A PR OU D H E R ITAG E OF E XPE R IE N C E & QU AL ITY
O W N E R ’ S M A N U A L
D U A L
- Z o n e
B
E V E R A G E &
W I N E
C O O L E R
EL-BWC101-01
W W W . O E . O
You r W i ne C el l ar
This unit can be used for storage and/or service. The unit has a glass door and soft interior
light that you can use to display your wine.
Serving Wines
Storing wines at the proper temperature is important. To preserve them as long as
possible wine should be stored at approximately 55° Fahrenheit. However, the chart below
suggests the optimal drinking temperature for the different styles of wine.
°C °F Wine Style
19
66
Armagnac, Brandy, Cognac
18
64
Full Bodied Red Wines, Shiraz
17
62
Tawny Port
15
59
Medium Bodied Red Wines
14
57
Amontillado Sherry
13
55
Light Bodied Red Wines
12
54
Full Bodied White Wines
11
52
Medium Bodied White Wines
10
50
Rosé, Light Bodied White Wines
9
48
Vintage Sparkling
8
46
Fino Sherry
7
45
Non Vintage Sparkling
General Operating Instructions
Remove all external and internal packaging from your appliance. Be sure that all parts
have been included before discarding any packaging materials. You may want to keep the
box and packing materials for use at a later date.
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged.
Let the unit rest UNPLUGGED for 24 hours once you have it placed in
your home.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
-Save these instructions-
To register your product, visit:
http://www.vinotemp.com/Warranty.aspx
Register your warranty within 10 days of receiving the unit.
Please be sure to retain your proof of purchase.
Protect Your Investment with an Extended Warranty!
Add a New Leaf extended warranty to your order, and have the security of knowing that if there should
be a problem, even years in the future, New Leaf will be there to assist! Usable for any Wine Cellar or
other electronic device manufactured by Vinotemp. Add this warranty to purchases made from
vinotemp.com or other qualified venders. Warranty must be registered within the first 10 days from
original purchase.
Visit www.Vinotemp.com to purchase.
W W W . O E . O
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
................................................................
6
ELECTRICAL CONNECTION
...................................................................................
7
PARTS AND SPECIFICATIONS
.............................................................................
8
BOTTLE CAPACITY
................................................................................................................ 9
INSTALLATION
...................................................................................................................10
OPERATING YOUR WINE COOLER
....................................................................
11
CARE AND MAINTENANCE
.................................................................................
13
TROUBLESHOOTING
.............................................................................................
14
TERMS OF SALE AND WARRANTY
....................................................................
15
SERVICE & IMPORTANT NOTICE
......................................................................
22
IMPORTANT SAFETY INSTRUCTIONS
•
Do not operate this or any other appliance with a damaged cord.
•
Do not operate if housing is removed or damaged.
•
Exercise caution and use reasonable supervision when appliance is used near children. Never allow
children to operate, play with or crawl inside the appliance. Keep packing materials away from children.
•
Before performing any maintenance or cleaning, ensure that the unit is unplugged or that the power line
is disconnected.
•
Do not clean appliance with flammable fluids. Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
•
Exercise caution when moving and installing the unit. The cooler is heavy and may require two or more
people when moving the unit to prevent strain or injury.
•
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 60°F and below 90°F.
•
Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc).This unit is
intended for indoor use only and must be installed in an area protected from the elements.
•
Place the appliance on a solid, level surface.
•
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
•
Connect to properly polarized outlets only. It is recommended that a separate circuit, serving only your
appliance be provided. Use receptacles that cannot be turned off by a switch or pull chain. Be sure that
the plug is fully inserted into the receptacle.
•
To protect against electric shock, do not immerse appliance, plug or cord in water or other liquids. Avoid
locating the unit in moist areas.
•
This appliance is designed to be built-in (fully-recessed) or freestanding.
•
Do not use this appliance for other than its intended purpose. For indoor, household use only.
•
Do not operate the unit with wet hands, while standing on a wet surface or while standing in water.
•
Do not use solvent-based cleaning agents or abrasives on the interior of the cooler. These cleaners may
damage or discolor the interior.
•
Keep fingers out of pinch point areas and be careful when closing doors if children are around.
•
This appliance is designed for storing and cooling wines. Do not store perishable food or medical
products within the unit.
•
When disposing of refrigerated appliances, special handling is often required. It is the consumer’s
responsibility to comply with federal and local regulations when disposing of this product.
•
Do not slide your wine cooler into place.
