Wireless earphones
User manual
BLP4899-004
Safety Precautions
Read these safety instructions before using your device and store them for possible future
reference.
• The device is not intended for use by persons (including children) with reduced
physical, sensory or mental capacity. Persons who have not read the manual, unless
they have received explanations by a person responsible for their safety and
supervision should not use this unit.
• Children should be monitored to ensure that they do not play with the device.
• The device should always be readily accessible.
• The device should not be exposed to dripping or splashing water.
• No objects filled with liquids such as vases shall be placed on the device.
• Always leave a minimum distance of 10 cm around the unit to ensure sufficient
ventilation.
• Open flame sources, such as candles, should not be placed on top of the device.
• The device is intended for use only in a temperate climate.
• At full volume, prolonged listening to the portable audio device may damage the
user’s hearing and cause hearing troubles (temporary or permanent deafness,
hearing drone, tinnitus, hyperacusis).
• So, we recommend not to listen to the portable audio device at high audio volume
and no more than one hour per day at medium audio volume.
• CAUTION: Danger of explosion if battery is incorrectly replaced or not replaced by
the same type or equivalent.
• The battery should not be exposed to excessive heat such as sunshine, fire or similar.
• Different types of batteries, new and used batteries should not be mixed.
• The battery must be installed according to the polarity.
• If the battery is worn, it must be removed from the product.
• The battery must be disposed of safely. Always use the collection bins provided
(check with your dealer) to protect the environment.
• The battery can’t be replaced by the user, but only by the maker of this product, the
after sales department or a qualified person.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off where the use of the device is not allowed or where there is a risk of
causing interference or danger, for example on board an aircraft, near medical equipment,
fuel, chemicals or blasting sites.
ROAD SAFETY COMES FIRST
Check the current laws and regulations regarding the use of this device in the areas where
you drive.
• Do not handle the device when driving.
• Concentrate fully on the driving
• Radio signals could affect some of the car’s electronic systems such as the audio stereo
and alarm systems.
INTERFERENCE
All wireless devices are susceptible to interference which may affect their performance.
All our device conforms to international standards and regulations, and if need be national
ones, with a view to limiting user exposure to electromagnetic fields. These standards and
regulations were adopted after the completion of extensive scientific research. This research
established no link between the use of the mobile headset and any adverse effects on
health if the device is used in accordance with standard practices.
AUTHORISED PERSONNEL
Only qualified people are authorized to install or repair this product.
ACCESSORIES
Only use batteries, chargers and other accessories which are compatible with this
equipment. Do not connect incompatible products.
CHILDREN
Keep your device in a safe place, out of the reach of young children.
The device contains small parts that may present a choking hazard.
Specifications
Rated voltage: DC 5V 1A
Max consumption: 0.228W
Li-Po battery: 400mAh / 2x40mAh
Sound power: 2 x 5mW
Max RF power : 3.98mW
Radio frequency : 2402-2480MHz
Frequency range: 20Hz-20KHz
Bluetooth compatible version: 5.0
Distance Bluetooth stays connected: 10m
Music playing time: Around 5-6 hours
Charging time: 1-2 hours
Size: 52 x 48 x 26mm
Weight: 46g
Product presentation
Definition
L
R
Voice
One Tap ①
（
Playing music
）
pause/play
（
Playing music
）
pause/play
N
One Tap ②
(Phone coming) answer
(Phone coming) answer
N
One Tap
③
（
On calling
）
hang up
（
On calling
）
hang
up
N
Double Tap
Volume+
Volume-
“du” &”max volume”
Triple Tap
Voice assistant Siri
Voice assistant Siri
N
Touch & Hold 2-3sec
①
（
Playing music
）
Next
song
（
Playing music
）
Previous song
N
Touch & Hold 2-3sec
②
（
Incoming call
）
reject
（
Incoming call
）
reject
N
Touch & Hold 7-8sec
Power on/off
Power on/off
Power on/Power off
Pairing
1- Please ensure that earbuds and charging case are charged. If not please charge them.
2- Open charge case and take out both earbuds. You will hear a voice “DONG DONG”, your earbuds are
connected each other and ready to be paired, LED light of right earbud will be flashing quickly.
3- Search on your mobile device Bluetooth function and connect it to the device name “BLP4899”. If successful,
you will hear “
connected” and LED light will turn off.
Charging
1- Earbuds
Put them on the charging case to star charging. The LED lights up red on both headphones and green on the
charging box until full charge, after the LED will turn off. When the headphones load, the number on the charging
box flashes for each of them.
2- Charging case
Charge you charging case with USB/Type C cable provided. Green number will flash until showed “100”.
About the single and both earbuds use
When you connected both earbuds with device. You can put anyone piece into charge case. It will not affect another
one use. And when you take the earbud out of case, it still can be dual paired status with another one.
About auto power-off
When you take the earbuds out of case but not connected with device within 3 minutes, the earbuds will power off
automatically.
About low battery
When earbuds in low battery status, it will voice you “low battery, please charge». At this time, please put the earbuds
into case for charge.
Whether pairing successes
If pairing failed. The 2 earbuds will not be connected at same time. You can put them into case and take them out
again and waiting 5s try.
Confirm whether both earbuds turn on
If only one earbud can hear sounds, please check whether both earbuds have power or not. If not please charge first.
Turn on have 2 way:1. Take the earbuds out from case;2. Long tap about 4-6s.
Confirm the charge case have power or not
When the charge case under low battery or no power status, it can’t recognize earbuds. Whatever turn on/off. Also,
the case green LED light will show”00” or nothing.
If earbuds put in case cannot charging
Please check the earbuds bottom point whether covered other stuff. It will affect the earbuds charging function. Also
need keep earbuds and charging case clear. If dirty, you can use alcohol to wipe.
Declaration of conformity UE
Dag Technologies®, herby declares that this equipment conforms to the essential requirements and other relevant
provisions of Directive 2014/53/UE. The declaration of Conformity can be viewed at the following address:
http://www.mms-support.net/OTA/ECD_DAG_BLP4899-004.pdf
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the
impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of
your obligation, that when you dispose of the appliance, it must be separately collected.
To avoid possible hearing damage, do not listen at high audio volume for long periods of time.
Imported by Dag Technologie®
79/81 Ancienne route Nationale 7
69570 Dardilly
FRANCE
www.blaupunkt.com
Dag Technologie®
79/81 Ancienne Route Nationale 7
69570 Dardilly – France
All rights reserved. All brand names are registered trademarks of their respective owners. Specifications are subject to change without prior
