EN
www.tefal.com
IT84XX
IMPORTANT SAFETY
INSTRUCTIONS
• When using your appliance, basic precautions should
always be followed, including the following:
• Read all instructions before using this appliance.
• This appliance has been designed for indoor, domestic
use only. Any commercial use, inappropriate use or failure
to comply with the instructions, the manufacturer accepts
no responsibility and the guarantee will not apply.
• Always plug your appliance:
- into a mains circuit with voltage between 220 V and
240V.
- into an earthed electrical socket.
Connecting to the wrong voltage may cause irreparable
damage to the appliance and will invalidate your
guarantee.
Do not use an extension lead. If you accept liability for
doing so, only use an extension lead which is in good
condition, has a plug with an earth connection and is
suited to the power rating of the appliance.
• Completely unwind the power cord before plugging into
an earthed socket.
• Use appliance for its intended use only.
• To reduce the risk of contact with hot water emitting from
steam vents, check appliance before each use by holding
it away from body and operating steam button.
2
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Never unplug the appliance by pulling on the power
cord; instead, grasp plug and pull away from the socket
to unplug the appliance.
• Do not allow the power cord to touch hot surfaces or
come into contact with rough or sharp edges. Let the
appliance cool completely down before putting away.
Loop cord loosely around appliance when storing.
• Before filling or emptying the water tank, cleaning,
or removing or retting accessories, ensure that the
appliance is unplugged an completely cool.
• Care should be taken when using the appliance due to
the emission of steam.
• The appliance must not be used if it has been dropped,
if it has any visible damage, if it leaks, or if it functions
abnormally in any way. Do not attempt to dismantle
your appliance: have it examined at an Approved Service
Centre to avoid any danger.
• Close supervision is necessary for any appliance being
used by or near children.
3
• Never leave the appliance unattended when it is
connected to the mains. Before storing the appliance,
once it is unplugged, please wait until it has cooled down
(around 1 hour).
• Burns could occur from touching hot metal or plastic
parts, hot water or steam. Use care when you empty a
steam appliance. There may be hot water in the reservoir.
• Do not use an extension lead. If you accept liability for
doing so, only use an extension lead which is in good
condition, has a plug with an earth connection and is
suited to the power rating of the appliance.
• Never immerse your appliance in water or any other
liquid. Never place it under a running tap.
• Do not direct steam at people, animals or clothes while
they are being worn.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
• The use of accessory attachments other than those
provided by the manufacturer is not recommended and
may result in re, electric shock or personal injury.
4
• The appliance must be used and placed on a at, stable,
heat-resistant surface. When you place the appliance on
its stand, ensure that the surface on which the stand is
placed is stable.
• The appliance must not be used if it has been dropped, if
there are visible signs of damage or if it is leaking.
• Check the electrical power cord and steam cords for signs
of wear or damage prior to use. If the electrical power
cord or the steam cord is damaged, it must be replaced
by an Approved Service Centre to avoid any danger.
• Do not use other descaling products than the one cited
in the IFU.
• Do not obstruct the appliance airways.
Before rst use
• When you rst use the appliance, some smoke or a harmless odour may be produced or there may be
a small discharge of particles. This will not aect the use of the appliance and will disappear quickly.
What water to use?
• Your appliance has been designed to use untreated tap water.
Do not use pure demineralised or pure distilled water, water from clothes dryers, scented or softened
water, rain water, ltered, bottled or boiled water, water from refrigerators, batteries or air conditioners
as these may damage the appliance. These types of water contain organic waste, mineral elements
that become concentrated when heated and cause spitting, brown staining, leaking or premature
wear on your appliance. If your water is very hard, mix 50% untreated tap water with 50% distilled
water (available in hardware stores).
SAVE THESE
INSTRUCTIONS
5
TROUBLESHOOTING
ENVIRONMENTAL PROTECTION FIRST !
L Your appliance contains valuable materials which can be recovered or recycled.
 Leave it at a local civic waste collection point.
Problems Possible causes Solutions
There is no steam. The appliance has not
been turned on.
Check that the appliance has been
plugged in correctly. Next press the
On/O pedal, the power indicator
light located at the front of the
appliance will come on.
The hose has been
obstructed.
Check that the hose is not bent or
twisted.
There is no water left in
the water tank.
Unplug the appliance and ll the
water tank.
The steam is not ready yet. The appliance will produce steam
about 45 seconds after it has been
switched on.
The steam ow is
low.
Your steamer has a
build-up of scale because
it has not been rinsed out
regularly.
See descaling process (Descaling
procedure paragraph).
The hose has been
obstructed.
Check that the hose is not bent or
twisted. Always extend fully the pole.
There is no water left in
the water tank.
Unplug the appliance and ll the
water tank.
Water runs through
the holes of the
steam head.
There is condensation in
the hose.
Never use a steamer in the horizontal
position. Hold the hose vertically
outstretched and wait for the
condensed water to return to the
steamer. Always extend fully the pole.
The steamer takes
a long time to heat
and/or ejects white
particles.
Your steamer has a
build-up of scale
because it has not been
descaled
regularly.
See descaling process
(Descaling procedure paragraph).
