > Connecting to a WLAN and conguring network settings
Setting network options
1
In the Wi-Fi Setting screen, move to an AP, and then touch .
2
Select each option, and then enter the required information.
Option Description
Network Password
Enter the network password.
IP Setting
Set the IP address automatically or manually.
Manually setting the IP address
1
In the Wi-Fi Setting screen, move to an AP, and then touch .
2
Touch IP Setting
→
Manual.
3
Select each option, and then enter the required information.
Option Description
IP
Enter the static IP address.
Subnet Mask
Enter the subnet mask.
Gateway
Enter the gateway.
DNS Server
Enter the DNS address.
Using the login browser
You can enter your login information via the login browser when
connecting to some APs, sharing sites, or cloud servers.
Icon Description
Close the login browser.
Move to the previous page.
Move to the next page.
Stop loading the page.
Reload the page.
•
You may not be able to select some items depending on the page you
connected to. This does not indicate a malfunction.
•
The login browser may not close automatically after you log into some pages.
If this occurs, close the login browser by touching
, and then proceed
with the desired operation.
•
It may take longer to load the login page due to the page size or network
speed. If this occurs, wait until the login information input window appears.
126
Wireless network > Connecting to a WLAN and conguring network settings
Network connection tips
•
You must insert a memory card to use the Wi-Fi features.
•
The quality of the network connection will be determined by the AP.
•
The further the distance between your camera and the AP, the longer it
will take to connect to the network.
•
If a nearby device is using the same radio frequency signal as your
camera, it may interrupt your connection.
•
If your AP name is not in English, the camera may not be able to locate
the device or the name may appear incorrectly.
•
For network settings or a password, contact your network administrator
or network service provider.
•
If a WLAN requires authentication from the service provider, you may
not be able to connect to it. To connect the WLAN, contact your network
service provider.
•
Depending on the encryption type, the number of digits in the password
may dier.
•
A WLAN connection may not be possible in all surroundings.
•
The camera may display a WLAN enabled printer on the AP List. You
cannot connect to a network via a printer.
•
You cannot connect your camera to a network and a TV simultaneously.
•
Connecting to a network may incur additional charges. Costs will vary
based on the conditions of your contract.
•
If you cannot connect to a WLAN, try another AP from the available AP
list.
•
A login page may appear when you select free WLANs provided by some
network service providers. Enter your ID and password to connect to
the WLAN. For information about registering or the service, contact the
network service providers.
•
Be cautious when you enter personal information for an AP connection.
Do not enter any payment or credit card information on your camera.
The manufacturer is not liable for any problem caused by entering such
information.
•
Available network connections may dier by country.
•
The WLAN feature of your camera must comply with radio transmission
laws in your region. To ensure compliance, use the WLAN feature only in
the country where you purchased the camera.
•
The process for adjusting network settings may dier, depending on
network conditions.
•
Do not access a network that you are not authorized to use.
•
Before you connect to a network, ensure your battery is fully charged.
•
You cannot upload or send les captured in some modes.
•
Files that you transfer to another device may not be supported by the
device. In this case, use a computer to play back the les.
127
Wireless network > Connecting to a WLAN and conguring network settings
Entering text
Learn how to enter text. The icons in the table let you move the cursor,
change the case, etc. Touch a key to enter it.
Icon Description
Move the cursor.
Stop entering text and return to the previous page.
Change case.
Switch between Symbol/Number mode and the normal mode.
Change the input language.
Enter a space.
Save the displayed text.
Delete the last letter.
•
You can use only the English alphabets in some modes, regardless of the
display language.
•
You can enter up to 64 characters.
•
The screen may dier depending on the input mode.
•
Touch and hold a key to enter the character at the upper right corner of the
key.
128
Wireless network
Saving les to a smart phone automatically
The camera connects to a smart phone that supports the AutoShare
feature via a WLAN. When you capture a photo with your camera, the
photo is saved to the smart phone automatically.
•
The AutoShare feature is supported by Galaxy series smart phones, Galaxy
Tab models, or iOS devices. Before using this feature, update the device’s
rmware to the latest version. If the rmware version is not the most recent,
this function may not perform properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
To install and launch Samsung SMART CAMERA App on an NFC-enabled
smart phone, turn on the NFC feature and place the smart phone near an
NFC tag (p. 29) on the camera. This feature is supported by smart phones
running Android OS 2.3 or higher. This feature is not available for iOS devices.
•
You must insert a memory card to use this feature.
•
If you set this function, the setting is maintained even when you change the
Shooting mode.
•
This feature may not be supported in some modes or may not be available
with some shooting options.
1
On the camera, in Shooting mode, touch .
2
On the camera, touch 1
→
AutoShare
→
On.
•
If the pop-up message that prompts you to download the
application appears, touch Next.
3
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 29) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 6.
4
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
5
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
•
An icon that shows the connection status ( ) will appear on the
camera’s screen.
6
On the camera, capture a photo.
•
The captured photo is saved to the camera, and then transferred to
the smart phone.
•
If you recorded a video, it is saved only to the camera.
129
Wireless network
The camera connects to a smart phone that supports the MobileLink
feature via a WLAN. You can easily send photos or videos to your smart
phone.
•
The MobileLink feature is supported by Galaxy series smart phones, Galaxy
Tab models, or iOS devices. Before using this feature, update the device’s
rmware to the latest version. If the rmware version is not the most recent,
this function may not perform properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
To install and launch Samsung SMART CAMERA App on an NFC-enabled
smart phone, turn on the NFC feature and place the smart phone near an NFC
tag (p. 29) on the camera. This feature is supported by smart phones running
Android OS 2.3 or higher. This feature is not available for iOS devices.
•
When there are no les in the camera memory, you cannot use this feature.
•
If you select les from the smart phone, you can view up to 1,000 recent les
and send up to 150 les at a time. If you select les from the camera, you can
view les that were selected from the camera. The maximum number of les
that can be sent varies depending on the storage space of the smart phone.
•
When you send Full HD videos using MobileLink feature, you may not be able
to play back les on some devices.
•
When using this feature on an iOS device, the device may lose its Wi-Fi
connection.
•
You cannot send RAW les.
1
On the Mode screen, touch Wi-Fi
→
MobileLink.
•
If the pop-up message that prompts you to download the
application appears, touch Next.
2
On the camera, touch a sending option.
•
If you select Select Files from Smartphone, you can use your
smart phone to view and share les stored on the camera.
•
If you select Select Files from Camera, you can select les to send
from the camera.
3
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 29) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 6.
Sending photos or videos to a smart phone
130
Wireless network > Sending photos or videos to a smart phone
4
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
5
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
6
On the smart phone or camera, select les to transfer from the
camera.
7
On the smart phone, touch the copy button or on the camera,
touch Send.
•
The camera will send the les.
131
Wireless network
The camera connects to a smart phone that supports the Remote
Viewnder feature via a WLAN. Use the smart phone as a remote shutter
release with the Remote Viewnder feature. The captured photo will
display on the smart phone.
•
The Remote Viewnder feature is supported by Galaxy series smart phones,
Galaxy Tab models, or iOS devices. Before using this feature, update the
device’s rmware to the latest version. If the rmware version is not the most
recent, this function may not perform properly.
•
You should install Samsung SMART CAMERA App on your phone or device
before using this feature. You can download the application from Samsung
Apps, the Google Play Store, or the Apple App Store. Samsung SMART
CAMERA App is compatible with Samsung camera models manufactured in
2013 or later.
•
To install and launch Samsung SMART CAMERA App on an NFC-enabled
smart phone, turn on the NFC feature and place the smart phone near an NFC
tag (p. 29) on the camera. This feature is supported by smart phones running
Android OS 2.3 or higher. This feature is not available for iOS devices.
•
This function is not available in 3D mode.
1
On the Mode screen, touch Wi-Fi
→
Remote Viewnder.
•
If the pop-up message that prompts you to download the
application appears, touch Next.
2
On the smart phone, turn on Samsung SMART CAMERA App.
•
For iOS devices, turn on the Wi-Fi feature before turning on the
application.
•
To start the application automatically on an NFC-enabled smart
phone, turn on the function and place the smart phone near
the NFC tag (p. 29) on the camera. Verify that the smart phone is
connected to your camera, and then skip to step 5.
3
Select the camera from the list and connect the smart phone
to the camera.
•
The smart phone can connect to only one camera at a time.
Using a smart phone as a remote shutter release
132
Wireless network > Using a smart phone as a remote shutter release
4
On the camera, allow the smart phone to connect to your
camera.
•
If the smart phone has been connected to your camera before, it is
connected automatically.
5
On the smart phone, set the following shooting options.
Icon Description
Flash option
Timer option
Photo size
*
Storage location
Switches between VGA and QVGA
•
While using this feature, some buttons are not available on your
camera.
•
The zoom button and the shutter button on your smart phone will
not function when using this feature.
•
Remote Viewnder mode supports the and
2.1
photo sizes
only.
* For iOS devices, only the storage location option is available.
6
On the smart phone, touch and hold to focus.
•
The focus is automatically set to Multi AF.
•
You can touch the area on the screen where you want to focus.
7
Release to capture the photo.
•
Photos saved to the smart phone will be resized to 1616X1080
when shooting in
and to 1920X1080 when shooting in
2.1
resolution.
•
When you use this feature, the ideal distance between the camera and the
smart phone may vary, depending on your surroundings.
•
The smart phone must be within 7 m of the camera to use this feature.
•
It will take some time to capture the photo after you release on the smart
phone.
•
The Remote Viewnder function will deactivate when:
-
there is an incoming call on the smart phone
-
either the camera or the smart phone turns o
-
the memory is full
-
device loses its connection to the WLAN
-
the Wi-Fi connection is poor or unstable
-
you perform no operations for approximately 5 minutes while connected
133
Wireless network
Using Auto Backup to send photos or videos
You can send photos or videos that you captured with the camera to a PC
wirelessly.
Installing the program for Auto Backup on
your PC
1
Install i-Launcher on the PC. (p. 163)
2
Connect the camera to the PC with the USB cable.
3
When the Auto Backup program icon appears, click it.
•
The Auto Backup program is installed on the PC and the
information about the PC will be stored to the camera. Follow the
on-screen instructions to complete the installation.
•
You can also save the information about the PC to the camera by
connecting the PC and the camera via Wi-Fi.
4
Disconnect the camera from the PC.
Before installing the program, ensure that the PC is connected to a network.
If no internet connection is available, you must install the program from the
provided CD.
Sending photos or videos to a PC
1
On the Mode screen, touch Wi-Fi
→
Auto Backup.
•
If the pop-up message that prompts you to download the
application appears, touch Next.
