Samsung DV42H5600EP/A3-00 dryer User Manual

DV45H6300*

DV42H5600*

Gas and Electric Dryer

User manual

Imagine the possibilities

Thank you for purchasing this Samsung product.

DV6000HA_DC68-03380A-04_EN.indd 1 2014-11-25  4:46:51

English - 2

Content

Safety instructions 4

What you need to know about safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Important safety symbols and precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing your dryer 8

Unpacking your dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

What’s included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Important to installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Basic requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Gas models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Electric models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Location considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Alcove or closet installations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Ducting requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Exhausting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Dryer exhaust tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Gas requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Commonwealth of massachusetts installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting the inlet hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Replacement parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Door reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Final installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Operating instructions, tips 22

Overview of the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Load the dryer properly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Rack dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Child Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Drum Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

DV6000HA_DC68-03380A-04_EN.indd 2 2014-11-25  4:46:51

English - 3

Sound Oﬀ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

My Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Smart Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Vent Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Care and cleaning 32

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Tumbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Stainless steel tumbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Dryer exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Dryer exhaust system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Clean the lint ﬁlter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Special laundry tips 33

Special laundry tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Troubleshooting 34

Check these points if your dryer… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Information codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Appendix 36

Fabric care chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Protecting the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

DV6000HA_DC68-03380A-04_EN.indd 3 2014-11-25  4:46:51

English - 4

SAVE THESE INSTRUCTIONS

Safety instructions

Congratulations on your new Samsung Dryer. This manual contains important information on the installation, use,

and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many

beneﬁts and features.

What you need to know about safety instructions

Please read this manual thoroughly to ensure that you know how to operate the extensive features and functions

of your new appliance safely and eﬃciently. Retain the manual in a safe place near the appliance for future

reference. Use this appliance only for its intended purpose as described in this instruction manual. The Warnings

and Important Safety Instructions in this manual do not cover all possible conditions and situations that may

occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, or operating

your dryer.

Always contact your manufacturer about problems or conditions you do not understand.

Important safety symbols and precautions

WARNING: Hazards or unsafe practices that may result in severe physical injury, death and/or

property damage.

Follow the information in this manual to minimize the risk of ﬁre or explosion or to prevent property

damage, personal injury, or death.

CAUTION: Hazards or unsafe practices that may result in physical injury and/or property damage.

NOTE

These warning signs are here to prevent injury to you and others.

Please follow them explicitly.

After reading this section, keep it in a safe place for future reference.

DV6000HA_DC68-03380A-04_EN.indd 4 2014-11-25  4:46:52

English - 5

01 SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

WARNING - RISK OF FIRE

• Clothes dryer installation must be performed by a qualiﬁed installer.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• Do not install a clothes dryer with ﬂexible plastic venting materials. If ﬂexible metal (foil type) duct is

installed, it must be of a speciﬁc type identiﬁed by the appliance manufacturer as suitable for use with

clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint. These

conditions will obstruct clothes dryer airﬂow and increase the risk of ﬁre.

• To reduce the risk of severe injury or death, follow all installation instructions.

TO REDUCE THE RISK OF FIRE OR EXPLOSION:

• Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning

solvents, or other ﬂammable or explosive substances. They emit vapors that could ignite or explode. Any

material that has been in contact with a cleaning solvent or ﬂammable liquids or solids should not be placed

in the dryer until all traces of these ﬂammable liquids or solids and their fumes have been removed.

There are many highly ﬂammable items used in homes, such as acetone, denatured alcohol, gasoline,

kerosene, some liquid household cleaners, some spot removers, turpentine, waxes, and wax removers.

• Do not dry items containing foam rubber (may be labeled latex foam) or similarly textured rubber-like

materials on a heat setting. Heated foam rubber materials can, under certain circumstances, produce ﬁre by

spontaneous combustion.

WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not turn on the appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

• Installation and service must be performed by a qualiﬁed installer, service agency, or the gas supplier.

DV6000HA_DC68-03380A-04_EN.indd 5 2014-11-25  4:46:52

English - 6

SAVE THESE INSTRUCTIONS

Important safety instructions

WARNING

To reduce the risk of re, electric shock, or injury to persons when using your appliance, follow basic

precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not use the dryer to dry clothes which have traces of any ﬂammable substance, such as vegetable oil,

cooking oil, machine oil, ﬂammable chemicals, thinner, etc., or anything containing wax or chemicals, such as

mops and cleaning cloths. Flammable substances may cause the fabric to catch ﬁre by itself.

3. Do not store or use gasoline or other ﬂammable vapors and liquids near this or any other appliance.

4. Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary when

the appliance is used near children and pets.

5. Before the appliance is removed from service or discarded, remove the door to the drying compartment to

prevent children or animals from becoming trapped inside.

6. Do not reach into the appliance when the drum is moving.

7. Do not install or store this appliance where it will be exposed to the weather.

8. Do not tamper with the internal controls.

9. Do not repair or replace any part of the appliance or attempt any servicing unless speciﬁcally recommended

in the user-maintenance instructions or published in the user-repair instructions that you understand and

have the skills to carry out.

10. Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the

fabric softener or product.

11. Clean the lint screen before or after each load.

12. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.

13. Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.

14. The interior of the dryer and exhaust duct should be cleaned periodically by qualiﬁed service personnel.

15. Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may

contribute to a chemical reaction that could cause a load to catch ﬁre.

16. This appliance must be grounded. See “Electrical requirements” and “Grounding” in the “Installing your dryer”

section.

17. This appliance must be properly grounded. Never plug the power cord into a receptacle that is not grounded

adequately and in accordance with local and national codes. Refer to installation instructions for grounding

this appliance.

18. Ensure pockets are free from small irregularly shaped hard objects and foreign material, i.e. coins, knives, pins,

etc. These objects could damage your dryer.

19. Gas leaks may occur in your system, resulting in a dangerous situation.

20. Gas leaks may not be detected by smell alone.

21. Gas suppliers recommend you purchase and install a UL-approved gas detector.

22. Control board and inlet valve are intentionally not grounded and may present a risk of electric shock only

during servicing. Service personnel - do not contact this part while appliance is energized.

DV6000HA_DC68-03380A-04_EN.indd 6 2014-11-25  4:46:52

English - 7

01 SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

WARNING

Gas Appliances:

WARNING: This product contains chemicals known to the State of California to cause cancer and reproductive

toxicity.

Gas appliances can cause low-level exposure to Proposition 65 listed substances, including but not limited to ,

benzene, carbon monoxide, formaldehyde and soot, substances resulting from the incomplete combustion of

natural gas or LP fuels.

CAUTION

1. Do not sit on top of the dryer.

2. Because of continuing product improvements, Samsung reserves the right to change speciﬁcations without

notice. For complete details, see the Installation Instructions packed with your product before selecting

cabinetry, making cutouts, or beginning installation.

3. Do not wash clothing with large buckles, buttons, or other heavy metal or solid things.

4. Install and use in accordance with the manufacturer’s instructions.

5. All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous. Washing these

items in hot water with extra detergent will reduce, but not eliminate, the hazard. Always use the Cool Down

cycle for these items to reduce their temperature. Never remove these items from the dryer hot or interrupt

the drying cycle until the items have run through the Cool Down cycle. Never pile or stack these items when

they are hot.

6. Take care that children’s ﬁngers are not caught in the door when closing it. This may result in injury.

DV6000HA_DC68-03380A-04_EN.indd 7 2014-11-25  4:46:52

English - 8

Installing your dryer

Unpacking your dryer

Unpack your Dryer and inspect it for shipping damage. Make sure you have received all the items shown below. If

your Dryer was damaged during shipping, or you do not have all the items, contact 1-800-SAMSUNG (726-7864).

WARNING

• The packing materials can be dangerous to children. Keep all packaging material (plastic bags,

polystyrene, etc.) well out of the reach of children.

