User manual of Honda ODYSSEY 2023 (125 pages)
file thumbnail

The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co. Ltd. reserves the right. however. to discontinue or change specifications or design at any time without notice and without incurring any obligation.

Accessories Precautions

The GPS antenna is located on the roof. Trees. tall buildings. highway overpasses. tunnels. or overhead electrical power wires can easily interrupt or interfere GPS reception.

Signal noise from devices such as radar detectors. vehicle tracking devices. remote starters. and additional amplifiers can disrupt the navigation system. If you install any such item. install it away from the navigation display and antenna.

Important Safety Information

Avoid focusing on the screen or manually operating the system controls while driving.

Certain on-screen controls are disabled when driving. however most of the voice commands continue to function. Pull to the side of the road if you need to devote more attention and time to look at the screen or access additional menus.

Route guidance may conflict with street closures. road construction. detours. and out-of-date map data.

The system itself may also have limitations. Verify route information by carefully observing roads. signs. and signals. Always use your own judgment and obey traffic laws.

2 System Limitations P. 106

NOTICE This vehicle’s navigation display. if so equipped. includes mercury-containing components. Upon removal. please reuse. recycle. or dispose of as hazardous waste.

Clean the screen with a soft. damp cloth. You may use a mild cleaner intended for use on navigation screens.

3 WARNING

Using the navigation system while driving can take your attention away from the road. causing a crash in which you could be seriously injured or killed.

Only operate system controls when the conditions permit you to safely do so.

Contents

2 System Setup P. 15

Start-up 16 Voice Control System 17 Personal Information 18 Display Mode Settings 30 Guidance Volume Settings 32 Map and Vehicle 33 Navigation 40 Traffic 48 Location History 49 About 50 Data Reset 51

2 Navigation P. 53

Entering a Destination 54 Calculating the Route 72 Driving to Your Destination 75 Map Operation 82 Changing Your Route 88 Changing Your Destination 94

2 Troubleshooting P. 99 Troubleshooting 100

2 Reference Information P. 105 System Limitations 106 Customer Assistance 108 Legal Information 110

2 Voice Commands P. 117 Voice Commands 118 List of Categories 120

Quick Reference Guide P. 2

System Setup P. 15

Navigation P. 53

Troubleshooting P. 99

Reference Information P. 105

Voice Commands P. 117

Index P. 121

Quick Reference Guide

Quick Reference Guide

Overview—Functions at a Glance

Navigation You can select any place/landmark as a destination by using the touchscreen. The navigation system gives you turn-by-turn driving directions to your destination.

Store home address (P18) Register 1 home address.

Track route (P75) Follow your route in real-time with voice guidance.

Store contacts (P19) Store locations to use as the destination.

Enter destination (P54) Select your destination using several methods.

Select route (P73) Set route preferences and select one of the available routes.

Avoid certain areas (P43) Set streets and areas to detour around.

Add waypoints (P90) Add “pit stops” along your route.

Traffic Information* (P80) View and avoid congestion and traffic incidents.

+: Available only in certain areas.

Quick Reference Guide

HOME Screen The system displays various functions from the HOME screen. Press the icon at any time to return to the main HOME screen.

(Home) Display the HOME screen. (Back) Go back to the previous screen. (Display Mode) Switch between Day and Night modes manually.

VOL (Volume) Increase or decrease the audio volume.

Navigation Display the map screen.

Quick Reference Guide

Touchscreen Operation You can operate the system using your finger on the touchscreen.

The touchscreen can be operated if you are wearing thin gloves. but it may be more difficult for the system to respond.

Touch the screen lightly with your finger to select an option on the screen.

Swipe

Lightly sweep your finger side to side or up and down to scroll a list or map.

You can change the touchscreen sensitivity setting.

2 Refer to the Owner’s Manual.

Slide

Move your finger slowly across the screen to scroll the map.

Pinch In/Out

Open or close your fingers on the screen in a pinching motion to zoom in or out of the map.

Quick Reference Guide

How to Enter Information You can enter information (e.g. city names. street names. numbers. and symbols) when prompted on the input screen.

Using Voice Commands When you see in this manual. voice commands are available for that feature.

The system recognizes only certain commands.

Available navigation commands (P118)

 Press the button. and say the command. phrase. letter. number. or symbol (e.g. say “1”).

 If a voice command is not recognized. a list is displayed with possible options.

On list screens:  Say the number of the list item (e.g. say “Three” to select item 3).

 Say “Back” to return to the previous screen.

 Say “Next” for next page.

 Say “Previous” for previous page.

 Say “Cancel” to end the voice command function.

Using the Touchscreen Select a character or icon on the screen to select it.

 Select to remove the last entered character.

 Select to remove all entered characters.

 Select to display upper/lower case characters.

 Select Space to enter a space character.

 Select to display other types of characters.

 Select to change the keypad language.

On input search screens. the suggested search terms are displayed. Select Done to display a list of possible entries.

Quick Reference Guide

Map Screen Legend The color of the map is different depending on the selected Map Theme.

Map operation icons (P82)

Current vehicle position

Streets

Landmark icons

Map scale (P82)

Map tools (P83)

Feature areas

Where To? (P54)

Quick Reference Guide

During Route Guidance During route guidance. route information is displayed on the map screen.

You can see the detailed information on the turn list screen.

Map Screen

Guidance Screen

Dashboards (P75)

Next guidance indicator (P75) Distance to the next guidance point and street name of next guidance point.

Select to get next voice guidance.

Queue indicator Where To? (P54)

Calculated route

Current street name

Waypoint

Street name of next guidance point Distance to next guidance point

Estimated time to next guidance point

Day or Night Mode Press the icon to manually switch between Day and Night modes.

Turn-by-Turn Directions The next guidance point appears on the Driver Information Interface.

Day Mode Night Mode

Remaining distance Street name of next guidance point

Next driving maneuver is approaching.

Quick Reference Guide

Navigation—Home Addresses and Going Home The “Home” feature automatically routes you to your home address from any location simply by selecting Go Home.

You can store one home address. (P18)

The order of the steps may change depending on the map data loaded on your system.

Storing Your Home Address

Going Home

Alternatively. you can say “Navigation” and then “Go Home” from any screen.

Troubleshooting

Troubleshooting .. 100 Map. Voice. Entering Destinations .. 100 Traffic .. 101 Guidance. Routing. 102 Update. Coverage. Map Errors. 103 Display. Accessories 103 Miscellaneous Questions. 104

Troubleshooting

Troubleshooting

Map. Voice. Entering Destinations

Problem Solution

The Startup Confirmation screen is displayed every time I start the car.

This is normal. The Startup Confirmation screen reminds you and your guest drivers to always operate the navigation system in a safe manner. The Startup Confirmation screen goes off after a certain period of time. even if you do not select OK.

The navigation system reboots by itself (returns to the opening screen).

A reboot can be caused by extreme temperatures or shock from bumpy roads. and does not necessarily indicate a problem. If this happens frequently. please see your dealer.

How do I specify a destination when an entered city or street could not be found?

Try selecting the destination directly from the map.

2 Map Input P. 71

How do I delete saved places?

1. Press the icon and then select Navigation > > Saved > > Delete Saved Places.

2. Select saved places you want to delete.

3. Select Delete.

4. Select Delete.

I cannot hear the navigation system voice.

• Press the icon. Select Navigation > > Guidance Volume.

Turn up the volume if it is low.

● Adjust the volume using the volume knob during the voice guidance.

Troubleshooting

Traffic

Problem Solution

Traffic information is missing or is not displaying properly. What is wrong?

Verify the following:

● Traffic information relies on a clear signal. If signal strength is low. traffic data may not be available.

● Check that the traffic feature is enabled.

2 Traffic P. 48

● It is possible that there is a temporary technical problem with your metropolitan area traffic provider. You can call Honda Automobile Customer Service to see if there is an outage.

2 Contacting Honda Customer Service P. 108

● If the situation persists. see your authorized Honda dealer for assistance.

● Traffic information is available only in certain areas.

Troubleshooting

Guidance. Routing

Problem Solution

The navigation system does not route me the same way I would go or the same way as other mapping systems.

The navigation system attempts to generate the optimal route. You can change the route preferences used when calculating a route.

2 Calculation Mode P. 41

The street I’m on is not shown on the map screen.

The mapping database is constantly undergoing revision.

The vehicle position icon is not following the road.

• This is normal. The signals received from the GPS satellites are extremely weak and can easily be interrupted or interfered as your vehicle travels near tall buildings or in tunnels. Check your vehicle surroundings for anything that may be blocking the reception.

If this happens frequently and there is no obstruction that is interfering the reception. please see your dealer.

● Metallic tinting or other aftermarket devices can interfere with GPS reception.

Please consult your dealer.

2 GPS P. 106

How do I stop the map from rotating as I drive along?

1. Press the icon and then select Navigation >

2. Select Settings > Map and Vehicle > Driving Map View.

3. Check that Driving Map View is set to Track Up or 3D.

4. Select North Up and then select Save.

The “Arrival time” display sometimes increases even though I am getting closer to my destination.

