Installation
Instructions
Range Knob
Replacement
Replacing the Range Top Knobs
1. Make sure all knobs are in the OFF position.
2. Choose which knob you will work with first.
3. Match the replacement knob with the knob you are
going to remove — make sure they have the same
writing and markings.
4. Remove the knob by grasping the sides and pulling
away from the appliance until the knob is free from its
shaft. You may have to wiggle it slightly as you pull
5. Hold the replacement knob so that OFF is at the top
and it lines up properly with the valve shaft.
6. Push the knob onto the valve shaft as far as possible
so it fits snugly. Repeat these removal and installation
steps for each knob until they have all been removed
and replaced.
IMPORTANT!
¥7XUQRIISRZHUWR\RXUDSSOLDQFHEHIRUH\RXUHPRYHRUUHSODFHWKHNQREV
¥:RUNZLWKRQHNQREDWDWLPHWRHQVXUH\RXGRQ¶WPL[XSUHSODFHPHQWSLHFHV
¥0DNHVXUH\RXFKHFNWKHZULWLQJRQHDFKRI\RXUNQREVDQGVHWWKHPRXWLQRUGHU\RXZLOO
UHSODFHWKHP7KLVZLOOKHOSHQVXUH\RXGRQ¶WSXWWKHPLQWKHZURQJRUGHU
¥5HDGLQVWUXFWLRQV
31-2000917 Rev. 1 05-21 GEA
GriddleFront
Control Panel
Flat Side
Flat
Side
OFF OFF
Burner Knobs
Valve
Shaft
