DW60M6050**
DW60M6051**
DW60M6040**
Dishwasher
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DD81-02437K-00
DW5500M_DD81-02437K-00_EN.indd 1DW5500M_DD81-02437K-00_EN.indd 1 2019-03-15 4:56:542019-03-15 4:56:54
2_ Safety instructions
Safety instructions
Congratulations on your new Samsung dishwasher. This manual contains
important information on the installation, use and care of your appliance. Please
take time to read this manual to take full advantage of your dishwasher’s many
benefits and features.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Please read this manual thoroughly to ensure that you know how to safely and eciently operate the
extensive features and functions of your new appliance and retain it at a safe place near the appliance for
your future reference. Use this appliance only for its intended purpose as described in this user manual.
Warning and important safety instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, and operating your dishwasher.
Because the following operating instructions cover various models, the characteristics of your dishwasher
may dier slightly from those described in this manual and not all warning signs may be applicable. If you
have any questions or concerns, contact your nearest service center or find help and information online at
www.samsung.com.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
Important safety symbols
WARNING
Hazards or unsafe practices that may result in severe personal injury and/or property
damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using your
dishwasher, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the appliance is grounded to prevent electric shock.
Call the service centre for help.
Note
These warning symbols are here to prevent injury to you and others.
Please follow them explicitly.
Keep these instructions in a safe place and ensure that new users are familiar with the content.
Pass them on to any future owner.
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic
precautions, including the following:
WARNING
DW5500M_DD81-02437K-00_EN.indd 2DW5500M_DD81-02437K-00_EN.indd 2 2019-03-15 4:57:012019-03-15 4:57:01
Safety instructions _3
1. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
2. For use in Europe: This appliance can be used by
children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
3. Children should be supervised to ensure that they do not
play with the appliance.
4. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualifi ed
persons in order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
6. For appliances with ventilation openings in the base, that
a carpet must not obstruct the openings.
7. For use in Europe: Children of less than 3 years should
be kept away unless continuously supervised.
DW5500M_DD81-02437K-00_EN.indd 3DW5500M_DD81-02437K-00_EN.indd 3 2019-03-15 4:57:022019-03-15 4:57:02
4_ Safety instructions
8. CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not
be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly
switched on and o by the utility.
9. This appliance is intended to be used in household and
similar applications such as:
– sta kitchen areas in shops, o ces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments.
10. The door should not be left in the open position since
this could present a tripping hazard.
11. WARNING: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Safety instructions
DW5500M_DD81-02437K-00_EN.indd 4DW5500M_DD81-02437K-00_EN.indd 4 2019-03-15 4:57:022019-03-15 4:57:02
Safety instructions _5
INSTRUCTIONS WHEN USING YOUR DISHWASHER
This dishwasher is not designed for commercial use. It is intended for use in domestic households and
in similar working and residential environments such as:
• Shops
• Oces and showrooms
and by residents in establishments such as:
• Hostels and guest houses.
It must only be used as a domestic appliance as specified in these user manual, for cleaning domestic
crockery and cutlery.
Any other usage is not supported by the manufacturer and could be dangerous.
The manufacturer cannot be held liable for damage resulting from incorrect or improper use or
operation.
Do not use solvents in the dishwasher. Danger of explosion.
Do not inhale or ingest dishwasher detergent. Dishwasher detergents contain irritant or corrosive
ingredients which can cause burning in the nose, mouth and throat if swallowed, or inhibit breathing.
Consult a doctor immediately if detergent has been swallowed or inhaled.
Avoid leaving the door open unnecessarily, as you could trip over it.
Do not sit or lean on the opened door. This could cause the dishwasher to tip and be damaged, and
you could get injured.
Only use detergent and rinse aid formulated for domestic dishwashers.
Do not use washing‐up liquid.
Do not use the strong acid cleaning agent.
Do not fill the rinse aid reservoir with powder or liquid detergent. This will cause serious damage to the
reservoir.
Inadvertently filling the salt reservoir with powder or liquid dishwasher detergent will damage the water
softener. Make sure you have picked up the correct packet of dishwasher salt before filling the salt
reservoir.
Please only use special coarse grained dishwasher salt for reactivation, as other salts may contain
insoluble additives which can impair the functioning of the softener.
In an appliance with a cutlery basket (depending on model), cutlery is cleaned and dried more if placed
in eciently the basket with the handles downwards. However, to avoid the risk of injury, place knives
and forks etc. with the handles upwards.
Plastic items which cannot withstand being washed in hot water, such as disposable plastic
containers, or plastic cutlery and crockery should not be cleaned in the dishwasher.
The high temperatures in the dishwasher may cause them to melt or lose shape.
On models with Delay Start function, make sure that the dispenser is dry before adding detergent.
Wipe dry if necessary. Detergent will clog if poured into a damp dispenser and may not be thoroughly
dispersed.
Knives and other utensils with sharp points must be loaded in the basket with their points down or
placed in a horizontal position.
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
WARNING
DW5500M_DD81-02437K-00_EN.indd 5DW5500M_DD81-02437K-00_EN.indd 5 2019-03-15 4:57:022019-03-15 4:57:02
6_ Safety instructions
INSTRUCTIONS FOR PROTECTING YOUR CHILDREN
This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to
play in or around the dishwasher or to use the controls. They will not understand the potential dangers
posed by it. They should be supervised whenever you are working in the kitchen.
There is also a danger that children playing might shut themselves in the dishwasher.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Older children may only use the dishwasher when its operation has been clearly explained to them and
they are able to use it safely, recognising the dangers of misuse.
KEEP CHILDREN AWAY FROM DETERGENTS! Dishwasher detergents contain irritant and corrosive
ingredients which can cause burning in the mouth, nose and throat if swallowed, or inhibit breathing.
Keep children away from the dishwasher when the door is open.
There could still be detergent residues in the cabinet.
Consult a doctor immediately if your child has swallowed or inhaled detergent.
WARNING
WARNING
WARNING
WARNING
Safety instructions
DW5500M_DD81-02437K-00_EN.indd 6DW5500M_DD81-02437K-00_EN.indd 6 2019-03-15 4:57:032019-03-15 4:57:03
Safety instructions _7
INSTRUCTIONS FOR INSTALLING YOUR DISHWASHER
Before setting up the appliance, check it for any externally visible damage. Under no circumstances
should you use a damaged appliance. A damaged appliance could be dangerous.
The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
The electrical socket must be easily accessible after the dishwasher is installed so that it can be
disconnected from the electricity supply at any time. (Refer to the “Parts and features” section on
page 10.)
There must be no electrical sockets behind the dishwasher. Danger of overheating and fire risk if the
dishwasher were to be pushed up against a plug.
The dishwasher must not be installed under a hob. The high radiant temperatures which are
sometimes generated by a hob could damage the dishwasher. For the same reason it should not be
installed next to open fires or other appliances which give o heat, such as heaters etc.
Do not connect the dishwasher to the mains supply until it has been fully installed and any adjustment
has been made to the door springs.
Before connecting the appliance, check that the connection data on the data plate (voltage and
connected load) match the mains electricity supply. If in any doubt, consult a qualified electrician.
The electrical safety of this appliance can only be guaranteed when continuity is complete between it
and an eective grounding system. It is most important that this basic safety requirement is present
and regularly tested and where there is any doubt the electrical system in the house should be
checked by a qualified electrician.
The manufacturer cannot be held liable for the consequences of an inadequate grounding system (e.g.
electric shock).
Do not connect the appliance to the mains electricity supply by a multi‐socket unit or an extension
lead. These do not guarantee the required safety of the appliance (e.g. danger of overheating).
This appliance may only be installed in mobile installations such as ships if a risk assessment of the
installation has been carried out by a suitably qualified engineer.
The plastic housing of the water connection contains an electrical component. The housing must not
be submerged in water.
There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if it is too long.
Installation, maintenance and repairs may only be carried out by a suitably qualified and competent
person in strict accordance with current national and local safety regulations. Repairs and other work
by unqualified persons can be dangerous. The manufacturer cannot be held liable for unauthorised
work.
WARNING
CAUTION
WARNING
WARNING
CAUTION
CAUTION
CAUTION
DW5500M_DD81-02437K-00_EN.indd 7DW5500M_DD81-02437K-00_EN.indd 7 2019-03-15 4:57:032019-03-15 4:57:03
8_ Safety instructions
The integrated waterproof system oers protection from water damage, provided the following
conditions are met:
• The dishwasher is correctly installed and plumbed in.
• The dishwasher is properly maintained and parts are replaced where it can be seen that this is
necessary.
• The stopcock has been turned o when the appliance is not used for a longer period of time (e.g.
during holidays).
• The waterproof system will work even if the appliance is switched o. However, the appliance must
remain connected to the electricity supply.
A damaged appliance can be dangerous. If the dishwasher gets damaged, switch it o at the mains
and call your dealer or the service department.
Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer
cannot accept liability. Repairs should only be undertaken by an approved service technician.
Faulty components must only be replaced by original spare parts. Only when these parts are fitted can
the safety of the appliance can be guaranteed.
Always disconnect the dishwasher from the electrical supply for maintenance work (switch o at the
wall socket and remove the plug).
If the connection cable is damaged it must be replaced with a special cable, available from the
manufacturer. For safety reasons, this must only be fitted by the service department or an authorised
service technician.
In countries where there are areas which may be subject to infestation by cockroaches or other
vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all
times. Any damage which may be caused by cockroaches or other vermin will not be covered by the
guarantee.
In the event of a fault or for cleaning purposes, the appliance is only completely isolated from the
electiricity supply when:
• it is switched o at the wall socket and the plug is withdrawn, or
• it is switched o at the mains, or
• the mains fuse is disconnected, or
• the screw-out fuse is removed (in countries where this is applicable).
Do not make any alterations to the appliance, unless authorised to do so by the manufacturer.
Never open the casing/housing of the appliance.
Tempering with electrical connections or components and mechanical parts is highly dangerous and
can cause operational faults or electric shock.
While the appliance is under guarantee, repairs should only be undertaken by a service technician
authorised by the manufacturer. Otherwise the guarantee will be invalidated.
When installing the product, make sure there is space at the top, left, right and back of the product to
ensure proper ventilation.
If there is insucient space between the product and the sink, it may damage the sink or allow mold to
grow.
Make sure that your dishwasher’s hardness level setting is correct as your area.
(Refer to the “Water softener mode (Water hardness level setting)” section on page 18.)
CAUTION
WARNING
CAUTION
WARNING
CAUTION
CAUTION
CAUTION
Safety instructions
DW5500M_DD81-02437K-00_EN.indd 8DW5500M_DD81-02437K-00_EN.indd 8 2019-03-15 4:57:032019-03-15 4:57:03
Contents _9
Contents
PARTS AND FEATURES
10
10 Dishwasher features
13 Control panel
16 Displays
USING THE DETERGENT AND WATER
SOFTENER
18
18 Water softener mode
(Water hardness level setting)
19 Loading the salt into the softener
20 Using detergent
21 Using rinse aid
22 How to use the Multi tap option
LOADING THE DISHWASHER RACKS
23
23 Loading the upper basket
25 Loading the lower basket
25 Folding spikes of lower basket
26 Cutlery(silverware) tray
28 For washing in the dishwasher the following
cutlery/dishes
WASHING PROGRAMMES
29
29 Turning on the appliance
29 Change the programme
30 At the end of the wash cycle
30 Wash cycle table
CLEANING AND CARE
32
32 Cleaning the filters
33 Cleaning the spray arms
33 Cleaning the door
33 Caring for the dishwasher
33 Protect against freezing
34 How to maintain your dishwasher
SETTING UP YOUR DISHWASHER
35
35 Water supply and drain
37 Connection of drain hoses
37 Position the appliance
37 Start of dishwasher
INSTALLING YOUR DISHWASHER
38
38 Built under, Semi built in, Fully built in
Dishwasher
TROUBLESHOOTING
44
44 Before calling for service
47 Information codes
APPENDIX
48
48 Specifications
49 Product dimension
DW5500M_DD81-02437K-00_EN.indd 9DW5500M_DD81-02437K-00_EN.indd 9 2019-03-15 4:57:042019-03-15 4:57:04
10_ Part and features
Parts and features
DISHWASHER FEATURES
Front & Rear view (DW60M6050**)
1
2
4
10
4
7
8
8
11
9
9
3
5
5
6
1 3rd Rack
2 Upper Basket
3 Lower Basket
4 Duct Nozzle
5 Salt Container
6 Dispenser
7 Cup Shelf
8 Spray arms
9 Filter assembly
10 Inlet hose
11 Drain hose
Accessory parts - User manual, Salt funnel, cutlery basket.
DW5500M_DD81-02437K-00_EN.indd 10DW5500M_DD81-02437K-00_EN.indd 10 2019-03-15 4:57:042019-03-15 4:57:04
Part and features _11
01 PART AND FEATURES
Front & Rear view (DW60M6051**)
1
2
4
10
4
7
8
8
11
9
9
3
5
5
6
1 3rd Rack
2 Upper Basket
3 Lower Basket
4 Duct Nozzle
5 Salt Container
6 Dispenser
7 Cup Shelf
8 Spray arms
9 Filter assembly
10 Inlet hose
11 Drain hose
Accessory parts - User manual, Salt funnel, cutlery basket.
DW5500M_DD81-02437K-00_EN.indd 11DW5500M_DD81-02437K-00_EN.indd 11 2019-03-15 4:57:062019-03-15 4:57:06
12_ Part and features
Front & Rear view (DW60M6040**)
9
10
1
3
6
7
8
2
4
5
3
7
84
1 Upper Basket
2 Lower Basket
3 Duct Nozzle
4 Salt Container
5 Dispenser
6 Cup Shelf
7 Spray arms
8 Filter assembly
9 Drain hose
10 Inlet hose
Accessory parts - User manual, Salt funnel, cutlery basket.
Parts and features
DW5500M_DD81-02437K-00_EN.indd 12DW5500M_DD81-02437K-00_EN.indd 12 2019-03-15 4:57:072019-03-15 4:57:07
Part and features _13
01 PART AND FEATURES
CONTROL PANEL
DW60M6050F*/DW60M6051F*/DW60M6040F*
DW60M6050U*/DW60M6051U*/DW60M6040U*
DW60M6050S*/DW60M6051S*/DW60M6040S*
DW60M6050
DW60M6051
DW60M6040
4
3
4
2
2
1
9
9
7
7
8
6
6
1
5
1 POWER Press this button to turn on your dishwasher: the screen lights up.
2
Program To select washing program press this button.
3 Half load
For small amount of loading items, use either the upper or lower basket
only to save energy.
Press the Half load button to select the upper or lower basket.
4 Control lock
This option allows you to lock the buttons on the control panel so children
cannot accidentally start the dishwasher by pressing the buttons on the
panel.
To lock and unlock the buttons on the control panel, hold down both the
Control lock buttons for three (3) seconds.
5 Display window Running indicator, delay time, information codes and etc.
6START
To start a cycle, press the START button before closing the door.
*Reset : To cancel a currently running cycle and drain the dishwasher,
press and hold the START button for three (3) seconds.
Once the dishwasher is reset, select a cycle and option, and then press START
to restart the dishwasher.
7 Delay start
Press this button to set the delayed hours for washing. You can delay the
start of washing up to 24 hours. One press on this button delays the start
of washing by one hours.
8 Hygiene
Push the Hygiene button for the best possible hygiene in your
dishwasher. This function is available with all program except Auto,
Quick Wash and Pre Wash.
9 Multi tap
To select Multi tap option which needs salt and rinse aid but a
Multi tab tablet. This function is available with all program except Auto,
Quick Wash and Pre Wash.
DW5500M_DD81-02437K-00_EN.indd 13DW5500M_DD81-02437K-00_EN.indd 13 2019-03-15 4:57:092019-03-15 4:57:09
14_ Part and features
• When the door is open only the POWER button will operate.
• You can select options (Multi tap, Delay start and/or Half load) before starting a cycle.
IMPORTANT: To get the best performance from your dishwasher, read all the operating instructions
before using it for the first time.
DW60M6050BB
3 4 5 10 116 8 971 2
DW60M6040BB
1 POWER Press this button to turn on your dishwasher : the screen lights up.
2 Cycle To select washing program press this button.
3 Upper
When you select Upper, only the upper rack nozzle is activated.
The lower nozzle will not operate.
Use this feature to wash a small load of dishes or glasses placed in the
upper rack.
When you select Upper, place dishes, glasses, etc. in the upper
rack only. The dishwasher will not wash items placed in the lower
rack.
Selecting Upper reduces both the cycle time and the amount of electricity
consumed.
4 Lower
When you select Lower, only the lower rack nozzle is activated. The
upper nozzle will not operate.
Use this feature to wash a small load of dishes or glasses placed in the
lower rack.
When you select Lower, place items, glasses, etc. in the lower rack
only. The dishwasher will not wash items placed in the upper rack.
Selecting Lower reduces both the cycle time and the amount of electricity
consumed.
5 Hygiene
Push the Hygiene button for the best possible hygiene in your
dishwasher. This function is available with all program except Auto,
Quick Wash and Pre Wash.
6 Multi tab
To select Multi tap option which needs salt and rinse aid but a
Multi tap tablet. This function is available with all program except Auto,
Quick Wash and Pre Wash.
Parts and features
DW5500M_DD81-02437K-00_EN.indd 14DW5500M_DD81-02437K-00_EN.indd 14 2019-03-15 4:57:092019-03-15 4:57:09
Part and features _15
01 PART AND FEATURES
7 Control lock
This option allows you to lock the buttons on the control panel so children
cannot accidentally start the dishwasher by pressing the buttons on the
panel.
To lock and unlock the buttons on the control panel, hold down both the
Control lock buttons for three (3) seconds.
8 Indicator
If Rinse Refill or Salt Refill indicator is lit, it means rinse or salt is needed
to refill.
Delay start Indicator
• If the “Delay start” indicator is lit, it means, you select
“Delay start” option.
Rinse Refill Indicator
• If the “Rinse Refill” indicator is lit, it means the dishwasher is low
on dishwasher rinse aid and requires a refill.
Salt Refill Indicator
• If the “Salt Refill” indicator is lit, it means the dishwasher is low
on dishwasher salt and needs to be refilled.
9 Display Display the remaining time, information code, or delay time.
10 Delay start
Press this button to set the delayed hours for washing. You can delay the
start of washing up to 24 hours. One press on this button delays the start
of washing by one hours.
11 START
To start a cycle, press the START button before closing the door.
*Reset : To cancel a currently running cycle and drain the dishwasher,
press and hold the START button for three (3) seconds.
Once the dishwasher is reset, select a cycle and option, and then press START
to restart the dishwasher.
You can select options (Multi tab, Half load, Delay start, Hygiene) before starting a cycle.
To prevent the touchpad from losing response sensitivity, follow these instructions:
• Touch the center of each keypad using one finger. Do not push.
• Clean the touch control’s surface regularly with a soft, damp cloth.
• Be careful not to touch more than one touch key pad at a time, except as directed.
kAĮkAĮkAĮ
DW5500M_DD81-02437K-00_EN.indd 15DW5500M_DD81-02437K-00_EN.indd 15 2019-03-15 4:57:092019-03-15 4:57:09
16_ Part and features
DISPLAYS
DW60M6050F*/DW60M6051F*/DW60M6040F*
DW60M6050U*/DW60M6051U*/DW60M6040U*
DW60M6050S*/DW60M6051S*/DW60M6040S*
2 23 31
DW60M6050/DW60M6051 DW60M6040
1 Program icons Press the Program button to select each program.
Intensive Heavily soiled items include pots and pans
Auto wash
Lightly to heavily soiled daily using items, automatic detection of the
amount of soils.
ECO
Normally soiled daily using items, with reduced energy and water
consumptions.
Express Normal daily used items, with short cycle time.
Quick Wash Lightly soiled with very short cycle time. (DW60M6050/DW60M6051)
Delicate Lightly soiled delicate items.
Pre Wash Cold water rinse for removing dirt before running another program.
2 Display Display the remaining time, information code, or delay time.
3 Refill indicators
If Rinse or Salt Refill indicator is lit, it means rinse or salt is needed to
refill.
Rinse Refill indicator
If Rinse or Salt Refill indicator is lit, it means rinse or salt needs to be
refilled. To refill the rinse reservior, refer to the “When to refill the rinse
aid dispenser” section on page 21.
Salt Refill indicator
If the “Salt Refill” indicator is lit, it means the dishwasher is low on
dishwasher salt and needs to be refilled.
To refill the salt reservior, refer to the “Loading the salt into the
softener” section on page 19.
Parts and features
DW5500M_DD81-02437K-00_EN.indd 16DW5500M_DD81-02437K-00_EN.indd 16 2019-03-15 4:57:102019-03-15 4:57:10
Part and features _17
01 PART AND FEATURES
DW60M6050BB/DW60M6040BB
321
DW60M6050
DW60M6040
1 Program icons Press the Program button to select each program.
Auto wash
Lightly to heavily soiled daily using items, automatic detection of the
amount of soils.
ECO
Normally soiled daily using items, with reduced energy and water
consumptions.
Intensive Heavily soiled items include pots and pans
Quick Wash Lightly soiled with very short cycle time. (DW60M6050/DW60M6051)
Delicate Lightly soiled delicate items.
Express Normal daily used items, with short cycle time.
Pre Wash Cold water rinse for removing dirt before running another program.
2 Refill indicators
If Rinse or Salt Refill indicator is lit, it means rinse or salt is needed to
refill.
Salt Refill indicator
If the “Salt Refill” indicator is lit, it means the dishwasher is low on
dishwasher salt and needs to be refilled.
To refill the salt reservior, refer to the “Loading the salt into the
softener” section on page 19.
Rinse Refill indicator
If Rinse or Salt Refill indicator is lit, it means rinse or salt needs to be
refilled. To refill the rinse reservior, refer to the “Filling the rinse aid
reservoir” section on page 21.
Delay start indicator
If the “Delay start” indicator is lit, it means, you select “Delay start”
option.
3 Display Display the remaining time, information code, or delay time.
DW5500M_DD81-02437K-00_EN.indd 17DW5500M_DD81-02437K-00_EN.indd 17 2019-03-15 4:57:102019-03-15 4:57:10
18_ Using the detergent and water softener
Using the detergent and water
softener
WATER SOFTENER MODE (WATER HARDNESS LEVEL SETTING)
The dishwasher is designed to allow for adjusting the amount of salt consumed based on the hardness of
the water used. This is intended to optimise the level of salt consumption. To set the salt consumption,
proceed as below:
1. Switch on the appliance;
2. Press the Pre Wash button for more than 5 seconds to start the water softener set model within 60
seconds after the appliance was switched on;
• Press the Pre Wash button to select the proper set according to your local environment, the sets
will change in the following sequence: H1 H2 H3 H4 H5 H6; It is recommended that
adjustments should be made in accordance with the following table.
* The manufactory setting: H3 (IEC 60436)
3. Wait for 5 seconds to end the set up model.
WATER HARDNESS
Selector Position
Salt consumption
(gram/cycle)
º dH º fH º Clark mmol/l
0-5 0-9 0-6 0-0.94 H1 0
6-11 10-20 7-14 1.0-2.0 H2 9
12-17 21-30 15-21 2.1-3.0 H3 12
18-22 31-40 22-28 3.1-4.0 H4 20
23-34 41-60 29-42 4.1-6.0 H5 30
35-55 61-98 43-69 6.1-9.8 H6 60
1 dH (German degree) = 0.178 mmol/l
1 Clark (British degree) = 0.143 mmol/l
1 fH (French degree) = 0.1 mmol/l
Contact your local water board for information on the hardness of your water supply.
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits
may form on dishes and utensils. The appliance is equipped with a special softener that uses a salt
specifically designed to eliminate lime and minerals from the water.
[Deposits on utensils]
DW5500M_DD81-02437K-00_EN.indd 18DW5500M_DD81-02437K-00_EN.indd 18 2019-03-15 4:57:102019-03-15 4:57:10
Using the detergent and water softener _19
02
USING THE DETERGENT AND WATER SOFTENER
LOADING THE SALT INTO THE SOFTENER
Always use salt intended for use with dishwasher.
The salt container is located beneath the lower rack and should be filled as follows:
ATTENTION
• Only use salt specifically designed for use in dishwashers. All other types of salt not specifically
designed for use in a dishwasher, especially table salt, will damage the water softener. In case of
damages caused by the use of unsuitable salt the manufacturer does not give any warranty nor is
liable for any caused damages.
• Only fill with salt just before starting one of the complete washing programs. This will prevent any
grains of salt or salty water, which may have been split, remaining of the bottom of the machine for
any period of time, which may cause corrosion.
• After the first wash cycle the control panel light expires.
1. Remove the lower basket and then unscrew and remove the cap from
the salt container.
Open
Open
2. If you are fi lling the container for the fi rst time, fi ll 2/3 of its volume with water (around 1 liter).
3. Place the end of the funnel (supplied) into the hole and introduce about
1.5 kg of salt. It is normal for a small amount of water to come out of
the salt container.
4. Carefully screw the cap back on.
5. Usually, the salt warning light will be o after the salt container is fi lled with salt.
• The salt container must be refilled when the salt warning light on the control panel comes on.
Although the salt container is filled enough, the indicator light may not switch o until the salt fully
dissolves.
If there is no salt warning light on the control panel, you can judge when to load the salt into the
softener by the cycles that the dishwasher has run.
• If a lot of salt is spilt inside the dishwasher, run a pre wash program to reduce the spillage.
DW5500M_DD81-02437K-00_EN.indd 19DW5500M_DD81-02437K-00_EN.indd 19 2019-03-15 4:57:102019-03-15 4:57:10
20_ Using the detergent and water softener
USING DETERGENT
All dishwasher cycles require detergent in the detergent compartment.
Add the correct amount of detergent for the selected cycle to ensure the best performance.
CAUTION: Use dishwasher detergent only. Regular detergent produces too much foam, which may
decrease the dishwasher’s performance or cause it to malfunction.
WARNING: Do not swallow dishwasher detergent. Avoid breathing in the fumes. Dishwasher
detergent contains irritants and caustic chemicals that can induce respiratory conditions. If you have
swallowed dishwasher detergent or inhaled the fumes, seek medical attention immediately.
WARNING: Keep dishwasher detergent out of the reach of children.
Filling the detergent dispenser
1. Open the detergent dispenser fl ap by pushing the detergent
dispenser release catch.
The flap is always open at the end of a dishwashing cycle.
2. Add the recommended amount of detergent to the main
wash detergent compartment.
3. Close the fl ap by sliding it to the left and then pressing it
down.
There is no separate button that is specific to using tablet
detergents.
4. For better cleaning result, especially if you have very dirt
items, add small amount (about 8 g) of detergent on the
door. That will act in prewash phase.
Using the detergent and water
softener
DW5500M_DD81-02437K-00_EN.indd 20DW5500M_DD81-02437K-00_EN.indd 20 2019-03-15 4:57:132019-03-15 4:57:13
Using the detergent and water softener _21
02
USING THE DETERGENT AND WATER SOFTENER
USING RINSE AID
Filling the rinse aid reservoir
When the Rinse Refill indicator lights up on the control panel, refill with rinse aid.
Your dishwasher has been designed to use liquid rinse aid only.
Using a powdered rinse aid will clog the reservoir opening and cause the dishwasher to
malfunction.
Rinse aid improves the drying performance of the dishwasher.
CAUTION: Do not add regular detergent to the rinse aid reservoir.
1. Remove the rinse aid reservoir cap by rotating it
counterclockwise.
Adding rinse aid to tablet detergents will improve drying
performance.
2. Fill the rinse aid reservoir with rinse aid.
Use the viewing port when filling the rinse aid reservoir.
CAUTION: Do not fill the reservoir above the full level
indicator.
Excess rinse aid can overflow during the wash cycle.
3. Turn the rinse aid indicator dial to a number between 1 and
6. The higher the number, the more rinse aid the dishwasher
uses. If you are unable to rotate the rinse aid dial easily, try
using a coin.
4. Close the rinse aid reservoir cap by rotating it clockwise.
DW5500M_DD81-02437K-00_EN.indd 21DW5500M_DD81-02437K-00_EN.indd 21 2019-03-15 4:57:142019-03-15 4:57:14
22_ Using the detergent and water softener
HOW TO USE THE MULTI TAP OPTION
Your dishwasher has a Multi tap option which does not need salt and rinse aid but a 3 In1 tablet. This
option can select on Intensive, Eco program only.
The Multi tap setting is only for use with Multi tap tablets. If using Multi tap tablet without this option,
the appliance will not get its best performance.
1. Put the Multi tap tablet into the container then start the Multi tap
option.
2. Close the lid and press until it locks in place.
When using Multi tap compact combination detergents ensure
that the lid can be closed correctly.
ATTENTION: Keep all detergents in a safe place out of
children’s reach. Always add the detergent in the dispenser just
before starting the dishwasher.
Using the detergent and water
softener
DW5500M_DD81-02437K-00_EN.indd 22DW5500M_DD81-02437K-00_EN.indd 22 2019-03-15 4:57:142019-03-15 4:57:14
Loading the dishwasher racks _23
03 LOADING THE DISHWASHER RACKS
Loading the dishwasher racks
For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of racks and silverware baskets may vary from your
model.
Attention before or after loading the dishwasher racks
Scrape o any large amounts of leftover food. It is not necessary to rinse the dishes under running
water. Place objects in the dishwasher in the following order:
1. Items such as cups, glasses, pots/pans, etc. are stood upside down.
2. Curved items, or those with recesses, should be at a slant so that water can run o.
3. Ensure they are stacked securely and can not tip over.
4. Ensure they do not prevent the spray arms from rotating while washing takes place.
Very small items should not be washed in the dishwasher as they could easily fall out of the racks.
Removing the dishes
To prevent water dripping from the upper basket into the lower basket, we recommend that you empty
the lower basket first and then the upper basket.
LOADING THE UPPER BASKET
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coee and tea
cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
Position the dishes and cookware so that they will not get moved by the spray of water. Always place
glasses, cups & bowls upside down.
IN
3
2
4
5
6
1
3
3
3
1
6
3
3
3
7
8
2
4
5
3
9
IN
DW60M6050
DW60M6051
(14 place setting)
DW60M6040
(13 place setting)
Cups
1
2
Saucers
3
Glasses
4
Small serving bowl
5
Medium serving bowl
6
Large serving bowl
7
Knives
8
Forks
9
Soup spoons
DW5500M_DD81-02437K-00_EN.indd 23DW5500M_DD81-02437K-00_EN.indd 23 2019-03-15 4:57:142019-03-15 4:57:14
24_ Loading the dishwasher racks
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to create more space for large utensils
both for the upper/lower basket.
1. To lower the upper rack, press the “A”
levers located at the left and right sides
of the upper basket and push the upper
basket downwards slightly at the same
time.
2. To raise the upper rack, just pull the
upper basket upwards without operating
any levers.
CAUTION: We recommend adjusting
the height of the upper basket before
loading dishes into the basket. If you
adjust the the basket after loading the
dishes, you may damage the dishes.
To lower position To upper position
Loading the dishwasher racks
DW5500M_DD81-02437K-00_EN.indd 24DW5500M_DD81-02437K-00_EN.indd 24 2019-03-15 4:57:162019-03-15 4:57:16
Loading the dishwasher racks _25
03 LOADING THE DISHWASHER RACKS
LOADING THE LOWER BASKET
We recommend that you place large items which are most dicult to clean in to the lower rack: pots, pans,
lids, serving dishes and bowls, as shown in the figure to the right.
It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the
rotation of the top spray arm. Pots, serving bowls, etc. must always be placed top down.
Deep pots should be slanted to allow water to flow out.
The bottom rack feature fold down tine rows so that larger or more pots and pans can be loaded.
11
10
10 11
12
13
11 11
10
10
12
13
DW60M6050
DW60M6051
(14 place setting)
DW60M6040
(13 place setting)
10
Dessert dishes
11
Dinner plates
12
Soup bowls
13
Oval platter
IN
Long items, serving cutlery, salad servers and big knives should be placed on the shelf so that they do
not obstruct the rotation of the spray arms.
FOLDING SPIKES OF LOWER BASKET
For better stacking of pots and pans, the spikes can be folded down and/or removable tine as show in the
picture below.
DW60M6050
DW60M6051
DW60M6040
DW60M6050
DW60M6051
DW5500M_DD81-02437K-00_EN.indd 25DW5500M_DD81-02437K-00_EN.indd 25 2019-03-15 4:57:162019-03-15 4:57:16
26_ Loading the dishwasher racks
CUTLERY(SILVERWARE) TRAY
Silverware should be placed in the cutlery tray with handles at the bottom: The spoon should be loaded
individually into the appropriate slots, especially long utensils should be placed in the horizontal position at
the front of the upper basket.
DW60M6050/DW60M6051
3
7
5
2
2
3
8
6
6
2
2
4
1
1
1 Soup spoons 5 Dessert spoons
2 Forks 6 Serving spoons
3 Knives 7 Serving forks
4 Teaspoons 8 Gravy ladles
WARNING
• Do not let any item extend through the bottom.
• Always load sharp utensils with the sharp point down!
Loading the dishwasher racks
DW5500M_DD81-02437K-00_EN.indd 26DW5500M_DD81-02437K-00_EN.indd 26 2019-03-15 4:57:202019-03-15 4:57:20
Loading the dishwasher racks _27
03 LOADING THE DISHWASHER RACKS
DW60M6040
8
4
41
1
1
41
1
4
1
5
5
5
5
5
5
5
5
2
2
55
5
7
5
4
4
4
1
4
3
3
1
1
1
1
1
4
4
4
4
1 Soup spoons 5 Dessert spoons
2 Forks 6 Serving spoons
3 Knives 7 Serving forks
4 Teaspoons 8 Gravy ladles
WARNING
• Do not let any item extend through the bottom.
• Always load sharp utensils with the sharp point down!
DW5500M_DD81-02437K-00_EN.indd 27DW5500M_DD81-02437K-00_EN.indd 27 2019-03-15 4:57:212019-03-15 4:57:21
28_ Loading the dishwasher racks
FOR WASHING IN THE DISHWASHER THE FOLLOWING CUTLERY/
DISHES
Not suitable Limited suitability
Plastic items that are not heat resistant.
Older cutlery with glued parts that is not
temperature resistant.
Bonded cutlery items or dishes.
Pewter or copper items Lead crystal glass.
Steel items subject to rusting.
Wooden platters.
Items made from synthetic fibres.
Some types of glasses can become dull after a
large number of washes.
Silver and aluminium parts have a tendency to
discolour during washing.
Glazed patterns may fade if machine washed
frequently.
Do not try and wash items soiled with cigarette ash, candle wax, lacquer or paint. If you buy new
dishes please make sure that they are suitable for dishwashers.
Please do not overload your dishwasher. Do not use any dishes that are not suitable for dishwashers.
This is important for good results and for reasonable energy consumption.
When loading the dishes and cutlery
Dishes and cutlery must not impede the rotation of the spray arms.
Load hollow items such as cups, glasses, pans etc. with the opening downwards so that water
cannot collect in the container or a deep base.
Dishes and items of cutlery must not lie inside one another, or cover each other
• To avoid damage to glasses, they must not touch.
• Load large items which are most dicult to clean into the lower rack.
• The upper rack is designed to hold more delicate and lighter dishware such as glasses,
coee and tea cups.
ATTENTION
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in
the upper basket.
Damage to glassware and other dishes.
Possible causes Suggested remedy
• Type of glass or manufacturing process.
Chemical composition of detergent.
• Water temperature and duration of
dishwasher programme.
• Use glassware or porcelain dishes that
have been marked dishwasher-proof by
the manufacturer.
• Use a mild detergent that is described as
kind of dishes If necessary, seek further
information from detergent manufacturers.
• Select a programme with as low a
temperature.
• To prevent damage, take glass and cutlery
out of the dishwasher as soon as possible
after the programme has ended.
Loading the dishwasher racks
DW5500M_DD81-02437K-00_EN.indd 28DW5500M_DD81-02437K-00_EN.indd 28 2019-03-15 4:57:222019-03-15 4:57:22
Washing programmes _29
04 WASHING PROGRAMMES
Washing programmes
TURNING ON THE APPLIANCE
Starting a cycle wash
1. Draw out the lower and upper basket, load the dishes and push them back..
It is recommended to load the lower basket fi rst, then the upper one (see the section entitled “Loading
the dishwasher racks”).
2. Pour in the detergent (see the section entitled “Using the detergent and water softener”).
3. Insert the plug into the socket. The power supply is 220-240 V~, 50 Hz, the specifi cation of the socket
is 10A 250 VAC. Make sure that the water supply is turned on to proper pressure.
4. Close the door, press the POWER button, to switch on the machine.
A click could be heard when the door is closed perfectly. When the washing is over, you can shut o
the switch by pressing POWER button.
CHANGE THE PROGRAMME
Premise:
1. A cycle that is underway can only be modifi ed if it has only been running for a short time. Otherwise, the
detergent may have already been released, and the appliance may have already drained the wash water.
If this is the case, the detergent dispenser must be refi lled (see the section entitled “Filling the detergent
dispenser”).
2. Press POWER button or Reset button 3 seconds to cancel the programme, and turn on it again, then
you can change the programme to the desired cycle setting.
If you open the door during a wash cycle, the machine will pause. The program light will stop blinking
and the buzzer will beep every minute unless you close the door. After you close the door, the machine
will keep on working after 3 seconds automatically.
If your model has broken memory function, the machine will go on to finish the selected program after
the power cut.
Adding dishes
A forgotten dish can be added at any time before the detergent dispenser opens.
1. Open the door a little to stop the washing.
2. After the spray arms stop working, you can open the door completely.
3. Add forgotten dishes.
4. Close the door, the dishwasher will work after ten seconds.
WARNING: It is dangerous to open the door when washing, because the hot water may
scald you. If the door is opened while the dishwasher is running, a safety mechanism is
activated and stops the cycle.
DW5500M_DD81-02437K-00_EN.indd 29DW5500M_DD81-02437K-00_EN.indd 29 2019-03-15 4:57:222019-03-15 4:57:22
30_ Washing programmes
AT THE END OF THE WASH CYCLE
When the working cycle has finished, the buzzer of dishwasher will beep shortly, then stop. In the digital
display appears “0”, only in this case the programme has ended.
1. Switch o the dishwasher by pressing the POWER button.
2. Turn o the water tap!
Open the door carefully. Hot steam may escape when the door is opened!
• Hot dishes are sensitive to knocks. The dishes should be allowed to cool down around 15 minutes
before removing from the appliance.
• Open the dishwasher’s door, leave it and wait a few minutes before removing the dishes. In this
way they will be cooler and the drying will be improved.
• Unloading the dishwasher.
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper
basket onto the dishes in the lower one.
WASH CYCLE TABLE
DW60M6050/DW60M6051/DW60M6040
Program Description of Cycle
Detergent
(Prewash/Main wash) (g)
Running time
(min)
Water (ℓ)
Intensive
Pre Wash (50 °C)
5/30 175 17.5
Wash (60 °C)
Rinse
Rinse
Rinse (70 °C)
Drying
Intensive + Hygiene
Pre Wash (50 °C)
5/30 200 17.5
Wash (60 °C)
Rinse
Rinse
Rinse (70 °C)
Drying
ECO *
Pre Wash
5/30 225 10.5
Wash (50 °C)
Rinse (55 °C)
Drying
ECO + Hygiene
Pre Wash
5/30 235 10.5
Wash (50 °C)
Rinse (60 °C)
Drying
Delicate
Pre Wash
5/30 130 13
Wash (40 °C)
Rinse
Rinse (60 °C)
Drying
Delicate + Hygiene
Pre Wash
5/30 140 13
Wash (40 °C)
Rinse
Rinse (65 °C)
Drying
Washing programmes
DW5500M_DD81-02437K-00_EN.indd 30DW5500M_DD81-02437K-00_EN.indd 30 2019-03-15 4:57:222019-03-15 4:57:22
Washing programmes _31
04 WASHING PROGRAMMES
Program Description of Cycle
Detergent
(Prewash/Main wash) (g)
Running time
(min)
Water (ℓ)
Express
Pre Wash (50 °C)
5/30 60 10
Wash (60 °C)
Rinse (60 °C)
Drying
Express + Hygiene
Pre Wash (50 °C)
5/30 80 10
Wash (60 °C)
Rinse (65 °C)
Drying
Quick Wash
(DW60M6050**/DW60M6051**)
Wash (45 °C)
25 30 11
Rinse (50 °C)
Rinse (55 °C)
Auto
Pre Wash (45 °C)
5/30 150 11-15
Auto (45-55 °C)
Rinse
Rinse (65 °C)
Drying
Pre Wash Pre Wash / 15 4
* IEC 60436: This program is the test cycle. The information for comparability test in accordance with
IEC 60436.
The wash time varies depending on the pressure and temperature of the supplied water.
Quick Wash: Continuous use of the Quick Wash cycle for an extended time is not recommended. This
may reduce the performance of the water softener.
DW5500M_DD81-02437K-00_EN.indd 31DW5500M_DD81-02437K-00_EN.indd 31 2019-03-15 4:57:222019-03-15 4:57:22
32_ Cleaning and care
Cleaning and care
CLEANING THE FILTERS
Filtering system
For your convenience, we have placed the drain pump and filtering system within easy reach
inside the tub. There are three components of the filtering system: the main filter, the coarse filter,
and the fine filter.
1. Main fi lter: Food and soil particles trapped by this fi lter are
pulverized by a special jet on the lower spray arm and washed down
the drain.
2. Coarse fi lter: Larger items, such as pieces of bone or glass, that
could clog the drain are trapped in the coarse fi lter. To remove an
item caught in this fi lter, gently squeeze the tabs on top of this fi lter
and lift it out.
3. Fine fi lter: This fi lter holds soil and food residue in the sump area
and prevents it from being redeposited on the dishes during a cycle.
2
1
3
ATTENTION: Do not put the fine filter upside down.
Filter assembly
For best performance and results, the filter assembly must be cleaned. The filter eciently
removes food particles from the wash water, allowing it to be recirculated during the cycle.
For this reason, it is a good idea to remove the larger food particles trapped in the filter after
each wash cycle by rinsing the semicircular filter and cup under running water. To remove the
filter assembly, turn it in anti-clockwise direction and lift the filter assembly up. The entire filter
assembly should be cleaned regularly.
To clean the coarse filter and the fine filter, use a cleaning brush. Then, reinsert the entire
assembly in the dishwasher, positioning in its seat, pressing downward, turning it clockwise
direction.
Open
Open
The dishwasher must never be used without the filters. Improper replacement of the filter may
reduce the performance level of the appliance and damage dishes and utensils.
WARNING: Never run the dishwasher without the filters in place. When cleaning the filters,
do not damage them. Otherwise the filters may not perform as intended and poor wash
results or damage to the internal parts may be encountered.
DW5500M_DD81-02437K-00_EN.indd 32DW5500M_DD81-02437K-00_EN.indd 32 2019-03-15 4:57:222019-03-15 4:57:22
Cleaning and care _33
05 CLEANING AND CARE
CLEANING THE SPRAY ARMS
It is necessary to clean the spray arms regularly as hard water residue can clog
the spray arm jets and bearings. To remove the middle spray arm, hold the nut,
rotate the arm clockwise to remove it. To remove the lower spray arm, pull out
the spray arm upward. Wash the arms in warm and soapy water and use a soft
brush to clean the jets. Replace them after rinsing them thoroughly.
Open
CLEANING THE DOOR
To clean the edge around the door, you should use only a soft warm, damp cloth.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch the
finish. Some papers towels can also scratch or leave marks on the surface.
WARNING: Never use a spray cleaner to clvean the door panel for it could damage the door lock and
electrical components. It is not advised to use the abrasive agent or some paper towel because of the
risk of scratching or leaving spots on the stainless steel surface.
CARING FOR THE DISHWASHER
To clean the control panel use a lightly damp cloth then dry thoroughly. To clean the exterior use a good
appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
PROTECT AGAINST FREEZING
If your dishwasher is left in an unheated place during the winter:
1. Cut o electrical power to the dishwasher.
2. Turn o the water supply and disconnect the water inlet pipe from the water valve.
3. Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4. Reconnect the water inlet pipe to the water valve.
5. Remove the fi lter in the tub the bottom and use a sponge sock up water.
DW5500M_DD81-02437K-00_EN.indd 33DW5500M_DD81-02437K-00_EN.indd 33 2019-03-15 4:57:232019-03-15 4:57:23
34_ Cleaning and care
HOW TO MAINTAIN YOUR DISHWASHER
• After Every Wash
After every wash, turn o the water supply to the appliance and leave the door slightly ajar so that
moisture and odours not trapped inside.
• Remove the Plug
Before cleaning or performing maintenance, always remove the plug from the socket.
• No Solvents or Abrasive cleaning
To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning
products. use only a cloth and warm soapy water. To remove spots or stains from the surface of
the interior, Use a cloth dampened with water and a little white vinegar, or a cleaning product made
specifically for dishwashers.
• When You Go on Holiday
When you go on holiday, it is recommended that you run a wash cycle with the dishwasher empty and
then remove the plug from the socket, turn o the water supply and leave the door of the appliance
slightly ajar. This will help the seals last longer and prevent odours from forming within the appliance.
• Moving the Appliance
If the appliance must be moved, try to keep it in the vertical position. If absolutely necessary, it can be
positioned on its back.
• Seals
One of the factors that cause odours to form in the dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this from occurring.