The “Arrival time” is based on the speed limit on each road. Depending on the traffic conditions. the “Arrival time” may be calculated to be earlier or later.

My elevation (shown when I display the current position) seems to fluctuate even though my elevation has not changed.

This is normal. The elevation can vary ±100 ft (30 m) due to GPS calculation errors.

2 GPS P. 106

My elevation is missing on the “current position” screen.

The elevation is only displayed if the GPS antenna can receive signals from at least four satellites. Try moving the vehicle into an open area. The elevation is also not displayed if the calculated elevation is zero or below sea level.

Troubleshooting

Update. Coverage. Map Errors

Display. Accessories

Problem Solution

My city is not part of a fully verified detailed coverage area.

The mapping database is constantly undergoing revision.

Does the navigation system work outside North America?

The system contains maps for the United States of America. Canada. Mexico.

Puerto Rico. US Virgin Islands. Cayman Islands. Bahamas. French Guiana.

Guadeloupe. Martinique. Saint Barthelemy. and Jamaica. The navigation system will not work in other countries.

2 Map Coverage P. 109

Problem Solution

The display appears dim when starting the car in really cold weather.

This is normal. The display will become brighter after a few minutes.

Troubleshooting

Miscellaneous Questions

Problem Solution

My clock frequently changes forward and backward by one hour.

The clock setting is automatically updated based on your GPS location. If you are driving near a time zone border. the automatic update likely is the reason.

How do I change the interface language?

Select the icon and then select Settings > System > Language.

Select the desired language for system language.

For more information. see the Owner's Manual.

Reference Information

System Limitations ..106 GPS 106 Address Calculation 106 Database .106 Customer Assistance ..108 Resolving Problems .108 Obtaining a Navigation Update .108 Visiting Your Dealer 108 Contacting Honda Customer Service ..108 Map Coverage ..109 Traffic Information ..109

Legal Information 110 End User License Agreement. 110

Reference Information

System Limitations

The signals received from GPS satellites are extremely weak (less than a millionth of the strength of a local FM station) and require an unobstructed view of the sky. The GPS antenna is located in the fin antenna. The signal reception can easily be interrupted or interfered with by the following:

• Audio electronic devices mounted near the navigation unit

• Trees. tall buildings. highway overpasses. tunnels. or overhead electrical power wires

GPS is operated by the U.S. Department of Defense. For security reasons. there are certain inaccuracies built into GPS for which the navigation system must constantly compensate. This can cause occasional positioning errors of up to several hundred feet (meters).

Address Calculation

The destination icon shows only the approximate location of a destination address. This occurs if the number of possible addresses is different from the number of actual addresses on a block. For example. the address 1425 on a 1400 block with 100 possible addresses (because it is followed by the 1500 block) will be shown a quarter of the way down the block by the system. If there are only 25 actual addresses on the block. the actual location of address 1425 would be at the end of the block.

Database

The digitized map database reflects conditions as they existed at various points in time before production. Accordingly. your database may contain inaccurate or incomplete data or information due to the passage of time. road construction. changing conditions. or other causes.

For example. some places/landmarks may be missing when you search the database because the name was misspelled. the place was improperly categorized. or a place/ landmark is not yet in the database. This is also true for police stations. hospitals. and other public institutions. Do not rely on the navigation system if you need law enforcement or hospital services. Always check with local information sources.

Reference Information

The database does not include. analyze. process. consider. or reflect any of the following categories of information:

• Neighborhood quality or safety

• Population density

• Availability or proximity of law enforcement

• Emergency. rescue. medical. or other assistance

• Construction work. zones. or hazards

• Road and lane closures

• Legal restrictions (such as vehicular type. weight. load. height. and speed restrictions)

• Road slope or grade

• Bridge height. width. weight. or other limits

• Traffic facilities safety

• Special events

• Pavement characteristics or conditions

Every effort has been made to verify that the database is accurate. The number of inaccuracies you experience increases the longer you go without obtaining an updated map database.

2 Obtaining a Navigation Update P. 108

We assume no liability for any incident that may result from an error in the program. or from changed conditions not noted above.

Quick Reference Guide

Navigation—Entering a Destination Enter your destination using one of several methods. then follow route guidance on the map to your destination.

The order of the steps may change depending on the map data loaded on your system.

 Routes: Choose one of multiple routes.

 Info: Display the location information and save a place.

Reference Information

Customer Assistance

Resolving Problems

If you run into a specific issue that you cannot resolve. consult the following help resources:

• For navigation system issues: 2 Troubleshooting P. 100 Or. please contact your dealer.

• For traffic-related issues: 2 Traffic P. 101

• For reporting issues with the database or places/landmarks:

• Visit https://my.garmin.com/mapErrors/ report.faces

• Or call Garmin OEM support directly at (855) 607-2536.

Obtaining a Navigation Update

Honda is continuously updating the navigation system and new software is usually made available on an annual basis.

For information on navigation updates for your vehicle. please visit:

• U.S.: hondanavi.navigation.com

• Canada: www.honda.ca/owners/honda services/navigation

You can also contact your authorized Honda dealer for further information regarding the update program available for your vehicle.

Visiting Your Dealer

If you have a question that you cannot resolve using the available help resources. you can consult your dealer. Please identify the specific issue (e.g. error occurs when you enter a specific address. when driving on a certain road. or just when it’s cold) so that the service advisor can refer the issue to the factory so that a solution can be found.

Be patient. the service advisor may be unfamiliar with your specific issue.

Contacting Honda Customer Service

If neither the available help resources nor your authorized Honda dealer can resolve your issue to your satisfaction. contact Honda Automobile Customer Service.

American Honda Motor Co. Inc.

Honda Automobile Customer Service Mail Stop CHI-5 1919 Torrance Blvd.

Torrance. CA 90501-2746 Tel: (800) 999-1009 Fax: (310) 783-3023 Website: owners.honda.com 24/7 Virtual Agent: askdave.honda.com

Honda Canada Inc.

Honda Customer Relations 180 Honda Blvd.

Markham. ON L6C 0H9 Tel: (888)-9-HONDA-9 Hours: 8:00 am to 7:30 pm Mon to Fri (ET)

Reference Information

Map Coverage

The system provides maps for the United States of America. Canada. Mexico. Puerto Rico. US Virgin Islands. Cayman Islands.

Bahamas. French Guiana. Guadeloupe.

Martinique. Saint Barthelemy. and Jamaica.

The navigation system will not work in other countries.

Traffic Information

Continuously updated traffic information is available in major metropolitan areas across the contiguous United States and some cities in Canada.

Reference Information

Legal Information

End User License Agreement

The infotainment system you have purchased for your vehicle may contain a navigation solution ("Navigation Solution").

The software embedded in the Navigation Solution (the "Software") is owned by the navigation solution provider or its subsidiaries (collectively. "Navigation Provider"). The map data that may be embedded in your Navigation Solution or downloaded separately (the "Map Data") is either owned by the Navigation Provider. or by HERE North America LLC and/or its affiliates ("HERE") or another third party and licensed to the Navigation Provider.

The Navigation Provider also owns. or licenses from third party providers. information. traffic data. text. images. graphics. photographs. audio. video. images and other applications and data that may be embedded in the Navigation Solution. or downloaded separately ("Other Content"). The Map Data and Other Content are collectively the "Content". The Software and Content (collectively. the "Navigation Provider Products") are protected under copyright laws and international copyright treaties. The

Navigation Provider Products are licensed. not sold. The structure. organization and code of the Software are valuable trade secrets of the Navigation Provider and/or its third-party providers. The Navigation Provider Products are each provided under this License Agreement and are subject to the following terms and conditions which are agreed to by End User ("you" or "your"). on the one hand. and the Navigation Provider and its licensors and affiliated companies of the Navigation Provider and its licensors. on the other hand. The Navigation Provider's licensors. including the licensors. service providers. channel partners. suppliers and affiliated companies of the Navigation Provider and its licensors. are each a direct and intended third party beneficiary of this Agreement and may enforce their rights directly against you in the event of your breach of this Agreement.

IMPORTANT: CAREFULLY READ THIS ENTIRE LICENSE AGREEMENT BEFORE PURCHASING OR USING YOUR NAVIGATION SOLUTION OR CONTENT.

PURCHASING. INSTALLING. COPYING. OR OTHERWISE USING YOUR NAVIGATION

SOLUTION OR CONTENT CONSTITUTES YOUR ACKNOWLEDGMENT THAT YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS AND CONDITIONS.

The Navigation Provider grants you a limited. non-exclusive license to use the applicable Navigation Provider Product in accordance with the terms of this Agreement. You agree to use the applicable Navigation Provider Product for solely personal use. or if applicable. for use in your business' internal operations. and not for service bureau. time sharing. resale or other similar purposes. You agree not to otherwise reproduce. archive. copy. modify. decompile. disassemble. reverse engineer or create derivative works of any portion of the Navigation Solution. and may not transfer or distribute it in any form. for any purpose. except to the extent permitted by mandatory laws. The Navigation Provider also reserves the right to discontinue offering any Content supplied by any third party supplier if such supplier ceases to supply such content or the Navigation Provider's contract with such supplier terminates for any reason.

