INSTALL SIDE PANELS
• Disconnect power from appliance before installing
panel.
• Remove the top case bumper by removing the hex
screw (on some models).
• Remove the paper from the adhesive strips on the
side panels.
• Loosen screws holding top hinge cover on the side of
unit where panel will be installed. Slip panel under
hinge cover.
• Align the panels to the unit as shown.
• Press with force on adhesive areas starting with the
top front section to secure the panels.
• Secure the top hinge cover and replace the rear case
bumper (or install new one from kit).
• Remove protective film by starting in the front/top
corner and peeling downward toward the back/bottom
corner.
• Connect appliance to power.
31-1000616 Rev. 1 02-22 GEA
Hex screw
Rear case bumper
Matte White Side Panel Kit
Installation Instructions
For more information about this kit, visit cafeappliances.com. In Canada, visit cafeappliances.ca.
WARNING
Electrical Shock Hazard
Death or serious injury can result from failure to follow
these instructions.
• Disconnect power before installing this panel.
• Replace all parts and panels before operating.
WARNING
Cut Hazard Warning
Panel edges along stamp/cut-out areas may be sharp.
Avoid placing hands, fingers or other appendages near
these areas. Wear gloves for installation. Failure to do
so can result in cuts.
Adhesive
strips
Top hinge cover Top hinge cover
Rear
case
bumper
