KODAK PIXPRO AZ652
DIGITAL CAMERA
User Manual
11
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
Company Website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS210.
This device complies with Industry Canada license-exempt RSS standard (s).Operation
is subject to the following two conditions: (1) this device may not cause interference
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
BEFORE YOU START
2
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection
of electrical waste and electronic equipment in the European countries. Please do
not throw the equipment into domestic refuse. Please use the return and collection
systems available in your country for proper, safe disposal of this product.
“CE” mark indicates that this product complies with the European requirements
for safety, health, environment and customer protection. “CE” marked cameras are
intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive
2014/53/EU. The following test methods have been applied in order to prove
presumption of conformity with the essential requirements of the R&TTE Directive
2014/53/EU:
- EN 609501: 2006+A11:2009 +A1:2010 +A12:2011
Safety of Information Technology Equipment
- EN 50566: 2013
Product standard to demonstrate compliance of radio frequency ields from
handheld and body- mounted wireless communication devices used by the general
public (30 MHz — 6 GHz)
- EN 622092: 2010
Human exposure to radio frequency ields from handheld and bodymounted
wireless communication devices — Human models, instrumentation, and
procedures
Part 2: Procedure to determine the speciic absorption rate (SAR) for wireless
communication devices used in close proximity to the human body (frequency
range of 30 MHz to 6 GHz)
3
- EN 300 328 V1.9.1 : 2015
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband
transmission systems; Data transmission equipment operating in the 2.4GHz ISM
band andusing wide band modulation techniques; Harmonized EN covering the
essential requirements of article
- EN 301 4891 V1.9.2: 2011
Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electro
Magnetic Compatibility (EMC) standard for radio equipment and services; Part 1:
Common technical requirements.
- EN 301 48917 V2.2.1:2012
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic
Compatibility (EMC) standard for radio equipment; Part 17: Speciic conditions for
Broadband Data Transmission Systems
Hereby, Sintai Optical (Shenzhen) Co., Ltd, declares that this PIXPRO AZ652 is
in compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town,
Bao’an District, Shenzhen, Guangdong, China
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
4
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modiications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an
uncontrolled environment and is safe for intended operation as described in this manual.
Additional RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
5
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual
carefully and keep it in a safe place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual
may be reproduced, transmitted, transcribed, stored in a retrieval system or translated
into any language or computer language, in any form, by any means, without the prior
written permission of JK Imaging Ltd.
All trademarks mentioned in this manual are used for identiication purposes only and
are properties of their respective owners.
This manual provides you with instructions on how to use your new KODAK PIXPRO
Digital Camera. Every effort has been made to ensure that the contents of this manual
are accurate; however JK Imaging reserves the right to make changes without notice.
Throughout this manual, the following symbols are used to help you locate
information quickly and easily:
Indicates useful information.
The following symbols may be used throughout this manual to facilitate your
understanding of how to operate the camera:
[Item properties] ： The optional properties in the camera interface are indicated by
the [ ] symbol.
6
SAFETY NOTES
Safety Notes for this Camera
Do not drop the camera or allow it to
hit solid objects.
Do not attempt to disassemble or
repair the camera.
Do not use or store the camera in dusty
places or on a beach to help prevent
dust or sand from entering the camera,
causing possible damage.
Do not use or store the camera in a hot
environment or in direct sunlight.
Do not use or store the camera near
powerful magnetic ields, for example
near a magnet or transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct
sunlight for a long period of time.
To prevent the camera from being
damaged by moisture, do not use
or store the camera in very humid
environments, such as in rain or near
bodies of water.
If water accidentally comes in contact
with the camera, turn the camera off
immediately, remove the battery and
the memory card and dry it completely
within 24 hours.
When you take the camera from a cold
environment to a warmer environment,
condensation may occur. Please wait
for a reasonable period of time before
you turn the camera on.
Before you remove the battery and
memory card, the camera should be
turned off.
When you clean the body of the
camera, do not use abrasive, alcohol-
based or organic cleansers or solvents.
Use a professional lens cleaning cloth
and appropriate cleaner to wipe and
clean the lens.
Download your photos and remove the
memory card when you are going to
store the camera for long periods of
time.
If this camera is not in use for a long
period of time, please keep it in a dry
and clean storage location.
Our company will not pay
compensation for any failure of
playback including: pictures or
videos damaged or unrecoverable by
improper operation.
77
Safety Notes for Battery
Please use a battery that is the same
type as the one included.
Please use the attached charger to
charge the battery.
If battery luid leaks inside the
camera, contact our customer service
department immediately. If battery
luid leaks onto your skin, rinse your
skin immediately with clean water and
seek immediate medical attention.
Disposal of used batteries should be
carried out in accordance with your
local (national or regional) regulations.
To prevent the battery from being
damaged, do not drop the battery or
allow it to hit solid objects or to be
scratched by foreign objects.
Do not let the battery come in contact
with metal objects (including coins)
to avoid short circuiting, discharging,
excessive heat or possible leakage.
Do not attempt to disassemble the
battery.
Do not expose the battery to water.
Always keep the battery contacts dry.
Do not heat the battery or throw it into
a ire to avoid a possible explosion.
Do not store the battery in a hot
environment or in direct sunlight.
If the battery overheats during
charging or use, stop charging or use
immediately. Turn off the product,
remove the battery carefully, and wait
until it cools down.
When the camera is stored for a long
period of time, remove the battery and
keep it in a safe, dry place that is not
accessible to infants and children.
In colder environments, the
performance of the battery could be
noticeably reduced.
When you install the battery, align the
battery markings according to the
positive and negative markings inside
the camera battery compartment.
Never force the battery into the battery
compartment.
8
Safety Notes for Memory Card
We highly suggest buying only well-
known, name brand memory cards
to ensure peak performance and
reliability.
Format the memory card using the
camera before you use it or insert a
new one.
Do not drop the memory card or
allow it to hit solid objects to avoid
damaging it.
Do not attempt to disassemble or
repair the memory card.
Do not expose the memory card to
water. Always keep it dry.
Do not remove the memory card when
the camera is turned on. Otherwise,
the memory card and photo/video iles
could be permanently damaged.
Do not directly edit the data on the
memory card. Copy the data to your
computer before you edit iles.
When the camera is stored for long
periods of time, be sure to download
your photos and remove the memory
card. Store the memory card in a dry
environment.
Do not modify the name of the iles
or folders of the memory card using
your computer. Modifying the ile
names may cause the iles to not
be recognized on the camera or a
possible permanent error may occur.
A photo taken with the camera
will be stored in the folder that is
automatically generated on the
memory card. Do not store photos
that are not taken using this camera in
these folders as the pictures cannot be
recognized during playback.
When you insert the memory card,
make sure the notch of the card
matches the markings on the top of
the camera card slot.
9
Other Safety Notes
Do not disconnect the power or turn the camera off during the update process. Doing
so may cause incorrect data to be written and the camera may not power on later.
Do not hang the neck strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules speciied by the
airline and FAA regulations.
Due to the limitations of manufacturing technology, the LCD may have a few dead
or bright pixels. These pixels do no effect the quality or performance of the camera,
photos or video.
Do not expose the camera’s LCD to water. In a humid environment, only wipe it with a
soft, dry, cleaning cloth.
If the LCD is damaged and the liquid crystal comes into contact with your skin, wipe
your skin with a dry cloth immediately and rinse it with clean water. If liquid crystal
comes into contact with your eyes, wash them with clean water at least for 15 minutes
and seek immediate medical attention. If you accidentally swallow liquid crystal, rinse
your mouth immediately and seek medical attention.
10
BEFORE YOU START .............1
SAFETY NOTES ....................6
CONTENTS ...........................10
GETTING READY ................... 14
Accessories Included ......................14
Installing Lens Cap and Neck Strap ..15
Part Names ......................................16
Installing Battery and Memory Card 19
Charging the Battery .......................21
Vari-angle LCD .................................22
Turning Camera On and Off ...........23
Set your Language, Date/Time
after the First Power-On ............24
Set your Language, Date/Time .......24
Resetting your Language ..........25
Resetting Date/Time .................26
MODE OVERVIEW ................27
LCD Display......................................27
Overview of the Screen Icons in
Shooting Mode .........................27
Overview of the Screen Icons in
Movie Mode ...............................29
Overview of the Screen Icons in
Playback Mode ..........................30
How to Take Pictures .......................31
Using the Mode Dial ........................32
Face Beautiier
..................35
Wi-Fi Mode
.........................36
Scene Mode
....................43
Custom Settings (
) ..............49
BASIC OPERATION ............... 51
Using EVF (Electronic View Finder) .51
Using the Zoom Function................52
Display Setting ................................53
CONTENTS
1111
AF Area ............................................55
Macro Mode.....................................56
Self-Timer Mode .............................57
Flash Mode .....................................58
WB (White Balance) Mode ..............60
Continuous Shot Mode ...................62
Exposure Compensation Functions
Setting .............................................64
EV Adjustment...........................64
ISO Adjustment .........................65
Shutter Speed Adjustment .......65
Aperture Adjustment ................66
Using Quick Recording ...................66
“i” Button Function Menu ................67
Using the Lens Function Ring .........68
Zoom/AF Mode ..........................68
Function Ring (Smart) Mode ....69
MF(Manual Focus) Mode ...........70
PLAYBACK ............................ 71
Viewing Photos and Videos ............71
Thumbnail View ...............................72
Using Zoom Playback (for still
pictures only) ...................................73
Continuous Shot Group Playback ..74
Animation Panorama Play ...............75
Slideshow ........................................76
Deleting Photos and Videos ............77
USING THE MENUS ..............78
Shooting Menu ................................78
Expo Metering ...........................79
OIS (Optical Image
Stabilization) .............................79
Beautiier ...................................80
Select Scene .............................80
Shoot Setting1 .................................81
Image Size .................................82
12
Movie Size .................................83
Quality .......................................84
MF (Manual Focus) Assist .........85
AF Assist Beam ..........................86
Digital Zoom ..............................86
Shoot Setting 2................................87
Date Imprint ..............................88
Quick Review.............................88
Continuous AF...........................89
Face Detection ..........................89
Custom Settings .......................90
Function Ring (Smart) ...............91
Playback Menu ................................92
Menu
...................................92
Display Mode .......................93
Rotate
..................................93
Color ...................................94
HDR .....................................95
Touch-Up
.............................96
Resize
.................................97
Playback Settings ...........................97
Protect .......................................98
Delete ........................................98
DPOF (Digital Print Order
Format) ......................................99
Trim ............................................100
Play Slide Show .........................100
General Settings ..............................101
Sound Settings..........................102
Power Saver...............................102
Language ...................................103
World Time ................................103
Date & Time ...............................103
LCD Brightness ..........................103
File Settings .....................................104
Format ......................................105
13
Copy to Card .............................106
File Numbering ..........................106
Reset Settings ...........................107
Version ....................................... 107
CONNECTION SETTINGS ...108
Connecting to a Computer .............1 08
Setting the USB Mode ..............108
Transferring Files to your
Computer ..................................109
Connecting to a PICTBRIDGE™
Compatible Printer ..........................110
Setting the USB Mode ..............110
Connecting to your Printer .......111
Using the PICTBRIDGE™ Menu ........112
Print (with Date) ........................112
Print (without Date) ...................113
Print Index .................................114
Print DPOF Images ....................115
Exit .............................................115
Video System ..................................116
Supported HDMI Connections .......117
Connecting HDMIReady TV .....117
HDMI CEC Control ...........................118
Set Eye-Fi SD Card Connection Mode
123
APPENDICES .......................124
Product Speciications ....................124
Prompts and Warning Messages ....128
Troubleshooting ..............................133
1414
GETTING READY
Your camera box should contain the camera model you purchased along with the
following accessories. If anything is missing or appears to be damaged, please contact
your retailer irst or our customer service center (Based on sales in different countries or
regions, the shape of the AC adapter will vary. Please subject to the actual product will
prevail.)