■ License Terms and Conditions

Continued

Reference Information

Restrictions. Except where you have been specifically licensed to do so by Navigation Provider. and without limiting the preceding paragraphs. you may not use the Navigation Provider Products with any products. systems. or applications installed or otherwise connected to or in communication with vehicles. and which are capable of dispatch. fleet management or similar applications where the Content is used by a central control center in dispatching a fleet of vehicles. In addition. you are prohibited from renting or leasing the Navigation Provider Products to any other person or third party.

You agree to be fully responsible for your own conduct and content while using the Software and for any consequences thereof. You agree to use the Software only for purposes that are legal. proper and in accordance with this Agreement and any applicable policies or guidelines. By way of example. and not as a limitation. you agree that when using the Software. You will not:

• upload. post. email or transmit or otherwise make available content that infringes any patent. trademark. copyright. trade secret or other

In the event that you are located outside of the United States. you agree to comply with any laws. rules or regulations in your locale or in the location of your web server regarding online conduct and acceptable content. including laws regulating the export of data to the United States or your country of residence.

No Warranty. The Navigation Provider Products are provided to you "as is. and you agree to use them at your own risk.

The Navigation Provider and its licensors including the licensors. service providers. channel partners and suppliers. and affiliated companies of Navigation Provider and its licensors. make no guarantees. representations or warranties of any kind. express or implied. arising by law or

Disclaimer of Warranty. THE NAVIGATION PROVIDER AND ITS LICENSORS. INCLUDING THE LICENSORS.

SERVICE PROVIDERS. CHANNEL PARTNERS.

SUPPLIERS AND AFFILIATED COMPANIES OF THE NAVIGATION PROVIDER AND ITS LICENSORS. DISCLAIM ANY WARRANTIES.

EXPRESS OR IMPLIED. OF QUALITY.

PERFORMANCE. MERCHANTABILITY.

FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF THE NAVIGATION PROVIDER PRODUCTS. NO ORAL OR

Reference Information

WRITTEN ADVICE OR INFORMATION PROVIDED BY THE NAVIGATION PROVIDER OR ITS SUPPLIERS AND LICENSORS SHALL CREATE A WARRANTY. AND YOU ARE NOT ENTITLED TO RELY ON ANY SUCH ADVICE OR INFORMATION. THIS DISCLAIMER OF WARRANTIES IS AN ESSENTIAL CONDITION OF THIS AGREEMENT. Some States.

Territories and Countries do not allow certain warranty exclusions. so to that extent the above exclusion may not apply to you.

Disclaimer of Liability. THE NAVIGATION PROVIDER AND ITS LICENSORS. INCLUDING THE LICENSORS. SERVICE PROVIDERS.

CHANNEL PARTNERS. SUPPLIERS AND AFFILIATED COMPANIES OF THE NAVIGATION PROVIDER AND ITS LICENSORS. SHALL NOT BE LIABLE TO YOU: IN RESPECT OF ANY CLAIM. DEMAND OR ACTION. IRRESPECTIVE OF THE NATURE OF THE CAUSE OF THE CLAIM. DEMAND OR ACTION ALLEGING ANY LOSS. INJURY OR DAMAGES. DIRECT OR INDIRECT. WHICH MAY RESULT FROM THE USE OR POSSESSION OF THE NAVIGATION PROVIDER PRODUCTS; OR FOR ANY LOSS OF PROFIT. REVENUE. CONTRACTS OR

SAVINGS. OR ANY OTHER DIRECT.

INDIRECT. INCIDENTAL. SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF YOUR USE OF OR INABILITY TO USE THE NAVIGATION PROVIDER PRODUCTS. ANY DEFECT IN THE CONTENT OR INFORMATION. OR THE BREACH OF THESE TERMS OR CONDITIONS. WHETHER IN AN ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY AND WHETHER RESULTING FROM THE USE. MISUSE. OR INABILITY TO USE THE NAVIGATION PROVIDER PRODUCTS OR FROM DEFECTS OR ERRORS IN THE APPLICATION. EVEN IF GARMIN OR ITS LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE NAVIGATION PROVIDER'S AND ITS LICENSORS' TOTAL AGGREGATE LIABILITY WITH RESPECT TO ITS OBLIGATIONS UNDER THIS LICENSE AGREEMENT OR OTHERWISE WITH RESPECT TO THE APPLICATION OR THE CONTENT SHALL NOT EXCEED $1.00.

Some States. Territories and Countries do not allow certain liability exclusions or damages limitations. so to that extent the above may not apply to you.

ANY CONTENT OR MATERIAL DOWNLOADED OR UPLOADED OR OTHERWISE OBTAINED THROUGH THE SOFTWARE IS DONE AT YOUR OWN DISCRETION AND RISK. YOU WILL BE SOLELY RESPONSIBLE FOR ANY DAMAGE TO YOUR ELECTRONIC COMMUNICATION DEVICE OR ANY LOSS OF DATA THAT MAY RESULT FROM THE DOWNLOAD OR UPLOAD OF ANY SUCH CONTENT OR MATERIAL OR THE USE OF THE SOFTWARE.

Predictive Routing. Your Navigation Solution may have a "predictive routing" feature called myTrends that identifies your driving routines. If it does have this feature. when your device predicts a route. it will display your estimated time to destination and relevant traffic information regarding the predicted route. Information related to your driving routines would be accessible to any other person who uses your device. If you do not want your device to predict your routes or display information related to predicted routes. you may turn off myTrends by accessing your navigation system's Settings menu.

Continued

Reference Information

Disclaimer of Endorsement; Change of Content Providers. Reference to any products. services. processes. hypertext links to third parties or other Content by trade name. trademark. manufacturer. supplier or otherwise does not necessarily constitute or imply its endorsement. sponsorship or recommendation by the Navigation Provider or its licensors. Product and service information are the sole responsibility of each individual vendor. The HERE name and logo. the HERE and HERE ON BOARD trademarks and logos. and other trademarks and trade names owned by HERE North America LLC may not be used in any commercial manner without the prior written consent of HERE. Content providers may be changed by the Navigation Provider during the term of this Agreement. and your experience with the Content provided by a new provider may not duplicate your experience with the previous Content supplier.

Export Control. You agree not to export from anywhere any part of the Content or any direct product thereof except in compliance with and with all licenses and

Legal Compliance. You represent and warrant that (i) you are not located in a country that is subject to a U.S. Government embargo. or has been designated by the U.S. Government as a "terrorist supporting" country. and (ii) you are not listed on any U.S. Government list of prohibited or restricted parties.

Indemnity. You agree to indemnify. defend and hold the Navigation provider and its licensors. including the respective licensors. service providers. channel partners. suppliers. assignees. subsidiaries. affiliated companies. and the respective officers. directors. employees. shareholders. agents and representatives of the Navigation Provider and its licensors. free and harmless from and against any liability. loss. injury (including injuries resulting in death). demand. action. cost. expense. or claim of any kind or character. including but not limited to attorney's fees. arising out of or in connection with any use or possession by you of the Navigation Provider Products.

Map Data. Use of the Map Data is subject to certain restrictions and/or requirements imposed by third party suppliers and/or governmental or regulatory authorities. and in the case of HERE Data. as further set forth at http://corporate.navteq.com/ supplierterms.html.

Term. This Agreement is effective until such time as (i) if applicable. your subscription term is either terminated (by you or by the Navigation Provider) or expires. or (ii) Navigation Provider terminates this Agreement for any reason. including. but not limited to. if the Navigation Provider finds that you have violated any of the terms of this Agreement. In addition. this Agreement shall terminate immediately upon the termination of an agreement between the Navigation Provider and any third party from whom the Navigation Provider (a) obtains services or distribution necessary to support the Navigation Provider Products. or (b) licenses Content.

You agree. upon termination. to destroy all copies of the Content. The Disclaimers of Warranty and Liability set out above shall continue in force even after any termination.

Reference Information

Entire Agreement. These terms and conditions constitute the entire agreement between the Navigation Provider and its licensors. including the licensors. service providers. channel partners. suppliers and affiliated companies of the Navigation Provider and its licensors. and you pertaining to the subject matter hereof. and supersedes in their entirety any and all written or oral agreements previously existing between us with respect to such subject matter.

Governing Law.

(a) For European Union HERE Data

The above terms and conditions shall be governed by the laws of the Netherlands. without giving effect to (i) its conflict of laws provisions. or (ii) the United Nations Convention for Contracts for the International Sale of Goods. which is explicitly excluded. You agree to submit to the jurisdiction of the Netherlands for any and all disputes. claims and actions arising from or in connection with the HERE Data provided to you hereunder.