• To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

What’s included

1 Top cover 4 Filter

2 Control panel 5 Water Inlet

3 Door 6 Duct Exhaust

Accessories

“Y”-connector Short inlet hose Long inlet hose Rubber Washer

DV6000HA_DC68-03380A-04_EN.indd 8 2014-11-25  4:46:53

English - 9

02 INSTALLATION

Important to installer

Please read the following instructions carefully before installing the dryer. These instructions should be kept for

future reference.

WARNING: Remove the door from all discarded appliances to avoid the danger of a child being trapped

and suﬀocating.

Basic requirements

Make sure you have everything necessary for the proper installation

• A GROUNDED ELECTRICAL OUTLET is required.

• A POWER CORD electric dryer (except for Canada).

• GAS LINES (if a gas dryer) must meet national and local codes.

• The EXHAUST SYSTEM must be made of rigid metal or ﬂexible stiﬀ-walled metal exhaust ducting.

Grounding

This dryer must be grounded. In the event of a malfunction or breakdown, grounding the product will reduce the

risk of electrical shock by providing a path of least resistance for the electrical current.

Gas models

Your dryer has a cord with an equipment-grounding conductor and a grounding plug.

• The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance

with all local codes and ordinances.

• Do not modify the plug provided with your dryer – if it doesn’t ﬁt the outlet, have a proper outlet installed by

a qualiﬁed electrician.

• Never connect the ground wire to the plastic plumbing lines, gas lines, or hot water pipes.

Electric models

Your dryer has an optional cord with an equipment-grounding conductor and a grounding plug, which is sold

separately.

• The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance

with all local codes and ordinances.

• Do not modify the plug provided with your dryer – if it doesn’t ﬁt the outlet, have a proper outlet installed by

a qualiﬁed electrician.

• If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be connected to

a permanently grounded metal wiring system, or an equipment grounding conductor must be run with the

circuit conductors and connected to the equipment grounding terminal or lead on the dryer.

DV6000HA_DC68-03380A-04_EN.indd 9 2014-11-25  4:46:53

English - 10

Location considerations

The dryer should be located where there is enough space at the front for loading the dryer, and enough space

behind for the exhaust system. This dryer is factory-ready for the rear exhaust option. To exhaust out the bottom,

right or the left, use the accessory exhaust kit. Instructions are included with the kit. Make sure the room in which

the dryer is located has enough fresh air. The dryer must be located where there are no air-ﬂow obstructions.

For gas dryers, adequate clearance must be maintained as noted on the data plate to ensure adequate air for

combustion and the proper dryer operation.

The dryer must not be installed or stored in an area where it will be exposed to water and/or weather. The dryer

area must be kept clear of combustible materials, gasoline, and other ﬂammable vapors and liquids. A dryer

produces combustible lint. The area around the dryer should be kept lint-free.

Alcove or closet installations

WARNING

• The dryer must be exhausted to the outside to reduce the risk of ﬁre when installed in an alcove or

closet.

• No other fuel-burning appliance should be installed in the same closet as the dryer.

Minimum clearances between the dryer and adjacent walls or other surfaces:

Sides 1 in (25 mm) Rear 5.9 in (150 mm)

Top 17 in (432 mm) Closet front 2 in (51 mm)

AABB

FDE

A 1 in. (25 mm)

B 27 in. (686 mm)

C 17 in. (432 mm)

D 2 in. (50 mm)

E 32.4 in. (823 mm)

F 5 in. (127 mm)

Recessed area

Side view

(closet or conﬁned area)

DV6000HA_DC68-03380A-04_EN.indd 10 2014-11-25  4:46:53

English - 11

02 INSTALLATION

Installation with pedestal

A 38.7 in. (984 mm)

B 53.3 in. (1355 mm)

C 27 in. (686 mm)

53 in. (1345 mm) to

clear open door

E 32.4 in. (823 mm)

F 5 in. (127 mm)

Installation with stacked washing machine and dryer

GH JKL

A 3 in. (76 mm)

B 48 in.² (3100 mm²)

C 24 in.² (1550 mm²)

D 3 in. (76 mm)

E 6 in. (152 mm) *

F 77.5 in. (1968 mm)

G 1 in. (25 mm)

H 27 in. (686 mm)

I 5 in. (127 mm)

J 1 in. (25 mm)

K 32.4 in. (823 mm)

L 8 in. (203 mm)

The front of the closet must have two unobstructed air openings (B, C) for a combined minimum total

area of 72 in² (465 cm²) with a minimum clearance of 3 in. (7.6 cm) at the top (A) and bottom (D).

External exhaust elbow requires additional space (L).

Stacking (MODEL NO: SK-5A)

Samsung’s Washer and Dryer can be stacked to maximize usable space.

The dryer legs need to be removed to stack the Washer and Dryer. You can purchase an optional stacking

kit from your Samsung retailer.

DV6000HA_DC68-03380A-04_EN.indd 11 2014-11-25  4:46:53

English - 12

Ducting requirements

No. of 90° elbows

Weather hood type

4” (10 .16 cm) 2.5” (6.35 cm)

Recommended Use only for short-run installation

Rigid Metallic Flexible* Rigid Metallic Flexible*

0 24.4 m (80 ft.) 12.4 m (41 ft.) 22.6 m (74 ft.) 10.1 m (33 ft.)

1 20.7 m (68 ft.) 11.2 m (37 ft.) 18.9 m (62 ft.) 8.8 m (29 ft.)

2 17.4 m (57 ft.) 10.1 m (33 ft.) 15.5 m (51 ft.) 7.6 m (25 ft.)

3 14.3 m (47 ft.) 9.0 m (29 ft.) 12.5 m (41 ft.) 6.5 m (21 ft.)

* Do not use non-metallic ﬂexible ducts.

• Use a 4 inch (10.2 cm) diameter rigid aluminum or rigid galvanized steel duct.

• Do not use a smaller duct.

• Ducts larger than 4 inches (10.2 cm) in diameter can result in increased accumulation of lint.

• Lint should be removed regularly.

• If a ﬂexible metal duct must be used, use the type with a stiﬀ sheet metal wall. Do not use a ﬂexible duct with

a thin foil wall. A serious blockage can result if the ﬂexible metal duct is bent too sharply.

• Never install any type of ﬂexible duct in walls, ceilings, or other concealed spaces.

• Keep the exhaust duct as straight and short as possible.

• Secure joints with duct tape. Do not use screws.

• Plastic ﬂexible ducts can kink, sag, be punctured, reduce airﬂow, extend drying times, and aﬀect the dryer

operation.

• Exhaust systems longer than recommended can extend drying times, aﬀect machine operations, and collect

lint.

• The exhaust duct should end with an exhaust hood with a swing-out damper to prevent back drafts and

entry of wildlife. Never use an exhaust hood with a magnetic damper.

• The hood should have at least 12 inches (30.5 cm) of clearance between the bottom of the hood and the

ground or other obstruction. The hood opening should point down.

• Never install a screen over the exhaust outlet.

• To avoid lint buildup, do not exhaust the dryer directly into a window well. Do not exhaust under a house or

porch.

• If the exhaust duct must run through an unheated area, the duct should be insulated and slope slightly down

towards the exhaust hood to reduce condensation and lint buildup.

• Inspect and clean the interior of the exhaust system at least once a year. Unplug the power cord before

cleaning.

• Check frequently to make sure the exhaust hood damper opens and closes freely.

• Check once per month, and clean at least once per year. Note: If your clothes are not getting dry, then check

the duct for obstructions.

• Do not exhaust the dryer into a wall, ceiling, crawl space, or concealed space of a building, gas vent, or any

other common duct or chimney. This could create a ﬁre hazard from the lint expelled by the dryer.

DV6000HA_DC68-03380A-04_EN.indd 12 2014-11-25  4:46:53

English - 13

02 INSTALLATION

If the new dryer is installed into an existing exhaust system you must make sure:

• The exhaust system meets all local, state, and national codes.

• That a ﬂexible plastic duct is not used.

• To inspect and clean all lint buildup from inside the existing duct.

• The duct is not dented or crushed.

• The exhaust hood damper opens and closes freely.

• The static pressure in any exhaust system must not exceed 0.83 inches of water column, or be less than 0.