Accessories Included
Micro USB Cable
Warranty Card
AC Adapter Neck StrapRechargeable
Li-ion Battery
Lens Cap With Strap
Quick Start Guide
Quick Start Guide
STOP
Service Card CDROM
1515
Installing Lens Cap and Neck Strap
16
Part Names
11
10
1
2
3
98
7654
1. Micro HDMI Port
2. Micro USB Port
3. Zoom Lever
4. Shutter Button
5. Strap Eyelet
6.
Exposure Compensation Button
7.
Continuous Shot Button
8. Power Button
9. AF Assist Beam/Self-Timer Lamp
10. Flash Lamp
11. Lens
1717
13
12
14
17
16
18
19
20212223
15
5
12. Microphone
13. Electronic View Finder (EVF)
14.
EVF / LCD Switch Button
15. Indicator Lamp
16. Mode Dial
17.
Fast Video Recording Button
18. Menu Button
19.
Jog Dial
[
] AF Button/Up Button
[
] Delete Button/Self-Timer
Button/Down Button
[
] Macro Button/Left Button
[
] Flash Button/Right Button
20.
Display Button
21. Playback Button
22.
SET Button
23.
“i” Button
Rolling the jog dial can be for fast selection instead of pressing the up/down/left/
right button.
1818
2425262728
24. Vari-angle LCD
25. Diopter Adjustment Knob
26. Speaker
27. Lens Function Ring Lever
28. Lens Function Ring
2930
29. Battery Cover
30. Tripod Socket
19
2. Insert the battery into the battery
compartment according to the
negative and positive directions as
illustrated in the picture. Push the
battery down until it locks in place.
1. Open the battery cover door.
2
1
Installing Battery and Memory Card
Battery Lock Knob
2020
A memory card (SD/SDHC/SDXC) is optional and not included in all camera
packaging. It needs to be purchased separately. Please use an original memory card
which is Class 4 or higher and has a capacity of 4GB to 256GB.
To remove your memory card, open the battery cover door, gently press the
memory card to eject it and remove it carefully.
3. Insert the memory card into the memory
card slot as shown in the diagram:
4. Close the battery cover door.
1
2
Write Protection
Toggle Switch
21
Please insert the battery and charge it
under shutdown mode.
1. Connect the camera to the power
charger using the supplied Micro USB
cable.
2. Insert the plug of the power charger
into the power outlet to charge the
battery.
After the battery is stored for long
periods of time, use the supplied
power charger to charge the battery
prior to use.
Charging indicator:
Steady orange: Charging
Steady green: Charging complete
To maximize battery life, charge the
battery for at least 4 hours the irst
time.
Please charge the battery indoors
between 0°C and 40°C (32°F and
104°F).
Charging the Battery
Indicator Lamp
2
1
22
Vari-angle LCD
The LCD is housed in the camera’s body. You may follow the directions shown below to
move it as needed:
2
1
3
4
1. Turn on the LCD along the direction shown by arrow ①.
2. Available to rotate 180° along the direction shown by arrow ②.
3. Available to rotate 90° along the direction shown by arrow ③.
4. Turn off the LCD along the direction shown by arrow ④.
Please don’t rotate the LCD with excessive force to prevent damages.
Please turn off the LCD along the direction shown by arrow ④ after use to protect it
from scratches.
23
Turning Camera On and Off
Press the Power button to turn the camera on. To turn the camera off, press the Power
button again.
Power Button
When the power is off, press and hold the playback button to power on and
enter Playback mode.
24
Set your Language, Date/Time
Set your Language, Date/Time after
the First Power-On
1. When you turn the camera on for
the irst time, the language selection
screen appears.
2. Press the [
]/[ ] button to
select your desired language.
3. After you press the
button to
conirm your language selection, the
Date/Time settings screen will appear.
4. Press the [
]/[ ] button to
select the Date/Time to be adjusted:
Time is displayed in YYYY.MM.DD/
HH:MM.
5. Press the [
]/[ ] button to
adjust the value for the desired Date/
Time.
6. Press the
button to conirm the time
settings and the shooting screen will
appear.
Sound Settings
Power Saver Auto
Language
World Time Home
Date & Time
English
LCD Brightness
2017.04.29 00:00
Exit
Set
Select
Soun
P
o
w
e
Au
t
o
L
an
g
W
o
r
ld
Ho
m
e
Date
ng
lis
h
L
CD
B
0
0:0
0
Ex
it
Se
Language
য檥Иކ
এѽИކ
মୁ
䚐ạ㛨
English
Français
Date & Time
:
.. 04 29 00 00
H-M
2017
Exit
Select
Set
2525
Sound Settings
Power Saver Auto
Language
World Time Home
Date & Time
English
LCD Brightness
2017.04.29 00:00
ExitSet
Select
Sound Settings
Power Saver Auto
Language
World Time Home
Date & Time
English
LCD Brightness
2017.04.29 00:00
Exit
Set
Select
Soun
P
o
w
e
Au
t
o
L
an
g
W
o
r
ld
Ho
m
e
Date
ng
lis
h
L
CD
B
0
0:0
0
Ex
it
Se
Language
য檥Иކ
এѽИކ
মୁ
䚐ạ㛨
English
Français
Resetting your Language
After you set your language for the irst
time, follow the instructions below to reset
your language.
1. Press the
button, press the [ ]
/[ ] button to select and press
the button to enter the menu.
2. Press the [
]/[ ] button to select
.
3. Press the [
]/[ ] button
to select [Language] and press the
button to enter the menu.
4. Press the [
]/[ ] button to
select your desired language and press
the button to conirm.
5. Press the
button and the shooting
screen will appear.
2626
Resetting Date/Time
After you set your Date/Time for the irst
time, follow the instructions below to
reset date and time.
1. Press the
button, press the [ ]
/[ ] button to select , and
press the button to enter the menu.
2. Press the
[ ]/[ ] button to
select .
3. Press the [
]/[ ] button to
select [Date & Time] and press the
button to enter the menu.
4. Press the [
]/[ ] button to
select the Date/Time to be adjusted:
Time is displayed in YYYY.MM.DD/
HH:MM.
5. Press the [
]/[ ] button to
press the value for your selected entry.
After you inish your settings, press the
button to conirm.
6. Press the
button and the shooting
screen will appear.
Sound Settings
Power Saver Auto
Language
World Tim
eH
ome
Date & Time
English
LCD Brightness
2017.04.29 00:00
ExitSet
Select
Date & Time
:
..
04 29 00 00
H-M
2017
Exit
Select
Set
27
Overview of the Screen Icons in Shooting Mode
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
x3.0
1 2
3
4
5 6
7
9 10
11
13
15
16
17
12
8
18
14
LCD Display
1
Eye-Fi ON (with signal)
7
Video Pixels
13
Color Effect
2
Focus Mode
8
Zoom Display(By turning the
Zoom Lever)
14
No Memory Card
3
Quality
9
Number of Pictures in Static
Mode
15
Beautiier
4
Face Detection
10
Ratio of Shooting Pixels
16
Flash Mode
5
Maximum Record Time
11
Image Size
17
OIS
6
Recording Speed (fps)
12
Battery Status
18
Self-Timer
MODE OVERVIEW
28
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
x3.0
20212325 2224
32
31
30
29
28
27
26
19
19
Lens Function Ring
Custom Settings
24 Focus Frame 29 White Balance
20
ISO Value 25
Exposure
Compensation Value
30 AF Area
21
Shutter Speed 26 Shooting Mode 31 Expo Metering
22 Histogram 27 Custom Settings 32
Single / Continuous Shot /
HDR / WDR / AE Bracketing
23 Aperture Value 28 Macro Mode
29
Overview of the Screen Icons in Movie Mode
00:00:00
1
43 2
00/15
1
Battery Status
2
Number of Videos Captured
3
Continuous Recording Time
4
Movie Mode
3030
Overview of the Screen Icons in Playback Mode
1
Eye-Fi ON (with signal)
9
Image Area
2
Quality
10
Zoom Magniication Area
3
Capture Date
11
Image Zoom Ratio
4
File Name
12
Index Prompt
5
Shooting Pixel Ratio
13
Touch-Up
6
Image Size
14
HDR
7
Battery Status
15
DPOF File Icon
8
Continuous Shot Group Playback
16
File Protection Icon
0000
000-00002016/04/18
Thumbnail3x3
1 32 4 6 75
8
16
12
11
10
9
2016/04/18
x2
13
14
15
31
How to Take Pictures
1. Hold the camera with both hands,
being careful to not block the lash and
lens with ingers.
2. Point the lens toward the object you
want to take a picture of, and then
frame it with the LCD.
3. Use the Zoom button to select Tele or
Wide positions to zoom in or out on
your subject.
4. Press the shutter button halfway to
focus on the subject. When the focus
frame turns green, press the shutter
button down completely to take the
picture.
32
Using the Mode Dial
This camera provides a convenient Mode dial that allows you to manually switch between
different modes with ease. The available modes are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will
be set based on the subject and environment. It is the most
commonly used mode for taking pictures.
Program AE
Under different scenes, the user can switch the ISO and EV
value according to personal preference, the camera can
automatically set the shutter speed and aperture value.
Shutter Priority
Setting allows you to adjust the shutter speed / EV value and
ISO value. The camera automatically sets the aperture value
based on the shutter speed and ISO value to get the most
appropriate exposure value.
Aperture
Priority
In this mode, you can adjusting the aperture size, EV and ISO
values. The large aperture is to highlight the object focused
through blurring the background, while the small aperture is for
clear focusing on both the background and the object.
3333
Manual Mode
This mode is for manually setting the aperture, shutter speed
and ISO value.
Face Beautiier
This mode automatically enhances facial features with skin
softening touches and eye brightening capabilities.
Wi-Fi Mode
Enable image transmission and remote control by connecting
smart device with Wi-Fi.
Scene Mode
Choose from 14 different pre-set scene types and effects for
your photos.
Movie Mode
Record videos.
Custom Settings
The user can store frequently used shooting modes and
parameters. Switching to this mode enables quick adjustment.
34
Please refer to the table below if any nonadjustable options in mode:
(O: Available X: Unavailable)
Aperture Shutter EV ISO
X
(Display)
X
(Display)
O O
X
(Display)
O O O
O
X
(Display)
O O
O O
X
(Display)
O
1. Turn the mode dial to select the
mode you want.
2. Press the
button to conigure settings.
3. Press the [
]/[ ] button to select an adjustment setting.
4. Press the [
]/[ ] button to adjust the parameters.
5. Press the
button to conirm the settings and enter the shooting screen.
Mode
Options
35
Face Beautiier
1. Turn the Mode dial to select Face Beautiier Mode (
).
2. Press the
button and press the [ ]/[ ] button to select .
3. Press the [
]/[ ] button or rolling the jog dial to select an option and press
the
button to conirm and enter the shooting screen.
Beautifier:Effect 1
Skin Soften
Effect 1: Skin Soften
Effect 2: Skin Soften + Eye Brightening
Effect 3: Skin Soften + Eye Brightening + Eye Enlargement
36
Wi-Fi Mode
Enable image transmission and remote control by connecting smart device with Wi-Fi.
Matters needing attention before use:
Your smart device operating system version needs to be iOS 8 or higher, or ANDROID
4.2 or higher. If not, please upgrade your smart device before using the App.
Please do not use in places having high intensity magnetic ield, electrostatic and
electric wave interference (for example near a microwave oven), which may cause
failure in receiving signals.
To maintain a connection, please keep the camera within 10 meters (32.8 feet) without
signal shielding interference.
Please do not use Wi-Fi connection functionality on a plane.
The camera and the smart device can only be connected one to one.
Downloading the APP package:
Download a dedicated installation package from the application store (App name:
PIXPRO Remote Viewer
) and then install it.
PIXPRO Remote Viewer”
in Google play, and install it following the instructions on the
interface.
: Search and download the APP “PIXPRO Remote Viewer”
in APP
store, and install it following the instructions on the interface.
37
1. Rotate the mode dial to and then
enter the Wi-Fi selection interface.
2. Press the [
]/[ ] button to
select and set options.