•
You must congure the backup PC information to use the Auto
Backup feature. For more details, refer to "Installing the program
for Auto Backup on your PC". (p. 133) If the Auto Backup program is
installed on your PC, save the PC information via USB cable or Wi-Fi
connection.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
2
Select a backup PC.
•
If you have performed a backup before, move to the next step.
134
Wireless network > Using Auto Backup to send photos or videos
3
Touch OK.
•
To cancel sending, touch Cancel.
•
You cannot select individual les to backup. This function backs up
only new les on the camera.
•
The backup's progress will be shown on the PC monitor.
•
When the transfer is completed, the camera will turn o
automatically in approximately 30 seconds. Touch Cancel to return
to the previous screen and prevent the camera from turning o
automatically.
•
To turn o your PC automatically after the transfer is complete,
touch Shut down PC after backup.
•
To change the backup PC, select .
•
When you connect the camera to the WLAN, select the AP that is connected
to the PC.
•
The camera will search for available access points even if you are connecting
to the same access point again.
•
If you turn o the camera or remove the battery while sending les, the le
transfer will be interrupted.
•
While you are using this feature, the shutter control is disabled on your
camera.
•
You can connect only one camera to the PC at a time for sending les.
•
The backup may be canceled due to network conditions.
•
Photos or videos can be sent to a PC one time only. Files cannot be sent again
even if you reconnect your camera to another PC.
•
When there are no les in the camera memory, you cannot use this feature.
•
You must turn o Windows Firewall and any other rewalls before using this
feature.
•
You can send up to 1,000 recent les.
•
On the PC software, the server name must be entered in the Latin alphabet
and can contain no more than 48 characters.
•
When multiple le types are created at once, only the image les (JPG) will be
sent to the PC with this feature.
135
Wireless network
4
Touch the Name box, enter your name, and then touch .
Sender Setting
Name
Save
Email
Reset
5
Touch the Email box, enter your email address, and then
touch
.
6
Touch Save to save your changes.
•
To delete your information, touch Reset.
You can change settings in the email menu and send photos or videos
stored on the camera via email.
Changing email settings
In the email menu, you can change settings for storing your information.
You can also set or change the email password. For information about
entering text, refer to "Entering text". (p. 127)
Storing your information
1
On the Mode screen, touch Wi-Fi
→
Email.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
2
Touch .
3
Touch Sender Setting.
Sending photos or videos via email
136
Wireless network > Sending photos or videos via email
Setting an email password
1
On the Mode screen, touch Wi-Fi
→
Email.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
2
Touch .
3
Touch Setting Password
→
On.
•
To deactivate the password, touch O.
4
When the pop-up appears, touch OK.
5
Enter a 4-digit password.
6
Enter the password again.
7
When the pop-up appears, touch OK.
If you lost your password, you can reset it by touching Reset on the password
setting screen. When you reset the information, the previously saved user’s
setting information, email address, and recently sent email list will be deleted.
137
Wireless network > Sending photos or videos via email
Changing the email password
1
On the Mode screen, touch Wi-Fi
→
Email.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
2
Touch .
3
Touch Change Password.
4
Enter your current 4-digit password.
5
Enter a new 4-digit password.
6
Enter the new password again.
Sending photos or videos via email
You can send photos or videos stored on the camera via email. For
information about entering text, refer to "Entering text". (p. 127)
1
On the Mode screen, touch Wi-Fi
→
Email.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
2
Touch the Sender box, enter your email address, and then
touch
.
•
If you have previously saved your information, it will be inserted
automatically. (p. 135)
•
To use an address from the list of previous senders, touch
→
an address.
138
Wireless network > Sending photos or videos via email
3
Touch the Receiver box, enter an email address, and then
touch
.
•
To use an address from the list of previous recipients, touch
→
an address.
•
Touch to add additional recipients. You can input up to
30 recipients.
•
Touch to delete an address from the list.
4
Touch Next.
5
Select les to send.
•
You can select up to 20 les. The total size must be 7 MB or less.
6
Touch Next.
7
Select the comment box, enter your comments, and then
touch
.
8
Touch Send.
•
The camera will send the email.
•
Even if a photo appears to have transferred successfully, errors with the
recipient’s email account may cause the photo to be rejected or recognized
as spam.
•
You may not be able to send an email if no network connection is available or
if your email account settings are incorrect.
•
You cannot send an email if the le size exceeds the limit. The maximum
photo resolution you can send is 2M and the longest video you can upload is
a video recorded using
. If the selected photo resolution is higher than 2M,
it will be automatically resized to a lower resolution.
•
If you cannot send an email because of rewall or user authentication
settings, contact your network administrator or network service provider.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can also send an email in Playback mode by touching
→
Share(Wi-Fi)
→
Email.
139
Wireless network
Upload your photos or videos to le sharing websites. Available websites
will be displayed on your camera. To upload les to some websites, you
must visit the website and register before connecting your camera.
Accessing a website
1
On the Mode screen, touch Wi-Fi
→
SNS & Cloud.
2
Select a website.
•
If the pop-up message that prompts you to create an account
appears, touch OK.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN,
it will search for available AP devices. (p. 124)
3
Enter your ID and password to log in.
•
For information about entering text, refer to "Entering text".
(p. 127)
•
If you connected to SkyDrive, refer to "Using the login browser".
(p. 125)
•
To select an ID from the list, touch
→
an ID.
•
If you have previously logged in to the website, you may be logged
in automatically.
You must have an existing account on the le sharing website to use this feature.
Using photo or video sharing websites
140
Wireless network > Using photo or video sharing websites
Uploading photos or videos
1
Access the website with your camera.
2
Select les to upload.
•
You can select up to 20 les. The total size must be 10 MB or less.
(On some websites, the total size or number of les may vary.)
3
Touch Upload.
•
On some websites, you can enter your comments by touching
the comment box. For information about entering text, refer to
"Entering text". (p. 127)
•
You can set an upload folder for Facebook by touching
→
Upload
Folder (Facebook) on the website's list screen.
•
You cannot upload les if the le size exceeds the limit. The maximum photo
resolution you can upload is 2M, and the longest video you can upload is a
video recorded using
. If the selected photo resolution is higher than 2M,
it will be automatically resized to a lower resolution. (On some websites, the
maximum photo resolution may vary.)
•
The method of uploading photos or videos may dier depending on the
selected website.
•
If you cannot access a website because of rewall or user authentication
settings, contact your network administrator or network service provider.
•
Uploaded photos or videos may be automatically titled with the date they
were captured.
•
The speed of your internet connection may aect how quickly photos upload
or web pages open.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can also upload photos or videos to le sharing websites in Playback
mode by touching
→
Share(Wi-Fi)
→
a desired website.
•
You cannot upload videos to some websites.
•
When you upload photos to SkyDrive, they will be resized to 2M while
maintaining their aspect ratios.
141
Wireless network
Using Samsung Link to send les
You can upload les from your camera to Samsung Link online storage or
view les on a Samsung Link device connected to the same AP.
Uploading photos to online storage
1
On the Mode screen, touch Wi-Fi
→
Samsung Link
→
Web
storage.
•
If the guide message appears, touch OK.
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
•
To change the size for uploaded photos, touch
→
Upload
Image Size.
•
If you have registered more than one web storage, you can select
from the list by touching
→
Change Web storage.
2
Enter your ID and password, and then touch Login
→
OK.
•
For information about entering text, refer to "Entering text". (p. 127)
•
To select an ID from the list, touch
→
an ID.
•
If you have previously logged in to the website, you may be logged
in automatically.
To use this feature, you must create a Samsung Link account and an
account with an aliated online storage service using your PC. After
nishing creating accounts, add your online storage account to Samsung
Link.
3
Select les you want to upload, and then touch Upload.
•
If you have registered more than one web storage, select a web storage rst.
•
You cannot upload video les to Samsung Link online storage.
•
When there are no les in the camera memory, you cannot use this feature.
•
You can upload up to 20 les.
•
You can also upload photos in Playback mode by touching
→
Share(Wi-Fi)
→
Samsung Link.
142
Wireless network > Using Samsung Link to send les
Viewing photos or videos on devices that
support Samsung Link
1
On the Mode screen, touch Wi-Fi
→
Samsung Link
→
Nearby
devices.
•
If the guide message appears, touch Ye s .
•
The camera will automatically attempt to connect to a WLAN via
the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN, it will
search for available AP devices. (p. 124)
•
You can set to allow only selected devices or all devices to connect
by touching
→
DLNA Access Control on the screen.
•
A sharing le list is created. Wait until other devices can nd your
camera.
2
Connect the Samsung Link device to a network, and then turn
on the Samsung Link feature.
•
Refer to your device's user manual for more information.
3
On the camera, allow the Samsung Link device to connect to
your camera.
4
On the Samsung Link device, select a camera to connect.
5
On the Samsung Link device, browse the shared photos or
videos.
•
For information about searching for the camera and browsing the
photos or videos on the Samsung Link device, refer to the device's
user manual.
•
Videos may not play smoothly depending on the type of Samsung
Link device or the network condition.
AP
S
A camera is connected to a TV that supports Samsung Link via WLAN.
143
Wireless network > Using Samsung Link to send les
•
You can share up to 1,000 recent les.
•
On a Samsung Link device, you can view only photos or videos captured with
your camera.
•
The range of the wireless connection between your camera and a Samsung
Link device may vary depending on the specications of the AP.
•
If the camera is connected to 2 Samsung Link devices, playback may be
slower.
•
Photos or videos will be shared in their original sizes.
•
You can use this feature only with devices that support Samsung Link.
•
Shared photos or videos will not be stored on the Samsung Link device, but
they can be stored in the camera to meet the device's specications.
•
Transferring photos or videos to the Samsung Link device may take some
time depending on the network connection, the number of les to be shared,
or the sizes of the les.
•
If you power o the camera abnormally while viewing photos or videos on
a Samsung Link device (for example, by removing the battery), the device
considers the camera to still be connected.
•
The order of photos or videos on the camera may be dierent than on the
Samsung Link device.
•
Depending on the number of photos or videos you want to share, it may
take some time to load your photos or videos and complete the initial set-up
process.
•
While viewing photos or videos on the Samsung Link device, continuously
using the device's remote or performing additional operations on the device
may prevent this feature from working properly.
•
If you reorder or sort les on the camera while viewing them on a Samsung
Link device, you must repeat the initial set-up process to update the list of
les on the device.
•
When there are no les in the camera memory, you cannot use this feature.
•
We recommend you use a network cable to connect your Samsung
Link device to your AP. This will minimize any video ‘Stuttering’ you may
experience when streaming content.
•
To view les on a Samsung Link device using the Nearby devices feature,
enable multicast mode on your AP.
•
You can view 3D les only on 3D-compatible TVs or monitors.