6
* EN Depending on model
2*
3
1
10
11
5
9
6
8
13*
14*
17*
15*
16*
4
12*
7*
PRODUCT DESCRIPTION
1. EN Hanger + hanger hook
2. EN Steam Head*
3. EN Steam Hose
4. EN Adjustable pole +
adjustable vertical support
hook* + Power cord hook
5. EN Control panel
6. EN ON/OFF button
7. EN Steam level led*
8. EN Anti-calc button
9. EN Water tank button
10. EN Removable Water tank
11. EN Draining Cap
12. EN Removable vertical
support*
13. EN Fabric Brush *
14. EN Steam bonnet*
15. EN Lint pad*
16. EN Glove*
17. EN Crease attachment*
* EN Depending on model
9
1. ASSEMBLY
Open the two pole locks.
EN
Extend the pole fully.
EN
Insert the pole in the housing until you
hear a "click".
EN
Close the two locks.
EN
10
1
2
Unlock the hanger and fully insert it
vertically on top of the pole and lock it.
EN
Position the steam head on its craddle.
EN
Take out the vertical support* from its
bag and unroll it.
EN
Hook the upper part of the vertical
support* on rear hanger.
EN
* EN Depending on model
11
2. BEFORE USE
1.3L
44OZ
MAX
Unwind the support and insert it in
the adjustable hook, by adjusting the
tension with the dedicated hook and
lock it.
EN
Remove the water tank.
EN
Remove the cap and ll the water tank.
EN
* EN Depending on model
12
3. ACCESSORIES
Ensure the appliance is unplugged and completely cool
when adjusting or removing accessories.
EN
Fully screw the water tank cap and
insert tank back in appliance.
EN
Add the garment of your choice on the
hanger.
EN
* EN Depending on model
13
The fabric brush opens the weaves
of the fabrics for better steam
penetration.
EN
The steam bonnet lters water
impurities and protects fabrics from
water drips.
EN
The crease attachment is used to make
pant creases easily or to remove stubborn
wrinkles. Put your fabric in the space
between the two accessory parts. Move
the crease attachment in a downwards
motion starting from the top.
EN
*
*
*
* EN Depending on model
14
4. USE
45s
The appliance must remain in a
horizontal position on the oor.
EN
Totally unroll the cord and plug the
appliance.
EN
Push the ON/OFF button, in order to
switch on the appliance. The leds will
ash for approx 45 seconds.
EN
After 45 seconds approximately, steam
will come out.
EN
15
Level max = all leds are bright = steam
max
EN
level 2 = 2 led bright = steam low
EN
level 0 = no led bright = no steam
EN
*
*
*
*
Adjust steam output by pushing the
buttons + and - on the steam head.
EN
* EN Depending on model
16
5. DURING USE
Never steam a garment while it is
being worn. Always hang on the stand
or on a hanger.
EN
For optimal use, press the steam jets
on your garment from top to bottom.
EN
If "WATER" button is ashing, the level
of water in the water tank is low and
must be lled.
EN
17
1.3L
44OZ
MAX
The appliance must be switched o,
push the ON/OFF button in order to
switch it o.
EN
Unplug, then remove the water tank.
EN
Remove the cap then ll in the water
tank.
EN
Fully screw the water tank cap and
insert tank back in appliance.
EN
18
6. AFTER USE
45s
Plug in the appliance.
EN
Push the ON/OFF button in order to
switch on the appliance.The steam
level will ash on maximum level for
45 seconds.
EN
Long push the ON/OFF button in order
to switch o the appliance.
EN
19
Unplug the appliance.
EN
Remove the water tank.
EN
Unscrew the cap and then empty the
water tank completely in a sink.
EN
Screw back the cap and place the
water tank back in the appliance.
EN
20
1h
7. DESCALING PROCEDURE
Roll up the power cord and place it on
its power cord hook.
EN
Wait for an hour for your appliance to
cool before storing.
EN
Make sure the water tank is empty
before moving the appliance on its
wheel.
EN
To apply when the "anti-calc" button is
ashing. Reset by pressing the button.
EN
21
Water
0.5 L
17OZ
1h
Unlock and half collapse the pole,
lock it.
EN
Remove the water tank.
EN
Fill in 0.5L(litre) of water in the
appliance tank inlet.
EN
WARNING! Wait for an hour for the
appliance to completely cool down.
EN
22
Shake gently the appliance to remove
the main particles.
EN
Place the appliance over a sink &
unscrew the «Anti calc» cap by turning
it anti clockwise.
EN
Be careful , water might be hot.
Never unscrew the cap when the appliance is in use.
Wait for full cool down.
EN
23
Tilt the appliance to empty water in
a sink.
EN
Set back the draining cap, fully screw
it until complete locking and check
there is no leakage.
EN
Unlock the pole , extend fully, lock.
EN
Place the steam head on its craddle.
EN
24
1.3L
44OZ
MAX
Remove the cap then ll the water
tank.
EN
Plug in and switch on the appliance.
EN
Let the appliance run until water tank
is emptied completely.
EN
Fully screw the water tank cap and
insert tank back in appliance.
EN
25
8. CLEANING
1h
Wait an hour for complete cool down.
EN
Only use a sponge with water to clean
the base. Never put water on control
panel.
EN
Only use a sponge with water to clean
the steam head. Never put water on
+/- buttons and leds
EN
EN
Never use detergents when cleaning
your appliance.
26
Never wash or rinse appliance directly
over a sink.
EN
Never wash or rince the steam head
directly over a sink.
EN
The sponge below the water tank can
be removed and cleaned with tap
water. Don't forget to put it back.
EN
9100035167
