OWNER & OPERATOR
INSTRUCTION MANUAL
For service contact:
German Knife Inc.
1-800-500-3519
www.turboairinc.com
Model No.
GBS-450S
www.turboairinc.com
IMPORTANT SAFETY NOTICE
To ensure safe and trouble free performance of you new
German knife slicer, we suggest that all personnel who will
use and maintain the slicer read and understand the manual
before operating the equipment. Should there be any
questions or if we can be of further assistance, please call us
toll free at (800) 500-3519.
2
TABLE OF CONTENTS
LUBRICATION INSTRUCTION
FRAME PARTS
UPPER SAW WHEEL PARTS
LOWER SAW WHEEL PARTS
SAW GUIDE PARTS
DRIVE PARTS
FRONT SCRAPER PARTS
REAR SCRAPER PARTS
MEAT GAUGE PARTS
TABLE PARTS
ELECTRIC CURCUIT
WARRANTY INFORMATION
3
4
5
6
7
8
9
10
11
12
13
14
PAGE
German Knife Industries
4184 E. Conant St., Long Beach, CA 90808
Phone : 800-500-3519
Fax : 310-900-1066
www.turboairinc.com
3
LUBRICATION INSTRUCTIONS
U
UPPER WHEEL :
2-4 strokes with
grease gun every 30
days as needed
MEAT CARRYING
TABLE WHEELS :
Lubricate daily with
edible oil
LOWER WHEEL &
BEARING HOUSING :
2-4 strokes with
grease gun every 30
days as needed
TENSION HANDLE :
Lubricate daily with
edible oil while
screwing in and out
UPPER BLADE GUIDE
SUPPORT BAR :
Lubricate daily with
food grade oil while
moving up and down
MOTOR :
If equipped with grease
fittings grease every six
months with bearing
grease
4
FRAME PARTS
ྦ
ྥ
ྤ
ྦྷ
ྡ
ྡྷ
ྠ
ྟ
ྞ
ྜྷ
ྜ
ྛ
ྚ
ྙ
ྣ
ITEM
1
2
3
4
5
6
7
8
Upper micro switch cover
Micro switch
Upper door
Hinge Pin
Hinge
Door Latch
Door Handle
Lower Door
301101
301102
301103
301104
301105
301106
301107
301108
1
2
1
6
6
2
2
1
9
10
11
12
13
14
15
Scrap Box
Motor Access Panel
Leg Assy
Brace Adjust Bracket
Brace
Middle Door
Rear Cover
301109
301110
301111
000219
301113
301114
301115
1
2
4
2
2
1
1
DESCRIPTION PART NO. USE ITEM DESCRIPTION PART NO. USE
5
UPPER SAW WHEEL PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
000101
000102
301203
301204
000132
301206
301207
301208
301209
301210
301211
301212
301213
000114
301215
301216
301217
301218
301219
301220
000121
301222
301223
301224
301225
000126
301227
000128
301229
301230
301231
Guide Block LH
Guide Block RH
Scraper Arm
Fiber Scraper
Scraper Spring
Upper Shaft & Bearing Assy
16" Upper Wheel & Shaft Assy
Washer
Upper Shaft W/Nut & Washer
Bearing Retainer
Gasket
Rubber Seal
Bearing
16" Upper Wheel
Bearing Spacer
Retainer & Screw Assy
Gasket
Hub Cap
Upper Shaft Nut
Adjusting Screw & Nut
Upper Hanger
Tension Spring
Indicator
Adjusting Screw
Pins & Spring Assy
Tension Handle
Wheel Scraper Assy
Gauge Block
Blade Tension Assy
Hanger & Arm Assy
Tension Handle Assy
ITEM DESCRIPTION PART NO. USE ITEM DESCRIPTION PART NO. USE
6
LOWER SAW WHEEL PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2
2
1
2
1
1
1
1
1
3
1
1
1
1
301301
301213
301303
301304
301305
000138
301307
301308
301309
301310
301311
301312
301313
000145
301211
301218
Snap Ring
Bearing
Lower Wheel Shaft & Washer, Nut
Snap Ring
Nut & Washer
Bearing Case
Rubber Seal
Special Washer
Key
Lower Shaft and Bearing Assy