Settings Station AP mode
Wi-Fi Mode
In AP mode, the camera will act
as an access point enabling another
Wi-Fi device to connect to it.
[Settings] ：
Customize the Wi-Fi settings for
the camera system.
[Station] ：
Use the Station Mode to connect
to a “Personal Hotspot” created by
your mobile device.
[AP Mode] ：
In AP mode, the camera will act as
an access point enabling another
Wi-Fi device to connect to it.
Rotate the mode dial to disconnect.
AP Mode
This camera may connect with your smart
device through Wi-Fi.
Settings of Camera:
1. Select and press the button to
enter the setting interface.
2. Press the [
]/[ ] button
to select options to be adjusted, and
press the button to enter the option
setting interface.
AP mode
Back
Refresh
Setting pre-connected device for the
following serial number:
SSID: PIXPRO AZ652_XXXX
WPA2-PSK: XXXXXXXX
password.
38
Settings of Smart Device:
1. Enable the Wi-Fi of smart device and
then search surrounding wireless
devices.
2. Select the name of camera SSID to be
connected and then input the eight-
digit number password after WPA2PSK
on the camera.
3. Click the icon of the APP
to enable
the APP.
Set up completion:
Once the APP is connected to the camera,
functional operations can be enabled on
the smart device.
Station
Enable image transmission and remote
control by connecting the camera with a
Wi-Fi access point created by your smart
device.
1. Enable the Wi-Fi access point of smart
device.
2. Select the
on camera and then
press the button to conirm
connection with smart device.
3. Press the [
]/[ ] button
to select the name of smart device to
be connected and then press the
button to conirm. Then, the camera
enters the password input interface.
39
Press the [ ]/[ ] button to select:
wireless devices.
: Select the name of device to be
connected.
screen.
4. Press the [
]/[ ]/ [ ]/
[ ] button or rolling the jog
dial to select and then press the
button to conirm your selection. Enter
the completion of WPA2- PSK after
password storage.
Type the network security key
A/a
Cancel
Enter Password
Save
#!?
Meanings of Interface Icons:
Icon Description
Delete the last letter
$D
Switch the display of letters
in capital and lowercase
Move the Cursor
#!?
Switch the symbol input
Input Space
40
5. Connect to network after storing the
password.
shown below:
Station
Wi-Fi Mode
Connected with device
SSID: XXXXXXXX
Disconnect
device and try again.
6. After connection, click the icon of the
APP
on the smart device, you may
use it to carry out relative operation.
Display of Wi-Fi Connection Status:
The Wi-Fi has successfully connected but
APP is not enabled.
AP mode
Wi-Fi Mode
Connected with device
MAC address: xx:xx:xx
Disconnect
AP mode
The Wi-Fi has successfully connected and
APP is enabled.
Wi-Fi Mode
Connected with APP
XXXXX
Disconnect
41
For interrupting the connection:
Wi-Fi Mode
No
Yes
Disconnect from device?
to previous page.
connection screen.
The Wi-Fi of smart device interrupts:
AP mode
Wi-Fi Mode
Disconnected, please check
Back
Wi-Fi device and try again.
Setting
The name of this camera can be changed
through key stroking.
1. Select the
and then press the
button to enter the setting interface.
2. Press the [
]/[ ] button to
select options to be adjusted and then
press the button to enter the menu.
DSC device
MAC address
PIXPRO AZ652_
XXXX
38:67:93:
XX:XX:XX
Exit
Select
Set
3. Press the button to conirm settings
and then skip the menu.
42
DSC Device
The default name of DSC device is
[PIXPRO AZ652_XXXX]. Change the name
of DSC device through key stroking.
Name between 1-18 Letters
PIXPRO AZ652_XXXX
$D
Cancel
DSC device
Save
#!?
For the method of input, please refer to
the introduction on password input on
page 39.
MAC address
Check the wireless MAC address of this
camera.
App Operating Instructions
Refer to the "PIXPRO Remote Viewer User
Manual" located on the web:
http://kodakpixpro.com/Europe/
support/downloads.php
Europe
http://kodakpixpro.com/
Americas/support/downloads.php
Americas
43
Scene Mode
You can select your desired scene from the 14 scene modes according to the type of
environment you are shooting in. The camera then automatically conigures the most
appropriate settings for the best possible photos.
1. Rotate the Mode dial to
, then the LCD will display as below:
Auto Scence
The camera automatically detects
the most suitable shooting scene.
2. Press the [ ]/[ ] button to select a scene, and press the button to conirm.
3. If any need of changing the scene, please press the
button and then the button
and inally the [ ]/[ ] button to reselect the scene.
44
Scene Description
Auto Scene
The camera automatically detects the most suitable shooting
scene.
Panorama Mode For shooting up to 360-degrees of landscape.
Handheld Night Reduce blur when shooting low light/ illuminated scenes.
Multi Exposure Take several shots and overlap as a single image.
Cat/Dog
The camera automatically takes a picture when a dog or cat
face is detected.
Snow For subjects in the snow. Reduce underexposure.
Party
For subjects at night without using a tripod.
Capture sharp shots without blur.
Sport
For fast-moving subjects. Capture sharp action shots without
blur.
Night Portrait For portraits against night time scenery.
Portrait For shooting portraits
Children For kids and pets. Flash is disabled for eye protection.
Landscape Speed adjusted for brilliant images.
Sunset For sunsets. Capture subjects in strong sunlight.
Fireworks
For ireworks at night. Slow shutter speed adjusted for brilliant
images.
45
Auto Scene (ASCN)
In “ASCN” scene mode, the camera can intelligently detect different environments and
automatically select the best scene and photo settings for you.
“ASCN” can intelligently detect the following scenes:
Mode Name Description
Auto
The camera automatically adjusts the exposure and focus to
ensure the best possible pictures.
Landscape
For landscapes, automatically adjusts the exposure to match the
background.
Backlit Portrait
When the sun or any other light source is behind you,
automatically adjusts the foreground exposure to produce the
best pictures possible.
Macro
The Macro setting is ideal for shooting small objects or close-up
photos.
Night
Landscape
For night scenes, automatically increases the ISO value to
compensate for low light.
Portrait
Most suitable for capturing people with focus on their faces.
Night Portrait
When you take portraits at night, or in low light conditions,
automatically adjusts the exposure for people and night scenes.
46
Panorama Mode
This feature allows you to capture a
panoramic view that will have signiicantly
more content than a single photograph.
Follow the instruction arrow with a
smooth and steady movement of the
camera to seamlessly shoot an ultra-wide
scene of up to 360 degrees.
Follow the steps below:
1. Select the Panorama Mode (
) and
then press the button to conirm.
2. Press the [
]/[ ]/[ ]/
[ ] button to select a desired
shooting direction. Should you not
select a direction, the default shooting
direction is “right”. 2 seconds later, the
camera will be ready to take pictures.
You can also press the button or
press the shutter button halfway down
to be ready to take pictures.
3. Compose your shot on the LCD and
half press the shutter button to focus
on the subject. After focusing, fully
press the shutter button down to
take the irst picture. At this time, the
process dialog of panorama mode
stitching appears on the screen.
0/0000F00.0
Save
Cancel
4. Rotate the camera according to the set
direction. When the range of rotation
does not exceed the range that the
camera can detect, the progress dialog
along the indication arrow partially
turns red. When it completely turns
red, panorama mode shooting is
inished.
Panoramic image can be played
back by the method of lash playing.
Please see the animation panoramic
playback on page 75.
In Panorama Mode, the Flash, Self-
Timer, Macro Modes and Exposure
Compensation are not available.
Focus adjustment is also not available
at this time.
47
During panorama mode shooting,
press the button to interrupt
shooting and save the current
pictures taken. Press the [ ]
button to cancel shooting and not to
save the previously taken pictures.
During panorama mode shooting,
when the moving direction of
the camera is wrong or the angle
deviates from the internal settings,
the LCD shows a warning message
[Improper alignment. Please try
again.] and the current pictures
taken are saved.
Multi Exposure
Suitable for shooting moving objects (as
many as 6) in the same background.
Keep camera steady before
shooting. Press and hold the shutter
button to take 6 photos continuously
when it will stop automatically. To
stop shooting, release the shutter
button in the midway.
Objects shall be moved only from
left to the right in order to be
recorded. Objects moving from
other directions would not be
recorded.
Shooting effect will be inluenced
if object is moving too fast or too
close.
Cat/Dog
1. It defaults to enabling the auto
shoot after entering the Cat/Dog
mode. When a face of cat or dog is
detected, the camera will take photos
automatically. Meanwhile, you also
may press down the shutter button to
shoot.
2. Press the [ ] button to enter
Auto Shoot menu. If this function is
disabled, you may only take photos
manually.
At most, 10 cat /dog faces can be
detected at one time.
48
Functions that can be adjusted in each scene are as below:
Scene Adjustable Functions
Auto Scene Flash*
1
/Self-Timer
Panorama Mode None
Handheld Night Expo Metering/Self-Timer*
2
Multi Exposure Expo Metering
Cat/Dog Auto Shooting/Continuous Shot/Expo Metering/Macro
Snow Continuous Shot/Expo Metering/Flash/Self-Timer
Party Continuous Shot/HDR/Expo Metering/Flash/Self-Timer/Macro
Sport Continuous Shot/Expo Metering
Night Portrait HDR/Expo Metering/Self-Timer
Portrait Continuous Shot/HDR/Expo Metering/Flash/Self-Timer/Macro
Children Continuous Shot/Expo Metering
Landscape Expo Metering/Self-Timer*
2
Sunset HDR/WDR/Expo Metering/Flash/Self-Timer*
2
Fireworks Continuous Shot/Expo Metering/Self-Timer*
2
*1 Means the lash as an option of Night Landscape mode in Auto Scene is non-adjustable.
*2 Means Self-Timer smile is not included in the Self-Timer.
For continuous shot, there are only [Continuous Shot] and [Time-Lapse] for selection.
49
Custom Settings ( )
The user can store frequently used
shooting modes; and parameters and
switch to this mode for a quick adjustment.
Settings under mode (unset state or
state after reset):
1. Turn the Mode dial to select the
mode, and enter the setup screen, as
shown in the igure below:
Select one capture mode to define CS .
Auto Mode
Confirm
Exit
2. As shown in the igure, press the [ ]
/[
] button to select a capture mode
that you want to deine as , and press
the button to enter the shooting
screen.
3. As shown in the igure, press the
button, and choose whether to
continue the mode setting or rotate
the Mode dial to skip.
Or
Go to setting CS mode
Rotate the mode dial to skip.
Yes
For setting under other modes (use this
method to select a different custom
setting):
1. Select any mode to be stored.
2. Set your desired parameters in the
current mode.
3. Press the
button, press the [ ]
/[ ] button to select , and
press the button to enter the menu.
4. Press the [
]/[ ] button to select
.
5050
7. Turn the mode dial to switch to the
custom settings ( ).
8. The photo settings you stored the last
time are used.
When the
mode is used for
the irst time, there is no preset
parameter stored in the mode.
If you want to remove the parameter
setting of [Custom Settings], please
see the reset function on page 107
to operate.
5. Press the [ ] button select
[Custom Settings] and press the
button to enter the menu.
Off
Face Detection
Off
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
Normal
Function Ring (Smart)
6. Select [Yes] to save or [No] to cancel.
Set camera to
Yes
Custom Settings
No
user custom mode
51
3. When the screen display is not clear,
rotate the dioptric adjustment knob to
adjust the screen sharpness.
4. Press the button again or restart
the camera to switch back to the LCD
display.
The effect of eyes to refract rays of
light is referred to as refraction. The
capacity of refraction is represented
by focal power, which is called
diopter.
Diopter adjustment is aimed at
making the naked eyes of the
operators with myopia (-300 or less)
or hyperopia (+100) adapt to the
viewinder (EVF).
BASIC OPERATION
Using EVF (Electronic View Finder)
EVF functions as the LCD, which can be
used to observe the scene and objects
and for playback, preview and menu
operations.