144
Wireless network
Sending photos using Wi-Fi Direct
When the camera connects via a WLAN to a device that supports the Wi-Fi
Direct function, you can send photos to the device. This feature may not be
supported on some devices.
1
On the device, turn on the Wi-Fi Direct option.
2
On the camera, in Playback mode, scroll to a photo.
3
Touch
→
Share(Wi-Fi)
→
Wi-Fi Direct.
•
When in the single image view, you can send only one photo at a
time.
•
When in thumbnails view, you can select multiple photos. Touch
Upload when you are nished selecting photos.
4
Select the device from the camera’s list of Wi-Fi Direct devices.
•
Ensure that the device's Wi-Fi Direct option is turned on.
•
You can also select your camera from the device's list of Wi-Fi Direct
devices.
5
On the device, allow the camera to connect to the device.
•
The photo will be sent to the device.
•
You can send up to 20 les at a time.
•
When there are no photos in the camera memory, you cannot use this
feature.
•
If you cannot connect to a Wi-Fi Direct device, update the device with the
latest rmware. This feature may not be supported on some devices.
Chapter 5
Camera settings menu
Learn about the user settings and general settings menu.
You can adjust the settings to better suit your needs and preferences.
146
Camera settings menu
You can set the user environment with these settings.
To set user options,
In Shooting mode, touch
→
5
→
an option.
Available items and the order of them may dier depending on shooting
conditions.
ISO Customizing
ISO Step
You can set the size for the ISO sensitivity by either 1/3 or 1 step.
Auto ISO Range
You can set the maximum ISO value under which each EV step is chosen
when you set the ISO to Auto.
* Default
Option Value
1/3 Step
ISO 125, ISO 160, ISO 200, ISO 250, ISO 320, ISO 400,
ISO 500, ISO 640, ISO 800, ISO 1000, ISO 1250, ISO 1600,
ISO 2000, ISO 2500, ISO 3200*
1 Step
ISO 200, ISO 400, ISO 800, ISO 1600, ISO 3200*
Noise Reduction
Use the Noise Reduction to reduce the visual noise in photos.
* Default
Option Description
High ISO NR
This function reduces noise that may occur when you
set a high ISO sensitivity. (O, High, Normal*, Low)
Long Term NR
This function reduces noise when you set the camera
for a long exposure. (O, On*)
User settings
147
Camera settings menu > User settings
Bracket Set
You can set up the options for AE Bracket, WB Bracket, and P Wiz Bracket.
Option Description
AE Bracket Set
Set the exposure interval. (-/+0.3 EV*, -/+0.7 EV,
-/+1 EV, -/+1.3 EV, -/+1.7 EV, -/+2 EV, -/+2.3 EV,
-/+2.7 EV, -/+3 EV)
WB Bracket Set
Adjust the White Balance interval range of the
3 bracketed photos. (AB-/+3*, AB-/+2, AB-/+1,
MG-/+3, MG-/+2, MG-/+1)
For example, AB-/+3 adjusts the Amber value plus
or minus three steps. MG-/+3 adjusts the Magenta
value the same amount.
P Wiz Bracket Set
Select 3 Picture Wizard settings the camera uses to
capture the 3 bracketed photos.
DMF (Direct Manual Focus)
You can adjust the focus manually by rotating the focus ring after
achieving the focus by half-pressing [Shutter]. This feature may not be
available with some lenses.
148
Camera settings menu > User settings
Color space
The color space option allows you to select methods for representing
colors. Digital imaging devices such as digital cameras, monitors, and
printers have their own methods for representing colors, which are called
color spaces.
Option Description
sRGB
sRGB (Standard RGB) is an international specication
to dene the color space created by IEC (International
Electrotechnical Commission). It is widely used for
creating colors on PC monitors and is also the standard
color space for Exif. sRGB is recommended for regular
images and images you intend to publish on the
Internet.
Adobe RGB
Adobe RGB is used for commercial printing and has a
larger color range than sRGB. Its wider range of colors
helps you to easily edit photos on a computer. Note
that individual programs are generally compatible
with a limited number of color spaces.
Adobe RGB
sRGB
When the color space is set to Adobe RGB, photos will be saved as
“_SAMXXXX.JPG”.
149
Camera settings menu > User settings
Distortion Correct
You can correct lens distortion that might occur from lenses.
This feature may not be available with some lenses.
Save as Custom Mode
You can create your own shooting modes by adjusting options and saving
them. (C1, C2, or C3) (p. 65)
iFn Customizing
You can select options that can be adjusted when you press [i-Function]
on an i-Function lens.
Option Description
Aperture
Set to adjust the aperture value.
Shutter Speed
Set to adjust the shutter speed.
EV
Set to adjust the exposure value.
ISO
Set to adjust ISO sensitivity.
White Balance
Set to adjust the White Balance.
Z
Set to adjust the zoom ratio.
User Display
You can add or remove shooting information from the display.
F
1
2
3
London
No. Description
1
Date & Time
Set to display the date and time.
2
Icons
Set to display icons on the right in Shooting mode.
150
Camera settings menu > User settings
No. Description
3
Histogram
Set the histogram on the display on or o.
About histogram
A histogram is a graph that shows the brightness distribution of a
photo. A histogram inclined to the left indicates a dark photo.
A histogram inclined to the right indicates a bright photo. The height
of the graph is related to color information. The graph gets higher if a
specic color is more common.
Insucient exposure Balanced exposure Excessive exposure
Key Mapping
You can change the function assigned to the Custom button (
F
) on the
screen or DIRECT LINK button on the camera.
* Default
Button Function
Custom
Set a function for the Custom button.
• O*: Do not use the Custom button.
• Optical Preview: Execute the Depth of Field Preview
function for the current aperture value. (p. 23)
• One Touch WB (White Balance): Execute the Custom
White Balance function.
• One Touch RAW+: Save a le in the RAW+JPEG
format. To save a le in JPEG format, touch the
button again.
• Reset: Reset some settings.
• AEL: Execute the auto exposure lock function.
• AEL Hold: Keep executing the auto exposure lock
function after shooting.
DIRECT LINK
Set a function of the DIRECT LINK button.
(AutoShare*, MobileLink, Remote Viewnder,
Auto Backup, Email, SNS & Cloud, Samsung Link)
151
Camera settings menu > User settings
Grid Line
Select a guide to help you compose a scene.
(O*, 3 X 3, 2 X 2, Cross, Diagonal)
AF Lamp
When shooting in dark places, turn the AF lamp on in order to have a
better auto focus. The Auto Focus functions more accurately in dark places
when the AF lamp is on.
152
Camera settings menu
Learn to congure your camera's settings.
To set Setting
options,
In Shooting or Playback mode, touch
→
q
→
an option.
* Default
Item Description
Sound
• System Volume: Set the sound volume or turn all sound
o entirely. (O, Low, Medium*, High)
Even if the system volume is turned o, the camera emits
the sound while playing a video or a slide show.
• AF Sound: Set the sound the camera emits when you
half-press the shutter button on or o. (O, On*)
• Button Sound: Set the sound the camera emits when
you press the buttons or touch the screen on or o.
(O, On*)
Quick View
Set the Quick View time length – the amount of time the
camera displays a photo immediately after you capture it.
(O, 1 sec*, 3 sec, 5 sec, Hold)
* Default
Item Description
Display
Adjust
Adjust the display brightness, auto brightness setting,
display color, or level gauge.
• Display Brightness: You can adjust the display
brightness manually.
• Auto Brightness: Turn auto brightness on or o.
(O, On*)
• Display Color: You can adjust the display color manually.
• Horizontal Calibration: Calibrate the level gauge. If the
level gauge is not level, position the camera on the level
surface, and then follow the on-screen instructions.
•
You cannot access the Horizontal Calibration option
in Playback mode.
•
You cannot calibrate the level gauge in portrait
orientation.
Auto Display
O
Set the display o time. The display turns o if you do not
use the camera for the time you set.
(O, 30 sec*, 1 min, 3 min, 5 min, 10 min)
Setting
153
Camera settings menu > Setting
* Default
Item Description
Power Save
Set power shut o time. The camera shuts o if you do not
use it for the time you set. (30 sec, 1 min*, 3 min, 5 min,
10 min, 30 min)
•
The camera retains the power-o time setting even if
you replace the battery.
•
Power Save may not work if the camera is connected to
a computer or a TV or playing a slide show or a movie.
Language
Set a language the camera shows on the display.
Date & Time
Set date, time, date format, time zone and whether to
imprint the date on photos. (Time Zone, Date & Time,
Date Type, Time Type, Imprint)
•
The date appears on the lower right side of the photo.
•
When you print a photo, some printers may not print
the date appropriately.
* Default
Item Description
Video Out
Set the video signal output appropriate for your country
when connecting the camera to an external video device
such as a monitor or HDTV.
• NTSC: USA, Canada, Japan, Korea, Taiwan, Mexico, etc
• PAL (Supports only PAL B, D, G, H, or I): Australia, Austria,
Belgium, China, Denmark, Finland, France, Germany,
England, Italy, Kuwait, Malaysia, New Zealand, Singapore,
Spain, Sweden, Switzerland, Thailand, Norway, etc
Anynet+
(HDMI-CEC)
When you connect the camera to an HDTV that supports
Anynet+ (HDMI-CEC), you can control the play function of
the camera with the TV remote control.
• O: You cannot control the play function of camera with
the TV remote control.
• On*: You can control the play function of camera with the
TV remote control.
HDMI Output
When you connect the camera to an HDTV with an HDMI
cable, you can change the resolution of the image.
• NTSC: Auto*, 1080p, 720p, 480p,
576p (activates only when PAL is selected)
If the connected HDTV does not support the resolution
you select, the camera sets the resolution one level lower.
154
Camera settings menu > Setting
* Default
Item Description
File Name
Set the method of creating le names.
• Standard*: SAM_XXXX.JPG (sRGB)/
• Date:
- sRGB les - MMDDXXXX.JPG. For example, for a photo
captured on Jan. 01, the le name would be
0101XXXX.jpg.
- Adobe RGB les - _MDDXXXX.JPG for the months Jan
through Sept. For the months Oct through Dec, the month
number is replaced by the letters A (Oct.), B (Nov.) and
C (Dec.).
For example, for a photo captured on Feb. 03, the le
name would be _203XXXX.jpg. For a photo captured on
Oct. 05, the le name would be _A05XXXX.jpg.
* Default
Item Description
File Number
Set the method of numbering les and folders.
• Reset: After using the reset function, the next le name is
started at 0001.
• Series*: New le numbers continue the existing number
sequence, even if you have installed a new memory card,
formatted the card, or deleted all photos.
•
The rst folder name is 100PHOTO, if you have selected
the sRGB color space and Standard le naming, the rst
le name is SAM_0001.