(b) For North American HERE Data and other non-European Union HERE Data

The above terms and conditions shall be governed by the laws of Illinois. without giving effect to (i) its conflict of laws provisions. or (ii) the United Nations Convention for Contracts for the International Sale of Goods. which is explicitly excluded. You agree to submit to the jurisdiction of Illinois for any and all disputes. claims and actions arising from or in connection with the HERE Data provided to you hereunder.

(c) For disputes. claims and actions not related to the HERE Data

The above terms and conditions shall be governed by the laws of Kansas. without giving effect to (i) its conflict of laws provisions. or (ii) the United Nations Convention for Contracts for the International Sale of Goods. which is explicitly excluded. You agree to submit to the jurisdiction of Kansas for any and all disputes. claims and actions arising from or in connection with the Application or Content. Any translation of this Agreement

Map Data Government End Users. If End User is an agency. department. or other entity of the United States Government. or funded in whole or in part by the U.S.

Government. then use. duplication. reproduction. release. modification. disclosure or transfer of the Map Data is subject to restrictions as set forth in DFARS 252.227-7014(a)(1) (JUN 1995) (DOD commercial computer software definition).

DFARS 27.7202-1 (DOD policy on commercial computer software). FAR 52.227-19 (JUN 1987) (commercial computer software clause for civilian agencies). DFARS 252.227-7015 (NOV 1995) (DOD technical data - commercial items clause); FAR 52.227-14 Alternates I. II. and III (JUN 1987) (civilian agency technical data and noncommercial computer software clause); and/or FAR 12.211 and FAR 12.212 (commercial item acquisitions). as applicable. In case of conflict between

Reference Information

HERE is a trademark in the U.S. and other countries. All other company names and trademarks mentioned or referenced in this documentation are the properties of their respective owners. All rights reserved.

Quick Reference Guide

Navigation—Changing Route or Destination You can alter your route by adding waypoints to visit. or changing your destination during route guidance.

Adding a Waypoint (“Pit Stop”) You can add waypoints along your route. (P90)

Changing Your Destination There are several methods you can use to specify a new destination during route guidance.

 Searching nearby hospitals. police stations. gas stations. or tow services (P95) Select the vehicle icon and select an option.

 Selecting an icon on the map (P94) Select a place/landmark icon or a new area on the map twice.

 Entering a new destination (P97) Select Where To? and then enter a new destination.

Canceling Your Route

Alternatively. you can say “Navigation” and then “Stop route” from any screen.

Voice Commands

Voice Commands

Navigation Commands

The system only accepts these commands on a map/guidance screen.

Navigation

Show Map Go Home Find Place Find Address Find City Find Intersection Saved Places Recent Places Stop Route Detour

Back Next Previous Cancel

■ Voice Portal Commands

■ Navigation Commands

■ Other Commands

No Go

Start New Route Add to Active Route Change Country Along Route Near Destination Near Current Location

Restaurants Everyday Life Banks & ATMs Rest Areas Attractions Medical Care Shopping Gas Stations Parking

■ Line Number Commands

■ Category Commands

Art & Entertainment Recreation Transit Lodging

All Restaurants Browse By Style Barbecue Coffee and Tea Delis Donuts and Baked Goods Fast Food Fish and Seafood Grills Pizza Steakhouses Wine. Beer. and Liquor

All Everyday Life Auto Services Car Washes Colleges and Universities Community Services Convenience Store Fitness and Gyms Laundry Services Libraries

■ Sub Category Commands

Voice Commands

Places of Worship Post Offices Schools Veterinary Clinics

All Attractions Amusement Parks Event Centers Historical Landmarks Museums and Galleries Offbeat Places Parks and Gardens Tourist Information Wineries and Breweries Zoos and Aquariums

All Medical Care Hospitals Doctor Offices Pharmacies

All Shopping Books. Music. and Movies Clothing and Accessories Computers and Electronics Convenience Store Department Stores Florists and Gifts Grocery Stores Home and Garden Housewares Office Supply and Shipping Pharmacies Shopping Centers Sporting Goods Wine. Beer. and Liquor

All Art & Entertainment Bars and Pubs Casinos Movie Theaters Museums and Galleries Nightclubs Performing Arts

All Recreation Amusement Parks Bowling Center Camps and Retreats Golfing Skiing and Winter Sports Sport Centers Stadiums and Tracks

All Transit Airports Bus Stations Car Rental Ferry Terminals Transit Service Truck Stops Train Stations Travel Agents

All Lodging Bed and Breakfast or Inn Campground or RV Park Hotel or Motel

Voice Commands

List of Categories

Restaurants Everyday Life Recreation Barbecue Fish and Seafood Auto Services Laundry Services Amusement Parks Skiing and Winter Sports Coffee and Tea Grills Car Washes Libraries Bowling Center Sport Centers Delis Pizza Colleges and Universities Places of Worship Camps and Retreats Stadiums and Tracks Donuts and Baked Goods Steakhouses Community Services Post Offices Golfing Fast Food Wine. Beer. and Liquor Convenience Store Schools Medical Care Shopping Fitness and Gyms Veterinary Clinics Doctor Offices Pharmacies Books. Music. and Movies Home and Garden Art & Entertainment Hospitals Clothing and Accessories Housewares Bars and Pubs Museums and Galleries Transit Computers and Electronics Office Supply and Shipping Casinos Nightclubs Airports Train Stations Convenience Stores Pharmacies Movie Theatres Performing Arts Bus Stations Transit Service Department Stores Shopping Centers Attractions Car Rental Travel Agents Florists and Gifts Sporting Goods Major Attractions Offbeat Places Ferry Terminals Truck Stops Grocery Stores Wine. Beer. and Liquor Amusement Parks Parks and Gardens Gas Stations Lodging Event Centers Tourist Information Banks & ATMs Bed and Breakfast or Inn Hotel or Motel Historical Landmarks Wineries and Breweries Parking Campground or RV Park Museums and Galleries Zoos and Aquariums Rest Areas

Index

Index

Index Symbols

Numbers

D Map. 35

About. 50 Adding Waypoints. 90 Avoidances. 42

Calculating the Route .. 72 Calculation Mode 41 Cancel Route. 10 Categories List of Categories 120 Changing Your Destination. 94 Changing Your Route .. 88 Custom Avoidances 43 Customer Assistance .. 108

Data Reset 51 Detour 89 Display Mode Settings .. 30 Driving to Your Destination. 75

Editing the Route 91 Entering a Destination. 54 Categories. 67 Map Input. 71 myTrends .. 70 myTrips .. 69 Recents .. 68 Saved .. 68 Search Tools. 60 Entering a New Destination. 97

Go Home. 8 Guidance Volume Settings. 32

Home Location. 18 HOME Screen 3 Honda Customer Service .. 108

Legal Information 110 Location History .. 49

Map and Vehicle. 33 Map Coverage 109 Map Layer 37 Map Legend .. 6 Map Operation. 82 Map Screen. 75 Icon. 6 Map Theme. 36 Map Tools 83 Map View. 35 myMaps. 38 myTrips Creating. 26 Deleting. 29 Editing 27

Navigation .. 40 North Up .. 35

Index

Off-Road Breadcrumbs. 79

Personal Information. 18 Predicted Destination 70

Satellite Status .. 47 Saved Locations 19 Deleting .. 24. 25 Editing. 22 Saving. 19 Setting About .. 50 Data Reset. 51 Display Mode Settings. 30 Guidance Volume .. 32 Location History .. 49 Map and Vehicle. 33 Navigation. 40 Personal Information. 18 Traffic .. 48 Start-up. 16 Stopping the Route 88 System Limitations 106

Track Up 35 Traffic Setting 48 Traffic Information 80 Troubleshooting 12. 100

Update System Software Map Updates .. 39 Obtaining Update Data 108

Vehicle Selection. 34 Voice Commands Basic Operation. 5 Voice Commands List 118 Voice Control System .. 17 Voice Control Operation. 11 Voice Recognition .. 17

+ 2022 Honda Motor Co. Ltd. — All Rights Reserved Printed in the U.S.A.

THR850 NM-18583 X31-THR-8500

2023 Honda Odyssey Navigation Manual

Quick Reference Guide

Voice Control Operation

Voice Portal Screen

 The system beeps when ready for a command. Press the button to cancel.

 The audio system is muted during voice control mode.

 You can use other voice commands on the Voice Portal screen.

 Carefully read the usage note for the voice control.

Voice Control System (P17)

 The system recognizes only certain commands.

Available navigation commands (P118)

Voice Command Screen

 You do not need to press the button again in the Voice Command screen.

 Available voice commands are highlighted on the screen.

Quick Reference Guide

Troubleshooting For more Information (P99)

Why does the vehicle position icon on the map appear slightly off my actual position. especially at intersections?

This is normal. The navigation system is unaware of the width of intersections. Large differences in vehicle position can indicate a temporary loss of the GPS signal.

Why does the “Arrival time” display sometimes increase even though I am getting closer to my destination?

The “Arrival time” is based on the speed limit on each road. Depending on the traffic conditions. the “Arrival time” may be calculated to be earlier or later.

Why does my clock frequently change the time forward and backward by one hour?

