WallMaster®ProductProfile
PackagedTerminalAirConditionersandHeatPumps
7,000 / 9,000 / 12,000 / 15,000 Btu/h
TheAll-newWallMaste_
isaperfectfitfor:
Newconstructioninhotels/motels,
medicalfacilities,assistedlivingcenters,
apartments/c0nd0s,officesuites,
dormitoriesandremodels.
TheNewWallMaster®retrofitsinto
existing16"x42"sleevesmoreeasilythan
othermanufacturers'PTACs.
StandardFeatures
• Ultrahigh efficiency- up to 12.2 EER.
• Unique component mounting and isolation
provide ultraquiet operation and vibration
dampening.
• Large well-spaced control panel with universal
markings and non-removable controls
• Attractive front cover and tamper resistant
contoured discharge grille blend with any decor.
• Quiet and efficient rotary compressor mounted
on vibration isolators, with internal high
temperature overload protection.
• Built-in damper allows up to 70 CFM of fresh air.
• Convenient top-mounted return air filters feature
an anti-microbial treatment for protection against
fungal and bacterial growth.
• Availablein heat pumpor electric heat.
• Front cover fastens tochassis with
thumbscrews hidden from user.
• Emergency heat compressor override switch on
all heat pumps.
• Single,totally enclosed "clam shell" motor
design protects against premature failure.
• Optional seacoast protection for harshcoastal
environments.
• Complete line of accessories.
• Remotethermostat control units are available.
• Units are rated in accordance
with ARI Standard 310/380.
• Manufactured in theU.S.A.
PTAC-BW-04 (1-04)