•
File name numbers are increased by 1 from SAM_0001 to
SAM_9999.
•
Folder numbers are increased by 1 from 100PHOTO to
999PHOTO.
•
The maximum number of les that can be saved in one
folder is 9,999.
•
File numbers are assigned according to DCF (Design rule
for Camera File system) specications.
•
If you change a le name (for example, on a computer),
the camera will not be able to play the le.
Folder Type
Set the type of folder.
• Standard*: XXXPHOTO
• Date: XXX_MMDD
155
Camera settings menu > Setting
* Default
Item Description
Format
Format the memory card. Formatting deletes all existing
les including protected les. (Ye s , No)
Errors can occur if you use a memory card formatted by
another brand of camera, a memory card reader, or a
computer. Please format memory cards in the camera
before using them to capture photos.
Device
Information
View the rmware version of the body and the lens, Mac
address, and network certication number, or update the
rmware.
• Firmware Update: Update the rmware of the camera
body or lens. (Body Firmware, Lens Firmware)
•
You can download rmware upgrades from
www.samsung.com.
•
You cannot run a rmware upgrade without a fully
charged battery. Recharge the battery fully before
running a rmware upgrade.
•
If you update the rmware, user settings and values will
be reset. (Date, time, language, and video out will not
change.)
•
Do not turn the camera o while the update is in
progress.
* Default
Item Description
GPS
• Geotagging: Set to capture photos with location
information using the Global Positioning System (GPS).
Location information is added to the Exif data associated
with the photo. (O, On*)
• GPS Valid Time Settings: Set the time to use the last
location information when the camera fails to receive
GPS signals. If the camera fails to receive GPS signals after
the specified time, the location information will not be
recorded onto the photos. (15 sec*, 30 sec, 1 min, 3 min,
10 min, 30 min)
• Location Display: Set to display the location information
on the screen in Shooting mode. The location information
will appear in Korean only when you are in Korea and
the display language is set to Korean. When another
language is set, the location information will appear in
English. (O, On*)
• GPS Reset: Set to search for GPS satellites closest to your
current position. (Ye s , No)
To use the GPS function, you must purchase an optional
GPS device.
156
Camera settings menu > Setting
* Default
Item Description
Sensor
Cleaning
• Sensor Cleaning: Remove dust from the sensor.
• Start-Up Action: When on, the camera performs sensor
cleaning each time you turn it on. (O*, On)
As this product uses interchangeable lenses, the sensor
can get dust on it when you change lenses. This can lead
to dust particles appearing in the photos you capture. It
is recommended not to change lenses when you are in a
particularly dusty area. Also, make sure to attach the lens
cap to the lens when not using it.
Reset
Reset the setup menu and shooting options to the factory
defaults. (Date, time, language, and video output settings
do not change.) (Ye s , No)
Open Source
Licenses
View open source licenses.
Chapter 6
Connecting to external devices
Make full use of the camera by connecting it to external devices such as a computer, HDTV or 3D TV.
158
Connecting to external devices
Play back photos or videos by connecting your camera to an HDTV (3D TV)
using an optional HDMI cable.
Viewing les on an HDTV
1
In Shooting or Playback mode, touch
→
q
→
HDMI Output
→
an option. (p. 153)
2
Turn o your camera and HDTV.
3
Connect your camera to your HDTV with the optional HDMI
cable.
4
Turn on your HDTV, and then select the HDMI video source.
5
Turn on the camera.
•
The camera automatically enters into Playback mode when you
connect it to an HDTV.
6
Control the camera to view photos or play videos.
•
When using the HDMI cable, you can connect the camera to an HDTV using
the Anynet+(CEC) method.
•
If the HDTV supports Anynet+(CEC), the TV turns on automatically when used
in conjunction with the camera. This feature may not be available on some
HDTVs.
•
When connected to an HDTV by an HDMI cable, the camera cannot capture a
photo or video.
•
When connected to an HDTV, some of the camera’s playback functions may
not be available.
•
The length of time after which the camera and an HDTV are connected may
vary depending on the memory card that you are using. As the main feature
of a memory card is to increase the transfer speed, it is not necessarily true
to say that a memory card with a faster transfer speed is also fast in using the
HDMI function.
Viewing les on an HDTV or 3D TV
159
Connecting to external devices > Viewing les on an HDTV or 3D TV
Viewing les on a 3D TV
You can view photos or videos captured in 3D mode or with the 3D
Panorama option in Smart mode on a 3D TV.
1
In Shooting or Playback mode, touch
→
q
→
HDMI Output
→
an option. (p. 153)
2
Turn o your camera and 3D TV.
3
Connect your camera to your 3D TV with the optional HDMI
cable.
4
Turn on your 3D TV, and then select the HDMI video source.
5
Turn on your camera.
•
The camera automatically enters into Playback mode when you
connect it to a 3D TV.
6
Move to a 3D le, and then touch to switch to 3D mode.
•
Touch
to switch to 2D Mode.
7
Turn on your TV's 3D function.
•
Refer to your TV's user manual for more details.
8
Control the camera to view 3D photos or play 3D videos.
•
You cannot view an MPO le in 3D eect on TVs that do not support the le
format.
•
Use proper 3D glasses when you view an MPO le or a 3D video le on a
3D TV.
•
Capturing photos in 3D Panorama mode may result in a less pronounced 3D
eect than those captured in 3D mode with a 3D lens.
Do not view the 3D photos or videos captured by your camera on a 3D TV or
3D monitor for an extended period of time. It may cause unpleasant symptoms,
such as eyestrain, fatigue, nausea, and more.
160
Connecting to external devices
Transfer les on a memory card to your computer by connecting the
camera to the computer.
Transferring les to your Windows OS
computer
Connecting the camera as a removable disk
You can connect the camera to your computer as a removable disk.
1
Turn o the camera.
2
Connect the camera to your computer with the USB cable.
•
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
•
If you try to plug the USB cable into the HDMI port, the camera may not
work properly.
3
Turn on the camera.
•
The computer recognizes the camera automatically.
4
On your computer, select My Computer
→
Removable Disk
→
DCIM
→
100PHOTO or 101_0101.
5
Select the les you want, and then drag or save them to your
computer.
If the Folder Type is set to Date, the folder name appears as “XXX_MMDD”.
For example, if you capture a photo on January 1, the folder name will be
"101_0101".
Transferring les to your computer
161
Connecting to external devices > Transferring les to your computer
Disconnecting the camera (for Windows XP)
With Windows Vista, Windows 7, and Windows 8, the methods for
disconnecting the camera are similar.
1
Ensure that no data is being transferred between the camera
and the computer.
•
If the status lamp on your camera is blinking, it means the data
transfer is in progress. Please wait until the status lamp stops
blinking.
2
Click on the tool bar at the bottom right of your computer
screen.
3
Click the pop-up message.
4
Click the message box indicating safely removed.
5
Remove the USB cable.
Transferring les to your Mac OS
Mac OS 10.5 or later is supported.
1
Turn o the camera.
2
Connect your camera to a Macintosh computer with the USB
cable.
•
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your les. The manufacturer is not
responsible for any loss of data.
•
If you try to plug the USB cable into the HDMI port, the camera may not
work properly.
162
Connecting to external devices > Transferring les to your computer
3
Turn on the camera.
•
The computer recognizes the camera automatically and displays a
removable disk icon.
4
Open the removable disk.
5
Transfer photos or videos to the Mac OS computer.
163
Connecting to external devices
You can view and edit les using the provided programs. You can also send
the les to a computer wirelessly.
Installing programs from the provided CD
1
Insert the installation CD into your computer.
2
Select a language.
3
Select a program to install.
4
Follow the on-screen instructions.
5
Click Exit to complete the installation.
Available programs when using i-Launcher
Item Description
Multimedia Viewer
You can view les with Multimedia Viewer.
Firmware Upgrade
You can download the rmware of your camera.
PC Auto Backup
You can send photos or videos that you
captured with the camera to a PC wirelessly.
Using i-Launcher
i-Launcher allows you to play back les with Multimedia Viewer and
provides a link to download the PC Auto Backup program.
Requirements for Windows OS
Item Requirements
CPU
Intel Core 2 Duo
®
2.0 GHz or higher/
AMD Phenom™ 2.4 GHz or higher
RAM
Minimum 512 MB RAM (1 GB or more recommended)
OS*
Windows XP SP2, Windows Vista, Windows 7, Windows 8
Hard disk
capacity
250 MB or more (1 GB and above recommended)
Others
• CD-ROM drive
• 1024X768 pixels, 16-bit color display compatible
monitor (1280X1024 pixels, 32-bit color display
recommended)
• USB 2.0 port
• nVIDIA Geforce 7600GT or higher/
ATI X1600 series or higher
• Microsoft DirectX 9.0c or higher
* A 32-bit version of i-Launcher will be installed—even on 64-bit editions of Windows XP,
Windows Vista, Windows 7, and Windows 8.
Using programs on a computer
164
Connecting to external devices > Using programs on a computer
•
The requirements are recommendation only. i-Launcher may not work
properly even when the computer meets the requirements, depending on the
condition of your computer.
•
If your computer does not meet the requirements, videos may not play
correctly.
The manufacturer is not responsible for any damage that results from using
unqualied computers such as a computer you assembled yourself.
Requirements for Mac OS
Item Requirements
OS
Mac OS 10.5 or higher (except PowerPC)
RAM
Minimum 256 MB RAM (512 MB or more
recommended)
Hard disk capacity
Minimum 110 MB
Others
USB 2.0 port, CD-ROM drive
Opening i-Launcher
On your computer, select Start
→
All Programs
→
Samsung
→
i-Launcher
→
Samsung i-Launcher. Or, click Applications
→
Samsung
→
i-Launcher on your Mac OS computer.
165
Connecting to external devices > Using programs on a computer
Using Multimedia Viewer
Multimedia Viewer allows you to play back les. From the Samsung
i-Launcher screen, click Multimedia Viewer.
•
Multimedia Viewer supports the following formats:
-
Videos: MP4 (Video: H.264, Audio: AAC), WMV (WMV 7/8/9), AVI (MJPEG)
-
Photos: JPG, GIF, BMP, PNG, TIFF, MPO
•
Files that have been recorded with other manufacturers’ devices may not play
back smoothly.
Viewing photos
1
2
3
4567891011
No. Description
1
File name
2
Enlarged area
3
Histogram
4
Open the selected le.
5
Histogram button
6
Rotate to the left/Rotate to the right.
7
Move to the previous le/Move to the next le.
8
Fit the photo to the screen.
9
View the photo in the original size.
10
Zoom in/Zoom out
11
Switches between 2D and 3D mode.
166
Connecting to external devices > Using programs on a computer
Viewing videos
1
2
345678
No. Description
1
File name
2
Adjust the volume.
