DWG.
No.
TRIG.
DR COMPLETED
도면 DR 완료
완료일 : 16.09.19
LG 전자 (주)
LG Electronics Inc.
UNIT SCALE
1
1
mm
REVIEWEDDESIGNED
RELATED DWG.
CHECKED APPROVED
장현연
17.08.04 17.08.04 17.08.04
이갑선 김현석
MODELING
I
T
L
E
T
APPROVED
승인자
PREPARED
시방자
DATE
년/월/일
REF. NO.
시방 번호
REV. NO.
기호
REVISION DESCRIPTION
변경 사항
김동윤홍순창2017/08/25EAGH800161 인쇄내용 변경
1
2
3
4
RELEASING THIS DRAWING
WITHOUT PERMISSION LG
Electronics SHOULD BE
ACCUSED ACCORDING TO THE
LAWS AND COMPANY RULES.
이 도면은 LG전자의 자산으로 불법
유출시 관계법과 회사규정에 의해 처벌됨.
PDF
ILLUSTRATOR
1 5 4 1 5 4
2 16
MFL70280504
MANUAL,OWNER’S
W-module(W) 1/1
MFL70280504
<< 주기 >>
1. 재질 : 모조지 80g
2. 인쇄 작업
3. 문자의 크기 및 형상은 주어진 FILM에 준한다.
4. 책자의 크기는 일반적 규격(국판)에 준한다.
6. 유해물질 관리 기준
:본 부품에 금지물질이 포함되지 않도록 하고, 상세내용은 LG(63)-A-5501-34를
만족할 것.
<< NOTES >>
1. Material : Vellum paper
2. Print work
1) G/S(LG) BRAND(FIG1) : * Cover - First color : LG Red Pantone #207
- Second color : LG GRAY PANTONE #430
* Inside - First color : Black
3. Printing, text size and line are based on LG designg film.
4. Size will Follow the standard.
5. Before product controlled by criteria sample.
6. Standard of supervision for hazardous material
: The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,PBDE)
and details should comply with LG standard of LG(63)-A-5501-34.
가
가
P/NO. 다
<FRONT> <BACK>
나
WORK
가
BRAND
04
나
MODEL
다
P/NO.
MATERIAL AND PRINTING DESCRIPTION
PRINTING DEGREE
EXTERIER INTERIER
LG MODEL 명
SUFFIX
LANGUAGE
PAGE
REMARK
SEC.
1) G/S(LG) BRAND(FIG1): * 표지 - 1도 : LG RED PANTONE #207
- 2도 : LG GRAY PANTONE #430
* 내지 -1도 : BLACK
2) OEM BRAND(FIG2) : * 표지 - 1도 : BLACK
* 내지 - 1도 : BLACK
5. 양산 전에 설계 한도를 득할것.
2) OEM BRAND(FIG2) : * Cover - First color : Black
* Inside - First color : Black
LG
MFL70280504
1 1
EN
44
모조지 80g OFFSET 인쇄
W-module (W)
WTP20WY
ABWREAPF8K5XNK3
www.lg.com
OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
WTP20WY
MFL70280504
Rev.00_080117
Copyright © 2017 LG Electronics Inc. All Rights Reserved.
TABLE OF CONTENTS
This manual may contain images or
content different from the model you
purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS ........................................................ 4
IMPORTANT SAFETY INSTRUCTIONS ....................................................4
INSTALLATION ....................................................................... 10
Parts .........................................................................................................10
Accessories .............................................................................................. 11
Specifications ........................................................................................... 11
Installation Place Requirements ...............................................................12
Stacking Mini Washer ...............................................................................13
Connecting the Supply Hose ....................................................................15
Installing the Drain Hose ..........................................................................17
Leveling the Appliance ..............................................................................18
OPERATION ........................................................................... 19
Using the Appliance .................................................................................. 19
Sorting Laundry ........................................................................................20
Closing the Door and Drawer ...................................................................21
Adding Cleaning Products ........................................................................22
Control Panel ............................................................................................ 24
Programme Table .....................................................................................25
Option Programme ...................................................................................26
SMART FUNCTIONS .............................................................. 27
Using SmartThinQ Application ..................................................................27
Using Smart Diagnosis™ .........................................................................29
MAINTENANCE ...................................................................... 30
Cleaning the Washing Machine ................................................................30
Cleaning the Drum .................................................................................... 31
Cleaning the Water Inlet Filter ..................................................................31
Cleaning the Lint Filter .............................................................................. 32
Caution on Freezing During Winter ..........................................................32
TROUBLESHOOTING ............................................................ 34
Diagnosing Problems ...............................................................................34
Error Messages ........................................................................................38
4
SAFETY INSTRUCTIONS
EN
The following safety guidelines are intended to prevent
unforeseen risks or damage from unsafe or incorrect
operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’
as described below.
This symbol is displayed to indicate matters and
operations that can cause risk. Read the part with this
symbol carefully and follow the instructions in order to
avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of explosion, fire, death, electric shock,
injury or scalding to persons when using this product,
follow basic precautions, including the following:
Children in the Household
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
5
EN
Installation
•Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
•This appliance should only be installed and transported by two or
more people holding the appliance securely.
•Do not install the appliance in a damp and dusty place. Do not
install or store the appliance in any outdoor area, or any area that
is subject to weathering conditions such as direct sunlight, wind,
or rain or temperatures below freezing.
•Tighten the drain hose at connecting ends to avoid separation.
6
EN
•If the power cord is damaged or the hole of the outlet socket is
loose, do not use the power cord and contact an authorized
service centre.
•This appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of
the appliance, in such a way that a full opening of the appliance
door is restricted.
•This appliance must be grounded (earthed via the power cord). In
the event of malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least resistance for
electric current.
•This appliance is equipped with a power cord having an
equipment-grounding conductor (earthing pin) and a grounding
power plug. The power plug must be plugged into an appropriate
socket outlet that is installed and grounded in accordance with all
local codes and ordinances.
•Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance
is properly grounded.
•Do not modify the power plug provided with the appliance. If it
does not fit the outlet, have a proper outlet installed by a qualified
electrician.
7
EN
Operation
•Do not use a sharp object like drill or pin to penetrate, modify or
disassemble the unit.
•Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner’s Manual. Use only
authorized factory parts.
