Vacuum Cleaner
User Manual
EN
VCO 6325 FD
01M-8910653200-4220-01
CONTENTS
ENGLISH 04-11
This product has been manufactured in environmental friendly modern plants without giving any harm
to the nature.
It does not contan PCB.
Please read this user
manual first!
Dear Customers,
Thank you for selecting a Beko product.
We hope that you get the best results
from your product which has been
manufactured with high quality and
state-of-the-art technology. Therefore,
please read this entire user manual and all
other accompanying documents carefully
before using the product and keep it as a
reference for future use. If you handover
the product to someone else, give the
user manual as well. Follow all warnings
and information in the user manual.
Meanings of the symbols
Following symbols are used in the various
section of this manual:
Important information and useful
hints about usage.
WARNING:
Warnings against
dangerous situations concerning the
security of life and property.
Protection class for electric shock.
1. On/Off button
2. Dust contaner
3. Sucton nozzle
4. Hose cap
5. Hose
6. Dust contaner removal button
7. Power cable wndng button
8. Sucton power adjustment knob
9. Parquet/carpet brush parkng hook
10. Brush adjustment latch
11. Hgh performance parquet/carpet brush
12. Telescopc tube adjustment latch
13. Telescopc tube
14. Vacuum control
15. Handle
16. Upholstery tool
17. Dust brush
18. Crevce tool
Techncal data
Supply voltage :
220-240 V~, 50/60 Hz
Power :
1550 W Nom
:
1800 W Max
Cable length :
7 m
Techncal and desgn modfcaton rghts are
reserved.
The values whch are declared n the markngs affxed
on your applance or other prnted documents suppled
wth t represent the values whch were obtaned n
the laboratores pursuant to the pertnent standards.
These values may vary accordng to the usage of the
applance and ambent condtons.
4 / EN
Vacuum Cleaner / User manual
Ths secton contans safety
nstructons that wll help protect
from rsk of personal njury or
property damage.
Falure to follow these
nstructons nvaldates the
granted warranty.
1.1 General safety
• Ths applance comples wth
the nternatonal securty
standards.
• Ths applance s ntended to be
used n household and smlar
applcatons such as:
- Staff ktchen areas n shops,
offces and other workng
envronments;
- Farm houses;
- By clents n hotels, motels
and other resdental type
envronments;
- Bed and Breakfast type
envronments
- It s not ft for ndustral use.
• Ths applance can be used by
chldren aged from 8 years and
above and persons wth reduced
physcal, sensory or mental
capabltes or lack of experence
and knowledge f they have
been gven supervson or
nstructon concernng use of
the applance n a safe way
and understand the hazards
nvolved. Chldren shall not play
wth the applance. Cleanng
and user mantenance shall not
be made by chldren wthout
supervson.
• Do not use t f the power cable or
the applance tself s damaged.
Contact an authorzed servce.
• Your mans power supply should
comply wth the nformaton
suppled on the ratng plate of
the applance.
• The mans supply of the
applance must be secured wth
a mnmum 16 A fuse.
• Do not use the applance wth
an extenson cord.
1 Important safety and envronmental nstructons
Vacuum Cleaner / User manual
5 / EN
1 Important safety and envronmental nstructons
• In order to prevent the power
cable from gettng damaged,
make sure that t doesn’t get
stuck, twsted or rub aganst
sharp surfaces.
• Do not touch the applance or ts
plug when t s plugged f your
hands are damp or wet.
• Do not pull the power cable
when unpluggng the applance.
• Do not vacuum flammable
materals and when vacuumng
cgarette ashes make sure that
t got cold.
• Do not vacuum water or other
lqud materals.
• Protect the applance from ran,
humdty and heat sources.
• Never use the applance
n or near to combustble
or nflammable places and
materals.
• Unplug the applance before
cleanng and mantenance.
• Do not dp the applance or ts
cable n water to clean t.
• Check the hose of the applance
regularly. Do not use f t s
damaged and contact an
authorzed servce.
• Do not attempt to dsmantle the
applance.
• Only use the orgnal parts or
parts recommended by the
manufacturer.
• Do not use the applance
wthout flters; otherwse t can
get damaged.
• When vacuumng the stars,
the applance should be located
below the user.
• If your store the package
materal, keep t out of the
reach of chldren.
6 / EN
Vacuum Cleaner / User manual
EN
OPERATION CLEANING AND CARE
1
5 4
6 7 8
23
12
13
14
15
11
10
9
16 17 18
1
4
5
6
2 3
7
1
2
ON
8
9
MIN/MAX
11
10
12
OFF
2
1
3
13
3
6
2
1
7 8
5
1
2
24h
1
2
24h
4
10 / EN
Vacuum Cleaner / User manual
2.1 Cleanng and care
Swtch off and unplug the applance before cleanng t.
WARNING:
Never use gasolne, solvent, abrasve cleanng agents, metal objects or hard
brushes to clean the applance.
WARNING:
Do not use applances producng hot ar such as har dryer or heater to dry
the flters.