• This can be measured with the dryer running with a manometer at the point where the exhaust duct

connects to the dryer. A no-heat setting should be used. The dryer tumbler should be empty and the lint ﬁlter

clean.

Exhausting

The dryer shall not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a

building.

Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the

room.

• All dryers must be exhausted to the outside.

• Do not assemble the duct with screws or other fastening means that extend into the duct and catch

lint.

• The exhaust duct should be 4 inches (102 mm) in diameter.

• The total length of ﬂexible metal duct shall not exceed 2.4 m (7.8 ft.).

In the United States:

Use only those foil-type ﬂexible ducts, if any, speciﬁcally identiﬁed for use with the appliance by the manufacturer

and that comply with the Outline for Clothes Dryer Transition Ducts, Subject 2158A.

In Canada:

Use only those foil-type ﬂexible ducts, if any, speciﬁcally identiﬁed for use with the appliance by the manufacturer.

Outside the U.S. and Canada:

Refer to the local codes.

WARNING

• The dryer must be exhausted to the outside to reduce the risk of ﬁre when installed in an alcove or

closet.

• NEVER USE A PLASTIC OR NON-METAL FLEXIBLE DUCT.

If your existing ductwork is plastic, non-metal, or combustible, replace it with metal.

Use only a metal exhaust duct that is non-ﬂammable to ensure containment of the exhaust air, heat,

and lint.

DV6000HA_DC68-03380A-04_EN.indd 13 2014-11-25  4:46:54

English - 14

Dryer exhaust tips

WARNING: A plastic or non-metal ﬂexible duct presents a potential ﬁre hazard.

• Make sure your dryer is installed properly so it exhausts air easily.

• Use a 4” diameter rigid metal duct. Tape all joints, including at the dryer.

Never use lint-trapping screws.

• Keep ducts as straight as possible.

• Clean all old ducts before installing your new dryer.

• Be sure the vent ﬂap opens and closes freely.

• Inspect and clean the exhaust system annually.

4”

Tape

Don’t let a poor exhaust system slow the drying process by:

• Restricting your dryer with a poor exhaust system.

• Using a plastic, thin foil, or non-metal ﬂexible duct.

• Unnecessarily using long ducts that have many elbows.

• Allowing dented or clogged ducts and vent.

DV6000HA_DC68-03380A-04_EN.indd 14 2014-11-25  4:46:54

English - 15

02 INSTALLATION

Gas requirements

THE INSTALLATION MUST CONFORM WITH LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH

THE NATIONAL FUEL GAS CODE ANSI/Z223.1, LATEST REVISION (FOR THE UNITED STATES), OR WITH THE

CAN/CGA-B149 INSTALLATION CODES (FOR CANADA).

• Use only natural or LP (liquid propane) gases.

• This dryer designed for use with natural gas. If you plan to use your dryer with LP gas (liquid propane), the

conversion must be done by a qualiﬁed service technician in order to achieve safe and proper performance.

• A 1/2 inch (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8 inch (1 cm)

gas line on your dryer. The National Fuel Gas Code requires that an accessible, approved manual gas shut-oﬀ

valve be installed within 6 inches of your dryer.

• Gas dryers installed in residential garages must be raised 18 inches (46 cm) above the oor.

• Additionally, a 1/8 inch (0.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge

connection, must be installed immediately upstream of your dryer’s gas supply connection.

• Your dryer must be disconnected from the gas supply pipe system during any pressure testing of the system.

• DO NOT reuse old ﬂexible metal gas lines. Flexible gas lines must be design certiﬁed by the American Gas

Association (CGA in Canada).

• Any pipe joint compound used must be resistant to the action of any liqueﬁed petroleum gas.

• As a courtesy, most local gas utilities will inspect a gas appliance installation.

• GAS IGNITION - Your dryer uses an automatic ignition system to ignite the burner. There is no constant

burning pilot.

Commonwealth of massachusetts installation instructions

Your dryer must be installed by a licensed plumber or gas ﬁtter. A “T” handle manual gas valve must be installed in

the gas supply line to your dryer. If a ﬂexible gas connector is used to install your dryer, the connector may not be

longer than 3 feet (36 inches).

WARNING

• Gas leaks may occur in your system, creating a dangerous situation.

• Gas leaks may not be detected by smell alone.

• Gas suppliers recommend that you purchase and install a UL-approved gas detector.

• Install and use it in accordance with the manufacturer’s instructions.

DV6000HA_DC68-03380A-04_EN.indd 15 2014-11-25  4:46:54

English - 16

Electrical requirements

The wiring diagram is located on the plate below the control panel.

WARNING

• The improper connection of the equipment grounding conductor can result in a risk of electric

shock. Check with a qualiﬁed electrician or serviceman if you are in doubt as to whether your dryer is

properly grounded. Do not modify the plug provided with your dryer - if it doesn’t ﬁt the outlet, have

a proper outlet installed by a qualiﬁed electrician.

• To prevent unnecessary risk of ﬁre, electrical shock, or personal injury, all wiring and grounding must

be done in accordance with local codes, or in the absence of local codes, with the National Electrical

Code, ANSI/NFPA No. 70-Latest Revision (for the U.S.) or the Canadian Electrical Code CSA C22.1 -

Latest Revisions and local codes and ordinances. It is your responsibility to provide adequate electrical

services for your dryer.

• All gas installations must be done in accordance with the national Fuel Code ANSI/Z2231 - Latest

Revision (for the U.S.) or CAN/CGA - B149 Installation Codes - Latest Revision (for Canada) and local

codes and ordinances.

Electrical connections

Before operating or testing, follow all grounding instructions in the “Grounding” section on page 13.

An individual branch (or separate) circuit serving only your dryer is recommended. DO NOT USE AN EXTENSION

CORD.

Gas models – U.S. and Canada

A 120 volt, 60 Hz AC approved electrical service, with a 15-ampere fuse or circuit breaker is required.

Electric models – U.S. only

Most U.S. dryers require a 120/240 volt, 60 Hz AC approved electrical service. Some require 120/208 volt, 60 Hz

approved electrical service. The electric service requirements can be found on the data label located behind the

door. A 30-ampere fuse or circuit breaker on both sides of the line is required.

If a power cord is used, the cord should be plugged into a 30-ampere receptacle.

The power cord is NOT provided with U.S. electric model dryers.

WARNING - RISK OF ELECTRIC SHOCK

When local codes allow, the electrical supply of the dryer may be connected by means of a new power

supply cord kit, marked for use with a dryer, that is U.L. listed and rated at a minimum of120/240 volts,

30-ampere with three No. 10 copper wire conductors terminated with closed loop terminals, open-end

spade lugs with turned up ends, or with tinned leads.

• Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be

retained at the dryer cabinet with a suitable UL-listed strain relief.

• Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2)

mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through

the neutral conductor. (Use a 4-prong plug for 4 wire receptacles, NEMA type 14-30R.)

Electric models – Canada Only

• A 120/240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on

both sides of the line is required.

• All Canadian models are shipped with the power cord attached. The power cord should be plugged into a

30-ampere receptacle.

In Canada, you may not convert a dryer to 208 volts.

DV6000HA_DC68-03380A-04_EN.indd 16 2014-11-25  4:46:54

English - 17

02 INSTALLATION

3-WIRE system connections

1. Loosen or remove the center terminal block screw.

2. Connect the neutral wire (white or center wire) of the power cord to the center, silver-colored terminal screw

of the terminal block. Tighten the screw.

3. Connect the other wires to the outer terminal block screws. Tighten the screws.

4. Tighten the strain relief screws.

5. Insert the tab of the terminal block cover into your dryer’s rear panel slot.

6. Secure the cover with a hold-down screw.

A External ground connector

B Neutral grounding wire (white or green/yellow)

C Center silver-colored terminal block screw

D Neutral wire (white or center wire)

E 3/4 in. (1.9 cm) UL-listed strain relief

If converting from a 4-wire electrical system to a 3-wire, the ground strap must be reconnected to the

terminal block support to ground the dryer frame to the neutral conductor.