Cleaning and care
DW5500M_DD81-02437K-00_EN.indd 34DW5500M_DD81-02437K-00_EN.indd 34 2019-03-15 4:57:232019-03-15 4:57:23
Setting up your dishwasher _35
06 SETTING UP YOUR DISHWASHER
Setting up your dishwasher
WARNING : Electrical shock hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
ATTENTION: The installation of the pipes and electrical equipments should be done by professionals.
About electricity connecting
CAUTION, for personal safety:
DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE THIRD GROUNDING
PRONG FROM THE POWER CORD.
Electrical requirements
• An 220-240 V~, 50 Hz fuse or a circuit breaker.
• An individual branch circuit serving your dishwasher.
Grounding instructions
Insure proper ground exists before use
This appliance must be grounded. In the event of a malfunction or breakdown, grounding
will reduce the risk of electric shock by providing a path of least resistance of electric
current. This appliance is equipped with a cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into an appropriate outlet that is installed
and grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment grounding conductor can result in the
risk of an electric shock. Check with a qualified electrician or service representative if you
are in doubt whether the appliance is properly grounded. Do not modify the plug provided
with the appliance.
WATER SUPPLY AND DRAIN
Cold water connection
Connect the cold water supply hose to a threaded 3/4 (inch)
connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an
extended period of time, let the water run to make sure that the
water is clear. This precaution is needed to avoid the risk of the
water inlet to be blocked and damage the appliance.
Provided water supply hose has the aqua-safe system.
Ensure that water supply hose’s aqua-safe pipe is
connected to the faucet.
DW5500M_DD81-02437K-00_EN.indd 35DW5500M_DD81-02437K-00_EN.indd 35 2019-03-15 4:57:232019-03-15 4:57:23
36_ Setting up your dishwasher
Hot water connection
The water supply to the appliance can also be connected to the house hot water line (centralized
system, heating system), as long as it does not exceed a temperature of 60 °C. In this case, the
wash cycle time will be shortened by about 15 minutes and the wash eciency slightly reduced.
The connection must be made to the hot water line following the same procedures as those for
the connection to the cold water line.
Positioning the appliance
Position the appliance in the desired location. The back should rest against the wall behind
it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with
water supply and drain hoses that can be positioned to the right or the left to facilitate
proper installation.
How to drain excess water from hoses
If the sink is 1000 mm higher from the floor, the excess water in hoses cannot be drained
directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
Water outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
Extension hose
If you need a drain hose extension, Use a similar size and quality drain hose.
It must be no longer than 4 metres; otherwise the cleaning eect of the dishwasher could be
reduced.
Syphon connection
The waste connection must be at a height of between 40 cm (minimum) and 100 cm (maximum)
from the bottom of the dishwasher. The water drain hose should be fixed by a hose clip.
Aqua-safe
The Aqua-safe System is a safety valve system, preventing water leaks. If the water inlet hose
starts to leak anytime, the safety valve cuts o the running water. If the water inlet hose or the
safety valve is damaged, remove and replace it.
Do not enlarge or shorten the inlet hose.
Setting up your dishwasher
DW5500M_DD81-02437K-00_EN.indd 36DW5500M_DD81-02437K-00_EN.indd 36 2019-03-15 4:57:232019-03-15 4:57:23
Setting up your dishwasher _37
06 SETTING UP YOUR DISHWASHER
CONNECTION OF DRAIN HOSES
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making
sure to avoid bending or crimping it. The top of the hose must be at a height between 40 and 100 cm. The
free end of the hose must not be immersed in water to avoid the back flow of it.
NOTE
The top of the hose must
be at a height between
40 and 100 cm.
The free end of the hose
must not be immersed in
water.
Drain pipe
40 mm
Counter
Min. 400 mm
Max 1000 mm
POSITION THE APPLIANCE
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that
can be positioned either to the right or the left sides to facilitate proper installation.
Levelling the Appliance
Once the appliance is positioned for levelling, the height of the
dishwasher may be altered via adjustment of the screwing level of the
feet. In any case, the appliance should not be inclined more than 2°.
START OF DISHWASHER
The following should be checked before starting the dishwasher.
1. the dishwasher is level and fi xed
2. the inlet valve is opened
3. There is no leakage at the connections of the conducts
4. the wires are tightly connected
5. the power is switched on
6. the inlet and drain hoses are not knotted
7. All packaging materials and printings have been taken out of the dishwasher
ATTENTION: After installation please put this manual in a safe place. The contents of this manual can
be useful to users.
DW5500M_DD81-02437K-00_EN.indd 37DW5500M_DD81-02437K-00_EN.indd 37 2019-03-15 4:57:232019-03-15 4:57:23
38_ Installing your dishwasher
Installing your dishwasher
BUILT UNDER, SEMI BUILT IN, FULLY BUILT IN DISHWASHER
Be sure that you or your installer follow these instructions closely so that your new dishwasher works
properly and that you’re not at risk of injury when washing dishes.
New installation
If the dishwasher is a new installation, most of the installation work must be done before the
dishwasher is moved into place.
Replacement
If the dishwasher is replacing an old dishwasher, you must check the exising dishwasher connections
for compatibility with the new dishwasher. Replace the existing connections as necessary.
STEP 1. SELECTING THE BEST LOCATION FOR THE DISHWASHER
The installation position of dishwasher should be near the existing inlet and drain hoses and power
cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of the
dishwasher.
1. Choose a place near the sink to facilitate the installation of inlet and drain hoses.
2. Less than 5mm between the top of dishwasher and cabinet and the outer door aligned to cabinet.
820~870
820~870
580
580
minimum
minimum
Electrical, drain
Electrical, drain
and water supply
and water supply
line entrances
line entrances
Space between cabient
Space between cabient
bottom and floor
bottom and floor
600 minimum
600 minimum
100
100
90°
90°
90°
90°
3. If dishwasher is in stalled at the corner of the cabinet, there
should be some space when the door is opened.
cabinet
Dishwasher
Dishwasher
Door of
Door of
Dishwasher
Dishwasher
Minimum space
of 50 mm
Depending on where your electrical outlet is, you may need to cut a hole in the opposite cabinet side.
DW5500M_DD81-02437K-00_EN.indd 38DW5500M_DD81-02437K-00_EN.indd 38 2019-03-15 4:57:232019-03-15 4:57:23
Installing your dishwasher _39
07 INSTALLING YOUR DISHWASHER
STEP 2. CHECKING WATER SUPPLY AND ELECTRICAL
REQUIREMENTS
• The water supply line pressure must be between 0.04-1.0 MPa.
• Supply cold water only. Make sure that the water temperature does not exceed 60 ˚C.
• Do not supply hot water. Otherwise, the product may malfunction.
• Use a rated power of 220-240 V~, 50 Hz.
• Install the product while the power cord is unplugged.
• Use a power outlet with a maximum allowable current of 16 A. (The maximum current for this dish
washer is 11 A.)
• When powering the dishwasher, ensure that your power supply has:
- An 220-240 V~, 50 Hz fuse or circuit breaker.
- An individual branch circuit serving your dishwasher.
• After the installation, check if the power cord is not bent or damaged.
• Ensure that the water supply valve is turned o before connecting the water supply line to the
dishwasher.
• Seal the water supply line connections using teflon tape or sealing compound to stop any water
leakage.
STEP 3. PREPARING THE CUSTOM PANEL
(FOR FULLY BUILT IN AND SEMI BUILT IN DISHWASHER)
The custom panel should be processed in accordance with the illustrated dimensions.
A
A
A
A-A
589
38
436
30
720 (MAX)
20(MAX)
2-Ø 5.5
2-Ø 2( 8)
4-Ø 2(
8)
8-Ø 2(
8)
2-Ø 11
517
474.8
127
566±0.2
451±0.2
540±0.2
75±0.2
62
ف
18
6-8
8-9.5
1.5
6-C1.5
1.5
566
589
36
220
115.5
20
220
570 (MAX)
397
202
7
6-Ø 1
8-Ø 2
20
Fully built in
Semi built in
CAUTION
WARNING
DW5500M_DD81-02437K-00_EN.indd 39DW5500M_DD81-02437K-00_EN.indd 39 2019-03-15 4:57:242019-03-15 4:57:24
40_ Installing your dishwasher
Fully built in
1. Install the hook on the custom wooden panel and put the hook into the slot of the outer door
of dishwasher.
2. After positioning of the panel, fi x the panel onto the outer door by screws and bolts.
CAUTION: Use a custom panel between 3~8 kg.
Take away the four short screws.
Pin up the four long screws.
Semi built in
1. Magical paster A and magical paster B be disjoined on, magical paster A on the custom
wooden panel and felted magical paster B of the outer door of dishwasher.
2. After positioning of the panel, fi x the panel onto the outer door by screws and bolts.
CAUTION: Use a custom panel between 3~7 kg.
Magical Paster
Magical Paster
Take away the four short screws.
Pin up the four long screws.
Installing your dishwasher
DW5500M_DD81-02437K-00_EN.indd 40DW5500M_DD81-02437K-00_EN.indd 40 2019-03-15 4:57:242019-03-15 4:57:24
Installing your dishwasher _41
07 INSTALLING YOUR DISHWASHER
STEP 4. TENSION ADJUSTMENT OF THE DOOR SPRING
(FOR FULLY BUILT IN AND SEMI BUILT IN DISHWASHER)
Ƹť
UĮǮĘ
1. The door springs are set at the factory to the proper tension for the outer door. If custom wooden panel
are installed, you will have to adjust the door spring tension. Rotate the adjusting screw to drive the
adjustor to strain or relax the steel cable.
2. Door spring tension is correct when the door remains horizontal in the fully opened position yet rises to
a close with the slight lift of a fi nger.
DW5500M_DD81-02437K-00_EN.indd 41DW5500M_DD81-02437K-00_EN.indd 41 2019-03-15 4:57:242019-03-15 4:57:24
42_ Installing your dishwasher
STEP 5. DISHWASHER INSTALLATION
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
1. Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer to the
template for positioning of the brackets. (For Fully built in and Semi built in dishwasher)
2. Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to tight en the
left and right door springs. Failure to do this could cause damage to your dishwasher. (For Fully built in
and Semi built in dishwasher)
3. Connect the inlet hos e to the cold water supply.
4. Connect the drain hose. Refer to diagram.
5. Connect the power cord.
6. A x the condensation strip under the work surface of cabinet. Please ensure the condensation strip is
fl ush with edge of work surface.
7. Place the dishwasher into position.
8. Level the dishwasher. The rear food can be adjusted from the front of the dishwasher by turning the
Allen screw in the middle of the base of dishwasher use an Allen key. To adjust the front feet, use a fl at
screw driver and turn the front feet until the dishwasher is level.
9. The dishwasher must be secured in place. There are two ways to do this:
A. Normal work surface : Put the installation hook into the slot of the side plane and se cure it to the
work surface with the wood screws.
B. Marble or granite work top : Fix the side with Screw.
Installing your dishwasher
DW5500M_DD81-02437K-00_EN.indd 42DW5500M_DD81-02437K-00_EN.indd 42 2019-03-15 4:57:242019-03-15 4:57:24
Installing your dishwasher _43
07 INSTALLING YOUR DISHWASHER
STEP 6. LEVELLING THE DISHWASHER
Check level
front to back
Check level
side to side
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
Dishwasher must be level for proper dish rack operation and wash performance.
1. Place a spirit level on door and rack track inside the tub as shown to check that the dishwasher is level.
2. Level the dishwasher by adjusting the three levelling legs individually.
3. When level the dishwasher, please pay attention not to let the dishwasher tip over.
If the height of the leg is not high enough, use extra feet.
DW5500M_DD81-02437K-00_EN.indd 43DW5500M_DD81-02437K-00_EN.indd 43 2019-03-15 4:57:242019-03-15 4:57:24
44_ Troubleshooting
Troubleshooting
The manufacturer, following a policy of constant development and up-dating of
the product, may make modifications without giving prior notice.
BEFORE CALLING FOR SERVICE
PROBLEM POSSIBLE CAUSE WHAT TO DO
Dishwasher doesn’t
run
• Fuse blown or the circuit
breaker tripped.
• Replace fuse or reset circuit breaker.
Remove any other appliances sharing the
same circuit with the dishwasher.
• Power supply is not turned
on.
• Make sure the dishwasher is turned on
and the door is closed securely.
Make sure the power cord is properly
plugged into the wall socket.
• Water pressure is low. • Check that the water supply is connected
properly and the water is turned on.
Drain pump doesn’t
stop
• Overflow. • The system is designed to detect an
overflow. When it does, it shuts o the
circulation pump and turns on the drain
pump.
Noise • Some audible sounds are
normal.
• Sound from soft food shredding action
and detergent cup opening.
• Utensils are not secure in
the baskets or something
small has dropped into the
basket.
• To ensure everything is secured in the
dishwasher.
• Motor hums. • Dishwasher has not been used regularly.
If you do not use it often, remember to
set it to fill and pump out every week,
which will help keep the seal moist.
Suds in the tub • Improper detergent. • Use only the special dishwasher
detergent to avoid suds.
• If this occurs, open the dishwasher and
let suds evaporate.
• Add 1 gallon of cold water to the tub.
Close and latch the dishwasher, then
start the “soak” wash cycle to drain out
the water. Repeat if necessary.
• Spilled rinse agent. • Always wipe up rinse agent spills
immediately.
Stained tub interior • Detergent with colorant
was used.
• Make sure that the detergent is the one
without colorant.
Dishes are not dried • Rinse agent dispenser is
empty.
• Make sure that the rinse agent dispense
is filled.
Dishes and flatware
not clean
• Improper program. • Select a more intensive wash program.
• Improper rack loading. • Make sure that the action of the detergent
dispenser and spray arms are not
blocked by large dishware.
DW5500M_DD81-02437K-00_EN.indd 44DW5500M_DD81-02437K-00_EN.indd 44 2019-03-15 4:57:242019-03-15 4:57:24
Troubleshooting _45
08 TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE WHAT TO DO
Spots and filming on
glasses and flatware
1. Extremely hard water.
2. Low inlet temperature.
3. Overloading the
dishwasher.
4. Improper loading.
5. Old or damp powder
detergent.
6. Empty rinse agent
dispenser.
7. Incorrect dosage of
detergent.
To remove spots from glassware:
1. Take out all metal utensils out of the
dishwasher.
2. Do not add detergent.
3. Choose the longest cycle.
4. Start the dishwasher and allow it to run
for about 18 to 22 minutes, then it will be
in the main wash.
5. Open the door to pour 2 cups of white
vinegar into the bottom of the dishwasher.
6. Close the door and let the dishwasher
complete the cycle. If the vinegar does
not work: Repeat as above, except use
1/4 cup (60 ml) of citric acid crystals
instead of vinegar.
Cloudiness on
glassware
• Combination of soft water
and too much detergent.
• Use less detergent if you have soft water
and select a shortest cycle to wash the
glassware and to get them clean.
Yellow or brown film on
inside surfaces
• Tea or coee stains. • Using a solution of 1/2 cup of bleach and
3 cups warm water to remove the stains
by hand.
WARNING: Wait for 20 minutes after
a cycle to allow heating elements cool
down before cleaning interior; Failing to
follow this instruction may result in injury.
• Iron deposits in water can
cause an overall film.
• Water softener company to install
specialist water filtration system on the
water supply.
White film on inside
surface
• Hard water minerals. • Clean the interior, use specialist
dishwasher cleaner or use a damp
sponge with dishwasher detergent and
wear rubber gloves. Never use any other
cleaner than dishwasher detergent for the
risk of foaming or suds.
Detergent dispenser lid
won’t latch
• Dial is not in the OFF
position.
• Turn the Dial to OFF position and slide the
door latch to the left.
Detergent left in
dispenser
• Dishes block detergent
dispenser.
• Re-loading the dishes properly.
Steam • Normal phenomenon. • There is some steam coming through the
vent by the door latch during drying and
water draining.
Black or gray marks on
dishes
• Aluminum utensils have
rubbed against dishes.
• Use a mild abrasive cleaner to eliminate
those marks.
Water standing in the
bottom of the tub
• This is normal. • A small amount of clean water around the
outlet on the tub bottom keeps the water
seal lubricated.
DW5500M_DD81-02437K-00_EN.indd 45DW5500M_DD81-02437K-00_EN.indd 45 2019-03-15 4:57:242019-03-15 4:57:24
46_ Troubleshooting
PROBLEM POSSIBLE CAUSE WHAT TO DO
Dishwasher leaks • Overfill dispenser or rinse
aid spills.
• Be careful not to overfill the rinse aid
dispenser.
Spilled rinse aid could cause overusing
and lead to overflowing.
Wipe away any spills with a damp cloth.
• Dishwasher isn’t level. • Make sure the dishwasher is level.
Buttons are not
working on power on
state
• Door is open. • When door is opened, buttons are not
working except POWER button. Close
the door and press the button.
• Control lock function is
selected.
• When selected Control lock function,
buttons are not responded. To unlock
this function, hold down both the Multi tap
and Delay start buttons for three (3)
seconds.
Also, Control lock function is released
when power cord is reconnected.
The result of washing performance may be caused by a power supply issue. Try another program
before contacting for service.
Troubleshooting
DW5500M_DD81-02437K-00_EN.indd 46DW5500M_DD81-02437K-00_EN.indd 46 2019-03-15 4:57:252019-03-15 4:57:25
Troubleshooting _47
08 TROUBLESHOOTING
INFORMATION CODES
When a fault occurs, the appliance will display information codes to inform you.
Codes Meanings Possible Causes
4C Water supply check
Faucets is not opened, or water intake is
restricted,or water pressure is too low
LC Leakage Some element of dishwasher leaks.
HC Not reaching required temperature Malfunction of heating element
PC Divider valve failed Divider valve failed
AC
Failure of communication between main
PCB with sub PCB
Open circuit or break wiring for the
communication
bC2 Button pressed long time Button pressed 30 seconds
WARNING: If overflow occurs, turn o the main water supply before calling a service. If there is water
in the base pan because of an over fill or small leak, the water should be removed before restarting the
dishwasher.
DW5500M_DD81-02437K-00_EN.indd 47DW5500M_DD81-02437K-00_EN.indd 47 2019-03-15 4:57:252019-03-15 4:57:25
48_ Appendix
Appendix
SPECIFICATIONS
Model
DW60M6050FS
DW60M6050FW
DW60M6040FS
DW60M6040FW
DW60M6050US
DW60M6050UW
DW60M6051US
DW60M6051UW
DW60M6040US
DW60M6040UW
DW60M6050SS
DW60M6050BB
DW60M6040BB
Type Freestanding Built Under Semi Built in Fully Built in
Power 220-240 V~, 50 Hz
Water pressure 0.04 - 1.0 Mpa
Rated power usage 1760-2100 W
Hot water connection Max 60 °C
Dry type Condensed dry system
Wash type Rotating nozzle spray
Dimensions (Width x Depth x Height)
598 x 600 x 845 mm 598 x 570 x 815 mm
598 x 550 x 815 mm
Wash capacity
DW60M6050 14 place setting
DW60M6051 14 place setting
DW60M6040 13 place setting
Weight
Freestanding Unpacked 50 kg
Built Under
Unpacked 43 kgSemi Built in
Fully Built in
DW5500M_DD81-02437K-00_EN.indd 48DW5500M_DD81-02437K-00_EN.indd 48 2019-03-15 4:57:252019-03-15 4:57:25
Appendix _49
09 APPENDIX
PRODUCT DIMENSION
600
845
1175
598
570
815
1150
598
DW60M6050FS/DW60M6050FW
DW60M6040FS/DW60M6040FW
DW60M6050US/DW60M6050UW
DW60M6051US/DW60M6051UW
DW60M6040US/DW60M6040UW
DW60M6050SS
550
598
815
1150
DW60M6050BB/DW60M6040BB
DW5500M_DD81-02437K-00_EN.indd 49DW5500M_DD81-02437K-00_EN.indd 49 2019-03-15 4:57:252019-03-15 4:57:25
50_ For standard test
DW60M6050/DW60M6051
The information for comparability test in accordance with IEC 60436, as follows:
• Washing capacity: 14 place settings
• Test standard: IEC 60436
• Position of upper basket: to lower position
• Wash cycle: Eco
• Additional options: None
• Rinse aid setting: 5
• Water softener setting: H3
• Dosage of the standard detergent: pre/wash 5 g + main/wash 30 g
• For the arrangement of the items, refer below figures
<Upper basket> <Lower basket>
<Silverware basket>
3
7
5
2
2
3
8
6
6
2
2
4
1
1
1 Soup spoons
2 Forks
3 Knives
4 Teaspoons
5 Dessert spoons
6 Serving spoons
7 Serving forks
8 Gravy ladles
For standard test
DW5500M_DD81-02437K-00_EN.indd 50DW5500M_DD81-02437K-00_EN.indd 50 2019-03-15 4:57:292019-03-15 4:57:29
For standard test _51
DW60M6040
The information for comparability test in accordance with IEC 60436, as follows:
• Washing capacity: 13 place settings
• Test standard: IEC 60436
• Position of upper basket: to lower position
• Wash cycle: Eco
• Additional options: None
• Rinse aid setting: 5
• Water softener setting: H3
• Dosage of the standard detergent: pre/wash 5 g + main/wash 27.5 g
• For the arrangement of the items, refer below figures
<Upper basket> <Lower basket>
<Silverware basket>
8
55555555
44
1
11 4
1
141
2
44 44
444
1
4
25
557
5
3
1
11 1 1
3
1 Soup spoons
2 Forks
3 Knives
4 Teaspoons
5 Dessert spoons
6 Serving spoons
7 Serving forks
8 Gravy ladles
DW5500M_DD81-02437K-00_EN.indd 51DW5500M_DD81-02437K-00_EN.indd 51 2019-03-15 4:57:302019-03-15 4:57:30
52_ Terminology for dishwasher
Terminology for dishwasher
1. Circulation Motor
A motor that sucks the water remaining on the floor of the dishwater and
infects water using high pressure through the internal water passages to
the top Middle and lower nozzles.
2. Drain Pump
The pump that drains the polluted water from the dishwater generated
while the dishwater is running.
3. Heater
The healer is located on the water passages inside the dishwasher. It heats