•Use a new hose or hose-set supplied with the appliance. Reusing
old hoses can cause a water leak and subsequent property
damage.
•Do not reach into the appliance if the tub or agitator is moving.
•Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
•Do not put animals, such as pets into the appliance.
•Do not leave the appliance door open. Children may hang on the
door or crawl inside the appliance, causing damage or injury.
•Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
•Do not put in, wash or dry articles that have been cleaned in,
washed in, soaked in, or spotted with combustible or explosive
substances (such as wax, oil, paint, gasoline, degreasers,
drycleaning solvents, kerosene, vegetable oil, cooking oil, etc.).
Improper use can cause a fire or explosion.
•In case of flood, disconnect the power plug and contact the LG
Electronics customer information centre.
•Do not push down the drawer excessively, when the appliance
drawer is open.
8
EN
•Do not use flammable gas and combustible substances (benzene,
gasoline, thinner, petroleum, alcohol, etc.) near the appliance.
•If the drain hose or inlet hose is frozen during winter, use it only
after thawing.
•Keep all washing detergents, softener and bleach away from
children.
•Do not touch the power plug or the appliance controls with wet
hands.
•When pulling out the power plug from an outlet, hold the power
plug, not the cable.
•Do not bend the power cable excessively or place a heavy object
on it.
•If there is a gas leakage (isobutane, propane, natural gas, etc.),
do not touch the appliance or power plug and ventilate the area
immediately.
•Do not instal the Mini Washer on top of another Mini Washer or
Pedestal or elevated surface or stand.
•To avoid breaking the door glass, do not push too hard on the
door when closing.
•Do not step on Mini Washer.
•Do not wash rugs, mats, shoes or pet blankets, or any other items
other than clothes or small sheets, in this machine.
•This appliance must only be used for domestic household
purposes and should not be used in mobile applications.
•Do not open or close the door by foot.
9
EN
Maintenance
•Securely plug the power plug in the socket outlet after completely
removing any moisture and dust.
•Disconnect the power cord before cleaning the appliance.
•Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the socket
outlet.
•Do not spray water inside or outside the appliance to clean it.
Disposal
•Before discarding an old appliance, unplug it. Cut off the cable
directly behind the appliance to prevent misuse.
•Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can
cause suffocation.
•Remove the door before disposing of or discarding this appliance
to avoid the danger of children or small animals getting trapped
inside.
10
INSTALLATION
EN
Parts
7
8
6
5
4
3
2
1
Door
Drum
Control Panel
Drawer
1
2
3
4
Water Supply Hose
Power Plug
Water Drain Hose
Leveling Feet
5
6
7
8
11
EN
Accessories
Water supply hose
(for cold water)
Connecting
supply hose
Water drain hose Water supply hose
connector
Water drain hose
connector
Anti-slip sheets
(2 EA)
Detergent
measuring
cup
Brackets (front)
(2 EA)
Brackets (back)
(2 EA)
Spanner
* Screws
Type A (37 EA)
Type B (5 EA)
Type C (11 EA)
Cable ties
(2 EA)
Band clamps
(3 EA)
Remote control
(some models only)
* Type A : long sheet metal screw, Type B : short sheet metal screw, Type C : machine screw
NOTE
• Different accessories may apply to each model.
• Depending on the installation environment, you may have to purchase a separate drain hose
connector. The connector supplied will suit a standard laundry drum side drain hole.
• In addition to the screws required for installation, some extra screws have been provided.
Specifications
Power supply 220 - 240 V~, 50 Hz
Size 600 mm (W) X 700 mm (D) X 365 mm(H)
Product weight 43 kg
Permissible water pressure 0.1 - 0.8 Mpa (1.0 - 8.0 kgf / cm²)
Wash capacity 2 kg
• Appearance and specifications may change without notice to improve the quality of the product.
12
EN
Installation Place
Requirements
Location
125 cm
5 cm5 cm
60 cm
10 cm
114 cm
135 cm
123 cm
2 cm
*125 cm
0.5 cm
*125 cm: minimum space for installation
Level floor : Allowable slope under the entire
appliance is 1°.
Power outlet : Must be within 1.5 meters of
either side of the location of the appliance.
• Do not overload the outlet with more than one
appliance.
Additional Clearance : 5 cm at the sides and 10
cm behind the unit.
• Do not place or store laundry products on top
of the appliance at any time. These products
may damage the finish or controls.
WARNING
• The plug must be plugged into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Positioning
• Install the appliance on a flat hard floor. Then,
level the Mini Washer before placing the Main
washer on top. Lock only the rear feet of the
Mini washer after leveling as the two front feet
may need readjusting after the Main Washer
has been placed on top.
• Make sure that air circulation around the
appliance is not impeded by carpets, rugs, etc.
• Never try to correct any unevenness in the floor
with pieces of wood, cardboard or similar
materials under the appliance.
• If it is impossible to avoid positioning the
appliance next to a gas cooker or coal burning
stove, an insulation (85x60 cm) covered with
aluminum foil on the side facing the cooker or
stove must be inserted between the two
appliances.
• Do not install the appliance in rooms where
freezing temperatures may occur. Frozen
hoses may burst under pressure. The
reliability of the electronic control unit may be
impaired at temperatures below freezing point.
• Ensure that when the appliance is installed, it
is easily accessible for an engineer in the
event of a breakdown.
• With the appliance installed, adjust all four
feet using a transit bolt spanner to ensure the
appliance is stable, and a clearance of
approximately 5 mm is left between the top of
the appliance and the underside of any
work-top.
• If the appliance is delivered in winter and
temperatures are below freezing, place the
appliance at room temperature for a few hours
before putting it into operation.
• Do not use a drip pan as it can block the
drawer. Using the drip pan may result in
increased vibration and noise during
operation.
WARNING
• This appliance is not designed for maritime
use or for use in mobile installations such as
caravans, aircraft etc.
Electrical Connection
• Do not use an extension cord or double
adapter.
• Always unplug the appliance and turn off the
water supply after use.
• Connect the appliance to an earthed socket in
accordance with current wiring regulations.
• The appliance must be positioned so that the
plug is easily accessible.
• Repairs to the appliance must only be carried
out by qualified personnel. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctioning. Contact an authorised
LG repairer.
