Wireless earphones
User manual
BLP4890-003
Safety Precautions
Read these safety instructions before using your device and store them for possible future
reference.
• The device is not intended for use by persons (including children) with reduced
physical, sensory or mental capacity. Persons who have not read the manual, unless
they have received explanations by a person responsible for their safety and
supervision should not use this unit.
• Children should be monitored to ensure that they do not play with the device.
• The device should always be readily accessible.
• The device should not be exposed to dripping or splashing water.
• No objects filled with liquids such as vases shall be placed on the device.
• Always leave a minimum distance of 10 cm around the unit to ensure sufficient
ventilation.
• Open flame sources, such as candles, should not be placed on top of the device.
• The device is intended for use only in a temperate climate.
• At full volume, prolonged listening to the portable audio device may damage the
user’s hearing and cause hearing troubles (temporary or permanent deafness,
hearing drone, tinnitus, hyperacusis).
• So, we recommend not to listen to the portable audio device at high audio volume
and no more than one hour per day at medium audio volume.
• CAUTION: Danger of explosion if battery is incorrectly replaced or not replaced by
the same type or equivalent.
• The battery should not be exposed to excessive heat such as sunshine, fire or similar.
• Different types of batteries, new and used batteries should not be mixed.
• The battery must be installed according to the polarity.
• If the battery is worn, it must be removed from the product.
• The battery must be disposed of safely. Always use the collection bins provided
(check with your dealer) to protect the environment.
• The battery can’t be replaced by the user, but only by the maker of this product, the
after sales department or a qualified person.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off where the use of the device is not allowed or where there is a risk of
causing interference or danger, for example on board an aircraft, near medical equipment,
fuel, chemicals or blasting sites.
ROAD SAFETY COMES FIRST
Check the current laws and regulations regarding the use of this device in the areas where
you drive.
• Do not handle the device when driving.
• Concentrate fully on the driving
• Radio signals could affect some of the car’s electronic systems such as the audio stereo
and alarm systems.
INTERFERENCE
All wireless devices are susceptible to interference which may affect their performance.
All our device conforms to international standards and regulations, and if need be national
ones, with a view to limiting user exposure to electromagnetic fields. These standards and
regulations were adopted after the completion of extensive scientific research. This research
established no link between the use of the mobile headset and any adverse effects on
health if the device is used in accordance with standard practices.
AUTHORISED PERSONNEL
Only qualified people are authorized to install or repair this product.
ACCESSORIES
Only use batteries, chargers and other accessories which are compatible with this
equipment. Do not connect incompatible products.
CHILDREN
Keep your device in a safe place, out of the reach of young children.
The device contains small parts that may present a choking hazard.
Specifications
Rated voltage: DC 5V 1A
Max consumption: 15mW
Earphone battery: Li-Po 50mAh*2
Battery case charge: Li-Po 500mAh
Sound power: 3mW
Max RF power : 1,44mW
Radio frequency : 2,4GHz
Frequency range: 20Hz-20KHz
Bluetooth compatible version: 5.0
Distance Bluetooth stays connected: 10m
Music playing time: 3 hours
Charging time: 2 hours
Size: 58 x 55 x 22 mm
Weight: 40g
Product presentation
Left sensor
• One-tap: answer / hang up / pause / play
• Double-tap: Volume down
• Triple-tap: switch previous music
• Keep pressing for 2 seconds: Reject
• Keep pressing for 3 seconds: Call Siri
• Turn Off: Keep pressing for 5 seconds to turn off
Left sensor
LED indicator
Left earphone indicator
light
Power
indicator
Charging
interface
Right sensor
Microphone
Right earphone indicator
light
The fully charged charging
case can charge the
earphone
up to 4 times
Right sensor
• One-tap: answer / hang up / pause / play
• Double-tap: Volume up
• Triple-tap: switch next music
• Keep pressing for 2 seconds: Reject
• Keep pressing for 3 seconds: Call Siri
• Turn Off: Keep pressing for 5 seconds to turn off
Bluetooth Pairing
1.Turn on the charging box switch. When charging, the digital screen will flash and the power will increase, and it will
stop flashing when the display reaches "100". It means the battery is full.
2.Open the top cover of the charging box and take out the earphones.
3.Pair with other devices: Open the phone or other device Bluetooth settings, search for the Bluetooth name
“BLP4890”, click to connect to Bluetooth.
4.The headset is placed in the charging box to enter the charging mode, and the headset is automatically turned off.
5.The headset will automatically shut down if it’s not connected to Bluetooth device for 5 minutes.
Charging
1. After putting the earphones in the case, the green light will flash twice quickly. Flashing twice means the earphones
are detected; then flash slowly for 20 seconds. Flashing slowly means it is in charging.
2. After flashing slowly for 20 seconds, the display screen will enter the sleep state and the light will be off.
3. When the earphones are fully charged, the digital screen will light for 1 second and then be off.
Declaration of conformity UE
Market Maker Brand Licensing herby declares that this equipment conforms to the essential requirements and other
relevant provisions of Directive 2014/53/UE. The declaration of Conformity can be viewed at the following address:
http://www.mms-support.net/OTA/ECD_MMBL_BLP4890-003.pdf
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the
impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of
your obligation, that when you dispose of the appliance, it must be separately collected.
To avoid possible hearing damage, do not listen at high audio volume for long periods of time.
Imported by Market Maker Brand Licensing
79/81 Ancienne route Nationale 7
69570 Dardilly
FRANCE
www.blaupunkt.com
Market Maker Brand Licensing
79/81 Ancienne Route Nationale 7
69570 Dardilly – France
All rights reserved. All brand names are registered trademarks of their respective owners. Specifications are subject to change without prior
