Figure 1
OPERATING INSTRUCTIONS
DIGITAL CLAMP METER
Model DSA600TRMS
IMPORTANT: RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage. If you find damage,
notify the carrier at once.
Shipping damage is NOT covered by warranty. The carrier is responsible
for all repair or replacement costs resulting from damage in shipment.
Clamp Jaw
DSA600TRMS
OFF
NCV
°C°F
COM
CATIII
600V
- AUTO-POWER OFF Press 2 Sec
PEAK
HOLD
INR
REL
HZ%
SEL
HOLD
!
Ω
V/Ω/Hz
V/Ω/Hz
}
}
}
}
600A
60A
V
Hz%
Light
Trigger
Function Selection (SEL)
LCD Screen
COM Terminal Input Terminal
Peak Button (PEAK HOLD)
HOLD / Backlight /
Clamp Light
Dial
Frequency / Duty Cycle (Hz/%)
Inrush Current /
Relative Measurement (INR/REL)
1
Figure 2
Data Hold AC Alternating Current Low Battery NCV Non-contact Voltage Detection
-
Negative Value Diode Check nF, µF, mF
Nanofarad, Microfarad,
Millifarad (Capacitance)
°F Degrees Fahrenheit
REL
Relative Measurement Audible Continuity Check mV, V Millivolt, Volt °C Degrees Celsius
AUTO
Auto Ranging P MAX Peak maximum value A Ampere (Current) % Duty Cycle
INRUSH
Inrush Current Measurement P MIN Peak minimum value Ω, kΩ, MΩ
Ohm, Kiloohm, Megaohm
(Resistance)
OL Overload
DC
Direct Current
P MAX-
MIN
Peak to Peak value Hz, kHz, MHz
Hertz, Kilohertz,
Megahertz (Frequency)
EF Electric Field Detection