13
EN
Stacking Mini Washer
Brackets (front)
Brackets (back)
Brackets (front) Brackets (back)
• The
error message appears on the
display, if the stacking holder is not attached
to the bottom of the Main Washer.
1
Tilt and hold Main Washer.
2
Assemble the front brackets and stacking
holder at the bottom of Main Washer.
NOTE
• The stacking holder and screws needed for
assembly are enclosed in the Main
Washer, which must be stacked with this
Mini Washer.
Type 1. Where the bottom part of the
Main Washer is silver in color.
• First assemble the stacking holder using 2
type A screws included in the accessory
box of the Mini Washer, then each bracket
using 7 type A screws included in the
accessory box of the Mini Washer.
2
3
1
Type 2. Where the bottom part of the
Main Washer is white in color.
• First assemble the stacking holder using 2
type C screws included in the accessory
box of the Main Washer, then each
bracket using 4 type C screws included in
the accessory box of the Mini Washer.
2
1
14
EN
3
Pull and save the foam block for future use.
• If the washing machine must be moved in
the future, the foam block will help prevent
damage to the washing machine during
transportation.
NOTE
• To prevent damage, do not remove the
foam block until Mini Washer is at the final
location.
4
Rotate the top cover 180 degrees.
Cover the upper hole with the top cover and
install 4 type B screws to fix it in place.
5
Attach the two back brackets on the rear
top of the Mini Washer by inserting 4 type A
screws in each bracket.
6
Carefully place the Main Washer on top of
Mini Washer.
• Make sure the 4 legs are totally wound in
and the holes of Mini Washer align with
the holes of Main Washer.
Washer leg
Washer leg
7
Securely attach the two appliances at the
corners using 14 type A screws.
• First, insert screws on each side. Then
insert screws on the front and back side.
NOTE
• It can be difficult to assemble if it is not
assembled in the proper order.
• Use two type C screws to assemble the
stacking holder.
1
1
2
3
Stacking holder
8
Turn the feet of the Main Washer slightly
until they are firmly snug up against the
Mini Washer.
NOTE
• Mini Washer will not work as a standalone
unit.
15
EN
Connecting the Supply Hose
• Water supply pressure must be between 0.1
MPa and 0.8 MPa (100 ~ 800kPa).
• Do not overtighten the water supply hose.
• If the water supply pressure is more than 0.8
MPa, a decompression device should be
installed.
• Periodically check the condition of the hose
even after installation and replace the hose if
necessary.
• Contact the service centre if there is no rubber
seal fitted to the hose ends.
Checking the Rubber Seal on the
Supply Hose
Two rubber seals are supplied with the water
supply hoses. They are used for preventing
water leaks. Make sure the connection to taps
is sufficiently tight. Do not use mechanical
devices such as multi grips to tighten the inlet
hoses.
Hose connector
Rubber seal
Hose connector
Rubber seal
Connecting Hose to Water Tap
Connecting Screw-Type Hose to Tap
with Thread
Screw an inlet hose of the Main washer to the
COLD water supply tap.
16
EN
Connecting the Cold Supply
Hoses to Both Washing Machines
1
Connect one end of the cold water supply
hose connector to the cold water supply
hose of the Main Washer first. Open the
accessory package for the Mini Washer
installation accesories.
Water supply hose
connector
2
Connect the water supply hose of Mini
Washer to the COLD water supply hose
connector.
3
Connect the additionally provided water
supply hose of Main Washer to the cold
water supply hose connector and cold water
tap.
Water supply hose
connector
NOTE
• Make sure the water supply hose is not kinked
or pinched.
17
EN
Installing the Drain Hose
• The drain hose should not be placed higher
than 100 cm above the floor. Water in the
appliance may not drain or may drain slowly.
1
Insert the band clamp onto the drain hose
elbow. Pliers may be required to open the
clamp so it can be fitted to the rubber end
of the hose.
Band clamp
2
With the hose leading up from the elbow,
firmly insert the elbow onto the drain outlet
on the back of Mini Washer.
3
Adjust the band clamp with pliers to keep
the hose securely in place and prevent
leaking.
Band clamp
Using the Drain Hose Connector
1
Connect the drain hose of Main Washer
and Mini Washer to the drain connector.
2
Insert the included band clamps on to the
ends of the two drain hoses.
3
Push the drain hoses firmly onto the drain
connector.
Drain hose
connector
CAUTION
• Adjust the band clamps to prevent the hoses
from coming loose or leaking. Failure to do so
could result in flooding. Use of the drain
connector helps avoid siphoning, odors, or
improper draining.
• Make sure the drain hoses are not kinked or
pinched. This is a potential cause of drainage
problems or noise.
NOTE
• Depending on the installation environment,
you may have to purchase a separate drain
hose connector. The connector supplied will
suit a standard laundry tub side drain hole.
18
EN
Leveling the Appliance
If the floor is uneven, turn the adjustable feet as
required (Do not insert pieces of wood etc.
under the feet). Make sure that all four feet are
stable and resting on the floor and then check
that the appliance is perfectly level (Use a spirit
level).
• Once the appliance is level, tighten the lock
nuts up towards the base of the appliance. All
lock nuts must be tightened.
Raise Lower
Lock nut
Tighten all 4
lock nuts securely
Diagonal Check
• When pushing down on the edges of the top
plate diagonally, the appliance should not
move up and down at all (check both
directions). If the appliance rocks when
pushing the machine top plate diagonally,
adjust the necessary foot or feet again.
WARNING
• After stacking the Main Washer on to the Mini
Washer, use the leveling feet on Mini Washer
to level both. Main Washer´s leveling feet
should be already be firmly snug against the
Mini Washer and the locknuts turned
counter-clockwise to secure them.
NOTE
• Timber or suspended type flooring will
contribute to excessive vibration and
unbalance. Re enforcement or bracing of the
timber floor may need to be considered to
stop or reduce excessive noise and vibration.
Using Anti-Slip Sheets (Optional)
If you install the appliance on a slippery
surface, it may move because of excessive
vibration. Incorrect leveling may cause
malfunction through noise and vibration. If this
occurs, install the anti-slip sheets under the
leveling feet and adjust the level.
1
Clean the floor to attach the anti-slip sheets.
• Use a dry rag to remove and clean foreign
objects and moisture. If moisture remains,
the anti-slip sheets may slip.