WARNING:
Do not nstall the flters wthout completely dryng them; otherwse, smell of
mosture may occur durng use, water can leak from the back of the applance or the flters
may get damaged.
WARNING:
Attach the flters nto ther places after they are dred.
Blue status led of the suction power adjustment knob turns into red when suction power
decreases or the container is full.
Suction power adjustment knob turns into red when the container is full.
2.2 Storage
• If you do not ntend to use the applance for a long tme, store t carefully.
• Unplug the applance.
• Keep the applance out of the reach of chldren.
2.3 Handlng and transportaton
• Durng handlng and transportaton, carry the applance n ts orgnal packagng. The packagng of the
applance protects t aganst physcal damages.
• Do not place heavy loads on the applance or on the packagng. The applance may get damaged.
• Droppng the applance may render t non-operatonal or cause permanent damage.
2 Informaton
Vacuum Cleaner / User manual
11 / EN
2.4 Complance wth the WEEE Drectve and Dsposng of the
Waste Product
This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol
for waste electrical and electronic equipment (WEEE).
This symbol indicates that this product shall not be disposed with other household wastes at
the end of its service life. Used device must be returned to offical collection point for recycling
of electrical and electronic devices. To find these collection systems please contact to your
local authorities or retailer where the product was puchased. Each household performs
important role in recovering and recycling of old appliance. Appropriate disposal of used
appliance helps prevent potential negative consequences for the environment and human health.
2.5 Complance wth RoHS Drectve
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the Directive.
2.6 Package nformaton
Packaging materials of the product are manufactured from recyclable materials in accordance
with our National Environment Regulations. Do not dispose of the packaging materials
together with the domestic or other wastes. Take them to the packaging material collection
points designated by the local authorities.
2 Informaton
55 Blanck Street, Ormeau Q 4208
P O Box 354, Ormeau Q 4208
p : 5549 3146 f : 5549 3546
ABN : 49 152 055 162
Sensitivity: Public
ORIGINAL MANUFACTURER’S WARRANTY
ADVICE FORM
BEKO SMALL DOMESTIC APPLIANCE
12 months warranty, full parts and labour warranty only.
WARRANTY CONDITIONS
The following conditions apply only in relations to the warranty expressly given on this Warranty Advice Form supplied with the product. This
warranty only applies to appliances purchased and used in Australia or New Zealand and is in addition to (and does not exclude, restrict or
modify in any way) other rights and remedies under a law to which the appliances relate, including any non-excludable statutory guarantees in
Australia and New Zealand. It applies to the original purchaser and for appliances used in domestic applications only.
1. This warranty does not apply:
(a) if the identification number attached to the appliance has been altered, rendered illegible or removed;
(b) to light globes;
(c) to paint and vitreous enamel finishes and glass;
(d) to surfaces damaged by use of aerosols or cleaners;
(e) if the appliance has been –
(i) subject to misuse, abuse, negligence, accident, fire or floods;
(ii) connected or improper, inadequate or faulty electricity, gas, water or drainage services or intake or exhaust
ducts or flues, or operated using incorrect or contaminated fuels or lubricants;
(iii) installed, maintained or operated otherwise than in accordance with the instructions furnished by Beko including the
improper use of detergents, bleaches, cleaners or other additives;
(iv) damaged by foreign objects in the appliance;
(v) serviced, repaired or altered otherwise than by Beko authorised service agents of Beko, or using other than Beko
approved replacement parts.
2. The purchaser shall be responsible for any expenses involved in making the appliances readily accessible for servicing, the purchaser
shall be responsible for any costs of transporting the appliance or parts thereof to and from the nearest Beko authorised service agent.
3. This warranty is the only expressed warranty given by Beko.
4. Beko reserves the right to determine whether or not the fault is caused by faulty workmanship or material or that any part is defective.
5. Where permitted by law, this warranty shall not apply to loss suffered through or resulting from the non-operation or the ineffective
operation of the appliance or any part of the appliance.
6. The purchaser must produce proof of the date of purchase together with this Warranty Advise Form when making a claim.
7. Subject to your statutory rights as to the merchantable quality of the product or accessory. In the event of a product or accessory being
replaced during the guarantee, the guarantee on the replacement will expire at the original date, i.e., 12 months from the original
purchase date.
8. Australia: For Appliances and services provided by Beko in Australia, Beko goods come with a guarantee by Beko that cannot be
excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance
fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the
same meaning as referred to in the Australian Consumer Law.
9. New Zealand: For Appliances and services provided by Beko in New Zealand, the Appliances come with a guarantee by Beko
pursuant to the provisions of the Consumer Guarantees Act, the Sales of Goods Act and the Fair Trading Act. Where the Appliance
was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
These Warranty Conditions supersedes and excludes all other representations, conditions and warranties, except those implied
by legislation previously referred to.
For Service or Spare Parts: Aust 1300 282 356 NZ 0800 692 356
Beko A&NZ Pty Ltd 55 Blanck Street,
Ormeau QLD, 4208 AUSTRALIA
www.beko.com.au
Ph: 1300 282 356