•
WARNING:
Risk of child entrapment and suffocation. Before you throw away this or an old unit, take off
the door. Leave the shelves in place, so that children may not easily climb inside.
•
Caution:flammable refrigerant used! When handing,moving and use of the refrigerator,make sure
to avoid either damaging the refrigerant tubing,or in creasing the risk of a leak.
W W W . O E . O
ELECTRICAL CONNECTION
For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding-
type plug, and should be used in combination with a properly connected grounding-type outlet.
•
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
•
The cord should be secured behind the unit and not left exposed or dangling to prevent accidental
injury.
•
A standard electrical supply (115V AC only, 60Hz, 15A), properly grounded in accordance with the
National Electrical Code and local codes and ordinances, is required.
•
Never unplug the unit by pulling the power cord. To disconnect the appliance, always grip the plug
firmly and pull straight out from the wall outlet. When moving the unit, be careful not to damage the
power cord.
•
The unit should always be plugged into its own individual electrical outlet with a voltage rating that
matches the rating label on the unit.
Extension Cord
CAUTION:
It is strongly recommended that you do not use an adapter
or an extension cord with this unit.
PARTS AND SPECIFICATIONS
Model No.
EL-BWC101-01
Voltage
AC 115V
Frequency
60 Hz
Ambient Temperature Range
41
-100℉/ Humidity
45~90%
Control Temperature Range
39
- 64℉/
41
- 64℉
Refrigerant
R
600
a/2.11 oz.
Power Consumption
0.4 kWh/24h
Input Power
160
W
Volume
5.8 cu. ft
Net Weight
132 lbs
Gross Weight
159 lbs
Dimensions (W x D x H)
29.5
in x
22.6 in
x 34.5 in
Box Dimensions (W x D x H)
30.9
in x 24
.4
in x 40
.4
in
Cans / Bottles Capacity
101Cans + 33Bottles
W W W . O E . O
*Note: EL-BWC101-01 storage capacity is based on a standard 330ml beverage can and a standard 750ml wine bottle.
Storing mineral water bottles or different size cans will decrease the bottles/cans capacity of the beverage & wine cooler.
VINOTEMP
Dual-Zone Beverage & Wine Cooler
BOTTLE CAPACITY
You may adjust the shelves of your wine cooler to accommodate more or less bottles.
If stacking bottles 2-3 high, please do not pull out the shelves.
EL-BWC101-01: Depending on how the bottles are placed,
you can store between approximately 101 cans on left side and 33 bottles
on right side.
INSTALLATION
•
Remove all packing material before using your wine cooler.
•
IMPORTANT
: Before connecting the unit to a power source, let it stand upright for approximately 24
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•
Clean the interior surface with lukewarm water and a soft cloth.
•
This unit is designed for freestanding or built in installation but indoor use only. Position the unit in a dry
and well-ventilated place. Avoid placing the wine cooler near any source of heat or moisture, or in direct
sunlight. Do NOT install the unit in a location with an ambient temperature that will fall below 60°F.
•
For built-in installation, leave a ¼” (6.35mm) space on each side and at the top of the wine cooler to
ensure proper air circulation to cool the compressor and condenser. Also, be sure to not obstruct the
front exhaust vent with any objects as this may affect the unit from performing properly.
•
For freestanding installation, 6” of space at the back, 10-12” of space on each side, and unlimited
clearance at the top of the wine cooler are suggested to ensure proper air circulation to cool the
compressor and condenser. Do not place underneath a table, counter top, or anything of the sort as this
will not allow for proper air circulation.
•
Do not slide the unit into place.
•
Place the wine cooler on a level surface strong enough to support it when it is fully loaded. To level the
wine cooler, adjust the front leveling legs at the bottom of the wine cooler.
•
For best performance it is recommended that you install the appliance in a location with an ambient
temperature between 41°-100°F. If the ambient temperature is above or below recommended
temperatures, the performance of the unit may be affected.
•
Plug the wine cooler into an exclusive, properly installed-grounded wall outlet.
INSTALLING THE STAINLESS STEEL HANDLE
This wine cellar includes a stainless steel handle that is not required to operate this unit. To install the handle
please follow the below instructions:
•
Pull away the door gasket in the area where
the handle is to be installed - you can see two
designated holes for handle installation. The
gasket is easily displaced by hand, no tools
are necessary.
•
Install the handle tightly as shown below with
the two screws, lock washers and flat washers
provided. (DO NOT over tighten as this will
cause damage to the handle assembly and
stainless steel surface of glass door).
•
Replace the door gasket to its original position.