2
Adjust the level after placing the appliance
in the installation area.
3
Place the adhesive side of the anti-slip
sheets on the floor.
• It is most effective to install the anti-slip
sheets under the front feet. If it is difficult
to place the pads under the front feet,
place them under the back feet.
This side up
Adhesive side
4
Ensure the appliance is level.
• Push or rock the top edges of the
appliance gently to make sure that the
appliance does not rock. If the appliance
rocks, level the appliance again.
NOTE
• You can obtain anti-slip sheets from an LG
Service Centre or a Hardware store.
19
OPERATION
EN
Using the Appliance
1
Sort laundry and load items.
• Sort laundry by fabric type, soil level,
colour and load size as needed. Open the
door and load items into the washing
machine.
2
Add cleaning products.
• Add the proper amount of detergent with
the detergent measuring cup to the
washing drum evenly.
3
Closing the door and drawer.
4
Turn on the washing machine.
• Press the Power button to turn on the
washing machine.
5
Choose the desired washing cycle.
• Press the cycle button repeatedly until the
desired cycle is selected.
6
Begin cycle.
• Press the Start/Pause button to begin the
cycle. The Mini washer will agitate briefly
without water to measure the weight of the
load. If the Start/Pause button is not
pressed within 15 minutes, the washing
machine will shut off and all settings will
be lost.
7
To Add softener.
• The Mini Washer will chime during the
final rinse for approximately 20 seconds.
When this occurs, press the Start/Pause
button, then slide open the drawer and
open the Lid to manually add the softener,
and then after closing the lid and drawer,
press Start/Pause to resume the cycle. If
no attempt is made to add softener, the
machine will automatically continue to
wash 30 seconds after the chime has
finished sounding.
8
End of cycle.
• When the cycle is finished, another
melody will sound. Immediately remove
your clothing from the washing machine to
reduce wrinkling and odors.
• After washing is complete, wipe off the
washing machine door, gasket and inside
the washing drum with a soft dry towel for
clean washing.
20
EN
Sorting Laundry
1
Look for the care label on your clothes.
• This will tell you about the fabric content
of your garment and how it should be
washed.
• Symbols on the care labels.
Wash temperature
Normal machine wash
Permanent press
Delicate
Hand wash
Do not wash
2
Sorting laundry.
• To get the best results, sort clothes into
loads that can be washed with the same
wash cycle.
• Different fabrics need to be washed at
varying temperatures and spin speeds.
• Wash two or more towels or knits
together. If washed separately, laundry
which absorbs a lot of water may not be
washed well or abnormal spin-drying may
occur due to an unbalanced load.
• Always sort dark colours from pale colours
and whites. Wash separately as dye and
lint transfer can occur causing
discolouration of white and pale garments.
Do not wash heavily soiled loads in this
Machine.
− Soil (Heavy, Normal, Light) :
Separate clothes according to amount of
soil.
− Colour (White, Lights, Darks):
Separate white fabrics from coloured
fabrics.
− Lint (Lint producers, Collectors):
Wash lint producers and lint collectors
separately.
3
Caring before loading.
• Do not wash items that contain support or
memory wire such as Bras as it may
damage other clothes as well as the
washing machine and cause noise and
vibration.
• Check all pockets to make sure that they
are empty. Items such as nails, hair clips,
matches, pens, coins and keys can
damage both your washing machine and
your clothes.
• Close zippers, hooks and strings to make
sure that these items don’t snag on other
clothes.
• Pre-treat dirt and stains by brushing a
small amount of detergent dissolved water
onto stains to help lift dirt.
• If an item of clothing has a long lace
attached to it, arrange the lace so it
cannot be tangled or put it into a washing
net.
• Remove the insides of cushions, pillows,
or sitting mats and only wash the cover.
The insides may protrude, damaging other
laundry. Plastic parts may generate
abnormal vibrations.
CAUTION
• Divide laundry of large volume for seperate
washing so that the laundry can be
submerged under water completely. If laundry
expands during washing, it may cause
damage to the wash load and to the washer's
parts during washing or spin.
21
EN
Closing the Door and Drawer
1
Gently push down on the Mini Washer’s Lid
until it clicks.
2
Push the drawer in until it has completely
closed.
CAUTION
• Do not let your hands get stuck between the
door and the washing machine, as this can
cause injury.
• Forcing the drawer or the Lid to open can
cause parts to be damaged and safety
problems.
• Closing the drawer before having closed the
Lid completely may scratch the Lid glass.
• Ensure the drawer is pulled out completely to
prevent the Lid from contacting the front of the
upper Main washing machine.
NOTE
• The Lid lock may fail if there is too much
laundry in the machine or if the Lid is not
completely closed.
• If the product is operating or the drawer lock
, indicator is displayed, the drawer cannot
open. To open the drawer, press the Start/
Pause button to stop the washer, and when
the drawer lock , indicator disappears, open
the drawer. Do not force the drawer or the
glass Lid open.
• If
, , warning appears on the
display, close the drawer and the Lid
completely. After doing so, press the Start/
Pause button again.
• If the drawer cannot be opened completely,
pull the drawer forward with a little force using
both hands.
• If power failure occurs during product
operation, the door cannot be opened.
Restore the power again or contact the LG
service centre.
• The Lid may not open due to high ambient
temperatures, if this occurs after a wash and
there are no error codes on the display, select
the Rinse+Spin programme or wait until
temperatures drop so that the Lid can be
released.
22
EN
Adding Cleaning Products
Detergent Dosage
• Detergent should be used according to the
instruction of the detergent manufacturer and
selected according to type, colour, soiling of
the fabric and washing temperature.
• If too much detergent is used, too many suds
can occur and this will result in poor washing
results or cause heavy load to the motor.
• If you wish to use liquid detergent follow the
guidelines provided by the detergent
manufacturer. We recommend the use of low
sudsing Front loader detergent for use in this
Mini Washer.
• If too many suds occur, reduce the detergent
amount.
• Detergent usage may need to be adjusted for
water temperature, water hardness, size and
soil level of the load. For best results, avoid
oversudsing.
• Refer to the label of the clothes, before
choosing the detergent and water
temperature.
