Use this manual to familiarize yourself with the various parts and components, the use, handling and features of the
sprinkler. Save this manual for future reference.
Fig. 3
inlet lter
Fig. 5
cleaning pin
Fig. 4
hose-end
tube
Attach your garden hose to the sprinkler.
Use the range sliding tabs to select desired rectangular watering distance. (Fig 1 & Fig 2)
Turn on the faucet and check to see how the process is working. Make adjustments to suit your needs.
Usage
1.
2.
3.
Storage Tips
Drain the sprinkler after use. DO NOT allow water to
freeze in the sprinkler (Fig. 7).
1.
2.
3.
4.
Think of the best coverage design for the watering
without wasting water resources before placing the
sprinkler in the location where you want to water.
Drain any water from the sprinkler after use. This
will preserve the unit for longer lasting use.
Place the sprinkler in a dry warm storage area until
it is required.
Water only when necessary, preferably in the
morning as this will minimize water loss through
evaporation. To obtain deep root growth,water
deeply but do not water often. Watering every
second day will provide for better water coverage.
Using a timer can be helpful in reducing waste.
Watch water application to avoid water run-o.
2 Extra stainless steel
lter washers for a
leak-free seal
96213EDAMZ
Fig. 7
Remove the cleaning pin from the opposite end of
the oscillator (Fig. 5).
3.
Use the provided cleaning pin to clear any clogs
from the spray nozzles while running water in
step 2 (Fig. 6).
4.
Fig. 6
Fig. 6
cleaning pin
spray nozzles
cleaning pin
spray nozzles
If your sprinkler begins to display irregular water pressure or is clogged due to dirt buildup, do the following
maintenance task.
Remove your hose from your sprinkler.
Notice a small inlet lter from the hose-end of the
oscillator, remove it and run under water to remove
the dirt (Fig. 3).
1.
Maintenance + Care
To ush, connect the oscillator to a faucet.
Turn on the faucet and while the water continues
running, spin the tube gently back and forth for few
minutes (Fig 4)
2.
16 NOZZLES ESSENTIAL OSCILLATING SPRINKLER
Base
Spray nozzles (16)
Oscillator tube
Sliding tabs
Plastic nozzle heads :
Adjustable range control :
Coverage Max :
16
Yes
3600 sq ft (335 m²)
(Based on 40PSI / 2.76Bar)
1.
2.
3.
4.
Hose-end
Inlet lter
Cleaning pin
5.
6.
7.
Get To Know Your Sprinkler Specications
7.
2.
1.
5.
6.
4.
3.
Fig. 1 Fig. 2