4-WIRE system connections

1. Remove the center terminal block screw.

2. Connect the ground wire (green or unwrapped) of the power cord to the external ground conductor screw.

3. Connect the neutral wire (white or center wire) of the power cord and the appliance ground wire (white or

green/yellow stripes) under the central screw of the terminal block.

4. Connect the other wires to the outer terminal block screws. Tighten the screws.

5. Tighten the strain relief screws.

6. Insert the tab of the terminal block cover into your dryer’s rear panel slot.

7. Secure the cover with a hold-down screw.

A External ground connector

B Green or bare copper wire of the power cord

C 3/4 in. (1.9 cm) UL-listed strain relief

D Center silver-colored terminal block screw

E Neutral grounding wire (white or green/yellow)

F Neutral wire (white or center wire)

8. With a level, check your dryer and make the necessary adjustments to the leveling legs.

9. At this time, make sure all gas connections (on gas models), exhaust and electrical connections are complete.

Plug in your dryer, and check its operation by using the checklist below.

10. (GAS MODELS ONLY)

The burner may not ignite initially due to air in the gas line. Allowing your dryer to operate on a heat setting

will purge the line. If the gas does not ignite within 5 minutes, turn your dryer oﬀ and wait 5 minutes. Be sure

the gas supply to your dryer has been turned on. In order to conﬁrm the gas ignition, check the exhaust for

heat.

DV6000HA_DC68-03380A-04_EN.indd 17 2014-11-25  4:46:55

English - 18

Connecting the inlet hose

The dryer must be connected to the cold water faucet using the new inlet hoses. Do not use old hoses.

1. Turn the cold water faucet oﬀ.

2. Attach the brass female end of the Y connector (A) to the cold water

faucet.

3. Attach the straight end of long hose (B) to the Y connector.

4. Using pliers, tighten the coupling with an additional two-thirds turn.

If the Y connector cannot be attached directly to the cold water

faucet, the short hose must be used.

(If space permits, please skip steps 5 to 8, and go directly to step 9.)

5. Attach the short inlet hose (C) to the cold water faucet.

Screw on the coupling by hand until it is seated on the faucet.

6. Using the pliers, tighten the coupling with an additional two-thirds

turn.

7. Attach the Y connector (A) to the brass male end of the small hose.

Screw on the coupling by hand until it is seated on the connector.

8. Using the pliers, tighten the coupling with an additional two-thirds

turn.

9. Attach the angled end of long hoses to the ﬁll valve at the bottom of

the dryer rear frame. Screw on the coupling by hand until it is seated

on the ﬁll valve connector.

10. Using pliers, tighten the coupling with an additional two-thirds turn.

11. Attach the washer hose (D) to the other side of the Y connector (A).

Screw on the hose coupling until it is tight. Using pliers, tighten the

coupling with an additional two thirds turn.

12. Check that the water faucets are on.

13. Check for leaks around the Y connector, faucets and hoses.

When you tighten the coupling with pliers, do not overtighten. This may damage the coupling.

DV6000HA_DC68-03380A-04_EN.indd 18 2014-11-25  4:46:55

English - 19

02 INSTALLATION

Replacement parts and accessories

If your dryer requires replacement parts or accessories, contact the dealer where you purchased your dryer or the

SAMSUNG customer care center at 1-800-SAMSUNG (726-7864).

Installation

For the proper installation, we recommend that you hire a qualied installer.

1. Move your dryer to an appropriate location for the installation.

Consider installing the dryer and washer side-by-side, to allow access

to the gas, electrical, and exhaust connections. Place two of the carton

cushion-tops on the ﬂoor. Tip your dryer on its side so it lies across

both cushion-tops.

2. Set your dryer back in an upright position.

3. To ensure that the dryer provides the optimal drying performance, it

must be level. To minimize vibrations, noise, and unwanted movement,

the ﬂoor must be a perfectly level, solid surface.

To set the dryer to the same height as the washer, fully retract the

leveling feet (A) by turning them counterclockwise, then loosen the

legs by turning them clockwise.

Adjust the leveling feet only as much as necessary to level the

dryer. Extending the leveling feet more than necessary can

cause the dryer to vibrate.

4. Review the “Exhausting” section on page 13 before installing the exhaust system.

Install the ductwork from your dryer to the exhaust hood. The crimped end of the duct sections must point

away from your dryer.

• DO NOT use sheet metal screws when assembling the ducting. These joints should be taped.

• Never use plastic ﬂexible exhaust material.

• Tip for tight installations: install a section of the exhaust system onto your dryer before putting it in place.

• Use duct tape to secure this section to your dryer, but do not cover the ventilation slots at the back of

the unit in dryer cabinet.

5. Review the “Electrical requirements” section on page 16.

BEFORE OPERATING OR TESTING, follow the grounding instructions in the “Grounding” section on page 9.

WARNING - U.S. MODELS

RISK OF ELECTRIC SHOCK - All U.S. models are produced for a 3-WIRE SYSTEM CONNECTION.

The dryer frame is grounded to the neutral conductor at the terminal block.

A 4-WIRE SYSTEM CONNECTION is required for new or remodeled construction, mobile homes, or if

local codes do not permit grounding through the neutral conductor. If the 4-wire system is used, the

dryer frame cannot be grounded to the neutral conductor at the terminal block.

Refer to the following instructions for “Electrical connections” on page 16.

Remove the terminal block cover plate.

Insert the power cord with a UL-listed strain relief through the hole provided in the cabinet near the terminal

block.

A strain relief must be used.

Do not loosen the nuts already installed on the terminal block. Be sure they are tight.

Use a 3/8 in. (1 cm) deep well socket.

DV6000HA_DC68-03380A-04_EN.indd 19 2014-11-25  4:46:55

English - 20

6. Review the “Gas requirements” section on page 15.

Remove the pipe thread protective cap. Apply a pipe joint compound or about 1½ wraps of Teﬂon tape over

all threaded connections.

The pipe joint compound must be resistant to the actions of any liqueﬁed petroleum gas.

Connect the gas supply to your dryer. An additional ﬁtting is required to connect the 3/4” (1.9 cm) female

thread end of a ﬂexible connector to the 3/8” (1 cm) male threaded end on the dryer.

Securely tighten the gas line ﬁtting over the threads.

Turn on the gas supply.

Check all gas connections for leaks using a soap solution.

If bubbles appear, tighten the connections and recheck. DO NOT use an open ﬂame to check for gas leaks.

Door reversal

1. Unplug the power cord.

2. Remove two door hinge screws.

3. Lift the door and remove it.

4. Remove two screws from the frame front.

5. Remove the two screws from the opposite side of the door hinge.

6. Remove the two screws from the holder lever.

7. Reassemble the two screws on the inside holes.

DV6000HA_DC68-03380A-04_EN.indd 20 2014-11-25  4:46:56

English - 21

02 INSTALLATION

8. Remove a screw from the door hinge.

The screw is for pre-ﬁxing the door to the frame front.

9. Reassemble the screw in the other hole.

10. Place the door on the other side and reattach it to the dryer.

11. Reattach the holder lever.

12. Reattach the screws in the remaining holes.

Final installation checklist

• The dryer is plugged into an electrical outlet and is properly grounded.

• The exhaust ductwork is hooked up and the joints are taped.

• A plastic ﬂexible duct is NOT used.

• Use rigid or stiﬀ-walled ﬂexible metal vent material.

• The dryer is level and is sitting ﬁrmly on the ﬂoor.

• Gas models – the gas is turned on with no gas leaks.

• Start your dryer to conﬁrm that it runs, heats, and shuts oﬀ.

DV6000HA_DC68-03380A-04_EN.indd 21 2014-11-25  4:46:56

English - 22

Operating instructions, tips

To reduce the risk of ﬁre, electric shock, or injury to persons,read the IMPORTANT SAFETY INSTRUCTIONS

before operating this appliance.

Overview of the control panel

Electric model

3 4 5

1 22

69 7

Gas model

3 4 5

1 22

69 7

DV6000HA_DC68-03380A-04_EN.indd 22 2014-11-25  4:46:57

English - 23

03 OPERATION

1. Cycle selector

To select a cycle, rotate the Cycle selector dial to the desired cycle.