W W W . O E . O
OPERATING YOUR BEVERAGE COOLER
●
The appliance should be placed where the ambient temperature is between 32°F to 91°F. If the
ambient temperature is above or below this range, the performance of the unit may be affected.
For example, placing your unit in extreme cold or hot conditions may cause interior temperatures
to fluctuate.
●
Connect power cord to a properly grounded outlet.
●
This appliance is equipped with Memory IC – should there be a power interruption, unit will auto
recover at last setting.
Control Panel:
ON/OFF Power
To turn the appliance on or off, press and hold the ON/OFF button for 3 seconds.
Setting the temperature Control
●
Adjustable temperature: 5℃ to 20℃
●
Set the desired temperature by pressing the corresponding buttons, to increase or to
decrease. Each press is in 1-degree increment. Once released, set temperature will flash for
approximately 5 seconds then revert back to display the internal temperature.
●
To view your set temperature, press either the or button once and LED display will flash
set temperature for 5 seconds.
●
The appliance has the capability to display temperature in either Celsius or Fahrenheit. To change
the temperature scale, press and hold both buttons simultaneously for approximately 3
seconds.
Note: The temperature of cans inside may vary slightly depending on whether or not the interior bulb is
ON or OFF and where the bottles are located (upper/middle or lower section).
RUN
When unit’s compressor is running, this indicator light will illuminate to signify that cooling mode is
currently in operation.
LIGHT/LOCK
●
Press to turn the interior light ON or OFF. Light will automatically turn off after 10 minutes. For best
cooling, keep the light off except when viewing.
●
Press and hold for 3 seconds to lock or unlock the control panel.
NOTE:
●
If the unit is unplugged, turned off or experienced a power failure, you must wait 3 to 5 minutes
before restarting the unit. If you attempt to restart before this time delay, the appliance will not start.
●
When you use the appliance for the first time, or restart after having been shut off for a long time,
there could be a few degrees variance between the set temperature and the displayed
temperature on the LED readout. This is normal and is due to the length of inactivity. Once the unit
runs for a few hours, everything will be back to normal.
Setting the Temperature Control
You can select temperature display setting from Fahrenheit to Celsius degree b
touching the ℃/℉ Selector mark. Fahrenheit or Celsius degrees indicator will appear
in blue color in the temperature display window for each zone. You can set the
temperature as you desire by touching the UP and DOWN marks. When you touch the
two marks for the first time, the LED readout will show the original temperature set
previously.
l
The temperature that you desire to set will increase 1 ℃or 1 ℉ if you touch the
UP mark once, on the contrary the temperature will decrease 1 ℃or 1℉ if you
touch the DOWN mark once.
l
Temperature range : 5-20℃/41-68℉
l
The temperature inside the unit will be appeared in blue color in the display
window.
Shelves
l
To prevent damaging the door gasket, make sure the door is fully open when
pulling shelves out of the rail compartment.
l
For easy access to the bottles stored, pull the shelves out approximately 1/3.The
shelves are designed with an emergency stop to prevent the being removed too far
when loaded.
l
The shelves has been designed so that a range of shelf height can be selected. All
the shelves can be adjusted.
W W W . O E . O
DOOR LOCK
The wine cooler comes with a lock and key combination. The keys are located inside the plastic bag
containing the Owner’s Manual. To unlock the door, insert the key into the lock and turn it counter-clockwise.
To lock the door, insert the key and turn it clockwise, ensuring that the metal pin is fully engaged.
DEFROSTING
The wine cooler defrosts automatically. The evaporator behind the rear wall of the unit automatically defrosts
and the condensate collects in the drainage channel behind the rear wall of the unit, and flows through the
drainage hole into the drip tray by the compressor, where it evaporates.
CARE AND MAINTENANCE
CLEANING YOUR WINE COOLER
IMPORTANT
: Always unplug the unit before cleaning or performing maintenance. Never use harsh
cleansers or scouring pads to clean any part of the unit.
•
Turn off the power, unplug the appliance, and remove all items including shelves.
•
Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
•
Wash the shelves with a mild detergent solution.
•
Wring excess water out of the sponge or cloth before cleaning control panels or any electrical parts.
•
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a
clean soft cloth.
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature of your appliance.
If the power is off for an extended period of time, proper steps should be taken to protect your contents.
INACTIVITY
If the unit will not be used for a period of less than three weeks, leave the cooler operating. If the period of
inactivity is several months, remove all items and turn the unit off. Clean and dry the interior thoroughly.
Leave the door open slightly to prevent any possible moisture build-up.
