DO NOT USE SILICONE
OLIVERI DOES NOT RECOMMEND THE USE OF A WASTE
DISPOSAL UNIT WITH GRANITE SINKS.
CUTTING THE COUNTER / BENCHTOP
GRANITE SINK INSTALLATION INSTRUCTIONS
Please retain for consumer as care instructions are included
DO NOT USE SILICONE
BASKET WASTE INSTALLATION
1 Fit the basket waste into the hole in the sink and then place the drain under the
hole. DO NOT USE SILICONE ADHESIVE.
2. Fasten the basket waste to the drain using a screw. Do not overtighten.
DRILLING THE TAP HOLE
3. Oliveri granite sinks with drainboards are provided with a pre-punched hole (picture
A) placed on the front and back of the sink in order to choose which side the bowls
/ drainer will sit. NOTE!
In order to avoid any possible damage to the sink, we strictly recommend to drill these
pre-punched holes using 35-37mm drill following the procedure shown in pictures B
and C. We recommend using a diamond coated drill to drill this hole.
Fig. A - Pre-punched tap holes Fig. B - Place the tool on the
pre-punched hole.
Fig. C - Drill the hole.
CHECK SPACE
Ensure there is adequate space for tapware (including a splashback
if specied). Check space for installation (underneath) and operation
(above). Particular care must be taken when a thick splash back is used
(it may interfere with tapware location and operation). Ensure the cabinet
will not foul the sink mounting ange or basins.
TEMPLATE *
Cut out templates for your Oliveri sink are available online at oliverisinks.
com. Use the product model number to nd the template. Some sink
templates apply to both left-hand and right-hand model sinks. Ensure
template is correct way around for your model.
MARK CUT OUT *
Carefully mark out the template (or follow drawing instructions) making
allowance for any additional polishing back that is required after cutting.
NOTE: THE TEMPLATE IS THE EXACT FINISHED CUT-OUT SIZE
REQUIRED.
CUT & FINISH HOLE *
Drill pilot holes to accept an appropriate cutting tool for the counter/
benchtop material (wear suitable personal protection equipment). Cut
inside the mark, allowing sufcient room for any polishing back.
Note: Accuracy is essential to ensure the bowl / basin and
accessories t correctly.
TRIAL FIT THE SINK
Carefully position the sink against counter/benchtop to make sure it ts
the cut-out correctly. If the t is not correct, remove the sink and proceed
with remedial work. Perform another trial t after corrections have been
made.
IT IS HIGHLY RECOMMENDED THE ACTUAL SINK BE PRESENT AT TIME OF CUTTING
Any advice, recommendation, information, assistance or service provided
by Tasman Sinkware in relation to goods manufactured by it or their use
and installation, is given in good faith and is believed by Tasman Sinkware
to be appropriate and reliable. However, any advice, recommendation, in-
formation, assistance or service is provided by Tasman Sinkware without
responsibility or liability.
CHECK MODEL
The model number on the sink
packaging must match the model
of sink the customer ordered.
Do not install if incorrect.
AVOID CUTS
The perimeter and punch-outs on
the sink may contain sharp edges.
Handle the sink carefully to avoid
personal injury.
CHECK THE CONDITION
Inspect the sink for any visible
defects. Do not install the sink if
defects are found. Contact your
sink retailer / point of purchase.
AVOID BREAKAGES
Granite sinks can be broken if
proper care is not taken during
installation.
Download cutout
template files
(PDF, DWG & DXF)
from our website.
© Tasman Sinkware - V(b) Granite Sink Installation Instructions