The clock setting is automatically updated based on your GPS location. If you are driving near a time zone border. the automatic update likely is the reason.

How do I turn on the navigation system voice guidance?

● Press the icon.

Select Navigation > > Guidance Volume.

Turn up the volume if it is low.

● Adjust the volume using the volume knob during the voice guidance.

How do I specify a destination when an entered city or street could not be found?

Try selecting the destination directly from the map.

How to Use This Manual This section explains different methods on how you can easily find information in this manual.*

Searching the Table of Contents

(P1)

First. find the general chapter related to what you are looking for (e.g. entering a destination from the Saved Places).

Then. go to that chapter to view a more specific table of contents.

Searching the Index (P121)

This more detailed table of contents shows you exactly what information is listed by section and title.

The Index consists of main terms and sub entries. The sub-entries help you get to the desired page depending on what you are looking for.

Table of Contents Chapter Contents

Navigation Screen Index

Two types of Tables of Contents help you find your desired information.

Menu items displayed on the navigation screen (e.g. Saved) can be found individually in the Index.

More Detailed Contents

Go to the Next Page

+ Sample pages and images in this section may differ from the actual ones.

Navigation

Saved

Select a saved location to use as the destination.

1. Select your destination from the list.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

Recents

Select an address from a list of your 50 most recent destinations to use as the destination The list is displayed with the most recent destination at the top

1 Saved

You can add. edit. or delete the saved place.

2 Saved Locations P. 19

Using Voice Command You can utilize a saved place by using voice commands.

From the Voice Portal screen. say “Navigation.” Say “Saved Places” on the voice command screen. then say a saved place (e.g.. “Honda”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

1 Recents

Select the item on the system control panel.

Menu Tree

The menu tree helps guide you through the system’s menu options.

To get to your desired function. follow the menu tree in order of the steps shown.

Select the menu option.

After following the menu tree. step-by-step instructions explain how to achieve the desired result.

Select Saved.

Saved Navigation

System Setup

This section describes the start-up procedure and the navigation and setup functions.

Start-up .16 Voice Control System 17 Voice Recognition ..17 Personal Information .18 Setting Home Location .18 Saved Locations ..19 Saved Trips 26 Display Mode Settings .30 Switching Display Mode Manually ..30 Guidance Volume Settings .32 Map and Vehicle ..33 Vehicle Selection .34 Driving Map View (Map Orientation) .35 Map Theme ..36 Map Layer ..37

System Setup

Start-up

The navigation system starts automatically when you set the power mode to ACCESSORY or ON. At start-up. the following confirmation screen is displayed.

1. Select OK.

Certain manual functions are disabled or inoperable while the vehicle is in motion.

You cannot select a grayed-out option until the vehicle is stopped.

Voice commands are still operable while the vehicle is in motion.

1 Start-up

Avoid focusing on the screen and drive safely.

When you use the navigation system. the system may close other apps.

■ Limitations for Manual Operation

System Setup

Voice Control System

Your vehicle has a voice control system that allows hands-free operation of the navigation system functions.

The voice control system uses the and buttons on the steering wheel and a microphone near the map lights on the ceiling.

For details of the button. button and microphone position. see the Owner's Manual.

Voice Recognition

To achieve optimum voice recognition when using the navigation voice control system:

• Make sure the correct screen is displayed for the voice command that you are using. The system recognizes only certain commands.

Available navigation commands: 2 Voice Commands P. 118

• Close the windows and moonroof.

• Adjust the dashboard and side vents so air does not blow onto the microphone on the ceiling.

• Speak in a clear. natural speaking voice without pausing between words.

• Reduce any background noise if possible. The system may misinterpret your command if more than one person is speaking at the same time.

1 Voice Control System

When you press the button. the system prompts you to say a voice command. Press and release the button again to bypass this prompt and give a command.

1 Voice Recognition

The voice control system can only be used from the driver’s seat because the microphone unit removes noises from the front passenger’s side.

System Setup

Personal Information

Setting Home Location

Use the personal information menu to set your home location.

1. Select Set Home Location.

2. Select an option.

The following options are available:

• Enter My Address: Sets the home location by entering the address.

2 Storing Your Home Address P. 8

• Use Current Location: Sets your current location as your home location.

• Recently Found: Sets the home location from a recently found location.

• Saved Place: Sets the home location from a saved place.

1 Personal Information

The home location can be overwritten. Select Change Home Location in step 1.

Continued

System Setup

Saved Locations

You can save locations so you can quickly find them and create routes to them.

1. Select a search method.

3. Select Save.

4. Enter a name and select Done.

■ Saving a Location

System Setup

1. Select a destination from the map.

2 Map Input P. 71 2. Select the destination name at the bottom of the map.

3. Select Save.

4. Enter the place name and select Done.

■ Saving a Location Manually

Continued

System Setup

1. Select the vehicle icon.

2. Select Save.

3. Enter a name of the location.

4. Select Done.

■ Saving Your Current Location 1 Saving Your Current Location

Vehicle position may not be displayed when:

• The vehicle is traveling off-road.

• The vehicle position data cannot be updated.

Continued

System Setup

5. Select an option.

The following options are available:

• Name: Enters a new name for the location.

• Phone Number: Enters a phone number.

• Map Symbol: Select a symbol.

System Setup

1. Select

2. Select Delete Saved Places.

3. Select a saved location you want to delete. u Select Select All to delete all saved locations.

4. Select Delete.

5. Select Delete.

■ Deleting Saved Locations

System Setup

Saved Trips

You can use myTrips feature to create and save a route with multiple destinations.

1. Select a method to enter a new destination.

2 Entering a Destination P. 54 2. Select Select if necessary.

3. Select Add Destinations to add additional locations. u Repeat steps 1 and 2 to enter the destination.

■ Creating Your Trip

Continued

System Setup

1. Select a saved trip you want to edit.

2. Select Trip Settings.

3. Select an option.

The following options are available:

• Trip Name: Enters a new name for the saved trip.

• Optimize Order: Automatically orders the waypoints in the destination list.

• Calculation Mode: Changes the route preferences (calculating method).

• Avoidances: Changes preferences for route options to avoid.

■ Editing a Saved Trip 1 Editing a Saved Trip

The route preference is just for the trip. If you want to change the route preference for routing. change the navigation settings.

2 Calculation Mode P. 41 2 Avoidances P. 42

System Setup

■ Reordering Destinations 1. Select a trip from myTrips list.

2. Select Edit Destinations.

3. Select and hold or and then move the destination to the desired position. u Select Add Destinations to add a new location.

5. Select the location to delete.

System Setup

Display Mode Settings

Switching Display Mode Manually

Set the screen brightness separately for Day and Night modes. Press the icon to cycle through the display modes (Day to Night to Off).

Press the icon.

1 Switching Display Mode Manually

You can also adjust the display brightness by sliding or swiping on the brightness bar.

You can change the touchscreen sensitivity setting.

2 Refer to the Owner’s Manual.

System Setup

Illumination control Operation

Sunlight sensor* (see your Owner’s Manual for location)

If the sunlight sensor detects daylight and the headlights are turned on. the system automatically overrides the Night display and displays the Day display mode.

Remember: If desired. use the icon to override this automatic choice.

Dash illumination adjustment knob (see your Owner’s Manual for location)

When the headlights are turned on. and you wish to have the Day display mode. adjust the illumination to the full brightness (beeps).

Remember: Adjust the dash brightness back to midrange to allow auto switching by sensing the headlights are on or off.

Headlights (Auto*/On/Off) When turned on. the display changes to Night display mode.

The previous three controls listed above can “cancel” this function.

Remember: Use the icon. to adjust the dash illumination to full brightness. or set the display to your desired choice.

+ Not available on all models

System Setup

Guidance Volume Settings

Adjust the navigation system volume level.

Select or to adjust the guidance volume. u Select Mute to mute the guidance.

1 Guidance Volume Settings

You can also adjust the volume by sliding or swiping on the volume bar.

This option is accessible on any screen that includes the options menu icon.

Select to open the options menu. and then select Guidance Volume.

During the voice guidance. you can adjust the guidance volume using the volume knob.

System Setup

Map and Vehicle

Change the map settings.

Select an option.

The following options are available:

• Vehicle Selection: Changes the icon to represent your position on the map.

2 Vehicle Selection P. 34

• Driving Map View: Sets the perspective on the map.

2 Driving Map View (Map Orientation) P. 35

• Map Theme: Changes the color of the map data.

2 Map Theme P. 36

• Map Layer: Sets the data that appears on the map.

2 Map Layer P. 37

• myMaps: View installed maps the system uses.

2 myMaps P. 38

• Map Updates: View the instructions for map updates.

2 Map Updates P. 39

System Setup

Vehicle Selection

You can choose your vehicle icon.

1. Select or to choose the desired icon.

2. Select Save.

1 Vehicle Selection

The factory default is set to 1 of 7.

System Setup

Driving Map View (Map Orientation)

Select the map orientation.

1. Select an option.

2. Select Save.

The following options are available:

• 3D (factory default): Displays the map in 3D with your direction of travel facing upwards.