MOVING YOUR WINE COOLER
Before moving your wine cooler, first be sure to remove all items from the cooler.
•
Securely tape down any loose items, such as shelves, inside the unit.
•
Turn the adjustable leg up to the base to avoid damage.
•
Tape the door shut.
•
Ensure that the unit stays securely in the upright position during transportation. Protect the outside of
the appliance with a blanket or similar item.
ENERGY SAVING TIPS
•
The unit should be located in the coolest area of the room away from heat sources or direct sunlight.
•
Ensure that the unit has proper allowances on all sides for proper ventilation. Never cover any air
vents.
•
Only open the cooler door for as long as necessary. Frequent opening of the door will affect internal
temperature.
PROBLEMS WITH YOUR WINE COOLER
Most common problems can be solved easily, saving you the cost of a possible service call. Try the following
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
Wine Cooler does not operate
•
Ensure unit is plugged into an electrical outlet.
•
Check if unit is turned off.
•
Check for a tripped circuit breaker or blown fuse.
Wine Cooler is not cold
enough
•
Check the temperature control setting.
•
External environment or ambient temperature may require a higher
setting.
•
Check if door does not close completely or is open too often.
•
Check if door gasket does not seal properly.
Wine Cooler turns on and off
frequently
•
The room temperature may be hotter than normal.
•
Check if door does not close completely or is open too often.
•
Check if door gasket does not seal properly.
•
The temperature control is not set correctly.
Wine Cooler light does not
work
•
Ensure unit is properly plugged in.
•
Check for a tripped circuit breaker or blown fuse.
•
Check if the light switch is OFF.
Wine Cooler makes too much
noise or vibrates
•
Check to ensure the unit is level.
•
The rattling noise may come from the flow of refrigerant. This is
normal.
•
As each cycle ends, you may hear gurgling sounds caused by the
flow of refrigerant in the unit. This is normal.
•
Contraction and expansion of the inside walls may cause popping
and crackling noises.
Wine Cooler door will not
close properly
•
Check to ensure the unit is level.
•
The door was reversed and was not properly installed.
•
The gasket is dirty.
•
The shelves are out of position.
W W W . O E . O
One side of the unit works,
and the other side stops
•
Check if the magnet value leads to one zone not working.
•
Check if the pipe near the value needs to be sealed. There is a
three-way pipe. The pipe on one side is working properly, but the
pipe on the other side needs to be sealed if necessary.
•
The unit is only cooling on one side. Wine zone is coming down
in temperature, but the beverage zone is not. This is normal.
Cancellation or Fees Terms:
Shipping/Delivery fees are the responsibility of the Purchaser. Seller is not responsible for the
carrier’s missed/Non delivery for any reason. Delivery is curbside. Optional upgrades in delivery
service is an additional fee. If upgraded delivery service cannot be performed properly,
Purchaser agrees to accept delivery curbside and the difference in upgraded cost will not be
refunded. If item with free shipping/freight is canceled in transit, a charge of 25% of the price of
the unit/s plus freight costs both ways will be charged. All damages must be noted at time of
delivery on BOL and Seller to be notified within 48 hours of delivery of such damage. Purchaser
acknowledges if cancelation is authorized by Seller, a 35% restocking fee and freight both ways
will be charged. No cancelation or refund on made-to- order products. If an order has been
placed and production has not started, cancellation fee of 15% of total amount will be charged.
Cancelled orders paid by Credit Card will have an additional fee of 3% deducted from the total
refund. Refurbished units are sold as is. Purchaser assumes risks to the quality and performance
of goods and assumes the costs of all necessary service or repair not covered herein.
(Box here for check mark) Accept Terms & Conditions
Vinotemp International Corp. (“Seller”) and the person or entity that acquires these goods from
Seller (“Purchaser”) hereby fully agrees to the following terms and conditions of the sale:
Shipping/Delivery fees are the responsibility of the Purchaser whether freight prepaid or
freight collect. Seller assumes responsibility for the goods sold to the Purchaser until the goods
have reached Purchaser’s delivery address (FOB Destination) and the delivery receipt is signed
clear. Seller is not responsible for the carrier’s late delivery, missed delivery, unpaved roads,
remote locations, stairs, elevators, narrow door openings and other such issues in attempting
to fit or deliver the goods into the Purchaser’s location. Delivery to remote locations may
require additional fees. Remote location may be defined at the discretion of the carrier as more
or less than 50 miles from the nearest major city. Purchaser assumes all responsibility for
additional costs related to freight such as access, measurement, installation, hookup, wiring,
moving and storage of the goods, flight of stairs, carrier’s inability to safely and/or adequately
deliver, inability to use the building elevator to lift the goods, narrow openings, along with any
additional costs to deliver or redeliver the product properly. Make sure to review access to the
property and size of the product ordered. The transportation of all goods is subject to the terms
and conditions which the carrier imposes on Purchaser. Installation is the responsibility of the
Purchaser. If white glove delivery was ordered and cannot be performed properly, or access is
hindered in any way, Purchaser agrees to accept delivery curbside (delivery service cannot be
refunded). If Purchaser will-calls or pays for their own freight responsibility transfers to the
Purchaser when the Purchaser or Purchasers freight company picks up the unit from Seller.