The indicator light by the cycle name will illuminate. The ECO NORMAL, NORMAL, HEAVY DUTY, BEDDING,

SANITIZE, PERM PRESS, WOOL and DELICATES cycles are Sensor Dry cycles.

Sensor Dry automatically senses the moisture in the load and shuts the dryer oﬀ when the selected dryness

level (Very Dry to Damp Dry) is reached.

CYCLE RECOMMENDED ITEMS DETAILS

ECO NORMAL Cottons, Work clothes, Linen

For reducing energy usage. This cycle adjusts the cycle

time and temperature for increased eﬃciency.

NORMAL

Cottons, Work clothes, Linen,

Mixed loads

The NORMAL cycle is for most fabrics including cotton,

underwear and linen.

(If this cycle is selected, the Eco Dry function is enabled

by default. For more information, please refer to the

descriptions about the “Eco Dry” option on next page.)

HEAVY DUTY

Heavy fabrics such as jean,

Corduroys, Heavy work clothes

Use this cycle to get high heat for heavy fabrics such as

jeans, corduroys, or work clothes.

BEDDING

Bulky items such as blankets,

Sheets, Comforters, Pillows

For bulky items such as blankets, sheets, and comforters.

SANITIZE

Bedding, Curtains, Children’s

clothing

Sanitize garments by infusing high temperature heat deep

into the fabric during the drying cycle. Use this course to

keep your bedding and curtains clean through sanitization.

PERM PRESS

Shirts, Synthetic fabrics,

Knits, Wrinkle-free cottons,

Permanent

Dry wrinkle-free cottons, synthetic fabrics, knits, and

permanent press fabrics automatically.

WOOL

For machine washable and

tumble dryable wool only

(Maximum amount : 3lb)

For machine washable and tumble dryable wool only.

DELICATES Underwear, Blouses, Lingerie

The DELICATES cycle is designed to dry heat-sensitive

items at a low drying temperature.

QUICK DRY Small loads Provides a 30 minutes drying cycle.

TIME DRY Any load

The TIME DRY cycle allows you to select a cycle time in

minutes.

(If this cycle is selected, the Eco Dry function is enabled

by default. For more information, please refer to the

descriptions about the “Eco Dry” option on next page.)

AIR FLUFF Foam, Rubber, Plastic

The AIR FLUFF cycle tumbles the load in room temperature

air.

REFRESH

Shirts, Trouser, Comforter,

Pillows

This cycle is best for smoothing out wrinkles and reducing

odors from loads consisting of one to four dry items. In

this cycle a small amount of water is sprayed into the dryer

drum after several minutes of tumbling with heat.

WRINKLE AWAY Shirts, Trouser, Blouses

The WRINKLE AWAY cycle removes wrinkles from clothes

stored in closets, etc. It provides wrinkle release via

optimized steam care.

You can change the drying time.

(Minimum time : 20 minutes)

*For best results, load no more than 3 items.

DV6000HA_DC68-03380A-04_EN.indd 23 2014-11-25  4:46:57

English - 24

2. Cycle options

Anti Static

To reduce statics by clothing friction and spray steam at the later period of drying cycle.

It is only available with: NORMAL, HEAVY DUTY, PERM PRESS, DELICATES (Dry level of every

course exceeds Normal) and TIME DRY course.

In order to reduce statics, the drum can be paused during operation.

Rack Dry

Rack Dry is available in the TIME DRY cycle. Temperature will be set to Extra Low only.

(Refer to the “Rack dry” section on page 28.)

Mixed Load Bell

The mixed load bell that notiﬁes you when the average dry level in a load is damp dry (80

% dried). This lets you take garments that you don’t want fully dried or that dry quickly out

of the dryer early while letting others continue to dry.

You can select this function in all Sensor Dry cycles except WOOL, SANITIZE. The dry level

selections are limited to Normal Dry, More Dry, and Very Dry.

Wrinkle Prevent

Wrinkle Prevent provides approximately 180 minutes of intermittent tumbling in

unheated air at the end of the cycle to reduce wrinkling. Press the Wrinkle Prevent button

to activate this feature.

The indicator light above the pad will illuminate when Wrinkle Prevent is selected.

The load is dry, and can be removed at any time during the Wrinkle Prevent cycle.

My Cycle

Choose your favorite cycle including cycle, temp, dry level option, etc. (Refer to the “My

Cycle” section on page 30.)

Adjust Time

Time can be added or subtracted from the automatically set times in the Manual Dry

cycles (TIME DRY, QUICK DRY, or AIR FLUFF cycles) and WRINKLE AWAY cycle.

To add or subtract time from the cycle, press the Adjust Time arrow pad up or down until

the desired time is displayed.

Small Load Care™

(Gas model Only)

To control operation rate for drying a small loads at Sensor Dry course.

It is only available with: NORMAL, HEAVY DUTY, PERM PRESS and DELICATES course.

It can’t be selected/cancelled when the drying course is running.

In order to improve drying eﬀect and control operation rate, the drum can be paused

during operation.

Eco Dry

(Electric model

Only)

This function is available in the NORMAL, and TIME DRY cycles. When the Eco Dry function

is activated, drying takes longer but the power consumption is reduced.

(When the Eco Dry function is enabled, the drying time can be extended up to 3 times

depending on the speciﬁed temperature and the amount of laundry to be dried. When

the product is shipped, the Eco Dry function is set to On by default.)

3. Dry Level

To select the dry level in the NORMAL, HEAVY DUTY, or other Sensor Dry cycles, press the Dry Level button. An

indicator light will illuminate next to the desired dryness level.

Press the button repeatedly to scroll through the settings. Larger or bulkier loads may require the Very Dry or

More Dry setting for complete dryness.

The Less Dry setting is best suited for lightweight fabrics or for leaving some moisture in the clothing at the

end of the cycle. Damp Dry is designed to partially dry items. Use for items that lay ﬂat or hang to dry.

DV6000HA_DC68-03380A-04_EN.indd 24 2014-11-25  4:46:57

English - 25

03 OPERATION

4. Temp.

To select the correct temperature for the load, press the Temp. button. An indicator light will illuminate next

to the desired temperature. Press the button repeatedly to scroll through the settings.

High For sturdy cottons or those labeled Tumble Dry.

Medium

For permanent press, synthetics, lightweight cottons, or items labeled Tumble Dry

Medium.

Med Low For lower heat than Medium to dry synthetic or washable knit fabrics.

Low For heat sensitive items labeled Tumble Dry Low or Tumble Dry Warm.

Extra Low Provides the lowest heated dry temperature possible.

5. Time

When using Manual Dry cycles, you can adjust the drying time by pressing the Time selection button.

During the Sensor Dry cycle, the time light indicator is oﬀ because exact drying times are determined by

ﬂuctuating humidity levels.

6. LED Display

The display window shows the estimated time remaining in the cycle after the Start/Pause button is pressed.

The estimated time remaining may ﬂuctuate as the cycle progresses.

The Drying light will illuminate and remain lit until the cycle is complete.

When your dryer is in the cool-down phase, the Cooling light will illuminate.

When your dryer is in the wrinkle prevent phase, the Wrinkle Prevent light will illuminate.

When the cycle is complete, “End” will appear in the display panel until the dryer door is opened or the Power

button is pushed.

If your dryer is paused during a cycle, the indicator lights will blink until the Start/Pause button is pressed.

7. Power

Press once to turn your dryer on. Press again to turn it oﬀ. If your dryer is left on for more than 10 minutes

without any buttons being touched, the power automatically turns oﬀ.

8. Start/Pause

Press to pause and restart programs.

9. Indicators

Filter Check Sound Oﬀ

Drum Light

Vent Sensor (The Vent Sensor is only on the

DV45H6300* model.)

Child Lock Steam

DV6000HA_DC68-03380A-04_EN.indd 25 2014-11-25  4:46:58

English - 26

Load the dryer properly

• Place only one washload in your dryer at a time.

• Mixed loads of heavy and lightweight fabrics will dry diﬀerently, which may result in lightweight fabrics being

dry while heavy fabrics remain damp at the end of a drying cycle.

