Save For Future Reference
This vacuum cleaner is a high quality, precision made product. All
parts used in the manufacturing of this vacuum cleaner have passed
rigid quality control standards prior to assembly and an “each unit”
final inspection prior to packaging is your assurance of proper
assembly. This vacuum cleaner was protectively packed to prevent
possible damage in transit. Should damage occur, please notify the
transporting carrier immediately for loss and/or claim.
0RGHO$6%3'
Dry Asbestos Vacuum Cleaner
MOTOR:
The suction head of this vacuum cleaner is equipped with a 2 stage,
11.1 amp, 2HP by-pass motor, developing 105” waterlift and 110
CFM.
When removing the motor head, care in handling is essential.
Dropping, banging or other abuse may result in poor vacuum seal
and a loss in suction power and will invalidate your warranty.
IMPORTANT SAFEGUARDS
EXTENSION CORDS:
Vacuums that have 3 wire cords requiring grounding must only be
used with extension cords that have 3-prong grounding type plugs
and 3-pole receptacles.
To determine the minimum wire size required, refer to the chart
below:
Minimum Wire Size (AWG) of Extension Cord
Nameplate Total Extension Cord Length (Feet)
Rating-Amps 25 50 75 100 125 150 175 200
0-10.0 18 18 16 16 14 14 12 12
10.1-13.0 16 16 14 14 14 12 12 12
13.1-15.0 12 12 12 12 12 12 12 –
Before using an extension cord,inspect it for loose or exposed wires,
damaged insulation and defective fitting.
Operation & Care Instructions
CAUTION
Always disconnect power cable from outlet when working
on this vacuum.