EVF has the following advantages:
It will not be affected by ambient light
and may avoid poor composition due to
light relection on the LCD.
Follow the steps below:
1. Turn the camera on and press the
button to switch to the EVF display. At
this time, the LCD will become black.
2. View the scenes and objects through
the EVF.
52
Your camera is equipped with two types
of Zoom functions: optical zoom and
digital zoom. Toggle the Zoom lever of the
camera to zoom in or out on the subject
while taking pictures.
Using the Zoom Function
Zoom Lever
ISO00000
0/0000F00.0EV-0.0
x3.0
Zoom
Indicator
When the Optical Zoom reaches the
threshold as Digital Zoom, release
and turn the Zoom lever to T to switch
between the Optical Zoom and Digital
Zoom.
53
Mode:
Press the button to switch among 4
screens.
Function Message Display
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
x3.0
Display with Grid and Histogram
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
x3.0
No Message Display
ISO00000
0/0000F00.0EV-0.0
Message Display
ISO00000
0/0000F00.0EV-0.0
x00.0 00:00:00 0000
Display Setting
5454
Function Message Display
000-00000000/00/00
:N[SHTGOR^
Detailed Message Display
000mm
ISO00000
0/0000F00.0
EV-0.0
000-0000
0000/00/00
No Message Display
Mode:
Press the
button to display the playback screen, press the button to switch among
3 screens.
55
AF Area
In different photo shooting modes, you
can select different focus methods.
(Adjustable in mode)
1. Press the [
] button to display
the settings screen.
Center-AF
2. Press the [ ]/[ ] button to
select the following 4 modes:
Center-AF
The focus frame appears on the
center of the LCD to focus on the
subject.
Multi-AF
The camera automatically
focuses the subject in a wide
area to ind the focus point.
Spot Focus
Choose the single-point focus
position within the scope of
focus.
Object Tracking:
Smart tracking of the object
in motion under the focusing
shooting.
3. Press the
button to conirm the
settings and enter the shooting screen.
After enabling spot focus, rolling the
jog dial to adjust the position of
focus point in the screen.
The function of object tracking
cannot be enabled until successful
focus. For tracking the focus, you
need to keep the shutter semi-
pressed.
56
Macro Mode
The Macro Setting is ideal for shooting small objects or close-up photos. This mode
allows you to focus on subjects very close to the camera.
1. Press the [
] button to enter the Macro Menu.
Macro On
2. Press the [ ]/[ ] button to select the following 2 modes:
Macro On
Select this option to make focusing on the object closer to the lens (At the W
side, the shooting distance should be more than 1 cm).
Macro Off
Select this option to disable Macro.
3. Press the button to conirm the settings and enter the shooting screen.
57
Self-Timer Mode
Using this function can take photos at
regular time. The camera can be set to
shoot after 2 seconds, 10 seconds since
pressing the shutter or with Shoot After
Smile.
1. Press the [
] button to enter the
Self-Timer menu.
Self-timer 2sec
2. Press the [ ]/[ ] button to
select the following 4 modes:
Self-Timer 2sec
A single picture is shot 2
seconds after the Shutter
button is pressed.
Self-Timer 10sec
A single picture is shot 10
seconds after the shutter
button is pressed.
Self-Timer Smile
Press the shutter button
and a picture will be taken
immediately after a smile is
detected.
Self-Timer Off
Disables the Self-Timer.
3. Press the
button to conirm the
settings and enter the shooting screen.
When enabling the Self-Timer,
pressing the shutter or the [
]
button can disable the Self-Timer
and return to the shooting screen
while keeping the Self-Timer setting.
58
Flash Mode
The lash provides supplemental light for
the scene. The lash is usually used when
shooting against the light to highlight the
object; it is also suitable for metering and
shooting in darker scenes to improve the
exposure.
1. Press the [
] button to enter the
lash settings menu.
Force Off
2. Press the [ ]/[ ] button to
select the following 6 modes:
Force Off
Flash is turned off.
When enabling the Smile Detection,
pressing the shutter or the
button
can disable the Self-Timer and return
to the shooting screen while keeping
the Self-Timer smile setting.
Self-Timer settings will remain after
completion of shooting with the
Self-Timer. They can be canceled by
switching modes or by turning the
camera off and then on again.
5959
Fill Flash
For ill lash at the moment of taking a picture.
Flash Auto
Camera lash goes off automatically based on existing light conditions.
Red-Eye Reduction
The camera emits a brief pre-lash before the picture is taken to reduce red-
eye effects.
Slow Sync.
This allows you to take pictures of people at night that clearly show both your
subjects and the night time backdrop. The use of a tripod is recommended
when shooting with this setting.
Slow Sync.+Red-Eye Reduction
Use this mode for slow synchrony shots with red-eye reduction.
3. Press the
button to conirm the settings and enter the shooting screen.
After pressing the shutter button half way to achieve focus lock, the lash will
automatically pop up if needed.
60
The white balance function allows
adjustment of the color temperature for
different light sources. (Adjustable in
Mode)
Follow the steps below to set white
balance of the camera:
1. Press the
button to enter white
balance menu.
'=(
2. Press the [ ]/[ ] button to
select the following 9 modes:
AWB
Daylight
Cloudy
Fluorescent
Fluorescent H
Incandescent
Manual WB
Set WB according to the
current light source, press the
button to set.
Color Temp. (1900K~10000K)
Press the button to enter
and rolling the jog dial to
adjust the color temperature
value.
WB Bracketing
Press the shutter button once
to take three photos with
different WB settings.
3. Press the
button to conirm the
settings and enter the shooting screen.
WB (White Balance) Mode
6161
WB Bracketing:
Press the
button to enter options and then press the [ ]/[ ]/ [ ]/[ ]
button to adjust the shift and rolling the jog dial to adjust the BKT value (0, 1 and 2).
Rotate clockwise to adjust X axis (BA). BKT value
Rotate counterclockwise to adjust Y axis (GM). BKT value
Press the
button to conirm your settings.
WB Bracketing : BG±1
Shift
BKT
B9
1
2G
Confirm
WB bracketing is for setting the bracketing range. Shift to both sides for 3 spaces at
most. If at the page border, shift only to the other side and 2 photos can be taken. If
no shift, only one photo can be taken.
62
Functions that can be enabled under each
mode may be different.
Mode：
For setting the single, continuous shot,
Time-Lapse, HDR, WDR or AE bracketing
functions.
Please follow the following steps to set:
1. Press the button to enter the
continuous shot menu.
Single
2. Press the [ ]/[ ] button to
select the following 8 modes:
Single
Capture a single shot only.
Continuous Shot
For taking more than one
picture continuously.
Cont.Shot-Fast (2M)
For continuous shot with 2M
pixels.
Cont.Shot-High Speed (VGA)
For continuous shot with VGA
pixel.
Time-Lapse
Take pictures based on the
preset interval (30sec/ 1min/
5min/ 10min).Press the
button to select the interval
time.
HDR (-1EV, 0EV, +1EV)
This setting is to control the
high dynamic image range in
taking still pictures, with vivid
effect in highlight and that
the effect in dark parts can
identify the outline and depth
of the object. (Use of tripod is
recommended)
Continuous Shot Mode
6363
WDR (Wide Dynamic Range)
When the camera detects
that there is a big contrast in
brightness between scenes
and such scenes are against
the light, it will automatically
adjust the brightness and
saturation to capture an image
that better represents the
scene.
AE Bracketing (0.3EV, 0.7EV,
1.0EV, 1.3EV, 1.7EV, 2.0EV)
The camera will automatically
and continuously take three
pictures separately with a
brightness of original, darker
and brighter as long as you
press the shutter once. Press
the button to select the
range of exposure.
3. Press the
button to conirm the
settings and then enter shooting
screen.
Mode:
Single
Single
WDR
64
Exposure Compensation Functions Setting
The EV Function Menu of the camera
includes functions, such as EV
Adjustment, ISO, Shutter Adjustment,
Aperture Adjustment, etc. Using the
appropriate Function Settings can
improve your pictures.
Please follow the steps below to set:
1. Press the
button to display the
Settings screen.
4 options in [ Exposure Compensation
Functions Setting ]:
2. Press the [
]/[ ] button to
select the Setting options.
3. Press the [
]/[ ] button to
adjust the option values.
4. Press the button to complete the
setting and enter shooting screen.
EV Adjustment
Set up Exposure Compensation to adjust
the picture brightness. If there is very high
contrast between the photographed object
and the background, the brightness of the
picture can be adjusted as necessary. (This
can be adjustable in
Mode)
EV-0.0
ISO00000
0/0000F00.0
The adjustable range of exposure value is
from EV -3.0 to EV+3.0.
6565
ISO Adjustment
ISO allows you to set the sensitivity of the
camera sensor. Please use a higher ISO
value in darker places and a lower value in
brighter conditions.
(This can be adjustable in
Mode)
ISO00000
0/0000F00.0EV-0.0
Options of ISO value: Auto, 100, 200, 400,
800, 1600 and 3200.
Shutter Speed Adjustment
For shutter speed, the camera may
automatically set the aperture value
corresponding to the manually set shutter
speed so as to obtain a most suitable
exposure value. The movement of object
may be shown by adjusting the shutter
speed. High shutter value can help you
more clearly capture fast moving objects,
while low shutter value can better show
the movement of objects. (This can be
adjustable in
Mode)
F00.0EV-0.0
ISO00000
0/0000
6666
Aperture Adjustment
You can adjust the aperture size value.
Selecting a large aperture opening will
emphasize the point of focus and show
a blurry background and foreground. A
small aperture opening will keep both
the background and main object in clear
focus. (This can be adjustable in
Mode)
F00.0
ISO00000
EV-0.0
0/0000
Using Quick Recording
In photo shooting mode, press the
button to begin recording video.
00:00:00
00/15
15 pictures at most can be taken by
pressing the shutter when recording.
The sizes of images taken are as below
when playing them back:
FHD -> 2M
HD -> 1M
DVD -> VGA
Once you are inished, press the
button again to stop recording. The
camera will store the video and return to
the shooting screen.
6767
“i” Button Function Menu
Functions that can be enabled are
different under each mode.
Mode:
The image color setting allows you to
select different effects.
1. Press the
button to select the Image
color setting menu.
Normal
2. Press the [ ]/[ ] button to
select the image color setting options.
Normal
Vivid
Black and White
Sepia
Partial Color-Red
Partial Color-Yellow
Partial Color-Blue
Partial Color-Green
Dreamy
Vignetting
EKTACHROME Film
KODACHROME Film
KODACOLOR Film
Salon
Punk
Negative
Relection
Sketch
Fish Eye
4 Grids - Stylish(2M)
Fish Eye effect is not available when
shot size is 20M.
68
Using the Lens Function Ring
There is a lens function ring lever in one side
of the lens. Moving it up and down can switch
among ZOOM/AF, SMART and MF mode.
Zoom/AF Mode
Rotate the lens function ring for optical zoom.
1. Switch the lens function ring lever to
position
.
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
2. Rotate the lens function ring to
optically zoom the object.
ISO00000
0/0000F00.0EV-0.0
x3.0
Rotating the lens function ring in
Zoom/AF mode is only for optical
zoom.
6969
Function Ring (Smart) Mode
Rotate the lens function ring to set
parameters of aperture, shutter, ISO, EV,
etc.
1. Switch the lens function ring lever to
position
.
2. Rotate the lens function ring or rolling
the jog dial to select options
needed.
ISO00000
EV+0.0
EV+0.3
EV+0.7
EV-0.3
EV-0.7
EV-0.0
F00.0
0/0000
3. Press the button to complete the
setting and enter shooting screen.
The selection of functions of Function
Ring (Smart) in the menu is needed
before using Function Ring (Smart)
mode. The default setting is Normal.
(See P91
for details)
Options Referred Pages
Normal P64
Aperture Priority P66
Shutter Priority P65
EV P64
ISO P65
Continuous Shot P62
Color P67
White Balance P60
Image Size P82
Expo Metering P79
Flash P58
AF Area P55
7070
MF(Manual Focus) Mode
Rotate the lens function ring for manual
focus.