Lower Bearing Case and Shaft Assy
Stud
Bearing Case Support
16" Lower Wheel
Gasket
Hub Cap
ITEM DESCRIPTION PART NO. USE
7
SAW GUIDE PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
1
1
1
1
1
1
1
1
1
1
1
1
1
301401
301402
301403
301404
301405
301406
000152
301408
000154
301410
000157
301412
301413
301414
Blade Support Adj. Bar
Blade Guard Assy. Rh
Knob
Blade Guard Extension Rh
Extension Stop
Blade Guide
Holder
Lock Nut
Hand Grip Hex Nut
Knob
Blade Support Bar Guide
Blade Guard Assy. W/Ext-Rh
Blade Guard Assy. W/Ext & Adj. Bar
Blade Support Bar Guide Spacer
ITEM DESCRIPTION PART NO. USE
8
DRIVE PARTS
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
2
1
301501
301502
301503
301503
301504
301505
301506
301507
301508
301509
V-Belt
Driven Pulley(8.5")
Motor Pulley(Standard)
Motor Pulley(High Speed)
Torque Rod Assy
Torque Bracket
Motor(3HP)
Motor Mount Assy
Rubber Mount Assy
Rubber Washer
ITEM DESCRIPTION PART NO. USE
9
FRONT SCRAPER PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
301601
301602
000170
301604
301605
301606
301607
301608
000176
301610
301611
000179
301613
000132
301227
Front Scraper Assy
Fiber Blade Block
Scraper & Roller Mount
Lower Blade Guide
Back-Up Bearing
Bolt
Blade Scraper Assy
Spring
Lh Scraper Holder
Scraper - Stainless Steel
Deflector
Rh Scraper Holder
Fiber Wheel Scraper
Scraper Spring
Wheel Scraper Assy
ITEM DESCRIPTION PART NO. USE
10
REAR SCRAPER PARTS
1
2
3
4
5
6
7
8
9
10
1
1
1
1
1
1
2
1
1
1
300405
301702
000179
301608
000176
301706
301707
301708
301607
301710
Scraper Mount & Lock
Lock Pin
Rh Scraper Holder
Spring
Lh Scraper Holder
Bolt & Nut
Fiber Scraper
Holding Stud
Blade Scraper Assy
Scraper Assy
ITEM DESCRIPTION PART NO. USE
ྙ
ྠ
ྞ
ྟ
ྜྷ
ྜ
ྛ
ྚ
ྡ
ྡྷ
11
MEAT GAUGE PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
1
1
1
1
1
4
1
1
1
2
1
2
1
301801
301802
301803
301804
301805
301806
301807
301808
301809
301810
301811
301812
301813
Thickness Gauge Rollor
Thickness Gauge Plate
Thickness Gauge Arm
Thickness Gauge Arm Assy
Handle Assy
Bushing
Gauge Spindle
Thickness Gauge Slide Bracket
Thickness Gauge Slide Lod
Slide Lod Bracket
Gauge Latch Lock
Wing Bolt
Slide Lod Assy
ITEM DESCRIPTION PART NO. USE
ྤ
ྡྷ
ྡ
ྠ
ྟ
ྞ
ྜྷ
ྜ
ྛ
ྙ
ྚ
ྥ
ྣ
12
TABLE PARTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
1
1
1
2
1
2
2
2
1
2
3
1
4
6
1
301901
301902
301903
301904
301905
301906
301907
301908
301909
301910
301911
301912
301913
301914
301915
301916
Stationary Table Assy
Table Lock Lever
Front Table Support
Rear Table Support
Lever Adjusting Lock
Table Track
Table Track Support
Stop Bracket Assy
Rubber Stopper
Angle Support Assy
Table Wheel Axel
Table Holding Pin
Table Stop Handle
Table Rolling Wheel
Table Button
Roller Table Assy
ITEM
DESCRIPTION PART NO. USE
13
ELECTRIC CURCUIT
Magnet Switch
T2
T1
T3
Motor
Protection
and Magnetic
Thermal
L2
L1
L3
A1
L1
T1
GRN
T
S
R
Lower
A2
A2
NOL3
L2
NOT3
T2
Door
Upper
Door
Signal Light
Open Block
Switch
Main
Close Block
Open Block
GBS-450S
MODEL
(3Φ 208V 60Hz
GRN
Main Power
3Φ 208V 60Hz
3HP)
LIMITED WARRANTY
Warranty Claims...