• Add one or more similar items to your dryer when only one or two articles of clothing need drying.

This improves the tumbling action and drying eﬃciency.

• Overloading restricts tumbling action, resulting in uneven drying as well as excessive wrinkling of some

fabrics.

If you insert laundry into your dryer while it is extremely tangled immediately after your washer has

ﬁnished a wash or spin cycle, it may degrade the drying eﬃciency or cause the door to open. We

recommend that you untangle your laundry appropriately before inserting it.

Getting started

1. Load your dryer loosely (DO NOT overload).

2. Close the door.

3. Select the appropriate cycle and options for the load. (For detail, refer to the “Cycle overview” on next page.)

4. Press the Start/Pause button.

5. The dryer indicator light will illuminate.

6. The estimated cycle time will appear in the display.

The time may ﬂuctuate as humidity levels ﬂuctuate in the dryer.

• When the cycle is complete, “End” will appear in the display.

• Pressing Power cancels the cycle and stops your dryer.

• The Drying, Cooling, and Wrinkle Prevent indicator lights will illuminate during those portions of the

cycle.

Do not place anything on top of your dryer while it is running.

DV6000HA_DC68-03380A-04_EN.indd 26 2014-11-25  4:46:58

English - 27

03 OPERATION

Cycle overview

Predeﬁned

CYCLE LOAD SIZE

DRY LEVEL TEMPERATURE

Predened Adjustable Predened Adjustable

Sensor Dry

ECO NORMAL Medium Normal Dry o Extra Low -

NORMAL Large Normal Dry o High o

HEAVY DUTY Large Normal Dry o High -

BEDDING Large Normal Dry o High -

SANITIZE Large Very Dry - High -

PERM PRESS Medium Normal Dry o Medium -

WOOL Small Normal Dry - Low -

DELICATES Medium Normal Dry o Extra Low -

Manual Dry

QUICK DRY Small - - High -

TIME DRY Large - - High o

AIR FLUFF Small - - - -

Steam Cycles

REFRESH Small - - High -

WRINKLE AWAY Small - - High -

Load size recommendations

For best results, follow the load size recommendations for each drying cycle.

Large Fill the drum to about ¾ full. Do not add items over this level as they need to tumble freely.

Medium Fill the drum to about ½ full.

Small Fill the drum with 3~5 items, not more than ¼ full.

Options

CYCLE

AVAILABLE OPTIONS

Mixed

Load Bell

Adjust time

Up/Down

Eco Dry

Small Load

Care™

Anti

Static

Wrinkle

Prevent

Sensor Dry

ECO NORMAL o - - - - o

NORMAL o - o o o o

HEAVY DUTY o - - o o o

BEDDING o - - - - o

SANITIZE - - - - - o

PERM PRESS o - - o o o

WOOL - - - - - o

DELICATES o - - o o o

Manual Dry

QUICK DRY - o - - - o

TIME DRY - o o - o o

AIR FLUFF - o - - - o

Steam Cycles

REFRESH - - - - - o

WRINKLE AWAY - o - - - o

DV6000HA_DC68-03380A-04_EN.indd 27 2014-11-25  4:46:58

English - 28

Rack dry

Installing the drying rack

1. Open the dryer door.

2. Position the drying rack in the tumbler, placing the front lip of the

drying rack (A) on the top of the lint ﬁlter.

3. Place the rear legs in the two recessed areas of the dryer’s back wall,

and then push down the middle of the drying rack to ﬁx in place.

4. Place the items to be dried on the rack, leaving space between them

so air can circulate.

5. Close the dryer door.

6. Press the Rack Dry button in the TIME DRY cycle and then select the

time according to the amount of moisture and the weight of the items.

The drying rack can be also used at AIR FLUFF cycle.

SUGGESTED ITEMS SUGGESTED TEMP. SETTINGS

Washable sweaters

(block to shape and lay ﬂat on rack)

Extra Low (TIME DRY cycle)

Stuﬀed toys

(cotton or polyester ﬁberﬁlled)

Extra Low (TIME DRY cycle)

Stuﬀed toys

(foam or rubber-ﬁlled)

AIR FLUFF

Foam rubber pillows AIR FLUFF

Sneakers AIR FLUFF

Drying foam rubber, plastic, or rubber on a heat setting may cause damage to the items and lead to a ﬁre

hazard.

DV6000HA_DC68-03380A-04_EN.indd 28 2014-11-25  4:46:58

English - 29

03 OPERATION

Child Lock

Prevents children from playing with your dryer.

Setting/Releasing

To turn Child Lock on or oﬀ, press both the Temp. and Time buttons simultaneously for 3 seconds.

Child Lock Details

1. You can turn Child Lock on while your dryer is running.

2. Once you set the Child Lock function, no button, except for the Power button, will respond until you turn oﬀ

the Child Lock function.

3. The “Child Lock

” indicator will be lit.

• If the dryer is powered on again, the Child Lock function stays on.

• To turn oﬀ Child Lock, follow the instructions above.

When other buttons, except for the Power button, do not respond, check the Child Lock indicator. If Child

Lock is on, follow the instructions above to turn Child Lock oﬀ.

Drum Light

Lights the dryer drum while the dryer is running.

Turning On and Off

To turn on or turn oﬀ the Drum Light, press and hole the Wrinkle Prevent button for 3 seconds.

You can turn the Drum Light on and oﬀ while your dryer is running and when it is stopped.

If you do not turn the Drum Light oﬀ 5 minutes after turning it on, the Drum Light is automatically turned

oﬀ.

Sound Off

Use this function to mute the button and operating sounds.

Setting and Releasing

To turn the Sound Oﬀ function on or oﬀ, press the Dry Level button for 3 seconds.

Sound Off Details:

1. You can set Sound Oﬀ while your dryer is running.

2. Once you have activated Sound Oﬀ, the button and operating sounds are muted until you deactivate it.

3. The “Sound Oﬀ

” indicator will be lit.

If you do not turn the Sound Oﬀ function oﬀ before you turn your dryer oﬀ, It will still be on when you turn

your dryer on again. To turn Sound Oﬀ oﬀ, follow the instructions above.

DV6000HA_DC68-03380A-04_EN.indd 29 2014-11-25  4:46:58

English - 30

My Cycle

Load

• Press the My Cycle button for less than 3 seconds to activate My Cycle mode where all course settings and

selected options are loaded.

• The My Cycle indicator turns on when the mode is active.

• If you have not conﬁgured any My Cycle settings, the default course settings are loaded.

Save

You can add and save preferred options to My Cycle.

1. Turn the course dial to select a course.

2. Set necessary options for the selected course. For details on each course and options, see page 27.

3. Press and hold the My Cycle button for more than 3 seconds to save the course options. The My Cycle

indicator blinks while the options are being saved.

The Wrinkle Prevent option is not available for the My Cycle function.

Smart Care

This function enables you to check the status of the dryer using a smartphone.

1. Press and hold the Eco Dry (Electric model) or Small Load Care (Gas model) buttons for 3 seconds when an

error occurs or if you haven’t pressed any buttons on the dryer after you turned the power on.

2. When the Smart Care function is activated, the LED on the window display rotates for 2 or 3 seconds and then

the error code will appear in the display panel.

3. Run the Smart Care app on your smart phone.

The Smart Care function has been optimized for: Galaxy & iPhone series (cannot be supported for

some models).

4. If the smart phone’s camera is focused on the display panel of the dryer, the panel and error message is

automatically recognized and the error type and countermeasures are displayed on the smart phone.

5. If the smartphone fails to recognize the error code more than twice, please enter the error code displayed on

the display panel of the dryer manually into the Smart Care app.

Downloading the Smart Care app

Download the Samsung Laundry App into your mobile phone from the Android market or Apple App store.

(Search word : Samsung Smart Washer/Dryer)

Precautions when using Smart Care

• If light from a light bulb, ﬂuorescent bulb, or lamp is reﬂected on the display panel of the washing machine,

the smartphone may not be able to recognize the panel or error message easily.