Freight quoted are either curbside, threshold or white glove. Standard white glove delivery is
main floor, easy access and NO STAIRS, Doors, aligned feet attached (if necessary) and removal
of packaging, additional fees for additional requests. Each service has a different rate and will
require additional fees. If freight is not charged (Free Shipping or Freight Included) and the
order is cancelled after shipping, a freight charge of 25% of the cost of the unit, each direction
will be charged. Item swap outs are arranged as curbside delivery and pickup unless noted
otherwise. There is no white glove service for returns. Approved returns must have original
and/or proper packaging. Swap-outs (Delivery and Pick up are at the same time) Original unit
must be packed and ready for carrier pick up at time of delivery of new unit. Packaging of old
unit must be adequate for shipping, not oversized or on a pallet if unit was not originally
delivered on a pallet. Carrier will not drop off new unit if the original unit is not ready. If the
carrier has to make a second attempt, customer will be subject to additional charges for the
attempted delivery and for any packaging issues. Deliveries include ONE attempt by the
shipping company to deliver the product to the consumer. If for any reason the customer is
unavailable to accept the order and the product is undeliverable under any circumstances, the
customer will be responsible for any extra shipping and handling charges. We are a
manufacturer not a shipping company, deliveries are done by a 3rd party service. Email us at
info@vinotemp.com for a quote or any additional information. Freight discussed is Continental
USA (excluding Alaska, Puerto Rico, Hawaii), cost is additional please email info@vinotemp.com
for a quote.
California Proposition 65 Warning: The products sold on this ecommerce website and to the
public may contain chemicals and other substances known to the State of California to cause
cancer and birth defects and other
reproductive harm.
Totes made of vinyl, imitation leather, and/or leather material contain lead and/or other
substances that are known to the State of California to cause cancer, birth defects and other
reproductive harm.
Microfiber “Plastic microfiber” means a small synthetic particle that is fibrous in shape, less
than 5 millimeters in length, and is released into water through the regular washing of textiles
made from synthetic material.
Composite wood: May contain formaldehyde.
Galvanized metal and some of its constituents contain lead and/or other substances that are
known to the State of California to cause cancer, birth defects and other reproductive harm.
Products made of vinyl contain lead, Diethyl Hexyl Phthalate (DEHP), and/or other substances
that are known to the State of California to cause cancer, birth defects and other reproductive
harm.
Acrylic may contain Acrylic Acid and/or other substances that are known to the State of
California to cause cancer, birth defects, and other reproductive harm.
Appliances may contain tin or lead in either the paint or the controllers, and/or other
substances that are known to the State of California to cause cancer, birth defects, and other
reproductive harm.
Our barware items may contain plastic, acrylic, enamel, crystal, metal and/or other substances
that are known to the State of California to cause cancer, birth defects, and other reproductive
harm.
Appliances may contain Tin, Lead or Nickel
Damage: All damages must be noted at time of delivery. If a bill is signed that there is no
damage, buyer accepts delivery as free and clear. Any claim for damages of the goods, when
FOB Destination, that incurred during shipment by the carrier are insured and handled directly
with the carrier by the Seller if noted on the receipt and notified within 48 hours of delivery.
W W W . O E . O
OPEN AND INSPECT YOUR DELIVERY. When FOB Destination, if the item is damaged by the
freight company, and Purchaser cancels rather than accepts a replacement, the order can be
cancelled by paying for freight costs both ways and a 35% restocking fee for stocked items. No
cancellation or refunds on custom/made or made to order products. When shipped 3rd Party
(FOB Warehouse), Purchaser assumes all responsibility for delivery, payment of freight and
freight claims for damages during shipment. Manufacture defects will be handled directly with
Seller, subject to the limited warranty below.
