EN 2-in-1 Upright vacuum cleaner
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE
• This vacuum cleaner may be used by children 8years
of age and older and by persons with physical or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how to
use this vacuum cleaner in asafe manner and understand
the potential dangers.
• Children must not play with the appliance. Cleaning
and maintenance performed by the user must not be
performed by unsupervised children.
• In the event that the power adapter is damaged, it must be
replaced with an original type. For areplacement power
adapter, please contact an authorised service centre. It is
forbidden to use the appliance if it has adamaged power
adapter.
• Only use the vacuum cleaner with the original power
adapter and accessories that were supplied with it.
• Keep the vacuum cleaner and its accessories out of reach of children that are younger than 8 years of age.
• Disconnect the power adapter from the power socket before cleaning or performing maintenance on the appliance.
• This vacuum cleaner is designed for use in households, offices and similar types of areas. Do not use in industrial surroundings.
• Do not expose the vacuum cleaner to direct sunlight and do not place it near an open fire or appliances that are asource of heat.
• Before connecting the power adapter to apower socket, check that the technical details on the vacuum cleaner’srating label match the electrical
voltage in the socket.
• Make sure the adapter power cord is not touching ahot surface or sharp objects. Position the adapter power cord so that it will not be tripped over.
• Never submerge the vacuum cleaner or the power adapter in water or any other liquid and do not wash it under running water.
• Prior to turning on the vacuum cleaner, check that the dust container is correctly installed and the filters are correctly inserted.
• When the vacuum cleaner is running, ensure that the air outlets and the suction hole are not blocked.
• Do not use the vacuum cleaner to vacuum the following items:
- smouldering cigarettes, burning items, matches or embers;
- water and other liquids;
- flammable or volatile materials;
- 2 -
09/2022
2022, .
- sharp items, e.g. broken glass, needles, pins, etc.;
- flour, wall plaster, cement and other building materials;
- larger pieces of paper or plastic bags, which can easily block the suction hole.
• Vacuuming of some types of floors or floor surfaces can create an electrostatic discharge, which presents no danger to the user.
• Always turn off the vacuum cleaner when you have finished using it, before cleaning or seating it in the charging base.
• Disconnect the power adapter from the power socket before cleaning it and after it has finished charging.
• Disconnect the power adapter from the power socket by pulling on the plug, never pulling on the power cord. Otherwise, this could damage the
power adapter or the socket.
• Do not use the vacuum cleaner if it is not working correctly, if it has been damaged or has been submerged in water. Do not repair the vacuum
cleaner yourself or make any adjustments to it. Have all repairs performed at an authorised service centre. By tampering with the appliance, you
risk voiding your legal rights arising from unsatisfactory performance or quality warranty.
- 3 -
09/2022
2022, .
• Prior to using this appliance, please read the user‘smanual thoroughly,
even in cases, when one has already familiarised themselves with
previous use of similar types of appliances. Only use the appliance in
the manner described in this user’smanual. Keep this user‘smanual in
asafe place where it can be easily retrieved for future use.
• We recommend saving the original cardboard box, packaging material,
purchase receipt and responsibility statement of the vendor or warranty
card for at least the duration of the legal liability for unsatisfactory
performance or quality. In the event of transportation, we recommend
that you pack the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE VACUUM CLEANER AND ITS ACCESSORIES
A1 Handle
A2 On/Off button of the upright
vacuum cleaner
A3 Body of the upright vacuum
cleaner
A4 Hand vacuum cleaner
A5 Floor nozzle release button
A6 Floor nozzle with an electric
rotary brush
A7 Locking screw
A8 Hand vacuum cleaner release
button
A9 Travel wheels
A10 Dust container
A11 Dust container release button
A12 Battery level indicator
A13 Suction power adjustment
button of the upright vacuum
cleaner
A14 On/Off button of the hand
vacuum cleaner
A15 Hand vacuum cleaner handle
A16 Air outlets
A17 Suction hole
A18 Washable inner HEPA type
filter.
A19 Washable outer filter
A20 Power adapter
A21 Brush nozzle
A22 Crevice nozzle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Before first use, take the appliance and its accessories out of the
packaging material and remove all promotional labels and stickers.
Check that neither the appliance nor any of its parts is damaged.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASSEMBLY AND DISASSEMBLY
Assembling and disassembling the hand vacuum cleaner
When assembling the hand vacuum cleaner A4, proceed as follows:
1. Insert the inner filter A18 into the outer filter A19.
2. Insert both filters into the dust container A10 and check that they are
properly inserted.
3. Put the dust container A10 on to the motor unit of the hand vacuum
cleaner.
If you need to disassemble the hand vacuum cleaner A4, proceed as
follows:
1. Press button A11, to release the dust container A10. Take the dust
container A10 off the motor unit.
2. Out of the dust container A10, remove the outer filter A19 and the inner
filter A18.
Assembling and disassembling the upright vacuum cleaner
For reasons of safety during transport, the upright vacuum cleaner is
supplied disassembled.
