WSX D & SPODRMD – WIRING TO GROUND (NO NEUTRAL)
WSX EZ D WIRING TO GROUND (NO NEUTRAL)
WSX D & SPODMRD – WIRING TO NEUTRAL
WIRE KEY
Dimming Wall Switch Wiring Diagrams
Wall Switch
Wiring Diagrams
DIMMING
DIMMING
DIMMING
DIMMING
(+)
(—)
(+)
(—)
(+)
(—)
(+)
(—)
WIRING TO GROUND (NO NEUTRAL) WIRING TO NEUTRAL
WIRING TO GROUND (NO NEUTRAL) WIRING TO NEUTRAL
WSX D 2
SPODMRD
DIMMING
DIMMING
DIMMING
DIMMING
(+)
(—)
(+)
(—)
(+)
(—)
(+)
(—)
WIRING TO GROUND (NO NEUTRAL) WIRING TO NEUTRAL
WIRING TO GROUND (NO NEUTRAL) WIRING TO NEUTRAL
WSX D 2
SPODMRD
NOTE:
1. Relay remains closed
2. Load BLK wire driver hot
120/277 VAC WIRING
- Line/Load Miswire Protected
347 VAC WIRING (-347 Option)
wires replace wires.
0-10 VDC
- Low Voltage Dim Output (0-10 VDC)
- Low Voltage Common
Per NEC requirements, the 0-10V violet and gray
wires must be installed as Class One.
The 0-10V control wires must not exceed 250 ft
(76 m) in length and must be sized at no less than
20AWG.
(+)
(— )
One Lithonia Way | Conyers, Georgia 30012 | Phone: 800.279.8041 | Fax: 770.918.1209 | www.lithonia.com
© 2014 Acuity Brands Lighting, Inc. All rights reserved. | Rev. 8/14 | Job No. LL_OP_0039
One Lithonia Way | Conyers, Georgia 30012 | Phone: 800.535.2465 | www.acuitycontrols.com
©2015 Acuity Brands Lighting, Inc. All rights reserved. | 10/15 | SSI_2204
One Lithonia Way, Conyers, GA 30012 | Phone: 800.535.2465 | www.acuitycontrols.com
© 2016 Acuity Brands Lighting, Inc. All Rights Reserved. | 3/16 | SSI_2844
WALL SWITCH – 1-POLE NEUTRAL/GROUND
WALL SWITCH – 2-POLE NEUTRAL/GROUND
SSD 120
WALL SWITCH – 1-POLE GROUND
WALL SWITCH – 2-POLE GROUND
PRESET TIMER SWITCH
WALL SWITCHES: LOW VOLTAGE
Wall Switch Occupancy Sensor Wiring Diagrams
BLK - 120 V
ORN - 277 V
R - RELAY OPTION
PP20