the flowing water to increase wash eciency.
4. Flow Meter
Measure the amount of supplied water by counting the pulses of the hall IC
located at the next of the inlet valve.
5. Distributor
Located at the output end of the sump inside the dishwasher. It turns the
flow of the water that goes to the bottom part of the dishwasher on or o.
(This model does not have this part)
6. Dispenser
The location where the detergent and rinse aids are stored so they can be
used by the dishwasher.
The dispenser automatically supplies detergent and rinse aids to the inside
of the dishwasher when they are needed.
7. Tub Assy
An internal case mode of stainless steel that makes up the basic
framework of the dishwasher.
8. Sump Assy
The place inside the dishwasher where water is collected. The injected
water gathers here after circulation.
The sump Assy is connected to the circulation motor and drain pump.
9. Tub Front Assy
An internal case made of stainless steel that makes up internal part of the
front door.
10. Base Assy A plastic part that makes up the basic bottom framework.
11. Basket Assy The upper and lower racks where dishes can be loaded.
12. Middle/Lower Nozzles
Washes dishes by rotating and injecting the supplied water through the
water passage at high pressure.
13. Case Brake
A passage that adjusts the air pressure by connecting the pressure of the
inside air which is expanded at high temperature during wash and rinse
cycles and the outside air pressure.
14. Door Lock Switch
Detects whether the door of the dishwasher is open or closed if the door is
open while the dishwasher is running the cycle is temporary stopped.
DW5500M_DD81-02437K-00_EN.indd 52DW5500M_DD81-02437K-00_EN.indd 52 2019-03-15 4:57:312019-03-15 4:57:31
Note
DW5500M_DD81-02437K-00_EN.indd 53DW5500M_DD81-02437K-00_EN.indd 53 2019-03-15 4:57:312019-03-15 4:57:31
Note
DW5500M_DD81-02437K-00_EN.indd 54DW5500M_DD81-02437K-00_EN.indd 54 2019-03-15 4:57:312019-03-15 4:57:31
Note
DW5500M_DD81-02437K-00_EN.indd 55DW5500M_DD81-02437K-00_EN.indd 55 2019-03-15 4:57:312019-03-15 4:57:31
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.A.E 800-SAMSUNG (800 - 726 7864)
www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
OMAN 800-SAM CS (800-72627)
KUWAIT 183-CALL (183-2255)
BAHRAIN 8000-GSAM (8000-4726)
QATAR 800-CALL (800-2255)
DW5500M_DD81-02437K-00_EN.indd 56DW5500M_DD81-02437K-00_EN.indd 56 2019-03-15 4:57:312019-03-15 4:57:31
DW60M6050**
DW60M6051**
DW60M6040**
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
مﺪﺨﺘﺴﳌا ﻞﻴﻟد
ﺔﻠﺋﺎﻬﻟا تﺎﻧﺎﻜﻣﻹا ﻞﻴﺨﺗ
.Samsung ﻦﻣ ﺞﺘﻨﳌا اﺬﻫ ءاﺮﺷ ﻰﻠﻋ كﺮﻜﺸﻧ
DD81-02437K-00
DW5500M_DD81-02437K-00_AR.indd 1DW5500M_DD81-02437K-00_AR.indd 1 2019-03-18 11:14:162019-03-18 11:14:16
ﺔﻣﻼﺴﻟا تادﺎﺷرإ _٢
ﺔﻣﻼﺴﻟا تادﺎﺷرإ
زﺎﻬﳉا ﺐﻴﻛﺮﺗ لﻮﺣ ﺔﻤﻬﻣ تﺎﻣﻮﻠﻌﻣ ﻰﻠﻋ ﻞﻴﻟﺪﻟا اﺬﻫ يﻮﺘﺤﻳ .Samsung ﻦﻣ ةﺪﻳﺪﺟ قﺎﺒﻃأ ﺔﻟﺎﺴﻏ ﻚﺋاﺮﺸﻟ ﺎﻨﻴﻧﺎﻬﺗ
ﺎﻳاﺰﻣ ﺔﻓﺎﻛ ﻦﻣ ﺔﻠﻣﺎﻜﻟا ةدﺎﻔﺘﺳﻻا ﻖﻴﻘﺤﺘﻟ ﻞﻴﻟﺪﻟا اﺬﻫ ةءاﺮﻗ ﻲﻓ ﺎ
ﹰ
ﻴﻓﺎﻛ ﺎ
ﹰ
ﺘﻗو ﺬﺧ
ﹰ
ءﺎﺟر .ﻪﺑ ﺔﻳﺎﻨﻌﻟاو ﻪﻣاﺪﺨﺘﺳاو
.تاﺰﻴﳌاو ﺪﺋاﻮﻔﻟا ةدﺪﻌﺘﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
ﺔﻣﻼﺴﻟا تادﺎﺷرإ ﻦﻋ ﺎﻬﺘﻓﺮﻌﻣ ﺐﺠﻳ تﺎﻣﻮﻠﻌﻣ
ﻲﻓ ﻪﺑ ظﺎﻔﺘﺣﻻا ﻊﻣ ﻦﻣآ
ﹴ
ﻞﻜﺸﺑو ﺔﻣﺎﺗ ةءﺎﻔﻜﺑ ﻪﻔﺋﺎﻇوو ﺪﻳﺪﳉا زﺎﻬﳉا ﺎﻳاﺰﻣ ﻊﻴﻤﺟ ﻞﻴﻐﺸﺗ ﺔﻴﻔﻴﻛ ﻰﻠﻋ فﺮﻌﺘﻟا نﺎﻤﻀﻟ ﻞﻣﺎﻜﻟﺎﺑ ﻞﻴﻟﺪﻟا اﺬﻫ ةءاﺮﻗ ءﺎﺟﺮﻟا
ﻮﻫ ﺎﻤﻛ ﻪﻠﺟأ ﻦﻣ ﺎ
ﹰ
ﺼﻴﺼﺧ ﻢﻤ
ﹸ
ﺻ يﺬﻟا ضﺮﻐﻟا ﻲﻓ ﻻإ زﺎﻬﳉا اﺬﻫ مﺪﺨﺘﺴﺗ ﻻو .
ﹰ
ﻼﺒﻘﺘﺴﻣ ﻪﻴﻟإ عﻮﺟﺮﻟا ﻲﻓ ﺔﺒﻏﺮﻟا لﺎﺣ ﻲﻓ زﺎﻬﳉا ﻦﻣ بﺮﻘﻟﺎﺑ ﻦﻣآ نﺎﻜﻣ
.مﺪﺨﺘﺴﳌا ﻞﻴﻟد ﻲﻓ ﺢﺿﻮﻣ
ﺔﻳﺎﻨﻌﻟاو هﺎﺒﺘﻧﻻاو ﻲﻋﻮﺑ فﺮﺼﺘﻟا ﻚﺘﻴﻟﻮﺌﺴﻣ ﻰﻠﻋ ﻊﻘﻳو .ثوﺪﳊا ﺔﻠﻤﺘﺤﻣ ﻒﻗاﻮﳌاو فوﺮﻈﻟا ﺔﻓﺎﻛ ﻞﻴﻟﺪﻟا اﺬﻫ ﻲﻓ ﺔﻣﻼﺴﻟاو ﺮﻳﺬﺤﺘﻟا تادﺎﺷرإ ﻲﻄﻐﺗ ﻻ
.ﺎﻬﻠﻴﻐﺸﺗو ﺎﻬﺘﻧﺎﻴﺻو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ﺪﻨﻋ
ﺪﻗ ﺎﻤﻛ ،ﻞﻴﻟﺪﻟا اﺬﻫ ﻲﻓ رﻮﻛﺬﳌا ﻮﺤﻨﻟا ﻦﻋ ﺎ
ﹰ
ﻔﻴﻔﻃ ﺎ
ﹰ
ﻓﻼﺘﺧا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺺﺋﺎﺼﺧ ﻒﻠﺘﺨﺗ ﺪﻘﻓ ،ﺔﻋﻮﻨﺘﻣ زﺮ
ﹸ
ﻃ ﺔﻴﻟﺎﺘﻟا ﻞﻴﻐﺸﺘﻟا تادﺎﺷرإ ﺔﻴﻄﻐﺘﻟ ا
ﹰ
ﺮﻈﻧ
ﻊﻗﻮﳌا ﻰﻟإ ةﺮﺷﺎﺒﻣ ﻞﻘﺘﻧا وأ ﺔﻣﺪﺧ ﺰﻛﺮﻣ بﺮﻗﺄﺑ ﻞﺼﺗا ،تارﺎﺴﻔﺘﺳا وأ ﺔﻠﺌﺳأ يأ ﻚﻳﺪﻟ ﺖﻧﺎﻛ اذإ .ﺮﻳﺬﺤﺘﻟا تﺎﻣﻼﻋ ﺾﻌﺑ ﻖﻴﺒﻄﺗ رﺬﻌﺘﻳ
.تﺎﻣﻮﻠﻌﳌا وأ تﺎﻤﻴﻠﻌﺘﻟا ﻰﻠﻋ لﻮﺼﺤﻠﻟ www.samsung.com
ﺔﻣﻼﺴﻠﻟ ﺔﻤﻬﳌا تﺎﻃﺎﻴﺘﺣﻻاو زﻮﻣﺮﻟا
ﺔﻤﻬﳌا ﺔﻣﻼﺴﻟا زﻮﻣر
تحذير
.تﺎﻜﻠﺘﻤﳌا ﻒﻠﺗ وأ/و ﺮﻴﻄﺧ ﻲﻧﺪﺑ حﺮﳉ ضﺮﻌﺘﻟا ﺎﻬﻨﻋ ﺞﺘﻨﻳ ﺪﻗ ﻲﺘﻟا ﺔﻨﻣﻵا ﺮﻴﻏ تﺎﺳرﺎﻤﳌا وأ ﺮﻃﺎا
تنبيه
.تﺎﻜﻠﺘﻤﳌا ﻒﻠﺗ وأ/و ﺔﻴﺼﺨﺷ ﺔﺑﺎﺻﻹ ضﺮﻌﺘﻟا ﺎﻬﻨﻋ ﺞﺘﻨﻳ ﺪﻗ ﻲﺘﻟا ﺔﻨﻣﻵا ﺮﻴﻏ تﺎﺳرﺎﻤﳌا وأ ﺮﻃﺎا
تنبيه
وأ ﺔﻴﺋﺎﺑﺮﻬﻛ ﺔﻣﺪﺻ وأ رﺎﺠﻔﻧا وأ ﻖﻳﺮﺣ ثوﺪﺣ ﺮﻃﺎﺨﻣ ﻞﻴﻠﻘﺘﻟ ﺔﻣﻼﺴﻟﺎﺑ ﻖﻠﻌﺘﺗ ﻲﺘﻟا ﺔﻴﺗﻵا ﺔﻴﺳﺎﺳﻷا تﺎﻃﺎﻴﺘﺣﻻا ﻊﺒﺗا
:ﻚﺑ ﺔﺻﺎﳋا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا ﺪﻨﻋ ﺔﻳﺪﺴﺟ ﺔﺑﺎﺻإ
.ءاﺮﺟﻹا اﺬﻬﺑ مﺎﻴﻘﻟا ﺮﻈﺤﻳ
.ﻚﻔﻟا ﺮﻈﺤﻳ
.ﺲﻤﻠﻟا ﺮﻈﺤﻳ
.ﺔﻗﺪﺑ تﺎﻬﻴﺟﻮﺘﻟا ﻊﺒﺗا
.ﻂﺋﺎﳊا ﺬﺧﺄﻣ ﻦﻣ ﺔﻗﺎﻄﻟا ﺲﺑﺎﻗ عﺰﻧا
.ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺼﻟ ضﺮﻌﺘﻟا ﺐﻨﺠﺘﻟ ﻲﺿرأ فﺮﻄﺑ ﻞ
ﹼ
ﺻﻮﻣ زﺎﻬﳉا نأ ﻦﻣ ﺪﻛﺄﺗ
.تﺎﻤﻴﻠﻌﺗ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ﺔﻣﺪﳋا ﺰﻛﺮﲟ ﻞﺼﺗا
ﺔﻈﺣﻼﻣ
.ىذﻷ ضﺮﻌﺘﻟا ﻦﻣ ﻦﻳﺮﺧﻵا ﺔﻳﺎﻤﺣو ﻚﺘﻳﺎﻤﳊ ﻚﻠﺗ ﺮﻳﺬﺤﺘﻟا زﻮﻣر ﻊﺿو ﰎ
.ﺔﻗﺪﺑ ﺎﻬﻋﺎﺒﺗا ﻰﺟﺮ
ﹸ
ﻳ
.ﻞﺒﻘﺘﺴﳌا ﻲﻓ زﺎﻬﺠﻠﻟ ﻚﻟﺎﻣ يﻷ ﺎﻬﻄﻋأو .ﺎﻫاﻮﺘﺤﲟ ﻢﻠﻋ ﻰﻠﻋ ﲔﻣﺪﺨﺘﺴﳌا ﻊﻴﻤﺟ نأ ﻦﻣ ﺪﻛﺄﺗو ﻦﻣآ نﺎﻜﻣ ﻲﻓ تادﺎﺷرﻹا هﺬﻬﺑ ﻆﻔﺘﺣا
ﻞﻤﺸﺗ ﻲﺘﻟا ﺔﻴﺳﺎﺳﻷا تﺎﻃﺎﻴﺘﺣﻻا ﻊﺒﺗا ،ﻚﺑ صﺎﳋا زﺎﻬﳉا ماﺪﺨﺘﺳا ﺪﻨﻋ صﺎﺨﺷﻸﻟ ﺔﺑﺎﺻإ وأ ﺔﻴﺋﺎﺑﺮﻬﻛ ﺔﻣﺪﺻ وأ ﻖﻳﺮﺣ ثوﺪﺣ ﺮﻃﺎﺨﻣ ﻞﻴﻠﻘﺘﻟ
:ﻲﺗﻵا
تحذير
DW5500M_DD81-02437K-00_AR.indd 2DW5500M_DD81-02437K-00_AR.indd 2 2019-03-18 11:14:292019-03-18 11:14:29
٣_ ﺔﻣﻼﺴﻟا تادﺎﺷرإ
١ . تارﺪﻘﻟا ﻲﻓ رﻮﺼﻗ ﻦﻣ نﻮﻧﺎﻌﻳ ﻦﳑ (لﺎﻔﻃﻷا ﻚﻟذ ﻲﻓ ﺎﲟ) صﺎﺨﺷﻷا ﻰﻠﻋ ﺐﺠﻳ
ﺔﻣزﻼﻟا ﺔﻓﺮﻌﳌا وأ ةﺮﺒﳋا ﻢﻬﺼﻘﻨﺗ ﻦﳑ وأ ﺔﻴﻠﻘﻌﻟا وأ ﺔﻴﺴﳊا وأ ﺔﻳﺪﺴﳉا
اﺬﻫ ماﺪﺨﺘﺳﺎﺑ صﺎﳋا ﻪﻴﺟﻮﺘﻟاو فاﺮﺷﻹا ﻢﻬﻟ م
ﱠ
ﺪﻘ
ﹸ
ﻳ ﻢﻟﺎﻣ ،زﺎﻬﳉا اﺬﻫ ماﺪﺨﺘﺳﻻ
.ﻢﻬﺘﻣﻼﺳ ﻦﻋ لوﺆﺴﳌا ﺺﺨﺸﻟا ﻞﺒﻗ ﻦﻣ زﺎﻬﺟﻻا
٢ . ﺮﺜﻛأ وأ ماﻮﻋأ ٨ ﻢﻫرﺎﻤﻋأ ﻎﻠﺒﺗ ﻦﻳﺬﻟا لﺎﻔﻃﻸﻟ ﺢﻤﺴ
ﹸ
ﻳ
:ﺎﺑوروأ ﻲﻓ ماﺪﺨﺘﺳﻼﻟ
وأ ﺔﻴﻧﺪﺒﻟا تارﺪﻘﻟا ﻲﻓ رﻮﺼﻗ ﻦﻣ نﻮﻧﺎﻌﻳ ﻦﳑ ﻚﻟﺬﻛو ،زﺎﻬﳉا اﺬﻫ ماﺪﺨﺘﺳﺎﺑ
فاﺮﺷﻺﻟ ﻢﻬﻋﺎﻀﺧإ طﺮﺸﺑ ﺔﻓﺮﻌﳌاو ةﺮﺒﳋا ﻢﻬﺼﻘﻨﺗ ﻦﳑ وأ ﺔﻴﻠﻘﻌﻟا وأ ﺔﻴﺴﳊا
تاذ رﺎﻄﺧﻷا ﻢﻬﻓو ﻦﻣآ ﻞﻜﺸﺑ زﺎﻬﳉا ماﺪﺨﺘﺳﺎﺑ ﺔﺻﺎﳋا تﺎﻤﻴﻠﻌﺘﻟا ﻢﻬﻨﻴﻘﻠﺗ وأ
ءاﺮﺟﺈﺑ لﺎﻔﻃﻸﻟ حﻮﻤﺴﻣ ﺮﻴﻏ .زﺎﻬﳉﺎﺑ ﺚﺒﻌﻟﺎﺑ لﺎﻔﻃﻸﻟ حﻮﻤﺴﻣ ﺮﻴﻏ .ﺔﻠﺼﻟا
.فاﺮﺷإ نود مﺪﺨﺘﺴﳌا ﺎﻬﺑ مﻮﻘﻳ ﻲﺘﻟا ﺔﻧﺎﻴﺼﻟاو ﻒﻴﻈﻨﺘﻟا لﺎﻤﻋأ
٣ ..زﺎﻬﳉﺎﺑ ﻢﻬﺜﺒﻋ مﺪﻋ نﺎﻤﻀﻟ لﺎﻔﻃﻷا ﺔﺒﻗاﺮﻣ ﻲﻐﺒﻨﻳ
۴ . ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ﻞﺒ
ﹺ
ﻗ ﻦﻣ ﻪﻟاﺪﺒﺘﺳا ﺐﺠﻳ ،ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻚﻠﺳ ﻒﻠﺗ ﺔﻟﺎﺣ ﻲﻓ
.ﺮﻄﺧ يﻷ ضﺮﻌﺘﻟا ﺐﻨﺠﺘﻟ ﲔﻠﻫﺆﻣ ﲔﻴﻨﻓ يأ وأ ﺎﻬﻟ ﻊﺑﺎﺘﻟا ﺔﻧﺎﻴﺼﻟا ﻞﻴﻛو وأ
۵ . ةدﺎﻋإ مﺪﻋو زﺎﻬﳉا ﻊﻣ ﺔﻘﻓﺮﳌا ةﺪﻳﺪﳉا ﻢﻴﻃاﺮﳋا ﺔﻋﻮﻤﺠﻣ ماﺪﺨﺘﺳا ﺐﺠﻳ
.ﺔﳝﺪﻘﻟا ﻢﻴﻃاﺮﳋا ﺔﻋﻮﻤﺠﻣ ماﺪﺨﺘﺳا
۶ . ةدﺎﺠﺳ يأ ﺪﺴﺗ ﻻأ ﺐﺠﻳ ،ةﺪﻋﺎﻘﻟا ﻲﻓ ﺔﻳﻮﻬﺗ تﺎﺤﺘﻓ ﺎﻬﺑ ﻲﺘﻟا ةﺰﻬﺟﻸﻟ ﺔﺒﺴﻨﻟﺎﺑ
.تﺎﺤﺘﻔﻟا هﺬﻫ ةدﻮﺟﻮﻣ
٧ . ﻲﻓ ﻻإ زﺎﻬﳉا ﻦﻋ تاﻮﻨﺳ ٣ ﻦﻣ ﻞﻗأ لﺎﻔﻃﻷا دﺎﻌﺑإ ﺐﺠﻳ :ﺎﺑوروأ ﻲﻓ ماﺪﺨﺘﺳﻼﻟ
.راﺮﻤﺘﺳﺎﺑ ﻢﻬﺘﺒﻗاﺮﻣ ﺔﻟﺎﺣ
DW5500M_DD81-02437K-00_AR.indd 3DW5500M_DD81-02437K-00_AR.indd 3 2019-03-18 11:14:292019-03-18 11:14:29
ﺔﻣﻼﺴﻟا تادﺎﺷرإ _٤
٨ . ﺮﻴﻏ ﻞﻜﺸﺑ يراﺮﳊا ﻊﻃﺎﻘﻟا ﻂﺒﺿ ةدﺎﻋإ ﺔﺠﻴﺘﻧ ﺮﻃﺎﺨﻣ يأ ثوﺪﺣ ﺐﻨﺠﺘﻟ :ﻪﻴﺒﻨﺗ
وأ ،ﺖﻗﺆﳌا ﻞﺜﻣ ،ﻲﺟرﺎﺧ ﻞﺻوو ﻞﺼﻓ زﺎﻬﺠﺑ زﺎﻬﳉا ﺪﻳوﺰﺗ مﺪﻋ ﺐﺠﻳ ،دﻮﺼﻘﻣ
ﻖﻓﺮﳌا ﻞﺒﻗ ﻦﻣ مﺎﻈﺘﻧﺎﺑ ﺎﻬﻠﻴﻐﺸﺗ فﺎﻘﻳإو ﺎﻬﻠﻴﻐﺸﺗ ﻢﺘﻳ ﺔﻴﺋﺎﺑﺮﻬﻛ ةﺮﺋاﺪﺑ ﻪﻠﻴﺻﻮﺗ
.مﺎﻌﻟا
٩ .:ﻞﺜﻣ ،ﺔﻠﺛﺎﳑ ىﺮﺧأ تﺎﻘﻴﺒﻄﺗو ﻲﻟﺰﻨﳌا ماﺪﺨﺘﺳﻼﻟ ﺎ
ﹰ
ﺼﻴﺼﺧ ﻢﻤﺼﻣ زﺎﻬﳉا اﺬﻫ
– :ىﺮﺧﻷا ﻞﻤﻌﻟا تﺎﺌﻴﺑو ﺐﺗﺎﻜﳌاو تﻼﶈا ﻲﻓ ﲔﻔﻇﻮﳌا ﺦﺑﺎﻄﻣ ﺎﻬﺑ ﻖﻃﺎﻨﻣ
– :ﺔﻴﻔﻳر لزﺎﻨﻣ
– :ىﺮﺧﻷا ﺔﻴﻨﻜﺴﻟا تﺎﺌﻴﺒﻟاو تﺎﺣاﺮﺘﺳﻻاو قدﺎﻨﻔﻟا ﻲﻓ ءﻼﻤﻌﻟا ﺔﻄﺳاﻮﺑ
– .رﺎﻄﻓﻹاو ﺖﻴﺒﳌا ﺮﻓﻮﺗ تﺎﺌﻴﺑ
١٠ ..ﺪﺣأ ﻪﺑ ﺮﺜﻌﺘﻳ ﺪﻘﻓ ،ﺎ
ﹰ
ﺣﻮﺘﻔﻣ بﺎﺒﻟا كﺮﺗ مﺪﻋ ﺐﺠﻳ
١١ . ﺚﻴﺤﺑ ﺔﻠﺴﻟا ﻲﻓ ةدﺎﳊا فاﺮﻃﻷا تاذ ىﺮﺧﻷا تاودﻷاو ﲔﻛﺎﻜﺴﻟا ﻊﺿو ﺐﺠﻳ :ﺮﻳﺬﲢ
.ﻲﻘﻓأ ﻞﻜﺸﺑ وأ ﻞﻔﺳﻷ ﺔﻬﺠﺘﻣ ﺎﻬﺳأر نﻮﻜﺗ
ﺔﻣﻼﺴﻟا تادﺎﺷرإ
DW5500M_DD81-02437K-00_AR.indd 4DW5500M_DD81-02437K-00_AR.indd 4 2019-03-18 11:14:302019-03-18 11:14:30
٥_ ﺔﻣﻼﺴﻟا تادﺎﺷرإ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا لﻮﺣ تادﺎﺷرإ
وأ ﻞﻤﻌﻟا تﺎﺌﻴﺑ ﻲﻓ ﺔﻠﺛﺎﳑ تﺎﻣاﺪﺨﺘﺳاو ﺔﻴﻟﺰﻨﳌا تﺎﻣاﺪﺨﺘﺳﻼﻟ ﺔﺼﺼﺨﻣ ﺎﻬﻧإ ﺚﻴﺣ .يرﺎﺠﺘﻟا ماﺪﺨﺘﺳﻼﻟ ﺔﻤﻤﺼﻣ ﺖﺴﻴﻟ هﺬﻫ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ نإ
:ﻞﺜﻣ ،ﺔﻣﺎﻗﻹا ﻦﻛﺎﻣأ
•تﻼﶈا
•ضرﺎﻌﳌاو ﺐﺗﺎﻜﳌا
:ﻞﺜﻣ ،تﺎﻳﺎﻨﺒﻟا ﻲﻓ ﲔﻤﻴﻘﳌاو
•.ﺔﻓﺎﻴﻀﻟا رودو قدﺎﻨﻔﻟا
.ةﺪﺋﺎﳌا تاودأو ﺔﻴﻟﺰﻨﳌا ﺔﻳرﺎﺨﻔﻟا ﻲﻧاوﻷا ﻒﻴﻈﻨﺘﻟ ،اﺬﻫ مﺪﺨﺘﺴﳌا ﻞﻴﻟﺪﺑ ﺢﺿﻮﻣ ﻮﻫ ﺎﻤﻛ ﻲﻟﺰﻨﻣ زﺎﻬﺠﻛ ﻂﻘﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا ﺐﺠﺑ
.ا
ﹰ
ﺮﻴﻄﺧ نﻮﻜﻳ ﺪﻗ يﺬﻟا ﺮﺧآ ماﺪﺨﺘﺳا يأ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ﻢﻋﺪﺗ ﻻ
.ﻞﻴﻐﺸﺘﻟا وأ ماﺪﺨﺘﺳﻻا ءﻮﺳ وأ ﺢﻴﺤﺼﻟا ﺮﻴﻏ ماﺪﺨﺘﺳﻻا ﻦﻋ ﰋﺎﻧ ﻒﻠﺗ يأ ﻦﻋ ﺔﻟوﺆﺴﻣ ﺮﻴﻏ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا
.رﺎﺠﻔﻧﻻا ﺮﻄﺧ ﻰﻠﻋ ﻚﻟذ يﻮﻄﻨﻳ ﺚﻴﺣ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺔﺒﻳﺬﻣ ﻒﻴﻈﻨﺗ داﻮﻣ مﺪﺨﺘﺴﺗ ﻻ
ﻒﻧﻷﺎﺑ قوﺮﺣ ﺐﺒﺴﻳ ﺪﻗ ﺎﳑ ﻞﻛﺂﺘﻠﻟ ﺔﺒﺒﺴﻣ وأ ﺔﺠ
ﱢ
ﻴﻬﻣ تﺎﻧﻮﻜﻣ ﻰﻠﻋ يﻮﺘﺤﻳ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻤﻓ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻣ ﻞﻛﺄﺗ وأ ﻖﺸﻨﺘﺴﺗ ﻻ
.ﻪﻗﺎﺸﻨﺘﺳا وأ ﻒﻴﻈﻨﺘﻟا ﻒ
ﹼ
ﻈﻨﻣ ﻊﻠﺑ لﺎﺣ ﻲﻓ رﻮﻔﻟا ﻰﻠﻋ ﺎ
ﹰ
ﺒﻴﺒﻃ ﺮﺸﺘﺳا .ةﻮﻘﺑ ﻪﻗﺎﺸﻨﺘﺳا وأ ﻪﻌﻠﺑ ﺔﻟﺎﺣ ﻲﻓ ﻖﻠﳊا وأ ﻢﻔﻟا وأ
.كﺮ
ﹼ
ﺜﻌﺗ ﻲﻓ ﺐﺒﺴﺘﻳ ﺪﻗ ﻚﻟذ نﻷ
ﹴ
عاد نود ﺎ
ﹰ
ﺣﻮﺘﻔﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ بﺎﺑ كﺮﺗ ﺐﻨﲡ
.ﺔﺑﺎﺻﻺﻟ ﻚﺿﺮﻌﻳ ﺪﻗ ﺎﳑ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻢﻜﲢ وأ بﻼﻘﻧا ﻲﻓ ﺐﺒﺴﺘﻳ ﺪﻗ ﻚﻟذ نﻷ ،حﻮﺘﻔﳌا بﺎﺒﻟا ﻰﻠﻋ ﺪﻨﺘﺴﺗ وأ ﺲﻠﲡ ﻻ
.ﺔﻴﻟﺰﻨﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ ﺺﺼا ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ وأ ﻒﻈﻨﳌا ﻻإ مﺪﺨﺘﺴﺗ ﻻ
.ﻞﻴﺴﻐﻟا ﻞﺋﺎﺳ مﺪﺨﺘﺴﺗ ﻻ
.ﺔﻳﻮﻗ ﺔﻴﻀﻤﺣ ﻒﻴﻈﻨﺗ ةدﺎﻣ مﺪﺨﺘﺴﺗ ﻻ
.جرﺪﻠﻟ ا
ﹰ
ﺮﻴﺒﻛ ا
ﹰ
رﺮﺿ ﺐﺒﺴﻳ ﺪﻗ اﺬﻫ نﻷ ،ﺎ
ﹰ
ﻗﻮﺤﺴﻣ وأ
ﹰ
ﻼﺋﺎﺳ ﺎ
ﹰ
ﻔﻈﻨﻣ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ جرد ﻲﻓ ﻊﻀﺗ ﻻ
تﻻﺎﺴﻏ ﺢﻠﻣ ﻦﻣ ﺐﺳﺎﻨﳌا عﻮﻨﻟا رﺎﻴﺘﺧا ﻦﻣ ﺪﻛﺄﺗ .هﺎﻴﳌا ﻲﻘﻨﻣ ﻒﻠﺗ ﻰﻟإ ﺢﻠﳌا جرد ﻲﻓ ﻞﺋﺎﺴﻟا وأ ﻒ
ﹼ
ﻈﻨﳌا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻈﻨﻣ ﻊﺿو يدﺆﻳ ﺪﻗ
.ﺢﻠﳌا جرد ﻲﻓ ﻪﺒﻜﺳ ﻞﺒﻗ قﺎﺒﻃﻷا
ﺔﻠﺑﺎﻗ ﺮﻴﻏ تﺎﻓﺎﺿإ ﻰﻠﻋ يﻮﺘﲢ ﺪﻗ ىﺮﺧﻷا ﺢﻠﳌا عاﻮﻧأ نﻷ ،ﻂﻴﺸﻨﺘﻟا ةدﺎﻋإ ﺪﻨﻋ قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ ﻦﺸﳋا تﺎﺒﻴﺒﳊا ﺢﻠﻣ ﻦﻣ صﺎﺧ عﻮﻧ ماﺪﺨﺘﺳا ﻲﺟﺮ
ﹸ
ﻳ
.ﺔﻴﻘﻨﺘﻟا ةﺰﻴﻣ ﻞﻤﻋ ﻖﻴﻌﻳ ﺪﻗ ﺎﳑ نﺎﺑوﺬﻠﻟ
ﺎﻬﻀﺑﺎﻘﻣو ﺔﻠﺴﻟا ﻲﻓ ﺖﻌﺿ
ﹸ
و اذإ ﻞﻀﻓأ ﻞﻜﺸﺑ ﺎﻬﻔﻴﻔﲡو ةﺪﺋﺎﳌا تاودأ ﻒﻴﻈﻨﺗ ﻢﺘﻳ ،(زاﺮﻄﻠﻟ ﺎ
ﹰ
ﻘﺒﻃ) ةﺪﺋﺎﳌا تاودﻷ ﺔﻠﺳ ﻰﻠﻋ يﻮﺘﲢ ﻲﺘﻟا ةﺰﻬﺟﻷا ﻲﻓ
.ﺔﺑﺎﺻﻺﻟ ضﺮﻌﺘﻟا ﺐﻨﺠﺘﻟ ﻰﻠﻋﻷ ةدﺎﳊا تاودﻷا ﻊﻴﻤﺟو ﲔﻛﺎﻜﺴﻟاو ك
ﹼ
ﻮﺸﻟا ﺾﺑﺎﻘﻣ ﻊﺿو ﻲﻐﺒﻨﻳ ﻦﻜﻟو .ﻞﻔﺳﻷ
تاودأ وأ ﺎﻬﻨﻣ ﺺﻠﺨﺘﻟا ﻦﻜﳝ ﻲﺘﻟا ﺔﻴﻜﻴﺘﺳﻼﺒﻟا ﻲﻧاوﻷا ﻞﺜﻣ ﻦﺧﺎﺴﻟا ءﺎﳌﺎﺑ ﻞﻴﺴﻐﻟا ﻞﻤﺤﺘﺗ ﻻ ﻲﺘﻟا ﺔﻴﻜﻴﺘﺳﻼﺒﻟا ﺮﺻﺎﻨﻌﻟا ﻞﻴﺴﻏ ﻢﺘﻳ ﻻأ ﻲﻐﺒﻨﻳ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺔﻳرﺎﺨﻔﻟا ﻲﻧاوﻷاو ﺔﻴﻜﻴﺘﺳﻼﺒﻟا ةﺪﺋﺎﳌا
.ﺎﻫﻮﺸﺗ وأ ﺎﻬﻧﺎﺑوذ ﻰﻟإ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ﺔﻴﻟﺎﻌﻟا ةراﺮﳊا تﺎﺟرد ﺐﺒﺴﺘﺗ ﺪﻗ
مﺪﻋ ﻰﺟﺮﻳ .ةروﺮﻀﻟا ﺪﻨﻋ ﻚﺴﻔﻨﺑ ﻪﻔﻔﺟ وأ .ﻒ
ﹼ
ﻈﻨﳌا ﺔﻓﺎﺿإ ﻞﺒﻗ ع
ﱢ
زﻮﳌا فﺎﻔﺟ ﻦﻣ ﺪﻛﺄﺗ ،(ءﺪﺒﻟا ﻞﻴﺟﺄﺗ) Delay Start ﺔﻔﻴﻇﻮﺑ ةدوﺰﳌا تازاﺮﻄﻟا ﻲﻓ
.ﺪﻴﺟ ﻞﻜﺸﺑ ﻒ
ﹼ
ﻈﻨﳌا ﻊﻳزﻮﺗ ﻊﻨﳝ ﺎﲟرو ع
ﱢ
زﻮﳌا داﺪﺴﻧا ﺐﺒﺴﻳ ﺪﻗ ﻚﻟذ نﻷ ﺐﻃر ﻮﻫو ع
ﱢ
زﻮﳌا ﻰﻠﻋ ﻒ
ﹼ
ﻈﻨﳌا ﺐﻜﺳ
.ﻲﻘﻓأ ﻞﻜﺸﺑ وأ ﻞﻔﺳﻷ ﺔﻬﺠﺘﻣ ﺎﻬﺳأر نﻮﻜﺗ ﺚﻴﺤﺑ ﺔﻠﺴﻟا ﻲﻓ ةدﺎﳊا فاﺮﻃﻷا تاذ ىﺮﺧﻷا تاودﻷاو ﲔﻛﺎﻜﺴﻟا ﻊﺿو ﺐﺠﻳ
تحذير
تحذير
تنبيه
تنبيه
تنبيه
تنبيه
تنبيه
تحذير
DW5500M_DD81-02437K-00_AR.indd 5DW5500M_DD81-02437K-00_AR.indd 5 2019-03-18 11:14:302019-03-18 11:14:30
ﺔﻣﻼﺴﻟا تادﺎﺷرإ _٦
ﻚﻟﺎﻔﻃأ ﺔﻳﺎﻤﳊ تادﺎﺷرإ
وأ ﺎﻬﻟﻮﺣ وأ ﺎﻬﻠﺧاد ﺐﻌﻠﻟﺎﺑ ﻢﻬﻟ ﺢﻤﺴﺗ ﻻو ﺎ
ﹰ
ﻣﺎﲤ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻋ ﻚﻟﺎﻔﻃأ ﺪﻌﺑا ،ﺔﺑﺎﺻﻺﻟ ضﺮﻌﺘﻟا ﺮﻄﺧ ﺐﻨﺠﺘﻟ !ﺔﺒﻌﻟ ﺲﻴﻟ زﺎﻬﳉا اﺬﻫ
.ﺦﺒﻄﳌا ﻲﻓ اودﻮﺟو ﺎﻤﺘﻗو ﻢﻬﺘﺒﻗاﺮﻣ ﺐﺠﻳ .ﻢﻬﺑ ﻖﺤﻠﻳ ﺪﻗ يﺬﻟا ﻞﻤﺘﶈا ﺮﻄﳋا ﻢﺠﺣ نﻮﺒﻋﻮﺘﺴﻳ ﻻ ﺪﻘﻓ .ﻢﻜﺤﺘﻟا ﺢﻴﺗﺎﻔﻣ ماﺪﺨﺘﺳا
.ﺎﻬﺑ لﺎﻔﻃﻷا ﺐﻌﻟ ءﺎﻨﺛأ ﺎﻬﻠﺧاﺪﺑ سﺎﺒﺤﻧﻻا ﺮﻄﺧ ﺎ
ﹰ
ﻀﻳأ ﺔﻤﺛ
وأ ﺔﻴﺴﳊا وأ ﺔﻴﻧﺪﺒﻟا تارﺪﻘﻟا ﻲﻓ رﻮﺼﻗ ﻦﻣ نﻮﻧﺎﻌﻳ ﻦﳑ ﻚﻟﺬﻛو ،زﺎﻬﳉا اﺬﻫ ماﺪﺨﺘﺳﺎﺑ ﺮﺜﻛأ وأ ماﻮﻋأ ٨ ﻢﻫرﺎﻤﻋأ ﻎﻠﺒﺗ ﻦﻳﺬﻟا لﺎﻔﻃﻸﻟ ﺢﻤﺴ
ﹸ
ﻳ
رﺎﻄﺧﻷا ﻢﻬﻓو ﻦﻣآ ﻞﻜﺸﺑ زﺎﻬﳉا ماﺪﺨﺘﺳﺎﺑ ﺔﺻﺎﳋا تﺎﻤﻴﻠﻌﺘﻟا ﻢﻬﻨﻴﻘﻠﺗ وأ فاﺮﺷﻺﻟ ﻢﻬﻋﺎﻀﺧإ طﺮﺸﺑ ﺔﻓﺮﻌﳌاو ةﺮﺒﳋا ﻢﻬﺼﻘﻨﺗ ﻦﳑ وأ ﺔﻴﻠﻘﻌﻟا
.زﺎﻬﳉﺎﺑ ﺚﺒﻌﻟﺎﺑ لﺎﻔﻃﻸﻟ حﻮﻤﺴﻣ ﺮﻴﻏ .ﺔﻠﺼﻟا تاذ
.فاﺮﺷإ نود مﺪﺨﺘﺴﳌا ﺎﻬﺑ مﻮﻘﻳ ﻲﺘﻟا ﺔﻧﺎﻴﺼﻟاو ﻒﻴﻈﻨﺘﻟا لﺎﻤﻋأ ءاﺮﺟﺈﺑ لﺎﻔﻃﻸﻟ حﻮﻤﺴﻣ ﺮﻴﻏ
ﺎﻬﻣاﺪﺨﺘﺳا ﻰﻠﻋ ةرﺪﻘﻟا ﻢﻬﻳﺪﻟ ﺖﻧﺎﻛو ﺎﻬﻣاﺪﺨﺘﺳا ﺔﻴﻔﻴﻛ حﺮﺷ ﰎ اذإ ﻂﻘﻓ ﺎﻬﻠﻴﻐﺸﺗو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳﺎﺑ ﺎ
ﹰ
ﻨﺳ ﺮﺒﻛﻷا لﺎﻔﻃﻸﻟ ﺢﻤﺴ
ﹸ
ﻳ
.ماﺪﺨﺘﺳﻻا ءﻮﺳ ﺮﻃﺎﺨﻣ ﻰﻠﻋ فﺮﻌﺘﻟاو نﺎﻣﺄﺑ
وأ ﻒﻧﻷﺎﺑ قوﺮﺣ ﺐﺒﺴﻳ ﺪﻗ ﺎﳑ ﻞﻛﺂﺘﻠﻟ ﺔﺒﺒﺴﻣ وأ ﺔﺠ
ﱢ
ﻴﻬﻣ تﺎﻧﻮﻜﻣ ﻰﻠﻋ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻣ يﻮﺘﺤﻳ !لﺎﻔﻃﻷا لوﺎﻨﺘﻣ ﻦﻋ ا
ﹰ
ﺪﻴﻌﺑ ﻒ
ﹼ
ﻈﻨﳌﺎﺑ ﻆﻔﺘﺣا
.ةﻮﻘﺑ ﻪﻗﺎﺸﻨﺘﺳا وأ ﻪﻌﻠﺑ ﺔﻟﺎﺣ ﻲﻓ ﻖﻠﳊا وأ ﻢﻔﻟا
.ﺎ
ﹰ
ﺣﻮﺘﻔﻣ بﺎﺒﻟا نﺎﻛ اذإ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻋ لﺎﻔﻃﻷا دﺎﻌﺑإ ﺐﺠﻳ
.ﺔﻧاﺰﳋا ﻞﺧاد ﻒﻈﻨﳌا ﺎﻳﺎﻘﺑ ﻞﻈﺗ ﺪﻗ
.ﻪﻗﺎﺸﻨﺘﺳا وأ ﻒﻈﻨﳌا ﻊﻠﺑ لﺎﺣ ﻲﻓ رﻮﻔﻟا ﻰﻠﻋ ﺎ
ﹰ
ﺒﻴﺒﻃ ﺮﺸﺘﺳا
تحذير
تحذير
تحذير
تحذير
ﺔﻣﻼﺴﻟا تادﺎﺷرإ
DW5500M_DD81-02437K-00_AR.indd 6DW5500M_DD81-02437K-00_AR.indd 6 2019-03-18 11:14:302019-03-18 11:14:30
٧_ ﺔﻣﻼﺴﻟا تادﺎﺷرإ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ لﻮﺣ تادﺎﺷرإ
ﺐﺒﺴﻳ ﺪﻗ ﻒﻟﺎﺘﻟا زﺎﻬﳉا نﻷ ،فﺮﻇ يأ ﺖﲢ ﻒﻟﺎﺗ زﺎﻬﺟ ماﺪﺨﺘﺳﺎﺑ ﻞﺒﻘﺗ ﻻو .ﺎﻬﺘﻳؤر ﻦﻜﳝ ﺔﻴﺟرﺎﺧ تﺎﻴﻔﻠﺗ يأ ﻦﻣ هﻮﻠﺧ ﻦﻣ ﺪﻛﺄﺗ ،زﺎﻬﳉا ﺐﻴﻛﺮﺗ ﻞﺒﻗ
.ﺮﻃﺎﺨﻣ
ﺪﻌﺑ ﻪﻴﻟإ لﻮﺻﻮﻟا ﺔﻟﻮﻬﺴﺑ ﻲﺑﺮﻬﻜﻟا ﺲﺒﻘﳌا ﺰﻴﻤﺘﻳ نأ ﺐﺠﻳ .ﺐﺳﺎﻨﻣ ﻞﻴﺻﻮﺗ ﺲﺒﻘﻣ ﺮﺒﻋ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﲟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﺻﻮﺗ ﺐﺠﻳ
ﺔﺤﻔﺻ ﻲﻓ "“تاﺰﻴﳌاو ءاﺰﺟﻷا” ﻢﺴﻗ ﻊﺟار) .ﺖﻗو يأ ﻲﻓ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﻣ ﻦﻣ ﺎﻬﻨﻋ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻞﺼﻓ ﻦﻜﳝ ﺚﻴﺤﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
(.١٠
ﻰﻠﻋﻷ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺖﻌﻓ
ﹸ
د اذإ ﻖﻳﺮﺣ عﻻﺪﻧا وأ ةﺪﺋاز ﺔﻧﻮﺨﺳ ﺮﻄﺧ دﻮﺟو ﻰﻟإ ﻚﻟذ يدﺆﻳ ﺪﻗ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻠﺧ ﺔﻴﺑﺮﻬﻜﻟا ﺲﺑﺎﻘﳌا ﺪﺟاﻮﺗ ﺮﻈﺤ
ﹸ
ﻳ
.ﺲﺑﺎﻘﻟا هﺎﲡﺎﺑ
ﺮﻈﺤ
ﹸ
ﻳ ،ﺐﺒﺴﻟا ﺲﻔﻨﻟو
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻠﺗ ﻰﻟإ يدﺆﺗ ﺪﻗ ،ﺪﻗﻮﳌا ﺎﻫرﺪﺼﻳ ﻲﺘﻟا ﺔﻴﻟﺎﻌﻟا ةراﺮﳊا نﻷ ،ﺪﻗﻮﳌا ﻞﻔﺳأ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻊﺿو ﺮﻈﺤ
ﹸ
ﻳ
.ﺎﻫﺮﻴﻏو تﺎﻧﺎﺨﺴﻟا ﻞﺜﻣ ﺔﻴﻟﺎﻋ ةراﺮﺣ رﺪﺼ
ﹸ
ﺗ يﺮﺧأ ةﺰﻬﺟأ راﻮﺠﺑ وأ ءﺎﻄﻏ نود ةﺪﻗﻮﻣ رﺎﻧ راﻮﺠﺑ ﺎﻬﻌﺿو
.بﺎﺒﻟا تﺎﻛﺮﺒﻧز ﻲﻓ تﻼﻳﺪﻌﺗ يأ ﻦﻣ ءﺎﻬﺘﻧﻻاو ﺎﻬﺒﻴﻛﺮﺗ مﺎﲤإ ﺪﻌﺑ ﻻإ ﻲﺴﻴﺋﺮﻟا ﺔﻗﺎﻄﻟا رﺪﺼﲟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﺻﻮﺘﺑ ﻢﻘﺗ ﻻ
رﺎﻴﺘﻠﻟ ﻲﺴﻴﺋﺮﻟا رﺪﺼﳌا ﻊﻣ (ﻞ
ﹶ
ﺻﻮﳌا ﻲﺑﺮﻬﻜﻟا ﻞﻤﳊاو ﻲﺑﺮﻬﻜﻟا ﺪﻬﳉا) تﺎﻧﺎﻴﺒﻟا ﺔﺣﻮﻟ ﻰﻠﻋ ﻞﻴﺻﻮﺘﻟا تﺎﻧﺎﻴﺑ ﻖﺑﺎﻄﺗ ﻦﻣ ﺪﻛﺄﺗ ،زﺎﻬﳉا ﻞﻴﺻﻮﺗ ﻞﺒﻗ
.ﺺﺼﺨﺘﻣ ءﺎﺑﺮﻬﻛ ﻲﻨﻓ ﻰﻟإ ءﻮﺠﻠﻟا ﻰﺟﺮﻳ ،ﺎﻬﺘﻘﺑﺎﻄﻣ مﺪﻋ ﻲﻓ ﻚﺸﻟا ﺔﻟﺎﺣ ﻲﻓو .ﻲﺑﺮﻬﻜﻟا
ﺐﻠﻄﳌا اﺬﻫ ﺮﻓاﻮﺗ ﺔﻳﺎﻐﻠﻟ ﻢﻬﳌا ﻦﻣ .لﺎﻌﻓ ﻲﺿرأ ﻞﻴﺻﻮﺗ مﺎﻈﻧ ﲔﺑو زﺎﻬﳉا ﲔﺑ ﻞﻴﺻﻮﺘﻟا ﻞﻤﺘﻜﻳ ﺎﻣﺪﻨﻋ زﺎﻬﳉا اﺬﻬﻟ ﻲﺑﺮﻬﻜﻟا نﺎﻣﻷا نﺎﻤﺿ ﻦﻜﳝ
.لﺰﻨﻤﻠﻟ ﻲﺑﺮﻬﻜﻟا مﺎﻈﻨﻟا صﻮﺼﺨﺑ ﻚﺷ يأ دﻮﺟو لﺎﺣ ﻲﻓ ﺺﺼﺨﺘﻣ ءﺎﺑﺮﻬﻛ ﻲﻨﻓ ةرﺎﺸﺘﺳﺎﺑ ﺢﺼﻨﻳ اﺬﻟ ،مﺎﻈﺘﻧﺎﺑ هرﺎﺒﺘﺧاو ﻲﺋﺎﻗﻮﻟا
.(ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺻ ثوﺪﺣ ﻞﺜﻣ) ﺾﻳرﺄﺘﻟا مﺎﻈﻧ ﺔﻣءﻼﻣ مﺪﻌﻟ تﺎﻌﺒﺗ يأ ﻦﻋ ﺔﻟﻮﺌﺴﻣ ﺮﻴﻏ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا
بﻮﻠﻄﳌا نﺎﻣﻷا ﻖﻘﲢ ﻻ ﻞﺋﺎﺳﻮﻟا ﻚﻠﺗ نﻷ .ﺪﻳﺪﲤ ﻚﻠﺳ وأ ﺲﺑﺎﻘﳌا ةدﺪﻌﺘﻣ ةﺪﺣو ماﺪﺨﺘﺳﺎﺑ ﻲﺴﻴﺋﺮﻟا ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﲟ زﺎﻬﳉا ﻞﻴﺻﻮﺘﺑ ﻢﻘﺗ ﻻ
.(ةﺪﺋاﺰﻟا ﺔﻧﻮﺨﺴﻟا ﺮﻄﺧ ﻞﺜﻣ) ﺮﻃﺎا ﻦﻣ زﺎﻬﳉا ﺔﻳﺎﻤﳊ
.ﺺﺼﺨﺘﻣ سﺪﻨﻬﻣ ﺪﻳ ﻰﻠﻋ ﺐﻴﻛﺮﺘﻟا ﺮﻃﺎﺨﻣ ﻢﻴﻴﻘﺗ ﺔﻟﺎﺣ ﻲﻓ ﻻإ ،ﻦﻔﺴﻟا ﻞﺜﻣ ،ﺔﻠﻘﻨﺘﳌا ﺐﻴﻛﺮﺘﻟا تﺎﺌﻴﺑ ﻲﻓ زﺎﻬﳉا اﺬﻫ ﺐﻴﻛﺮﺘﺑ ﺢﻤﺴ
ﹸ
ﻳ ﻻ
.هﺎﻴﳌﺎﺑ ﻲﺟرﺎﳋا ﻞﻜﻴﻬﻟا ﺮﻤﻏ ﺮﻈﺤ
ﹸ
ﻳ .ﻲﺑﺮﻬﻛ نﻮﻜﻣ ﻰﻠﻋ هﺎﻴﳌا ﻞﺻﻮﳌ ﻲﻜﻴﺘﺳﻼﺒﻟا ﻲﺟرﺎﳋا ﻞﻜﻴﻬﻟا يﻮﺘﺤﻳ
.ا
ﹰ
ﺪﺟ
ﹰ
ﻼﻳﻮﻃ نﺎﻛ اذإ ﻰﺘﺣ هﺎﻴﳌا داﺪﻣإ مﻮﻃﺮﺧ ا
ﹰ
ﺪﺑأ ﻊﻄﻘﺗ ﻻ .هﺎﻴﳌا بﺮﺴﺗ ﺔﻌﻧﺎﲟ دوﺰﳌا مﻮﻃﺮﳋا ﻲﻓ ﺔﻴﺋﺎﺑﺮﻬﻛ كﻼﺳأ ﺪﺟﻮﺗ
ﻞﻜﺸﻳ ﺪﻘﻓ ،ﺔﻴﻤﻴﻠﻗﻹاو ﺔﻴﻠﶈا نﺎﻣﻷا ﺢﺋاﻮﻟ مﺰﺤﺑ ﻖﺒﻄﻳ ءﻒﻛ ﺺﺼﺨﺘﻣ ﺺﺨﺷ ﺔﻄﺳاﻮﺑ ﻂﻘﻓ ﺢﻴﻠﺼﺘﻟاو ﺔﻧﺎﻴﺼﻟاو ﺐﻴﻛﺮﺘﻟا مﺎﻬﻣ زﺎﳒإ
ﺐﺠﻳ
.ﻪﺑ حﺮﺼﻣ ﺮﻴﻏ ﻞﻤﻋ يأ ﺔﻴﻟوﺆﺴﻣ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻬﳉا ﻞﻤﺤﺘﺗ ﻻ .ا
ﹰ
ﺮﻄﺧ ﲔﺼﺼﺨﺘﻣ ﺮﻴﻏ صﺎﺨﺷأ ﺔﻄﺳاﻮﺑ ﺎﻫﺮﻴﻏو ﺢﻴﻠﺼﺘﻟا مﺎﻬﻣ زﺎﳒإ
تحذير
تنبيه
تحذير
تحذير
تنبيه
تنبيه
تنبيه
DW5500M_DD81-02437K-00_AR.indd 7DW5500M_DD81-02437K-00_AR.indd 7 2019-03-18 11:14:312019-03-18 11:14:31
ﺔﻣﻼﺴﻟا تادﺎﺷرإ _٨
:ﺔﻴﻟﺎﺘﻟا طوﺮﺸﻟا عﺎﺒﺗا طﺮﺸﺑ هﺎﻴﳌا ﺐﺒﺴﺑ ثﺪﲢ ﺪﻗ ﻲﺘﻟا راﺮﺿﻷا ﻦﻣ ﺔﻳﺎﻤﳊا ﺞﻣﺪ
ﹸ
ﳌا هﺎﻴﳌا ﺔﻣوﺎﻘﻣ مﺎﻈﻧ ﺮﻓﻮﻳ
•.ﺔﺤﻴﺤﺻ ﺔﻘﻳﺮﻄﺑ ﺐﻴﺑﺎﻧﻷﺎﺑ ﺎﻬﻠﻴﺻﻮﺗو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
•.ةروﺮﻀﻟا ﺖﻗو ﺎﻬﺋاﺰﺟأ لاﺪﺒﺘﺳا ﻚﻟﺬﻛو ﺔﻤﻴﻠﺳ ةرﻮﺼﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻧﺎﻴﺻ
•.(
ﹰ
ﻼﺜﻣ تﻼﻄﻌﻟا لﻼﺧ) ﺔﻠﻳﻮﻃ ةﺮﺘﻔﻟ زﺎﻬﳉا ماﺪﺨﺘﺳا مﺪﻋ ﺔﻟﺎﺣ ﻲﻓ ﺲﺒﶈا ﻖﻠﻏ
• زﺎﻬﳉا ﻞﻴﺻﻮﺗ راﺮﻤﺘﺳا ﺐﺠﻳ ،ﻚﻟذ ﻦﻣ ﻢﻏﺮﻟا ﻰﻠﻋو .زﺎﻬﳉا ﻞﻴﻐﺸﺗ فﺎﻘﻳإ ﰎ اذإ ﻰﺘﺣ ﻞﻤﻌﻟا ﻦﻋ هﺎﻴﳌا ﺔﻣوﺎﻘﻣ مﺎﻈﻧ ﻒﻗﻮﺘﻳ ﻦﻟ
.ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﲟ
.تﺎﻣﺪﳋا ﻢﺴﻘﺑ وأ ﻊﺋﺎﺒﻟﺎﺑ ﻞﺼﺗاو ﻲﺴﻴﺋﺮﻟا رﺪﺼﳌا ﻦﻣ ﺎﻬﻠﻴﻐﺸﺗ ﻒﻗوأ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻠﺗ لﺎﺣ ﻲﻓ .ا
ﹰ
ﺮﻄﺧ ﻒﻟﺎﺘﻟا زﺎﻬﳉا ﻞﻜﺸﻳ ﺪﻗ
ﻢﺘﺗ نأ ﻲﻐﺒﻨﻳ .ﻚﻟذ ﻦﻋ ﺎﻬﺘﻴﻟوﺆﺴﻣ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ﻲﻠﺨ
ﹸ
ﺗ ﻚﻟﺬﻟو ،مﺪﺨﺘﺴﳌﺎﺑ ﺮﻀﺗ ﺔﻌﻗﻮﺘﻣ ﺮﻴﻏ رﺎﻄﺧأ ﻰﻟإ ﺪ
ﹶ
ﻤﺘﻌﳌا ﺮﻴﻏ ﺢﻴﻠﺼﺘﻟا يدﺆﻳ ﺪﻗ
.ﺪ
ﹶ
ﻤﺘﻌﻣ ﺔﻣﺪﺧ ﻲﻨﻓ ﺔﻄﺳاﻮﺑ ﺢﻴﻠﺼﺘﻟا مﺎﻬﻣ
.ﺪﻴﺟ
ﹴ
ﻞﻜﺸﺑ ءاﺰﺟﻷا هﺬﻫ ﻞﻤﻌﺗ ﺎﻣﺪﻨﻋ ﻂﻘﻓ زﺎﻬﳉا ﺔﻣﻼﺳ نﺎﻤﺿ ﻦﻜﳝ .ﺔﺒﻴﻌﳌا تﺎﻧﻮﻜﳌﺎﺑ ﺔﻴﻠﺻأ رﺎﻴﻏ ﻊﻄﻗ لاﺪﺒﺘﺳا ﺐﺠﻳ
.(ﺲﺑﺎﻘﻟا عﺰﻧاو ﻂﺋﺎﳊا ﺬﺧﺄﻣ ﻦﻣ ﺎﻬﻠﻴﻐﺸﺗ ﻒﻗوأ)
ﺔﻧﺎﻴﺼﻟا ءاﺮﺟإ ﺪﻨﻋ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﻣ ﻦﻋ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺼﻔﺑ ﺎ
ﹰ
ﻤﺋاد ﻢﻗ
ﻦﻋ ﻞﻳﺪﺒﺘﻟا اﺬﻫ ﻢﺘﻳ نأ ﺐﺠﻳ ،ﺔﻣﻼﺴﻟﺎﺑ ﻖﻠﻌﺘﺗ بﺎﺒﺳﻷو ،ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ىﺪﻟ ﺮﻓﻮﺘﻣ صﺎﺧ ﻞﺒﻜﺑ ﻪﻠﻳﺪﺒﺗ ﺐﺠﻳ ،ﻒﻠﺘﻠﻟ ﻞﻴﺻﻮﺘﻟا ﻞﺒﻛ ضﺮﻌﺗ اذإ
.ﺪ
ﹶ
ﻤﺘﻌﻣ ﺔﻣﺪﺧ ﻲﻨﻓ ﺔﻄﺳاﻮﺑ وأ تﺎﻣﺪﳋا ﻢﺴﻗ ﻖﻳﺮﻃ
وأ ﺮﻴﺻاﺮﺼﻟا ﻞﺜﻣ تاﺮﺸﳊﺎﺑ ةءﻮﺑﻮﻣ ﻖﻃﺎﻨﻣ
ﺎﻬﺑ ﺪﺟﻮﺗ ﻲﺘﻟا ناﺪﻠﺒﻟا ﻲﻓ ﻢﺋاد
ﹴ
ﻞﻜﺸﺑ ﻪﺑ ﺔﻄﻴﶈا ﺔﻘﻄﻨﳌاو زﺎﻬﳉا ﺔﻓﺎﻈﻧ ﻰﻠﻋ ظﺎﻔﳊا ﻚﻴﻠﻋ ﺐﺟﻮﺘﻳ
.تاﺮﺸﳊا ﻦﻣ ﺎﻫﺮﻴﻏ وأ ﺮﻴﺻاﺮﺼﻟا ﻦﻋ ﺞﺘﻨﻳ رﺮﺿ يأ نﺎﻤﻀﻟا ﻲﻄﻐﻳ ﻻ .تاﺮﺸﳊا ﻦﻣ ﺎﻫﺮﻴﻏ
:ﺔﻴﺗﻵا تﻻﺎﳊا ﻦﻣ يأ ﻲﻓ ﻂﻘﻓ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا رﺪﺼﻣ ﻦﻋ ﺎ
ﹰ
ﻣﺎﲤ زﺎﻬﳉا لﺰﻋ ﻢﺘﻳ ،ﻒﻴﻈﻨﺘﻟا ضاﺮﻏﻷ وأ ﻞﻄﻋ ثوﺪﺣ ﺪﻨﻋ
•،ﺲﺑﺎﻘﻟا ﺐﺤﺳو ﻂﺋﺎﳊا ﺬﺧﺄﻣ ﻞﻴﻐﺸﺗ فﺎﻘﻳإ
•،ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻠﻟ ﻲﺴﻴﺋﺮﻟا رﺪﺼﳌا ﻦﻋ ﻪﻠﺼﻓ وأ
•،ﻲﺴﻴﺋﺮﻟا رﺪﺼﳌا ﺮﻬﺼﻨﻣ ﻞﺼﻓ وأ
•.(تاﺮﻬﺼﻨﳌا هﺬﻫ ﺎﻬﻴﻓ ﺮﻓﻮﺘﺗ ﻲﺘﻟا دﻼﺒﻟا ﻲﻓ) ﻲﺒﻟﻮﻠﻟا ﺮﻬﺼﻨﳌا ﻚﻓ
.تﻼﻳﺪﻌﺘﻟا ﻚﻠﺘﺑ مﺎﻴﻘﻟا ﻰﻠﻋ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ﺖﻘﻓاو اذإ ﻻإ زﺎﻬﳉا ﻲﻓ تﻼﻳﺪﻌﺗ يﺄﺑ ﻢﻘﺗ ﻻ
.زﺎﻬﺠﻠﻟ ﻲﺟرﺎﳋا ﻞﻜﻴﻬﻟا ا
ﹰ
ﺪﺑأ ﺢﺘﻔﺗ ﻻ
.ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺻ وأ ﺔﻴﻠﻴﻐﺸﺗ لﺎﻄﻋأ ثوﺪﺣ ﻲﻓ ﺐﺒﺴﻳ ﺪﻗو ا
ﹰ
ﺮﻴﺒﻛ ا
ﹰ
ﺮﻄﺧ ﺔﻴﻜﻴﻧﺎﻜﻴﳌا ءاﺰﺟﻷا تﺎﻧﻮﻜﻣ وأ ءﺎﺑﺮﻬﻜﻟا تﻼﻴﺻﻮﺘﺑ ﺚﺒﻌﻟا ﻞﻜﺸﻳ
.ﺎ
ﹰ
ﻳرﺎﺳ ﺮﻴﻏ نﺎﻤﻀﻟا ﺪﻌ
ﹸ
ﻴﺳ ﻻإو ،زﺎﻬﳉا نﺎﻤﺿ ةﺮﺘﻓ لﻼﺧ ﺔﻌ
ﱢ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا ﻦﻣ ﻦﻳﺪﻤﺘﻌﻣ ﺔﻣﺪﺧ ﲔﻴﻨﻓ يﺪﻳأ ﻰﻠﻋ تﺎﺣﻼﺻﻹا ﻞﻛ ﻢﺘﺗ نأ ﻲﻐﺒﻨﻳ
.ﺪﻴﺟ ﻞﻜﺸﺑ ﻪﺘﻳﻮﻬﺗ نﺎﻤﻀﻟ ﺞﺘﻨﳌا ﻒﻠﺧو ﲔﳝو رﺎﺴﻳو ﻰﻠﻋأ ﺔﻓﺎﺴﻣ دﻮﺟو ﻦﻣ ﺪﻛﺄﺗ ،ﺞﺘﻨﳌا ﺐﻴﻛﺮﺗ ﺪﻨﻋ
.ﻦﻔﻌﻟا ﻮﳕ وأ ضﻮﳊا ﻒﻠﺗ ﻰﻟإ ﻚﻟذ يدﺆﻳ ﺪﻘﻓ ضﻮﳊاو ﺞﺘﻨﳌا ﲔﺑ ﺔﻴﻓﺎﻛ ﺔﺣﺎﺴﻣ دﻮﺟو مﺪﻋ ﺔﻟﺎﺣ ﻲﻓ
.ﺎﻬﻴﻓ ﺶﻴﻌﺗ ﻲﺘﻟا ﺔﻘﻄﻨﳌا ﻊﻣ ﻖﻓاﻮﺘﻳ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ءﺎﳌا ﺮﺴﻋ ىﻮﺘﺴﻣ داﺪﻋإ نأ ﻦﻣ ﺪﻛﺄﺗ
(.١٨ ﺔﺤﻔﺻ ﻲﻓ “(هﺎﻴﳌا ﺮﺴﻋ ىﻮﺘﺴﻣ داﺪﻋإ) هﺎﻴﳌا ﻲﻘﻨﻣ ﻊﺿو” ﻢﺴﻗ ﻊﺟار)
تنبيه
تحذير
تنبيه
تحذير
تنبيه
تنبيه
تنبيه
ﺔﻣﻼﺴﻟا تادﺎﺷرإ
DW5500M_DD81-02437K-00_AR.indd 8DW5500M_DD81-02437K-00_AR.indd 8 2019-03-18 11:14:312019-03-18 11:14:31
٩_ تﺎﻳﻮﺘﶈا
تﺎﻳﻮﺘﶈا
تاﺰﻴﳌاو ءاﺰﺟﻷا
١٠
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ تاﺰﻴﻣ ١٠
ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ١٣
ضﺮﻌﻟا ﺔﺷﺎﺷ ١٦
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
١٨
(هﺎﻴﳌا ﺮﺴﻋ ىﻮﺘﺴﻣ داﺪﻋإ) هﺎﻴﳌا ﻲﻘﻨﻣ ﻊﺿو ١٨
ﺢﻠﳌﺎﺑ ﻲﻘﻨﳌا ﺪﻳوﺰﺗ ١٩
ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا ٢٠
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ماﺪﺨﺘﺳا ٢١
تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﳋا ماﺪﺨﺘﺳا ﺔﻴﻔﻴﻛ ٢٢
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
٢٣
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ ٢٣
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ ٢٥
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻒﻓرأ
ﹼ
ﻲﻃ ٢٥
(ﺔﻴﻀﻔﻟا ﻲﻧاوﻷا) ةﺪﺋﺎﳌا تاودأ ﺔﻴﻨﻴﺻ ٢٦
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺔﻴﻟﺎﺘﻟا قﺎﺒﻃﻷا/ﲔﻛﺎﻜﺴﻟا ﻞﺴﻐﻟ ٢٨
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ
٢٩
زﺎﻬﳉا ﻞﻴﻐﺸﺗ ٢٩
ﺞﻣﺎﻧﺮﺒﻟا ﺮﻴﻴﻐﺗ ٢٩
ﻞﺴﻐﻟا ةرود ءﺎﻬﺘﻧا ﺪﻨﻋ ٣٠
ﻞﺴﻐﻟا ةرود لوﺪﺟ ٣٠
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا
٣٢
تﺎﺤﺷﺮﳌا ﻒﻴﻈﻨﺗ ٣٢
شﺮﻟا عرذأ ﻒﻴﻈﻨﺗ ٣٣
بﺎﺒﻟا ﻒﻴﻈﻨﺗ ٣٣
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﻳﺎﻨﻌﻟا ٣٣
ﺪﻤﺠﺘﻟا ﻦﻣ ﺔﻳﺎﻤﳊا ٣٣
ﻚﺑ ﺔﺻﺎﳋا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻰﻠﻋ ﻆﻓﺎﲢ ﻒﻴﻛ ٣٤
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ
٣٥
ﺎﻬﻔﻳﺮﺼﺗو هﺎﻴﳌا ﺪﻳرﻮﺗ ٣٥
ﻒﻳﺮﺼﺘﻟا ﻢﻴﻃاﺮﺧ ﻞﻴﺻﻮﺗ ٣٧
زﺎﻬﳉا ﻊﺿو ٣٧
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ءﺪﺑ ٣٧
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
٣٨
ﺔﺠﻣﺪ
ﹸ
ﻣ ،ﺔﺠﻣﺪ
ﹸ
ﻣ ﻪﺒﺷ ،ﻞﻤﻌﻟا ﺢﻄﺳ ﺖﲢ ﺔﺒ
ﹼ
ﻛﺮﻣ قﺎﺒﻃأ ﺔﻟﺎﺴﻏ ٣٨
ﺎ
ﹰ
ﻣﺎﲤ
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا
٤٤
ﺔﻧﺎﻴﺼﻟا ﺔﻣﺪﺨﺑ لﺎﺼﺗﻻا ﻞﺒﻗ ٤٤
تﺎﻣﻮﻠﻌﳌا زﻮﻣر ٤٧
ﻖﺤﻠﳌا
٤٨
تﺎﻔﺻاﻮﳌا ٤٨
ﺞﺘﻨﳌا دﺎﻌﺑأ ٤٩
DW5500M_DD81-02437K-00_AR.indd 9DW5500M_DD81-02437K-00_AR.indd 9 2019-03-18 11:14:322019-03-18 11:14:32
تاﺰﻴﳌاو ءاﺰﺟﻷا _١٠
تاﺰﻴﳌاو ءاﺰﺟﻷا
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ تاﺰﻴﻣ
(DW60M6050**) ﻲﻔﻠﳋاو ﻲﻣﺎﻣﻷا ناﺮﻈﻨﳌا
١
٢
٤
١٠
٤
٧
٨
٨
١١
٩
٩
٣
٥
٥
٦
١
ﺚﻟﺎﺜﻟا فﺮﻟا
٢
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا
٣
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا
٤
بﻮﺒﻧﻷا ﺔﻫﻮﻓ
٥
ﺢﻠﳌا ﺔﻳوﺎﺣ
٦
ﻒﻈﻨﳌا ع
ﱢ
زﻮﻣ
٧
باﻮﻛﻷا فر
٨
شﺮﻟا عرذأ
٩
ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ
١٠
ﺪﻳرﻮﺘﻟا مﻮﻃﺮﺧ
١١
ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ
.ةﺪﺋﺎﳌا تاودأ ﺔﻠﺳ ،ﺢﻠﳌا ﻊﻤﻗ ،مﺪﺨﺘﺴﳌا ﻞﻴﻟد – ﺔﻴﻓﺎﺿﻹا تﺎﻘﻓﺮﳌا
DW5500M_DD81-02437K-00_AR.indd 10DW5500M_DD81-02437K-00_AR.indd 10 2019-03-18 11:14:322019-03-18 11:14:32
١١_ تاﺰﻴﳌاو ءاﺰﺟﻷا
تاﺰﻴﳌاو ءاﺰﺟﻷا ٠١
(DW60M6051**) ﻲﻔﻠﳋاو ﻲﻣﺎﻣﻷا ناﺮﻈﻨﳌا
١
٢
٤
١٠
٤
٧
٨
٨
١١
٩
٩
٣
٥
٥
٦
١
ﺚﻟﺎﺜﻟا فﺮﻟا
٢
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا
٣
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا
٤
بﻮﺒﻧﻷا ﺔﻫﻮﻓ
٥
ﺢﻠﳌا ﺔﻳوﺎﺣ
٦
ﻒﻈﻨﳌا ع
ﱢ
زﻮﻣ
٧
باﻮﻛﻷا فر
٨
شﺮﻟا عرذأ
٩
ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ
١٠
ﺪﻳرﻮﺘﻟا مﻮﻃﺮﺧ
١١
ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ
.ةﺪﺋﺎﳌا تاودأ ﺔﻠﺳ ،ﺢﻠﳌا ﻊﻤﻗ ،مﺪﺨﺘﺴﳌا ﻞﻴﻟد – ﺔﻴﻓﺎﺿﻹا تﺎﻘﻓﺮﳌا
DW5500M_DD81-02437K-00_AR.indd 11DW5500M_DD81-02437K-00_AR.indd 11 2019-03-18 11:14:332019-03-18 11:14:33
تاﺰﻴﳌاو ءاﺰﺟﻷا _١٢
(DW60M6040**) ﻲﻔﻠﳋاو ﻲﻣﺎﻣﻷا ناﺮﻈﻨﳌا
٩
١٠
١
٣
٦
٧
٨
٢
٤
٥
٣
٧
٨٤
١
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا
٢
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا
٣
بﻮﺒﻧﻷا ﺔﻫﻮﻓ
٤
ﺢﻠﳌا ﺔﻳوﺎﺣ
٥
ﻒﻈﻨﳌا ع
ﱢ
زﻮﻣ
٦
باﻮﻛﻷا فر
٧
شﺮﻟا عرذأ
٨
ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ
٩
ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ
١٠
ﺪﻳرﻮﺘﻟا مﻮﻃﺮﺧ
.ةﺪﺋﺎﳌا تاودأ ﺔﻠﺳ ،ﺢﻠﳌا ﻊﻤﻗ ،مﺪﺨﺘﺴﳌا ﻞﻴﻟد – ﺔﻴﻓﺎﺿﻹا تﺎﻘﻓﺮﳌا
تاﺰﻴﳌاو ءاﺰﺟﻷا
DW5500M_DD81-02437K-00_AR.indd 12DW5500M_DD81-02437K-00_AR.indd 12 2019-03-18 11:14:352019-03-18 11:14:35
١٣_ تاﺰﻴﳌاو ءاﺰﺟﻷا
تاﺰﻴﳌاو ءاﺰﺟﻷا ٠١
ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ
DW60M6050F*/DW60M6051F*/DW60M6040F*
DW60M6050U*/DW60M6051U*/DW60M6040U*
DW60M6050S*/DW60M6051S*/DW60M6040S*
DW60M6050
DW60M6051
DW60M6040
٤
٣
٤
٢
٢
١
٩
٩
٧
٧
٨
٦
٦
١
٥
١(ﻞﻴﻐﺸﺗ) POWER
.ﺔﺷﺎﺸﻟا ءﻲﻀﺗ :قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
٢ﺞﻣﺎﻧﺮﺒﻟا
.ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ﺪﻳﺪﺤﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
٣ﺔﻟﻮﻤﺣ ﻒﺼﻧ
.ﺔﻗﺎﻄﻟا ﺮﻴﻓﻮﺘﻟ ﻂﻘﻓ ﺔﻴﻠﻔﺴﻟا وأ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا مﺪﺨﺘﺳا ،تاودﻷا ﻦﻣ ﺔﻠﻴﻠﻗ ﺔﻴﻤﻛ ﻞﺴﻐﻟ
.ﺔﻴﻠﻔﺴﻟا وأ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﺪﻳﺪﺤﺘﻟ ﺔﻟﻮﻤﺣ ﻒﺼﻧ ﻰﻠﻋ ﻂﻐﺿا
٤ﻢﻜﺤﺘﻟا ﻞﻔﻗ
ﻞﻴﻐﺸﺗ لﺎﻔﻃﻷا ﻰﻠﻋ رﺬﻌﺘﻳ ﺚﻴﺤﺑ ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﻰﻠﻋ ةدﻮﺟﻮﳌا رارزﻷا ﲔﻣﺄﺗ ﺔﻴﻧﺎﻜﻣإ رﺰﻟا اﺬﻫ ﻚﻟ ﺢﻴﺘﻳ
.ﺪﺼﻗ نود ﺔﺣﻮﻠﻟا رارزأ ﻰﻠﻋ ﻂﻐﻀﻟﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
ﻢﻜﺤﺘﻟا ﻞﻔﻗ ﻦﻳرﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟا ﻲﻓ ﺮﻤﺘﺳا ،ﺎﻬﻠﻔﻗ ءﺎﻐﻟإ وأ ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﻰﻠﻋ ةدﻮﺟﻮﳌا رارزﻷا ﻞﻔﻘﻟ
.