1. Attach the handle of the upright vacuum cleaner A1 to the body of
the vacuum cleaner A3 so that the handle is aligned with the hole in
the body of the vacuum cleaner. Insert the supplied screw A7 into the
hole and screw it in properly – see figure B1. Check than the handle is
correctly attached and not moving in any way.
2. Into the free space in the body of the vacuum cleaner A3, insert the
hand vacuum cleaner A4 by first inserting the suction hole A17 into the
bottom part of the body of the vacuum cleaner A3 and then carefully tilt
down the handle A15 until you hear aclick.
3. Insert the floor nozzle A6 into the suction hole A17 of the hand vacuum
cleaner – see figure B2 until you hear aclick.
4. If you need to disassemble the upright vacuum cleaner, first remove
the hand vacuum cleaner A4 from the body A3 by pressing button A8.
Then press button A5 to release the floor nozzle A6. Finally screw out
the locking screw A7 and carefully pull out the handle A1 from the body
of the vacuum cleaner A3.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHARGING THE VACUUM CLEANER
• Turn off the upright vacuum cleaner and set it to the vertical parking
position. Insert the power adapter plug A20 into the socket in the
vacuum cleaner - see figure D. Plug the power adapter plug A20 into
a power socket.
• The charging of the built-in battery will automatically start and the
battery power indicator A12 will indicate the charging status. A full
charge requires approximately 4.5 hours. The actual charging time
depends on the power level of the battery.
• When the charging process is completed, all the LEDdiodes of the
indicator A12 will be lit. Disconnect the power adapter A20 from the
power socket.
• The LED diodes of the battery level indicator A12 indicate the charge
level of the battery. The individual LED diodes will turn off as the
battery gradually discharges. When the battery is almost flat, the
bottom LEDdiode will start flashing. When it turns of completely, the
battery is completely flat.
Note:
Prior to starting recharging, it is important for the vacuum
cleaner to be turned off and standing in the vertical parking
position. Do not turn on the vacuum cleaner when it is being
recharged and the power adapter A20 is connected to the
power socket.
Note:
This vacuum cleaner contains aLi-ion battery. To ensure
the longest possible lifetime of the battery, we recommend:
- Do not unnecessarily leave the battery fully charged or
completely flat for too long.
- Do not keep the battery permanently fully charged. Its
lifetime will be extended by keeping it at approximately
half charge.
- Do not fully discharge the battery.
PARKING POSITION OF THE VACUUM CLEANER
• Put the upright vacuum cleaner into the parking position by placing
the tip of your foot on top of the floor nozzle A6 and with asimple
forward movement of the handle secure the vacuum cleaner in the
vertical position. The latch located at the front on the elbow of the
floor nozzle A6 will slide into the groove on the top cover of the floor
nozzle A6.
• To release the upright vacuum cleaner from the parking position, place
the tip of your foot on top of the floor nozzle A6 and tilt the handle
backwards. The latch located at the front on the elbow of the floor
nozzle A6 will slide out of the groove on the top cover of the floor
nozzle A6.
USING THE VACUUM CLEANER
Upright vacuum cleaner
• You may use the upright vacuum cleaner for vacuuming various types
of floor coverings such as for example hard floor coverings, carpets,
etc.
• Hold the vacuum cleaner by the handle and release it from the
parking position. After releasing it from the parking position, the handle
may be moved in the vertical direction.
• Start the vacuum cleaner by pressing button A2. The vacuum cleaner
will start at full suction power. If you need to reduce the suction power,
EN
2-in-1 Upright vacuum cleaner
User'smanual
- 4 -
09/2022
2022, .
press button A13. The suction power of the vacuum cleaner will be
reduced. Press button A13 again to again increase the suction power.
• When you have finished using it, turn off the vacuum cleaner by
pressing button A2. Clean it according to the instructions contained in
chapter „Cleaning and maintenance“, and allow it to charge according
to the instructions contained in chapter „Charging the vacuum
cleaner“.
• In the event that the rotary brush is clogged while vacuuming, e.g.
by alarger amount of vacuumed hair or fur, the automatic safety
mechanism is activated, which will stop the rotary brush to prevent it
from becoming damaged. Turn off the vacuum cleaner using button
A2 and remove the wound on hair or fur from the rotary brush – more
in chapter „Cleaning and maintenance“. Prior to turning on the
vacuum cleaner again, check that the rotary brush, the dust container
A10 and the filters A18 andA19 are clean.
Hand vacuum cleaner
• The hand vacuum cleaner is suitable for vacuuming locally soiled floor
coverings, furniture, etc.
• In order to remove the hand vacuum cleaner from the body of the
upright vacuum cleaner, press button A8 and the top part of the hand
vacuum cleaner will be released. Hold the hand vacuum cleaner by
the handle A15 and carefully remove it from the body of the upright
vacuum cleaner.
• Turn on the hand vacuum cleaner by pressing button A14.