• When using the washing machine, use
designated detergent for each type of clothing
only:
− General powdered detergents for all types of
fabric
− Powdered detergents for delicate fabric
− Liquid detergents for all types of fabric or
designated detergents only for wool
• For better washing performance and
whitening, use detergent with the general
powdered bleach.
Adding Detergent
Measure the detergent with the detergent
dispenser and pour it into the tub.
• Use the provided detergent measuring cup to
add only one cup of detergent.
• Less detergent is required for lightly soiled
items. Please use appropriate amount of
detergent in the Mini Washer. If you use too
much detergent, excessive bubbles will remain
after rinsing.
23
EN
Adding Softeners
Adding Fabric Softener
CASE 1. When the machine chimes:
1
Press Start/Pause to pause the cycle.
• It can be paused by pressing the Start/
Pause button of the Mini Washer or by
using the remote control.
2
Slide open the drawer, open the door, and
add the liquid fabric softener.
3
Close the door, slide the drawer closed, and
press Start/Pause to restart the cycle.
NOTE
• To disable or enable the fabric softener alert,
press and hold the Extra Rinse button for
three seconds.
• The fabric softener can be added within 30
seconds after the chime has sounded.
CASE 2. If you miss the softener add point:
1
Press the Power button to interrupt the
cycle.
2
Slide open the drawer, open the door, and
add the liquid fabric softener.
3
Close the door, Slide the drawer, and select
the Rinse+Spin programme.
4
Press the Start/Pause to restart the cycle.
NOTE
• Do not pour fabric softener directly on the
clothes.
• The softener can also be diluted with water
and added directly into the drum. Do not pour
undiluted softener directly onto clothing as it
may stain fabrics.
Adding Water Softener
• A water softener, such as anti-limescale (e.g.
Calgon) can be used to cut down on the use
of detergent in extremely hard water areas.
Dispense according to the amount specified
on the packaging. First add detergent and
then the water softener.
• Use the quantity of detergent required for soft
water.
CAUTION
• Do not directly pour bleach on to the clothes.
This may cause partial discoloration and
severe damage to the load.
• Do not use chlorine bleach or acidic cleaner
when washing the laundry, as it can cause
damage to clothes such as discoloration of the
clothes.
24
EN
Control Panel
1
2
4
5
3
Power Button
• Press the Power button to turn the
washing machine on, or off if washing
hasn't commenced.
Display
• The display shows the cycle status and
estimated time remaining.
•
: Drawer lock indicator
•
: Wi-Fi connect indicator
•
: Remote start indicator
Programme Button
• Programmes are available according to
laundry type.
• In order to use the Download Cycle
function, refer to SMART FUNCTIONS.
1
2
3
Start/Pause Button
• The Start/Pause button is used to start
the wash cycle or pause the wash cycle.
• If a temporary stop of the wash cycle is
needed, press the Start/Pause button.
NOTE
• If you do not press the Start/Pause button
within 15 minutes of selecting a
programme, the washing machine
automatically turns off and all cycle
settings are lost.
Options
• Use these buttons to select the desired
options for the selected programme. For
more information about the options for the
each programme, please refer to Extra
Options.
• The setting indicator lights above the
buttons will illuminate to show the current
selection.
4
5
25
EN
Programme Table
Washing Programme
Programme Description Note
Maximum
Load
Light Soil
Use this programme to
wash lightly soiled normal
items, except delicate
fabrics such as wool or silk.
• Pressing the Start/Pause button
without selecting a programme will
cause the Normal programme to
begin immediately using the default
settings.
2.0 kg
Speed Wash
Use this programme to
speed up the washing time
for small loads and lightly
soiled clothes.
• Use very little detergent in this
programme.
1.5 kg
Active Wear
Use this programme to
wash performance
garments that are specially
designed and treated for
sports.
• Use
1
/2 the amount of detergent
recommended by the manufacturer
for a normal load.
• Do not wash white or brightly colored
laundry with darkly colored laundry
that can discharge colors.
• It is more effective to pre-wash
laundry which is stained with blood
or milk briefly with cold water before
carrying out main washing can
remove stains more effectively.
• Bubble Removing Function: If an
excessive amount of detergent is
used, the bubble removing function
may operate.
• Lowering Drain Temperature
Function: For the safety, cold water
is briefly supplied before draining to
lower the water temperature.
1.0 kg
Tub Clean
Use this programme to
keep the drum clean by
sterilizing germs within the
drum.
• Select a proper type of neutral
detergent such as Dish Washer
powdered detergent.
• DO NOT add clothes or any other
items during this function.
Hand Wash
Use this programme to
wash textiles, lingerie, or
fine clothes likely to shrink
or deform.
• To reduce damage to textiles and
improve washing performance, use
special neutral detergent for wool.
• To prevent damage to clothes, the
drum spins gently to the left and
right for washing.
1.0 kg
Rinse+Spin
Select this programme to
rinse and spin a load
separately from a regular
cycle.
• Add fabric softener only if desired. 1.5 kg
26
EN
Option Programme
Spin Only
Use this option to spin a hand washed load that
may not have been washed in the machine.
Extra Rinse
Use this option to increase the number of
rinsing programmes.
1
Press the Power button.
2
Select a washing programme.
3
Press the Extra Rinse button to set the
amount of Rinses required.
• When you press the Extra Rinse button,
the number of rinsing cycles will be
displayed. (1 up to 5 extra rinses can be
selected depending on the Programme)
4
Press the Start/Pause button.
Child Lock
Use this option to disable the controls. This
feature can prevent children from changing
cycles or operating the appliance.
Locking the Control Panel
1
Press and hold the Child Lock button for
three seconds.
2
will appear on the display.
When the Child Lock is set, all buttons are
locked except the Power button.
NOTE
• Turning off the power or completing all cycles
will not reset the child lock function. You must
deactivate child lock before you can access
any other functions.
Unlocking the Control Panel
Press and hold the Child Lock button for three
seconds.
• To change the cycle or option, press the Start/
Pause button to stop operation, and then
choose the cycle or option which you wish to
change. Depending on the selection, the cycle
may restart again.
27
SMART FUNCTIONS
EN
Using SmartThinQ
Application
Installing SmartThinQ
Search for the LG SmartThinQ application from
the Google Play Store or Apple App Store on a
smart phone. Follow instructions to download
and install the application.