ﹴ
ناﻮﺛ (٣) ثﻼﺛ ةﺪﳌ
٥ضﺮﻌﻟا ةﺬﻓﺎﻧ
.ﺎﻫﺮﻴﻏو تﺎﻣﻮﻠﻌﳌا زﻮﻣرو ﻞﻴﺟﺄﺘﻟا ةﺪﻣو ﻞﻴﻐﺸﺘﻟا ﺮﺷﺆﻣ
٦(ءﺪﺒﻟا) START
.بﺎﺒﻟا قﻼﻏإ ﻞﺒﻗ (ءﺪﺒﻟا) START رز ﻰﻠﻋ ﻂﻐﺿا ،ةرود ءﺪﺒﻟ
(ءﺪﺒﻟا) START رز ﻰﻠﻋ راﺮﻤﺘﺳﺎﺑ ﻂﻐﺿا ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻳﺮﺼﺗو ﺔﻴﻟﺎﳊا ةروﺪﻟا ءﺎﻐﻟﻹ :ﻂﺒﺿ ةدﺎﻋإ*
.
ﹴ
ناﻮﺛ (٣) ثﻼﺛ ةﺪﳌ
ﻞﻴﻐﺸﺗ ةدﺎﻋﻹ (ءﺪﺒﻟا) START ﻰﻠﻋ ﻂﻐﺿا ﻢﺛ ا
ﹰ
رﺎﻴﺧو ةرود دﺪﺣ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻂﺒﺿ ةدﺎﻋإ دﺮﺠﲟو
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
٧
ءﺪﺒﻟا ﻞﻴﺟﺄﺗ
ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﻐﺸﺗ ءﺪﺑ ﻞﻴﺟﺄﺗ ﻚﻨﻜﳝ .ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﺟﺄﺗ تﺎﻋﺎﺳ ﲔﻴﻌﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
.ةﺪﺣاو ﺔﻋﺎﺳ ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﺟﺄﺗ ﻰﻟإ رﺰﻟا اﺬﻫ ﻰﻠﻋ ةﺪﺣاو ةﺮﻣ ﻂﻐﻀﻟا يدﺆﻳ .ﺔﻋﺎﺳ ٢٤ ﻰﺘﺣ
٨ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ
ﺔﻔﻴﻇﻮﻟا هﺬﻫ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ رﺰﻟا ﻰﻠﻋ ﻂﻐﺿا
.ﻲﻟوأ ﻞﺴﻏ و ﻲﻟوأ ﻞﺴﻏ و ﻲﺋﺎﻘﻠﺗ اﺪﻋﺎﻣ ﺞﻣاﺮﺒﻟا ﻞﻜﻟ ﺔﺣﺎﺘﻣ
٩تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا
صﺮﻗ ﺐﻠﻄﺘﻳ ﻞﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣو ﺢﻠﻣ دﻮﺟو ﺐﻠﻄﺘﻳ ﻻ يﺬﻟا تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﺧ ﺪﻳﺪﺤﺘﻟ
.ﻲﻟوأ ﻞﺴﻏ و ﻲﻟوأ ﻞﺴﻏ و ﻲﺋﺎﻘﻠﺗ اﺪﻋﺎﻣ ﺞﻣاﺮﺒﻟا ﻞﻜﻟ ﺔﺣﺎﺘﻣ ﺔﻔﻴﻇﻮﻟا هﺬﻫ .تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا
DW5500M_DD81-02437K-00_AR.indd 13DW5500M_DD81-02437K-00_AR.indd 13 2019-03-18 11:14:362019-03-18 11:14:36
تاﺰﻴﳌاو ءاﺰﺟﻷا _١٤
•.ﻂﻘﻓ (ﻞﻴﻐﺸﺗ) POWER رﺰﻟا ﻞﻴﻐﺸﺗ ﻢﺘﻴﺳ ،بﺎﺒﻟا ﺢﺘﻓ ﺪﻨﻋ
•.تاروﺪﻟا ىﺪﺣإ ءﺪﺑ ﻞﺒﻗ (ﺔﻟﻮﻤﺣ ﻒﺼﻧ وأ/و ءﺪﺒﻟا ﻞﻴﺟﺄﺗ وأ/و تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا) تارﺎﻴﳋا ﺪﻳﺪﲢ ﻚﻨﻜﳝ
.ةﺮﻣ لوﻷ ﺎﻬﻣاﺪﺨﺘﺳا ﻞﺒﻗ ﻞﻴﻐﺸﺘﻟا تادﺎﺷرإ ﻊﻴﻤﺟ ةءاﺮﻗ ﻰﺟﺮﻳ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ءادأ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ :ﺔﻤﻬﻣ ﺔﻈﺣﻼﻣ
DW60M6050BB
٣ ٤ ٥ ١٠ ١١٦ ٨ ٩٧١ ٢
DW60M6040BB
١(ﻞﻴﻐﺸﺗ) POWER
.ﺔﺷﺎﺸﻟا ءﻲﻀﺗ :قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
٢ةروﺪﻟا
.ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ﺪﻳﺪﺤﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
٣يﻮﻠﻌﻟا فﺮﻟا
.يﻮﻠﻌﻟا فﺮﻟا ﺔﻫﻮﻓ ىﻮﺳ ﻂﻴﺸﻨﺗ ﻢﺘﻳ ﻻ ،يﻮﻠﻌﻟا فﺮﻟا ﺪﻳﺪﲢ ﺪﻨﻋ
.ﻲﻠﻔﺴﻟا فﺮﻟا ﺔﻫﻮﻓ ﻞﻤﻌﺗ ﻦﻟو
.يﻮﻠﻌﻟا فﺮﻟا ﻲﻓ ﺔﻋﻮﺿﻮﳌا باﻮﻛﻷا وأ قﺎﺒﻃﻷا ﻦﻣ ةﺮﻴﻐﺻ ﺔﻟﻮﻤﺣ ﻞﺴﻐﻟ ةﺰﻴﳌا هﺬﻫ مﺪﺨﺘﺳا
ﺔﻟﺎﺴﻏ مﻮﻘﺗ ﻦﻟ .ﻂﻘﻓ يﻮﻠﻌﻟا فﺮﻟا ﻲﻓ ﺎﻫﺮﻴﻏو باﻮﻛﻷاو قﺎﺒﻃﻷا ﻊﺿ ,يﻮﻠﻌﻟا فﺮﻟا ﺪﻳﺪﲢ ﺪﻨﻋ
.ﻲﻠﻔﺴﻟا فﺮﻟا ﻲﻓ ةدﻮﺟﻮﳌا ءﺎﻴﺷﻷا ﻞﺴﻐﺑ قﺎﺒﻃﻷا
.ءﺎﺑﺮﻬﻜﻟا ﻦﻣ ﻚﻠﻬﺘﺴﳌا رﺪﻘﻟاو ةروﺪﻟا ﺖﻗو ﻦﻣ ﻞﻛ ﻞﻴﻠﻘﺗ ﻰﻟإ يﻮﻠﻌﻟا فﺮﻟا ﺪﻳﺪﲢ يدﺆﻳ
٤ﻲﻠﻔﺴﻟا فﺮﻟا
.يﻮﻠﻌﻟا فﺮﻟا ﺔﻫﻮﻓ ﻞﻤﻌﺗ ﻦﻟو .ﻲﻠﻔﺴﻟا فﺮﻟا ﺔﻫﻮﻓ ىﻮﺳ ﻂﻴﺸﻨﺗ ﻢﺘﻳ ﻻ ،ﻲﻠﻔﺴﻟا فﺮﻟا ﺪﻳﺪﲢ ﺪﻨﻋ
.ﻲﻠﻔﺴﻟا فﺮﻟا ﻲﻓ ﺔﻋﻮﺿﻮﳌا باﻮﻛﻷا وأ قﺎﺒﻃﻷا ﻦﻣ ةﺮﻴﻐﺻ ﺔﻟﻮﻤﺣ ﻞﺴﻐﻟ ةﺰﻴﳌا هﺬﻫ مﺪﺨﺘﺳا
ﺔﻟﺎﺴﻏ مﻮﻘﺗ ﻦﻟ .ﻂﻘﻓ ﻲﻠﻔﺴﻟا فﺮﻟا ﻲﻓ ﺎﻫﺮﻴﻏو باﻮﻛﻷاو تاودﻷا ﻊﺿ ,ﻲﻠﻔﺴﻟا فﺮﻟا ﺪﻳﺪﲢ ﺪﻨﻋ
.يﻮﻠﻌﻟا فﺮﻟا ﻲﻓ ةدﻮﺟﻮﳌا تاودﻷا ﻞﺴﻐﺑ قﺎﺒﻃﻷا
.ءﺎﺑﺮﻬﻜﻟا ﻦﻣ ﻚﻠﻬﺘﺴﳌا رﺪﻘﻟاو ةروﺪﻟا ﺖﻗو ﻦﻣ ﻞﻛ ﻞﻴﻠﻘﺗ ﻰﻟإ ﻲﻠﻔﺴﻟا فﺮﻟا ﺪﻳﺪﲢ يدﺆﻳ
٥ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ
ﺔﻔﻴﻇﻮﻟا هﺬﻫ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ رﺰﻟا ﻰﻠﻋ ﻂﻐﺿا
.ﻲﻟوأ ﻞﺴﻏ و ﻲﻟوأ ﻞﺴﻏ و ﻲﺋﺎﻘﻠﺗ اﺪﻋﺎﻣ ﺞﻣاﺮﺒﻟا ﻞﻜﻟ ﺔﺣﺎﺘﻣ
٦
تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا
صﺮﻗ ﺐﻠﻄﺘﻳ ﻞﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣو ﺢﻠﻣ دﻮﺟو ﺐﻠﻄﺘﻳ ﻻ يﺬﻟا تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﺧ ﺪﻳﺪﺤﺘﻟ
.ﻲﻟوأ ﻞﺴﻏ و ﻲﻟوأ ﻞﺴﻏ و ﻲﺋﺎﻘﻠﺗ اﺪﻋﺎﻣ ﺞﻣاﺮﺒﻟا ﻞﻜﻟ ﺔﺣﺎﺘﻣ ﺔﻔﻴﻇﻮﻟا هﺬﻫ .تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا
٧ﻢﻜﺤﺘﻟا ﻞﻔﻗ
ﻞﻴﻐﺸﺗ لﺎﻔﻃﻷا ﻰﻠﻋ رﺬﻌﺘﻳ ﺚﻴﺤﺑ ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﻰﻠﻋ ةدﻮﺟﻮﳌا رارزﻷا ﲔﻣﺄﺗ ﺔﻴﻧﺎﻜﻣإ رﺰﻟا اﺬﻫ ﻚﻟ ﺢﻴﺘﻳ
.ﺪﺼﻗ نود ﺔﺣﻮﻠﻟا رارزأ ﻰﻠﻋ ﻂﻐﻀﻟﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
ﻢﻜﺤﺘﻟا ﻞﻔﻗ ﻦﻳرﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟا ﻲﻓ ﺮﻤﺘﺳا ،ﺎﻬﻠﻔﻗ ءﺎﻐﻟإ وأ ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﻰﻠﻋ ةدﻮﺟﻮﳌا رارزﻷا ﻞﻔﻘﻟ
.
ﹴ
ناﻮﺛ (٣) ثﻼﺛ ةﺪﳌ
تاﺰﻴﳌاو ءاﺰﺟﻷا
DW5500M_DD81-02437K-00_AR.indd 14DW5500M_DD81-02437K-00_AR.indd 14 2019-03-18 11:14:362019-03-18 11:14:36
١٥_ تاﺰﻴﳌاو ءاﺰﺟﻷا
تاﺰﻴﳌاو ءاﺰﺟﻷا ٠١
٨ﺮﺷﺆﳌا
ةدﺎﻋإ ﺐﺠﻳ ﻪﻧأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﳌا نﺎﻛ اذإ
.ﺢﻠﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ
ءﺪﺒﻟا ﻞﻴﺟﺄﺗ ﺮﺷﺆﻣ
•."ءﺪﺒﻟا ﻞﻴﺟﺄﺗ" رﺎﻴﳋا ﺪﻳﺪﲢ ﻚﻴﻠﻋ نأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ءﺪﺒﻟا ﻞﻴﺟﺄﺗ" ﺮﺷﺆﻣ نﺎﻛ اذإ
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
• ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ
ضﺎﻔﺨﻧا ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ" ﺮﺷﺆﻣ نﺎﻛ اذإ
.ءﻞﳌا ةدﺎﻋإ ﻰﻟإ ﺔﺟﺎﳊاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ
ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
• ﺔﺟﺎﳊاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺢﻠﳌا ضﺎﻔﺨﻧا ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ" ﺮﺷﺆﻣ نﺎﻛ اذإ
.ءﻞﳌا ةدﺎﻋإ ﻰﻟإ
٩ضﺮﻋ ﺔﺷﺎﺷ
.ﻞﻴﺟﺄﺘﻟا ةﺪﻣ وأ تﺎﻣﻮﻠﻌﳌا ﺰﻣر وأ ﻲﻘﺒﺘﳌا ﺖﻗﻮﻟا ضﺮﻋ
١٠ءﺪﺒﻟا ﻞﻴﺟﺄﺗ
ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﻐﺸﺗ ءﺪﺑ ﻞﻴﺟﺄﺗ ﻚﻨﻜﳝ .ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﺟﺄﺗ تﺎﻋﺎﺳ ﲔﻴﻌﺘﻟ رﺰﻟا اﺬﻫ ﻰﻠﻋ ﻂﻐﺿا
.ةﺪﺣاو ﺔﻋﺎﺳ ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ﻞﻴﺟﺄﺗ ﻰﻟإ رﺰﻟا اﺬﻫ ﻰﻠﻋ ةﺪﺣاو ةﺮﻣ ﻂﻐﻀﻟا يدﺆﻳ .ﺔﻋﺎﺳ ٢٤ ﻰﺘﺣ
١١(ءﺪﺒﻟا) START
.بﺎﺒﻟا قﻼﻏإ ﻞﺒﻗ (ءﺪﺒﻟا) START رز ﻰﻠﻋ ﻂﻐﺿا ،ةرود ءﺪﺒﻟ
(ءﺪﺒﻟا) START رز ﻰﻠﻋ راﺮﻤﺘﺳﺎﺑ ﻂﻐﺿا ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻳﺮﺼﺗو ﺔﻴﻟﺎﳊا ةروﺪﻟا ءﺎﻐﻟﻹ :ﻂﺒﺿ ةدﺎﻋإ*
.
ﹴ
ناﻮﺛ (٣) ثﻼﺛ ةﺪﳌ
ﻞﻴﻐﺸﺗ ةدﺎﻋﻹ (ءﺪﺒﻟا) START ﻰﻠﻋ ﻂﻐﺿا ﻢﺛ ا
ﹰ
رﺎﻴﺧو ةرود دﺪﺣ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻂﺒﺿ ةدﺎﻋإ دﺮﺠﲟو
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
.تاروﺪﻟا
ىﺪﺣإ ءﺪﺑ ﻞﺒﻗ (ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ وأ ،ءﺪﺒﻟا ﻞﻴﺟﺄﺗ وأ ،ﺔﻟﻮﻤﺣ ﻒﺼﻧ وأ ،تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا) تارﺎﻴﳋا ﺪﻳﺪﲢ ﻚﻨﻜﳝ
:تادﺎﺷرﻹا هﺬﻫ ﻊﺒﺗا ،ﺔﺑﺎﺠﺘﺳﻻا ﺔﻴﺳﺎﺴﳊ ﺲﻤﻠﻟا ﺔﺣﻮﻟ ناﺪﻘﻓ ﻊﻨﳌ
•.ﻪﻴﻠﻋ ﻂﻐﻀﺗ ﻻ .ﺪﺣاو ﻊﺒﺻإ ماﺪﺨﺘﺳﺎﺑ ﺔﻴﻤﻗر ﺔﺣﻮﻟ ﻞﻛ ﻂﺳو ﺲﳌا
•.ﺔﺒﻃرو ﺔﻤﻋﺎﻧ شﺎﻤﻗ ﺔﻌﻄﻘﺑ مﺎﻈﺘﻧﺎﺑ ﺲﻤﻠﻟﺎﺑ ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﺢﻄﺳ ﻒ
ﹼ
ﻈﻧ
•.ﻚﻟذ فﻼﺨﺑ تادﺎﺷرإ تدرو اذإ ﻻإ ،ةﺪﺣاﻮﻟا ةﺮﳌا ﻲﻓ ةﺪﺣاو ﺢﻴﺗﺎﻔﻣ ﺔﺣﻮﻟ ﻦﻣ ﺮﺜﻛأ ﺲﻤﻠﺗ ﻻ
kAĮkAĮkAĮ
DW5500M_DD81-02437K-00_AR.indd 15DW5500M_DD81-02437K-00_AR.indd 15 2019-03-18 11:14:372019-03-18 11:14:37
تاﺰﻴﳌاو ءاﺰﺟﻷا _١٦
ضﺮﻌﻟا ﺔﺷﺎﺷ
DW60M6050F*/DW60M6051F*/DW60M6040F*
DW60M6050U*/DW60M6051U*/DW60M6040U*
DW60M6050S*/DW60M6051S*/DW60M6040S*
٢ ٢٣ ٣١
DW60M6050/DW60M6051 DW60M6040
١ﺞﻣﺎﻧﺮﺒﻟا زﻮﻣرﺞﻣﺎﻧﺮﺑ ﻞﻛ ﺪﻳﺪﺤﺘﻟ (ﺞﻣﺎﻧﺮﺒﻟا) Program رز ﻰﻠﻋ ﻂﻐﺿا
ﻒﺜﻜﻣ
ﺔﻴﻋوﻷاو ﻲﻧاوﻷا ﻚﻟذ ﻲﻓ ﺎﲟ خﺎﺴﺗﻻا ةﺪﻳﺪﺷ تاودﻷا ﻞﺴﻏ
ﻲﺋﺎﻘﻠﺗ ﻞﺴﻏ
ﺎﻳﺎﻘﺑ ﺔﻴﻤﻛ فﺎﺸﺘﻛا ﻢﺘﻳ ﺚﻴﺣ ،ﺎ
ﹰ
ﻴﻣﻮﻳ مﺪﺨﺘﺴ
ﹸ
ﺗ ﻲﺘﻟا خﺎﺴﺗﻻا ةﺪﻳﺪﺷو ﺔﻔﻴﻔﺧ تاودﻷا ﻞﺴﻏ
ﺎ
ﹰ
ﻴﺋﺎﻘﻠﺗ ﺔﻤﻌﻃﻷا
يدﺎﺼﺘﻗا
.هﺎﻴﳌا كﻼﻬﺘﺳا ﻞﻴﻠﻘﺗو ﺔﻗﺎﻄﻟا ﺮﻴﻓﻮﺗ ﻊﻣ يدﺎﻋ
ﹴ
ﻞﻜﺸﺑ ﺔﺨﺴﺘﳌا ﻲﻣﻮﻴﻟا ماﺪﺨﺘﺳﻻا تاودأ ﻞﺴﻏ
ﺔﻋﺮﺴﻟا ﻖﺋﺎﻓ
.ةﺪﳌا ةﺮﻴﺼﻗ ةرود ﻲﻓ يدﺎﻋ
ﹴ
ﻞﻜﺸﺑ ﺔﺨﺴﺘﳌا ﻲﻣﻮﻴﻟا ماﺪﺨﺘﺳﻻا تاودأ ﻞﺴﻏ
ﻲﻟوأ ﻞﺴﻏ
(DW60M6050/DW60M6051) .ةﺪﳌا ةﺮﻴﺼﻗ ةروﺪﺑ خﺎﺴﺗﻻا ﺔﻠﻴﻠﻗ تاودﻷا ﻞﺴﻐﻟ
ﻖﻴﻗر
.خﺎﺴﺗﻻا ﺔﻠﻴﻠﻗ ﺮﺴﻜﻟا ﺔﻠﻬﺳ تاودﻷا
ﻲﻟوأ ﻞﺴﻏ
.ﺮﺧآ ﺞﻣﺎﻧﺮﺑ ﻞﻴﻐﺸﺗ ﻞﺒﻗ خﺎﺴﺗﻻا ﺔﻟازﻹ ةدرﺎﺒﻟا هﺎﻴﳌﺎﺑ ﻒﻄﺸﻟا
٢ضﺮﻋ ﺔﺷﺎﺷ
.ﻞﻴﺟﺄﺘﻟا ةﺪﻣ وأ تﺎﻣﻮﻠﻌﳌا ﺰﻣر وأ ﻲﻘﺒﺘﳌا ﺖﻗﻮﻟا ضﺮﻋ
٣ءﻞﳌا ةدﺎﻋإ اﺮﺷﺆﻣ
ﺐﺠﻳ ﻪﻧأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ نﺎﻛ اذإ
.ﺢﻠﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
ﺐﺠﻳ ﻪﻧأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ نﺎﻛ اذإ
ﻢﺴﻘﻟا ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ ،ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﻞﻣ ةدﺎﻋﻹ .ﺢﻠﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ
.٢١ ﺔﺤﻔﺻ ﻲﻓ "ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ع
ﹼ
زﻮﻣ ءﻞﻣ ةدﺎﻋإ ﻪﻴﻓ ﻲﻐﺒﻨﻳ يﺬﻟا
ﺖﻗﻮﻟا"
ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
ﻰﻟإ ﺔﺟﺎﳊاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺢﻠﳌا ضﺎﻔﺨﻧا ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ" ﺮﺷﺆﻣ نﺎﻛ اذإ
.ءﻞﳌا ةدﺎﻋإ
.١٩ ﺔﺤﻔﺻ ﻲﻓ "ﺢﻠﳌﺎﺑ ﻲﻘﻨﳌا ﺪﻳوﺰﺗ" ﻢﺴﻗ ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ ،ﺢﻠﳌا ناﺰﺧ ءﻞﻣ ةدﺎﻋﻹ
تاﺰﻴﳌاو ءاﺰﺟﻷا
DW5500M_DD81-02437K-00_AR.indd 16DW5500M_DD81-02437K-00_AR.indd 16 2019-03-18 11:14:372019-03-18 11:14:37
١٧_ تاﺰﻴﳌاو ءاﺰﺟﻷا
تاﺰﻴﳌاو ءاﺰﺟﻷا ٠١
DW60M6050BB/DW60M6040BB
٣٢١
DW60M6050
DW60M6040
١ﺞﻣﺎﻧﺮﺒﻟا زﻮﻣرﺞﻣﺎﻧﺮﺑ ﻞﻛ ﺪﻳﺪﺤﺘﻟ ﺞﻣﺎﻧﺮﺒﻟا رز ﻰﻠﻋ ﻂﻐﺿا
ﻲﺋﺎﻘﻠﺗ ﻞﺴﻏ
ﺎﻳﺎﻘﺑ ﺔﻴﻤﻛ فﺎﺸﺘﻛا ﻢﺘﻳ ﺚﻴﺣ ،ﺎ
ﹰ
ﻴﻣﻮﻳ مﺪﺨﺘﺴ
ﹸ
ﺗ ﻲﺘﻟا خﺎﺴﺗﻻا ةﺪﻳﺪﺷو ﺔﻔﻴﻔﺧ تاودﻷا ﻞﺴﻏ
ﺎ
ﹰ
ﻴﺋﺎﻘﻠﺗ ﺔﻤﻌﻃﻷا
يدﺎﺼﺘﻗا
.هﺎﻴﳌا كﻼﻬﺘﺳا ﻞﻴﻠﻘﺗو ﺔﻗﺎﻄﻟا ﺮﻴﻓﻮﺗ ﻊﻣ يدﺎﻋ
ﹴ
ﻞﻜﺸﺑ ﺔﺨﺴﺘﳌا ﻲﻣﻮﻴﻟا ماﺪﺨﺘﺳﻻا تاودأ ﻞﺴﻏ
ﻒﺜﻜﻣ
ﺔﻴﻋوﻷاو ﻲﻧاوﻷا ﻚﻟذ ﻲﻓ ﺎﲟ خﺎﺴﺗﻻا ةﺪﻳﺪﺷ تاودﻷا ﻞﺴﻏ
ﻲﻟوأ ﻞﺴﻏ
(DW60M6050/DW60M6051) .ةﺪﳌا ةﺮﻴﺼﻗ ةروﺪﺑ خﺎﺴﺗﻻا ﺔﻠﻴﻠﻗ تاودﻷا ﻞﺴﻐﻟ
ﻖﻴﻗر
.خﺎﺴﺗﻻا ﺔﻠﻴﻠﻗ ﺮﺴﻜﻟا ﺔﻠﻬﺳ تاودﻷا
ﺔﻋﺮﺴﻟا ﻖﺋﺎﻓ
.ةﺪﳌا ةﺮﻴﺼﻗ ةرود ﻲﻓ يدﺎﻋ
ﹴ
ﻞﻜﺸﺑ ﺔﺨﺴﺘﳌا ﻲﻣﻮﻴﻟا ماﺪﺨﺘﺳﻻا تاودأ ﻞﺴﻏ
ﻲﻟوأ ﻞﺴﻏ
.ﺮﺧآ ﺞﻣﺎﻧﺮﺑ ﻞﻴﻐﺸﺗ ﻞﺒﻗ خﺎﺴﺗﻻا ﺔﻟازﻹ ةدرﺎﺒﻟا هﺎﻴﳌﺎﺑ ﻒﻄﺸﻟا
٢ءﻞﳌا ةدﺎﻋإ اﺮﺷﺆﻣ
ﺐﺠﻳ ﻪﻧأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ نﺎﻛ اذإ
.ﺢﻠﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ
ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
ﻰﻟإ ﺔﺟﺎﳊاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺢﻠﳌا ضﺎﻔﺨﻧا ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ" ﺮﺷﺆﻣ نﺎﻛ اذإ
.ءﻞﳌا ةدﺎﻋإ
.١٩ ﺔﺤﻔﺻ ﻲﻓ "ﺢﻠﳌﺎﺑ ﻲﻘﻨﳌا ﺪﻳوﺰﺗ" ﻢﺴﻗ ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ ،ﺢﻠﳌا ناﺰﺧ ءﻞﻣ ةدﺎﻋﻹ
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ
ﺐﺠﻳ ﻪﻧأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ نﺎﻛ اذإ
ﻢﺴﻗ ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ ،ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﻞﻣ ةدﺎﻋﻹ .ﺢﻠﳌا وأ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ةدﺎﻋإ
.٢١ ﺔﺤﻔﺻ ﻲﻓ "ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﻞﻣ"
ءﺪﺒﻟا ﻞﻴﺟﺄﺗ ﺮﺷﺆﻣ
."ءﺪﺒﻟا ﻞﻴﺟﺄﺗ" رﺎﻴﳋا ﺪﻳﺪﲢ ﻚﻴﻠﻋ نأ ﻲﻨﻌﻳ اﺬﻬﻓ ،
ﹰ
ءﺎﻀﻣ "ءﺪﺒﻟا ﻞﻴﺟﺄﺗ" ﺮﺷﺆﻣ نﺎﻛ اذإ
٣ضﺮﻋ ﺔﺷﺎﺷ
.ﻞﻴﺟﺄﺘﻟا ةﺪﻣ وأ تﺎﻣﻮﻠﻌﳌا ﺰﻣر وأ ﻲﻘﺒﺘﳌا ﺖﻗﻮﻟا ضﺮﻋ
DW5500M_DD81-02437K-00_AR.indd 17DW5500M_DD81-02437K-00_AR.indd 17 2019-03-18 11:14:372019-03-18 11:14:37
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
_١٨
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
(هﺎﻴﳌا ﺮﺴﻋ ىﻮﺘﺴﻣ داﺪﻋإ) هﺎﻴﳌا ﻲﻘﻨﻣ ﻊﺿو
كﻼﻬﺘﺳا ىﻮﺘﺴﻣ ﲔﺴﲢ ﻰﻟإ فﺪﻬﻳ اﺬﻫو .مﺪﺨﺘﺴﳌا ءﺎﳌا ﺮﺴ
ﹸ
ﻋ ﻰﻠﻋ ﺪﻤﺘﻌﺗ ﻲﺘﻟا ﺔﻜﻠﻬﺘﺴﳌا ﺢﻠﳌا ﺔﻴﻤﻛ ﻂﺒﺿ ﻦﻜﳝ ﺚﻴﺤﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻢﻴﻤﺼﺗ ﰎ
:ﻲﻠﻳ ﺎﲟ ﻢﻗ ،ﺢﻠﳌا كﻼﻬﺘﺳا ىﻮﺘﺴﻣ ﻂﺒﻀﻟ .ﺢﻠﳌا
١ .؛زﺎﻬﳉا ﻞﻴﻐﺸﺘﺑ ﻢﻗ
٢ .؛زﺎﻬﳉا ﻞﻴﻐﺸﺗ ﺪﻌﺑ ﺔﻴﻧﺎﺛ ٦٠ لﻼﺧ هﺎﻴﳌا ﻲﻘﻨﻣ ﻂﺒﺿ ﻊﺿو ﻞﻴﻐﺸﺗ ءﺪﺒﻟ
ﹺ
ناﻮﺛ ٥ ﻦﻣ ﺮﺜﻛﻷ ﻲﻟوأ ﻞﺴﻏ رﺰﻟا ﻰﻠﻋ ﻂﻐﺿا
•:ﻲﻟﺎﺘﻟا ﻞﺴﻠﺴﺘﻟﺎﺑ ﻂﺒﻀﻟا تﺎﻴﻠﻤﻋ ﺮﻴﻴﻐﺗ ﻢﺘﻴﺳو ،ﻚﺑ ﺔﺻﺎﳋا ﺔﻴﻠﶈا ﺔﺌﻴﺒﻠﻟ ﺎ
ﹰ
ﻘﻓو ﺐﺳﺎﻨﳌا ﻂﺒﻀﻟا ﺪﻳﺪﺤﺘﻟ ﻲﻟوأ ﻞﺴﻏ رﺰﻟا ﻰﻠﻋ ﻂﻐﺿا
.ﻲﻟﺎﺘﻟا لوﺪﺠﻠﻟ ﺎ
ﹰ
ﻘﻓو هﺬﻫ ﻂﺒﻀﻟا تاءاﺮﺟﺈﺑ مﺎﻴﻘﻟا ﺢﺼﻨ
ﹸ
ﻳو ;H6
H5
H4
H3
H2
H1
H3 (IEC 60436) :ﻊﻨﺼﳌا داﺪﻋإ *
٣ ..داﺪﻋﻹا جذﻮﳕ ءﺎﻬﻧﻹ
ﹺ
ناﻮﺛ ٥ ةﺪﳌ ﺮﻈﺘﻧا
ءﺎﳌا ﺮﺴﻋ
د
ﹺ
ﺪ
ﹸ
ﶈا ﻊﺿﻮﻣ
ﺢﻠﳌا كﻼﻬﺘﺳا
(ةرود/ماﺮﺟ)
تﺎﺟرﺪﻟﺎﺑ) ° dH
(ﺔﻴﻧﺎﳌﻷا
تﺎﺟرﺪﻟﺎﺑ) ° fH
(ﺔﻴﺴﻧﺮﻔﻟا
° Clark
تﺎﺟرﺪﻟﺎﺑ)
(ﺔﻴﻧﺎﻄﻳﺮﺒﻟا
mmol/l
(ﺮﺘﻟ/لﻮﻣ ﻲﻠﻠﻣ)
٥-٠٩-٠٦-٠٠٫٩٤-٠H1٠
١١-٦٢٠-١٠١٤-٧٢٫٠-١٫٠H2٩
١٧-١٢٣٠-٢١٢١-١٥٣٫٠-٢٫١H3١٢
٢٢-١٨٤٠-٣١٢٨-٢٢٤٫٠-٣٫١H4٢٠
٣٤-٢٣٦٠-٤١٤٢-٢٩٦٫٠-٤٫١H5٣٠
٥٥-٣٥٩٨-٦١٦٩-٤٣٩٫٨-٦٫١H6٦٠
ﺮﺘﻟ/لﻮﻣ ﻲﻠﻠﻣ ٠,١٧٨ = (ﺔﻴﻧﺎﳌأ ﺔﺟرد) dH ١
ﺮﺘﻟ/لﻮﻣ ﻲﻠﻠﻣ ٠,١٤٣ = (ﺔﻴﻧﺎﻄﻳﺮﺑ ﺔﺟرد) Clark ١
ﺮﺘﻟ/لﻮﻣ ﻲﻠﻠﻣ ٠,١ = (ﺔﻴﺴﻧﺮﻓ ﺔﺟرد) fH ١
.ﻚﺑ صﺎﳋا هﺎﻴﳌا داﺪﻣإ ﺮﺴ
ﹸ
ﻋ لﻮﺣ تﺎﻣﻮﻠﻌﻣ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ﺔﻴﻠﶈا هﺎﻴﳌا ﺔﺌﻴﻬﺑ ﻞﺼﺗا
هﺎﻴﳌا ﻲﻘﻨﻣ
زﺎﻬﳉا ﺪﻳوﺰﺗ ﰎ .ﺔﻴﻋوﻷاو قﺎﺒﻃﻷا ﻰﻠﻋ ﺐﺳاوﺮﻟا نﻮﻜﺘﺗ ﺪﻗ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻊﻣ ﺮﺴﻌﻟا ءﺎﳌا ماﺪﺨﺘﺳا ﺔﻟﺎﺣ ﻲﻓ .ﺮﺧﻵ نﺎﻜﻣ ﻦﻣ هﺎﻴﳌا ﺮﺴ
ﹸ
ﻋ ﻒﻠﺘﺨﻳ
.هﺎﻴﳌا ﻦﻣ ندﺎﻌﳌاو ﺐﺋاﻮﺸﻟا ﺔﻟازﻹ ﻖﻴﻗد ﻞﻜﺸﺑ ﻢﻤﺼﻣ ﺢﻠﻣ ماﺪﺨﺘﺴﻳ صﺎﺧ ﻲﻘﻨﲟ
[ﻲﻧاوﻷا ﻰﻠﻋ ﺔﻧ
ﹼ
ﻮﻜﺘﳌا ﺐﺳاوﺮﻟا]
DW5500M_DD81-02437K-00_AR.indd 18DW5500M_DD81-02437K-00_AR.indd 18 2019-03-18 11:14:382019-03-18 11:14:38
١٩_ هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا ٠٢
ﺢﻠﳌﺎﺑ ﻲﻘﻨﳌا ﺪﻳوﺰﺗ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻊﻣ ماﺪﺨﺘﺳﻼﻟ ﺺﺼا ﺢﻠﳌا ﺎ
ﹰ
ﻤﺋاد مﺪﺨﺘﺳا
:ﻲﻠﻳ ﺎﻤﻛ ﺎﻬﺘﺌﺒﻌﺗ ﻲﻐﺒﻨﻳو ﻲﻠﻔﺴﻟا فﺮﻟا ﻞﻔﺳأ ﺢﻠﳌا ﺔﻳوﺎﺣ ﻊﻘﺗ
هﺎﺒﺘﻧا
• ﺔﻟﺎﺴﻏ ﻊﻣ ماﺪﺨﺘﺳﻼﻟ ﺔﺼﺼﺨﻣ ﺖﺴﻴﻟ ىﺮﺧﻷا ﺢﻠﳌا عاﻮﻧأ ﻊﻴﻤﺟ نأ ﺚﻴﺣ .قﺎﺒﻃﻷا تﻻﺎﺴﻏ ﻊﻣ ماﺪﺨﺘﺳﻼﻟ ﻂﻘﻓ ﺺﺼا ﺢﻠﳌا مﺪﺨﺘﺳا
ﻲﻄﻐﺗ ﻼﻓ ،ﺐﺳﺎﻨﳌا ﺮﻴﻏ ﺢﻠﳌا ماﺪﺨﺘﺳا ﻦﻋ ﺔﲡﺎﻧ راﺮﺿأ دﻮﺟو ﺔﻟﺎﺣ
ﻲﻓ .هﺎﻴﳌا ﻲﻘﻨﻣ ﻒﻠﺗ ﻰﻟإ يدﺆﻴﺳ يﺬﻟا ،مﺎﻌﻄﻟا ﺢﻠﻣ ﺔﺻﺎﺧ ،قﺎﺒﻃﻷا
.ﻪﺘﺒﺒﺳ ﺪﻗ ﻒﻠﺗ يأ ﺔﻴﻟﻮﺌﺴﻣ ﻞﻤﺤﺘﺗ ﻦﻟو نﺎﻤﺿ يأ ﺔﻌ
ﹼ
ﻨﺼﳌا ﺔﻛﺮﺸﻟا
• ﻲﻘﺒﺘﻣ ﺢﻟﺎﻣ ءﺎﻣ وأ ﺢﻠﻣ تﺎﺒﻴﺒﺣ دﻮﺟو ﻊﻨﻤﻴﺳ هروﺪﺑ اﺬﻫو .ﺔﻠﻣﺎﻜﻟا ﻞﺴﻐﻟا ﺞﻣاﺮﺑ ﺪﺣأ ﻞﻴﻐﺸﺗ ﻲﻓ ةﺮﺷﺎﺒﻣ ءﺪﺒﻟا ﻞﺒﻗ ﻂﻘﻓ ﺢﻠﳌا ﺔﺌﺒﻌﺘﺑ ﻢﻗ
.زﺎﻬﺠﻠﻟ ﻞﻛﺂﺗ ﻲﻓ ﺐﺒﺴﺘﻳ نأ ﻪﻧﺄﺷ ﻦﻣ يﺬﻟاو ﺖﻗﻮﻟا ﻦﻣ ةﺮﺘﻔﻟ ﺔﺑﺎﻜﺴﻧا ﺪﻌﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟا عﺎﻗ ﻲﻓ
•.ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ةءﺎﺿإ ﺊﻔﻄﻨﺗ ،ﻰﻟوﻷا ﻞﺴﻐﻟا ةرود ﺪﻌﺑ
١ ..ﺢﻠﳌا ﺔﻳوﺎﺣ ﻦﻣ ﻪﺘﻟازإو ءﺎﻄﻐﻟا ﻚﻔﺑ ﻢﻗ ﻢﺛ ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﺔﻟازﺈﺑ ﻢﻗ
ﺢﺘﻓ
ﺢﺘﻓ
٢ ..(ﺮﺘﻟ ١ ﻲﻟاﻮﺣ) ءﺎﳌﺎﺑ راﺪﻘﳌا ﻦﻣ ٢/٣ ﺔﺌﺒﻌﺘﺑ ﻢﻗ ،ةﺮﻣ لوﻷ ﺔﻳوﺎﳊا ﺔﺌﺒﻌﺘﺑ مﻮﻘﺗ ﺖﻨﻛ اذإ
٣ . ةﺮﻴﻐﺻ ﺔﻴﻤﻛ جوﺮﺧ ﺪﻌ
ﹸ
ﻳ .ﺢﻠﳌا ﻦﻣ ﻢﺠﻛ ١٫٥ ﻲﻟاﻮﺣ ﻊﺿ ﻢﺛ ﺔﺤﺘﻔﻟا ﻞﺧاد (ﻖﻓﺮﳌا) ﻊﻤﻘﻟا ﺔﻳﺎﻬﻧ ﻊﺿ
.ﺎ
ﹰ
ﻳدﺎﻋ ا
ﹰ
ﺮﻣأ ﺢﻠﳌا ﺔﻳوﺎﺣ ﻦﻣ هﺎﻴﳌا ﻦﻣ
۴ ..ﺔﻳﺎﻨﻌﺑ ﺔﻴﻧﺎﺛ ةﺮﻣ ءﺎﻄﻐﻟا ﻂﺑرا
۵ ..ﺢﻠﳌﺎﺑ ﺔﻳوﺎﳊا ﺔﺌﺒﻌﺗ ﺪﻌﺑ ﺢﻠﳌﺎﺑ صﺎﳋا ﻪﻴﺒﻨﺘﻟا حﺎﺒﺼﻣ ﻞﻴﻐﺸﺗ فﺎﻘﻳإ ﻢﺘﻳ ﺎﻣ ةدﺎﻋ
• ،
ﹴ
فﺎﻛ رﺪﻘﺑ ﺢﻠﳌا ﺔﻳوﺎﺣ ءﻞﻣ ﻦﻣ ﻢﻏﺮﻟﺎﺑو .ﻢﻜﺤﺘﻟا ﺔﺣﻮﻠﺑ دﻮﺟﻮﳌا ﺢﻠﳌﺎﺑ صﺎﳋا ﻪﻴﺒﻨﺘﻟا حﺎﺒﺼﻣ ءﻲﻀﻳ ﺎﻣﺪﻨﻋ ﺢﻠﳌا ﺔﻳوﺎﺣ ﺔﺌﺒﻌﺗ ةدﺎﻋإ ﺐﺠﻳ
.ﻞﻣﺎﻜﻟﺎﺑ ﺢﻠﳌا ﺔﺑاذإ ﻢﺘﺗ ﻰﺘﺣ ﺮﺷﺆﳌا ءﻮﺿ ﺊﻔﻄﻨﻳ ﻻ ﺪﻘﻓ
ﻊﻣ ﺎﻬﻠﻴﻐﺸﺗ ﰎ ﻲﺘﻟا تاروﺪﻟا ﻖﻳﺮﻃ ﻦﻋ ﻲﻘﻨﳌا ﻞﺧاد ﺢﻠﳌا ﻞﻴﻤﲢ ﺖﻗو ﺔﻓﺮﻌﻣ ﻚﻨﻜﳝ ،ﻢﻜﺤﺘﻟا ﺔﺣﻮﻠﺑ ﺢﻠﳌﺎﺑ ﺔﺻﺎﳋا ﻪﻴﺒﻨﺘﻟا ةءﺎﺿإ ﺪﲡ ﻢﻟ اذإ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
•.ﻒﻴﻈﻨﺘﻠﻟ ﻲﻟوأ ﻞﺴﻏ ﺞﻣﺎﻧﺮﺑ ﻞﻴﻐﺸﺘﺑ ﻢﻗ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ةﺮﻴﺒﻛ ﺢﻠﻣ ﺔﻴﻤﻛ بﺎﻜﺴﻧا ﺔﻟﺎﺣ ﻲﻓ
DW5500M_DD81-02437K-00_AR.indd 19DW5500M_DD81-02437K-00_AR.indd 19 2019-03-18 11:14:382019-03-18 11:14:38
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
_٢٠
ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
.ﻒﻈﻨﳌا جرد ﻲﻓ ﻒﻈﻨﻣ دﻮﺟو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ تارود ﻊﻴﻤﺟ ﺐﻠﻄﺘﺗ
.ءادأ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﳊا نﺎﻤﻀﻟ ةدﺪﶈا ةروﺪﻠﻟ ﺔﺒﺳﺎﻨﳌا ﻒ
ﹼ
ﻈﻨﳌا ﺔﻴﻤﻛ ﻒﺿأ
ﻲﻓ ﺐﺒﺴﺘﻳ وأ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ءادأ ﻦﻣ ﻞﻠﻘﻳ ﺎﳑ ،ةﻮﻏﺮﻟا ﻦﻣ ﺮﻴﺜﻜﻟا جاﺮﺧإ ﻰﻠﻋ يدﺎﻌﻟا ﻒ
ﹼ
ﻈﻨﳌا ﻞﻤﻌﻳ .ﻂﻘﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻈﻨﻣ مﺪﺨﺘﺳا :ﻪﻴﺒﻨﺗ