Fees: All sales are final. Unless authorized in writing by the Seller, Purchaser may not return the
goods under any circumstance. If Seller agrees in writing to take back stocked
goods, there will be a restocking/service fee that is 35% of the purchase price of the goods and
freight both ways (product must be new, unused, and in original packaging). If Purchaser
returns goods claiming that the goods are defective and goods are found to be in working
condition by the Seller, Purchaser is liable for the cost of freight both ways plus and a service
fee that is 35% of the purchase price of the goods. Built to Order and Custom products are
nonreturnable, nonrefundable. Purchaser must notify Seller of nonconforming goods within 48
hours of receipt, after which time all goods are deemed accepted by the Purchaser. If an order
has been placed and production has not started, cancellation of your order will be a 15% charge.
If Purchaser tenders payment with a check that has insufficient funds (NSF), a collection fee
plus NSF fee of $50 will be added to the invoice, which Purchaser agrees to pay promptly. If
Purchaser puts a stop payment on a check or credit card for any reason, Purchaser agrees to
pay for all costs associated with the Seller’s collection or litigation of such a claim, including,
without limitation, general and special damages, court costs and attorneys’ fees. Finance
charges begin the date of invoice. Title to the goods reverts back to the Seller in the case of
nonpayment of goods or services. All fees and costs to retrieve the product, cost of freight,
legal costs, collection fees and court fees, credit card fees and interest rate of 18% (annual rate)
will be the responsibility of the Purchaser. In a credit card dispute, Purchaser assumes and must
immediately pay any “credit card arbitration” fees and chargeback fees which the credit card
companies charge at the time of the chargeback. Cancelled orders using a Credit Card will have
an additional fee of 3% deducted from the refund.
Any disputes not resolved within 30 days from the invoice date will be reported to credit
reporting agencies.
LIMITED WARRANTY: Seller warrants that the goods will be free of defects in materials and
workmanship as follows:
Furniture style (wood) wine cabinets made in the U.S.: all cooling unit parts only for a period of
1 (year) year; cabinetry and labor (uninstalled) for a period of 12 (twelve) Months (Model
numbers “Vino” and “Custom”.
Metal cabinet units (appliances) (compressor) (made in China and Denmark)(Model numbers
start with EL, VT, IL, or EP: parts and labor for cooling system and cabinetry for a period of 12
(twelve) months.
Thermoelectric Units: 90 (ninety) days (including Wine and Beverage Coolers, Beer Dispensers,
Humidor, Portofino Wood Cellars, and Refrigerators). (Models start with EL, VT, IL or EP).
WineMate and Cellar Tec (WM, Wine Mate or CT)(Wine Cooling Units) Split and Ducted
OPEN AND INSPECT YOUR DELIVERY. When FOB Destination, if the item is damaged by the
freight company, and Purchaser cancels rather than accepts a replacement, the order can be
cancelled by paying for freight costs both ways and a 35% restocking fee for stocked items. No
cancellation or refunds on custom/made or made to order products. When shipped 3rd Party
(FOB Warehouse), Purchaser assumes all responsibility for delivery, payment of freight and
freight claims for damages during shipment. Manufacture defects will be handled directly with
Seller, subject to the limited warranty below.
Fees: All sales are final. Unless authorized in writing by the Seller, Purchaser may not return the
goods under any circumstance. If Seller agrees in writing to take back stocked
goods, there will be a restocking/service fee that is 35% of the purchase price of the goods and
freight both ways (product must be new, unused, and in original packaging). If Purchaser
returns goods claiming that the goods are defective and goods are found to be in working
condition by the Seller, Purchaser is liable for the cost of freight both ways plus and a service
fee that is 35% of the purchase price of the goods. Built to Order and Custom products are
nonreturnable, nonrefundable. Purchaser must notify Seller of nonconforming goods within 48
hours of receipt, after which time all goods are deemed accepted by the Purchaser. If an order
has been placed and production has not started, cancellation of your order will be a 15% charge.
If Purchaser tenders payment with a check that has insufficient funds (NSF), a collection fee
plus NSF fee of $50 will be added to the invoice, which Purchaser agrees to pay promptly. If
Purchaser puts a stop payment on a check or credit card for any reason, Purchaser agrees to
pay for all costs associated with the Seller’s collection or litigation of such a claim, including,
without limitation, general and special damages, court costs and attorneys’ fees. Finance
charges begin the date of invoice. Title to the goods reverts back to the Seller in the case of
nonpayment of goods or services. All fees and costs to retrieve the product, cost of freight,
legal costs, collection fees and court fees, credit card fees and interest rate of 18% (annual rate)
will be the responsibility of the Purchaser. In a credit card dispute, Purchaser assumes and must
immediately pay any “credit card arbitration” fees and chargeback fees which the credit card
companies charge at the time of the chargeback. Cancelled orders using a Credit Card will have
an additional fee of 3% deducted from the refund.