All Claims for parts or labor must be made directly through German Knife or Radiance. All claims should include the model number, serial
number, proof of purchase, date of installation and all pertinent information supporting the alleged defect. All warranty claims must be
authorized by German Knife or Radiance prior to the purchase of parts or labor. Failure to comply with these warranty policies will result in
the voiding of warranty claims.
Products Under Warranty...
Radiance warrants all heavy duty microwaves to include all new parts and components to be free from defects in material or workmanship
under normal and proper use and maintenance service as specified by Radiance upon proper commercial installation. Radiance’s
obligation under this warranty is limited to a period of three (3) years from the date of original purchase. Any Part covered under this
warranty that is found by Radiance to have been defective within 3 years of the original purchase is limited to the repair or replacement,
including labor charges, of defective parts or assemblies. The labor charges shall include standard straight time labor charges only and
reasonable travel time as determined by Radiance.
Radiance warrants all gas cooking equipment and microwave models TMW-1100MR and TMW-1100ER and German Knife warrants all
light duty meat slicers to include all new parts and components to be free from defects in material or workmanship under normal and
proper use and maintenance service as specified by German Knife upon proper commercial installation. German Knife’s obligation under
this warranty is limited to a period of one (1) year from the date of original purchase. Any Part covered under this warranty that is found by
German Knife to have been defective within 1 year of the original purchase is limited to the repair or replacement, including labor charges,
of defective parts or assemblies. The labor charges shall include standard straight time labor charges only and reasonable travel time as
determined by German Knife.
German Knife warrants all heavy duty meat slicers, meat grinders, and meat saws to include all new parts and components to be free
from defects in material or workmanship under normal and proper use and maintenance service as specified by German Knife upon
proper commercial installation. German Knife’s obligation under this warranty is limited to a period of two (2) years from the date of
original purchase. Any Part covered under this warranty that is found by German Knife to have been defective within 2 years of the original
purchase is limited to the repair or replacement, including labor charges, of defective parts or assemblies. The labor charges shall include
standard straight time labor charges only and reasonable travel time as determined by German Knife.
What is Not Covered by This Warranty...
German Knife’s sole obligation under this warranty is limited to either repair or replacement of parts, subject to the additional limitations
below. This warranty neither assumes nor authorizes any person to assume obligations other than those expressly covered by this
warranty.
No consequential damages. Radiance is not responsible for economic loss; profit loss; or special, indirect, or consequential damages.
Warranty is not transferable, this warranty is not assignable and applies only in favor of the original purchaser/user to whom delivered.
Any such assignment or transfer shall void the warranties herein and shall void all warranties, express or implied, including any warranty
of merchantability or labor coverage for component failure or other warranty packet provided with the unit.
Alteration, neglect, abuse, misuse, accident, damage during transit or installation, fire, food, acts of god. German Knife is not responsible
for the repair or replacement of any parts that radiance determines have been subjected after the date of manufacture to alteration,
neglect, abuse, misuse, accident, damage during transit or installation, fire, flood, or act of god. Improper electrical connections. German
Knife is not responsible for the repair or replacement of failed or damaged components resulting from electrical power failure, the use of
extension cords, low voltage, or voltage drops to the unit. No implied warranty of merchantability or fitness for a particular purpose; there
are no other warranties, expressed, implied or statutory, except the warranties expressly granted above. These warranties are exclusive
and in lieu of all other warranties, including implied warranty and merchantability or fitness for a particular purpose. There are no warran-
ties, which extend beyond the description on the face hereof.
Outside U.S. and Canada; this warranty does not apply to, and radiance is not responsible for, any warranty claims made on products sold
or used outside the continent of the United States and Canada.