.ءادﻷا ﻲﻓ رﻮﺼﻗ ثوﺪﺣ
داﻮﻣو ﺔﺠﻴﻬﻣ تﺎﻧﻮﻜﻣ ﻰﻠﻋ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻣ يﻮﺘﺤﻳ ﺚﻴﺣ .ةﺮﺨﺑﻷا قﺎﺸﻨﺘﺳا ﺐﻨﲡ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻈﻨﻣ عﻼﺘﺑﺎﺑ ﻢﻘﺗ ﻻ :ﺮﻳﺬﲢ
ﺔﻳﺎﻋﺮﻟا ﺐﻠﻃﺎﻓ ،ﻪﺗﺮﺨﺑأ قﺎﺸﻨﺘﺳا وأ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻣ عﻼﺘﺑﺎﺑ ﺖﻤﻗ اذإ .ﺲﻔﻨﺘﻟﺎﺑ ﻞﻛﺎﺸﻣ ثوﺪﺣ ﻲﻓ ﺐﺒﺴﺘﺗ نأ ﻦﻜﳝ ﺔﻳوﺎﻛ ﺔﻴﺋﺎﻴﻤﻴﻛ
.ا
ﹰ
رﻮﻓ ﺔﻴﺒﻄﻟا
.لﺎﻔﻃﻷا لوﺎﻨﺘﻣ ﻦﻋ ا
ﹰ
ﺪﻴﻌﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻈﻨﻣ ﻆﻔﺣا :ﺮﻳﺬﲢ
ﻒ
ﹼ
ﻈﻨﳌا ع
ﹼ
زﻮﻣ ﺔﺌﺒﻌﺗ
١ . .ﻒ
ﹼ
ﻈﻨﳌا عزﻮﻣ ﺮﻳﺮﲢ ﻚﺳﺎﻣ ﻰﻠﻋ ﻂﻐﻀﻟﺎﺑ ﻒ
ﹼ
ﻈﻨﳌا عزﻮﻣ ءﺎﻄﻏ ﺢﺘﻓا
.ﻞﺴﻐﻟا ةرود ءﺎﻬﺘﻧا ﺪﻨﻋ ﺎ
ﹰ
ﺣﻮﺘﻔﻣ ءﺎﻄﻐﻟا نﻮﻜﻳ ﺎﻣ ﺎ
ﹰ
ﻤﺋاد
٢ . .ﻲﺴﻴﺋﺮﻟا ﻞﺴﻐﻟا ﻒ
ﹼ
ﻈﻨﻣ جرد ﻰﻟإ ﺎﻬﺑ ﻰﺻﻮﳌا ﻒ
ﹼ
ﻈﻨﳌا ﺔﻴﻤﻛ ﻒﺿأ
٣ ..ﻞﻔﺳﻷ ﻪﻴﻠﻋ ﻂﻐﻀﻟا ﻢﺛ رﺎﺴﻴﻟا ﺔﻬﺟ ﻪﻜﻳﺮﲢ ﻖﻳﺮﻃ ﻦﻋ ءﺎﻄﻐﻟا ﻖﻠﻏأ
.ﻒ
ﹼ
ﻈﻨﳌا صاﺮﻗأ ماﺪﺨﺘﺳﺎﺑ صﺎﺧ ﻞﺼﻔﻨﻣ رز ﺪﺟﻮﻳ ﻻ
۴ . ،خﺎﺴﺗﻻا ةﺪﻳﺪﺷ تاودأ ﻚﻳﺪﻟ نﺎﻛ اذإ ﺔﺻﺎﺧ ﻒﻴﻈﻨﺘﻠﻟ ﺔﺠﻴﺘﻧ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ
ﻲﻓ ﺪﻴﻔﻣ ﺮﻣﻷا اﺬﻬﻓ ،بﺎﺒﻟا ﻰﻟإ ﻒ
ﹼ
ﻈﻨﳌا ﻦﻣ (تﺎﻣاﺮﺟ ٨ ﻲﻟاﻮﺣ) ةﺮﻴﻐﺻ ﺔﻴﻤﻛ ﻒﺿأ
.ﻲﻟوﻷا ﻞﺴﻐﻟا ﺔﻠﺣﺮﻣ
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
DW5500M_DD81-02437K-00_AR.indd 20DW5500M_DD81-02437K-00_AR.indd 20 2019-03-18 11:14:412019-03-18 11:14:41
٢١_ هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا ٠٢
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ماﺪﺨﺘﺳا
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﻞﻣ
.ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ءﻞﻣ ﺪﻋأ ،ﻢﻜﺤﺘﻟا ﺔﺣﻮﻠﺑ دﻮﺟﻮﳌا ﺢﻠﳌا ءﻞﻣ ةدﺎﻋإ ﺮﺷﺆﻣ ﺊﻀﻳ نأ دﺮﺠﲟ
.ﺎﻬﻌﻣ ﻂﻘﻓ ﻞﺋﺎﺴﻟا ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ مﺪﺨﺘﺳا ﻦﻜﳝ ﺚﻴﺤﺑ ﻚﺑ ﺔﺻﺎﳋا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻢﻴﻤﺼﺗ ﰎ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞ
ﹼ
ﻄﻌﺗ ﻰﻟإ يدﺆﻳ ﺎﳑ ناﺰﳋا ﺔﺤﺘﻓ داﺪﺴﻧا ﻲﻓ قﻮﺤﺴﳌا ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ماﺪﺨﺘﺳا ﺐﺒﺴﺘﻴﺳ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﻒﻴﻔﺠﺘﻟا ءادأ ﲔﺴﲢ ﻰﻠﻋ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ﻞﻤﻌﻳ
.ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ﻰﻟإ يدﺎﻋ ﻒ
ﹼ
ﻈﻨﻣ ﺔﻓﺎﺿﺈﺑ ﻢﻘﺗ ﻻ :ﻪﻴﺒﻨﺗ
١ ..ﺔﻋﺎﺴﻟا برﺎﻘﻋ ﺲﻜﻋ هﺎﲡا ﻲﻓ هﺮﻳوﺪﺘﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ﺢﺘﻓا
ءادأ ﲔﺴﲢ ﻰﻠﻋ ﺔﻣﺪﺨﺘﺴﳌا ﻒ
ﹼ
ﻈﻨﳌا صاﺮﻗأ ﻰﻟإ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ﺔﻓﺎﺿإ ﻞﻤﻌﺘﺳ
.ﻒﻴﻔﺠﺘﻟا
٢ ..ﻒﻄﺸﻟا ﺪﻋﺎﺴﲟ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ﻸﻣا
.ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﻞﻣ ﺪﻨﻋ ناﺰﳋا ﺔﺤﺘﻓ مﺪﺨﺘﺳا
.ﻲﻠﻜﻟا ىﻮﺘﺴﳌا ﺮﺷﺆﻣ قﻮﻓ ناﺰﳋا ﻸﲤ ﻻ :ﻪﻴﺒﻨﺗ
.ﻞﺴﻐﻟا ةرود ءﺎﻨﺛأ ﺪﺋاﺰﻟا ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ﺾﻴﻔﻳ ﺪﻘﻓ
٣ . داز ،ﻢﻗﺮﻟا داز ﺎﻤﻠﻛو .٦و ١ ﲔﺑ ﺎﻣ ﻢﻗر ﻰﻟإ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ﺮﺷﺆﻣ صﺮﻗ ك
ﹼ
ﺮﺣ
صﺮﻗ ﺮﻳوﺪﺗ ﻰﻠﻋ ا
ﹰ
ردﺎﻗ ﻦﻜﺗ ﻢﻟ اذإ .ﻒﻄﺸﻟا ﺪﻋﺎﺴﳌ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا
.ﺔﻴﻧﺪﻌﻣ ﺔﻠﻤﻋ ماﺪﺨﺘﺳا لوﺎﺤﻓ ،ﺔﻟﻮﻬﺴﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ
۴ ..ﺔﻋﺎﺴﻟا برﺎﻘﻋ هﺎﲡا ﻲﻓ هﺮﻳوﺪﺘﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ناﺰﺧ ءﺎﻄﻏ ﻖﻠﻏأ
DW5500M_DD81-02437K-00_AR.indd 21DW5500M_DD81-02437K-00_AR.indd 21 2019-03-18 11:14:412019-03-18 11:14:41
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
_٢٢
تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﳋا ماﺪﺨﺘﺳا ﺔﻴﻔﻴﻛ
اﺬﻫ ﺪﻳﺪﲢ ﻦﻜﳝ .١ ﻲﻓ ٣ صﺮﻗ دﻮﺟو ﺐﻠﻄﺘﻳ ﻦﻜﻟو ﻒﻄﺷ ةدﺎﻣو ﺢﻠﻣ دﻮﺟو ﺐﻠﻄﺘﻳ ﻻ يﺬﻟا تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﳋا ﻚﻳﺪﻟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻤﻀﺘﺗ
.ﻂﻘﻓ يدﺎﺼﺘﻗا وأ ﻒﺜﻜﻣ ﺞﻣﺎﻧﺮﺒﻟا ﻊﻣ رﺎﻴﳋا
،رﺎﻴﳋا اﺬﻫ نوﺪﺑ تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا ماﺪﺨﺘﺳا ﰎ اذإ تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا ﻊﻣ ماﺪﺨﺘﺳﻼﻟ ﺪﻌ
ﹸ
ﻣ تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا صاﺮﻗﻷا داﺪﻋإ نإ
.زﺎﻬﳉا ﻦﻣ ءادأ ﻞﻀﻓأ ﻰﻠﻋ ﻞﺼﲢ ﻦﻠﻓ
١ ..تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا رﺎﻴﺧ أﺪﺑا ﻢﺛ ﺔﻳوﺎﳊا ﻲﻓ تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا ﻊﺿ
٢ ..ﻪﻧﺎﻜﻣ ﻲﻓ ﺮﻘﺘﺴﻳ ﻰﺘﺣ ﻂﻐﻀﻟا ﻲﻓ ﺮﻤﺘﺳاو ءﺎﻄﻐﻟا ﻖﻠﻏأ
ﺪﻛﺄﺗ ،تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا ﻦﻤﻀﺘﺗ ةدﺪﻌﺘﻣ ةﺰ
ﹼ
ﻛﺮﻣ تﺎﻔ
ﹼ
ﻈﻨﻣ ﺔﻋﻮﻤﺠﻣ ماﺪﺨﺘﺳا ﺪﻨﻋ
.ﺢﻴﺤﺻ ﻞﻜﺸﺑ ءﺎﻄﻐﻟا قﻼﻏإ ﺔﻴﻧﺎﻜﻣإ ﻦﻣ
ﺎ
ﹰ
ﻤﺋاد ﻒﺿأو .لﺎﻔﻃﻷا لوﺎﻨﺘﻣ ﻦﻋ ا
ﹰ
ﺪﻴﻌﺑ ﻦﻣآ نﺎﻜﻣ ﻲﻓ تﺎﻔ
ﹼ
ﻈﻨﳌا ﻊﻴﻤﺠﺑ ﻆﻔﺘﺣا :هﺎﺒﺘﻧا
.ةﺮﺷﺎﺒﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ءﺪﺑ ﻞﺒﻗ عزﻮﳌا ﻰﻟإ ﻒ
ﹼ
ﻈﻨﳌا
هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا
DW5500M_DD81-02437K-00_AR.indd 22DW5500M_DD81-02437K-00_AR.indd 22 2019-03-18 11:14:422019-03-18 11:14:42
٢٣_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ ٠٣
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
ﻒﻓرﻷا لﺎﻜﺷأو تاﺰﻴﻣ ﻒﻠﺘﺨﺗ ﺪﻗ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ءادأ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ ﺔﻴﻟﺎﺘﻟا ﻒﻓرﻷا ﻞﻴﻤﲢ تﺎﻤﻴﻠﻌﺗ ﻊﺒﺗا
.ﺮﺧﻵ زاﺮﻃ ﻦﻣ ﺔﻴﻀﻔﻟا ةﺪﺋﺎﳌا ﺔﻴﻧآ ﺔﻠﺳو
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ ﺪﻌﺑ وأ ﻞﺒﻗ :هﺎﺒﺘﻧا
ﺎ
ﹰ
ﻘﻓو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ﺔﻴﻧﻵا ﻊﺿ .يرﺎﳉا ءﺎﳌﺎﺑ قﺎﺒﻃﻷا ﻒﻄﺷ يروﺮﻀﻟا ﻦﻣ ﺲﻴﻟ .مﺎﻌﻄﻟا تﻼﻀﻓ ﻦﻣ ةﺮﻴﺒﻛ تﺎﻴﻤﻛ يأ ﻂﺸﻜﺑ ﻢﻗ
:ﺔﻴﻟﺎﺘﻟا تﺎﻬﻴﺟﻮﺘﻠﻟ
١ ..ﻞﻔﺳﻷ ﺎﻬﻬﻴﺟﻮﺗ ﻊﻣ ﺎﻫﺮﻴﻏو تﺎﻳﻼﻘﻟا/ﻖﻳرﺎﺑﻷاو باﻮﻛﻷاو ﲔﺟﺎﻨﻔﻟا ﻞﺜﻣ ﺔﻴﻧﻵا ﻊﺿو
٢ ..ﺎﻬﺒﻧاﻮﺟ ﻊﻴﻤﺟ ﻰﻟإ لﻮﺻﻮﻟا هﺎﻴﻤﻠﻟ ﻦﻜﳝ ﺚﻴﺤﺑ ﻞﺋﺎﻣ ﻊﺿﻮﺑ ﺔﻘﻴﻤﻌﻟا ﺔﻴﻧﻵا وأ تﺎﻴﻨﺤﻨﳌا تاذ ﺔﻴﻧﻵا ﻊﺿو ﺐﺠﻳ
٣ ..ﺎﻬﺑﻼﻘﻧا رﺬﻌﺘﻳ ﺚﻴﺤﺑ مﺎﻜﺣﺈﺑ ﺔﻴﻧﻵا ﺖﻴﺒﺜﺗ ﻦﻣ ﺪﻛﺄﺗ
۴ ..ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ءاﺮﺟإ ءﺎﻨﺛأ ناروﺪﻟا ﻦﻣ ءﺎﳌا شﺎﺷر عرذأ ﺔﻴﻧﻵا قﻮﻌﺗ ﻻأ ﻦﻣ ﺪﻛﺄﺗ
.ﻒﻓرﻷا ﻰﻠﻋ ﻦﻣ ﺎﻬﻃﻮﻘﺳ ﻞﻬﺴﻟا ﻦﻣ نﻮﻜﻳ ﺚﻴﺣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ةﺮﻴﻐﺼﻟا ﻊﻄﻘﻟا ﻞﺴﻏ ﻢﺘﻳ ﻻأ ﺐﺠﻳ
قﺎﺒﻃﻷا جاﺮﺧإ
.ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻰﻟإ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻦﻣ هﺎﻴﳌا ﺮﻴﻄﻘﺗ ﻊﻨﳌ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا غاﺮﻓإ ﻢﺛ
ﹰ
ﻻوأ ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا غاﺮﻓإ ﻦﺴﺤﺘﺴﳌا ﻦﻣ
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ
ﺔﻴﺟﺎﺟﺰﻟا قﺎﺒﻃﻷاو ﲔﺟﺎﻨﻔﻟا نﻮﺤﺻو ةﻮﻬﻘﻟاو يﺎﺸﻟا ﲔﺟﺎﻨﻓو باﻮﻛﻷا ﻞﺜﻣ ﺔﺸﻬﻟاو ﺔﻔﻴﻔﳋا ةﺪﺋﺎﳌا قﺎﺒﻃأ ﺎﻬﺑ ﻊﺿﻮﻴﻟ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻢﻴﻤﺼﺗ ﰎ
.(ةﺪﺸﺑ ﺔﺨﺴﺘﻣ نﻮﻜﺗ ﻻ ﺚﻴﺣ) ﺔﻘﻴﻤﻌﻟا ﺮﻴﻏو ةﺮﻴﻐﺼﻟا ﺔﻴﻋوﻷاو
.ﺎ
ﹰ
ﻤﺋاد ﻞﻔﺳﻷ ﺎﻬﻬﻴﺟﻮﺗ ﻊﻣ ﺔﻴﻋوﻷاو ﲔﺟﺎﻨﻔﻟاو ﺔﻴﺟﺎﺟﺰﻟا باﻮﻛﻷا ﻊﺿ .هﺎﻴﳌا شر ﺐﺒﺴﺑ ﺎﻬﻜﻳﺮﲢ رﺬﻌﺘﻳ ﺚﻴﺤﺑ ﻲﻬﻄﻟا ﺔﻴﻧآو قﺎﺒﻃﻷا ﻊﺿ
ﻞﺧاﺪﻟا ﻲﻓ
٣
٢
۴
۵
۶
١
٣
٣
٣
١
۶
٣
٣
٣
٧
٨
٢
۴
۵
٣
٩
ﻞﺧاﺪﻟا ﻲﻓ
DW60M6050
DW60M6051
(ا
ﹰ
دﺮﻓ ١٤ ﺔﻌﺳ)
DW60M6040
(ا
ﹰ
دﺮﻓ ١٣ ﺔﻌﺳ)
ﲔﺟﺎﻨﻓ
١
٢
ﲔﺟﺎﻨﻔﻟا نﻮﺤﺻ
٣
باﻮﻛأ
۴
ةﺮﻴﻐﺻ ةﺪﺋﺎﻣ قﺎﺒﻃأ
۵
ﺔﻄﺳﻮﺘﻣ ةﺪﺋﺎﻣ قﺎﺒﻃأ
۶
ةﺮﻴﺒﻛ ةﺪﺋﺎﻣ قﺎﺒﻃأ
٧
ﲔﻛﺎﻜﺴﻟا
٨
تﺎﻛﻮﺸﻟا
٩
ءﺎﺴﳊا ﻖﻋﻼﻣ
DW5500M_DD81-02437K-00_AR.indd 23DW5500M_DD81-02437K-00_AR.indd 23 2019-03-18 11:14:422019-03-18 11:14:42
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ _٢٤
ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻂﺒﺿ
.ﺔﻳﻮﻠﻌﻟا/ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻲﻓ ﺎﻬﻌﺿﻮﻟ ةﺮﻴﺒﻜﻟا ىﺮﺧﻷا تاودﻸﻟ ﺔﻴﻓﺎﺿإ ﺔﺣﺎﺴﻣ ﺮﻴﻓﻮﺗ ﻞﺟأ ﻦﻣ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا عﺎﻔﺗرا ﻂﺒﺿ ﻦﻜﳝ
١ . "A" ﺔﻌﻓاﺮﻟا ﻰﻠﻋ ﻂﻐﺿا ،يﻮﻠﻌﻟا فﺮﻟا عﺎﻔﺗرا ﺾﻔﳋ
ﻢﻗو ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻠﻟ ﺮﺴﻳﻷاو ﻦﳝﻷا ﲔﺒﻧﺎﳉا ﻰﻠﻋ ةدﻮﺟﻮﳌا
.ﻪﺴﻔﻧ ﺖﻗﻮﻟا ﻲﻓ
ﹰ
ﻼﻴﻠﻗ ﻞﻔﺳﻷ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻊﻓﺪﺑ
٢ . ﺔﻠﺴﻟا ﺐﺤﺳ ىﻮﺳ ﻚﻴﻠﻋ ﺎﻣ ،يﻮﻠﻌﻟا فﺮﻟا عﺎﻔﺗرا ةدﺎﻳﺰﻟ
.ﺔﻌﻓار يأ ﻞﻴﻐﺸﺗ نود ﻰﻠﻋﻷ ﺔﻳﻮﻠﻌﻟا
ﻞﺒﻗ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا عﺎﻔﺗرا ﻂﺒﺿ ﻦﺴﺤﺘﺴﳌا ﻦﻣ :ﻪﻴﺒﻨﺗ
ﺪﻌﺑ ﺔﻠﺴﻟا ﻂﺒﻀﺑ ﺖﻤﻗ اذإو .ﺔﻠﺴﻟا ﻲﻓ قﺎﺒﻃﻷا ﻞﻴﻤﲢ
.قﺎﺒﻃﻷا ﺮﺴﻛ ﻲﻓ ﻚﻟذ ﺐﺒﺴﺘﻳ ﺪﻘﻓ ،قﺎﺒﻃﻷا ﻞﻴﻤﲢ
ﻲﻠﻔﺴﻟا ﻊﺿﻮﻟا ﻲﻓ ﻂﺒﻀﻠﻟيﻮﻠﻌﻟا ﻊﺿﻮﻟا ﻲﻓ ﻂﺒﻀﻠﻟ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
DW5500M_DD81-02437K-00_AR.indd 24DW5500M_DD81-02437K-00_AR.indd 24 2019-03-18 11:14:442019-03-18 11:14:44
٢٥_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ ٠٣
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ
ﻲﻓ ﺢﺿﻮﻣ ﻮﻫ ﺎﻤﻛ ،ﺔﻴﻋوﻷاو ةﺪﺋﺎﳌا قﺎﺒﻃأو تﺎﻳﻼﻘﻟاو ﻲﻬﻄﻟا ﺔﻴﻋوأ :ﻲﻠﻔﺴﻟا فﺮﻟا ﻲﻓ ﻒﻴﻈﻨﺘﻟا ﻲﻓ ﺐﻌﺻﻷا ةﺮﻴﺒﻜﻟا ﺔﻴﻧﻵا ﻊﺿو ﻦﺴﺤﺘﺴﳌا ﻦﻣ
.ﻦﳝﻷا ﺐﻧﺎﳉا ﻰﻠﻋ دﻮﺟﻮﳌا ﻞﻜﺸﻟا
ﺎﻬﻬﻴﺟﻮﺗ ﻊﻣ ةﺪﺋﺎﳌا ﺔﻴﻧآو ﻖﻳرﺎﺑﻷا ﻊﺿو ﺐﺠﻳ .ﺔﻳﻮﻠﻌﻟا هﺎﻴﳌا شﺎﺷر عرذأ نارود ﺔﻗﺎﻋإ ﺐﻨﺠﺘﻟ ﻒﻓرﻷا ﺐﻧاﻮﺟ ﻰﻠﻋ ﺔﻴﻄﻏﻷاو ةﺪﺋﺎﳌا قﺎﺒﻃأ ﻊﺿو ﻞﻀﻔﳌا ﻦﻣ
.ﺎ
ﹰ
ﻤﺋاد ﻞﻔﺳﻷ
.ﺎﻬﻴﻠﻋ هﺎﻴﳌا ﻖﻓﺪﺘﺑ حﺎﻤﺴﻠﻟ ﻞﺋﺎﻣ ﻊﺿو ﻲﻓ ﺔﻘﻴﻤﻌﻟا ﻖﻳرﺎﺑﻷا ﻊﺿو ﺐﺠﻳ
.ةﺮﻴﺒﻜﻟا تﺎﻳﻼﻘﻟاو ﻖﻳرﺎﺑﻷا ﻦﻣ ﺪﻳﺰﳌا ﻞﻴﻤﲢ ﻦﻜﳝ ﺚﻴﺤﺑ ﻞﻔﺳﻷ ﺎﻬﻴﻃ ﻦﻜﳝ تاءﻮﺘﻧ تاذ فﻮﻔﺻ ﻲﻠﻔﺴﻟا فﺮﻟا ﻢﻋﺪﻳ
١١
١٠
١٠ ١١
١٢
١٣
١١ ١١
١٠
١٠
١٢
١٣
DW60M6050
DW60M6051
(ا
ﹰ
دﺮﻓ ١٤ ﺔﻌﺳ)
DW60M6040
(ا
ﹰ
دﺮﻓ ١٣ ﺔﻌﺳ)
١٠
ىﻮﻠﳊا قﺎﺒﻃأ
١١
ةﺪﺋﺎﳌا قﺎﺒﻃأ
١٢
ءﺎﺴﳊا ﺔﻴﻋوأ
١٣
يوﺎﻀﻴﺑ ﺮﻴﺒﻛ ﻖﺒﻃ
ﻲﻓ
ﻞﺧاﺪﻟا
.هﺎﻴﳌا شﺎﺷر عرذأ نارود ﻖﻴﻌﺗ ﻻ ﺚﻴﺤﺑ فﺮﻟا ﻰﻠﻋ ةﺮﻴﺒﻜﻟا ﲔﻛﺎﻜﺴﻟاو ﺔﻄﻠﺴﻟا ﱘﺪﻘﺗ تاودأو ةﺪﺋﺎﳌا تاودأو ﺔﻠﻳﻮﻄﻟا ﺔﻴﻧﻵا ﻊﺿو ﺐﺠﻳ
ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻒﻓرأ
ﹼ
ﻲﻃ
.هﺎﻧدأ ةرﻮﺼﻟا ﻲﻓ ﺢﺿﻮﻣ ﻮﻫ ﺎﻤﻛ ﺔﻟازﻺﻟ ﻞﺑﺎﻘﻟا ءﻮﺘﻨﻟا وأ/و ﻞﻔﺳﻷ ﻒﻓرﻷا
ﹼ
ﻲﻃ ﻦﻜﳝ ،ﻞﻀﻓأ ﻮﺤﻧ ﻰﻠﻋ مﺎﻜﺣﺈﺑ تﺎﻳﻼﻘﻟاو ﻲﻬﻄﻟا ﺔﻴﻋوأ ﺖﻴﺒﺜﺘﻟ
DW60M6050
DW60M6051
DW60M6040
DW60M6050
DW60M6051
DW5500M_DD81-02437K-00_AR.indd 25DW5500M_DD81-02437K-00_AR.indd 25 2019-03-18 11:14:452019-03-18 11:14:45
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ _٢٦
(ﺔﻴﻀﻔﻟا ﻲﻧاوﻷا) ةﺪﺋﺎﳌا تاودأ ﺔﻴﻨﻴﺻ
تاودﻷا ﺔﺻﺎﺧو ،ﺔﺒﺳﺎﻨﳌا تﺎﺤﺘﻔﻟا ﻲﻓ يدﺮﻓ ﻞﻜﺸﺑ ﻖﻋﻼﳌا ﻞﻴﻤﲢ ﺐﺠﻳ :ﻞﻔﺳﻷ ﺾﺑﺎﻘﳌا ﻪﻴﺟﻮﺗ ﻊﻣ ةﺪﺋﺎﳌا تاودأ ﺔﻴﻨﻴﺻ ﻲﻓ ةﺮﻔﺴﻟا تاودأ ﻊﺿو ﺐﺠﻳ
.ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻠﻟ ﻲﻣﺎﻣﻷا ءﺰﳉﺎﺑ ﻲﻘﻓأ ﻊﺿو ﻲﻓ ﺎﻬﻌﺿو ﺐﺠﻳ ﺚﻴﺣ ﺔﻠﻳﻮﻄﻟا
DW60M6050/DW60M6051
٣
٧
۵
٢
٢
٣
٨
۶
۶
٢
٢
۴
١
١
١
ءﺎﺴﳊا ﻖﻋﻼﻣ
۵
ىﻮﻠﳊا ﻖﻋﻼﻣ
٢
تﺎﻛﻮﺸﻟا
۶
ةﺪﺋﺎﳌا ﻖﻋﻼﻣ
٣
ﲔﻛﺎﻜﺴﻟا
٧
ةﺪﺋﺎﳌا تﺎﻛﻮﺷ
۴
يﺎﺸﻟا ﻖﻋﻼﻣ
٨
ءﺎﺴﳊا ﺔﻓﺮﻐﻣ
ﺮﻳﺬﲢ
•.ﻲﻠﻔﺴﻟا ءﺰﳉا ﺮﺒﻋ ﺪﺘﲤ نأ ﺔﻌﻄﻗ يﻷ ﺢﻤﺴﺗ ﻻ
•!ﻞﻔﺳﻷ ﺎﻬﺗﺮﻔﺷ ﻪﻴﺟﻮﺗ ﻊﻣ ةدﺎﳊا تاودﻷا ﻞﻴﻤﺤﺘﺑ ﻢﻗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
DW5500M_DD81-02437K-00_AR.indd 26DW5500M_DD81-02437K-00_AR.indd 26 2019-03-18 11:14:492019-03-18 11:14:49
٢٧_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ ٠٣
DW60M6040
٨
۴
۴١
١
١
۴١
١
۴
١
۵
۵
۵
۵
۵
۵
۵
۵
٢
٢
۵۵
۵
٧
۵
۴
۴
۴
١
۴
٣
٣
١
١
١
١
١
۴
۴
۴
۴
١ءﺎﺴﳊا ﻖﻋﻼﻣ۵ىﻮﻠﳊا ﻖﻋﻼﻣ
٢تﺎﻛﻮﺸﻟا۶ةﺪﺋﺎﳌا ﻖﻋﻼﻣ
٣ﲔﻛﺎﻜﺴﻟا٧ةﺪﺋﺎﳌا تﺎﻛﻮﺷ
۴يﺎﺸﻟا ﻖﻋﻼﻣ٨ءﺎﺴﳊا ﺔﻓﺮﻐﻣ
ﺮﻳﺬﲢ
•.ﻲﻠﻔﺴﻟا ءﺰﳉا ﺮﺒﻋ ﺪﺘﲤ نأ ﺔﻌﻄﻗ يﻷ ﺢﻤﺴﺗ ﻻ
•!ﻞﻔﺳﻷ ﺎﻬﺗﺮﻔﺷ ﻪﻴﺟﻮﺗ ﻊﻣ ةدﺎﳊا تاودﻷا ﻞﻴﻤﺤﺘﺑ ﻢﻗ
DW5500M_DD81-02437K-00_AR.indd 27DW5500M_DD81-02437K-00_AR.indd 27 2019-03-18 11:14:502019-03-18 11:14:50
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ _٢٨
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺔﻴﻟﺎﺘﻟا قﺎﺒﻃﻷا/ﲔﻛﺎﻜﺴﻟا ﻞﺴﻐﻟ
ﻢﺋﻼﻣ ﺮﻴﻏةدوﺪﺤﻣ ﺔﻣءﻼﻣ
.ةراﺮﺤﻠﻟ ﺔﻣوﺎﻘﳌا ﺮﻴﻏ ﺔﻴﻜﻴﺘﺳﻼﺒﻟا تاودﻷا
.ةراﺮﺤﻠﻟ موﺎﻘﳌا ﺮﻴﻏ ءاﺮﻐﻟﺎﺑ ﺔﻘﺼﻠﳌا ءاﺰﺟﻷا تاذ ﺔﳝﺪﻘﻟا ةﺪﺋﺎﳌا تاودأ
.ﺔﻃﻮﺑﺮﳌا ءاﺰﺟﻷا تاذ قﺎﺒﻃﻷا وأ ةﺪﺋﺎﳌا تاودأ
.صﺎﺻﺮﻟﺎﺑ ﺔﳉﺎﻌﳌا ﺔﻴﻟﺎﺘﺴﻳﺮﻜﻟا باﻮﻛﻷاو ﺔﻴﺳﺎﺤﻨﻟا تاودﻷا
.أﺪﺼﻠﻟ ﺔﺿﺮﻌﳌا ﺔﻴﻧﺪﻌﳌا تاودﻷا
.ﺔﻴﺒﺸﳋا قﺎﺒﻃﻷا
.ﺔﻴﻋﺎﻨﺼﻟا فﺎﻴﻟﻷا ﻦﻣ ﺔﻋﻮﻨﺼﳌا تاودﻷا
.ةﺪﻳﺪﻋ تاﺮﳌ ﺎﻬﻠﺴﻏ ﺪﻌﺑ نﻮﻠﻟا ﺔﺘﻫﺎﺑ باﻮﻛﻷا عاﻮﻧأ
ﺾﻌﺑ ﺢﺒﺼﺗ نأ ﻦﻜﳝ
ﺔﻴﻠﻤﻋ ءﺎﻨﺛأ ﺎﻬﻧﻮﻟ ﺮﻴﻐﺘﻳ مﻮﻴﻨﻣﻮﻟﻷاو ﺔﻀﻔﻟا ﻦﻣ ﺔﻋﻮﻨﺼﳌا ءاﺰﺟﻷا
.ﻞﺴﻐﻟا
ﻞﻜﺸﺑ ﺎﻬﻠﺴﻏ ﰎ اذإ ﻲﻧاوﻷا ﻰﻠﻋ ةدﻮﺟﻮﳌا ﺔﻌﻣﻼﻟا لﺎﻜﺷﻷا ﺖﻬﺒﺗ ﺪﻗ
.رﺮﻜﺘﻣ
ﺎﻬﺘﻣءﻼﻣ ﻦﻣ ﺪﻛﺄﺘﻟا ءﺎﺟﺮﻟا ،ةﺪﻳﺪﺟ قﺎﺒﻃأ ءاﺮﺸﺑ ﺖﻤﻗ اذإ .ءﻼﻄﻟا وأ لزﺎﻌﻟا ﺶﻴﻧرﻮﻟا وأ ﻊﻤﺸﻟا وأ ﺮﺋﺎﺠﺴﻟا دﺎﻣﺮﺑ ﺔﺨﺴﺘﳌا تاودﻷا ﻞﺴﻏ لوﺎﲢ ﻻ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
ﻲﻓ ﻞﺴﻐﻠﻟ
لﻮﺼﺤﻠﻟ ﺔﻴﻤﻫأ ﻚﻟذ ﻞﺜﳝ ﺚﻴﺣ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺎﻬﻠﺴﻐﻟ ﺔﻤﺋﻼﻣ ﺮﻴﻏ قﺎﺒﻃأ يأ مﺪﺨﺘﺴﺗ ﻻ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﺪﺋاﺰﻟا ﻞﻴﻤﺤﺘﻟا ﺐﻨﲡ ءﺎﺟﺮﻟا
.لﻮﻘﻌﻣ ﻞﻜﺸﺑ ﺔﻗﺎﻄﻟا كﻼﻬﺘﺳﻻو ةﺪﻴﺟ ﺞﺋﺎﺘﻧ ﻰﻠﻋ
ﲔﻛﺎﻜﺴﻟاو قﺎﺒﻃﻷا ﻞﻴﻤﲢ ﺪﻨﻋ
.هﺎﻴﳌا شﺎﺷر عرذأ نارود ﲔﻛﺎﻜﺴﻟاو قﺎﺒﻃﻷا قﻮﻌﺗ نأ ﺐﺠﻳ ﻻ
وأ ﺎﻬﻠﺧاﺪﺑ هﺎﻴﳌا ﻊﻤﲡ رﺬﻌﺘﻳ ﺚﻴﺤﺑ ﻞﻔﺳﻷ ﺎﻬﺘﺤﺘﻓ ﻪﻴﺟﻮﺗ ﻊﻣ ﺎﻫﺮﻴﻏو تﺎﻳﻼﻘﻟاو باﻮﻛﻷاو ﲔﺟﺎﻨﻔﻟا ﻞﺜﻣ ﺔﻓ
ﹼ
ﻮا ﺮﺻﺎﻨﻌﻟا ﻞﻴﻤﺤﺘﺑ ﻢﻗ
.ﺔﻘﻴﻤﻌﻟا ﺎﻬﺗﺪﻋﺎﻗ ﻞﺧاﺪﺑ
ﺮﺧﻵﺎﺑ ﺎﻫﺪﺣأ ﺔﻴﻄﻐﺗ وأ ﺾﻌﺑ ﻞﺧاد ﺎﻬﻀﻌﺑ ةﺪﺋﺎﳌا تاودأو قﺎﺒﻃﻷا ﻊﺿو ﻢﺘﻳ ﻻأ ﺐﺠﻳ
•.ﺎﻬﻔﻠﺗ ﺐﻨﺠﺘﻟ ﺎﻬﻀﻌﺒﻟ باﻮﻛﻷا ﺔﺴﻣﻼﻣ ﺐﺠﻳ ﻻ
•.ﻲﻠﻔﺴﻟا فﺮﻟا ﻲﻓ ﺎﻬﻔﻴﻈﻨﺗ ﻲﻓ ﺮﺜﻛأ ﺔﺑﻮﻌﺻ ﻞﺜﲤ ﻲﻫ ﻲﺘﻟا ةﺮﻴﺒﻜﻟا ﺔﻴﻧﻵا ﻞﻴﻤﺤﺘﺑ ﻢﻗ
•.ةﻮﻬﻘﻟاو يﺎﺸﻟا ﲔﺟﺎﻨﻓو باﻮﻛﻷا ﻞﺜﻣ ﺔﺸﻬﻟاو ﺔﻔﻴﻔﳋا ةﺪﺋﺎﳌا قﺎﺒﻃأ ﻞﻴﻤﺤﺘﻟ يﻮﻠﻌﻟا فﺮﻟا ﻢﻴﻤﺼﺗ ﰎ
هﺎﺒﺘﻧا
!
ﹰ
ﻼﻤﺘﺤﻣ ا
ﹰ
ﺮﻄﺧ يدﻮﻤﻋ ﻊﺿو ﻲﻓ ﺔﻧ
ﹼ
ﺰا ﺔﻠﻳﻮﻄﻟا تاﺮﻔﺸﻟا تاذ ﲔﻛﺎﻜﺴﻟا ﻞﺜﲤ
.ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟﺎﺑ ﻲﻘﻓأ ﻊﺿو ﻲﻓ ﺔﺗﻮﺤﻨﳌا ﲔﻛﺎﻜﺴﻟا ﻞﺜﻣ ةدﺎﳊا وأ/و ﺔﻠﻳﻮﻄﻟا ةﺪﺋﺎﳌا تاودأ ﻦﻳﺰﺨﺗ ﺐﺠﻳ
ىﺮﺧﻷا قﺎﺒﻃﻷاو ةﺪﺋﺎﳌا باﻮﻛأ ﻒﻠﺗ
ﺔﻠﻤﺘﶈا بﺎﺒﺳﻷاحﺮﺘﻘﳌا ﻞﳊا
ﻲﺋﺎﻴﻤﻴﻜﻟا ﺐﻴﻛﺮﺘﻟا .ﻊﻴﻨﺼﺘﻟا ﺔﻘﻳﺮﻃ وأ باﻮﻛﻷا عﻮﻧ •
.ﻒ
ﹼ
ﻈﻨﻤﻠﻟ
.ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ةﺪﻣو هﺎﻴﳌا ةراﺮﺣ ﺔﺟرد •
ﺔﻣﻼﻋ ﻞﻤﲢ ﻲﺘﻟا ﺔﻴﻨﻴﺼﻟا قﺎﺒﻃﻷاو ةﺪﺋﺎﳌا باﻮﻛأ مﺪﺨﺘﺳا •
.ﻊﻴﻨﺼﺘﻟا ﺔﻛﺮﺷ ﻞ
ﹶ
ﺒ
ﹺ
ﻗ ﻦﻣ "قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ موﺎﻘﻣ"
قﺎﺒﻃﻷا ﻦﻣ عﻮﻨﻟا اﺬﻬﻟ ﺎ
ﹰ
ﺼﺼﺨﻣ ﺎ
ﹰ
ﻔﻴﻔﺧ ﺎ
ﹰ
ﻔ
ﹼ
ﻈﻨﻣ مﺪﺨﺘﺳا •
ﻦﻣ
ﻒ
ﹼ
ﻈﻨﳌا لﻮﺣ تﺎﻣﻮﻠﻌﳌا ﻦﻣ ﺪﻳﺰﳌا ﺐﻠﻃاو ،ﺮﻣﻷا مﺰﻟ اذإ
.ﻊﻴﻨﺼﺘﻟا ﺔﻛﺮﺷ
.ﺔﻀﻔﺨﻨﻣ ةراﺮﺣ ﺔﺟرﺪﺑ ﻞﺴﻏ ﺞﻣﺎﻧﺮﺑ مﺪﺨﺘﺳا •
ﺔﻟﺎﺴﻏ ﻦﻣ ﲔﻛﺎﻜﺴﻟاو باﻮﻛﻷا جﺮﺧأ ،ﻒﻠﺘﻟا تﻻﺎﺣ ﺐﻨﺠﺘﻟ •
.نﺎﻜﻣﻹا رﺪﻗ ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ءﺎﻬﺘﻧا دﺮﺠﲟ قﺎﺒﻃﻷا
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ
DW5500M_DD81-02437K-00_AR.indd 28DW5500M_DD81-02437K-00_AR.indd 28 2019-03-18 11:14:502019-03-18 11:14:50
٢٩_ ﻞﺴﻐﻟا ﺞﻣاﺮﺑ
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ ٠٤
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ
زﺎﻬﳉا ﻞﻴﻐﺸﺗ
ﻞﺴﻐﻟا ةرود ﻞﻴﻐﺸﺗ ءﺪﺑ
١ ..ىﺮﺧأ ةﺮﻣ ﻞﺧاﺪﻠﻟ ﺎﻤﻬﻌﻓداو قﺎﺒﻃﻷا ﻞ
ﹼ
ﻤﺣ ﻢﺛ جرﺎﺨﻠﻟ ﺔﻴﻠﻔﺴﻟاو ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﺐﺤﺴﺑ ﻢﻗ
.("قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻓرأ ﻞﻴﻤﲢ" ناﻮﻨﻌﺑ ﻢﺴﻘﻟا ﻊﺟار) ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ ﻢﺛ ،
ﹰ
ﻻوأ ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻞﻴﻤﲢ ﻦﺴﺤﺘﺴﳌا ﻦﻣ
٢ ..("هﺎﻴﳌا ﻲﻘﻨﻣو ﻒ
ﹼ
ﻈﻨﳌا ماﺪﺨﺘﺳا" ناﻮﻨﻌﺑ ﻢﺴﻘﻟا ﻊﺟار) ﻒ
ﹼ
ﻈﻨﳌا ﻒﺿأ
٣ . ﻞﻴﻐﺸﺗ ﻦﻣ ﺪﻛﺄﺗ .ددﺮﺘﻣ رﺎﻴﺗ ﺖﻟﻮﻓ ٢٥٠و ﺮﻴﺒﻣأ ١٠ ﻲﻫ ﺲﺒﻘﳌا تﺎﻔﺻاﻮﻣ ،ﺰﺗﺮﻫ ٥٠ ،ﺖﻟﻮﻓ ٢٤٠-٢٢٠ ﺔﻗﺎﻄﻟا درﻮﻣ .ﺲﺒﻘﳌا ﻞﺧاد ﺲﺑﺎﻘﻟا جاردﺈﺑ ﻢﻗ
.ﺐﺳﺎﻨﻣ ﻂﻐﻀﺑ هﺎﻴﳌا د
ﹼ
رﻮﻣ
۴ ..زﺎﻬﳉا ﻞﻴﻐﺸﺘﻟ (ﻞﻴﻐﺸﺗ) POWER رﺰﻟا ﻰﻠﻋ ﻂﻐﺿاو ،بﺎﺒﻟا ﻖﻠﻏأ
. (ﻞﻴﻐﺸﺗ) POWER رﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟا لﻼﺧ ﻦﻣ حﺎﺘﻔﳌا ءﺎﻔﻃإ ﻚﻨﻜﳝ ،ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ
ءﺎﻬﺘﻧا ﺪﻨﻋ .ﺎ
ﹰ
ﻣﺎﲤ بﺎﺒﻟا قﻼﻏإ ﺪﻨﻋ ةﺮﻘﻧ تﻮﺻ عﺎﻤﺳ ﺐﺠﻳ
ﺞﻣﺎﻧﺮﺒﻟا ﺮﻴﻴﻐﺗ
:ﺔﻣﺪﻘﻣ
١ . مﺎﻗ ﺪﻗ زﺎﻬﳉا نﻮﻜﻳو ،ﻞﻌﻔﻟﺎﺑ ﻒ
ﹼ
ﻈﻨﳌا ﻊﻳزﻮﺗ ﰎ ﺪﻗ نﻮﻜﻳ ﺪﻘﻓ ،ﻻإو .ةﺮﻴﺼﻗ ةﺮﺘﻔﻟ ﺎﻬﻠﻴﻐﺸﺗ ﰎ ﺪﻗ نﺎﻛ اذإ ﻻإ ﻞﻴﻐﺸﺘﻟا ﺪﻴﻗ ﻲﺘﻟا ةروﺪﻟا ﻞﻳﺪﻌﺗ ﻦﻜﳝ ﻻ
.("ﻒ
ﹼ
ﻈﻨﳌا ع
ﹼ
زﻮﻣ ﺔﺌﺒﻌﺗ" ناﻮﻨﻌﺑ ﻢﺴﻘﻟا ﻊﺟار) ﺪﻳﺪﺟ ﻦﻣ ﻒ
ﹼ
ﻈﻨﳌا عزﻮﻣ ﺔﺌﺒﻌﺗ ةدﺎﻋإ ﺐﺠﻴﻓ ،ﻚﻟﺬﻛ ﺮﻣﻷا نﺎﻛ اذإ .