Any disputes not resolved within 30 days from the invoice date will be reported to credit
reporting agencies.
LIMITED WARRANTY: Seller warrants that the goods will be free of defects in materials and
workmanship as follows:
Furniture style (wood) wine cabinets made in the U.S.: all cooling unit parts only for a period of
1 (year) year; cabinetry and labor (uninstalled) for a period of 12 (twelve) Months (Model
numbers “Vino” and “Custom”.
Metal cabinet units (appliances) (compressor) (made in China and Denmark)(Model numbers
start with EL, VT, IL, or EP: parts and labor for cooling system and cabinetry for a period of 12
(twelve) months.
Thermoelectric Units: 90 (ninety) days (including Wine and Beverage Coolers, Beer Dispensers,
Humidor, Portofino Wood Cellars, and Refrigerators). (Models start with EL, VT, IL or EP).
WineMate and Cellar Tec (WM, Wine Mate or CT)(Wine Cooling Units) Split and Ducted
W W W . O E . O
5
warranty. Change Orders: Custom units already in production that require a change will be
subject to a change order fee.
Storage Fees: When having an item serviced by a Vinotemp service technician at the Vinotemp
facility, Purchaser agrees to pick up their repaired item or make arrangements for return
shipping within a 30 day period once they have been notified by Vinotemp through phone call,
email, or letter that their unit is ready for pick up. If the item remains in the Vinotemp
warehouse after 30 days but no longer than 60 days, the Purchaser will incur additional storage
fees of 2%. After 60 days in storage, the item will become property of Vinotemp. For custom
units with deposits: If product is not picked up or shipped within 60 days of completion,
Purchaser deposit is forfeited and product becomes the property of Vinotemp. Warranty period
is from the date of sale (not from shipping, delivery, nor installation). All completed cabinetry,
racking, or other custom work must be picked up or shipped within a period of 14 days after
Vinotemp has notified the Purchaser by phone call, email, or letter. Any completed cabinetry,
racking, or other custom work stored longer than 14 days will incur an additional monthly
storage fee. After 60 days, the product will become property of Vinotemp.
This Limited Warranty does not cover damage due to such things as accident, misuse, abuse,
mishandling, neglect, acts of God, fires, earthquakes, floods, high winds, government, war, riot
or labor trouble, strikes, lockouts, delay of carrier, unauthorized repair, or any other cause
beyond the control of the Seller, whether similar or dissimilar to the foregoing. Seller is not
responsible for any damages caused to Purchaser's property resulting from the goods. This
limited warranty applies only inside the Continental US (Alaska, Puerto Rico, Hawaii and other
territories/countries are not warranted). Purchaser understands and acknowledges that the
goods sold here are wine cellars, cigar humidors, and/or other similar units which house wine
or cigars or other items. Purchaser assumes all risk of using these units, including risk of
spoilage, humidity variations, temperature variations, leaks, fire, water damage, mold, mildew,
dryness and similar and any other perils that might occur. Seller is not responsible for incidental
or consequential damages, and there are no warranties, expressed or implied, which extend
beyond the Limited Warranty described above. Warranty and liability are nontransferable. The
implied warranties of merchantability and of fitness for a particular purpose are hereby
expressly disclaimed. Some states do not allow the exclusion of incidental or consequential
damages, or a waiver of the implied warranties of fitness and/or merchantability, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may also
have other rights which vary from state to state. Seller disclaims any indemnification for claims
of infringement of any intellectual property of protectable nature. In the event of any dispute
between Seller and Purchaser arising out of or relating to these terms and conditions or to the
goods sold generally, Purchaser must first file a written claim with Seller within ten days of the
occurrence giving rise to the claim and wait an additional thirty days for a response before
initiating any legal action. The sale and all terms are subject to California law. Any legal
proceeding arising out of or relating to these terms and conditions or to the goods sold
Purchaser shall bring, solely and exclusively in the County of Los Angeles. In no event may
Purchaser initiate any legal proceeding more than six months after the occurrence of the event
giving rise to the dispute. Seller may make nonpayment claims until debt is paid in full. Any
dispute or claim relating in any way to these to the Terms and Conditions, the Website, or any
products or services sold or distributed by or through this Website, store, or catalog will be
resolved by binding arbitration, rather than in court, except that you may assert claims in small
claims court if your claims qualify. The Federal Arbitration Act and federal arbitration law apply
to the Terms and Conditions. We each agree that any dispute resolution proceedings will be
conducted only on an individual basis and not in a class, consolidated or representative action.