1. Switch the lens function ring lever to
position
.
ISO00000
0/0000F00.0EV-0.0
00:00:00
0000
2. If the lens function ring is operated
or rolling the
jog dial, the focus
enlargement frame will appear on
the LCD. After clear focus is achieved
through manual adjustment, press the
button to close the focus enlargement
frame. The camera will return to the
normal shooting screen. Semi-pressing
the shutter button will have no effect;
you need to fully press the shutter button
to take a normal photo.
ISO00000
0/0000F00.0EV-0.0
10
cm
00:00:00 0000
Manual focus works only under the
mode.
The MF assist needs to be enabled in
the menu before it will function. (See
P85 for details)
71
Viewing Photos and Videos
PLAYBACK
For viewing taken photos and videos on the LCD:
1. After pressing the
button, the last photo or video clip taken will be displayed on
the LCD.
2. Press the [ ]/[ ] button to scroll through the photos or video clips stored in the
built-in memory or on the Memory Card.
3. To play a selected video clip, press the button to enter the movie playback mode.
An operation guide appears on the screen when playing back a video. Press the
appropriate buttons to enable the corresponding functions.
00:00:0000:00:00
00:00:0000:00:00
Under Playback Paused
Pause
Rewind
Fast Forward
Clockwise Volume Up
Counterclockwise
Volume Down
Volume
Mute
Play
Frame Backward
Frame Forward
Cancel Playback
72
Thumbnail View
When in Playback Mode, rotate the Zoom
lever counter to the position to
display thumbnail images of the photos
and videos on the screen.
W Zoom Out T Zoom In
1. Slide the Zoom lever to switch
between 3x3 and 4x4 thumbnails.
Select index mode
Select index mode
2. Press the [ ]/[ ]/[ ]/
[ ] button to select a picture or
video clip to view and press the
button to restore it to the original size.
3. As shown in the picture, press the
button to select index mode.
4 options in [ Index Mode ] :
When the icon
appears, it means
this is a video ile.
When the icon
appears, it means
this is a continuous group ile.
73
Using Zoom Playback (for still pictures only)
When playing back photos, you can also use the zoom lever to zoom in on the photos 2
to 8 times their original magniication.
1. Press the
button to switch to playback mode.
2. Press the [
]/[ ] button to select a picture on which to use the zoom feature..
3. Rotate the Zoom lever to
position to zoom in.
4. Rolling the
jog dial clockwise to zoom in and counterclockwise to zoom out.
5. The bottom right corner of the LCD will display the number of times the image is
magniied and area of the photo shown.
x2
6. Press the [ ]/[ ]/ [ ]/[ ] button to navigate and select a portion of
the photo to be zoomed in on.
7. Press the button to return the image to its original scale.
Movie images cannot be magniied.
x2
74
High speed (VGA) and fast (2M) can make Continuous Shot for group image playback.
1. Press the
button to enter playback screen.
2. Press the [
]/[ ] button to select continuous group.
3. Press the
button to start playback.
0000
0000
000-00000000/00/00
0000
Thumbnail3x3
000-00000000/00/00
Continuous Shot Group Playback
Cont. Group Playing Pause
Play
Previous Photo (loop available
only in continuous group)
Next Photo (loop available only in
continuous group)
Cancel Play (back to 1:1 playback
for continuous group)
Pause
Cancel Play (back to 1:1
playback for continuous
group)
Playing
Pause
75
Panoramic animation playing is to play full size image in accordance with the shooting
direction. After playing, it will automatically return to the static screen of panoramic
image.
1. Press the
button to enter playback screen.
2. Press the [
]/[ ] button to select animated panoramic photos.
3. Press the
button to play in selected shooting direction.
000-00000000/00/00
Thumbnail3x3
In the process of panoramic animation playback, press the [ ] button to stop
playing and return to the playback screen.
Picture will not be rotated during panorama play or pause.
Animation Panorama Play
Pause
Cancel Play
Video Panorama
Playing
Pause
76
Exit
Exit
Type 1: Slow-in and slow-out
Type 2: Separate in middle and
move off to the left and
right
Type 3: Separate into blocks and
spin in
This setting allows you to view all the
stored images as a slideshow.
1. Press the
button to enter playback
screen.
2. Rotate the Zoom lever counter to the
position to display thumbnails 3x3
and then press the button to select
the index mode.
Slide show
Back
3. Press the [ ]/[ ] button to
select slideshow playing and then
press the button to enter slide
option.
4. Press the [ ]/[ ] button to
select play effect and then press the
button to conirm.
Slideshow
77
Deleting Photos and Videos
In playback mode, press the [ ] button to delete your photos and videos.
To delete photos or videos:
1. Press the
button to switch to playback mode.
2. Press the [
]/[ ] button to select the photos or videos to be deleted.
3. Press the [
] button and the deletion screen is displayed.
4. Press the [ ]/[ ] button to select [Delete One] or [Exit] and press the
button to conirm.
Erased photos/video clips cannot be recovered.
Please refer to page 98 for instructions on deleting more than one image at a time.
78
Shooting Menu
USING THE MENUS
Mode:
1. In shooting mode, press the button
to enter the shooting menu.
12 options in [ Shooting Menu ]:
P60)
Mode)
(Adjustable only in Mode)
2. Press the [
]/[ ] button to
select the shooting menu to be set.
3. Press the [
]/[ ] button or
rolling the jog dial to select options
of the shooting menu to be set and
then press the button to conirm.
Refer to the following pages for more
details about each setting.
Functions that can be enabled are
different under each mode.
7979
OIS (Optical Image Stabilization)
This mode can help reduce photo blur
caused by unintentional shaking, or low
light.
OIS: On
OIS: Off
OIS: On
Use this image stabilization mode in
dark environments.
Shooting in a windy or unstable
environment (such as a moving
vehicle) may cause blurry images.
You may not need OIS when using a
tripod.
Expo Metering
Use this setting to select the “target”
size of the camera’s ield of view to be
metered.
Expo Metering: AiAE
Spot
For metering the block
displayed in the center of the
screen.
Center
For metering the object in the
center of the screen.
AiAE (Artiicial Intelligence AE)
For automatically selecting
the central and surrounding
metering to weight a proper
metering value.
8080
Beautiier
Select the effect for Face Beautiier Mode.
Beautifier:Effect 1
Skin Soften
Effect 1: Skin Soften
Effect 2: Skin Soften
+ Eye Brightening
Effect 3: Skin Soften
+ Eye Brightening
+ Eye Enlargement
Select Scene
Select the scene mode under the SCN
mode.
Select Scene
.
81
Mode:
1. Press the button, press the [ ]/
[ ] button to select .
2. Press the
button to enter the menu.
3. Press the [
]/[ ] button to select
.
6 options in [Shoot Settings 1]:
Functions that can be enabled are
different under each mode.
Shoot Setting1
4. Press the [ ]/[ ] button to
select the item to be set and press the
button to enter the menu.
5. Press the [
]/[ ] button
to select an option and press the
button to conirm.
82
Image Size
The Size setting refers to the image resolution in pixels. A higher image resolution allows
you to print that image in larger sizes without degrading the photo image quality.
Image Size
Movie Size
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
30f
p
s
G
Fin
e
Off
O
ff
Off
Exi
t
I
ma
ge
M
ovi
e
Q
uali
t
M
F A
s
A
F A
s
Digi
t
a
Se
Image Size
18M-3:2
15M-16:9
10M
5M
3M
20M
The larger the number of recorded pixels, the larger the ile size and the fewer iles
that can be saved on your memory card.
83
Movie Size
Set the image resolution used during video recording.
Image Size
Movie Size
20M
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
I
mag
e
M
ovi
e
20M
30
fps
Q
uali
t
G
Fin
e
M
F A
s
O
ff
AF
As
Off
Di
g
it
a
Off
Exi
t
Se
Movie Size
1280x720 60fps
1280x720 30fps
640x480 30fps
640x360 120fps
1920x1080 30fps
Total time of video recorded for each setting:
No. Image Pixels
Frames
(fps)
Recommendation
Recording Time
(approximate)
(4GB)
1
1920x1080
*
30 Class 6 30 Minutes
2
1280x720
*
60 Class 6
33 Minutes
3
1280x720
*
30 Class 4
59 Minutes
4 640x480 30 Class 4
105 Minutes
5 640x360 120 Class 6 54 Minutes
84
* The longest recording time is 29
minutes at one time.
When recording in higher pixel
resolutions for extended periods of
time, this can cause the camera to
generate heat. This is not a camera
malfunction.
When the video format is set as
640x360 (120fps), shooting time is 30
seconds, playback time is 2 minutes.
Sound recording is disabled when
640x360 120fps is chosen.
Quality
The Quality setting can be used to adjust
the image compression ratio.
Image Size
Movie Size
20M
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
I
mag
e
M
ovi
e
20
M
30
f
ps
Q
uali
t
G
Fin
e
M
F A
s
O
ff
A
F A
s
O
ff
Di
g
it
a
O
ff
Exi
t
Se
Quality
RAW
JPG Fine
JPG Best
RAW+JPG
Creates two images: one in RAW and
the other in JPG best.
The image ile will contain more data
that can be used for the purpose of
editing on a computer.
85
If RAW or RAW+JPG is selected, the
settings of Colour Effect, Continuous
Shot, Cont.Shot-Fast (2M), Cont.Shot-
High Speed (VGA), HDR and AE Bracketing
cannot be adjusted.
ISO00000
0/0000F00.0EV-0.0
00:00:00 0000
Single
The RAW ile format provides
lossless compression of the image
data, which is not processed by
the camera. The RAW ile may
be opened and modiied using
the image processing software,
PhotoStudio Darkroom, that is
located on the CDROM included
with this camera. PhotoStudio
Darkroom supports Windows 7/8/10
and Mac OS X (V10.8~V10.11).
MF (Manual Focus) Assist
Enables an enlarged focus window during
the use of manual focus to provide the
user better visibility for focus control.
(Adjustable in
mode)
Image Size
Movie Size
20M
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
I
mag
e
M
ovi
e
20
M
30
f
ps
Q
uali
t
G
Fin
e
M
F A
s
O
ff
A
F A
s
O
ff
Di
g
it
a
O
ff
Exi
t
Se
MF Assist
On
Off
8686
AF Assist Beam
In a darker environment, the AF assist
beam setting can be turned on for better
focus.
Image Size
Movie Size
20M
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
I
mag
e
M
ovi
e
20
M
30
f
ps
Q
uali
G
Fin
e
M
F
A
O
ff
A
F A
s
O
ff
Di
g
it
a
O
ff
Exi
t
Se
AF Assist Beam
On
Off
Digital Zoom
This setting is for adjusting digital
zoom. If this function is disabled, only
optical zoom can be used.
Image Size
Movie Size
20M
1920x1080 30fps
Quality JPG Fine
MF Assist
Off
AF Assist Beam
Off
Digital Zoom
Off
Exit
Set
Select
I
mag
e
M
ovi
e
20
M
30
f
ps
Q
uali
G
Fin
e
M
F
A
O
ff
A
F A
s
O
ff
Di
g
it
a
O
ff
Exi
t
Se
Digital Zoom
On
Off
87
Mode:
1. Press the button, press the [ ]
/[ ] button to select .
2. Press the button to enter the menu.
3. Press the [ ]/[ ] button to
select .
6 options in [Shoot Settings 2]:
Shoot Setting 2
4. Press the [ ]/[ ] button to
select the item to be set and press the
button to enter the menu.
5. Press the [
]/[ ] button
to select an option and press the
button to conirm.
Functions that can be enabled are
different under each mode.
88
Date Imprint
Include a Date/Time stamp on the photo
image.
Normal
Function Ring (Smart)
Off
Face Detection
On
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
N
orma
l
Off
On
O
ff
O
ff
Exi
t
Func
t
F
ace
Cust
o
Date
Quic
k
C
ont.
S
e
Date Imprint
Date
Date/Time
Off
2017/04/29 00:00
Quick Review
This option enables a brief review of
images immediately after capture. Each
picture will be displayed on the LCD
screen per the selections below.