3
Open the selected le.
4
Move to the next le.
5
Stop
No. Description
6
Pause
7
Move to the previous le.
8
Progress bar
Downloading the rmware
From the Samsung i-Launcher screen, click Firmware Upgrade.
Downloading the PC Auto Backup program
From the Samsung i-Launcher screen, click PC Auto Backup.
For information about installing the PC Auto Backup program,
refer to page 133.
167
Connecting to external devices > Using programs on a computer
Installing Adobe Photoshop Lightroom
1
Insert Adobe Photoshop Lightroom DVD-ROM into your
computer.
2
Select a language.
3
Follow the on-screen instructions.
Using Adobe Photoshop Lightroom
Photos captured by a camera are often transformed to JPEG formats and
stored in the memory according to the settings of the camera at the time
of shooting. RAW files are not transformed to JPEG formats and are stored
in the memory without any changes. With Adobe Photoshop Lightroom,
you can calibrate exposures, White Balances, tones, contrasts, and colors
of photos. You can also edit JPEG or TIFF les as well as RAW les. For more
information, refer to the program guide.
Chapter 7
Appendix
Get information about error messages, camera maintenance,
trouble shooting tips, specications, and optional accessories.
169
Appendix
When the following error messages appear, try these remedies.
Error messages Suggested remedies
Lens is locked
The lens is locked. Rotate the lens counter-clockwise
until you hear a click. (p. 46)
Card Error
• Turn o your camera, and then turn it on again.
• Remove your memory card and insert it again.
• Format your memory card.
Low Battery
Insert a charged battery or recharge the battery.
No Image File
Capture photos or insert a memory card that contains
photos.
File Error
Delete the damaged le or contact a service center.
Memory Full
Delete unnecessary les or insert a new memory card.
Error messages Suggested remedies
Folder and le
number are max
values. Replace
the card
File names do not match the DCF standard. Transfer
the les on the memory card to your computer and
format the card. (p. 155)
Error 00
Turn o your camera and remount the lens. If the
message still appears, contact a service center.
Error 01/02
Turn o your camera, remove the battery, and insert
again. If the message still appears, contact a service
center.
Error messages
170
Appendix
Cleaning the camera
Camera lens and display
Use a brush to remove dust and wipe the lens gently with a soft cloth.
If any dust remains, apply lens cleaning liquid to a piece of cleaning paper
and wipe gently.
Image sensor
Depending on dierent shooting conditions, dust may appear in photos
because the image sensor is exposed to the external environment. This
problem is normal, and the exposure to dust occurs in everyday use
of the camera. You can remove dust from the sensor by operating the
sensor cleaning function. (p. 156) If dust remains after cleaning the sensor,
contact a service center. Do not insert the blower into the mounting
opening of the lens.
Camera body
Wipe gently with a soft, dry cloth.
Never use benzene, thinners, or alcohol to clean the device. These solutions can
damage the camera or cause it to malfunction.
Maintaining the camera
171
Appendix > Maintaining the camera
Using on beaches or shores
•
Protect your camera from sand and dirt when you use it on beaches or in
other similar areas.
•
Your camera is not waterproof. Do not handle the battery, adapter, or
memory card with wet hands. Operating the camera with wet hands
may cause damage to your camera.
Storing for extended period of time
•
When you store the camera for an extended period, place it in a sealed
container with an absorbent material, such as silica gel.
•
Over time, unused batteries will discharge and must be recharged before
use.
•
The present date and time can be initialized when the camera is turned
on after the camera and battery have been separated for a prolonged
period.
Using or storing the camera
Inappropriate places to use or store the camera
•
Avoid exposing the camera to very cold or very hot temperatures.
•
Avoid using your camera in areas with extremely high humidity, or
where the humidity changes drastically.
•
Avoid exposing the camera to direct sunlight and storing it in hot,
poorly-ventilated areas, such as in a car during summer time.
•
Protect your camera and the display from impact, rough handling, and
excessive vibration to avoid serious damage.
•
Avoid using or storing your camera in dusty, dirty, humid, or poorly-
ventilated areas to prevent damage to moving parts and internal
components.
•
Do not use your camera near fuels, combustibles, or ammable
chemicals. Do not store or carry ammable liquids, gases, or explosive
materials in the same compartment as the camera or its accessories.
•
Do not store the camera where there are mothballs.
172
Appendix > Maintaining the camera
Using the camera with caution in humid environments
When you transfer the camera from a cold environment to a warm one,
condensation can form on the lens or internal components of the camera.
In this situation, turn o the camera and wait for at least 1 hour.
If condensation forms on the memory card, remove the memory card from
the camera and wait until all moisture has evaporated before reinserting it.
Other cautions
•
Do not swing your camera by the strap. This may cause injury to yourself
or others or damage to your camera.
•
Do not paint your camera, as paint can clog moving parts and prevent
proper operation.
•
Turn o the camera when not using it.
•
Your camera consists of delicate parts. Avoid impacts to the camera.
•
Protect the display from external force by keeping it in the case when
not in use. Protect the camera from scratches by keeping it away from
sand, sharp implements, or loose change.
•
Do not use the camera if the screen is cracked or broken. Broken glass or
acrylic could cause injury to your hands and face. Take the camera to a
Samsung service center to have it repaired.
•
Never place cameras, batteries, chargers, or accessories near, on, or
in heating devices, such as microwave ovens, stoves, or radiators.
These devices may be deformed and can overheat and cause a re or
explosion.
•
Do not expose the lens to direct sunlight, as this may discolor the image
sensor or cause it to malfunction.
•
Protect your lens from ngerprints and scratches. Clean your lens with a
soft, clean, debris-free lens cloth.
•
The camera may turn o if impacted from the outside. This is to protect
the memory card. Turn on the camera to use it again.
•
While you use the camera, it may heat up. This is normal and should not
aect your camera’s lifespan or performance.
•
When you use the camera in low temperatures, it may take some time to
turn on, the color of the display may be changed temporarily, or after-
images may appear. These conditions are not malfunctions and they will
correct themselves when the camera is returned to milder temperatures.
•
Paint or metal on the outside of the camera may cause allergies,
itchy skin, eczema, or swelling for people with sensitive skin.
If you experience any of these symptoms, stop using the camera
immediately and consult a doctor.
•
Do not insert foreign objects into any of your camera’s compartments,
slots, or access points. Damage due to improper use may not be covered
by your warranty.
•
Do not allow unqualied personnel to service the camera or attempt to
service the camera yourself. Any damage that results from unqualied
service is not covered by your warranty.
173
Appendix > Maintaining the camera
About memory card
Supported memory card
This product supports microSD (Secure Digital), microSDHC (Secure Digital
High Capacity), or microSDXC (Secure Digital eXtended Capacity)
memory cards.
Memory card adapter
Memory card
To read data with a computer or memory card reader, insert the memory
card into a memory card adapter.
174
Appendix > Maintaining the camera
Memory card capacity
The memory capacity may dier depending on shooting scenes or shooting conditions. These capacities are based on a 2 GB SD card.
Size
Quality
Super Fine Fine Normal RAW RAW + S.Fine RAW + Fine RAW + Normal
20.0M (5472X3648) 130 163 217 39 30 31 33
10.1M (3888X2592) 277 356 505 - 33 34 35
5.9M (2976X1984) 471 570 727 - 35 36 36
2.0M (1728X1152) 1,053 1,426 1,941 - 37 37 38
Burst 430 514 638 - - - -
16.9M (5472X3080) 153 190 251 - 31 32 34
7.8M (3712X2088) 346 417 568 - 34 35 36
4.9M (2944X1656) 512 670 896 - 36 36 37
2.1M (1920X1080) 1,015 1,349 1,700 - 37 37 37
13.3M (3648X3648) 217 227 284 - 32 33 34
7.0M (2640X2640) 336 465 592 - 35 35 36
4.0M (2000X2000) 559 752 1,203 - 36 37 37
1.1M (1024X1024) 2,149 2,471 2,819 - 38 38 38
175
Appendix > Maintaining the camera
Size
Quality
HQ Normal
Video
1920X1080 (30 fps)
Approx. 17' 21" Approx. 21' 44"
*
1920X1080 (15 fps)
Approx. 23' 02" Approx. 28' 50"
1920X810 (24 fps)
Approx. 21' 11" Approx. 26' 31"
1280X720 (60 fps)
Approx. 16' 33" Approx. 20' 42"
1280X720 (30 fps)
Approx. 28' 38" Approx. 35' 53"
640X480 (30 fps)
Approx. 70' 48" Approx. 88' 58"
For Sharing (30 fps)
Approx. 213' 41" Approx. 271' 09"
*
is available only with some Smart Filter options.
•
The gures above are measured without using the zoom function.
•
Available recording time may vary if you use the zoom.
•
Several videos were recorded in succession to determine the total recording time.
•
The maximum recording time is 29 minutes and 59 seconds per le.
•
The maximum recording time when you select is 20 minutes.
•
The maximum playback time of For Sharing videos is 30 seconds per le.
176
Appendix > Maintaining the camera
•
Prevent memory cards from making contact with liquids, dirt, or foreign
substances. If dirty, wipe the memory card clean with a soft cloth before
you insert the memory card in your camera.
•
Do not allow liquids, dirt, or foreign substances to come in contact with
memory cards or the memory card slot. Doing so may cause memory
cards or the camera to malfunction.
•
When you carry a memory card, use a case to protect the card from
electrostatic discharges.
•
Transfer important data to other media, such as a hard disk, CD, or DVD.
•
When you use the camera for an extended period, the memory card may
become warm. This is normal and does not indicate a malfunction.
•
Use a memory card that meets the standard requirements.
The manufacturer is not responsible for any loss of data.
Cautions when using memory cards
•
Avoid memory cards to very cold or very hot temperatures (below
0 °C/32 °F or above 40 °C/104 °F). Extreme temperatures can cause
memory cards to malfunction.
•
Insert a memory card in the correct direction. Inserting a memory card in
the wrong direction may damage your camera and memory card.
•
Do not use memory cards that have been formatted by other cameras or
by a computer. Reformat the memory card with your camera.
•
Turn o the camera when you insert or remove the memory card.
•
Do not remove the memory card or turn o your camera while the lamp
is blinking, as this may damage your data.
•
When the lifespan of a memory card has expired, you cannot store any
more photos on the card. Use a new memory card.
•
Do not bend, drop, or subject memory cards to heavy impact or
pressure.
•
Avoid using or storing memory cards near strong magnetic elds.
•
Avoid using or keeping memory cards in areas with high temperature,
high humidity, or corrosive substances.
177
Appendix > Maintaining the camera
•
Do not rest the device on ammable surfaces, such as bedding, carpets, or
electric blankets for a prolonged period.