• To vacuum dust and dirt from hard-to-reach places, put the crevice
nozzle A22 on to the suction hole A17.
• If you need to vacuum dust and dirt from upholstered furniture, put the
brush nozzle A21 on to the suction hole A17.
• When you have finished using it, turn off the vacuum cleaner using
button A14. Clean it according to the instructions contained in chapter
„Cleaning and maintenance“, and insert it back into the body of
the upright vacuum cleaner. Allow it to recharge according to the
instructions in chapter „Charging the vacuum cleaner“.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AND MAINTENANCE
• Before cleaning, make sure that the vacuum cleaner is turned off and
the power adapter is disconnected from the power socket. In order
to extend the lifetime of the vacuum cleaner, we recommend you
perform cleaning and maintenance after every use.
Warning:
To prevent the risk of injury by electrical shock, do not
submerge the appliance, power cord or power plug in
water or any another liquid.
Dust container and filters
• Press button A11 to release the dust container A10 from the body of
the hand vacuum cleaner – see figure E1. Move the dust container A10
over awaste bin. Carefully pull the filters A18 andA19 out of the dust
container A10 – see figure E2.
• Tip out all the contents of the dust container A10 and rinse it out
as necessary under acurrent of cold running water. Allow it to dry
and check that the dust container A10 is completely dry before
reassembly.
• Pull the inner filter A18 out of the outer filter A19. Remove dust and dirt
from the outer filter A19 rinse it out as necessary under acurrent of
cold running water. Allow it to dry and check that the outer filter A19 is
completely dry before reassembly.
• Carefully remove any soils from the inner filter A18. If the inner filter
A18 is excessively soiled, rinse it under running water. Allow it to dry
naturally.
• Assemble the dust container A10 and filters A18 and A19 in reverse
sequence.
Warning:
Before assembling the vacuum cleaner, make sure
that all its parts are completely dry. Prior to starting it,
make sure that all the filters are properly installed in
their place. Otherwise, this could damage the vacuum
cleaner.
When filters are soiled, their effectiveness is reduced,
so do not neglect their cleaning.
• It is recommended to replace the inner filter A18 with anew one after
6months of use. Spare filters are available at brick and mortar, and
online stores.
Floor nozzle
• If the rotary brush is soiled, turn the floor nozzle A6 so that the rotary
brush is pointing upwards. On the left side of the nozzle A6 there is
alatch that secures the brush cover in place. Release the latch, tilt
open the cover and take out the brush –see figure F.
• Remove all dirt and dust from the rotary brush and the internal space
of the floor nozzle A6. After cleaning, return the rotary brush back in its
place. Tilt the cover back and secure it in place.
• For cleaning the surface of the floor nozzle A6, use adry or alightly
dampened cloth. Then wipe everything so that it is thoroughly dry.
Outer surface of the vacuum cleaner
• Clean the outer surface of the vacuum cleaner using adry or alightly
dampened cloth. Then wipe everything so that it is thoroughly dry.
Warning:
Do not clean any part of the vacuum cleaner using
steel wool, abrasive cleaning products, petrol,
solvents or any other similar products.
Storage
• When not using the vacuum cleaner for an extended period of time,
clean it according to the instructions provided above.
• Before storing it, check that the vacuum cleaner is perfectly clean
and dry.
• Store the vacuum cleaner in adry, clean and well-ventilated location
not exposed to extreme temperatures and out of children‘sreach.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
SVC 7811WH
Power adapter
Input ...................................................................100 – 240V~, 50/60Hz, 0.35A
Output ..................................................................................................14V
, 0.5A
Electrical shock protection class ............................................................................... II
Vacuum cleaner
Power input ............................................................................................................110W
Electric rotary brush .............................................................................................. 10W
Li-Ion battery .........................................................11.1V
, Li-Ion / 2,200mAh
Time required for charging to full capacity .............approximately 4.5hours
Operating time when fully charged (high / low power) ......up to 13 / 25min
Noise level ..................................................................................................... ≤ 76dB(A)
Dust container capacity ........................................................................................ 0.5l
The declared noise emission level of models SVC 7811WH is ≤76dB(A),
which represents level Aof acoustic power with respect to areference
acoustic power of 1pW.
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double
or heavy-duty insulation.
The product is intended for household use only. The
product is not intended for outdoor use.
- 5 -
09/2022
2022, .
We reserve the right to change text and technical specifications.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling hand over these appliances to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human
health, which could result from improper waste disposal. Ask your local
authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer
or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.
DISPOSAL OF BATTERIES
Prior to disposing of the product or handing it over at
aspecialised collection facility, it is necessary to ensure
that the built-in battery is removed. Before removing the
battery, it is necessary to start the vacuum cleaner and
wait until it is completely flat. Battery removal will be
performed at the authorised service centre.
The battery contains environmentally damaging substances and
therefore does not belong in standard household waste. Their correct
disposal will be performed by the respective collection facility.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