If for any reason a claim proceeds in court rather than in arbitration we each waive any right to
a jury trial. Both parties agree to bring suit in court to enjoin infringement or other misuse of
intellectual property rights.
The above terms and conditions are the only ones governing this transaction and Seller makes
no oral representations of any kind. These Terms and Conditions can only be modified in writing,
signed by both Purchaser and Seller.
SPECIFIC WARRANTY BELOW for SCRATCH & DENT/OPEN BOX/ REFURBISHED/FLOOR
MODELS/ CLOSEOUTS, OVERSTOCK: TERMS AND CONDITIONS OF SALE
Vinotemp (and its brands Element, Wine Mate, Cellar Tec, Apex Wine Racks, Epicureanist Il
Romanzo, Brama(“Seller”) and the person of the entity that acquires these goods from Seller
(“Purchaser”) hereby fully aggress to the following terms and conditions of the sale:
1. Freight: Vinotemp is not a freight, moving or installation company, if Freight is arranged for
the Buyer, the Seller assumes no responsibility for the goods sold to the Purchaser once the
goods have left the Seller’s premises, including, but not limited to, late delivery by the moving
carrier, or for events caused by any difficulty carrier incurs in attempting to fit the goods into
the Purchaser’s place of business or residence due to the size of the goods or otherwise, such
as the disassembly and reassembly of the goods. Purchaser assumes all responsibility for
delivery, payment of freight, extra fees, access, measurement, installation, hook-up, moving
and storage of the goods. The transportation of all goods is subject to the terms and conditions
which the moving carrier imposes on Purchaser including, but not limited to, additional charges
imposed per flight of stairs, and/or additional charges resulting from the carrier’s inability to
safely and/or adequately use the building elevator to lift the goods to an upper floor. Any claim
for damages incurred during shipment by the carrier of the goods are insured and handled
directly with the carrier and must be noted at time of delivery.
2. All sales are final, and unless authorized in writing by the Seller, Purchaser is not entitled to
return goods, under any circumstances. If Purchaser refuses to accept goods, the Purchaser is
liable for the return and cost of freight both directions and a restocking/service fee that is 35%
of the purchase price of the goods. Purchaser must notify Seller of non-conforming goods
within four days of delivery, after which time all goods are deemed accepted.
3. If Purchaser tenders payment with a check that has insufficient funds (NSF), or stops
payment on a check or credit card for any reason, Purchaser agrees to pay for all costs
associated with the Seller’s connection or litigation of such a claim, including without limitation
W W W . O E . O
LIABILITY ARE NON-TRANSFERABLE. THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF
FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXPRESSLY DISCLAIMED. SELLER DISCLAIMS
ANY INDEMNIFICATION FOR CLAIMS OF INFRINGEMENT OF ANY INTELLECTUAL PROPERTY OF
PROTECTABLE NATURE.
9. In the event of any dispute between Seller and Purchaser arising out of or relating to these
terms and conditions or to the goods sold generally, Purchaser must first file a written claim
with Seller within thirty days of the occurrence giving arise to the claim and wait an additional
thirty days for a response before initiating any legal action. Any legal proceeding arising out of
or relating to these terms and conditions or to the goods sold generally shall be brought solely
in the County of Los Angeles. The prevailing party in any such proceeding is entitled to its
attorney’s fees and costs. In no event may Purchaser initiate any legal proceeding more than six
months after the occurrence of the event giving rise to the dispute.
10. Delivery is curbside. Upgrades in delivery will require an additional fee.
The above terms and conditions are the only ones governing this transaction and Seller makes
no oral representations of any kind. These Terms and Conditions can only be modified in writing,
signed by both Purchaser and Seller. 02/05/2019
SERVICE & IMPORTANT NOTICE
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged.
Contact our customer service at 1-800-777-8466 or info@vinotemp.com.
The manufacturer has a policy of continuous improvement on its products and
reserves the right to change materials and specifications without notice.
WARNING:
Please do not place the unit within reach of children.
For adult use only.
Contact info@vinotemp.com with any questions or visit
www.vinotemp.com
732 S Racetrack Road,
Henderson NV 89015
www.vinotemp.com
Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to
change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for
errors, omissions, or future changes.
© 2019 Vinotemp International. All rights reserved.