•
When the device is switched on, do not leave it in any conned space for a
prolonged period.
•
Do not allow battery terminals to come in contact with metallic objects, such
as necklaces, coins, keys, or watches.
•
Use only authentic, manufacturer-recommended, Lithium-ion replacement
batteries.
•
Do not disassemble the battery or puncture the battery with any sharp
object.
•
Avoid exposing the battery to high pressure or crushing forces.
•
Avoid exposing the battery to major impacts, such as dropping it from high
places.
•
Do not expose the battery to temperatures of 60 °C (140 °F) or above.
•
Do not allow the battery to come in contact with moisture or liquids.
•
Battery shall not be exposed to excessive heat such as sunshine, re or the
like.
Disposal guidelines
•
Dispose of the battery with care.
•
Do not dispose of the battery in a re.
•
Disposal regulations may dier by country or region. Dispose of the battery in
accordance with all local and federal regulations.
Guidelines for charging the battery
Charge the battery only by the method described in this user manual.
The battery can ignite or explode if not charged properly.
About the battery
Use only Samsung-approved batteries.
Battery specications
Item Description
Model
BP1130
Type
Lithium-ion battery
Cell capacity
1,130 mAh
Voltage
7.6 V
Charging time* (When the battery
is completely discharged)
Approx. 215 min
* Charging the battery by connecting it to a computer may take longer.
Personal injury or death can occur if the battery is handled carelessly or
improperly. For your safety, follow these instructions for proper battery
handling:
•
The battery can ignite or explode if not handled properly. If you notice
any deformities, cracks, or other abnormalities in the battery, immediately
discontinue use of the battery and contact your manufacturer.
•
Use only authentic, manufacturer-recommend battery chargers and charge
the battery only by the method described in this user manual.
•
Do not place the battery near heating devices or expose to excessively warm
environments, such as the inside of an enclosed car in the summertime.
•
Do not place the battery in a microwave oven.
•
Avoid storing or using the battery in hot, humid places, such as spas or
shower enclosures.
178
Appendix > Maintaining the camera
Battery life
Shooting mode Average time / Number of photos
Photos
Approx. 170 min/Approx. 340 photos
Videos
Approx. 130 min (Record videos at 1920X1080
resolution and 30 fps.)
•
The gures above are based on the CIPA test standards.
Your results may dier depending on your actual usage.
•
Available shooting time diers depending on background, shooting
interval, and use conditions.
•
Several videos were recorded in succession to determine the total
recording time.
Low battery message
When the battery has fully discharged, the battery icon will turn red and
the "Low Battery" message will appear.
Notes about using the battery
•
Avoid exposing batteries to very cold or very hot temperatures (below
0 °C/32 °F or above 40 °C/104 °F). Extreme temperatures can reduce the
charging capacity of your batteries.
•
When you use the camera for an extended period, the area around the
battery chamber may become warm. This does not aect the normal use
of the camera.
•
Do not pull the power supply cable to disconnect the plug from the
power outlet, as this may cause a re or electric shock.
•
In temperatures below 0 °C/32 °F, battery capacity and battery life may
decrease.
•
Battery capacity may decrease in low temperatures, but will return to
normal in milder temperatures.
•
Remove the batteries from your camera when storing it for an extended
period. Installed batteries may leak or corrode over time and cause
serious damage to your camera. Storing the camera for extended
periods with the battery installed causes the battery to discharge. You
may not be able to recharge a fully discharged battery.
•
When you do not use the camera for an extended period (3 months or
more), check the battery and recharge it regularly. If you let the battery
discharge continually, its capacity and life may decrease, which can lead
to a malfunction, re, or explosion.
179
Appendix > Maintaining the camera
Cautions about using the battery
Protect batteries, chargers, and memory cards from damage.
Prevent batteries from making contact with metal objects, as this can
create a connection between the + and – terminals of your battery and
lead to temporary or permanent battery damage and may cause a re or
electric shock.
Notes about charging the battery
•
If the status lamp is o, make sure that the battery is inserted correctly.
•
If the camera is on while charging, the battery may not fully charge. Turn
o the camera before charging the battery.
•
Do not use your camera when you are charging the battery. This may
cause a re or electric shock.
•
Do not pull the power supply cable to disconnect the plug from the
power outlet, as this may cause a re or electric shock.
•
Let the battery charge for at least 10 minutes before turning on the
camera.
•
If you connect the camera to an external power source when the battery
is depleted, using high energy-consuming functions will cause the
camera to turn o. To use the camera normally, recharge the battery.
•
If you reconnect the power cable when the battery is fully charged, the
status lamp turns on for approximately 30 minutes.
•
Using the ash or recording videos depletes the battery quickly. Charge
the battery until the red status lamp turns o.
•
If the status lamp blinks in red, reconnect the cable, or remove the
battery and insert it again.
•
If you charge the battery when the cable is overheated or the
temperature is too high, the status lamp may blink in red. Charging will
start when the battery cools down.
•
Overcharging batteries may shorten battery life. After charging is
nished, disconnect the cable from your camera.
•
Do not bend or place heavy objects on the AC cable. Doing so may
damage the cable.
180
Appendix > Maintaining the camera
Notes about charging with a computer connected
•
Use only the provided USB cable.
•
The battery may not charge when:
- you use a USB hub
- other USB devices are connected to your computer
- you connect the cable to the port on the front side of your computer
- the USB port of your computer does not support the power output standard
(5 V, 500 mA)
Handle and dispose of batteries and chargers with care
•
Never dispose of batteries in a re. Follow all local regulations when you
dispose of used batteries.
•
Never place batteries or cameras on or in heating devices, such as
microwave ovens, stoves, or radiators. Batteries may explode when they
are overheated.
181
Appendix
Before contacting a service center
If you are having trouble with your device, try these troubleshooting
solutions before contacting a service professional.
When you leave your camera at a service center, be sure to also leave the other
components that may have contributed to the malfunction, such as the memory
card and battery.
Situation Suggested remedies
Cannot turn on the
camera
• Ensure that the battery is inserted.
• Ensure that the battery is inserted correctly.
• Charge the battery.
The power turns o
suddenly
• Charge the battery.
• Your camera may be in Power save mode or the
display turns o automatically. (p. 153)
• The camera may be turned o automatically to
prevent the memory card from being damaged
due to excessive heat. Turn on your camera
again.
The camera is losing
battery power quickly
• The battery may lose power more quickly in
low temperatures (below 0 °C/32 °F). Keep the
battery warm by putting it into your pocket.
• Using the ash or recording videos depletes the
battery quickly. Recharge if needed.
• Batteries are consumable parts that must be
replaced over time. Get a new battery if the
battery life is diminishing quickly.
Situation Suggested remedies
Cannot capture
photos
• There is no space on the memory card. Delete
unnecessary les or insert a new card.
• Format the memory card.
• The memory card is defective. Get a new
memory card.
• Ensure that the camera is switched on.
• Charge the battery.
• Ensure that the battery is inserted correctly.
The camera freezes
Remove the battery and insert it again.
The camera heats up
While using the camera, it may heat up.
This is normal and should not aect your camera’s
lifespan or performance.
The ash res
unexpectedly
The ash may re due to static electricity.
The camera is not malfunctioning.
The ash does not
work
• The ash option may be set to O. (p. 101)
• You cannot use the ash in some modes.
The date and time are
incorrect
Set the date and time under the q menu.
(p. 153)
The display or buttons
do not work
Remove the battery and insert it again.
182
Appendix > Before contacting a service center
Situation Suggested remedies
The memory card has
an error
• Turn o your camera, and then turn it on again.
• Remove your memory card, and then insert it
again.
• Format your memory card.
See "Cautions when using memory cards" for
more details. (p. 176)
Your computer does
not recognize a
microSDXC memory
card
microSDXC memory cards use the exFAT le
system. To use microSDXC memory cards on a
Windows XP computer, download and update
the exFAT le system driver from the Microsoft
website.
Your TV or computer
cannot display photos
and videos that are
stored on a microSDXC
memory card
microSDXC memory cards use the exFAT le
system. Ensure that the external device is
compatible with the exFAT le system before
connecting the camera to the device.
Cannot display les
If you change the name of a le, your camera may
not play the le (the name of the le should meet
the DCF standard). If you encounter this situation,
display les on your computer.
Situation Suggested remedies
The photo is blurry
• Ensure that the focus option you set is suitable
for the kind of shot you are capturing.
• Use a tripod to prevent your camera from
shaking.
• Ensure that the lens is clean. If not, clean the
lens. (p. 170)
The colors in the
photo do not match
the actual scene
An incorrect White Balance can create unrealistic
color. Select the proper White Balance option to
suit the light source. (p. 77)
The photo is too
bright or too dark.
Your photo is overexposed or underexposed.
• Adjust the aperture value or the shutter speed.
• Adjust the ISO sensitivity. (p. 76)
• Turn o or on the ash. (p. 101)
• Adjust the exposure value. (p. 104)
Photos are distorted
This camera can have minute distortion when
using a wide-angle lens that enables shooting
with a wide angle of view. This is normal, and
does not cause malfunction.
Playback screen does
not appear on the
connected external
device
• Ensure that HDMI cable is properly connected
to the external monitor.
• Ensure that the memory card is properly
recorded.
183
Appendix > Before contacting a service center
Situation Suggested remedies
Your computer does
not recognize your
camera
• Ensure that the USB cable is connected
correctly.
• Ensure that your camera is switched on.
• Ensure that you are using a supported
operating system.
Your computer
disconnects the
camera while
transferring les
The le transfer may be interrupted by static
electricity. Disconnect the USB cable and connect
it again.
Your computer cannot
play videos
Videos may not play on some video player
programs. To play video les captured with your
camera, use the Multimedia Viewer program that
you can install with the i-Launcher program on
your computer.
i-Launcher is not
functioning properly
• End i-Launcher and restart the program.
• Depending on your computer's specications
and environment, the program may not
launch automatically. In this case, click
Start
→ All Programs → Samsung →
i-Launcher
→ Samsung i-Launcher on your
Windows computer. (For Windows 8, open
Start screen, and then select All apps
→
Samsung i-Launcher.) Or, click Applications
→ Samsung → i-Launcher on your Mac OS
computer.
Situation Suggested remedies
Cannot set the DPOF
for RAW les
You cannot set the DPOF for RAW les.
Auto Focus does not
work
• Subject is not in focus. When the subject is
outside the AF area, shoot by moving the
subject inside the AF area and half-pressing
[Shutter].
• Subject is too close. Step back from the subject
and shoot.
• The focus mode is set to MF. Switch the mode
to AF.
AEL feature does not
work
AEL feature does not work in Auto, Manual and
Smart modes. Select another mode to use this
feature.