Normal
Function Ring (Smart)
Off
Face Detection
On
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
No
rm
al
Func
t
Off
F
ace
On
Cust
o
Date
Quic
k
O
ff
C
ont.
O
ff
Exi
t
Se
Quick Review
1 Sec
2 Sec
Off
3 Sec
89
Continuous AF
Use the Continuous AF setting to be able
to continuously focus automatically when
taking pictures.
Normal
Function Ring (Smart)
Off
Face Detection
On
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
No
rm
al
Off
On
O
ff
O
ff
Exi
t
Func
t
F
ace
Cust
o
Date
Quic
k
C
ont.
Se
Cont. AF
On
Off
Face Detection
For detecting and focusing on faces to
make all faces as clear as possible in
photo mode.
Normal
Function Ring (Smart)
Off
Face Detection
On
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
No
rm
al
Off
On
O
ff
O
ff
Exi
t
Func
t
F
ace
Cust
o
Date
Quic
k
C
ont.
S
e
Face Detection
On
Off
1. Hold the camera steadily and then
focus on the object to detect its face.
A focus frame will appear at the face
on the screen when a face is detected.
90
2. Press the shutter button half-way down
to focus. The LCD will show a green
focus frame when the subject is in
focus.
1/50F2.9
3. Press the shutter button all the way
down to take pictures.
The closed eyes detection is usually
on. If the camera detects in the
course of quick review there is a
face with eyes closed, a prompt of
closed eyes will appear
.
Custom Settings
Custom settings stores the current movie
shooting mode and its parameters.
The stored mode and parameters are
automatically used in Custom Settings
mode.
Set camera to
Yes
Custom Settings
No
user custom mode
91
Function Ring (Smart)
The options listed below can be set as
Function Ring (Smart) Custom. Once
set, the chosen function can be quickly
adjusted with the lens function ring
during shooting.
Off
Face Detection
Off
Custom Settings
Date Imprint
Quick Review
Off
Cont. AF Off
Exit
Set
Select
Function Ring (Smart) Normal
Off
Off
O
ff
Off
E
x
it
F
ace
Cust
o
D
ate
Quic
k
C
ont.
S
e
Func
t
o
rm
a
l
Function Ring (Smart)
Normal
Aperture priority
Shutter priority
EV
ISO
Continuous Shot
Continuous Shot
92
Playback Menu
Mode:
1. Press the button to display the
playback screen and press the
button to enter the menu.
7 options in [Playback Menu]:
Menu
Display Mode
Rotate
Color
HDR
Touch-Up
Resize
2. Press the [
]/[ ] button to
select the playback desired and press
the button to enter.
3. Press the [
]/[ ] button to
select an option and press the
button to conirm.
Refer to the following pages for more
details about each setting.
Menu
7 options in [ Menu ]
(See P81 for details)
(See P87 for details)
(See P97 for details)
General Settings
(See P101 for details)
File Settings
(See P104 for details)
(See P108 for details)
Wi-Fi Settings
(See P41 for details)
9393
Display Mode
Date Folder
Date Mode: Arranged by date.
Back
Normal Mode: Display all images.
Date Mode: Arranged by date.
Cont. Photo Mode: Arranged by
Cont. Photo Group.
Slide Show
The Date Folder is displayed in date
order based on photo shooting date/
time.
If there is no continuous shot image
ile in memory, continuous photo
mode cannot be enabled.
Rotate
You can use this setting to change the
orientation of the picture.
Exit
: Exit
: Turn Left
: Turn Right
Videos and panoramic pictures
cannot be rotated.
The rotated picture ile will replace
the original photo.
94
Vignetting
Salon
Punk (4M)
Negative (8M)
Relection
Fish Eye
4 Grids - Stylish (2M)
In playing back single photos, press
the button to enter the color
effect setting menu.
Fish Eye effect is not available when
shot size is 20M.
Color
This setting allows you to change the
picture color effect. The ile is saved as a
new photo and stored in memory together
with the original photo.
+^OZ
Exit
Vivid
Black and White
Sepia
Partial Color-Red
Partial Color-Yellow
Partial Color-Blue
Partial Color-Green
Dreamy
95
HDR
With the HDR function, pictures that
are overexposed may be corrected to
optimize the highlights and lowlights
captured to more accurately represent
the actual scene.
Exit
: Exit
: HDR
Select with HDR :
000-00000000/00/00
Thumbnail3x3
After using the HDR function, the
image will be saved as a new ile and
the original ile is still stored in the
memory.
9696
Select with touch-up:
Thumbnail3x3
000-00000000/00/00
Touch-Up
The playback beauty feature allows for
beautiication using three individual
effects.
Exit
: Exit
: Red-Eye Reduction
: Skin Soften
: Eye Brightening
: Eye Enlargement
The Touch-Up referred to is the
individual use of three effects. Beauty
Mode allows you to select one, two,
or all three of the effects combined.
97
Resize
This setting allows you to resize a picture
to a particular resolution and saves it as a
new picture.
Exit
: Exit
: Resize to 1024x768
: Resize to 640X480
Only for adjusting pictures with
high resolution to those with low
resolution.
Sizes of photos taken in panorama
mode or rotated cannot be adjusted.
Mode:
1. Press the button, press the [ ]
/[ ] button to select .
2. Press the
button to enter the menu.
3. Press the [
]/[ ] button to
select .
5 options in [ Playback Settings ]:
4. Press the [
]/[ ] button to
select the item to be set and press the
button to enter the menu.
5. Press the [
]/[ ] button
to select an option and press the
button to conirm.
Refer to the following pages for more
details about each setting.
Playback Settings
98
Protect
To prevent any pictures or videos from
being accidentally erased, use this setting
to lock one or all of the iles.
Play Slide Show
Protect
Delete
DPOF
Trim
Exit
Set
Select
Play
S
Prote
c
D
e
l
e
t
e
DPO
F
Tri
m
Exi
t
Se
Protect
One
Date Folder
Cont. Group
All
Reset
Lock the selected photo or video
if they are unprotected; unlock the
selected photo or video if they are
protected.
Protect all photos in the Date Folder.
Protect all photos in the Cont.
Group.
Lock all photos or videos.
Cancel all locked photos or videos.
Delete
You can delete one or all photo/video
iles.
Play Slide Show
Protect
Delete
DPOF
Trim
Exit
Set
Select
Exi
t
P
la
y
S
Pr
o
t
e
Dele
t
e
DP
OF
T
ri
m
Se
Delete
Date Folder
Cont. Group
All
One
Delete one photo or video.
Delete all photos in the Date Folder.
Delete all photos in the Cont.
Group.
Delete all photos or videos.
99
The “ ” indicator means a ile
is protected. File protection must
be removed before a ile can be
deleted.
Deleting iles will cause DPOF
settings to be reset.
When one photo in the Cont. Group
and Date Folders is protected, it will
be kept but any other photos will be
deleted.
Deleted iles will be permanently
deleted and will not be able to be
recovered or restored.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile
and select a group of pictures that you
would like to print and will save your
selection on the memory card so that you
can use the memory card to print without
having to individually specify the photos
you want to print.
Play Slide Show
Protect
Delete
DPOF
Trim
Exit
Set
Select
Exi
t
Pla
y
S
Pr
o
t
e
Dele
t
e
DP
OF
T
rim
Se
DPOF
All
Reset
One
The printer that supports DPOF is
needed for photo printing.
100100
Trim
The Trim setting allows you to crop photos
and save them as new pictures.
1. Select [Yes] to conirm trim. Toggle the
zoom lever or rolling the
jog dial to
select the aspect ratio and press the [
]/[ ]/[ ]/[ ] buttons
to adjust the part you want to trim.
Yes
Back
2. Press the button and the [Save
change?] prompt appears. Select [ ]
to change and save the picture. Select [
] to cancel changes and return to the
trim prompt screen.
The image cannot be clipped/trimmed
again once it has been clipped to
640X480.
Videos, RAW iles cannot be trimmed.
The picture after trimming cannot be
trimmed again.
Play Slide Show
This setting allows you to view all the
stored images as a slideshow.
Play Slide Show
Protect
Delete
DPOF
Trim
Exit
Set
Select
E
x
it
Play
S
P
rote
De
l
e
t
e
D
P
OF
Trim
Se
Play Slide Show
Still Captures
Videos
All Files
Cont. Group
To display and play back all images
in memory card.
To display and play back images of
photo iles in memory card.
To play back movies on memory
card.
To only play back images arranged
by cont. group in memory card.
101
General Settings
Mode :
1. Press the
button, press the [ ]
/[ ] button to select .
2. Press the
button to enter the menu.
3. Press the [
]/[ ] button to
select .
6 options in [General Settings] :
Sound Settings
Power Saver
anguage
World Time
Date & Time
Brightness
4. Press the [
]/[ ] button to
select the item to be set and press the
button to enter the menu.
5. Press the [
]/[ ] button
to select an option and press the
button to conirm.
Refer to the following pages for more
details about each setting.
102
Power Saver
This setting allows you to save power
and get the maximum possible running
time for your camera's batteries. Turn the
LCD and camera off automatically after a
consecutive period of inactivity.
Sound Settings
Power Saver
Language
World Time
Home
Date & Time
English
LCD Brightness
2017.04.29 00:00
ExitSet
Select
Off
Auto
Sound
Power
Langu
a
W
o
rl
d
T
o
m
e
Date
&
g
lish
LCD B
00
:
00
Exi
t
S
el
e
Of
f
Au
t
o
Power Saver
Auto
Normal
Best
Power
Saver
LCD power
off time
Turn off time
Auto 3 min 5 min
Normal
1 min 3 min
Best 30 s
1 min
Sound Settings
With this setting you may adjust the sound
volume.
Press the [
]/[ ] button to adjust
the volume and press the button to
conirm our setting.
Sound Settings
Volume
Exit
Select
Set
103
Language
Refer to the “Reset your language” section
on page 25.
World Time
The World Time setting is a useful
function for your overseas trips. This
feature enables you to display the local
time on the LCD while you are abroad.
1. Press the [
]/[ ] button to
select the departure place ( ) and
destination ( ) ields.
2. Press the [
]/[ ] button to
select a city located in the same time
zone as that of the ield. Press the
button to conirm settings.
Date & Time
Refer to the “Reset Date/Time” section on
page 26.
LCD Brightness
Use this setting to adjust the brightness of
your LCD.
Press the [
]/[ ] button to adjust
the brightness of screen and press the
button to conirm.
LCD Brightness
Select
Exit
Set
104
Mode:
1. Press the
button, press the [ ]
/[ ] button to select .
2. Press the
button to enter the menu.
3. Press the [
]/[ ] button to
select .
5 options in [File Settings] :
File Settings
4. Press the [ ]/[ ] button to
select the item to be set and press the
button to enter the menu.
5. Press the [
]/[ ] button to
select [Yes] or [No] and press the
button to conirm.
Refer to the following pages for more
details about each setting.
105105
Format
Please note: formatting enables you to delete all contents on the memory card and
camera’s built-in memory, including protected photo and movie iles.
Doing so will clear all data.
No
Yes
Format
If you select [Yes] the camera formats its memory.
IIf there is no memory card in the camera, the built-in memory will be formatted; if
there is a memory card, only the memory card will be formatted.
106
Copy to Card
Use this setting to copy the iles stored in
the built-in memory to a memory card.
Copy files from built-in memory to
No
Yes
Copy to Card
the memory card.
If there is no card available in the
camera, this function will not be
displayed.
File Numbering
After you take a picture or video clip,
the camera will save it with a sequential
number. You can use this to reset the ile
numbering to 1.
Create a new directory and
No
Yes
File Numbering
reset the file number.
107
Version
Use this setting to view the current
camera irmware version.
FW Version: X.XX
<KXYOUT
When there is a new irmware version in
the memory card, select [Yes] to update.
Current Ver: X.XX
New Ver: X.XX
Update Firmware?
No
Yes
Version
Reset Settings
Use this setting to restore the camera to
its original default settings.