ﻞﺴﻐﻟا هﺎﻴﻣ ﻒﻳﺮﺼﺘﺑ
٢ . ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ﺮﻴﻴﻐﺗ ﻚﻨﻜﳝ ﺎﻫﺪﻌﺑو ،ا
ﹰ
دﺪﺠﻣ ﻪﻠﻴﻐﺸﺘﺑ ﻢﻗ ﻢﺛ ،ﺞﻣﺎﻧﺮﺒﻟا ءﺎﻐﻟﻹ
ﹴ
ناﻮﺛ ٣ ةﺪﳌ ﻂﺒﺿ ةدﺎﻋإ رﺰﻟا وأ (ﻞﻴﻐﺸﺗ) POWER رﺰﻟا ﻰﻠﻋ ﻂﻐﺿا
.ﺎﻫﺪﻳﺮﺗ ﻲﺘﻟا ﻞﺴﻐﻟا ةرود ﺪﻳﺪﲢو
ﻢﺘﻳ ﻰﺘﺣ ﺔﻘﻴﻗد ﻞﻛ ﺎ
ﹰ
ﻨﻴﻧر سﺮﳉا رﺪﺼﻳو ﺾﻴﻣﻮﻟا ﻦﻋ ﻞﺴﻐﻟا ﺞﻣﺎﻧﺮﺑ ﺮﺷﺆﻣ ﻒﻗﻮﺘﻳ .ﻞﺴﻐﻟا ةرود ﻞﻴﻐﺸﺗ ءﺎﻨﺛأ بﺎﺒﻟا ﺢﺘﻓ ﰎ اذإ ﺎ
ﹰ
ﺘﻗﺆﻣ زﺎﻬﳉا ﻒﻗﻮﺘﻳ
.ﺎ
ﹰ
ﻴﺋﺎﻘﻠﺗ ناﻮﺛ ثﻼﺛ روﺮﻣ ﺪﻌﺑ ﻞﻴﻐﺸﺘﻟا زﺎﻬﳉا ﻞﺻاﻮﻳ ،بﺎﺒﻟا قﻼﻏإ ﺪﻌﺑو .بﺎﺒﻟا قﻼﻏإ
.ﺔﻗﺎﻄﻟا عﺎﻄﻘﻧا ﺪﻌﺑ دﺪﶈا ﺞﻣﺎﻧﺮﺒﻟا ءﺎﻬﻧﻹ زﺎﻬﳉا ﺮﻤﺘﺴﻳ ،ﻚﺑ صﺎﳋا زاﺮﻄﻟﺎﺑ ﺔﻠﻄﻌﻣ ةﺮﻛاﺬﻟا ﺔﻔﻴﻇو ﺖﻧﺎﻛ اذإ
قﺎﺒﻃﻷا ﺔﻓﺎﺿإ
.ﻒ
ﹼ
ﻈﻨﳌا ع
ﹼ
زﻮﻣ ﺢﺘﻓ ﻢﺘﻳ نأ ﻞﺒﻗ ﺖﻗو يأ ﻲﻓ ﻪﻧﺎﻴﺴﻧ ﰎ ﻖﺒﻃ يأ ﺔﻓﺎﺿإ ﻦﻜﳝ
١ ..ﻞﺴﻐﻟا فﺎﻘﻳﻹ
ﹰ
ﻼﻴﻠﻗ بﺎﺒﻟا ﺢﺘﻓا
٢ ..ﻞﻣﺎﻜﻟﺎﺑ بﺎﺒﻟا ﺢﺘﻓ ﻚﻨﻜﳝ ،ﻞﻤﻌﻟا ﻦﻋ هﺎﻴﳌا شﺎﺷر عرذأ ﻒﻗﻮﺗ ﺪﻌﺑ
٣ ..ﺔ
ﹼ
ﻴﺴﻨﳌا قﺎﺒﻃﻷا ﻒﺿأ
۴ ..
ﹴ
ناﻮﺛ ١٠ ﺪﻌﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻤﻌﺘﺳو ،بﺎﺒﻟا ﻖ
ﹺ
ﻠﻏأ
ءﺎﻨﺛأ بﺎﺒﻟا ﺢﺘﻓ ﰎ اذإ .ﺔﻨﺧﺎﺴﻟا هﺎﻴﳌا ﺐﺒﺴﺑ قوﺮﳊﺎﺑ ﺔﺑﺎﺻﻹا لﺎﻤﺘﺣﻻ ا
ﹰ
ﺮﻈﻧ ةرﻮﻄﺧ ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ءﺎﻨﺛأ بﺎﺒﻟا ﺢﺘﻓ ﻞﺜﳝ :ﺮﻳﺬﲢ
.ﻞﺴﻐﻟا ةرود ﻒﻗﻮﺘﺗو نﺎﻣأ ﺔﻴﻟآ ﻂﻴﺸﻨﺗ ﻢﺘﻳ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ
DW5500M_DD81-02437K-00_AR.indd 29DW5500M_DD81-02437K-00_AR.indd 29 2019-03-18 11:14:502019-03-18 11:14:50
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ _٣٠
ﻞﺴﻐﻟا ةرود ءﺎﻬﺘﻧا ﺪﻨﻋ
ﺞﻣﺎﻧﺮﺑ نﻮﻜﻳ ﻂﻘﻓ ﺔﻟﺎﳊا هﺬﻫ ﻲﻓو ،ﺔﻴﻤﻗﺮﻟا ﺔﺷﺎﺸﻟا ﻰﻠﻋ "0" ﺮﻬﻈﻳ .ﻒﻗﻮﺘﻳ ﻢﺛ ﺮﻴﺼﻗ ﻪﻴﺒﻨﺗ تﻮﺻ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ سﺮﺟ رﺪﺼﻳ ،ﻞﺴﻐﻟا ةرود ءﺎﻬﺘﻧا ﺪﻨﻋ
.ﻰﻬﺘﻧا ﺪﻗ ﻞﺴﻐﻟا
١ . (ﻞﻴﻐﺸﺗ) POWER رﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟا لﻼﺧ ﻦﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻖ
ﹺ
ﻠﻏأ
٢ .!هﺎﻴﳌا رﻮﺒﻨﺻ ﻖﻠﻏأ
!بﺎﺒﻟا ﺢﺘﻓ ﺪﻨﻋ ﻦﺧﺎﺳ رﺎﺨﺑ جﺮﺨﻳ ﺪﻗ .
ﺔﻳﺎﻨﻌﺑ بﺎﺒﻟا ﺢﺘﻓا
•.زﺎﻬﳉا ﻦﻣ ﺎﻬﺟاﺮﺧإ ﻞﺒﻗ ﺔﻘﻴﻗد ١٥ ةﺪﳌ دﺮﺒﺘﻟ قﺎﺒﻃﻷا كﺮﺗ ﺐﺠﻳ اﺬﻟ .تﺎﻣﺪﺼﻟا ﺪﺿ ﺔﺳﺎﺴﺣ نﻮﻜﺗ ﺔﻨﺧﺎﺴﻟا قﺎﺒﻃﻷا
•.ﺎﻬﻔﻴﻔﲡ ﺔﻴﻠﻤﻋ ﲔﺴﲢو قﺎﺒﻃﻷا ةدوﺮﺑ ﻰﻠﻋ ﻚﻟذ ﻞﻤﻌﻳو .قﺎﺒﻃﻷا جاﺮﺧإ ﻞﺒﻗ ﺔﻠﻴﻠﻗ ﻖﺋﺎﻗد ﺮﻈﺘﻧاو ﺎ
ﹰ
ﺣﻮﺘﻔﻣ ﻪﻛﺮﺗاو ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ بﺎﺑ ﺢﺘﻓا
•.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ غاﺮﻓﺈﺑ ﻢﻗ
.ﻞﺧاﺪﻟا ﻦﻣ ﺔﻠﻠﺒﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ نﻮﻜﺗ نأ ﻲﻌﻴﺒﻄﻟا ﻦﻣ
ﺔﻠﺴﻟﺎﺑ ةدﻮﺟﻮﳌا قﺎﺒﻃﻷا ﻰﻠﻋ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻦﻣ هﺎﻴﳌا ﺮﻴﻄﻘﺗ ﺐﻨﲡ ﻰﻠﻋ ﻚﻟذ ﻞﻤﻌﻳ ﺚﻴﺣ .ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻢﺛ
ﹰ
ﻻوأ ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا غاﺮﻓﺈﺑ ﻢﻗ
.ﺔﻴﻠﻔﺴﻟا
ﻞﺴﻐﻟا ةرود لوﺪﺟ
DW60M6050/DW60M6051/DW60M6040
ﺞﻣﺎﻧﺮﺒﻟاةروﺪﻟا ﻒﺻو
ﻒ
ﹼ
ﻈﻨﳌا
(ماﺮﳉﺎﺑ) ﻲﺴﻴﺋر ﻞﺴﻏ/ﻲﻟوأ ﻞﺴﻏ
ﻞﻴﻐﺸﺘﻟا ﺖﻗو
(ﻖﺋﺎﻗﺪﻟﺎﺑ)
(ﺮﺘﻠﻟﺎﺑ) هﺎﻴﳌا ﺔﻴﻤﻛ
ﻒﺜﻜﻣ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻲﻟوأ ﻞﺴﻏ
٥/٣٠١٧٥١٧٫٥
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻞﺴﻏ
ﻒﻄﺷ
ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٧٠) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ + ﻒﺜﻜﻣ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻲﻟوأ ﻞﺴﻏ
٥/٣٠٢٠٠١٧٫٥
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻞﺴﻏ
ﻒﻄﺷ
ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٧٠)
ﻒﻄﺷ
ﻒﻴﻔﲡ
*يدﺎﺼﺘﻗا
ﻲﻟوأ ﻞﺴﻏ
٥/٣٠٢٢٥١٠٫٥
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻞﺴﻏ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٥) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ + يدﺎﺼﺘﻗا
ﻲﻟوأ ﻞﺴﻏ
٥/٣٠٢٣٥١٠٫٥
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻞﺴﻏ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﻖﻴﻗر
ﻲﻟوأ ﻞﺴﻏ
٥/٣٠١٣٠١٣
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٤٠) ﻞﺴﻏ
ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ
DW5500M_DD81-02437K-00_AR.indd 30DW5500M_DD81-02437K-00_AR.indd 30 2019-03-18 11:14:512019-03-18 11:14:51
٣١_ ﻞﺴﻐﻟا ﺞﻣاﺮﺑ
ﻞﺴﻐﻟا ﺞﻣاﺮﺑ ٠٤
ﺞﻣﺎﻧﺮﺒﻟاةروﺪﻟا ﻒﺻو
ﻒ
ﹼ
ﻈﻨﳌا
(ماﺮﳉﺎﺑ) ﻲﺴﻴﺋر ﻞﺴﻏ/ﻲﻟوأ ﻞﺴﻏ
ﻞﻴﻐﺸﺘﻟا ﺖﻗو
(ﻖﺋﺎﻗﺪﻟﺎﺑ)
(ﺮﺘﻠﻟﺎﺑ) هﺎﻴﳌا ﺔﻴﻤﻛ
ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ + ﻖﻴﻗر
ﻲﻟوأ ﻞﺴﻏ
٥/٣٠١٤٠١٣
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٤٠) ﻞﺴﻏ
ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٥) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﺔﻋﺮﺴﻟا ﻖﺋﺎﻓ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻲﻟوأ ﻞﺴﻏ
٥/٣٠٦٠١٠
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻞﺴﻏ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﺔﻴﺤﺻ ﺔﻓﺎﻈﻧ +
ﺔﻋﺮﺴﻟا ﻖﺋﺎﻓ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻲﻟوأ ﻞﺴﻏ
٥/٣٠٨٠١٠
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠) ﻞﺴﻏ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٥) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﻲﻟوأ ﻞﺴﻏ
(DW60M6050**/DW60M6051**)
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٤٥) ﻞﺴﻏ
٢٥٣٠١١ (ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٠) ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٥) ﻒﻄﺷ
ﻲﺋﺎﻘﻠﺗ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٤٥) ﻲﻟوأ ﻞﺴﻏ
٥/٣٠١٥٠١٥-١١
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٥٥-٤٥) ﻲﺋﺎﻘﻠﺗ
ﻒﻄﺷ
(ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٥) ﻒﻄﺷ
ﻒﻴﻔﲡ
ﻲﻟوأ ﻞﺴﻏﻲﻟوأ ﻞﺴﻏ/١٥٤
.IEC 60436 ﻊﻣ ﺔﻘﺑﺎﻄﺘﻣ ﻖﻓاﻮﺘﻟا رﺎﺒﺘﺧا تﺎﻣﻮﻠﻌﻣو .رﺎﺒﺘﺧﻼﻟ ﺎ
ﹰ
ﺠﻣﺎﻧﺮﺑ اﺬﻫ ﺪﻌ
ﹸ
ﻳ :IEC 60436 *
.ﺎﻬﺗراﺮﺣ ﺔﺟردو ﺎﻫﺪﻳرﻮﺗ ﻢﺘﻳ ﻲﺘﻟا هﺎﻴﳌا ﻂﻐﻀﻟ ﺎ
ﹰ
ﻘﻓو ﻞﺴﻐﻟا ﺖﻗو ﻒﻠﺘﺨﻳ
.ءﺎﳌا ﻲﻘﻨﻣ ةءﺎﻔﻛ ﻞﻴﻠﻘﺗ ﻲﻓ ﻚﻟذ ﺐﺒﺴﺘﻳ ﺪﻗ ﺚﻴﺣ ،ﺔﻠﻳﻮﻃ ةﺮﺘﻔﻟ ﻲﻟوأ ﻞﺴﻏ ةروﺪﻟ ﻞﺻاﻮﺘﳌا ماﺪﺨﺘﺳﻻﺎﺑ ﻰﺻﻮﻳ ﻻ :ﻲﻟوأ ﻞﺴﻏ
DW5500M_DD81-02437K-00_AR.indd 31DW5500M_DD81-02437K-00_AR.indd 31 2019-03-18 11:14:512019-03-18 11:14:51
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا _٣٢
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا
تﺎﺤﺷﺮﳌا ﻒﻴﻈﻨﺗ
ﺢﻴﺷﺮﺘﻟا مﺎﻈﻧ
تﺎﻧﻮﻜﻣ ﺔﺛﻼﺛ ﺪﺟﻮﻳ ﺚﻴﺣ ،ضﻮﳊا ﻞﺧاد ﻪﻴﻟإ لﻮﺻﻮﻟا ﻞﻬﺴﻳ نﺎﻜﻣ ﻲﻓ ﺢﻴﺷﺮﺘﻟا مﺎﻈﻧو ﻒﻳﺮﺼﺘﻟا ﺔﺨﻀﻣ ﻊﺿﻮﺑ ﺎﻨﻤﻗ ،ﻚﺘﺣار ﻞﺟأ ﻦﻣ
.بﻮﻘﺜﻟا ﻖﻴﺿ ﺢﺷﺮﳌاو بﻮﻘﺜﻟا ﻊﺳاو ﺢﺷﺮﳌاو ﻲﺴﻴﺋﺮﻟا ﺢﺷﺮﳌا :ﺢﻴﺷﺮﺘﻟا مﺎﻈﻨﻟ
١ . كﺮﺤﻣ لﻼﺧ ﻦﻣ ﺢﺷﺮﳌا ﺪﻨﻋ ﻊﻤﺠﺘﺗ ﻲﺘﻟا ﺔﺑﺮﺗﻷاو ﺔﻤﻌﻃﻷا تﺎﺌﻳﺰﺟ ﻦﺤﻃ ﻢﺘﻳ :ﻲﺴﻴﺋﺮﻟا ﺢﺷﺮﳌا
.فﺮﺼﳌا ﻰﻟإ ﺎﻬﻌﻓد ﻢﺛ ،ﻲﻠﻔ
ﹸ
ﺴﻟا شﺮﻟا عارذ ﺪﻨﻋ صﺎﺧ
٢ . مﺎﻈﻌﻟا ﻊﻄﻗ ﻞﺜﻣ ،ﺎ
ﹰ
ﻤﺠﺣ ﺮﺒﻛﻷا تﻼﻀﻔﻟا ﺔﻴﻘﻨﺗ ﻰﻠﻋ ﺢﺷﺮﳌا اﺬﻫ ﻞﻤﻌﻳ :بﻮﻘﺜﻟا ﻊﺳاو ﺢﺷﺮﳌا
،ﺢﺷﺮﳌا اﺬﻫ ﻲﻓ ﺎﻫزﺎﺠﺘﺣا ﰎ ﻲﺘﻟا ﻖﻟاﻮﻌﻟا ﺔﻟازﻹو .فﺮﺼﳌا داﺪﺴﻧإ ﻰﻟإ يدﺆﺗ ﺪﻗ ﻲﺘﻟا ،جﺎﺟﺰﻟا وأ
.ﻰﻠﻋﻷ ﻪﻌﻓراو ﺢﺷﺮﳌا ﻰﻠﻋأ ﺾﺑﺎﻘﳌا ﻰﻠﻋ ﻖﻓﺮﺑ ﻂﻐﺿا
٣ . ﺔﻘﻄﻨﻣ ﻲﻓ ﺔﺑﺮﺗﻷاو ﺔﻤﻌﻃﻷا ﺎﻳﺎﻘﺑ زﺎﺠﺘﺣا ﻰﻠﻋ ﺢﺷﺮﳌا اﺬﻫ ﻞﻤﻌﻳ :بﻮﻘﺜﻟا ﻖﻴﺿ ﺢﺷﺮﳌا
.ﻞﺴﻐﻟا ةرود ءﺎﻨﺛأ قﺎﺒﻃﻷا ﻰﻠﻋ ﻢﻛاﺮﺘﻟا ةدﺎﻋإ ﻦﻣ ﺎﻬﻌﻨﻣو ﺔﻋﻮﻟﺎﺒﻟا
٢
١
٣
.ﺐﻘﻋ ﻰﻠﻋ ﺎ
ﹰ
ﺳأر ﺎ
ﹰ
ﺑﻮﻠﻘﻣ بﻮﻘﺜﻟا ﻖﻴﺿ ﺢﺷﺮﳌا ﻊﻀﺗ ﻻ :هﺎﺒﺘﻧا
ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ
هﺎﻴﻣ ﻦﻣ ﺔﻴﻟﺎﻋ ةءﺎﻔﻜﺑ ﺔﻤﻌﻃﻷا ﺎﻳﺎﻘﺑ ﺔﻟازإ ﻰﻠﻋ ﺢﺷﺮﳌا ﻞﻤﻌﻳ ﺚﻴﺣ ،ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ ﻒﻴﻈﻨﺗ ﺐﺠﻳ ،ﻞﻀﻓأ ﺞﺋﺎﺘﻧو ءادأ ﻰﻠﻋ لﻮﺼﺤﻠﻟ
ﻦﻋ ةرود ﻞﻛ ﺪﻌﺑ ﺢﺷﺮﳌا ﻲﻓ ﺔﻘﻟﺎﻌﻟا ﺔﻤﻌﻃﻷا ﺎﻳﺎﻘﺑ ﺔﻟازإ ﻞﻀﻓﻷا ﻦﻣ ﻪﻧﺈﻓ ،ﺐﺒﺴﻟا اﺬﻬﻟو .ةروﺪﻟا ءﺎﻨﺛأ ﺎﻫﺮﻳوﺪﺗ ةدﺎﻋﺈﺑ ﺢﻤﺴﻳ ﺎﳑ ،ﻞﺴﻐﻟا
ﺔﻋﻮﻤﺠﻣ ﻊﻓرأو ﺔﻋﺎﺴﻟا برﺎﻘﻋ هﺎﲡا ﺲﻜﻋ هردأ ،ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ ﻚﻔﻟ .ﺔﻳرﺎﳉا هﺎﻴﳌا ﺖﲢ سﺄﻜﻟاو يﺮﺋاد ﻒﺼﻨﻟا ﺢﺷﺮﳌا ﻒﻄﺷ ﻖﻳﺮﻃ
.مﺎﻈﺘﻧﺎﺑ ﻞﻣﺎﻜﻟﺎﺑ ﺢﺷﺮﳌا ﺔﻋﻮﻤﺠﻣ ﻒﻴﻈﻨﺗ ﺐﺠﻳ .ﻰﻠﻋﻷا ﻰﻟإ ﺢﺷﺮﳌا
نﺎﻜﳌا ﻲﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺎﻬﻠﻣﺎﻜﺑ ﺔﻋﻮﻤا ﺐﻴﻛﺮﺗ ﺪﻋأ ﻢﺛ .ﻒﻴﻈﻨﺗ ةﺎﺷﺮﻓ مﺪﺨﺘﺳا ،ﻦﺸﳋا ﺢﺷﺮﳌاو ﻖﻴﻗﺪﻟا ﺢﺷﺮﳌا ﻒﻴﻈﻨﺘﻟ
.ﺔﻋﺎﺴﻟا برﺎﻘﻋ هﺎﲡا ﻲﻓ ﺎﻬﺗرادإو ﻞﻔﺳأ ﻰﻟإ ﻂﻐﻀﻟﺎﺑ ﻚﻟذو ،ﺎﻬﻟ ﺺﺼا
ﺢﺘﻓ
ﺢﺘﻓ
زﺎﻬﳉا ءادأ ىﻮﺘﺴﻣ ﺾﻔﺧ ﻰﻟإ ءﻰﻃﺎﺧ
ﹴ
ﻞﻜﺸﺑ تﺎﺤﺷﺮﳌا لاﺪﺒﺘﺳا يدﺆﻳ ﺪﻗ .تﺎﺤﺷﺮﳌا نود ﺎ
ﹰ
ﻴﻌﻄﻗ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا ﺮﻈﺤﻳ
.ىﺮﺧﻷا ﺔﻴﻋوﻷاو قﺎﺒﻃﻷا ﺮﻴﺴﻜﺗو
،ﻻإو .ﻒﻴﻈﻨﺘﻟا ﺪﻨﻋ تﺎﺤﺷﺮﳌﺎﺑ ﻒﻠﺗ ىأ ث
ﹺ
ﺪ
ﹸ
ﲢ ﻻو .ﺎﻬﻧﺎﻜﻣ ﻲﻓ تﺎﺤﺷﺮﳌا دﻮﺟو نود ﺎ
ﹰ
ﻘﻠﻄﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻐﺸﺗ ﺮﻈﺤﻳ :ﺮﻳﺬﲢ
.ﺔﻴﻠﺧاﺪﻟا ءاﺰﺟﻸﻟ ﻒﻠﺗ ثﺪﺤﻳ ﺪﻗ
وأ ﺎ
ﹰ
ﺌﻳدر ءادﻷا ىﻮﺘﺴﻣ نﻮﻜﻴﺳو ﻲﻐﺒﻨﻳ ﺎﻤﻛ تﺎﺤﺷﺮﳌا ﻞﻤﻌﺗ ﻦﻠﻓ
DW5500M_DD81-02437K-00_AR.indd 32DW5500M_DD81-02437K-00_AR.indd 32 2019-03-18 11:14:512019-03-18 11:14:51
٣٣_ ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا ٠٥
شﺮﻟا عرذأ ﻒﻴﻈﻨﺗ
نﺎﻜﳌا ﺪﺴﺗو شﺮﻟا عرذأ تﺎﻛﺮﺤﻣ قﻮﻌﺗ ﺪﻗ ﺮ
ﹺ
ﺴ
ﹶ
ﻌﻟا ءﺎﳌا ﺎﻳﺎﻘﺑ نإ ﺚﻴﺣ مﺎﻈﺘﻧﺎﺑ شﺮﻟا عرذأ ﻒﻴﻈﻨﺗ يروﺮﻀﻟا ﻦﻣ
عارذ ﺔﻟازﻹ ﺎﻣأ .ﻪﺘﻟازﻹ ﺔﻋﺎﺴﻟا برﺎﻘﻋ هﺎﲡا ﻲﻓ عارﺬﻟا ر
ﹺ
دأو ﺔﻟﻮﻣﺎﺼﻟا ﻚﺴﻣا ،ﻂﺳوﻷا شﺮﻟا عارذ ﺔﻟازﻹو .ﻢﻬﺑ ﻂﻴﶈا
ﻒﻴﻈﻨﺘﻟ ﺔﻤﻋﺎﻧ ةﺎﺷﺮﻓ مﺪﺨﺘﺳاو نﻮﺑﺎﺼﻟاو ﺊﻓاﺪﻟا ءﺎﳌﺎﺑ عرذﻷا ﻞﺴﻏا .ﻰﻠﻋﻷا ﻰﻟإ عارﺬﻟا ﺐﺤﺳﺎﻓ ،ﻞﻔﺳﻷا شﺮﻟا
.ﻞﻣﺎﻜﻟﺎﺑ ﻢﻬﻔﻄﺷ ﺪﻌﺑ ﻢﻬﻨﻛﺎﻣأ ﻰﻟإ ﻢﻫﺪ
ﹺ
ﻋأ ﻚﻟذ ﺪﻌﺑو .تﺎﻛﺮﶈا
ﺢﺘﻓ
بﺎﺒﻟا ﻒﻴﻈﻨﺗ
.ﺔﺒﻃر ﺔﺌﻓاد شﺎﻤﻗ ﺔﻌﻄﻗ ماﺪﺨﺘﺳا ﻂﻘﻓ ﻦﻜﳝ ،بﺎﺒﻟا ﺔﻓﺎﺣ ﻒﻴﻈﻨﺘﻟ
ﻰﻟإ ﻒﺷﺎﻨﳌا ﺾﻌﺑ ماﺪﺨﺘﺳا يدﺆﻳ ﺎ
ﹰ
ﻀﻳأ ﺎﲟرو .ﺎ
ﹰ
ﺷوﺪﺧ ﺐﺒﺴﻳ ﺪﻗ اﺬﻫ نﻷ ﻲﺟرﺎﳋا ﺢﻄﺴﻟا ﻰﻠﻋ ﺔﻨﺸﺧ ﺔﻓﻮﻟ وأ ﺔﻄﺷﺎﻛ ﻒﻴﻈﻨﺗ داﻮﻣ ﺎ
ﹰ
ﻀﻳأ مﺪﺨﺘﺴﺗ ﻻ
.ﺢﻄﺴﻟا ﻰﻠﻋ ا
ﹰ
ﺮﺛأ كﺮﺘﻳ وأ شﺪﺧ ثوﺪﺣ
ةدﺎﻣ ماﺪﺨﺘﺳﺎﺑ ﺢ
ﹶ
ﺼﻨ
ﹸ
ﻳ
ﻻ ﺎﻤﻛ .ﺔﻴﺋﺎﺑﺮﻬﻜﻟا ءاﺰﺟﻷاو بﺎﺒﻟا ﻞﻔﻗ ﻒﻠﺘﻳ ﺪﻗ اﺬﻫ نﻷ بﺎﺒﻟا ﺔﺣﻮﻟ ﻒﻴﻈﻨﺗ ﺪﻨﻋ خﺎﺨﺑ ﻒﻈﻨﻣ أ
ﹰ
ﺪﺑأ مﺪﺨﺘﺴﺗ ﻻ :
ﺮﻳﺬﲢ
.ﻞﻴﺘﺳ ﺲﻠﻧﺎﺘﺴﻟا ﺢﻄﺳ ﻰﻠﻋ ﻊﻘﺑ كﺮﺗ وأ
ﹴ
شﺪﺧ ثوﺪﺣ ﺐﻨﺠﺘﻟ ﻚﻟذو ﻒﺷﺎﻨﻣ وأ ﺔﻄﺷﺎﻛ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﻳﺎﻨﻌﻟا
.ةﺰﻬﺟﻷا ﻊﻴﻤﻠﺗ ﻊﻤﺷ ﻦﻣ ﺪﻴﺟ عﻮﻧ مﺪﺨﺘﺳﺎﻓ ،ﻲﺟرﺎﳋا ءﺰﳉا ﻒﻴﻈﻨﺘﻟ ﺎﻣأ .أ
ﹰ
ﺪﻴﺟ ﺎﻬﻧﺎﻜﻣ ﻒﻔﺟ ﻢﺛ ﺔﺒﻃر ﺔﻨﻴﻟ ﺔﻗﺮﺧ مﺪﺨﺘﺳا ،ﻢﻜﺤﺘﻟا ﺔﺣﻮﻟ ﻒﻴﻈﻨﺘﻟ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ءﺰﺟ ىأ ﻰﻠﻋ ﺔﻴﺳﺎﻗ تﺎﻔﻈﻨﻣ وأ ﺔﻨﺸﺧ ﺔﻓﻮﻟ وأ ا
ﹰ
ﺪﺑأ ةدﺎﺣ تاودأ مﺪﺨﺘﺴﺗ ﻻ
ﺪﻤﺠﺘﻟا ﻦﻣ ﺔﻳﺎﻤﳊا
:ءﺎﺘﺸﻟا ﻞﺼﻓ ءﺎﻨﺛأ ﺊﻓاد ﺮﻴﻏ نﺎﻜﻣ ﻲﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺖﻛﺮﺗ اذإ
١ ..قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻋ ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻞﺼﻓا
٢ ..هﺎﻴﳌا مﺎﻤﺻ ﻦﻋ ءﺎﳌا ﺪﻳرﻮﺗ ةرﻮﺳﺎﻣ ﻞﺼﻓاو هﺎﻴﳌا درﻮﻣ ﻞﻴﻐﺸﺗ فﺎﻘﻳﺈﺑ ﻢ
ﹸ
ﻗ
٣ .(ءﺎﳌا طﺎﻘﺘﻟﻻ ءﺎﻋو مﺪﺨﺘﺳا) .هﺎﻴﳌا مﺎﻤﺻ ﻦﻣو ﺪﻳرﻮﺘﻟا ةرﻮﺳﺎﻣ ﻦﻣ هﺎﻴﳌا ف
ﱢ
ﺮ
ﹶ
ﺻ
۴ ..هﺎﻴﳌا مﺎﻤﺼﺑ
هﺎﻴﳌا ﺪﻳرﻮﺗ ةرﻮﺳﺎﻣ ﻞ
ﹺ
ﺻوأ
۵ . .هﺎﻴﳌا صﺎﺼﺘﻣﻻ ﺔﺠﻨﻔﺳإ مﺪﺨﺘﺳاو ﻞﻔﺳﻷﺎﺑ ضﻮﳊا ﻦﻣ ﺢﺷﺮﳌا ل
ﹺ
زأ
DW5500M_DD81-02437K-00_AR.indd 33DW5500M_DD81-02437K-00_AR.indd 33 2019-03-18 11:14:512019-03-18 11:14:51
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا _٣٤
ﻚﺑ ﺔﺻﺎﳋا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻰﻠﻋ ﻆﻓﺎﲢ ﻒﻴﻛ
•ﺔﻠﺴﻏ ﻞﻛ ﺪﻌﺑ
.ﻞﺧاﺪﻟا ﻲﻓ ﺔﺤﺋاﺮﻟاو ﺔﺑﻮﻃﺮﻟﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻆﻔﺘﲢ ﻻ ﻰﺘﺣ
ﹰ
ﻼﻴﻠﻗ ﺎ
ﹰ
ﺣﻮﺘﻔﻣ بﺎﺒﻟا كﺮﺗاو زﺎﻬﳉا ﻰﻟإ هﺎﻴﳌا د
ﹺ
رﻮ
ﹸ
ﻣ ﻞﻴﻐﺸﺗ فﺎﻘﻳﺈﺑ ﻢ
ﹸ
ﻗ ،ﺔﻠﺴﻏ ﻞﻛ ﺪﻌﺑ
•ﺲﺑﺎﻘﻟا ﺔﻟازإ
.ﻲﺋﺎﺑﺮﻬﻜﻟا ﺲﺒﻘﳌا ﻦﻣ ﺲﻟا ﺔﻟازﺈﺑ ﺎ
ﹰ
ﹶ
ﻤﺋاد ﻢ
ﹸ
ﻗ ،ﺔﻧﺎﻴﺼﻟا ءاﺮﺟإ وأ ﻒﻴﻈﻨﺘﻟا ﻞﺒﻗ
•.ﺔﻄﺷﺎﻜﻟا وأ ﺔﺒﻳﺬﳌا ﻒﻴﻈﻨﺘﻟا داﻮﳌ ﻻ
شﺎﻤﻗ ﺔﻌﻄﻗ مﺪﺨﺘﺳا ﻂﻘﻓ .ﺔﻄﺷﺎﻜﻟا وأ ﺔﺒﻳﺬﳌا ﻒﻴﻈﻨﺘﻟا تﺎﺠﺘﻨﻣ مﺪﺨﺘﺴﺗ ﻻ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﺔﻴﻃﺎﻄﳌا ءاﺰﺟﻷاو ﻲﺟرﺎﳋا ءﺰﳉا ﻒﻴﻈﻨﺘﻟ
ﺞﺘﻨﻣ وأ ،ﺾﻴﺑﻷا ﻞﳋا ﻦﻣ
ﹰ
ﻼﻴﻠﻗو ءﺎﳌﺎﺑ ﺔﻠﻠﺒﻣ شﺎﻤﻗ ﺔﻌﻄﻗ مﺪﺨﺘﺳا ،ﻲﻠﺧاﺪﻟا ﺢﻄﺴﻟا ﻰﻠﻋ ﻦﻣ تﺎﺨﻄﻠﻟا وأ ﻊﻘﺒﻟا ﺔﻟازﻹ .نﻮﺑﺎﺼﻟﺎﺑ ﺔﺌﻓاد هﺎﻴﻣو
.قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ ﺎ
ﹰ
ﺼﻴﺼﺧ عﻮﻨﺼﻣ ﻒﻴﻈﻨﺗ
•ةزﺎﺟإ ﻲﻓ بﺎﻫﺬﻟا ﺪﻨﻋ
هﺎﻴﳌا درﻮﻣ ﻞﻴﻐﺸﺗ فﺎﻘﻳإو ﻲﺋﺎﺑﺮﻬﻜﻟا ﺲﺑﺎﻘﻟا ﻦﻣ ﺲﺑﺎﻘﻟا عﺰﻧ ﻢﺛ ،ﺔﻏرﺎﻓ ﻰﻫو ةﺪﺣاو ةروﺪﻟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺘﺑ ﺢ
ﹶ
ﺼﻨ
ﹸ
ﻳ ،ةزﺎﺟإ ﻰﻟإ ﺐﻫﺬﺗ ﺎﻣﺪﻨﻋ
.زﺎﻬﳉا ﻞﺧاد ﺢﺋاوﺮﻟا ﻦﻳﻮﻜﺗ ﻊﻨﳝ ﺎﻤﻛ ،لﻮﻃأ ا
ﹰ
ﺮﻤ
ﹸ
ﻋ ﺶﻴﻌﺗ تاداﺪﺴﻟا ﻞﻌﺠﻳ فﻮﺳ اﺬﻫو .ﺎ
ﹰ
ﻴﺋﺰﺟ ﺎ
ﹰ
ﺣﻮﺘﻔﻣ زﺎﻬﳉا بﺎﺑ كﺮﺗو
•
ﻪﻧﺎﻜﻣ ﻦﻣ زﺎﻬﳉا ﻚﻳﺮﲢ
.ﺎﻫﺮﻬﻇ ﻰﻠﻋ ﺎﻬﻌﺿو ﻦﻜﻤﻴﻓ ،ا
ﹰ
ﺪﺟ ﺎ
ﹰ
ﻳروﺮﺿ نﺎﻛ اذإو .ﻲﺳأﺮﻟا ﻊﺿﻮﻟا ﻲﻓ ﻪﻴﻠﻋ ﻆﻓﺎﲢ نأ لوﺎﺤﻓ ،زﺎﻬﳉا ﻚﻳﺮﲢ ﻦﻣ ﺪﺑﻻ نﺎﻛ اذإ
•تاداﺪﺴﻟا
ﺔﺠﻨﻔﺳإ ماﺪﺨﺘﺳﺎﺑ يروﺪﻟا ﻒﻴﻈﻨﺘﻟا يدﺆﻳو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻲﻓ ﺢﺋاور ﻦﻳﻮﻜﺗ ﻰﻟإ يدﺆﺗ ﻲﺘﻟا ﻞﻣاﻮﻌﻟا ﺪﺣأ تاداﺪﺴﻟا ﻲﻓ ﺔﻤﻌﻃﻷا ﺎﻳﺎﻘﺑ رﺎﺸﺤﻧا ﺪﻌﻳ
.ﻚﻟذ ثوﺪﺣ ﻊﻨﻣ ﻰﻟإ ﺔﺒﻃر
ﺔﻳﺎﻨﻌﻟاو ﻒﻴﻈﻨﺘﻟا
DW5500M_DD81-02437K-00_AR.indd 34DW5500M_DD81-02437K-00_AR.indd 34 2019-03-18 11:14:522019-03-18 11:14:52
٣٥_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ ٠٦
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ
ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺻ ثوﺪﺣ ﺮﻄﺧ :ﺮﻳﺬﲢ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ﻞﺒﻗ ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻞﺼﻓا
.ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺼﻟ ضﺮﻌﺘﻟا وأ ةﺎﻓﻮﻟا ﻰﻟإ ﻚﻟﺬﺑ ماﺰﺘﻟﻻا مﺪﻋ يدﺆﻳ ﺪﻗ
.ﲔﻓﺮﺘﺤﻣ ﲔﻴﻨﻓ ﻖﻳﺮﻃ ﻦﻋ ﺔﻴﺋﺎﺑﺮﻬﻜﻟا ةﺰﻬﺟﻷاو ﺮﻴﺳاﻮﳌا ﻞﻴﺻﻮﺗ ﻲﻐﺒﻨﻳ :هﺎﺒﺘﻧا
ءﺎﺑﺮﻬﻜﻟا ﻞﻴﺻﻮﺗ ﻦﻋ ةﺬﺒﻧ
:ﺔﻴﺼﺨﺸﻟا ﺔﻣﻼﺴﻟا ﻲﻋاوﺪﻟ ,ﻪﻴﺒﻨﺗ
.زﺎﻬﳉا اﺬﻫ ﻊﻣ ﺊﻳﺎﻬﻣ ﺲﺑﺎﻗ وأ ﺪﻳﺪﲤ ﻚﻠﺳ ماﺪﺨﺘﺳا ﺮﻈﺤﻳ
.ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻚﻠﺳ ﻦﻣ ﻪﺘﻟازإ وأ ﺚﻟﺎﺜﻟا ﻲﺿرﻷا ﻦﺴﻟا ﻊﻄﻗ لاﻮﺣﻷا ﻦﻣ لﺎﺣ يﺄﺑ ﺮﻈﺤﻳ
ﺔﻴﺋﺎﺑﺮﻬﻜﻟا تﺎﺒﻠﻄﺘﳌا
•.ﺰﺗﺮﻫ ٥٠ ددﺮﺘﺑ / ﺖﻟﻮﻓ ٢٤٠ ﻰﻟإ ٢٢٠ هﺪﻬﺟ ﺮﻬﺼﻨﻣ وأ ﺔﻴﺑﺮﻬﻛ ةﺮﺋاد ﻊﻃﺎﻗ
•.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ مﺪﺨﺗ ﺔﻠﺼﻔﻨﻣ ﺔﻴﻋﺮﻓ ﺔﻴﺑﺮﻬﻛ ةﺮﺋاد
ﻲﺿرﻷا ﻞﻴﺻﻮﺘﻟا تادﺎﺷرإ
ماﺪﺨﺘﺳﻻا ﻞﺒﻗ ﺐﺳﺎﻨﻣ ﻲﺿرأ فﺮﻃ دﻮﺟو ﻦﻣ ﺪﻛﺄﺗ
ﺔﻣﺪﺼﻟا ةرﻮﻄﺧ ﻞﻴﻠﻘﺗ ﻰﻟإ ﻲﺿرﻷا ﻞﻴﺻﻮﺘﻟا يدﺆﻴﺳ ،ﻞﻄﻌﺗ وأ ءادﻷا ﻲﻓ ﻒﻌﺿ ثوﺪﺣ ﺔﻟﺎﺣ ﻲﻓو .ﻲﺿرأ فﺮﻄﺑ زﺎﻬﳉا ﻞﻴﺻﻮﺗ ﺐﺠﻳ
ﻞﻴﺻﻮﺗ ﺐﺠﻳ .ﻲﺿرأ ﺲﺑﺎﻗو ﻲﺿرأ ﻞﺻﻮﲟ ﻚﻠﺳ زﺎﻬﳉا ﻊﻣ ﺮﻓﻮﺘﻳ ﻚﻟﺬﻛ .ﻲﺑﺮﻬﻜﻟا رﺎﻴﺘﻠﻟ ﺔﻣوﺎﻘﳌا ﻦﻣ رﺎﺴﻣ ﺮﻴﻓﻮﺘﺑ ﻚﻟذو ﺔﻴﺑﺮﻬﻜﻟا
.ﺔﻴﻠﶈا ﻂﺑاﻮﻀﻟاو ﲔﻧاﻮﻘﻠﻟ ﺎ
ﹰ
ﻘﻓو ﺎ
ﹰ
ﻴﺿرأ ﻪﻠﻴﺻﻮﺗو ﻪﺒﻴﻛﺮﺗ ﰎ ﺐﺳﺎﻨﻣ ﺬﺧﺄﻣ ﻲﻓ ﺲﺑﺎﻘﻟا
وأ ﻞﻫﺆﻣ ءﺎﺑﺮﻬﻛ ﻲﻨﻓ ﺮﺸﺘﺳا .ﺔﻴﺑﺮﻬﻛ ﺔﻣﺪﺼﻟ ض
ﹼ
ﺮﻌﺘﻟا ﺮﻄﺧ ﻰﻟإ زﺎﻬﺠﻠﻟ ﻲﺿرﻷا ﻞﺻﻮﻤﻠﻟ ﺢﻴﺤﺼﻟا ﺮﻴﻏ ﻞﻴﺻﻮﺘﻟا يدﺆﻳ ﺪﻗ :ﺮﻳﺬﲢ
.زﺎﻬﺠﻠﻟ ﺺﺼا ﺲﺑﺎﻘﻟا ﺮﻴﻴﻐﺘﺑ ﻢﻘﺗ ﻻو .ﻢﻴﻠﺳ ﻞﻜﺸﺑ زﺎﻬﳉا ﻞﻴﺻﻮﺗ ﻦﻣ ا
ﹰ
ﺪﻛﺄﺘﻣ ﻦﻜﺗ ﻢﻟ اذإ ﺔﻣﺪﺧ ﻞﺜﳑ
ﺎﻬﻔﻳﺮﺼﺗو هﺎﻴﳌا ﺪﻳرﻮﺗ
درﺎﺒﻟا ءﺎﳌا ﻞﻴﺻﻮﺗ
ﻲﻓ ﻪﺘﻴﺒﺜﺗ ﻦﻣ ﺪﻛﺄﺗو (ﺔﺻﻮﺑ) ٣/٤ ﺔﻴﺒﻟﻮﻠﻟا ﺔﻠﺻﻮﻟﺎﺑ درﺎﺒﻟا ءﺎﳌا ﺪﻳرﻮﺗ مﻮﻃﺮﺧ ﻞﻴﺻﻮﺘﺑ ﻢﻗ
.مﺎﻜﺣﺈﺑ ﺢﻴﺤﺼﻟا ﻪﻧﺎﻜﻣ
نﺎﻤﻀﻟ يﺮﲡ هﺎﻴﳌا ﻞﻌﺟا ،ﺔﻠﻳﻮﻃ ةﺮﺘﻔﻟ ﺎﻬﻣاﺪﺨﺘﺳا ﻢﺘﻳ ﻢﻟ وأ ةﺪﻳﺪﺟ هﺎﻴﳌا ﺮﻴﺳاﻮﻣ ﺖﻧﺎﻛ اذإ
.زﺎﻬﳉا ﻒﻠﺗو ءﺎﳌا مﺎﻤﺻ داﺪﺴﻧا ﻰﻟإ ﺮﻄﺧ ﺐ
ﹼ
ﻨﺠﺘﻟ تﺎﻃﺎﻴﺘﺣﻻا هﺬﻬﺑ ماﺰﺘﻟﻻا ﺐﺠﻳ .ﺎﻬﺋﺎﻘﻧ
ةرﻮﺳﺎﻣ ﻞﻴﺻﻮﺗ ﻦﻣ ﺪﻛﺄﺗ .هﺎﻴﳌا ﺔﳉﺎﻌﳌ مﺎﻈﻧ ﻰﻠﻋ ﻖﻓﺮﳌا هﺎﻴﳌا داﺪﻣإ مﻮﻃﺮﺧ يﻮﺘﺤﻳ
.رﻮﺒﻨﺼﻟﺎﺑ هﺎﻴﳌا ﺪﻳرﻮﺗ مﻮﻃﺮﺨﺑ ﺔﺻﺎﳋا هﺎﻴﳌا ﺔﳉﺎﻌﳌ
DW5500M_DD81-02437K-00_AR.indd 35DW5500M_DD81-02437K-00_AR.indd 35 2019-03-18 11:14:522019-03-18 11:14:52
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ _٣٦
ﻦﺧﺎﺴﻟا ءﺎﳌا ﻞﻴﺻﻮﺗ
ﺔﺟرد زوﺎﺠﺘﻳ ﻻ ﻪﻧأ ﺎﳌﺎﻃ ،(ﺔﺌﻓﺪﺘﻟا مﺎﻈﻧ ،يﺰﻛﺮﳌا مﺎﻈﻨﻟا) لﺰﻨﳌﺎﺑ دﻮﺟﻮﳌا ﻦﺧﺎﺴﻟا ءﺎﳌا ﻂﺨﺑ زﺎﻬﳉﺎﺑ ﻞﺼﺘﳌا هﺎﻴﳌا د
ﹼ
رﻮﻣ ﻞﻴﺻﻮﺗ ﺎ
ﹰ
ﻀﻳأ ﻦﻜﳝ
ﻞﻴﺻﻮﺘﻟا ﺐﺠﻳ .
