1
2
3
4
5
6
7
8
9
10
11
Qty
1
2
2
4
4
4
4
1
1
4
4
Description
Seat
Steel plate
Steel frame
Seat screw
Nuts for saddle
Washer
Nuts for wheels
Plastic saddle
Lower steel frame
Steel frame screws
Castors
DRAPER TOOLS LTD, HURSLEY ROAD, CHANDLER'S FORD, EASTLEIGH, HANTS. SO53 1YF. U.K.
www.drapertools.com e-mail: [email protected]
MSDH0618
54243
SPECIFICATION
Stock no. .............................................................................................................................................54243
Part no. ............................................................................................................................................ WS-2-B
Seat length ........................................................................................................................ 360mm (approx.)
Seat width.......................................................................................................................... 210mm (approx.)
Maximum weight capacity ....................................................................................................................100kg
SAFETY INSTRUCTIONS
•
Do not use as a toy or skateboard.
•
Do not stand on work stool or use as a stepping device.
•
Do not use if any part of the work stool is defective or damaged in any way.
•
Always store in an upright position in a secure place.
•
Keep out of the reach of children.
ASSEMBLY
•
Attach steel frame (3) to steel plate (2) to seat (1)
using seat screw (4) ensuring the steel frame is correctly
positioned as per the diagram.
•
Attach plastic saddle (8) with steel frame (9) with castors (11)
by using nuts for wheels (7).
•
Finally, attach the upper and lower frame by using nut for
saddle (5) and washer (6).
FIXED
WORK STOOL