• Track Up: Displays the map with your direction of travel facing upwards.

• North Up: Displays the map with north always pointing up.

System Setup

Map Layer

Sets the data that appears on the map screen.

1. Select an option(s).

2. Select Save.

1 Map Layer

Off-Road Breadcrumbs is set to off as factory default.

You can set the categories of places appear along the road on the map screen.

Select beside Places along the road. select the categories to show. and then select Save.

System Setup

Map Updates

Start the map update process.

Follow the on-screen instructions.

1 Map Updates

For information on navigation updates for your vehicle. please visit:

• U.S.: hondanavi.navigation.com

• Canada: www.honda.ca/owners/honda-services/ navigation 2 Obtaining a Navigation Update P. 108

System Setup

Navigation

Changes the navigation settings.

The following options are available:

• Calculation Mode: Sets route preference.

2 Calculation Mode P. 41

• Avoidances: Sets road features to avoid on a route.

2 Avoidances P. 42

• Custom Avoidances: Allows you to avoid specific roads or areas.

2 Custom Avoidances P. 43

• Satellite Status: Displays the satellite status.

2 Satellite Status P. 47

• GPS Simulator: Stops the system from receiving a GPS signal.

1 Navigation

GPS Simulator is set to off as factory default.

You can access the navigation settings from any screen includes the options menu icon.

Select to open the options menu. and then select Navigation Settings.

System Setup

Calculation Mode

Sets the route preference.

1. Select an option.

2. Select Save.

The following options are available:

• Faster Time (factory default): Calculates routes that are faster to drive but can be longer in distance.

• Shorter Distance: Calculates routes that are shorter in distance but can take more time to drive.

• Less Fuel: Calculates routes that could use less fuel than other routes.

System Setup

Avoidances

Set preferences for route options to avoid.

1. Select an option(s).

2. Select Save.

The following options are available:

• U-Turns: Avoids u-turns.

• Highways: Avoids highways.

• Tolls and Fees: Avoids toll roads.

• Ferries: Avoids ferries.

• Carpool Lanes: Avoids car share lanes.

• Unpaved Roads: Avoids unpaved roads.

• Custom Avoidances: Avoids specific areas and roads.

2 Custom Avoidances P. 43

1 Avoidances

Highways. Tolls and Fees. and Ferries are set to off as factory default.

Continued

System Setup

Custom Avoidances

Allows you to avoid specific areas and sections of road. You can enable and disable custom avoidances as needed.

1. Select Add Avoidance.

2. Select an option.

The following options are available:

• Avoid Area: Sets an area to avoid.

2 Adding an Avoid Area P. 44

• Avoid Road: Sets a road to avoid.

2 Adding an Avoid Road P. 45

Continued

System Setup

1. Select the starting point of the section of road to avoid. Select Next. u The icon is displayed on the map.

2. Select the ending point of the road section. Select Next.

3. Select Done.

■ Adding an Avoid Road

System Setup

1. Select the area or road to edit from the list.

2. Select an item.

The following items are available:

• Enable: Sets whether to enable the avoidance.

• Rename: Enters a new name.

• Delete: Deletes a selected area or road.

■ Editing a Custom Avoidance

System Setup

Traffic

Sets the traffic feature.

Select an option.

The following options are available:

• Traffic: Enables the traffic feature.

2 Traffic Information P. 80

• Traffic Alert: Sets whether to receive an alert when traffic may cause a delay.

• Automatic Route Optimization: Sets whether to use optimized alternate routes.

• Current Provider: Sets the traffic provider to use for traffic data.

• Subscriptions: Displays the lists of the current traffic subscriptions.

System Setup

Location History

Set the history data usage or clear the travel data.

Select an option.

The following options are available:

• Travel Data Recording: Allows the system to record your travel data used for predictions.

• Predicted Destination Alert: Sets whether the system provides the predicted destination.

2 Predicted Destination P. 70

• Remove All myTrendsTM Places: Deletes all myTrends places.

• Clear Off-Road Breadcrumbs: Clears off-road breadcrumbs appear on the map.

System Setup

About

Select an option.

The following options are available:

• System Information: Displays the system information.

• EULAs: Displays end-user license agreements.

• Copyright and Acknowledgments: Displays copyright and acknowledgments information.

• Restore Navigation Settings: Restores navigation settings to the factory defaults.

2 Reset Factory Default Settings P. 51

System Setup

Data Reset

Reset Factory Default Settings

You can restore all settings to the factory default values.

1. Select Restore Navigation Settings.

2. Select Restore.

1 Reset Factory Default Settings

When you want to reset the following options. see the below references:

• Home 2 Deleting Saved Locations P. 25

• Saved 2 Deleting Saved Locations P. 25

• Recents 2 Recents P. 68

• myTrips 2 Deleting Saved Trips P. 29

When you transfer the vehicle to a third party. reset all settings to default and delete all personal data.

Navigation

This section describes how to enter a destination. select a route to take. and follow the

Entering a Destination .54 Search Tools .60 Categories .67 Saved 68 Recents 68 myTrips 69 myTrendsTM 70 Map Input ..71 Calculating the Route 72 Viewing and Selecting the Routes ..73 Viewing the Location Information ..74 Driving to Your Destination .75 Viewing the Route .75 Traffic Information .80

Map Operation. 82 Map Tools. 83 Changing Your Route .. 88 Stopping the Route .. 88 Taking a Detour. 89 Adding Waypoints 90 Editing the Route .. 91 Changing Your Destination. 94 Selecting a Destination on the Map .. 94 Searching Near Establishment. 95 Entering a New Destination .. 97

Navigation

Entering a Destination

This section describes how to enter a destination for route guidance.

Select an option.

The following options are available:

• Keyword or Address. State: Sets a destination by entering a keyword. address or state name.

2 Using the Search Bar P. 56

• Searching near: Selects the city to search near.

2 Changing the Search Area P. 57

• Go Home: Sets your home address as the destination.

2 Going Home P. 8

• Search Tools: Sets a destination by searching for a place.

2 Search Tools P. 60

• Saved: Sets a destination by selecting a place stored in the Saved list.

2 Saved P. 68

• Recents: Sets a destination by selecting a previous destination.

2 Recents P. 68

• Categories: Sets a destination by selecting a category.

2 Categories P. 67

• myTrips: Sets a destination by selecting a saved route.

2 myTrips P. 69

1 Entering a Destination

The Display Audio system can only provide route guidance from one navigation system at a time.

When setting a destination on one system. any active route guidance with the other system is canceled. and the system you are currently using will direct you to your destination.

If you press the button on the steering wheel. select Navigation and then press the ENTER button. the following items are available. Use the steering wheel buttons to select the items.

• Go Home

• Saved

• Recent When en route. the following item is available.

• Cancel Route

Button

Continued

Navigation

• myTrendsTM: Sets a destination by selecting a place in the list of frequently-visited destinations.

2 myTrendsTM P. 70

• Add Shortcut: Adds shortcuts to the Where To? menu.

2 Adding Shortcuts P. 58

Navigation

You can use the search bar to search for locations by entering a keyword. address. or state name.

1. Enter a search term.

■ Using the Search Bar 1 Using the Search Bar

Using Voice Command You can say the names of popular. well-known locations.

From the Voice Portal screen. say “Navigation.” Say “Find Place. then say a place name (e.g.. “Honda”).

Say the line number of screen (e.g.. “1”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

• To search for a type of business. enter a category name. such as “movie theaters.”

• To search for a business by name. enter all or part of the name.

• To search for an address near you. enter the street number and street name.

• To search for an address in another city. enter the street number. street name. city. and state.

• To search for a city. enter the city and state.

If you want to delete the search history. reset the navigation settings to default.

2 Reset Factory Default Settings P. 51

You can change the order of search results.

Select and then select Sort POI Results.

Continued

Navigation

By default. your system finds locations closest to your current location. You can find a location near another city or location.

Select an option.

The following options are available:

• My Active Route: Searches along your current route.

• My Destination: Searches near your current destination.

• My Current Location: Searches near your current location.

• A Different City: Searches near the city you select.

• Recent Places: Searches near a recent destination.

• Saved Places: Searches near a saved place.

■ Changing the Search Area 1 Changing the Search Area

My Active Route and My Destination can be set when the route is active.

Navigation

Search Tools

Find a location to set as the destination by searching for an address. intersection. city. dealership. coordinates or phone number.

Select an option.

The following options are available:

• Address: Sets a destination by entering an address.

2 Finding an Address P. 61

• Intersections: Sets a destination by finding an intersection.

2 Finding a Location by Intersections P. 62

• Cities: Sets a nearby city as the destination.

2 Finding a City P. 63

• Dealerships: Sets a nearby authorized Honda dealer as the destination.

2 Finding a Dealership P. 64

• Coordinates: Sets a destination by entering coordinates.

2 Finding a Location Using Coordinates P. 65

• Phone Number: Sets a destination by entering a phone number.

2 Finding a Location by Phone Number P. 66

Continued

Navigation

Enter an address to use as the destination.