Wi-Fi Function
• For appliances with the
or logo
Washer Cycle (Remote Start, Download
Cycle)
Set or download any preferred cycle and
operate by remote control.
Tub Clean Coach
This function shows how many cycles remain
before It is time to run the Tub Clean cycle.
Energy Monitoring
Check the energy consupmtion of the recently
used cycles and monthly average.
Smart Diagnosis™
This function provides useful information for
diagnosing and solving issues with the
appliance based on the pattern of use.
Settings
Various functions are available.
Push Alert
Turn on the Push Alerts to receive appliance
status notifications. The notifications are
triggered even if the LG SmartThinQ application
is off.
NOTE
• To verify the Wi-Fi connection, check that
Wi-Fi
icon on the control panel is lit.
• LG SmartThinQ is not responsible for any
network connection problems or any faults,
malfunctions, or errors caused by network
connection.
• The machine supports 2.4 GHz Wi-Fi
networks only.
• If the security protocol of the router is set to
WEP, you may fail to set up the network.
Please change it to other security protocols
(WPA2 is recommended) and register the
product again.
• Router SSID, please use only letters,
numbers. Other characters may not be
supported.
• If the appliance is having trouble connecting to
the Wi-Fi network, it may be too far from the
router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
• The Wi-Fi connection may not connect or may
be interrupted because of the home network
environment.
• The network connection may not work
properly depending on the internet service
provider.
• The surrounding wireless environment can
make the wireless network service run slowly.
• The application is subject to change for
appliance improvement purposes without
notice to users.
• Functions may vary by model.
RF Radiation Exposure Statement
This equipment shall be installed and
used at a minimum distance of 20 cm
from the human body.
28
EN
Using Washer Cycle
Remote Start
Use a smart phone to control your appliance
remotely. You can also monitor your cycle
operation so you know how much time is left in
the cycle.
To Use Remote Start:
1
Press the Power button.
2
Put the laundry in drum.
3
Press and hold Remote Start button for 3
seconds to enable Remote Start function.
4
Start a cycle from the LG Smart ThinQ
application on your smart phone.
NOTE
• Once the Remote Start mode is enabled, you
can start a cycle from the LG Smart ThinQ
smartphone application. If the cycle is not
started, the machine will wait to start the cycle
until it is turned off remotely from the
application or the Remote Start mode is
disabled.
• When Remote Start is turned on, the door is
automatically locked.
To Disable Remote Start:
When the Remote Start is activated, press and
hold Remote Start button for 3 seconds.
Download Cycle
Download new and special cycles that are not
included in the basic cycles on the appliance.
Appliances that have been successfully
registered can download a variety of specialty
cycles specific to the appliance.
Only one cycle can be stored on the appliance
at a time.
Once cycle download is completed in the
appliance, the product keeps the downloaded
cycle until a new cycle is downloaded.
Open Source Software Notice
Information
To obtain the source code under GPL, LGPL,
MPL, and other open source licenses, that is
contained in this product, please visit http://
opensource.lge.com.
In addition to the source code, all referred
license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source
code to you on CD-ROM for a charge covering
the cost of performing such distribution (such as
the cost of media, shipping, and handling) upon
email request to [email protected]. This
offer is valid for three (3) years from the date on
which you purchased the product.
Smart Diagnosis™ Using a Smart
Phone
• For appliances with the
or logo
Use this function if you need an accurate
diagnosis by an LG Electronics customer
information centre when the appliance
malfunctions or fails.
Smart Diagnosis™ can not be activated unless
the appliance is connected to power. If the
appliance is unable to turn on, then
troubleshooting must be done without using
Smart Diagnosis™.
29
EN
Using Smart Diagnosis™
Smart Diagnosis™ Through the
Customer Information Centre
Use this function if you need an accurate
diagnosis by an LG Electronics customer
information centre when the appliance
malfunctions or fails. Use this function only to
contact the service representative, not during
normal operation.
1
Press the Power button after opening the
drawer on Mini Washer.
2
When instructed to do so by the call centre,
place the mouthpiece of your phone close
to the Smart Diagnosis™ icon.
Max.
10 mm
3
Press and hold the Extra Rinse button for
three seconds, while holding the phone
mouthpiece to the icon or Power button.
4
Keep the phone in place until the tone
transmission has finished. Time remaining
for data transfer is displayed.
• For best results, do not move the phone
while the tones are being transmitted.
• If the call centre agent is not able to get
an accurate recording of the data, you
may be asked to try again.
5
Once the countdown is over and the tones
have stopped, resume your conversation
with the call centre agent, who will then be
able to assist you using the information
transmitted for analysis.
NOTE
• The Smart Diagnosis™ function depends on
the local call quality.
• The communication performance will improve
and you can receive better service if you use
the home phone.
• If the Smart Diagnosis™ data transfer is poor
due to poor call quality, you may not receive
the best Smart Diagnosis™ service.
30
MAINTENANCE
EN
WARNING
• Unplug the washing machine before cleaning
to avoid the risk of electric shock. Failure to
follow this warning may result in serious injury,
fire, electric shock, or death.
• Never use harsh chemicals, abrasive
cleaners, or solvents to clean the washing
machine. They may damage the finish.
Cleaning the Washing
Machine
Care After Wash
• After the cycle is finished, wipe the door and
the inside of the door seal to remove any
moisture.
• Leave the door open to dry the drum interior.
• Wipe the body of the washing machine with a
dry cloth to remove any moisture.
Cleaning the Exterior
Proper care of your washing machine can
extend its life.
Door:
• Wash with a damp cloth on the outside and
inside and then dry with a soft cloth.
Exterior:
• Immediately wipe off any spills.
• Wipe with a damp cloth.
• Do not press the surface or the display with
sharp objects.
Cleaning the Interior
• Use a towel or soft cloth to wipe around the
washing machine Lid opening and when
wiping the the Lid’s glass.
• Always remove items from the washing
machine as soon as the cycle is complete.
Leaving damp items in the washing machine
can cause wrinkling, colour transfer, and
odour.
• Run the Tub Clean programme once a month
(or more often if needed) to remove detergent
buildup and other residue
31
EN
Cleaning the Drum
Use the Tub Clean option to keep the drum
clean.
1
Press the Power button.
2
Dilute 200 ml liquid chlorine bleach in 1 ℓ of
water and pour the mixture in the drum.