• If you hold the smartphone at too large an angle relative to the front of the display panel, it may not be able

to recognize the error code. For best results, hold the smartphone so that the front of the panel and the

smartphone are parallel or nearly parallel.

DV6000HA_DC68-03380A-04_EN.indd 30 2014-11-25  4:46:58

English - 31

03 OPERATION

Vent Sensor

The Vent Sensor is only on the DV45H6300* model.

Your Samsung dryer is equipped with a Vent Sensor, which detects and notiﬁes you when it is time to clean the

ductwork. Keep your dryer safe and eﬃcient by cleaning the ducts when prompted.

The Vent Sensor detects any duct blockages

You can ﬁgure out whether there is a duct blockage from the “Vent Sensor ” lamp of the digital display.

Level Message Status Solution

The “Vent Sensor

” lamp is

turned oﬀ.

The ductwork is free from

blockages.

The “Vent Sensor

” lamp

illuminates.

When a part of the duct or the

lint ﬁlter is blocked by lint or a

foreign object.

When the resistance is high

because the duct is too long

or bent.

Check the duct connection

and shorten the duct and

straighten it if necessary.

Check the lint ﬁlter or the duct

and clean it if necessary.

The “Vent Sensor

” lamp

blinks.

When the duct is blocked by

lint or a foreign object.

When the resistance is very

high because the duct is too

long or bent excessively.

Check the duct connection

and shorten the duct and

straighten it if necessary.

Check the lint ﬁlter or the

duct and clean it as soon as

possible.

In the LEVEL 2 state, this lamp blinks for 3 hours after the completion of the cycle. (If the wrinkle prevention

function is activated, this message is displayed for up to 3 hours.)

If the Power button is pressed or the door is opened, the power is immediately turned oﬀ.

For more information about the duct installation, please refer to the “Ducting requirements” section on

page 12.

• Although the dryer is available even if the blockage message is displayed, the drying time may be

extended.

• If the LEVEL 1 message is displayed the ﬁrst time the dryer is run after the installation, check the

connection and clean the duct. If the LEVEL 1 message appears even after you have checked and

cleaned the ducts, this may indicate that there are some restrictions of the duct due to the length,

condition, etc.

If this occurs, you can use the dryer normally and no countermeasures need to be taken. However, the

drying time may be extended or the drying performance may be degraded.

DV6000HA_DC68-03380A-04_EN.indd 31 2014-11-25  4:46:59

English - 32

Care and cleaning

Control panel

Clean with a soft, damp cloth. Do not use abrasive substances.

Do not spray cleaners directly on the panel.

The control panel ﬁnish may be damaged by some laundry pre-treatment soil and stain remover products.

Apply such products away from your dryer and wipe up any spills or overspray immediately.

Tumbler

Remove any stains caused by crayon, ink, or fabric dye (from new items such as towels or jeans) with an all-

purpose cleaner.

Tumble old towels or rags to remove any remaining stain or cleaning substance.

Once these steps are followed, stains may still be visible, but should not transfer to subsequent loads.

Stainless steel tumbler

To clean the stainless steel tumbler, use a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel

surfaces.

Remove the cleaner residue and dry with a clean cloth.

Dryer exterior

Clean with a soft, damp cloth. Do not use abrasive substances.

Protect the surface from sharp objects.

Do not place any heavy or sharp objects or a detergent box on the dryer. Keep them on the purchased pedestal or

in a separate storage box. This may scratch or damage the top cover of the dryer.

Since the entire dryer has a high-gloss ﬁnish, the surface can be scratched or damaged.

Avoid scratching or damaging the surface when using the dryer.

Dryer exhaust system

Should be inspected and cleaned yearly to maintain optimum performance.

The outside exhaust hood should be cleaned more frequently to ensure proper operation.

Clean the lint ﬁlter

• After each load.

• To shorten drying time.

• To operate more energy eﬃciently.

Do not operate your dryer without the lint ﬁlter in place.

DV6000HA_DC68-03380A-04_EN.indd 32 2014-11-25  4:46:59

English - 33

05 LAUNDRY TIPS

Special laundry tips

Please follow the care label or manufacturer’s instructions for drying special items. If care label instructions are not

available, use the following information as a guide.

Bedspreads & Comforters

Follow the care label instructions or dry on the BEDDING cycle.

Make sure the item is thoroughly dry before using or storing.

May require repositioning to ensure even drying.

Blankets

Use NORMAL cycle and dry only one blanket at a time for best tumbling

action.

Make sure the item is thoroughly dry before using or storing.

Curtains & Draperies

Use the PERM PRESS cycle and Medium temperature to help minimize

wrinkling.

Dry these in small loads for best results and remove as soon as possible.

Cloth Diapers

Use the NORMAL cycle and the High temperature settings for soft, ﬂuﬀy

diapers.

Down–lled Items (jackets,

sleeping bags, comforters, etc.)

Use the NORMAL cycle and the Medium temperature setting.

Adding a couple of dry towels shortens drying time and absorbs moisture.

Foam Rubber (rug backs,

stued toys, shoulder pads, etc.)

DO NOT dry on a heat setting. Use the AIR FLUFF cycle (no heat).

WARNING – Drying a rubber item with heat may damage it or be a ﬁre

hazard.

Pillows

Use the NORMAL cycle.

Add a couple of dry towels and a pair of clean sneakers to help the

tumbling action and to ﬂuﬀ the item.

DO NOT dry kapok or foam pillows in dryer. Use the AIR FLUFF cycle.

Plastics (shower curtains,

outdoor furniture covers, etc.)

Use the AIR FLUFF cycle or the TIME DRY cycle and the Low or Extra Low

temperature settings depending on the care label instructions.

THINGS TO AVOID PUTTING IN THE DRYER:

• Fiberglass items (curtains, draperies, etc.).

• Woolens, unless recommended on the label.

• Vegetable oil- or cooking oil-soaked, or gasoline-soaked items.

DV6000HA_DC68-03380A-04_EN.indd 33 2014-11-25  4:46:59

English - 34

Troubleshooting

Check these points if your dryer…

PROBLEM SOLUTION

Doesn’t run.

• Make sure the door is latched shut.

• Be sure the power cord is plugged into a live electrical outlet.

• Check the home’s circuit breaker and fuses.

• Press the Start/Pause button again if the door is opened during the cycle.

Doesn’t heat.

• Check the home’s circuit breaker and fuses.

• Select a heat setting other than Air Fluﬀ.

• On a gas dryer, check that the gas supply is on.

• Clean the lint ﬁlter and exhaust duct.

• Dryer may have moved into the cool-down phase of the cycle.

Doesn’t dry.

• Check all of the above, plus...

• Be sure the exhaust hood outside the home can open and close freely.

• Check exhaust system for lint buildup. Ducting should be inspected and

cleaned annually.

• Use a 4” rigid metal exhaust duct.

• Do not overload. 1 wash load = 1 dryer load.

• Sort heavy items from lightweight items.

• Large, bulky items like blankets or comforters may require repositioning to

ensure even drying.

• Check that the dryer is draining properly to extract adequate water from the

load.

• Load may be too small to tumble properly. Add a few towels.

Is noisy.

• Check the load for objects such as coins, loose buttons, nails, etc. Remove

promptly.

• It is normal to hear the dryer gas valve or heating element cycle on and oﬀ

during the drying cycle.

• Be sure the dryer is leveled properly as outlined in the installation instruction.

• It is normal for the dryer to hum due to the high velocity of air moving

through the dryer drum and exhaust system.

Dries unevenly.

• Seams, pockets, and other similarly heavy areas may not be completely dry

when the rest of the load has reached the selected dryness level. This is

normal. Select the Very Dry setting if desired.

• If one heavy item is dried with a lightweight load, such as one towel with

sheets, it is possible that the heavy item will not be completely dry when the

rest of the load has reached the selected dryness level. Sort heavy items from

lightweight items for best drying results.

Has an odor.

• Household odors from painting, varnishing, strong cleaners, etc. may enter the

dryer with the surrounding room air. This is normal as the dryer draws the air

from the room, heats it, pulls it through the tumbler, and exhausts it outside.

• When these odors linger in the air, ventilate the room completely before using

the dryer.

