Simply attach the sprinkler head to the top of the base
and connect to your hose
LOCK
WATER
+
94127EDAMZ
Spray Width tabs (2)
control the width
of the watering area
Spray Range tabs (2) control the length of
the watering area
360° rotating head controls spray direction
Filter prevents sediments
and dirt from getting into
sprinkler
Water ow control knob
adjusts the overall watering area
20 clog-resistant spray nozzles for even watering
Aluminum wide “H” shape
platform design for more
stability
Quick Connect Adapter ts all
standard U.S. garden hoses
4-WAY ADJUSTABLE MINI OSCILLATING SPRINKLER
with METAL BASE
Flow-through design
allows for additional units
to be connected in series
394m²
4250 sq.ft
Coverage Area
Up To
Attach the sprinkler head to the top of the base. Connect the Product Adapter to the base of the sprinkler. Attach the lockable
Quick Connect to the end of the hose and simply snap in the hose to the sprinkler to begin using.
Simply remove the end-cap and attach another hose to connect an additional sprinkler if needed.
Set-Up with Quick Connect
Assembly
The Quick Connect Adapter (2 pcs) and Hose Connector
with Water Stop (1 pc) simplify your watering experience.
Simply attach the connector at the end of your hose.
Then, connect the adapters to your watering tools.
Interchange various tools in a snap without turning o the
water as the adapter will stop the water ow. No more
kinking or hose twisting as the adapter allows the hose to
swivel 360 degrees.
A
C
A B C D
B
D
Quick and easy connections to 5/8-inch and
1/2-inch garden hoses, sprinklers, nozzles, and/or
any other garden watering tools
-For outdoor use with cold water only
-Do not spray near electrical connections
-When not in use, rinse the tool with water to remove most of the dirt, dry your tool, and store indoors
This product can expose you to chemicals including styrene, which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov
UNLOCK
LOCK
UNLOCK
LOCK
Secure twist-and-lock
mechanism prevents
accidental disconnection
Sliding tabs control
the width
(up to 59ft. (18m))
Width Control
Push down tabs
control the length
(up to 36.1ft.(11m))
Range Control
Allows adjustment of
overall watering area.
Allow simple incremental angle
adjustments without moving the
sprinkler and hose.
Water Flow Control 360° Rotation Adjustment
CAUTION