Lens does not work
• Ensure that the lens is properly mounted.
• Remove the lens from the camera and
re-mount it.
External ash or GPS
does not work
Ensure that the external device is properly
mounted and turned on.
The date & time
settings screen
appears when you
power on the camera
• Set the date and time again.
• This screen appears when the camera’s internal
power source is completely discharged. Insert
a fully charged battery and wait at least 72
hours in power o status for the internal power
source to be recharged.
184
Appendix
Camera specications
Image Sensor
Type
CMOS
Sensor size
23.5 X 15.7 mm
Eective pixels
Approx. 20.3 mega-pixels
Total pixels
Approx. 21.6 mega-pixels
Color lter
RGB primary color lter
Lens Mount
Type
Samsung NX Mount
Available lens
Samsung lenses
Image Stabilization
Type
Lens shift (depends on lens)
Mode
O/Mode 1/Mode 2
Distortion Correct
O/On (depends on lens)
i-Function
Z (X1.2, 1.4, 1.7, 2.0)
Dust Reduction
Type
Super sonic drive
Display
Type
TFT-LCD with Touch Panel (C-type Touch Control
Enabled)
Size
3.7" (Approx. 93.8 mm)
Resolution
WVGA (800X480) 1,152k dots
Field of view
Approx. 100 %
Angle
Fixed
User display
Grid Line, Icons, Histogram, Distance Scale,
Level gauge
Focusing
Type
Contrast AF
Focusing point
• Selection: 1 point (Free selection)
• Multi: Normal 21 points, Close up 35 points
• Face detection: Max. 10 faces
• Object Tracking AF
Mode
Single AF, Continuous AF, Manual Focus,
Touch AF & Shutter
AF Assist Lamp
Green LED
185
Appendix > Camera specications
Shutter
Type
Electronically controlled vertical-run focal plane
shutter
Speed
• Auto: 1/4,000–30 sec.
• Manual: 1/4,000–30 sec. (1/3 EV Step)
• Bulb (time limit: 4 min)
Exposure
Metering system
TTL 221 (17 X 13) Block segment
Metering: Multi, Center-weighted, Spot
Metering range: EV 0–18 (ISO100 · 30 mm, F2)
Compensation
±3 EV (1/3 EV Step)
AE lock
Custom button
ISO equivalent
• 1 Step: Auto, ISO 100, ISO 200, ISO 400,
ISO 800, ISO 1600, ISO 3200, ISO 6400,
ISO 12800, ISO 25600
• 1/3 Step: Auto, ISO 100, ISO 125, ISO 160,
ISO 200, ISO 250, ISO 320, ISO 400, ISO 500,
ISO 640, ISO 800, ISO 1000, ISO 1250,
ISO 1600, ISO 2000, ISO 2500, ISO 3200,
ISO 4000, ISO 5000, ISO 6400, ISO 8000,
ISO 10000, ISO 12800, ISO 16000, ISO 20000,
ISO 25600
Drive Mode
Mode
Single, Continuous, Burst (5M only), Timer,
Bracket (Auto Exposure, White Balance, Picture
Wizard)
Continuous shooting
• JPEG: High (8 fps), Normal (5 fps)
• RAW: High (8 fps), Normal (5 fps)
Burst shooting
• 10, 15, or 30 frames per second
• Up to 30 shots per shutter-press
Bracket shooting
Auto exposure bracketing (±3 EV),
White Balance bracketing,
Picture Wizard bracketing
Self-timer
2–30 sec. (1 second interval)
Shutter release
SR2NX02 (via Micro USB port) (optional)
Flash
Type
External Flash (Bundle with SEF8A)
Mode
Smart Flash, Auto, Auto Red-eye, Fill in,
Fill-in Red, 1st Curtain, 2nd Curtain, O
Guide number
8 (based on ISO 100) (SEF8A)
Angle of view
28 mm (35 mm lm equivalent)
Sync speed
Less than 1/180 sec.
Flash EV
-2–+2 EV (0.5 EV Step)
186
Appendix > Camera specications
External ash
Optional Samsung external ashes:
SEF42A, SEF220A
Sync terminal
Hot-shoe
White Balance
Mode
Auto WB, Daylight, Cloudy, Fluorescent White,
Fluorescent NW, Fluorescent Daylight, Tungsten,
Flash WB, Custom Set, Color Temperature
(Manual)
Micro adjustment
Amber/Blue/Green/Magenta 7 steps respectively
Dynamic Range
O/Smart Range+/HDR
Picture Wizard
Mode
Standard, Vivid, Portrait, Landscape, Forest,
Retro, Cool, Calm, Classic, Custom1, Custom2,
Custom3
Parameter
Color, Saturation, Sharpness, Contrast
Shooting
Mode
Auto, Smart, Expert (Program, Aperture Priority,
Shutter Priority, Manual, Custom), Wi-Fi
Smart mode
Beauty Face, Best Face, Landscape, Macro,
Action Freeze, Rich Tones, Panorama, Waterfall,
Silhouette, Sunset, Night, Fireworks, Light Trace,
Creative Shot
Smart Filter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Sketch, Ink Sketch, Acryl,
Negative, Red, Green, Blue, Yellow
Size
• JPEG (3:2): 20.0M (5472X3648),
10.1M (3888X2592), 5.9M (2976X1984),
5.0M (2736X1824) (Burst mode only),
2.0M (1728X1152)
• JPEG (16:9): 16.9M (5472X3080),
7.8M (3712X2088), 4.9M (2944X1656),
2.1M (1920X1080)
• JPEG (1:1): 13.3M (3648X3648),
7.0M (2640X2640), 4.0M (2000X2000),
1.1M (1024X1024)
• RAW: 20.0M (5472X3648)
* 3D mode with 3D lens is available only with
JPEG (16:9) 4.1M (2688X1512) or 2.1M (1920X1080).
Quality
Super Fine, Fine, Normal
RAW standard
SRW (ver.2.0.0)
Color space
sRGB, Adobe RGB
187
Appendix > Camera specications
Video
Type
MP4 (H.264)
Format
Movie: H.264, Sound: AAC
Movie AE mode
Program, Aperture Priority, Shutter Priority,
Manual
Movie clip
Audio on/o (Shooting time: Max. 29' 59'')
Smart Filter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Sketch, Ink Sketch, Acryl,
Negative, Red, Green, Blue, Yellow
Size
1920X1080, 1920X810, 1280X720, 640X480,
320X240 (For Sharing)
Frame rate
30 fps, 24 fps (available only with 1920X810),
15 fps (available only with some Smart Filter
options)
Multi Motion
x0.25 (640X480, 320X240 only), x0.5 (1280X720
(30 fps), 640X480, 320X240 only), x1, x5, x10, x20
Quality
HQ, Normal
Sound
Stereo
Edit
Still image capture, Time trimming
Playback
Type
Single image, Thumbnails (15/28), Slide show,
Movie
Edit
Smart Filter, Red-eye Fix, Backlight, Resize,
Rotate, Face Retouch, Brightness, Contrast
Smart lter
Vignetting, Miniature, Colored Pencil, Watercolor,
Wash drawing, Oil Sketch, Ink Sketch, Acryl,
Negative, Red, Green, Blue, Yellow
Storage
Media
External memory (optional):
microSD card (2 GB guaranteed),
microSDHC card (up to 32 GB guaranteed),
microSDXC card (up to 64 GB guaranteed)
(Class 6 and above recommended)
File format
RAW (SRW (ver.2.0.0)), JPEG (EXIF 2.21),
MPO (3D), MP4 (Movie), DCF, DPOF 1.1
GPS
Type
Geo-tagging with an optional GPS Module
(WGS 84)
Feature
Location name (English and Korean only)
188
Appendix > Camera specications
Wireless network
Type
IEEE 802.11b/g/n
Function
MobileLink, Remote Viewnder, Auto Backup,
Email, SNS & Cloud, Samsung Link, AutoShare,
Wi-Fi Direct
NFC
Yes
Interface
Digital output
USB 2.0 (micro USB jack)
Video output
• NTSC, PAL (selectable)
• HDMI
External release
Yes (micro USB)
External microphone
Yes
DC power input
DC 5.0V, 1A via micro USB
Power Source
Type
Rechargeable battery: BP1130 (1,130 mAh)
* The power source may dier depending on your region.
Dimensions (W X H X D)
119 X 64.5 X 35.7 mm (without protrusions)
Weight
228 g (without battery and memory card)
Operating Temperature
0–40 °C
Operating Humidity
5–85 %
Software
i-Launcher, Adobe Photoshop Lightroom
* Specications may change without notice to improve performance.
* Other brands and products names are trademarks of respective owners.
189
Appendix
Glossary
AP (Access Point)
An access point is a device that allows wireless devices to connect to a
wired network.
Ad-Hoc network
An ad-hoc network is a temporary connection for sharing les or an
internet connection and between computers and devices.
AdobeRGB
Adobe RGB is used for commercial printing and has a larger color range
than sRGB. Its wider range of colors helps you to easily edit photos on a
computer.
AEB (Auto Exposure Bracket)
This feature automatically captures several images at dierent exposures
to help you capture a properly-exposed image.
AEL/AFL (Auto Exposure Lock/Auto Focus Lock)
These features help you lock the exposure or focus on which you want to
focus or calculate the exposure.
AF (Auto Focus)
A system that automatically focuses the camera lens on the subject. Your
camera uses the contrast to focus automatically.
AMOLED (Active-matrix organic light-emitting diode) /
LCD (Liquid Crystal Display)
AMOLED is a visual display that is very thin and light, as it does not
need backlighting. LCD is a visual display commonly used in consumer
electronics. This display needs a separate backlight, such as CCFL or LED, to
reproduce colors.
Aperture
The aperture controls the amount of light that reaches the camera’s sensor.
190
Appendix > Glossary
Composition
Composition in photography means arranging objects in a photo. Usually,
abiding by the rule of thirds leads to a good composition.
DCF (Design rule for Camera File system)
A specication to dene a le format and le system for digital cameras
created by the Japan Electronics and Information Technology Industries
Association (JEITA).
Depth of eld
The distance between the nearest and farthest points that can be
acceptably focused in a photograph. Depth of eld varies with lens
aperture, focal length, and distance from the camera to the subject.
Selecting a smaller aperture, for example, will increase the depth of eld
and blur the background of a composition.
DPOF (Digital Print Order Format)
A format for writing printing information, such as selected images
and number of prints, on a memory card. DPOF-compatible printers,
sometimes available at photo shops, can read the information from the
card for convenient printing.
Camera shake (Blur)
If the camera is moved while the shutter is open, the entire image may
appear blurred. This occurs more often when the shutter speed is slow.