Shuts o before load

is dry

• Dryer load is too small. Add more items or a few towels and restart the cycle.

• Dryer load is too large. Remove some items and restart the dryer.

DV6000HA_DC68-03380A-04_EN.indd 34 2014-11-25  4:46:59

English - 35

06 TROUBLESHOOTING

PROBLEM SOLUTION

Lint on clothes

• Make sure the lint ﬁlter is cleaned before every load. With some loads that

produce high amounts of lint, it may be necessary to clean the ﬁlter during the

cycle.

• Some fabrics are lint producers (for example, a fuzzy white cotton towel)

and they should be dried separately from clothes that are lint trappers (for

example, a pair of lack linen pants.)

• Divide larger loads into smaller loads for drying.

• Check pockets thoroughly before washing and drying clothes.

Garments still wrinkled

after Wrinkle-Care

• Small loads of 1 to 4 items work best.

• Load fewer garments. Load similar-type garments.

Odors remain in

clothing after Refresh.

• Fabrics containing strong odors should be washed in a normal cycle.

Water drips from

nozzle when Steam-

Care starts

• This is steam condensation. The dripping water will stop after a short time.

Sprayed water is not

visible during Steam-

Care

• Sprayed water is diﬃcult to see when the door is closed.

Extended time

• Verify correct loading (clothes)/cycle selection (see page 23).

Information codes

Information codes may be displayed to help you better understand what is occurring with your Dryer.

ERROR DISPLAY MEANING SOLUTION

The thermistor resistance is very low

or high.

Clean the screen or vent.

If the problem continues, call for service.

Invalid heating Temp when the dryer

is running.

Call for service.

Running the dryer with door open. Clean the door and then restart.

If the problem continues, call for service.

bE2

Invalid state of key. Make sure a button is NOT being pressed

continuously. Try restarting the cycle.

If the problem continue, call for service.

Invalid power source frequency. Try restarting the cycle.

If the problem continues, call for service.

9E1

Electronic Control Problem

(Over Voltage Error.)

Call for service.

Electronic Control Problem

(Communication Error.)

Call for service.

EEE

Invalid state of Eeprom

communication.

Call for service.

dF Invalid door. Call for service.

For any codes not listed above, call 1-800-SAMSUNG (726-7864)

DV6000HA_DC68-03380A-04_EN.indd 35 2014-11-25  4:46:59

English - 36

Appendix

Fabric care chart

The following symbols provide garment care direction. The Clothing care labels include symbols for washing,

bleaching, drying, and ironing, or dry cleaning when necessary. The use of symbols ensures consistency among

garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life

and reduce laundering problems.

Wash Cycle Special Instructions Warning Symbols for Laundering

Normal Line Dry/ Hang to Dry Do Not Wash

Permanent Press / Wrinkle

Resistant / Wrinkle Control

Drip Dry Do Not Wring

Gentle/Delicates Dry Flat Do Not Bleach

Hand Wash

Heat Setting

Do Not Tumble Dry

Water Temperature**

High No Steam (added to iron)

Hot Medium Do Not Iron

Warm Low

Dryclean

Cold Any Heat Dry Clean

Bleach

No Heat/Air Do Not Dry Clean

Any Bleach (when needed)

Iron-Dry or Steam Temperatures

Line Dry/ Hang to Dry

Only Non-Chlorine (color-

safe)

Bleach (when needed)

High Drip Dry

Tumble Dry Cycle Medium Dry Flat

Normal

Low

Permanent Press/ Wrinkle

Resistant/ Wrinkle Control

Gentle/Delicates

** The dot symbols represent appropriate wash water temperatures for various items. The temperature range for

Hot is 105 – 125 °F (41 – 52 °C), for Warm 85 – 105 °F (29 – 41 °C) and for Cold 60 – 85 °F (16 – 29 °C). (Wash water

temperature must be a minimum of 60 °F (16 °C) for detergent activation and eﬀective cleaning.)

DV6000HA_DC68-03380A-04_EN.indd 36 2014-11-25  4:46:59

English - 37

07 APPENDIX

Protecting the environment

This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please

observe local waste disposal regulations. Cut oﬀ the power cord so that the appliance cannot be connected to a

power source. Remove the door so that animals and small children cannot get trapped inside the appliance.

Declaration of conformity

This appliance complies with UL2158.

Speciﬁcations

TYPE FRONT LOADING DRYER

DIMENSIONS

Height 38.7” (98.4 cm)

Width 27” (68.6 cm)

Depth with door open 90° 53” (134.5 cm)

Depth 32.4” (82.3 cm)

WEIGHT 125.6 lb (57 Kg)

HEATER RATING

5300 W (Elec.)

22000 BTU/hr (Gas)

EXTRA LARGE CAPACITY 7.5 cu.ft.

DV6000HA_DC68-03380A-04_EN.indd 37 2014-11-25  4:46:59

English - 38

Warranty (U.S.A)

SAMSUNG DRYER

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG)

and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against

manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) Year All Parts and Labor

Two (2) Years Control Board Parts

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in

the United States.

To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service

procedures.

Warranty service can only be performed by a SAMSUNG authorized service center.

The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s

authorized service center.

SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within the

contiguous United States.

In-home service is not available in all areas.

To receive in-home service, product must be unobstructed and accessible to the service agent.

If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized

service center.

SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new

or reconditioned parts or products if found to be defective during the limited warranty period speciﬁed above.

All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.

Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer.

This limited warranty covers manufacturing defects in materials and workmanship encountered in normal,

noncommercial use of this product and shall not apply to the following: damage that occurs in shipment; delivery

and installation; applications and uses for which this product was not intended; altered product or serial numbers;

cosmetic damage or exterior ﬁnish; accidents, abuse, neglect, ﬁre, water, lightning, or other acts of nature or God;

use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations,

repairs, external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result

in service problems; incorrect electrical line voltage, ﬂuctuations and surges; customer adjustments and failure to

follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the

instruction book; product removal and reinstallation; problems caused by pest infestations.

This limited warranty does not cover problems resulting from incorrect electric current, voltage or supply, light

bulbs, house fuses, house wiring, cost of a service call for instructions, or ﬁxing installation errors.

SAMSUNG does not warrant uninterrupted or error-free operation of the product.

DV6000HA_DC68-03380A-04_EN.indd 38 2014-11-25  4:46:59

English - 39

08 WARRANTY

Except as set forth herein, there are no warranties on this product either express or implied, and samsung

disclaims all warranties including, but not limited to, any implied warranties of merchantability, infringement or

ﬁtness for a particular purpose.

No warranty or guarantee given by any person, ﬁrm, or corporation with respect to this product shall be binding

on samsung.

Samsung shall not be liable for loss of revenue or proﬁts, failure to realize savings or thter beneﬁts, or any other

special, incidental or consequential damages caused by the use, misuse, or inability to use this product, regardless

of the legal theory on which the claim is based, and even if samsung has been advised of the possibility of such

damages.

Nor shall recovery of any kind against samsung be greater in amount than the purchase price of the product sold

by samsung and causing the alleged damage.

Without limiting the foregoing, purchaser assumes all risk and liability for loss, damage, or injury to purchaser

and purchaser’s property and to others and their property arising out of the use, misuse, or inability to use this

product. This limited warranty shall not extend to anyone other than the original purchaser of this product, is

nontransferable and states your exclusive remedy.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of

incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty

gives you speciﬁc rights, and you may also have other rights, which vary from state to state.

To obtain warranty service, please contact SAMSUNG at:

Samsung Electronics America, Inc.

85 Challenger Road Ridgeeld Park, NJ 07660

1-800-SAMSUNG(726-7864)

www.samsung.com/us/support

DV6000HA_DC68-03380A-04_EN.indd 39 2014-11-25  4:46:59

English - 40

Warranty (CANADA)

SAMSUNG DRYER

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC. (SAMSUNG)

and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against

manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) year part and labor

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in

the Canada.

To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service

procedures.

Warranty service can only be performed by a SAMSUNG authorized service center.

The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s

authorized service center.

SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within the

Canada.