1. Enter the house number and street name. u Select Searching near if you want to search different city.

2. Select Done or a suggestion.

3. Select your destination from the list.

4. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

■ Finding an Address 1 Finding an Address

Using Voice Command You can say the entire address at once using voice commands.

From the Voice Portal screen. say “Navigation.” Say “Find Address” on the voice command screen. then say the entire address (e.g. “1-2-3-4 Main Street. Los Angeles. California”).

Say “Change Country” if you want to change the country.

The system interprets the address.

Say “Yes” or a line number of a screen if the destination list appears (e.g.. “1”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

The order of the steps may change depending on the map data loaded on your system.

Navigation

Select the intersection of two streets as the destination.

1. Enter two street names.

■ Finding a Location by Intersections 1 Finding a Location by Intersections

Using Voice Command You can find intersections by the street name using voice commands.

From the Voice Portal screen. say “Navigation.” Say “Find Intersection” on the voice command screen and then say a city name.

Say a street name 1. then say a line number of a screen (e.g.. “1”).

Say a street name 2. then say a line number of a screen (e.g.. “1”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

Navigation

Find any authorized Honda dealers to set as a destination.

1. Select the desired name from the list. u Select the search bar and enter a dealership name to narrow down the number of matches.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

■ Finding a Dealership

Continued

Navigation

You can find a location using latitude and longitude coordinates. This can be helpful when geocaching.

1. Select Change.

2. Select the latitude coordinate and enter the new coordinate. u Select N/S if necessary.

3. Select the longitude coordinate and enter the new coordinate. u Select E/W if necessary.

4. Select Done.

5. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

■ Finding a Location Using Coordinates 1 Finding a Location Using Coordinates

If you want to change the coordinate format. select and then select Coordinate Format.

You can add the coordinates location to the saved location list by selecting Save.

Navigation

Search for your destination by entering a phone number.

1. Enter the phone number.

3. Select your destination from the list.

4. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

■ Finding a Location by Phone Number

Navigation

Categories

Select the category of a place (e.g. Restaurants. Gas Stations. Shopping) stored in the map database to search for the destination.

1. Select a category.

2. Select a subcategory.

3. Select a place name from the list.

4. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

■ Finding a Location by Category

1 Categories

This option is convenient if you do not know the exact name of a place or if you want to narrow down the number of matches returned for places with a common name.

Navigation

Saved

Select a saved location to use as the destination.

1. Select your destination from the list.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

Recents

Select a location from a list of your 50 most recent destinations to use as the destination. The list is displayed with the most recent destination at the top.

1. Select your destination from the list.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

1 Saved

You can add. edit. or delete the saved place.

2 Saved Locations P. 19

Using Voice Command You can utilize a saved place by using voice commands.

From the Voice Portal screen. say “Navigation.” Say “Saved Places” on the voice command screen. then say a saved place (e.g.. “Honda”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

1 Recents

You can delete a recent destination. Select a destination to delete. select and then select Delete.

If you want to delete all recent destinations. select without selecting any destination in the list. and then select Clear All Recent Places.

Using Voice Command You can utilize a recent destination by using voice commands.

From the Voice Portal screen. say “Navigation.” Say “Recent Places” on the voice command screen. then say a line number of a screen (e.g.. “1”).

Say “Go” to set the route.

2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

Navigation

Set the route to your destination selecting a saved trip.

1. Select a trip.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

1 myTrips

You can create. edit. or delete trips.

2 Saved Trips P. 26

Navigation

Select a frequently-visited place to use as the destination.

1. Select your destination from the list.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

When you start the vehicle. the system predicts the most-likely destination based on your travel data. It displays the notification window to offer the destination and show related information.

Select Go! to accept the predicted destination.

1 myTrendsTM

Set Travel Data Recording to On to use myTrends feature.

2 Location History P. 49

You can delete myTrends location. Select the location to remove. select and then select Remove.

To delete all myTrends locations. select without selecting any location and then select Remove All in the myTrends list screen.

■ Predicted Destination 1 Predicted Destination

To use this feature. set Predicted Destination Alert to On.

2 Location History P. 49

The notification will be queued in the queue indicator after a certain period of time. Select the indicator to display the predicted destination.

Navigation

Map Input

Scroll the map to manually select an icon or a location as the destination.

1. Tap on the map screen and then select any point on the map. a street. intersection. or category icon. u Return to the current location when you select or press the icon.

2. Select Go! to set the route to your destination.

2 Calculating the Route P. 72

1 Map Input

“Show Map” 2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

You can customize the map as you like using or

2 Map Operation P. 82

Navigation

Calculating the Route

This section describes how to calculate your route.

Select Go!. u The system calculates and displays the route line on the map screen.

The following options are available:

• Explore This Venue: Displays a list of all POIs within the venue.

This option is available for some multiple facilities. such as hospitals or shopping centers.

• Routes: Displays different routes.

2 Viewing and Selecting the Routes P. 73

• Info: Displays detailed location information.

2 Viewing the Location Information P. 74

1 Calculating the Route

If the route is very long. the system will calculate the route to the first guidance point and start the guidance. The system will then continue calculation to final destination as you proceed.

Select to view the map with the location centered.

Navigation

Viewing and Selecting the Routes

View and select different routes to your destination.

1. Select your desired route.

Navigation

Viewing the Location Information

1. Select an option.

2. Select Go!.

The following options are available:

• Save: Adds the destination to the saved location list.

2 Saved Locations P. 19

• Set Location: Sets the vehicle position when you are indoors or not receiving satellite signals.

You can use this feature when GPS Simulator is set to on.

2 Navigation P. 40

• Routes: Displays different routes to the destination.

2 Viewing and Selecting the Routes P. 73

• Routes Settings: Changes the route preferences.

2 Navigation P. 40

Continued

Navigation

Driving to Your Destination

Viewing the Route

This section describes how to follow the route guidance to your destination.

After calculating the route to your destination. the route is displayed on the map screen.

2 During Route Guidance P. 7 As you drive. the system tracks your position on the map in real time and provides guidance as you approach each guidance point on the route.

The following options are available:

• Select the next guidance indicator to replay the voice guidance for the next maneuver.

• Select the text bar on the top of the map to display the turn list screen.

2 Turn List Screen P. 77

• Select the queue indicator to display queued notifications.

2 Alert and Notification Banners P. 78

• Select to display the map tools window.

2 Map Tools P. 83

• Select to cancel the route guidance and remove your current route.

2 Canceling Your Route P. 10

■ Map Screen

1 Viewing the Route

When your phone is connected to Bluetooth® HandsFreeLink®. the navigation screen will switch to the incoming call screen when receiving a call.

Select the vehicle icon to view the Where Am I? screen.

2 Viewing the Current Location Information P. 87

You can stop your vehicle en route (e.g. to rest. stop for gas. etc.). and then continue on your route.

If you did not complete your route. the navigation restarts when you restart your vehicle.

This will occur once the Disclaimer screen clears.

The next guidance indicator does not appear in the following cases.

• The vehicle speed is 3 mph (4.8 km/h) or less

• The GPS signal is weak

• The vehicle position on the map and current vehicle position do not match

Next guidance indicator

Dashboards

Queue indicator

Navigation

• Select the map dashboards when you want to change the information that is displayed. Select the following options: Elevation. Direction. Location. Arrival. Distance. Arrive In. Via Arrival. Via Distance. Via In.

The intersection view screen displays a view of the upcoming intersection and which lane you should be driving.

■ Intersection View Screen

1 Viewing the Route

Turn-by-Turn Directions The next guidance point appears on the Driver Information Interface.

The Turn-by-Turn directions may not be displayed if the information cannot be received correctly.

Continued

Navigation

The turn list screen displays turn-by-turn instructions and the distance between turns.

1. Select the text bar on the top of the map.

2. Select a turn to display on the map.

The full route screen displays the entire route and current vehicle position.

1. Select the text bar on the top of the map.

2. Select

3. Select View Full Route.

■ Turn List Screen 1 Turn List Screen

When you are on the multi-destination route. the list is separated for each route leg. You can skip from the current route leg to another route leg by selecting Go! displayed on the top of each route leg.

■ Full Route Screen

Navigation

The slide-in banner appears on the top of the map screen when the system provides an alert or notification.

■ School Zone Proximity Alert A proximity alert for school zone is displayed when the system receives the information.

Select the banner to display the distance to the alert point. speed limit. and map preview with the alert point centered.

■ Parking Reminder Notification A parking reminder notification is displayed when you approach your destination.

Select the banner to display the list of parking near the destination.

■ Alert and Notification Banners 1 Alert and Notification Banners

After a certain time of period. the alert or notification is queued in the queue indicator.

You can view the alert or notification again by selecting the queue indicator.

If the notifications center window is displayed. select the notification from the list.

Navigation

If you set the off-road breadcrumbs to show. a series of lines (breadcrumbs) are displayed to track your movement on a off-road.

2 Map Layer P. 37

If you leave the calculated route. the system automatically recalculates a route to the set destination based on your current location and direction.