Prevent camera shake by raising the sensitivity, using the ash, or using
a faster shutter speed. Alternatively, use a tripod or the OIS function to
stabilize the camera.
Cloud Computing
Cloud computing is a technology that allows you to store data on remote
servers and to use them from a device with internet access.
Color space
The range of colors that the camera can see.
Color temperature
Color Temperature is a measurement in degrees Kelvin (K) that indicates
the hue of a specic type of light source. As the color temperature
increases, the color of the light source has a more bluish quality. As the
color temperature decreases, the color of the light source has a more
reddish quality. At 5,500 degrees Kelvin, the color of the light source is
similar to the sun at midday.
191
Appendix > Glossary
Flash
A speed light that helps to create adequate exposure in low-light
conditions.
Focal length
The distance from the middle of the lens to its focal point (in millimeters).
Longer focal lengths result in narrower angles of view and the subject is
magnied. Shorter focal lengths result in wider angles of view.
Histogram
A graphical representation of the brightness of an image. The horizontal
axis represents the brightness and the vertical axis represents the number
of pixels. High points at the left (too dark) and right (too bright) on the
histogram indicate a photo that is improperly exposed.
H.264/MPEG-4
A high-compression video format established by international standard
organizations ISO-IEC and ITU-T. This codec is capable of providing good
video quality at low bit rates developed by the Joint Video Team (JVT).
EV (Exposure Value)
All the combinations of the camera’s shutter speed and lens aperture that
result in the same exposure.
EV Compensation
This feature allows you to quickly adjust the exposure value measured by
the camera, in limited increments, to improve the exposure of your photos.
Exif (Exchangeable Image File Format)
A specication to dene an image le format for digital cameras created by
the Japan Electronic Industries Development Association (JEIDA).
Exposure
The amount of light allowed to reach the camera’s sensor. Exposure is
controlled by a combination of the shutter speed, the aperture value, and
ISO sensitivity.
192
Appendix > Glossary
Metering
The metering refers to the way in which the camera measures the quantity
of light to set the exposure.
MF (Manual Focus)
A system that manually focuses the camera lens on the subject.
You can use the focus ring to focus on a subject.
MJPEG (Motion JPEG)
A video format which is compressed as a JPEG image.
MPO (Multi Picture Object)
An image le format that contains multiple images in a le. An MPO le
provides a 3D eect on MPO-compatible displays, such as 3D TVs or 3D
monitors.
Image sensor
The physical part of a digital camera that contains a photosite for each
pixel in the image. Each photosite records the brightness of the light that
strikes it during an exposure. Common sensor types are CCD (Charge-
coupled Device) and CMOS (Complementary Metal Oxide Semiconductor).
IP (Internet protocol) address
An IP address is a unique number that is assigned to every device that is
connected to the internet.
ISO sensitivity
The sensitivity of the camera to light, based on the equivalent lm speed
used in a lm camera. At higher ISO sensitivity settings, the camera uses a
higher shutter speed, which can reduce blur caused by camera shake and
low light. However, images with high sensitivity are more susceptible to
noise.
JPEG (Joint Photographic Experts Group)
A lossy method of compression for digital images. JPEG images are
compressed to reduce their overall le size with minimal deterioration of
the image resolution.
193
Appendix > Glossary
PAL (Phase Alternate Line)
A video color encoding standard used in numerous countries throughout
Africa, Asia, Europe, and the Middle East.
Quality
An expression of the rate of compression used in a digital image. Higher
quality images have a lower rate of compression, which usually results in a
larger le size.
RAW (CCD raw data)
The original, unprocessed data, collected directly from the camera’s image
sensor. White Balance, contrast, saturation, sharpness, and other data can
be manipulated with editing software before the image is compressed into
a standard le format.
Resolution
The number of pixels present in a digital image. High resolution images
contain more pixels and typically show more detail than low resolution
images.
Noise
Misinterpreted pixels in a digital image that may appear as misplaced or
random, bright pixels. Noise usually occurs when photos are shot with a
high sensitivity or when a sensitivity is automatically set in a dark place.
NFC (Near Field Communication)
NFC is a set of standards for radio communication at very close proximity.
You can use NFC-enabled devices to activate features or exchange data
with other devices.
NTSC (National Television System Committee)
A video color encoding standard used most commonly in Japan, North
America, the Philippines, South America, South Korea, and Taiwan.
Optical zoom
This is a general zoom which can enlarge images with a lens and does not
deteriorate quality of images.
194
Appendix > Glossary
Shutter speed
Shutter speed refers to the amount of time it takes to open and close the
shutter, and it is an important factor in the brightness of a photo, as it
controls the amount of light which passes through the aperture before
it reaches the image sensor. A fast shutter speed allows less time to let
light in and the photo becomes darker and more easily freezes subjects in
motion.
sRGB (Standard RGB)
International standard of color space established by the IEC (International
Electrotechnical Commission). This is dened from color space for PC
monitors and is also used as the standard color space for Exif.
Vignetting
A reduction of an image’s brightness or saturation at the periphery (outer
edges) compared to the center of the image. Vignetting can draw interest
to subjects positioned in the center of an image.
White Balance (Color balance)
An adjustment of the intensities of colors (typically the primary colors red,
green, and blue), in an image. The goal of adjusting the White Balance, or
color balance, is to correctly render the colors in an image.
Wi-Fi
Wi-Fi is a technology that allows electronic devices to exchange data
wirelessly over a network.
WPS (Wi-Fi Protected Setup)
WPS is a technology that secures wireless home networks.
195
Appendix
Optional accessories
Lens
SAMSUNG 18-55 mm
F3.5-5.6 OIS III
SAMSUNG 20-50 mm
F3.5-5.6 ED II
SAMSUNG 16 mm F2.4 SAMSUNG 20 mm F2.8
SAMSUNG 30 mm F2 SAMSUNG 50-200 mm
F4-5.6 ED OIS III
SAMSUNG 60 mm F2.8
Macro ED OIS SSA
SAMSUNG 18-200 mm
F3.5-6.3 ED OIS
Lens
SAMSUNG 85 mm F1.4 ED SSA SAMSUNG 12-24 mm F4-5.6 ED
SAMSUNG 45 mm F1.8 SAMSUNG 45 mm F1.8 [T6] 2D/3D
External ash
SEF42A SEF220A
GPS
GPS10
196
Appendix > Optional accessories
Shutter release (micro USB type) Microphone
SR2NX02 EM10
Rechargeable battery Battery charger
BP1130 BC3NX01
Camera bag Camera case
Memory card Filter
USB cable HDMI cable
Strap
•
These illustrations may dier from your actual items. Refer to the user
manuals of these optional accessories for details.
•
Use only Samsung-approved accessories. Samsung is not responsible for
damage caused by using another manufacturer’s accessories.
197
Appendix
A
Adobe Photoshop Lightroom 167
Aperture 15, 19
Auto Backup 133
Auto focus 82
B
Battery
Caution 177
Charging 34
Insert 33
Best Face mode 58
Bracketing 96
C
Camera
Connecting as removable disk 160
Connecting to PC 160
Disconnecting (Windows) 161
Layout 29
Camera specications 184
Charging 34
Color space 148
D
Date & Time 153
Depth of Field (DOF) 16, 21
Digital Print Order Format
(DPOF) 115
DIRECT LINK 31
Display brightness 152
Display type 44
Drive 94
E
Enlarging 114
Exposure Value (EV) 15, 104
F
Fader 107
Files
Deleting 113
Photo type 75
Protecting 112
Video type 106
Flash
Bounce photography 26
Flash options 101
Guide number 25
Intensity 102
F-number 15
Focal length 20
Focus assist 90
Focus Peaking 90
I
Icons
Playback mode 43
Shooting mode 41
i-Function 67
i-Launcher 163
Image adjustment
Adjusting photos 120
Red-eye 121
Retouching faces 121
ISO sensitivity 76
i-Zoom 69
L
Lenses
Layout 45
Locking 46
Markings 49
Unlocking 46
M
Maintenance 170
Memory card
Caution 173
Insert 33
Metering 98
MobileLink 129
Index
198
Appendix > Index
O
One touch shot 89
Optical Image Stabilization
(OIS) 93
Optional accessories
Attach the GPS module 53
Connect the ash 51
Flash layout 50
GPS module layout 53
P
Panorama mode 59
Photos
Editing 118
Enlarging 114
Shooting options 74
Viewing on 3D TV 159
Viewing on camera 110
Viewing on HDTV 158
Picture Wizard 80
Posture 13
Power save mode 153
R
Red-eye eect
Playback mode 121
Shooting mode 102
Remote Viewnder 131
Resolution
Playback mode 119
Shooting mode (Movie) 106
Shooting mode (Photo) 74
Retouching faces 121
Rotating 119
Rule of thirds 23
S
Samsung Link 141
Service center 181
Settings 152
Shooting modes
Aperture Priority 62
Auto 55
Custom 65
Manual 64
Program 61
Recording 66
Shutter Priority 63
Smart 57
Shutter speed 17, 19
Slide show 114
Smart lter
Playback mode 122
Shooting mode 81
Smart panel 39
T
Thumbnails 110
Timer 95
Touch AF 88
Touch screen 40
Tracking AF 88
Transferring les
Mac 161
Windows 160
TV 158
U
Unpacking 28
V
Video Out 153
Videos
Capturing 117
Options 106
Recording 66
Viewing 116
W
White balance 77
Wireless network 124
3
3D mode 70
199
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government oce, for details of where and how
they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the
batteries in this product should not be disposed of with other household
waste at the end of their working life. Where marked, the chemical symbols
Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead
above the reference levels in EC Directive 2006/66. If batteries are not
properly disposed of, these substances can cause harm to human health or
the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them through
your local, free battery return system.
CAN ICES-3 (B)/NMB-3(B)
Dispose unwanted electronics through an approved recycler.
To nd the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
Appendix
200
Appendix
FCC notice
Caution:
Any changes or modications in construction of this device which are not
expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorientate or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaration of Conformity
Trade Name : Samsung Electronics America, Inc.
Model No. : Samsung NX2000
Responsible Party : Samsung Electronics America, Inc.
Address : 85 Challenger Road, Ridgeeld Park, NJ 07660
Telephone No. : 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RF exposure statements:
This device is for handheld operation only. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least
20 cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
FCC ID:A3LNX2000
201
Complies with
IDA Standards
DA100790
28938/SDPPI/2013
1760
TRC/SS/2013/69
TA-2013/332
APPROVED
No.: ESD-1307120C
Model : NX2000
Year of Manufacture : 2013
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Caution:
Any changes or modications to the equipment not expressly
approved by the party responsible for compliance could void
user’s authority to operate the equipment.
IC: 649E-NX2000
This equipment may be operated in all EU countries.
In France, this equipment may only be used indoors.