Reset camera settings to
No
Yes
Reset Settings
factory defaults.
108
Connecting to a Computer
You can use a Micro USB cable to connect
the camera and copy (transmit) photos to
a computer, printer or other device.
Setting the USB Mode
The camera’s Micro USB port can be
used to connect to either a computer or
a printer. The following steps will allow
you to ensure that the camera is correctly
conigured to connect with a PC.
1. Press the
button, press the [ ]
/[ ] button to select and
press the button to enter the menu.
2. Press the [
]/[ ] button to
select .
3. Press the [
]/[ ] button to
select [USB] and press the button
to enter the menu.
CONNECTION SETTINGS
4. Press the [
]/[ ] button to
select [PC] and press the button to
conirm.
USB
TV-System
PC
NTSC
HDMI CEC Control
Off
Exit
Set
Select
PC
N
TSC
O
f
f
Exit
US
B
T
V-S
y
H
DMI
Se
USB
PC
Printer
109109
Transferring Files to your Computer
The computer will automatically detect
the camera as a removable drive. Double-
click the “My Computer” icon on the
desktop to locate the removable drive and
to copy folders and iles in the drive to a
directory on your PC as you would copy
any typical folder or ile.
Follow the steps below to connect the
camera to a computer:
1. Make sure the computer is turned on.
2. Connect one end of the supplied Micro
USB cable to the Micro USB port on
your camera.
3. Connect the other end of the cable
to an available USB port on your
computer.
4. After the transmission is complete,
disconnect the micro USB cable
according to your computer
manufacturer's instructions specifying
how to safely remove USB devices.
110
3. Press the [ ]/[ ] button to
select [USB] and press the button
to enter the menu.
4. Press the [
]/[ ] button to
select [Printer] and press the button
to conirm.
USB
TV-System
Printer
NTSC
HDMI CEC Control
Off
Exit
Set
Select
US
B
TV-Syste
m
P
r
i
nter
NTS
C
HDMI
C
E
C
C
ontro
l
Off
E
x
it
S
et
S
elec
t
USB
PC
Printer
After the camera is reset, it will
switch to PC mode automatically
from USB mode.
See “Using the PICTBRIDGE™ Menu“
section on page 112.
PICTBRIDGE™ technology allows printing
on the photos saved in the memory card
by a printer.
To ind out if a printer is PICTBRIDGE™
compatible, simply look for the
PICTBRIDGE™ logo on the packaging
or check the owner's manual for
speciications. With the PICTBRIDGE™
function on your camera, you can
print the captured photos directly to a
PICTBRIDGE™ compatible printer using
the supplied Micro USB cable, without the
need for a PC.
Setting the USB Mode
The camera’s Micro USB port can be set
to connect with either a PC or a Printer,
the following steps will ensure that the
camera is correctly conigured to connect
with a printer.
1. Press the
button, press the [ ]
/[ ] button to select and
press the button to enter the menu.
2. Press the [
]/[ ] button to
select .
Connecting to a PICTBRIDGE™ Compatible Printer
111111
Connecting to your Printer
1. Make sure the printer is turned on.
2. Connect one end of the supplied Micro
USB cable to the Micro USB port on
your camera.
3. Connect the other end of the cable to
the USB port on the printer.
If the camera is not connected to a
PICTBRIDGE™ compatible printer, the
following error message will appear on
the LCD.
Connect failed
The error message above will
also appear if the USB mode is
set incorrectly, in which case you
should disconnect the Micro USB
cable, check the USB mode settings,
ensure that the printer is turned on,
and then try connecting the USB
cable again.
112
After setting the USB mode to printer, the
PICTBRIDGE™ menu will appear.
PictBridge
Exit
Print (without Date)
Print Index
Print DPOF Images
Print (with Date)
Select
Set
Press the [ ]/[ ] button to
select a menu item and press the
button to enter the item.
Refer to the following sections for more
detailed information on each setting.
Print (with Date)
If you have set the date and time on
your camera, the date and time will be
recorded and saved with each photo you
take.
1. In the PICTBRIDGE™ menu, select [Print
(with Date)] and the screen as shown
below appears.
Back
01
2. Press the [ ]/[ ] button to
select a photo to be printed.
Using the PICTBRIDGE™ Menu
113113
Print (without Date)
Use this setting to print the photos
without dates on them.
1. In the PICTBRIDGE™ menu, select
[Print (without Date)] and the screen as
shown below appears.
Back
01
2. Press the [ ]/[ ] button to
select a photo to be printed.
3. Press the [
]/[ ] button
to select the number of copies for the
currently displayed photo.
4. Press the
button and the following
screen will appear.
3. Press the [ ]/[ ] button
to select the number of copies for the
currently displayed photo.
4. Press the
button and the following
screen will appear.
Print (With Date)
PictBridge
Yes
Cancel
5. Select [Yes] and press the button
to conirm; select [Cancel] to cancel
printing.
114
Print Index
You can print all photos in the camera via
this function.
1. In the PICTBRIDGE™ menu, select [Print
Index] and the screen as shown below
appears.
Print Index
PictBridge
Yes
Cancel
2. Select [Yes] and press the button
to conirm; select [Cancel] to cancel
printing.
Print (Without Date)
PictBridge
Yes
Cancel
5. Select [Yes] and press the button
to conirm; select [Cancel] to cancel
printing.
115
Exit
Select [Exit] to exit the PICTBRIDGE™
menu. At this time, the message [Remove
USB Cable!] will appear on the screen.
Remove USB Cable!
Disconnect the Micro USB cable from the
camera and printer.
Print DPOF Images
To use DPOF printing, you must select
your photos for printing using the DPOF
settings before hand. See “DPOF” section
on page 99.
1. In the PICTBRIDGE™ menu, select
[Print DPOF Images] and the screen as
shown below appears.
Print DPOF Images
PictBridge
Yes
Cancel
2. Select [Yes] and press the button
to conirm; select [Cancel] to cancel
printing.
116
Video System
You can use the AV cable (which should
be purchased separately) to connect the
camera and the television for setting up
the video output. Connect one end of the
AV cable to AV port of the camera, and
connect the other end to AVOUT port of
the television. To adjust the format of the
video output system according to your
requirements:
1. Press the
button, press the [ ]
/[ ] button to select and
press the button to enter the menu.
2. Press the [
]/[ ] button to
select
.
3. Press the [
]/[ ] button to
select [TVSystem] and press the
button to enter the menu.
4. Press the [
]/[ ] button to
select [NTSC] or [PAL] and press the
button to conirm.
USB Mode
TV-System
PC
NTSC
HDMI CEC Control
Off
Exit
Set
Select
PC
N
T
SC
O
f
f
E
x
it
U
SB
M
T
V-
Sy
HDMI
S
e
TV-System
PAL
NTSC
NTSC: English, Chinese (Traditional),
Japanese, French, Korean,
Russian, Vietnamese, Greek,
Hungarian
PAL: German, Spanish, Italian,
Chinese (Simpliied),
Portuguese, Swedish, Danish,
Finnish, Indonesia, Norwegian,
Dutch, Turkish, Polish, Thai,
Croatian, Czech, Arabic, Hindi
The video output system changes
based on the selected language.
117
Supported HDMI Connections
HDMI (High Deinition Multimedia
Interface), is a fully digital audio/video
transmission interface, through which
uncompressed audio and video signals
are transmitted.
Connecting HDMIReady TV
1. Use the cable with high resolution
output terminal (which should be
purchased separately) to connect the
camera to the television which meets
HDMI standards.
2. The camera will be automatically
detected by the TV.
3. After connecting via HDMI, the camera
enters Playback Mode.
Make sure the camera and the TV are
both turned on before connecting.
HDMI (Type D)
118
HDMI CEC Control
After connecting the camera with TV-
System, you may view pictures taken with
the camera on the TV screen and operate
the camera with your TV remote control
to view and edit all images.
USB Mode
TV-System
PC
NTSC
HDMI CEC Control
Off
Exit
Set
Select
PC
N
T
SC
O
f
f
E
xi
t
US
B
M
T
V-
Sy
HDMI
Se
HDMI CEC Control
Off
On
It is required that the TVSystem
supports HDMI CEC.
After the camera is successfully
connected with TVSystem, other
buttons of the camera except the
Power button cannot work, with the
LCD staying dark.
Please refer to TV manual for relative
settings of TVSystem.
Introduction on Icons
1. Info Hiding/Display
2.
Zoom-in
: Zoom in Images
: Zoom out Images
3. Rotate Images
: Only Turn Left
4.
Image Index
: 5*3 Index Playback
: 10*5 Index Playback
: 3*1 Date Folder Index
: 5*3 Cont. Group Index
5.
Back
6. Play Slide Show
7. Button for Switching Between
Previous and Next Images
119119
8. Videos
9. Movie Length:00:00:00
10.
Cont. Group File
11.
First Image Mark
12. 000/000:Current Sorting/Total
Number of Images in Group
13.
:Conirm Effect
14.
:No Change
The following operations are available
during HDMI CEC playback:
Pressing the four-color button on
remote control can enable relative
functions displayed on the TV-
System screen.
Remote control
TVSystem
Red Green
Yellow Blue
120
1:1 Single Playback:
Pressing the left and right arrow
buttons can switch among images.
Zoom-in Playback:
Under the 1:1 single playback mode,
press the red button to zoom in
images; press the red and green
buttons on remote control to zoom out
images.
Rotate:
Under the 1:1 single playback mode,
press the blue button to rotate single
picture.
Index Playback:
Under the 1:1 playback mode, press the
green button to enter index playback;
press the central button to enter image
selection and then the arrow buttons
to select iles you want and inally
press the central button again to back
to the 1:1 single playback.
Under the 5*3 index playback mode,
press the green button to enter index
selection and then the left and right
arrow buttons to select
, , ,
and , and inally press the central
button again to conirm your selection.
Cont. Group Playback:
Under the 1:1 single playback mode,
press the central button to start
playing images in continuous group.
If no images in the camera’s cont.
group, there will appear a prompt of no
pictures if you select on the index
playback interface.
Slide Show Playback:
Under the 1:1 single playback mode,
press the down arrow button to enter
slide show playback. While playing,
you may press the left and right arrow
buttons to directly switch between
previous and next images and the
central button to end playing.
121
Video Play:
Under the 1:1 single playback mode,
select a video and then press the
central button to start playing. While
playing, you may use the arrow buttons
and the central button to perform
operations such as fast forward/
backward, pause, frame forward/
backward, back to play, etc. according
to prompts on the screen.
Panoramic File Play:
Under the 1:1 single playback mode,
select a panoramic ile and then press
the central button to begin playing.
Image Edit:
Multiple edit can be repeated under
image edit mode. Only one picture is
saved inally.
Under the 1:1 single playback mode,
select a picture and then press the up
arrow button to enter image edit and
start detecting face.
Press the up arrow button to do HDR
editing.
Press the down arrow button to delete
one picture.
Press the left and right arrow buttons
to edit the color. 12 effects in total for
selection.
The following beautiier touch-up
functions cannot be enabled until a
face is detected. You may press relative
color buttons to edit.
: Skin Soften
: Eye Enlargement
: Eye Brightening
Availability of edit functions corresponding to
each type of ile (O : Available; X : Unavailable)
HDR Color Beautiier Delete
Normal
(face)
O O O O
Normal
(no face)
O O X O
Panorama X X X O
Video X X X O
122122
HDMI CEC Connection
Function
Full Size
Playback
Zoom-in
Playback
Index
Playback
Video
Play
Cont.
Group Play
Panoramic
File Play
Zoom In O
O
(Movable to
four directions
during zoom-in)
X X X X
Zoom Out X O X X X X
Rotate
O
(turn left
only)
X
X X X X
Play Slide Show O X X O O O
Edit Image O
*1
X X O O O
Info Hiding/
Display
O O X O
*2
O
*2
O
*2
Delete O X X O
*3
O
*3
O
*3
*1 After entering the image edit, relative operation of the beautiier cannot appear until a
face is detected.