If your vehicle is off a road segment. the system shows a dotted line indicating the direction back to the calculated route.

■ Off-Road Breadcrumbs Display 1 Off-Road Breadcrumbs Display

You can delete the off-road breadcrumbs.

2 Location History P. 49 2 Reset Factory Default Settings P. 51

■ Deviating From the Planned Route

Navigation

Traffic Information

When you set the traffic feature. the system examines traffic conditions and optimizes the route for the shortest time. If a severe traffic delay occurs while you are navigating. the system searches for a faster route. If it finds one. the system will automatically alter the route and display the reroute notification banner on the map screen.

The system may route you through a traffic delay if a better alternative route does not exist. The delay time is added into your estimated time of arrival automatically.

Select the reroute notification banner to view the saved time and avoided traffic events. u Select Use Original Route to use the original route.

The traffic alert window is displayed on the map screen when traffic may cause a delay.

Select the window to view detailed information and the map.

1 Traffic Information

Continuously updated traffic information is available in major metropolitan areas across the contiguous United States and some cities in Canada.

You can change the traffic information settings.

2 Traffic P. 48

■ Viewing Traffic Alert 1 Viewing Traffic Alert

The notification will be queued in the queue indicator after a certain period of time. Select the indicator to display the notification again.

Navigation

View the traffic flow and delays on nearby roads.

Select the traffic information window to view detailed information and map.

See an overview of the icons and colors used on the traffic map.

The system displays the traffic legend.

■ Viewing Traffic Delays Manually

■ Viewing Traffic Legends

Navigation

Map Operation

Customize the map. set a destination. and save a place from the map.

1. Select any point on the map.

2. Select an option.

Continued

Navigation

Map Tools

Select an option.

The following options are available:

• Detour: Calculates a detour route.

2 Taking a Detour P. 89

• Exit Services: Displays a list of the exit services for the route.

2 Viewing Exit Services P. 84

• Guidance Volume: Adjusts the guidance volume.

2 Guidance Volume Settings P. 32

• Up Ahead: Displays the list of upcoming services along the road where you are travelling.

2 Viewing Services Up Ahead P. 85

• Traffic: Displays traffic information.

2 Traffic Information P. 80

• Where Am I?: Displays the information about your current location.

2 Viewing the Current Location Information P. 87

• Settings: Changes settings for navigation functions.

2 System Setup P. 15

1 Map Tools

You can rearrange the order of menu icons.

Select and hold the icon and move it to the desired position.

Navigation

You can view exit services (e.g. whether the exit is near gas stations. restaurants. etc.) and add new destinations or waypoints to the calculated route.

1. Select an exit.

2. Select a category.

3. Select a service.

4. Select an option.

2 Calculating the Route P. 72 2 Adding Waypoints P. 90

■ Viewing Exit Services

Continued

Navigation

You can view the list of upcoming services along the road where you are travelling.

1. Select a category.

2. Select a service from the list.

3. Select an option.

2 Calculating the Route P. 72 2 Adding Waypoints P. 90

■ Viewing Services Up Ahead 1 Viewing Services Up Ahead

You can change the order of search results.

Select in the service list screen. select Sort POI Results and then select an option.

Navigation

■ Customizing the Up Ahead Categories

You can change the category to display.

1. Select in the service list screen.

2. Select Up Ahead Options.

3. Select the category to change.

4. Select a category to display.

1 Customizing the Up Ahead Categories

You can change the order of categories.

Select and hold or and then move the category to the desired position.

Navigation

You can confirm your current location. address. and nearest intersection.

Select an option.

The following options are available:

• Save: Saves your current location.

2 Saving Your Current Location P. 21

• Hospitals/Police Stations/Gas Stations/Tow Services: Searches for a hospital. police station. gas station or tow service around your current location.

2 Searching Near Establishment P. 95

■ Viewing the Current Location Information 1 Viewing the Current Location Information

Vehicle position may not be displayed when:

• The vehicle is traveling off-road.

• The vehicle position data cannot be updated.

When you deviate from the planned route. the closest route-able road is also displayed.

Navigation

Changing Your Route

Stopping the Route

Stop the route guidance and remove the destination and all waypoints.

1. Select

1 Stopping the Route

“Stop route” 2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

Navigation

Taking a Detour

Calculates a new route to avoid something ahead of you. The system creates a new route if possible. The system attempts to get you back on your original route as quickly as possible.

You can take a detour for a specified distance along your route or detour around specific roads. This is useful if you encounter construction zones. closed roads. or poor road conditions.

Select an option.

The following options are available:

• Skip Next Turn: Calculates a new route by avoiding the next turn on your route.

• 0.5 mi.: Calculates a new route by avoiding the next 0.5 mile on your route.

• 2 mi.: Calculates a new route by avoiding the next 2 miles on your route.

• 5 mi.: Calculates a new route by avoiding the next 5 miles on your route.

■ Taking a Detour Around Specified Areas

1 Taking a Detour

“Detour” 2 Using Voice Commands P. 5 2 Voice Control Operation P. 11

If your current route is the only reasonable option. the system might not calculate a detour.

1 Taking a Detour Around Specified Areas

Skip Next Destination Calculates a new route by skipping the next waypoint.

This option is available when you are in the route with multiple destinations.

Navigation

Adding Waypoints

Add waypoints (pit stops) along the route to your destination.

1. While en route. select a search method to add a new destination or waypoint.

2 Entering a Destination P. 54 2. Select a place. Select Go!.

3. Select Add as Next Stop or Add to Active Route. u Select Add as Next Stop to set the location as your next waypoint. The route is automatically recalculated and displayed on the map screen.

1 Adding Waypoints

When you add a waypoint. the system may take some time to update the arrival time.

Select Start New Route to set the location as your new destination.

Select Add as Last Stop to add the location to the end of your route.

2 Entering a New Destination P. 97

Continued

Navigation

Editing the Route

You can edit destinations on your route and save the route as your favorite trip.

1. Select the text bar on the top of the map.

2. Select

3. Select Edit Destinations.

4. Select and hold or and then move the destination to the desired position. u Select Add Destinations to add a new location.

5. Select

■ Reordering Destinations

Navigation

1. Select the text bar on the top of the map.

2. Select

3. Select Edit Destinations.

4. Select

5. Select Remove Destinations.

6. Select the location to delete.

■ Deleting a Destination

Navigation

You can add the current route to myTrips list.

1. Select the text bar on the top of the map.

2. Select

3. Select Save Route.

4. Enter a name.

5. Select Done.

■ Saving Your Current Route 1 Saving Your Current Route

You can use the saved trip from myTrips screen.

2 myTrips P. 69

You can also save your current route from myTrips screen. Select on the routing map. and then select myTrips. Select Save.

Navigation

Changing Your Destination

Selecting a Destination on the Map

Select a new destination when en route by selecting a location on the map.

1. Select any point on the map. or a street. intersection. or category icon.

2. Select Go!.

3. Select an option.

The following options are available:

• Start New Route: Sets the location as your new destination.

• Add as Next Stop: Sets the location as the next waypoint.

• Add as Last Stop: Adds the location as your last destination.

• Add to Active Route: Sets the location as the waypoint and edits the order of destinations in your route.

2 Adding Waypoints P. 90

Continued

Navigation

Searching Near Establishment

Search for a hospital. police station. gas station or tow service around your current location.

1. Select your vehicle icon.

3. Select a place.

4. Select Go!.

1 Searching Near Establishment

You can also search for nearby establishment by selecting on the map screen and select Where Am I?.

Navigation

5. Select an option.

The following options are available:

• Start New Route: Sets the location as your new destination.

• Add as Next Stop: Sets the location as the next waypoint.

• Add as Last Stop: Adds the location as your last destination.

• Add to Active Route: Sets the location as the waypoint and edits the order of destinations in your route.

2 Adding Waypoints P. 90

Navigation

Entering a New Destination

Enter a new destination using the destination menu screen even when you are en route.

1. Select a search method to enter a new destination.

2 Entering a Destination P. 54 2. Select a place and then select Go!.

3. Select an option.

The following options are available:

• Start New Route: Sets the location as your new destination.

• Add as Next Stop: Sets the location as the next waypoint.

• Add as Last Stop: Adds the location as your last destination.

• Add to Active Route: Sets the location as the waypoint and edits the order of destinations in your route.

2 Adding Waypoints P. 90



Newest Added: 2023 GROM 2022 CBR1000RR-R FIREBLADE SP 2022 CBR650R 2022 CB650R 2023 RUCKUS

Tags: 2019 Honda Metropolitan, Honda Metropolitan 2019, 2019 Honda Metro, Honda Metropilotan, Honda Crf 150 R, Honda Ruckus 2022 User Manual, Honda Trail 125

Honda ODYSSEY 2023 | Pages: 125 | Created on: 2022-01-11 | File type: PDF | Filename: 34308181_odyssey-2023.pdf | Size: 3.03 MB | Language: English | Other documents: 1 files.

Download User Manual

Contact us

T: @manualsFile

https://manualsFile.com