3
Press the Tub Clean button to set time
required.
4
Press the Start/Pause button.
CAUTION
• Do not leave the machine’s drawer or Lid
open if there is an unsupervised child nearby.
Cleaning the Water Inlet Filter
• Turn off the water supply tap if the washing
machine is to be left for any length of time
(e.g. holiday), especially if there is no floor
drain (gully) in the immediate vicinity.
•
icon may blink on the display when the
water pressure is weak or an inlet filter is
clogged with dirt. Clean the inlet filter.
• The inlet filter mesh could be clogged by hard
water scale, sediment in the water supply, or
other debris.
1
Turn off the water tap and unscrew the
water inlet hose.
2
Clean the filter using a hard bristle brush.
32
EN
Cleaning the Lint Filter
The Lint filter is an important part for an efficient
washing performance result, so it needs special
care from you. It is recommended that the filter
be cleaned regularly.
1
Squeeze the side tabs and lift out the filter.
2
Open the cap and remove any lint before
washing it
3
Insert the lower part of the filter into the
drum and close the cap until you hear a
click sound.
NOTE
• When the lint filter is damaged, contact an LG
service centre.
• Do not operate the washing machine without
the lint filter.
• Do not leave the lint filter loosely or poorly
fitted. Doing so may damage the fabrics or the
washing machine.
Caution on Freezing During
Winter
• When frozen, the product does not operate
normally. Make sure to install the product
where it will not freeze during winter.
• In case the product must be installed outside
on a porch or in other outdoor conditions,
make sure to check the following.
How to Keep the Product from
Freezing
• After closing the tap, disconnect the cold
supply hose from the tap, and remove water
while keeping the hose facing downwards.
Supply hose
33
EN
How to Handle Freezing
Step 1. When the Door is Frozen
• Thaw out the door using a hot water cloth.
Step 2. When the Water Supply Hose is
Frozen
•
icon may blink on the display when
water supply problems occur, take the
following measures.
− Take out water supply hose and connect to
the tap and check that water comes from the
tap and supply hose.
− Turn off the tap, and thaw out the tap and
both connection areas of supply hose of the
product using a hot water cloth.
− Take out supply hose and immerse in warm
water below 50–60 °C.
Supply hose
50‒60 °C
Step 3. When the Drain Pump is Frozen
•
, icon may blink on the display when
drain pump problems occur, take the following
measures.
1
Pour 15 ℓ warm water below 50–60 °C in
the drum until washing machine wing nuts
are immersed and wait for an hour.
2
Press the Power button and then run the
Spin Only programme.
• When
icon appears on the display,
repeat steps 1 to 2.
3
When icon appears on the display,
thaw out the drain hose inner part with the
hot water.
34
TROUBLESHOOTING
EN
The appliance is equipped with an automatic error-monitoring system to detect and diagnose
problems at an early stage. If the appliance does not function properly or does not function at all,
check the following before you call for service:
Diagnosing Problems
Symptoms Reason Solution
The drawer does
not open.
Power failure, or the power
cord was pulled out during
washing.
- The machine may not be
level
• After restoring the power again, press the
Power button on the control panel of the
Main Washer or the remote control.
- Ensure that the Mini Washer is leveled
correctly with the use of a spirit level
and checking the door symmetry for
parallel lines.
Draining starts
when pressing
Start/ Pause
button.
The Start/Pause button is
pressed during washing.
• When pressing the Start/Pause button
during washing, the drawer is unlocked
after the water is drained out for safety
reasons.
Rattling and
clanking noise
Foreign objects, such as
keys, coins, or safety pins
may be in the drum.
• Stop the washing machine, check drum
for foreign objects. If noise continues
after washing machine is restarted, call
for service.
Thumping sound
Heavy wash loads may
produce a thumping sound.
• If sound continues, wash load is probably
out of balance. Stop and redistribute the
wash load.
Wash load may be out of
balance.
• Pause the cycle and redistribute the load
after the door unlocks.
Vibrating noise
Packaging materials were not
removed.
• Remove packing materials.
Wash load may be unevenly
distributed in the drum.
• Pause the cycle and redistribute the load
after the door unlocks.
Not all leveling feet are
resting firmly and evenly on
the floor.
• See Leveling the Appliance in the
Installation section.
Floor not rigid enough.
• Make sure that the floor is solid and does
not flex.
Water leaks every
load
Hoses not installed correctly.
• Check all fill and drain hose connections
to ensure that they are tight and secure.
Excessive sudsing
Too much detergent or
incorrect detergent.
• Reduce the amount of detergent for
lightly soiled laundry. If you use too much
detergent, excessive bubbles will remain
after rinsing.
35
EN
Symptoms Reason Solution
Staining
Clothes were not properly
sorted.
-Wrong detergents are added.
• Always wash dark colors separately from
light colors and whites to prevent
discoloration.
• Do not mix softener and detergent
together. Add softener only when the
softener alert chime indicates to do so.
Water leaking
Supply hose connection is
loose at the tap, washing
machine, or drain hose
connector.
• Check hoses and drain hose connectors
for leaks, cracks and splits.
• Tighten hose connections.
House drain pipes are
clogged.
• The washing machine pumps out water
very rapidly. Check for water backing up
out of the drain pipe during drain. If water
is seen coming out of the drain, check for
proper drain hose installation and check
for restrictions in the drain. Contact a
plumber to repair the drain pipe.
Drain hose has come out of
drain connector or is not
inserted far enough.
• Tie drain hose to supply hose or
standpipe to prevent it from coming out
during drain. For smaller drain pipes,
insert the drain hose into the pipe as far
as the drain hose flange. For larger drain
pipes, insert the drain hose into the pipe
2-5 cm past the flange.
Load is too large for the
drum.
• Reduce the load or use the Main Washer.
• Stop the washing machine and check the
load. Make sure the load fits loosely in
the drum and the door closes easily.
Oversudsing of detergent.
• Oversudsing may create leaks, and may
be caused by the type and amount of
detergent used. Always reduce the
amount of detergent if the load is small
or lightly soiled, or if your water is very
soft. Never use more than the maximum
amount shown in the dispenser provided.
Wrinkling
Washing machine not
unloaded promptly.
• Always remove items from the washing
machine as soon as the cycle is
completed.
Washing machine overloaded.