*2 It is available before and in playing and during pause.
*3 The function of delete one cannot work until the camera enters image edit mode.
123
USB Mode
TV-System
PC
NTSC
HDMI CEC Control
Off
Eye-Fi
On
Exit
Set
Select
PC
N
T
SC
O
f
f
On
E
xi
t
US
B
M
TV-
Sy
HDMI
Ey
e-
F
S
el
Eye-Fi
Off
On
If the Eye-Fi card is not available
in the camera, this feature is not
displayed.
This camera supports wireless connection
for Eye-Fi memory cards. Enable the Eye-Fi
connection by following the steps below.
1. Press the
button, press the [ ]
/[ ] button to select and
press the button to enter the menu.
2. Press the [
]/[ ] button to
select .
3. Press the [
]/[ ] button to
select [Eye-Fi] and press the button
to enter the menu.
4. Press the [
]/[ ] button to
select [On] or [Off] and press the
button to conirm.
Set Eye-Fi SD Card Connection Mode
124
Image Sensor
Type 1/2.3” BSI CMOS
Effective Pixels 20.68 Megapixels
Total Pixels 21.14 Megapixels
Lens
Focal Length 4.3 mm (Wide) — 279.5 mm (Tele)
35 mm Film Equivalent 24 mm (Wide) — 1560 mm (Tele)
F number F2.9 (Wide) — F6.7 (Tele)
Lens Construction 14 groups 18 elements
Optical Zoom 65x
Focusing Range
Normal: (Wide) 50 cm ~ ∞, (Tele) 250 cm ~ ∞;
Macro: 1 cm ~ ∞ (Wide Only)
Autofocus System TTL Autofocus
Electronic Viewinder Yes (-3~+1 diopter)
Anti-Handshake Optical Image Stabilization
Digital Zoom 4x Digital Zoom (Combined Zoom: 260x)
Product Speciications
APPENDICES
Design and speciications are subject to change without notice.
125125
Number of
Recording
Pixels
Still Image
(4:3)
20MP: 5184 × 3888
10MP: 3648 × 2736
5MP: 2592 × 1944
3MP: 2048 × 1536
0.3MP: 640 × 480
(3:2)
18MP: 5184 × 3456
(16:9)
15MP: 5120 × 2880
2MP: 1920 × 1080
Movie
1920 × 1080 (30fps), 1280 × 720 (60fps), 1280 × 720 (30fps),
640 × 480 (30fps), High-Speed Movie: 640 × 360 (120fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File Format
Still Image JPEG (Fine, Standard), RAW, RAW+ JPEG (Fine)
Movie MOV [Image: H.264; Audio: Linear PCM (Stereo)]
Shooting Modes
Auto Mode, Program AE, Shutter priority, Aperture priority,
Manual Mode, Face Beautiier, Wi-Fi Mode, Scene Mode,
Movie Mode, Custom Settings
Scene Mode
Auto Scene, Panorama Mode, Handheld Night, Multi
Exposure, Cat/Dog, Snow, Party, Sport, Night Portrait,
Portrait, Children, Landscape, Sunset, Fireworks
Detection Features Face, Smile, Blink, Cat, Dog
Photo Touch-Up
Red-Eye Reduction, Skin Soften, Eye Brightening, Eye
Enlargement
126
HDR Yes
Scan Panorama Up to 360°
LCD
Display 3.0 inch (920k Pixels)
Angle
Adjustment
Yes
Image Auto Rotation Yes
ISO Sensitivity Auto, ISO100/200/400/800/1600/3200
Focus Mode Single AF, Continuous AF, Object Tracking, Manual Focus
Focusing Area Selection
Single Area Focusing, 25Area-Focusing, Face Detection,
Manual Area Focusing
Exposure Metering
Method
Artiicial Intelligence AE (AiAE), Center-Weighted Average,
Spot (Fixed to Center of Frame), Face AE
Exposure Control Method
Program AE (AELock Available), Shutter Prior AE, Aperture
Prior AE
Exposure Compensation ±3 EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 30 Seconds
Continuous Shooting Yes
Playback Modes
Single, Index (9/16 Thumbnails), Slide Show, Date, Burst
Shooting, Zoom (Approx. x2 ~ x8)
127
White Balance Control
AWB, Daylight, Cloudy, Fluorescent, Fluorescent H,
Incandescent, Manual WB, Color Temp. (1900K ~ 10000K)
Flash
Flash Method Pop-up (Auto)
Flash Modes
Force Off, Fill Flash, Flash Auto, Red-Eye Reduction, Slow
Sync., Slow Sync. + Red-Eye Reduction
Recording Media
Internal Memory: Approx. 15MB
SD/SDHC/SDXC Card (Up to 256GB Support) [MMC Card
Not Supported]
Multi-Language Support 27 Languages
Jacks AVOUT/USB 2.0 (Micro 5 pin USB), HDMI (Type D)
Eye-Fi Support Yes
Wi-Fi Yes
(802.11 b/g/n)
Remote Viewinder Yes (via iOS/ANDROID smart device)
Power
Rechargeable Li-ion Battery LB070, 7.4V 1000mAh, In-
Camera Charging
Shooting Capability
(Battery Performance)
Approx. 400 Shots (Based on CIPA Standards)
Operation Environment Temperature: 0 ~ 40°C, Humidity: 0 ~ 90%
Dimensions (W × H × D) Approx.
125.9 ×89.0 × 113.6 mm (Based on CIPA Standards)
Weight Approx.
602 g (Body only)
128
Prompts and Warning Messages
Message Description Action
Warning!
Battery exhausted.
Warning before power off
when the camera battery is
exhausted.
Displaying that it will power
off after 2 seconds.
Built-in memory error!
In the case of built-in memory
error.
Disappear after 2 seconds
and return to shooting.
Warning! Do not turn
off your camera during
update!
The message appears during
the irmware update process.
The message disappears
after the camera update and
restart.
Battery temperature is
too high.
Battery temperature is too high.
The message will disappear
after 2 seconds.
Let the battery cool before
attempting to use the camera
again.
Please update
irmware after the
battery is fully
charged!
The irmware cannot be
updated when power is
insuficient.
Remove the message after 2
seconds and returning to the
update screen.
129129
Message Description Action
Cannot change
settings under this
mode.
Appears during shooting mode if a
function can not be set by rotating
the function ring.
Remove the message
after 2 seconds and
return to shooting.
Improper alignment.
Please try again.
The offset is too big for panorama
shooting.
Remove the message
after 2 seconds and
return to shooting.
Connection Failed!
In the case of failing to connect to a
PC or a printer.
In the case of failing to connect to a
TV-system (including HDMI).
Remove cable and retry
connection
In this capture ********
Still size limited to
** M
After choosing the image size in the
Function Ring (Smart), this message
may occur when the still size limit is
reached.
Remove the message
after 2 seconds and
return to shooting.
Capture reached
maximum limit
Press the shutter to capture images
in recording a video. If the number
of images captured exceeds 15,
there will be a prompt if you press
the shutter again.
The message will
disappear in 2 seconds
with no inluence to
video recording.
130
Message Description Action
Write Protect !
In the case that there is lock
protection for the card when
saving the image.
Disappear after 2 seconds
and return to the previous
image.
Card Full !
In the case that the camera
detects the card capacity is
insuficient when turning on or
pressing the shutter.
Disappear after 2 seconds
and return to the previous
image.
Memory Full !
In the case that the camera
detects the memory capacity is
insuficient when turning on or
pressing the shutter.
Disappear after 2 seconds
and return to the previous
image.
Exceeded maximum
folder number.
When the folder number in the
card exceeds the maximum folder
number (999), the time for turning
on and reading will be too long, it
will prompt the message until the
reading is completed.
The message will end after
the camera processing is
complete.
Card Error !
The card cannot be recognized
after being formatted.
Normal display.
Card is not
formatted.
When the card reading error
occurs,the message of not
formatted will be displayed.
Disappear after 2 seconds
and enter the formatting
process.
131
Message Description Action
Slow access
When a card lower than Class 4 is
recording movie above HD, it may be
accessed slowly and the recording
cannot be continued.
Remove the message after
2 seconds and return to
the shooting image.
Cannot write to SD
card.
The recording cannot be continued if
there are problems which may cause
interruption of the recording during
writing to the card or recording in the
process of shooting or recording.
Disappear after 2 seconds
and return to shooting.
No Picture!
When pressing the button there is no
image in the camera or the card.
Disappear after 2 seconds
and return to shooting.
No continuous
group ile.
When it switches from playback mode
to Cont. playback mode, if there is no
continuous group ile in the iles, this
prompt message will display.
Remove the message after
2 seconds and return to
Thumbnail 3x3 mode.
No Red-Eye
Detected!
No red-eye detected when pressing
for red-eye removing in playback
touch-up.
Disappear after 2 seconds
and return to the touch-up
menu.
132132
Message Description Action
Too many pictures for
fast processing.
The image may be unable to enter
the date playback if the image
exceeds the speciication in the
case of date playback.
Remove the message
after 2 seconds and
return to Thumbnail 3x3
mode.
Unable to recognize
iles.
When the format of the ile
viewed is not supported or the
ile is damaged and cannot be
recognized properly.
This message disappears
only after the ile is
deleted.
Protected!
Undeletable!
This message will be displayed
on the image immediately when
executing delete action to the
protected iles.
Disappear after 2
seconds and return to
the previous image.
This image cannot be
edited.
The ile format does not support
editing or the edited ile cannot
be edited again.
Remove the message
after 2 seconds and
return to the original
image.
Cannot edit because no
face detected!
No face image entered into the
touch-up menu.
Remove the message
after 2 seconds and
return to the touch-up
menu.
133
Troubleshooting
Problem Possible causes Solution
Camera does not turn on
The battery has been
depleted.
The battery is not inserted
correctly.
Replace the battery.
Correctly reinstall the
batteries.
Camera turns off
suddenly during
operation
The batteries have been
depleted.
Replace the battery.
The picture is blurred
Camera shakes while taking a
picture.
Turn on OIS Feature.
Please use tripod for high
magniication (above 15X)
optical zoom.
Images and video iles
cannot be saved
The memory card is full.
The memory card is locked.
Use another memory card or
delete unnecessary iles.
Unlock the memory card.
Images will not print from
the connected printer
The camera is not connected
to the printer correctly.
The printer is not
PICTBRIDGE™ compatible.
The printer is out of paper or
ink.
The printer paper is jammed.
Check the connection
between the camera and
printer.
Use a PICTBRIDGE™
compatible printer.
Load paper into the printer or
replace the ink cartridge in the
printer.
Remove the jammed paper.
Saving data to memory
card is slow
Using a memory card below
Class 4 may result in slower
recording times.
Use a memory card with write
Class 4 or higher to improve
performance.
134
Problem Possible Causes Solution
Cannot write to the
memory card
The memory card has been
locked.
Release the write lock
of the memory card or
replace with another card.
Too many movies to
process
The number of pictures or
folders in the memory card
exceed the speciications, so
the playback of data folder can
not be displayed.
Delete unwanted iles.
When shooting with stacked ilters attached, the corners of the photo may turn dark
(vignetting effect) because the ilter holder blocks light from reaching the camera
image sensor; especially, at wide angle zoom control settings. Please take test shots
and review the results when using stacked ilters.
(Filter size : Φ52mm)
Please enter the new password on smart device after changing Wi-Fi password.
Some models of smart device will remember the Wi-Fi password previously entered,
so please clear the old password on smart device manually before connection (For
different models, this operation may be varied, please subject to your user manual).
1
2
iOS devices ANDROID devices
1
2
3
Ver. 1
© 2017 JK Imaging Ltd. All Rights Reserved.
The Kodak and Kodachrome, Kodacolor and Ektachrome trademarks, logo and trade dress are used under license from
Eastman Kodak Company.
All other logos, products or company names that are referred to in this document are trade names, trademarks or registered
trademarks of their holders. The holders are not afiliated with JK Imaging Ltd., our products or our website.
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK
kodakpixpro.com
Made in Myanmar