• The washing machine can be fully
loaded, but the drum should not be tightly
packed with items. The door of the
washing machine should close easily.
36
EN
Symptoms Reason Solution
Washing machine
will not operate.
Control panel has powered
off due to inactivity.
• This is normal. Press the Power button
to turn the washing machine back on.
Washing machine is
unplugged.
• Make sure the power cord is plugged
securely into a working outlet.
Water supply is turned off. • Turn the cold water tap fully on.
Controls are not set properly.
• Make sure the cycle was set correctly,
close the door and press the Start/Pause
button.
Lid or drawer is open.
• Close the Lid and drawer make sure that
nothing is caught under the Lid
preventing it from closing completely.
Circuit breaker/fuse is
tripped/blown.
• Check house circuit breakers/fuses.
Replace fuses or reset breaker. The
washing machine should be on a
dedicated circuit. The washing machine
will resume the cycle from where it
stopped once power is restored.
Control needs to be reset.
• Press the Power button, then re-select
the desired programme and press the
Start/Pause button.
Start/Pause was not pressed
after a cycle was set.
• Press the Start/Pause button on the
control panel of the Main Washer or
remote control after closing the drawer.
• When using the control panel of the Mini
Washer, press the Start/Pause button
and close the drawer within 5 seconds.
Extremely low water
pressure.
• Check another tap in the house to make
sure that household water pressure is
adequate.
Washing machine is too cold.
• If the washing machine has been
exposed to temperatures below freezing
for an extended period of time, allow it to
warm up before pressing the Power
button.
37
EN
Symptoms Reason Solution
Washing machine
is not filling
properly.
Filter clogged.
• Make sure the inlet filter on the fill valve
is not clogged. Refer to the filter cleaning
instructions.
Supply hoses may be kinked.
• Check that the supply hose is not kinked
or clogged.
Insufficient water supply.
• Make sure that the cold water tap is
turned on all the way.
door and drawer are open.
• The washing machine will not operate if
the lid is open. Close the lid and make
sure that nothing is caught under the lid
preventing it from closing completely.
Water level in the tub appears
to be too low.
• The fill level is optimized for the wash
motion to achieve the best wash
performance.
Water in the
washing machine
does not drain or
drains slowly.
Drain hose is kinked,
pinched, or clogged.
• Make sure the drain hose is free of
blockages, kinks, etc., and is not pinched
behind or under the washing machine.
Poor stain removal
Heavily soiled load. • Use Main Washer.
Previously set stains.
• Articles that have previously been
washed may have stains that have been
set. These stains may be difficult to
remove and may require hand washing
or pre-treating to aid in stain removal.
Wash cycle time is
longer than usual.
The washing machine
automatically adjusts the
wash time for the amount of
laundry, water pressure and
other operating conditions.
• This is normal. The washing machine
adjusts cycle time automatically to
provide optimal results for the selected
programme. The time remaining shown in
the display is only an estimate. Actual
time may vary.
Musty or mildewy
odor in washing
machine
Incorrect or too much
detergent has been used.
• This machine requires very little
detergent. Use the provided detergent
measuring cup.
Inside of drum was not
cleaned properly.
• Run the Tub Clean programme regularly.
Washing machine
chimes repeatedly
before final rinse.
This is not an error.
• This is an alert to allow the addition of
liquid fabric softener before the final
rinse.
38
EN
Error Messages
Symptoms Reason Solution
Drawer is not closed
properly.
• Close the drawer and press Start/Pause
button to start the cycle.
• If the drawer is closed and the drawer
lock error message is displayed, call for
service.
Door is not closed properly.
• Open the drawer and make sure the
latch area is free of clothing or other
obstructions.
• Close the door, shut the drawer, and
press Start/Pause to start the cycle.
• If the door is closed and the door error
message is displayed, call for service.
The cold water tap is not fully
open.
• Make sure that the cold water tap is fully
open.
Water line hoses are kinked,
pinched, or crushed.
• Make sure that the hoses are not kinked
or pinched. Be careful when moving the
washing machine during cleaning and
maintenance.
Water inlet filters are
clogged.
• Clean the inlet filters.
Water supply pressure to tap
or house is too low or very
high.
• Check another tap in the house to make
sure that household water pressure is
adequate and flow is not restricted.
Disconnect the supply hose from the
washing machine and run a few liters of
water through the hose to flush the water
supply lines. If water pressure is too high,
it may need a pressure reduction device
fitted to the tap.
Water supply connected with
leak-limiting hoses.
• Hoses designed to limit leaks can trip
falsely and prevent the washing machine
from filling. The use of leak limiting hoses
is not recommended.
Drain hose is kinked,
pinched, or clogged.
• Make sure the drain hose is free of
blockages, kinks, etc., and is not pinched
behind or under the washing machine.
39
EN
Symptoms Reason Solution
UE rebalancing operation
was not successful.
• The automatic attempt to rebalance the
load was not successful. The cycle has
been paused to allow the load to be
manually adjusted.
The load is too small.
• Add more items to allow the washing
machine to balance the loads.
Heavy articles are mixed with
lighter items.
• Wash articles of somewhat similar
weight.
The load is out of balance.
• Manually redistribute the load if articles
have become tangled.
Control error.
• Unplug the power plug and call for
service.
Water level is too high due to
a faulty water valve.
• Close the water taps, unplug the washing
machine, and call for service.
The water level sensor is not
working correctly.
• Close the water taps, unplug the washing
machine, and call for service.
A motor error has occurred.
• Allow the washing machine to stand for
30 minutes and then restart the cycle. If
the LE error code persists, call for
service.
It is a reminder to run the Tub
Clean programme.
• Run the Tub Clean programme.
Mini Washer is being
operated without a full-size
washing machine.
• Mini Washer will not operate as a
standalone unit. It must be stacked under
a suitable LG front-loading washing
machine.
Stacking switch is not
working properly.
• The product is for use only in
combination with LG authorized
appliances. Call the customer information
centre to check out LG authorized
appliances.
Drain hose, supply hose or
drain pump is frozen.
• Thaw out the supply hose using a hot
water cloth.
• Pour warm water in the drum.
CL is not an error. This
prevents children from
changing cycles or operating
the appliance.
• To deactivate, press the Child Lock
button for three seconds.
Memo
Memo
Memo