ﹰ
ﻼﻴﻠﻗ ﻞﺴﻐﻟا ﺔﻴﻠﻤﻋ ةءﺎﻔﻛ ﺾﻔﺨﻨﺗو ﺔﻘﻴﻗد ١٥ ﻮﺤﻧ ﻞﺴﻐﻟا ةرود ةﺪﻣ ﻞﻴﻠﻘﺗ ﻢﺘﻳ ،ﺔﻟﺎﳊا هﺬﻫ ﻲﻓو .ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠ ةراﺮﺣ
.درﺎﺒﻟا ءﺎﳌا ﻂﺧ ﻞﻴﺻﻮﺘﺑ
ﺔﺻﺎﳋا ﺎﻬﺴﻔﻧ تاءاﺮﺟﻹا عﺎﺒﺗﺎﺑ ﻦﺧﺎﺴﻟا ءﺎﳌا ﻂﺨﺑ
زﺎﻬﳉا ﻊﺿو
.ﻂﺋﺎﳊا وأ ةروﺎا تﺎﻧاﺰﳋاو ﺐﻧاﻮﳉاو ﻂﺋﺎﳊاو زﺎﻬﺠﻠﻟ ﻲﻔﻠﳋا ءﺰﳉا ﲔﺑ ﺔﻓﺎﺴﻣ كﺎﻨﻫ نﻮﻜﺗ نأ ﻲﻐﺒﻨﻳ .هﺪﻳﺮﺗ يﺬﻟا نﺎﻜﳌا ﻲﻓ زﺎﻬﳉا ﻊﺿ
ﺔﻘﻳﺮﻄﺑ ﺐﻴﻛﺮﺘﻟا ﻞﻴﻬﺴﺘﻟ رﺎﺴﻴﻟا وأ ﲔﻤﻴﻟا ﻰﻠﻋ ﺎﻬﻌﺿو ﻦﻜﳝ ﺚﻴﺤﺑ هﺎﻴﻤﻠﻟ ﻒﻳﺮﺼﺗو ﺪﻳرﻮﺗ ﻢﻴﻃاﺮﺨﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺪﻳوﺰﺗ ﰎ
.ﺔﺤﻴﺤﺻ
ﻢﻴﻃاﺮﳋا ﻦﻣ ﺪﺋاﺰﻟا ءﺎﳌا ﻒﻳﺮﺼﺗ ﺔﻴﻔﻴﻛ
ﻦﻣ نﻮﻜﻴﺳ ،ﻲﻟﺎﺘﻟﺎﺑو .
ﹰ
ةﺮﺷﺎﺒﻣ ضﻮﳊا ﻰﻟإ ﻢﻴﻃاﺮﳋا ﻲﻓ ﺪﺋاﺰﻟا ءﺎﳌا ﻒﻳﺮﺼﺗ ﻦﻜﳝ ﻼﻓ ،ضرﻷا ﻦﻣ ﱈ ١٠٠٠ راﺪﻘﲟ ﻰﻠﻋأ ضﻮﳊا نﺎﻛ اذإ
.ﺎ
ﹰ
ﻋﺎﻔﺗرا ﻞﻗأو ضﻮﳊا جرﺎﺧ نﻮﻜﺗ ﺔﺒﺳﺎﻨﻣ ﺔﻳوﺎﺣ وأ ءﺎﻋو ﻲﻓ ﻢﻴﻃاﺮﳋا ﻦﻣ ﺪﺋاﺰﻟا ءﺎﳌا ﻒﻳﺮﺼﺗ يروﺮﻀﻟا
ءﺎﳌا جﺮﺨﻣ
.هﺎﻴﳌا بﺮﺴﺗ ﻊﻨﳌ ﺢﻴﺤﺻ ﻞﻜﺸﺑ ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ ﺖﻴﺒﺜﺗ ﺐﺠﻳ .هﺎﻴﳌا ﻒﻳﺮﺼﺗ مﻮﻃﺮﺧ ﻞﻴﺻﻮﺘﺑ ﻢﻗ
.ﻪﻴﻠﻋ ﻂﻐﻀﻟا وأ هﺎﻴﳌا ﺪﻳرﻮﺗ مﻮﻃﺮﺧ ءاﻮﺘﻟا مﺪﻋ ﻦﻣ ﺪﻛﺄﺗ
ﺪﻳﺪﻤﺘﻟا مﻮﻃﺮﺧ
.ةدﻮﳉاو ﻢﺠﳊا ﺲﻔﻨﺑ ﻒﻳﺮﺼﺗ مﻮﻃﺮﺧ مﺪﺨﺘﺳﺎﻓ ،ﻒﻳﺮﺼﺘﻠﻟ مﻮﻃﺮﺧ ﺔﻠﺻو ﻰﻟإ جﺎﺘﲢ ﺖﻨﻛ اذإ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻴﻈﻨﺗ ةءﺎﻔﻛ ﻞﻘﺘﺳ ﻻإو ؛رﺎﺘﻣأ ٤ ﻦﻋ ﺔﻠﺻﻮﻟا لﻮﻃ ﺪﻳﺰﻳ ﻻأ ﺐﺠﻳ
نﻮﻔﻴﺴﻟا ﻞﻴﺻﻮﺗ
ﺖﻴﺒﺜﺗ ﻲﻐﺒﻨﻳو .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ةﺪﻋﺎﻗ ﻦﻣ (ﺮﺜﻛﻷا ﻰﻠﻋ) ﻢﺳ ١٠٠و (ﻞﻗﻷا ﻰﻠﻋ) ﻢﺳ ٤٠ ﲔﺑ عﺎﻔﺗرا ﻰﻠﻋ ﻒﻳﺮﺼﺘﻟا ﺔﻠﺻو نﻮﻜﺗ نأ ﺐﺠﻳ
.مﻮﻃﺮﳋا ﻚﺒﺸﻣ ماﺪﺨﺘﺳﺎﺑ هﺎﻴﳌا ﻒﻳﺮﺼﺗ مﻮﻃﺮﺧ
هﺎﻴﳌا ﺔﳉﺎﻌﻣ مﺎﻈﻧ
ﻞﻤﻌﻳ ،ﺖﻗو يأ ﻲﻓ ﺪﻳرﻮﺘﻟا مﻮﻃﺮﺧ ﻦﻣ هﺎﻴﳌا بﺮﺴﺗ ﺔﻟﺎﺣ ﻲﻓ .هﺎﻴﳌا بﺮﺴﺗ ﻊﻨﻣ ﻰﻠﻋ ﻞﻤﻌﻳ نﺎﻣأ مﺎﻤﺻ مﺎﻈﻧ ﻮﻫ هﺎﻴﳌا ﺔﳉﺎﻌﻣ مﺎﻈﻧ نإ
.ﻪﻟﺪﺒﺘﺳاو ﻪﺘﻟازﺈﺑ ﻢﻗ ،نﺎﻣﻷا مﺎﻤﺻ وأ هﺎﻴﳌا داﺪﻣإ مﻮﻃﺮﺧ ﻒﻠﺗ ﺪﻨﻋ .ﺔﻳرﺎﳉا هﺎﻴﳌا ﻊﻄﻗ ﻰﻠﻋ نﺎﻣﻷا مﺎﻤﺻ
.هﺮﻴﺼﻘﺗ وأ هﺎﻴﳌا ﺪﻳرﻮﺗ مﻮﻃﺮﺧ ﺮﻴﺒﻜﺘﺑ ﻢﻘﺗ ﻻ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ
DW5500M_DD81-02437K-00_AR.indd 36DW5500M_DD81-02437K-00_AR.indd 36 2019-03-18 11:14:522019-03-18 11:14:52
٣٧_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ داﺪﻋإ ٠٦
ﻒﻳﺮﺼﺘﻟا ﻢﻴﻃاﺮﺧ ﻞﻴﺻﻮﺗ
مﻮﻃﺮﳋا عﺎﻔﺗرا نﻮﻜﻳ نأ ﺐﺠﻳ .ﻪﻴﻠﻋ ﻂﻐﻀﻟا وأ ﻪﻴﻨﺛ نود ضﻮﳊا ﻰﻟإ ﻞﺼﻳ ﻪﻠﻌﺟا وأ ،ﻰﻧدأ ﺪﺤﻛ ﻢﺳ ٤ ﺮﻄﻘﺑ ﻒﻳﺮﺼﺘﻟا ﺔﺑﻮﺒﻧأ ﻲﻓ ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ ﻞﺧدأ
.ﺎﻬﻟ ﻲﻔﻠﳋا ﻖﻓﺪﺘﻟا ﺐﻨﺠﺘﻟ ءﺎﳌﺎﺑ مﻮﻃﺮﳋا فﺮﻃ ﺮﻤﻏ مﺪﻋ ﺐﺠﻳو .ﻢﺳ ١٠٠و ٤٠ ﲔﺑ
ﺔﻈﺣﻼﻣ
٤٠ ﲔﺑ مﻮﻃﺮﳋا عﺎﻔﺗرا نﻮﻜﻳ نأ ﺐﺠﻳ
.ﻢﺳ ١٠٠و
.ءﺎﳌﺎﺑ مﻮﻃﺮﳋا فﺮﻃ ﺮﻤﻏ مﺪﻋ ﺐﺠﻳو
ﻒﻳﺮﺼﺘﻟا ةرﻮﺳﺎﻣ
ﱈ ٤٠
داﺪﻌﻟا
ﱈ ٤٠٠ ﻰﻧدأ ﺪﺣ
ﱈ ١٠٠٠ ﻰﺼﻗأ ﺪﺣ
زﺎﻬﳉا ﻊﺿو
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺪﻳوﺰﺗ ﰎ .نارﺪﳉا وأ ةروﺎا تﺎﻧاﺰﳋاو ﺐﻧاﻮﳉاو ﻂﺋﺎﳊاو زﺎﻬﺠﻠﻟ ﻲﻔﻠﳋا ءﺰﳉا ﲔﺑ ﺔﻓﺎﺴﻣ كﺎﻨﻫ نﻮﻜﺗ نأ ﻲﻐﺒﻨﻳ .ﺐﺳﺎﻨﳌا نﺎﻜﳌا ﻲﻓ زﺎﻬﳉا ﻊﺿ
.ﺔﺤﻴﺤﺻ ﺔﻘﻳﺮﻄﺑ ﺐﻴﻛﺮﺘﻟا ﻞﻴﻬﺴﺘﻟ ﺮﺴﻳﻷا وأ ﻦﳝﻷا ﺐﻧﺎﳉا ﻰﻠﻋ ﺎﻬﻌﺿو ﻦﻜﳝ ﺚﻴﺤﺑ هﺎﻴﻤﻠﻟ ﻒﻳﺮﺼﺗو ﺪﻳرﻮﺗ ﻢﻴﻃاﺮﺨﺑ
زﺎﻬﳉا ءاﻮﺘﺳا
ﻂﺒﺿ ﻖﻳﺮﻃ ﻦﻋ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ عﺎﻔﺗرا ﺮﻴﻴﻐﺗ ﻢﺘﻳ ﺪﻗ ،
ﹺ
ﻮﺘﺴﻣ ﺢﻄﺳ ﻰﻠﻋ زﺎﻬﳉا ﻊﺿو دﺮﺠﲟ
.ﲔﺘﺟرد ﻦﻣ ﺮﺜﻛأ زﺎﻬﳉا ﺔﻟﺎﻣإ ﻲﻐﺒﻨﻳ ﻻ ،لﺎﺣ يأ ﻰﻠﻋو .ﻞﺟرﻷا ىﻮﺘﺴﻣ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ءﺪﺑ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ﻞﺒﻗ ﻲﺗﻵا ﻦﻣ ﻖﻘﺤﺘﻟا ﺐﺠﻳ
١ .ﺎﻬﺗﺎﺒﺛو ﺔﻟﺎﺴﻐﻟا ءاﻮﺘﺳا
٢ .هﺎﻴﳌا ﺪﻳرﻮﺗ مﺎﻤﺻ ﺢﺘﻓ
٣ ..ﺮﻴﺳاﻮﳌا تﻼﺻو ﲔﺑ بﺮﺴﺗ دﻮﺟو مﺪﻋ
۴ .مﺎﻜﺣﺈﺑ كﻼﺳﻷا ﻞﻴﺻﻮﺗ
۵ .ﺔﻗﺎﻄﻟا ﻞﻴﻐﺸﺗ
۶ .ﻒﻳﺮﺼﺘﻟاو ﺪﻳرﻮﺘﻟا ﻢﻴﻃاﺮﺧ ﻚﺑﺎﺸﺗ مﺪﻋ
٧ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ تﺎﻋﻮﺒﻄﳌاو ﻒﻴﻠﻐﺘﻟا داﻮﻣ ﻊﻴﻤﺟ ﺔﻟازإ
.ﻞﻴﻟﺪﻟا اﺬﻫ تﺎﻳﻮﺘﺤﻣ ﻦﻣ ةدﺎﻔﺘﺳﻻا ﲔﻣﺪﺨﺘﺴﻤﻠﻟ ﻦﻜﳝ
ﺚﻴﺣ ،ﻦﻣآ نﺎﻜﻣ ﻲﻓ ﻞﻴﻟﺪﻟا اﺬﻫ ﻊﺿو ﻰﺟﺮﻳ ،ﺐﻴﻛﺮﺘﻟا ﺪﻌﺑ :هﺎﺒﺘﻧا
DW5500M_DD81-02437K-00_AR.indd 37DW5500M_DD81-02437K-00_AR.indd 37 2019-03-18 11:14:522019-03-18 11:14:52
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ _٣٨
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
ﺎ
ﹰ
ﻣﺎﲤ ﺔﺠﻣﺪ
ﹸ
ﻣ ،ﺔﺠﻣﺪ
ﹸ
ﻣ ﻪﺒﺷ ،ﻞﻤﻌﻟا ﺢﻄﺳ ﺖﲢ ﺔﺒ
ﹼ
ﻛﺮﻣ قﺎﺒﻃأ ﺔﻟﺎﺴﻏ
ﺔﺑﺎﺻﻹا ﺮﻄﳋ ﺎ
ﹰ
ﺿ
ﹼ
ﺮﻌﻣ نﻮﻜﺗ ﻻ ﻰﺘﺣو ﻲﻐﺒﻨﻳ ﺎﻤﻛ ﻚﻳﺪﻟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻤﻌﺗ ﻰﺘﺣ ﺔﻗﺪﺑ تﺎﻤﻴﻠﻌﺘﻟا هﺬﻬﻟ ﻚﻳﺪﻟ ﺐﻴﻛﺮﺘﻟا ﻲﺋﺎﺼﺧأ وأ ﺖﻧأ ﻚﻋﺎﺒﺗا ﻦﻣ ﺪﻛﺄﺗ
.قﺎﺒﻃﻷا ﻞﺴﻏ ﺪﻨﻋ
ﺪﻳﺪﳉا ﺐﻴﻛﺮﺘﻟا
.ﺎﻬﻧﺎﻜﻣ ﻰﻟإ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻘﻧ ﻞﺒﻗ ﺐﻴﻛﺮﺘﻟا لﺎﻤﻋأ ﻢﻈﻌﲟ مﺎﻴﻘﻟا ﺐﺠﻴﻓ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﺪﻳﺪﳉا ﺐﻴﻛﺮﺘﻟا ﺔﻟﺎﺣ ﻲﻓ
لاﺪﺒﺘﺳﻻا
لﺪﺒﺘﺳاو ،ةﺪﻳﺪﳉا
ﺔﻟﺎﺴﻐﻟا ﻊﻣ ﺎﻬﻘﻓاﻮﺗ نﺎﻤﻀﻟ ﺔﻴﻟﺎﳊا تﻼﻴﺻﻮﺘﻟا ﺺﺤﻔﺑ مﻮﻘﺗ نأ ﺐﺠﻴﻓ ،ﺔﳝﺪﻘﻟا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ لاﺪﺒﺘﺳﺎﺑ مﻮﻘﺗ ﺖﻨﻛ اذإ
.ةروﺮﻀﻟا ﺪﻨﻋ ةدﻮﺟﻮﳌا تﻼﻴﺻﻮﺘﻟا
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ نﺎﻜﻣ ﻞﻀﻓأ رﺎﻴﺘﺧا ١ ةﻮﻄﳋا
.ﺔﻗﺎﻄﻟا ﻚﻠﺳو ﻞﻌﻔﻟﺎﺑ ﻦﻳدﻮﺟﻮﳌا ﻒﻳﺮﺼﺘﻟاو ﺪﻳرﻮﺘﻟا ﻲﻣﻮﻃﺮﺧ ﻦﻣ ﺎ
ﹰ
ﺒﻳﺮﻗ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ﻊﺿﻮﻣ نﻮﻜﻳ نأ ﺐﺠﻳ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒﻳﺮﺼﺗ ﻢﻴﻃاﺮﺧ ﻞﻴﺻﻮﺗ ﺔﻴﻠﻤﻋ ﻞﻴﻬﺴﺘﻟ ﺔﻧاﺰﳋا ضﻮﺣ ﺐﻧاﻮﺟ ﺪﺣأ رﺎﻴﺘﺧا ﺐﺠﻳ
١ ..ﻒﻳﺮﺼﺘﻟاو ﺪﻳرﻮﺘﻟا ﻢﻴﻃاﺮﺧ ﺐﻴﻛﺮﺗ ﺔﻴﻠﻤﻋ ﺮﻴﺴﻴﺘﻟ ضﻮﳊا ﻦﻣ ﺎ
ﹰ
ﺒﻳﺮﻗ ﺎ
ﹰ
ﻧﺎﻜﻣ ﺮﺘﺧا
٢ ..ﺔﻧاﺰﺨﻠﻟ يذﺎﶈا ﻲﺟرﺎﳋا بﺎﺒﻟاو ﺔﻧاﺰﳋاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻰﻠﻋأ ﲔﺑ ﱈ ٥ ﻦﻋ ﻞﻘﺗ ﺔﻓﺎﺴﻣ كﺮﺗا
٨٧٠
٨٧٠
~
~
٨٢٠
٨٢٠
ﻰﻧدأ
ﹴ
ﺪﺤﺑ
ﻰﻧدأ
ﹴ
ﺪﺤﺑ
٥٨٠
٥٨٠
تﻼﻴﺻﻮﺘﻟا ﻞﺧاﺪﻣ
تﻼﻴﺻﻮﺘﻟا ﻞﺧاﺪﻣ
ﺔﻴﺋﺎﺑﺮﻬﻜﻟا
ﺔﻴﺋﺎﺑﺮﻬﻜﻟا
ﻒﻳﺮﺼﺘﻟا ﻢﻴﻃاﺮﺧو
ﻒﻳﺮﺼﺘﻟا ﻢﻴﻃاﺮﺧو
هﺎﻴﳌﺎﺑ داﺪﻣﻹا ﻂﺧو
هﺎﻴﳌﺎﺑ داﺪﻣﻹا ﻂﺧو
ﺔﻴﺿرﻷاو ﺔﻧاﺰﳋا ﻞﻔﺳأ ﲔﺑ ﺔﻓﺎﺴﳌا
ﺔﻴﺿرﻷاو ﺔﻧاﺰﳋا ﻞﻔﺳأ ﲔﺑ ﺔﻓﺎﺴﳌا
ﻰﻧدأ
ﹴ
ﺪﺤﺑ
ﻰﻧدأ
ﹴ
ﺪﺤﺑ
٦٠٠
٦٠٠
١٠٠
١٠٠
ﺔﺟرد
ﺔﺟرد
٩٠
٩٠
ﺔﺟرد
ﺔﺟرد
٩٠
٩٠
٣ ..بﺎﺒﻟا ﺢﺘﻓ ﺪﻨﻋ ﺔﻓﺎﺴﻣ كﺮﺗ ﺐﺠﻴﻓ ،ﺔﻧاﺰﳋا ﺔﻳواﺰﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ﺔﻟﺎﺣ ﻲﻓ
ﺔﻧاﺰﳋا
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
ﺔﻟﺎﺴﻏ بﺎﺑ
ﺔﻟﺎﺴﻏ بﺎﺑ
قﺎﺒﻃﻷا
قﺎﺒﻃﻷا
تﺎﻓﺎﺴﻤﻠﻟ ﻰﻧدﻷا ﺪﳊا
ﱈ ٥٠
.ﻲﺋﺎﺑﺮﻬﻜﻟا ﺬﺧﺄﳌا ﻊﻗﻮﳌ ﺎ
ﹰ
ﻘﻓو ﺔﻧاﻮﺨﻠﻟ ﻞﺑﺎﻘﳌا ﺐﻧﺎﳉا ﻲﻓ ﺐﻘﺛ ﻞﻤﻋ ﻰﻟإ جﺎﺘﲢ ﺪﻗ
DW5500M_DD81-02437K-00_AR.indd 38DW5500M_DD81-02437K-00_AR.indd 38 2019-03-18 11:14:522019-03-18 11:14:52
٣٩_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ٠٧
ﺔﻴﺋﺎﺑﺮﻬﻜﻟا تﺎﺒﻠﻄﺘﳌاو هﺎﻴﳌا داﺪﻣإ ﻂﺧ ﻦﻣ ﻖﻘﺤﺘﻟا ٢ ةﻮﻄﳋا
•.لﺎﻜﺳﺎﺑﺎﺠﻴﻣ ١٫٠و لﺎﻜﺳﺎﺑﺎﺠﻴﻣ ٠٫٠٤ ﲔﺑ ﺎﻣ هﺎﻴﳌا ﻂﺧ ﻂﻐﺿ حواﺮﺘﻳ نأ ﺐﺠﻳ
•.ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠ زوﺎﺠﺘﺗ ﻻ هﺎﻴﳌا ةراﺮﺣ ﺔﺟرد نأ ﺪﻛﺄﺗ .ﻂﻘﻓ درﺎﺒﻟا ءﺎﳌﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺪﻳوﺰﺗ ﺐﺠﻳ
• .ﺞﺘﻨﳌا ﻞ
ﹼ
ﻄﻌﺘﻳ ﺪﻘﻓ ،ﻻإو .ﻦﺧﺎﺳ ءﺎﲟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺪﻳوﺰﺘﺑ ﻢﻘﺗ ﻻ
•.ﺰﺗﺮﻫ ٥٠ ددﺮﺘﺑ ~ ﺖﻟﻮﻓ ٢٤٠و ٢٢٠ ﲔﺑ حواﺮﺘﻳ ﺪﻬﺠﺑ ةر
ﹼ
ﺪﻘ
ﹸ
ﻣ ﺔﻗﺎﻃ مﺪﺨﺘﺳا
•.ﺔﻗﺎﻄﻟا ﻚﻠﺳ ﻞﺼﻓ ةﺎﻋاﺮﻣ ﻊﻣ ﺞﺘﻨﳌا ﺐﻴﻛﺮﺘﺑ ﻢﻗ
• قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺘﻟ مزﻼﻟا رﺎﻴﺘﻟا ةﺪﺸﻟ ﻰﺼﻗﻷا ﺪﳊا نأ ﻢﻠﻌﻟا ﻰﺟﺮ
ﹸ
ﻳ) ﻰﺼﻗأ
ﹴ
ﺪﺤﺑ ﺮﻴﺒﻣأ ١٦ ﻪﺗﺪﺷ رﺎﻴﺗ ﻪﻴﻓ ﺮﳝ ﺔﻗﺎﻄﻠﻟ ا
ﹰ
ﺬﺧﺄﻣ مﺪﺨﺘﺳا
(.ﺮﻴﺒﻣأ ١١ ﻮﻫ هﺬﻫ
•:ﻲﻠﻳ ﺎﻣ ﺮﻓﻮﻳ ﺔﻗﺎﻄﻟا رﺪﺼﻣ نأ ﻦﻣ ﺪﻛﺄﺗ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ﺪﻨﻋ
- .ﺰﺗﺮﻫ ٥٠ ددﺮﺘﺑ ~ ﺖﻟﻮﻓ ٢٤٠ ﻰﻟإ ٢٢٠ هﺪﻬﺟ ﺮﻬﺼﻨﻣ وأ ﺔﻴﺑﺮﻬﻛ ةﺮﺋاد ﻊﻃﺎﻗ
- .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ مﺪﺨﺗ ﺔﻠﺼﻔﻨﻣ ﺔﻴﻋﺮﻓ ﺔﻴﺑﺮﻬﻛ ةﺮﺋاد
•.ﺔﻗﺎﻄﻟا ﻚﻠﺳ ﻒﻠﺗ وأ ءﺎﻨﺜﻧا مﺪﻋ ﻦﻣ ﺪﻛﺄﺗ ،ﺐﻴﻛﺮﺘﻟا ﺪﻌﺑ
•.هﺎﻴﳌا داﺪﻣإ ﻂﺨﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﺻﻮﺗ ﻞﺒﻗ هﺎﻴﳌا داﺪﻣإ مﺎﻤﺻ ﻞﻴﻐﺸﺗ فﺎﻘﻳإ ﻦﻣ ﺪﻛﺄﺗ
•.هﺎﻴﻤﻠﻟ ب
ﹼ
ﺮﺴﺗ يأ فﺎﻘﻳﻹ بﺮﺴﺘﻠﻟ ﻊﻧﺎﻣ ﺐ
ﹼ
ﻛﺮﻣ وأ نﻮﻠﻔﻴﺗ ﻂﻳﺮﺷ ماﺪﺨﺘﺳﺎﺑ هﺎﻴﳌﺎﺑ داﺪﻣﻹا ﻂﺧ تﻼﻴﺻﻮﺗ ﺪﺳ مﺎﻜﺣﺈﺑ ﻢﻗ
ﺔﺼﺼا ﺔﺣﻮﻠﻟا داﺪﻋإ ٣ ةﻮﻄﳋا
(ﺔﺠﻣﺪ
ﹸ
ﳌا ﻪﺒﺷ وأ ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ)
.ﻢﺳﺮﻟﺎﺑ ﺔﺤ
ﹼ
ﺿﻮﳌا دﺎﻌﺑﻸﻟ ﺎ
ﹰ
ﻘﻓو ﺔﺼﺼا ﺔﺣﻮﻠﻟا ﻊﻣ ﻞﻣﺎﻌﺘﻟا ﺐﺠﻳ
A
A
A
A-A
٥٨٩
٣٨
٤٣٦
٣٠
(ﻰﺼﻗأ
ﹴ
ﺪﺤﺑ) ٧٢٠
(ﻰﺼﻗأ
ﹴ
ﺪﺤﺑ) ٢٠
٥,٥ Ø-٢
(٨ )٢ Ø-٢
(٨
)٢ Ø-٤
(٨
)٢ Ø-٨
١١ Ø-٢
٥١٧
٤٧٤٫٨
١٢٧
٠٫٢±٥٦٦
٠٫٢±٤٥١
٠٫٢±٥٤٠
٠٫٢±٧٥
٦٢
ف
١٨
٨-٦
٩٫٥-٨
١٫٥
C١٫٥-٦
١٫٥
٥٦٦
٥٨٩
٣٦
٢٢٠
١١٥٫٥
٢٠
٢٢٠
(ﻰﺼﻗأ
ﹴ
ﺪﺤﺑ) ٥٧٠
٣٩٧
٢٠٢
٧
١ Ø-٦
٢ Ø-٨
٢٠
ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﻣ قﺎﺒﻃأ ﺔﻟﺎﺴﻏ
ﺔﺠﻣﺪ
ﹸ
ﻣ ﻪﺒﺷ قﺎﺒﻃأ ﺔﻟﺎﺴﻏ
تنبيه
تحذير
DW5500M_DD81-02437K-00_AR.indd 39DW5500M_DD81-02437K-00_AR.indd 39 2019-03-18 11:14:522019-03-18 11:14:52
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ _٤٠
ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻏ
١ . .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﻲﺟرﺎﳋا بﺎﺒﻟا ﺔﺤﺘﻓ ﻲﻓ فﺎﻄﳋا ﻊﺿو ﺔﺼﺼا ﺔﻴﺒﺸﳋا ﺔﺣﻮﻠﻟﺎﺑ فﺎﻄﳋا ﺐﻴﻛﺮﺘﺑ ﻢﻗ
٢ ..ﻲﻏاﺮﺒﻟاو ﺮﻴﻣﺎﺴﳌا ماﺪﺨﺘﺳﺎﺑ ﻲﺟرﺎﳋا بﺎﺒﻟا ﻲﻓ ﺎﻬﺘﻴﺒﺜﺘﺑ ﻢﻗ ،ﺎﻬﻧﺎﻜﻣ ﻲﻓ ﺔﺣﻮﻠﻟا ﻊﺿو ﺪﻌﺑ
.ﻢﺠﻛ ٨و ٣ ﲔﺑ ﺎﻬﻧزو حواﺮﺘﻳ ﺔﺼﺼﺨﻣ ﺔﺣﻮﻟ مﺪﺨﺘﺳا :ﻪﻴﺒﻨﺗ
.ةﺮﻴﺼﻘﻟا ﺔﻌﺑرﻷا ﻲﻏاﺮﺒﻟا ﻚﻓ
.ﺔﻠﻳﻮﻄﻟا ﺔﻌﺑرﻷا ﻲﻏاﺮﺒﻟا ﺖﻴﺒﺜﺘﺑ ﻢﻗ
ﺔﺠﻣﺪ
ﹸ
ﳌا ﻪﺒﺷ قﺎﺒﻃﻷا تﻻﺎﺴﻏ
١ . ﻊﺿﻮﻳو ﺔﺼﺼا ﺔﻴﺒﺸﳋا ﺔﺣﻮﻠﻟا ﻰﻠﻋ (أ) ﻂﻳﺮﺸﻟا ﻊﺿﻮﻳ ﺚﻴﺤﺑ ،(ب) ﻲﻔﳋا ﻖﺻﻼﻟا ﻂﻳﺮﺸﻟاو (أ) ﻲﻔﳋا ﻖﺻﻼﻟا ﻂﻳﺮﺸﻟا ﻞﺼﻓ ﺐﺠﻳ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﻲﺟرﺎﳋا بﺎﺒﻟا ﻰﻠﻋ ﺪ
ﱠ
ﺒﻠﳌا (ب) ﻂﻳﺮﺸﻟا
٢ ..ﻲﻏاﺮﺒﻟاو ﺮﻴﻣﺎﺴﳌا ماﺪﺨﺘﺳﺎﺑ ﻲﺟرﺎﳋا بﺎﺒﻟا ﻲﻓ ﺎﻬﺘﻴﺒﺜﺘﺑ ﻢﻗ ،ﺎﻬﻧﺎﻜﻣ ﻲﻓ ﺔﺣﻮﻠﻟا ﻊﺿو ﺪﻌﺑ
.ﻢﺠﻛ ٧و ٣ ﲔﺑ ﺎﻬﻧزو حواﺮﺘﻳ ﺔﺼﺼﺨﻣ ﺔﺣﻮﻟ مﺪﺨﺘﺳا :ﻪﻴﺒﻨﺗ
ﻲﻔﺧ ﻖﺻﻻ ﻂﻳﺮﺷ
ﻲﻔﺧ ﻖﺻﻻ ﻂﻳﺮﺷ
.ةﺮﻴﺼﻘﻟا ﺔﻌﺑرﻷا ﻲﻏاﺮﺒﻟا ﻚﻓ
.ﺔﻠﻳﻮﻄﻟا ﺔﻌﺑرﻷا ﻲﻏاﺮﺒﻟا ﺖﻴﺒﺜﺘﺑ ﻢﻗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
DW5500M_DD81-02437K-00_AR.indd 40DW5500M_DD81-02437K-00_AR.indd 40 2019-03-18 11:14:532019-03-18 11:14:53
٤١_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ٠٧
بﺎﺒﻟا كﺮﺒﻧز ﺪﺷ ﺔﺟرد ﻂﺒﺿ ٤ ةﻮﻄﳋا
(ﺔﺠﻣﺪ
ﹸ
ﳌا ﻪﺒﺷ وأ ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ)
Ƹť
UĮǮĘ
١ . ﻚﻴﻠﻋ ﲔﻌﺘﻴﺴﻓ ،ﺔﺼﺼا ﺔﻴﺒﺸﳋا ﺔﺣﻮﻠﻟا ﺐﻴﻛﺮﺗ ﺔﻟﺎﺣ ﻲﻓ .ﻲﺟرﺎﳋا بﺎﺒﻠﻟ ﺔﺤﻴﺤﺼﻟا ﺪﺸﻟا ﺔﺟرد ﻰﻠﻋ ﻊﻨﺼﳌا ﻲﻓ بﺎﺒﻟا تﺎﻛﺮﺒﻧز ﻂﺒﺿ ﻢﺘﻳ
.يذﻻﻮﻔﻟا ﻞﺒﻜﻟا ءﺎﺧرإ وأ ﺪﺷ ﻰﻠﻋ ﻂﺒﻀﻟا ةادأ ﺰﻴﻔﺤﺘﻟ ﻂﺒﻀﻟا ﻲﻏﺮﺑ ﻒ
ﹺ
ﺿأ .بﺎﺒﻟا كﺮﺒﻧز ﺪﺷ ﺔﺟرد ﻂﺒﺿ
٢ ..ﻊﺒﺻإ ﺔﺴﻤﻠﺑ ﻪﻌﻓر ﺪﻨﻋ ﻪﻗﻼﻏإ ﻢﺘﻳ ﻢﺛ ،ﺎ
ﹰ
ﻣﺎﲤ ﻪﺤﺘﻓ
ﺪﻨﻋ ﻲﻘﻓأ
ﹴ
ﻊﺿو ﻲﻓ بﺎﺒﻟا ﻞﻈﻳ ﺎﻣﺪﻨﻋ ﺔﻃﻮﺒﻀﻣ بﺎﺒﻟا تﺎﻛﺮﺒﻧز ﺪﺷ ﺔﺟرد نﻮﻜﺗ
DW5500M_DD81-02437K-00_AR.indd 41DW5500M_DD81-02437K-00_AR.indd 41 2019-03-18 11:14:532019-03-18 11:14:53
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ _٤٢
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ٥ ةﻮﻄﳋا
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
١ . .تﺎﻣﺎﻋﺪﻟا ﻊﺿو ﺔﻴﻔﻴﻛ ﺔﻓﺮﻌﳌ ﻢﺳﺮﻟا ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ .ﺔﻘﻓﺮ
ﹸ
ﳌا تﺎﻣﺎﻋﺪﻟا ماﺪﺨﺘﺳﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﻲﺟرﺎﳋا بﺎﺒﻟا ﻰﻠﻋ ﺔﻨﻳﺰﻟا بﺎﺑ ﺐﻴﻛﺮﺘﺑ ﻢﻗ
(ﺔﺠﻣﺪ
ﹸ
ﳌا ﻪﺒﺷ وأ ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ)
٢ . مﺪﻋ يدﺆﻳ ﺪﻗ .ﺮﺴﻳﻷاو ﻦﳝﻷا بﺎﺒﻟا ﻲﻛﺮﺒﻧز ﻂﺑر مﺎﻜﺣﻹ ﺔﻋﺎﺴﻟا برﺎﻘﻋ هﺎﲡا ﻲﻓ ﻪﺗرادإ ﻊﻣ نﻻآ حﺎﺘﻔﻣ ماﺪﺨﺘﺳﺎﺑ بﺎﺒﻟا تﺎﻛﺮﺒﻧز ﺪﺷ ﺔﺟرد ﻂﺒﻀﺑ ﻢﻗ
(ﺔﺠﻣﺪ
ﹸ
ﳌا ﻪﺒﺷ وأ ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﳌا قﺎﺒﻃﻷا تﻻﺎﺴﻐﻟ) .ﻚﺑ ﺔﺻﺎﳋا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ فﻼﺗإ ﻰﻟإ ﻚﻟﺬﺑ مﺎﻴﻘﻟا
٣ ..ةدرﺎﺒﻟا هﺎﻴﳌﺎﺑ داﺪﻣﻹا ﻂﺨﺑ هﺎﻴﳌا ﺪﻳرﻮﺗ مﻮﻃﺮﺧ ﻞﻴﺻﻮﺘﺑ ﻢﻗ
۴ ..ﻲﺤﻴﺿﻮﺘﻟا ﻢﺳﺮﻟا ﻰﻟإ عﻮﺟﺮﻟا ﻰﺟﺮ
ﹸ
ﻳ .ﻒﻳﺮﺼﺘﻟا مﻮﻃﺮﺧ ﻞﻴﺻﻮﺘﺑ ﻢﻗ
۵ ..ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻚﻠﺳ
ﻞ
ﱠ
ﺻو
۶ ..ﻞﻤﻌﻟا ﺢﻄﺳ ﺔﻓﺎﺣ ﻊﻣ ﻒﻴﺜﻜﺘﻟا ﻂﻳﺮﺷ ةاذﺎﺤﻣ ﻦﻣ ﺪﻛﺄﺘﻟا ﻰﺟﺮ
ﹸ
ﻳ .ﺔﻧاﺰﳋا ﻞﻤﻋ ﺢﻄﺳ ﻞﻔﺳأ ﻒﻴﺜﻜﺘﻟا ﻂﻳﺮﺷ ﻖﺼﻟا
٧ ..ﺢﻴﺤﺼﻟا ﺎﻬﻧﺎﻜﻣ ﻲﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻊﺿ
٨ . ةﺪﻋﺎﻗ ﻒﺼﺘﻨﻣ ﻲﻓ نﻻآ ﻲﻏﺮﺑ ﺮﻳوﺪﺗ لﻼﺧ ﻦﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻬﺟاو ﻦﻣ ﻲﻔﻠﳋا ﻲﻠﻔﺴﻟا فﺮﻄﻟا ﻂﺒﺿ ﻦﻜﳝ .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ءاﻮﺘﺳا ﻰﻠﻋ صﺮﺣا
ﲔﻴﻣﺎﻣﻷا ﲔﻴﻠﻔﺴﻟا ﲔﻓﺮﻄﻟا ر
ﹺ
دأو ﺔﺤﻄﺴﳌا ﻲﻏاﺮﺒﻠﻟ ﺎ
ﹰ
ﻜﻔﻣ مﺪﺨﺘﺳا ،ﲔﻴﻣﺎﻣﻷا ﲔﻴﻠﻔﺴﻟا ﲔﻓﺮﻄﻟا ﻂﺒﻀﻟ .نﻻآ حﺎﺘﻔﻣ ماﺪﺨﺘﺳﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ يﻮﺘﺴﺗ ﻰﺘﺣ
٩ .:ﻚﻟﺬﺑ مﺎﻴﻘﻠﻟ نﺎﺘﻘﻳﺮﻃ ﺪﺟﻮﺗ .ﺎﻬﻧﺎﻜﻣ ﻲﻓ ﺔﺘﺑﺎﺛ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ نﻮﻜﺗ نأ ﺐﺠﻳ
A ..ﺐﺸﺨﻠﻟ ﺔﺼﺼا ﻲﻏاﺮﺒﻟا ماﺪﺨﺘﺳﺎﺑ ﻞﻤﻌﻟا ﺢﻄﺴﺑ ﻪﺘ
ﹼ
ﺒﺛو ﻲﺒﻧﺎﳉا ىﺮا ﺔﺤﺘﻓ ﻲﻓ ﺐﻴﻛﺮﺘﻟا فﺎﻄﺧ ﻊﺿ :يدﺎﻌﻟا ﻞﻤﻌﻟا ﺢﻄﺳ
B . .ﻲﻏاﺮﺒﻟﺎﺑ ﺐﻧﺎﳉا ﺖ
ﹼ
ﺒﺛ :ﺖﻴﻧاﺮﳉا ﻦﻣ عﻮﻨﺼﳌا وأ ﻲﻣﺎﺧﺮﻟا ﻞﻤﻌﻟا ﺢﻄﺳ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
DW5500M_DD81-02437K-00_AR.indd 42DW5500M_DD81-02437K-00_AR.indd 42 2019-03-18 11:14:532019-03-18 11:14:53
٤٣_ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺐﻴﻛﺮﺗ ٠٧
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ءاﻮﺘﺳا ٦ ةﻮﻄﳋا
ﻲﻓ ءاﻮﺘﺳﻻا ﻦﻣ ﻖﻘﺤﺘﻟا
ﻲﻔﻠﳋاو ﻲﻣﺎﻣﻷا ﲔﺒﻧﺎﳉا
ﻲﻓ ءاﻮﺘﺳﻻا ﻦﻣ ﻖﻘﺤﺘﻟا
ﺮﺴﻳﻷاو ﻦﳝﻷا ﲔﺒﻧﺎﳉا
Ƹť
UĮǮĘ
Ƹť
UĮǮĘ
.ﻞﺴﻐﻠﻟ ءادأ ﻞﻀﻓأ ﻰﻠﻋ لﻮﺼﳊاو ﻲﻐﺒﻨﻳ ﺎﻤﻛ ﻞﺴﻐﻟا ﻒﻓرأ ﻞﻤﻌﻟ ﺔﻳﻮﺘﺴﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ نﻮﻜﺗ نأ ﺐﺠﻳ
١ ..قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ءاﻮﺘﺳا ﻦﻣ ﻖﻘﺤﺘﻠﻟ ﺢﺿﻮﻣ ﻮﻫ ﺎﻤﻛ ضﻮﳊا ﻞﺧاد ﻒﻓرﻷا ىﺮﺠﻣو بﺎﺒﻟا ﻰﻠﻋ ﺔﻳﻮﺴﺗ ناﺰﻴﻣ ﻊﺿ
٢ ..ةﺪﺣ ﻰﻠﻋ
ﹴ
ﻞﻛ ءاﻮﺘﺳﻻا ﻞﺟرأ ﻂﺒﺿ لﻼﺧ ﻦﻣ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻳﻮﺴﺘﺑ ﻢﻗ
٣ ..ﺐﻘﻋ ﻰﻠﻋ ﺎ
ﹰ
ﺳأر ﺔﻟﺎﺴﻐﻟا ﺐﻠﻘﻨﺗ ﻻ ﻰﺘﺣ رﺬﳊا ﻲ
ﹼ
ﺧﻮﺗو هﺎﺒﺘﻧﻻا ﻰﺟﺮ
ﹸ
ﻳ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻳﻮﺴﺗ ﺪﻨﻋ
.ﺎ
ﹰ
ﻴﻓﺎﺿإ ﺎ
ﹰ
ﻴﻠﻔﺳ ﺎ
ﹰ
ﻓﺮﻃ مﺪﺨﺘﺳﺎﻓ ،ﺎ
ﹰ
ﻴﻓﺎﻛ ءاﻮﺘﺳﻻا ﻞﺟرأ عﺎﻔﺗرا ﻦﻜﻳ ﻢﻟ اذإ
DW5500M_DD81-02437K-00_AR.indd 43DW5500M_DD81-02437K-00_AR.indd 43 2019-03-18 11:14:542019-03-18 11:14:54
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا _٤٤
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا
ﻰﻠﻋ تﻼﻳﺪﻌﺗ ءاﺮﺟإ ﻰﻟإ ﺪﻤﻌﺗ ﻲﻬﻓ ﻲﻟﺎﺘﻟﺎﺑو ،ﻪﻨﻴﺴﲢو ﺞﺘﻨﻤﻠﻟ ﺮﻤﺘﺴﳌا ﺮﻳﻮﻄﺘﻟا ﺔﺳﺎﻴﺳ ﺔﻌﻨﺼﳌا ﺔﻛﺮﺸﻟا ﻊﺒﺘﺗ
.ﻖﺒﺴﻣ رﺎﻄﺧإ نود زﺎﻬﳉا
ﺔﻧﺎﻴﺼﻟا ﺔﻣﺪﺨﺑ لﺎﺼﺗﻻا ﻞﺒﻗ
ﺔﻠﻜﺸﳌاﺔﻠﻜﺸﳌا ﺐﺒﺳﻞﳊا
ﻞﻤﻌﺗ ﻻ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ
• ﻊﻃﺎﻗ ﻞﻴﻄﻌﺗ ﰎ وأ ﺮﻬﺼﻨﳌا ءﺎﻔﻃإ ﰎ
.ﺔﻴﺑﺮﻬﻜﻟا ةﺮﺋاﺪﻟا
• ةﺮﺋاﺪﻟا ﻊﻃﺎﻗ ﲔﻴﻌﺗ ةدﺎﻋﺈﺑ وأ ﺮﻬﺼﻨﳌا ﻞﻴﻐﺸﺗ ةدﺎﻋﺈﺑ ﻢ
ﹸ
ﻗ
ﻲﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ كرﺎﺸﺗ ىﺮﺧأ ةﺰﻬﺟأ يأ ل
ﹺ
زأ .ﺔﻴﺑﺮﻬﻜﻟا
.ﺔﻴﺑﺮﻬﻜﻟا ةﺮﺋاﺪﻟا ﺲﻔﻧ
•.ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻞﻴﻐﺸﺗ ﻢﺘﻳ ﻢﻟ •.مﺎﻜﺣﺈﺑ ﻖﻠﻐﻣ بﺎﺒﻟا نأو قﺎﺒﻃﻷا
ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ﻦﻣ ﺪﻛﺄﺗ
ﻢﻴﻠﺳ ﻞﻜﺸﺑ ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻚﻠﺳ ﻞﻴﺻﻮﺗ ﻦﻣ ﺪﻛﺄﺗ
.ﻂﺋﺎﳊا ﺲﺒﻘﲟ
•.هﺎﻴﳌا ﻂﻐﺿ ضﺎﻔﺨﻧا • نأ ﻦﻣو ﺔﺤﻴﺤﺻ ﺔﻘﻳﺮﻄﺑ
ﹰ
ﻻﻮﺻﻮﻣ هﺎﻴﳌا د
ﹺ
رﻮ
ﹸ
ﻣ نأ ﻦﻣ ﺪﻛﺄﺗ
.ﺔﺣﻮﺘﻔﻣ هﺎﻴﳌا
ﻒﻗﻮﺘﺗ ﻻ ﻒﻳﺮﺼﺘﻟا ﺔﺨﻀﻣ
•.ءﺎﳌا ﺾﻴﻓ • ﺔﺨﻀﻣ ﻖﻠﻐﻳ ﻮﻬﻓ .ءﺎﳌا ﺾﻴﻓ ﻦﻋ ﻒﺸﻜﻠﻟ مﺎﻈﻨﻟا ﻢﻤ
ﹸ
ﺻ
.ﻒﻳﺮﺼﺘﻟا ﺔﺨﻀﻣ ﻞ
ﹺ
ﻐﺸ
ﹸ
ﻳو ﺮﻳوﺪﺘﻟا
ءﺎﺿﻮﻀﻟا
• نﻮﻜﺗ ﺎﻫرﺪﺼﻳ ﻲﺘﻟا تاﻮﺻﻷا ﺾﻌﺑ
.ﺔﻳدﺎﻋ
•.ﻒ
ﹼ
ﻈﻨﳌا بﻮﻛ ﺢﺘﻓو ﺔﻤﻋﺎﻨﻟا ﺔﻤﻌﻃﻷا مﺮﻓ ﺔﻴﻠﻤﻋ تﻮﺻ
• ا
ﹰ
ﺪﻴﺟ ﺔﻠﺴﻟﺎﺑ ﺔﺘ
ﹶ
ﺒﺜ
ﹸ
ﻣ ﺖﺴﻴﻟ ﻲﻧاوﻷا
ﻞﺧاد ﺮﻴﻐﺻ ﺎﻣ
ﹲ
ءﻲﺷ ﻂﻘﺳ ﺎﲟر وأ
.ﺔﻠﺴﻟا
•.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ءﻲﺷ ﻞﻛ تﺎﺒﺛ ﻦﻣ ﺪﻛﺄﺗ
•.كﺮﶈا ﲔﻨﻃ • ﺮﺜﻜﺗ ﻻ ﺖﻨﻛ اذإ .مﺎﻈﺘﻧﺎﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ماﺪﺨﺘﺳا ﻢﺘﻳ ﻢﻟ
دﺮﻄﻟاو ءﻞﳌا ﻰﻠﻋ ﺎﻬﻄﺒﻀﺗ نأ ﺮﻛﺬﺘﻓ ،ﺎﻬﻣاﺪﺨﺘﺳا ﻦﻣ
.ةداﺪﺴﻟا ﺔﺑﻮﻃﺮﺑ ظﺎﻔﺘﺣﻻا ﻰﻠﻋ ﺪﻋﺎﺴﻳ ﺎﳑ ،ﺎ
ﹰ
ﻴﻋﻮﺒﺳأ
ضﻮﳊﺎﺑ نﻮﺑﺎﺻ ىوﺎﻏر
•.ﻢﺋﻼﻣ ﺮﻴﻏ ﻒ
ﹼ
ﻈﻨﳌا • ﻰﺘﺣ ﻂﻘﻓ قﺎﺒﻃﻷا تﻻﺎﺴﻐﺑ صﺎﳋا ﻒ
ﹼ
ﻈﻨﳌا مﺪﺨﺘﺳا
.نﻮﺑﺎﺼﻟا ىوﺎﻏر ن
ﹸ
ﻮﻜﺗ ﺐﻨﺠﺘﺗ
•.ﺮﺨﺒﺘﺗ ىوﺎﻏﺮﻟا كﺮﺗاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺢﺘﻓا ،اﺬﻫ ثﺪﺣ اذإو
• ﺔﻟﺎﺴﻏ ﻖﻠﻏأ .ضﻮﳊا ﻰﻟإ درﺎﺒﻟا ءﺎﳌا ﻦﻣ ﺎ
ﹰ
ﻧﻮﻟﺎﺟ ﻒﺿأ
(ﻊﻘﻧ) soak ﻞﺴﻏ ةرود ﻞﻴﻐﺸﺗ أﺪﺑا ﻢﺛ ،ﺎﻬﻠﻔﻗأو قﺎﺒﻃﻷا
.ﺮﻣﻷا مﺰﻟ اذإ ﺔﻴﻠﻤﻌﻟا رﺮﻛ .هﺎﻴﳌا ﻎﻳﺮﻔﺘﻟ
•.ﻒﻄﺸﻟا ةادﺄﺑ ﺾﻴﻓ •.لﺎﳊا ﻲﻓ ﻒﻄﺸﻟا ةادأ ﺎ
ﹰ
ﻤﺋاد ﻒﻈﻧ
ﺦﻄﻠ
ﹸ
ﻣ ﻲﻠﺧﺪﻟا ضﻮﳊا
•.ﺔﻐﺒﺻ ﻰﻠﻋ يﻮﺘﺤﻳ ﻒ
ﹼ
ﻈﻨﻣ ماﺪﺨﺘﺳا •.ﺔﻐﺒﺻ ﻰﻠﻋ يﻮﺘﺤﻳ ﻻ م
ﹶ
ﺪﺨﺘﺴ
ﹸ
ﳌا ﻒ
ﹼ
ﻈﻨﳌا نأ ﻦﻣ ﺪﻛﺄﺗ
قﺎﺒﻃﻷا ﺐﻴﻃﺮﺗ ﻢﺘﻳ ﻢﻟ
•.غرﺎﻓ ﻒﻄﺸﻟا ةادأ ع
ﹺ
زﻮ
ﹸ
ﻣ •.ﻒﻄﺸﻟا ةادأ ع
ﹺ
زﻮ
ﹸ
ﻣ ءﻼﺘﻣا ﻦﻣ ﺪﻛﺄﺗ
ةﺪﺋﺎﳌا ﻲﻧاوأو قﺎﺒﻃﻷا ﺔﻓﺎﻈﻧ مﺪﻋ
•.ﺐﺳﺎﻨﻣ ﺮﻴﻏ ﺞﻣﺎﻧﺮﺒﻟا •.ﺔﻓﺎﺜﻛ ﺮﺜﻛأ ﻞﺴﻏ ﺞﻣﺎﻧﺮﺑ دﺪﺣ
•.ﺐﺳﺎﻨﻣ ﺮﻴﻏ ﻒﻓرﻷا ﻞﻴﻤﲢ • عرذأو ﻒ
ﹼ
ﻈﻨﳌا ع
ﹺ
زﻮ
ﹸ
ﻣ ﺎﻬﺑ مﻮﻘﻳ ﻲﺘﻟا ﺔﻴﻠﻤﻌﻟا نأ ﻦﻣ ﺪﻛﺄﺗ
.ةﺮﻴﺒﻜﻟا نﻮﺤﺼﻟا ﺎﻬﺿﺮﺘﻌﺗ ﻢﻟ شﺮﻟا
DW5500M_DD81-02437K-00_AR.indd 44DW5500M_DD81-02437K-00_AR.indd 44 2019-03-18 11:14:542019-03-18 11:14:54
٤٥_ ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا ٠٨
ﺔﻠﻜﺸﳌاﺔﻠﻜﺸﳌا ﺐﺒﺳﻞﳊا
ﻲﻧاوأو باﻮﻛأ ﻰﻠﻋ تﺎﺨﻄﻟو ﻊﻘﺑ
ةﺪﺋﺎﳌا
١ ..ةﺪﺸﺑ ﺮ
ﹺ
ﺴ
ﹶ
ﻋ ءﺎﳌا
٢ ..ةد
ﹶ
رﻮ
ﹸ
ﳌا هﺎﻴﳌا ةراﺮﺣ ﺔﺟرد ضﺎﻔﺨﻧا
٣ ..ﺎﻬﺘﻗﺎﻃ قﻮﻓ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻤﲢ
۴ . ﺮﻴﻏ تاودﺄﺑ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻤﲢ
.ﺔﺒﺳﺎﻨﻣ
۵ ..ﺐﻃر وأ ﱘﺪﻗ ﻒ
ﹼ
ﻈﻨﻣ ماﺪﺨﺘﺳا
۶ ..غرﺎﻓ ﻒﻄﺸﻟا ةادأ ع
ﹺ
زﻮ
ﹸ
ﻣ
٧ . ﺮﻴﻏ ﺔﻣﺪﺨﺘﺴﳌا ﻒ
ﹼ
ﻈﻨﳌا ﺔﻴﻤﻛ
.ﺔﺒﺳﺎﻨﻣ
:ﺔﻴﺟﺎﺟﺰﻟا ﻲﻧاوﻷا ﻰﻠﻋ ﻦﻣ ﻊﻘﺒﻟا ﺔﻟازﻹ
١ ..قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﺔﻴﻧﺪﻌﳌا تاودﻷا ﻊﻴﻤﺟ ج
ﹺ
ﺮﺧ
ﹶ
أ
٢ ..ﻒ
ﹼ
ﻈﻨﳌا ﻒﻀﺗ ﻻ
٣ ..ﻞﺴ
ﹶ
ﻏ ةرود لﻮﻃأ ﺮﺘﺧا
۴ . ﻰﻟإ ١٨ ﻦﻣ ﻞﻤﻌﺗ ﺎﻬﻛﺮﺗاو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺘﺑ ﻢ
ﹸ
ﻗ
ﺔﻠﺴﻐﻟا قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ أﺪﺒﺘﺳ ﺎﻫﺪﻌﺑ ﻢﺛ ،ﺔﻘﻴﻗد ٢٢
.ﺔﻴﺴﻴﺋﺮﻟا
۵ . ﺔﻟﺎﺴﻏ عﺎﻗ ﻲﻓ ﺾﻴﺑﻷا ﻞﳋا ﻦﻣ ﲔﺑﻮﻛ ﺐﻜﺳاو بﺎﺒﻟا ﺢﺘﻓا
.قﺎﺒﻃﻷا
۶ . اذإو .ﻞﺴﻐﻟا ةرود ﻞﻤﻜﺗ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ كﺮﺗاو بﺎﺒﻟا ﻖﻠﻏأ
،ﺔﻘﺑﺎﺴﻟا تاﻮﻄﳋا رﺮﻛ :ﺾﻴﺑﻷا ﻞﺨﻠﻟ
ﹰ
ﻻﻮﻌﻔﻣ ﺪﲡ ﻢﻟ
ﺾﻣﺎﺣ تارﻮﻠﺑ ﻦﻣ (ﻞﻣ ٦٠) بﻮﻛ ١ / ٤ مﺪﺨﺘﺳا ﻂﻘﻓ ﻦﻜﻟو
.ﻞﳋا ﻦﻣ
ﹰ
ﻻﺪﺑ ﻚﻳﺮﺘﺴﻟا
ﺔﻴﺟﺎﺟﺰﻟا ﻲﻧاوﻷا ﻰﻠﻋ ﻢﻴﻏ دﻮﺟو
• ةﺮﻴﺒﻛ ﺔﻴﻤﻛ ﻊﻣ ﺮﻴﺴﻳ ءﺎﻣ ماﺪﺨﺘﺳا
.ﻒ
ﹼ
ﻈﻨﳌا ﻦﻣ
• ةرود دﺪﺣو ﺮﻴﺴﻴﻟا ءﺎﳌا ماﺪﺨﺘﺳا ﺪﻨﻋ ﻞﻗأ ﺎ
ﹰ
ﻔ
ﹼ
ﻈﻨﻣ ﻊﺿ
ﺔﻴﺟﺎﺟﺰﻟا ﻲﻧاوﻷا ﻞﻴﺴﻏ ﺪﻨﻋ قﻼﻃﻹا ﻰﻠﻋ ﺮﺼﻗﻷا ﻞﺴﻐﻟا
.ﺔﻓﺎﻈﻧ ﻞﻀﻓأ ﻰﻠﻋ ﻞﺼﲢ ﻰﺘﺣ
وأ نﻮﻠﻟا ﺔﻴﻨﺑ تﺎﺨﻄﻟ دﻮﺟو
ﺔﻴﻠﺧاﺪﻟا ﺢﻄﺳﻷا ﻰﻠﻋ ءاﺮﻔﺻ
•.ةﻮﻬﻘﻟا وأ يﺎﺸﻟا ﻊﻘﺑ • ٣و
ﺾ
ﹼ
ﻴﺒﻣ لﻮﻠﺤﻣ ﻦﻣ بﻮﻛ ١ / ٢ ماﺪﺨﺘﺳﺎﺑ ﻚﻳﺪﻴﺑ ﻊﻘﺒﻟا ل
ﹺ
ز
ﹶ
أ
.ﺊﻓاﺪﻟا ءﺎﳌا ﻦﻣ باﻮﻛأ
ﻲﻛ ﻞﺴﻐﻟا ةرود ﺪﻌﺑ ﺔﻘﻴﻗد ٢٠ ةﺪﳌ رﺎﻈﺘﻧﻻا ﻚﻴﻠﻋ :ﺮﻳﺬﲢ
هﺬﻫ عﺎﺒﺗا مﺪﻋ يدﺆﻴﺳ ؛دﺮﺒﺗ ﻰﺘﺣ ﲔﺨﺴﺘﻟا ﺮﺻﺎﻨﻋ كﺮﺘﺗ
.قوﺮﳊ ضﺮﻌﺘﻟا ﺮﻄﳋ ﻚﻀﻳﺮﻌﺗ ﻰﻟإ ةﻮﻄﳋا
• ﺦﻄﻠﻳ ﺪﻗ ءﺎﳌا ﻲﻓ ﺪﻳﺪﳊا ﻦﻣ
ﹴ
ناوأ ﻊﺿو
.ءﻲﺷ ﻞﻛ
• ﺢﻴﺷﺮﺗ مﺎﻈﻧ ﺐﻴﻛﺮﺘﻟ هﺎﻴﻣ ﺔﻴﻘﻨﺗ ﺔﻛﺮﺸﺑ لﺎﺼﺗﻻا ﻚﻴﻠﻋ
.ﻚﻳﺪﻟ هﺎﻴﳌﺎﺑ داﺪﻣﻹا رﺪﺼﻣ ﻲﻓ صﺎﺧ هﺎﻴﻣ
ﺢﻄﺴﻟا ﻰﻠﻋ ءﺎﻀﻴﺑ ﺔﻌﻘﺑ
ﻲﻠﺧاﺪﻟا
•.ﺮ
ﹺ
ﺴ
ﹶ
ﻌﻟا ءﺎﳌا ندﺎﻌﻣ • مﺪﺨﺘﺳاو ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﻲﻠﺧاﺪﻟا ءﺰﳉا ﻒﻴﻈﻨﺘﺑ ﻢﻗ
ﺔﺠﻨﻔﺳإ مﺪﺨﺘﺳا وأ قﺎﺒﻃﻷا تﻻﺎﺴﻐﺑ ﺎ
ﹰ
ﺻﺎﺧ ﺎ
ﹰ
ﻔ
ﹼ
ﻈﻨﻣ
.ﺔﻴﻃﺎﻄﻣ تازﺎﻔﻗ
ﹺ
ﺪﺗراو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻒ
ﹼ
ﻈﻨﻣ ﻊﻣ ﺔﻠﻠﺒﻣ
قﺎﺒﻃﻷا تﻻﺎﺴﻏ ﻖﻴﺣﺎﺴﻣ ﺮﻴﻏ ﻒﻈﻨﻣ يأ ا
ﹰ
ﺪﺑأ مﺪﺨﺘﺴﺗ ﻻ
.ىوﺎﻏﺮﻟا ن
ﹸ
ﻮﻜﺗ ﺮﻄﺧ ﺐﻨﺠﺘﺘﻟ
ﻖﻠﻐﻳ ﻻ ﻒ
ﹼ
ﻈﻨﳌا ع
ﹼ
زﻮﻣ ءﺎﻄﻏ
• "OFF" ﻊﺿو ﻦﻋ "Dial" صﺮﻗ ﻒﻠﺘﺨﻳ
.ﻞﻴﻐﺸﺘﻟا فﺎﻘﻳإ
• كﺮﺣو ﻞﻴﻐﺸﺘﻟا فﺎﻘﻳإ "OFF" ﻊﺿو ﻰﻟإ "Dial"صﺮﻗ ر
ﹺ
دأ
.رﺎﺴﻴﻟا ﻰﻟإ بﺎﺒﻟا ﻞﻔﻗ
ع
ﹼ
زﻮﳌا ﻞﺧاد ﻒ
ﹼ
ﻈﻨﻣ
ﺎﻳﺎﻘﺑ
•.قﺎﺒﻃﻷﺎﺑ ع
ﱢ
زﻮ
ﹸ
ﳌا داﺪﺴﻧا •.ﺔﻤﺋﻼﻣ ﺔﻘﻳﺮﻄﺑ قﺎﺒﻃﻷا ﻊﺿو ةدﺎﻋإ
رﺎﺨﺒﻟا
•.ﺔﻳدﺎﻋ ةﺮﻫﺎﻇ • ﻦﻣ ﻚﻟذو هﺎﻴﳌا ﻒﻳﺮﺼﺗو ﻒﻴﻔﺠﺘﻟا ءﺎﻨﺛأ رﺎﺨﺒﻟا ﺾﻌﺑ ﻲﺗﺄﻳ
.بﺎﺒﻟا ﻞﻔﻗ راﻮﺠﺑ ﺐﻘﺛ لﻼﺧ
ﻰﻠﻋ ﺔﻳدﺎﻣرو ءادﻮﺳ تﺎﻣﻼﻋ
قﺎﺒﻃﻷا
•.قﺎﺒﻃﻷﺎﺑ مﻮﻴﻨﻣﻮﻟﻷا تاودﻷا كﺎﻜﺘﺣا •.تﺎﻣﻼﻌﻟا ﻚﻠﺗ ﺔﻟازﻹ ﻖﻴﻗر ﻂﺷﺎﻛ ﻒﻈﻨﻣ مﺪﺨﺘﺳا
ضﻮﳊا عﺎﻗ ﻲﻓ ءﺎﻣ دﻮﺟو
•.ﻲﻌﻴﺒﻃ ﺮﻣأ اﺬﻫو • ﻲﻓ جﺮا لﻮﺣ ﻒﻴﻈﻨﻟا ءﺎﳌا ﻦﻣ ﺔﻴﻠﻗ ﺔﻴﻤﻛ دﻮﺟو ﻆﻓﺎﺤﻳ
.ةداﺪﺴﻟا ﺔﺟوﺰﻟ ﻰﻠﻋ ضﻮﳊا عﺎﻗ
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺐﻳﺮﺴﺗ
• تﺎﻓﺎﺿإ ﺾﻴﻓ وأ هﺮﺧآ ﻦﻋ ع
ﹺ
زﻮ
ﹸ
ﳌا ءﻼﺘﻣا
.ﻒﻄﺸﻟا
•،هﺮﺧآ ﻦﻋ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ع
ﹺ
زﻮ
ﹸ
ﻣ ءﻞﻣ مﺪﻋ ﻰﻠﻋ صﺮﺣا
ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ ﻦﻋ ﻢﺟﺎﻨﻟا ماﺪﺨﺘﺳﻻا ﻲﻓ طاﺮﻓﻹا
نﻷ
.ﺎ
ﹰ
ﻀﻴﻓ ﺐﺒﺴﻳ ﺪﻗ ﺐﻜﺴﻨﳌا
.ﺔﺒﻃر شﺎﻤﻗ ﺔﻌﻄﻗ ماﺪﺨﺘﺳﺎﺑ بﺎﻜﺴﻧا يأ ﺢﺴﻣا
•.ﺔﻳﻮﺘﺴﻣ ﺖﺴﻴﻟ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ •.
ﹴ
ﻮﺘﺴﻣ
ﹴ
ﺢﻄﺳ ﻰﻠﻋ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ نأ ﻦﻣ ﺪﻛﺄﺗ
DW5500M_DD81-02437K-00_AR.indd 45DW5500M_DD81-02437K-00_AR.indd 45 2019-03-18 11:14:542019-03-18 11:14:54
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا _٤٦
ﺔﻠﻜﺸﳌاﺔﻠﻜﺸﳌا ﺐﺒﺳﻞﳊا
ﻞﻴﻐﺸﺘﻟا ﺪﻨﻋ ﻞﻤﻌﺗ ﻻ رارزﻷا
•.حﻮﺘﻔﻣ بﺎﺒﻟا • رﺰﻟا ءﺎﻨﺜﺘﺳﺎﺑ ﻞﻤﻌﺗ ﻻ رارزﻷا نﺈﻓ ،ﺎ
ﹰ
ﺣﻮﺘﻔﻣ بﺎﺒﻟا نﻮﻜﻳ ﺎﻣﺪﻨﻋ
.رﺰﻟا ﻰﻠﻋ ﻂﻐﺿاو بﺎﺒﻟا ﻖﻠﻏأ اﺬﻟ (ﻞﻴﻐﺸﺗ) POWER
•.ﻢﻜﺤﺘﻟا ﻞﻔﻗ ﺔﻔﻴﻇو ﺪﻳﺪﲢ ﻢﺘﻳ • .رارزﻷا ﺐﻴﺠﺘﺴﺗ ﻻ ،ﻢﻜﺤﺘﻟا ﻞﻔﻗ ﺔﻔﻴﻇو ﺪﻳﺪﲢ ﺪﻨﻋ
ﻦﻳرﺰﻟا ﻰﻠﻋ راﺮﻤﺘﺳﺎﺑ ﻂﻐﺿا ،ﺔﻔﻴﻇﻮﻟا هﺬﻫ ﺔﺣﺎﺗﻹ
.
ﹴ
ناﻮﺛ (٣) ثﻼﺛ ةﺪﳌ ءﺪﺒﻟا ﻞﻴﺟﺄﺗو تﺎﻧﻮﻜﳌا دﺪﻌﺘﻣ صﺮﻘﻟا
ةدﺎﻋإ ﺪﻨﻋ ﻢﻜﺤﺘﻟا ﻞﻔﻗ ﺔﻔﻴﻇو ﻞﻤﻌﺗ ،ﻚﻟذ ﻰﻟإ ﺔﻓﺎﺿﻹﺎﺑ
.ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟا ﻚﻠﺳ ﻞﻴﺻﻮﺗ
.ﺔﻧﺎﻴﺼﻟا ﺔﻣﺪﺨﺑ ﻚﻟﺎﺼﺗا ﻞﺒﻗ ﺮﺧآ ﺎ
ﹰ
ﺠﻣﺎﻧﺮﺑ بﺮﺟ .ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟﺎﺑ ﻞﻴﺴﻐﻟا ءادأ ﺔﺠﻴﺘﻧ ﻖﻠﻌﺘﺗ ﺎﲟر
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا
DW5500M_DD81-02437K-00_AR.indd 46DW5500M_DD81-02437K-00_AR.indd 46 2019-03-18 11:14:542019-03-18 11:14:54
٤٧_ ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا
ﺎﻬﻠﺣو ﻞﻛﺎﺸﳌا فﺎﺸﻜﺘﺳا ٠٨
تﺎﻣﻮﻠﻌﳌا زﻮﻣر
.كرﺎﻄﺧﻹ تﺎﻣﻮﻠﻌﳌا زﻮﻣر زﺎﻬﳉا ضﺮﻌﻴﺳ ،ﻞﻄﻋ ثوﺪﺣ ﺪﻨﻋ
زﻮﻣﺮﻟاﻰﻨﻌﳌاﺔﻠﻤﺘﶈا بﺎﺒﺳﻷا
4C
هﺎﻴﳌا داﺪﻣإ ﻦﻣ ﻖﻘﺤﺘﻟا
ضﺎﻔﺨﻧا وأ هﺎﻴﳌا ﻞﺧﺪﻣ داﺪﺴﻧا وأ هﺎﻴﳌا ﺮﻴﺑﺎﻨﺻ ﺢﺘﻓ مﺪﻋ
هﺎﻴﳌا ﻂﻐﺿ
LC
بﺮﺴﺗ.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ءاﺰﺟأ ﺾﻌﺑ ﻦﻣ ب
ﹼ
ﺮﺴﺗ ثوﺪﺣ
HC
ﺔﺑﻮﻠﻄﳌا ةراﺮﳊا ﺔﺟرد ﻰﻟإ لﻮﺻﻮﻟا ﻢﺘﻳ ﻢﻟﻞ
ﹼ
ﻄﻌﻣ ﲔﺨﺴﺘﻟا ﺮﺼﻨﻋ
PC
ﻢﻴﺴﻘﺘﻟا مﺎﻤﺻ ﻞ
ﹼ
ﻄﻌﺗﻢﻴﺴﻘﺘﻟا مﺎﻤﺻ ﻞ
ﹼ
ﻄﻌﺗ
AC
ﺔﺣﻮﻟو ﺔﻴﺴﻴﺋﺮﻟا ﺔﻋﻮﺒﻄﳌا ةﺮﺋاﺪﻟا ﺔﺣﻮﻟ
ﲔﺑ لﺎﺼﺗﻻا ﻞﺸﻓ
ﺔﻴﻋﺮﻔﻟا ﺔﻋﻮﺒﻄﳌا ةﺮﺋاﺪﻟا
ﻞﻴﺻﻮﺘﻟا كﻼﺳﺄﺑ ﻒﻠﺗ وأ ﺔﺣﻮﺘﻔﻣ ﺔﻴﺋﺎﺑﺮﻬﻜﻟا ةﺮﺋاﺪﻟا
bC2
ﻞﻳﻮﻃ
ﹴ
ﺖﻗﻮﻟ رﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟاﺔﻴﻧﺎﺛ ٣٠ ةﺪﳌ رﺰﻟا ﻰﻠﻋ ﻂﻐﻀﻟا
هﺎﻴﳌا ﺮﻤﻏ ﺐﺒﺴﺑ ءﺎﻋﻮﻟا ةﺪﻋﺎﻗ ﻲﻓ هﺎﻴﻣ كﺎﻨﻫ ﺖﻧﺎﻛ اذإو .ﺔﻧﺎﻴﺼﻟا ﺔﻣﺪﺨﺑ لﺎﺼﺗﻻا ﻞﺒﻗ ﻲﺴﻴﺋﺮﻟا هﺎﻴﳌا درﻮﻣ ﻖﻠﻏﺄﻓ ،زﺎﻬﳉا ءﺎﳌا ﺮﻤﻏو ثﺪﺣ اذإ :ﺮﻳﺬﲢ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ةدﺎﻋإ ﻞﺒﻗ ءﺎﳌا ﺔﻟازإ ﺐﺠﻳ ﻪﻧﺈﻓ ،ﻂﻴﺴﺑ
ﹴ
بﺎﻜﺴﻧا ﺐﺒﺴﺑ ﻰﺘﺣ وأ
DW5500M_DD81-02437K-00_AR.indd 47DW5500M_DD81-02437K-00_AR.indd 47 2019-03-18 11:14:542019-03-18 11:14:54
ﻖﺤﻠﳌا _٤٨
ﻖﺤﻠﳌا
تﺎﻔﺻاﻮﳌا
زاﺮﻄﻟا
DW60M6050FS
DW60M6050FW
DW60M6040FS
DW60M6040FW
DW60M6050US
DW60M6050UW
DW60M6051US
DW60M6051UW
DW60M6040US
DW60M6040UW
DW60M6050SS
DW60M6050BB
DW60M6040BB
عﻮﻨﻟا
ﺔﻠﻘﺘﺴﻣ
ﺢﻄﺳ ﺖﲢ ﺔﺒ
ﹼ
ﻛﺮﻣ
ﻞﻤﻌﻟا
ﺔﺠﻣﺪ
ﹸ
ﻣ ﻪﺒﺷﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﻣ
ﺔﻗﺎﻄﻟا
ﺰﺗﺮﻫ ٥٠ ~ ﺖﻟﻮﻓ ٢٤٠-٢٢٠
هﺎﻴﳌا ﻂﻐﺿ
لﺎﻜﺳﺎﺑﺎﺠﻴﻣ ١٫٠ ~ ٠٫٠٤
ﺔﻗﺎﻄﻟا ماﺪﺨﺘﺳا لﺪﻌﻣ
طاو ٢١٠٠ ﻰﻟإ ١٧٦٠
ﻦﺧﺎﺴﻟا ءﺎﳌا ﻞﻴﺻﻮﺗ
ﺔﻳﻮﺌﻣ ﺔﺟرد ٦٠ ﻰﺼﻗأ ﺪﺣ
ﻒﻴﻔﺠﺘﻟا عﻮﻧ
ﻒﺜﻜﻣ ﻒﻴﻔﲡ مﺎﻈﻧ
ﻞﺴﻐﻟا عﻮﻧ
شﺮﻟا تﺎﺤﺘﻓ نارود
(عﺎﻔﺗرﻻا × ﻖﻤﻌﻟا ×
ضﺮﻌﻟا) دﺎﻌﺑﻷا
ﱈ ٨٤٥ × ٦٠٠ × ٥٩٨ﱈ ٨١٥ × ٥٧٠ × ٥٩٨ ﱈ ٨١٥ × ٥٥٠ × ٥٩٨
ﺔﻟﺎﺴﻏ ﺔﻌﺳ
قﺎﺒﻃﻷا
DW60M6050ا
ﹰ
دﺮﻓ ١٤ ﺔﻌﺳ
DW60M6051ا
ﹰ
دﺮﻓ ١٤ ﺔﻌﺳ
DW60M6040ا
ﹰ
دﺮﻓ ١٣ ﺔﻌﺳ
نزﻮﻟا
ﺔﻠﻘﺘﺴﻣﺔﺌﺒﻌﺗ نود ﻢﺠﻛ ٥٠
ﻞﻤﻌﻟا ﺢﻄﺳ ﺖﲢ ﺔﺒ
ﹼ
ﻛﺮﻣ
ﺔﺌﺒﻌﺗ نود ﻢﺠﻛ ٤٣ ﺔﺠﻣﺪ
ﹸ
ﻣ ﻪﺒﺷ
ﻞﻣﺎﻜﻟﺎﺑ ﺔﺠﻣﺪ
ﹸ
ﻣ
DW5500M_DD81-02437K-00_AR.indd 48DW5500M_DD81-02437K-00_AR.indd 48 2019-03-18 11:14:552019-03-18 11:14:55
٤٩_ ﻖﺤﻠﳌا
ﻖﺤﻠﳌا ٠٩
ﺞﺘﻨﳌا دﺎﻌﺑأ
٦٠٠
٨٤٥
١١٧٥
٥٩٨
٥٧٠
٨١٥
١١٥٠
٥٩٨
DW60M6050FS/DW60M6050FW
DW60M6040FS/DW60M6040FW
DW60M6050US/DW60M6050UW
DW60M6051US/DW60M6051UW
DW60M6040US/DW60M6040UW
DW60M6050SS
٥٥٠
٥٩٨
٨١٥
١١٥٠
DW60M6050BB/DW60M6040BB
DW5500M_DD81-02437K-00_AR.indd 49DW5500M_DD81-02437K-00_AR.indd 49 2019-03-18 11:14:552019-03-18 11:14:55
رﺎﻴﻌﳌا رﺎﺒﺘﺧا _٥٠
DW60M6050/DW60M6051
:ﻲﻟﺎﺘﻟﺎﻛ IEC 60436 ﻊﻣ ﺔﻘﺑﺎﻄﺘﳌا ﻖﻓاﻮﺘﻟا رﺎﺒﺘﺧا تﺎﻣﻮﻠﻌﻣ
•دﺮﻓ ١٤ :قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻌﺳ
•IEC 60436 :ﺮﻴﻳﺎﻌﳌا رﺎﺒﺘﺧا
•ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻰﻟإ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻊﺿو
•يدﺎﺼﺘﻗا :ﻞﺴﻐﻟا ةرود
•ﺪﺟﻮﻳ ﻻ :ﺔﻴﻓﺎﺿإ تارﺎﻴﺧ
•٥ :ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ داﺪﻋإ
•H3 :هﺎﻴﳌا ﻲﻘﻨﻣ داﺪﻋإ
•ﻢﺟ ٣٠ ﻲﺴﻴﺋﺮﻟا ﻞﺴﻐﻟا + تﺎﻣاﺮﺟ ٥ ﻲﻟوﻷا ﻞﺴﻐﻟا :يدﺎﻌﻟا ﻒ
ﹼ
ﻈﻨﳌا ﺔﻋﺮﺟ
•ﻞﻔﺳﻷﺎﺑ ﺔﻴﺤﻴﺿﻮﺘﻟا تﺎﻣﻮﺳﺮﻟا ﻰﻟإ ﺮﻈﻧا ،تاودﻷا ﺐﻴﺗﺮﺘﻟ
<ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا><ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا>
<ﺔﻴﻀﻔﻟا تاودﻷا ﺔﻠﺳ>
٣
٧
۵
٢
٢
٣
٨
۶
۶
٢
٢
۴
١
١
١
ءﺎﺴﳊا ﻖﻋﻼﻣ
٢
تﺎﻛﻮﺸﻟا
٣
ﲔﻛﺎﻜﺴﻟا
۴
يﺎﺸﻟا ﻖﻋﻼﻣ
۵
ىﻮﻠﳊا ﻖﻋﻼﻣ
۶
ةﺪﺋﺎﳌا ﻖﻋﻼﻣ
٧
ةﺪﺋﺎﳌا تﺎﻛﻮﺷ
٨
ءﺎﺴﳊا ﺔﻓﺮﻐﻣ
رﺎﻴﻌﳌا رﺎﺒﺘﺧا
DW5500M_DD81-02437K-00_AR.indd 50DW5500M_DD81-02437K-00_AR.indd 50 2019-03-18 11:15:002019-03-18 11:15:00
٥١_ رﺎﻴﻌﳌا رﺎﺒﺘﺧا
DW60M6040
:ﻲﻟﺎﺘﻟﺎﻛ IEC 60436 ﻊﻣ ﺔﻘﺑﺎﻄﺘﳌا ﻖﻓاﻮﺘﻟا رﺎﺒﺘﺧا تﺎﻣﻮﻠﻌﻣ
•دﺮﻓ ١٣ :قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻌﺳ
•IEC 60436 :ﺮﻴﻳﺎﻌﳌا رﺎﺒﺘﺧا
•ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا ﻰﻟإ ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا ﻊﺿو
•يدﺎﺼﺘﻗا :ﻞﺴﻐﻟا ةرود
•ﺪﺟﻮﻳ ﻻ :ﺔﻴﻓﺎﺿإ تارﺎﻴﺧ
•٥ :ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣ داﺪﻋإ
•H3 :هﺎﻴﳌا ﻲﻘﻨﻣ داﺪﻋإ
•ﻢﺟ ٢٧٫٥ ﻲﺴﻴﺋﺮﻟا ﻞﺴﻐﻟا + تﺎﻣاﺮﺟ ٥ ﻲﻟوﻷا ﻞﺴﻐﻟا :يدﺎﻌﻟا ﻒ
ﹼ
ﻈﻨﳌا ﺔﻋﺮﺟ
•ﻞﻔﺳﻷﺎﺑ ﺔﻴﺤﻴﺿﻮﺘﻟا تﺎﻣﻮﺳﺮﻟا ﻰﻟإ ﺮﻈﻧا ،تاودﻷا ﺐﻴﺗﺮﺘﻟ
<ﺔﻳﻮﻠﻌﻟا ﺔﻠﺴﻟا><ﺔﻴﻠﻔﺴﻟا ﺔﻠﺴﻟا>
<ﺔﻴﻀﻔﻟا تاودﻷا ﺔﻠﺳ>
٨
۵۵۵۵۵۵۵۵
۴۴
١
١١ ۴
١
١۴١
٢
۴۴ ۴۴
۴۴۴
١
۴
٢۵
۵۵٧
۵
٣
١
١١ ١ ١
٣
١
ءﺎﺴﳊا ﻖﻋﻼﻣ
٢
تﺎﻛﻮﺸﻟا
٣
ﲔﻛﺎﻜﺴﻟا
۴
يﺎﺸﻟا ﻖﻋﻼﻣ
۵
ىﻮﻠﳊا ﻖﻋﻼﻣ
۶
ةﺪﺋﺎﳌا ﻖﻋﻼﻣ
٧
ةﺪﺋﺎﳌا تﺎﻛﻮﺷ
٨
ءﺎﺴﳊا ﺔﻓﺮﻐﻣ
DW5500M_DD81-02437K-00_AR.indd 51DW5500M_DD81-02437K-00_AR.indd 51 2019-03-18 11:15:012019-03-18 11:15:01
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﺻﺎﳋا تﺎﺤﻠﻄﺼﳌا _٥٢
قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﺑ ﺔﺻﺎﳋا تﺎﺤﻠﻄﺼﳌا
١ .ناروﺪﻟا كﺮﺤﻣ
ﻦﻣ ﻲﻟﺎﻌﻟا ﻂﻐﻀﻟا ﺎ
ﹰ
ﻣﺪﺨﺘﺴﻣ هﺎﻴﳌا لﺎﺧدﺈﺑ مﻮﻘﻳو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻴﺿرأ ﻲﻓ ﺔﻴﻘﺒﺘﳌا هﺎﻴﳌا ﺺﺘﳝ كﺮﺤﻣ ﻮﻫ
.ﻰﻠﻔﺴﻟاو ﻰﻄﺳﻮﻟا تﺎﻫﻮﻔﻠﻟ يﻮﻠﻌﻟا ءﺰﳉا ﻰﺘﺣو ﺔﻴﻠﺧاﺪﻟا هﺎﻴﳌا تاﺮﳑ لﻼﺧ
٢ .ﻒﻳﺮﺼﺘﻟا ﺔﺨﻀﻣ.ﺎﻬﻠﻴﻐﺸﺗ ءﺎﻨﺛأ قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﺖﻧﻮﻜﺗ ﻲﺘﻟا ﺔﺛﻮﻠﳌا هﺎﻴﳌا ﻒﻳﺮﺼﺘﺑ مﻮﻘﺗ ﺔﺨﻀﻣ ﻲﻫ
٣ .نﺎﺨﺴﻟا
ﺔﻴﻟﺎﻌﻓ ةدﺎﻳﺰﻟ ﺔﻘﻓﺪﺘﳌا هﺎﻴﳌا ﲔﺨﺴﺘﺑ مﻮﻘﻳ ﺚﻴﺣ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد هﺎﻴﳌا تاﺮﳑ ﻰﻠﻋ نﺎﺨﺴﻟا ﻊﺿو ﻢﺘﻳ
.ﻞﺴﻐﻟا
۴ .ﻖﻓﺪﺘﻟا لﺪﻌﻣ سﺎﻴﻗ زﺎﻬﺟ
ﺔﻠﻣﺎﻜﺘﳌا لﻮﻫ ةﺮﺋاد ﺮﻌﺸﺘﺴﻣ تﺎﻀﺒﻧ دﺪﻋ ءﺎﺼﺣإ لﻼﺧ ﻦﻣ ﻚﻟذو ،ﺎﻫﺪﻳرﻮﺗ ﻢﺘﻳ ﻲﺘﻟا هﺎﻴﳌا ﺔﻴﻤﻛ سﺎﻴﻘﺑ مﻮﻘﻳ
.ﺪﻳرﻮﺘﻟا مﺎﻤﺻ ﺐﻧﺎﺠﺑ دﻮﺟﻮﳌا (Hall IC)
۵ .هﺎﻴﳌا ع
ﹼ
زﻮﻣ
ﻲﺘﻟا هﺎﻴﳌا ﻖﻓﺪﺗ ﻖﻠﻏ وأ ﺢﺘﻔﺑ هﺎﻴﳌا ع
ﹼ
زﻮﻣ مﻮﻘﻳ ﺚﻴﺣ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد ةدﻮﺟﻮﳌا ةﺎﻔﺼﳌا جاﺮﺧإ فﺮﻃ ﻲﻓ ﻊﻘﻳ
(ءﺰﳉا ﻚﻠﺗ ﻰﻠﻋ زاﺮﻄﻟا اﺬﻫ يﻮﺘﺤﻳ ﻻ) .قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻦﻣ ﻲﻠﻔﺴﻟا ءﺰﳉا ﻰﻟإ ﻞﻘﺘﻨﺗ
۶ .ﻒﻈﻨﳌا ع
ﱢ
زﻮﻣ
.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﺔﻄﺳاﻮﺑ ﺎﻤﻬﻣاﺪﺨﺘﺳا ﻦﻜﳝ ﺚﻴﺤﺑ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣو ﻒ
ﹼ
ﻈﻨﳌا ﻦﻳﺰﺨﺗ نﺎﻜﻣ
.ﺔﺟﺎﳊا ﺪﻨﻋ ﺎ
ﹰ
ﻴﺋﺎﻘﻠﺗ ﻒﻄﺸﻟا ﺪﻋﺎﺴﻣو ﻒ
ﹼ
ﻈﻨﳌﺎﺑ ﺔﻟﺎ
ﹼ
ﺴﻐﻟا ﻦﻣ ﻲﻠﺧاﺪﻟا ءﺰﳉا داﺪﻣﺈﺑ ع
ﹼ
زﻮﳌا مﻮﻘﻳ
٧ .ضﻮﳊا ﺔﻋﻮﻤﺠﻣ.قﺎﺒﻃﻷا ﺔﻟﺎﺴﻐﻟ ﻲﺳﺎﺳﻷا ﻞﻜﻴﻬﻟا ﻞﻜﺸﺗ ﺚﻴﺣ ،أﺪﺼﻠﻟ ﻞﺑﺎﻘﻟا ﺮﻴﻏ ذﻻﻮﻔﻟا ﻦﻣ ﺔﻋﻮﻨﺼﻣ ﺔﻴﻠﺧاد ﺔﺒﻠﻋ ﻦﻋ ةرﺎﺒﻋ
٨ .ةﺎﻔﺼﳌا ﺔﻋﻮﻤﺠﻣ
.ناروﺪﻟا ﺪﻌﺑ ﺎﻨﻫ ﺎﻬﻟﺎﺧدإ ﰎ ﻲﺘﻟا هﺎﻴﳌا ﻊﻤﺠﺘﺗ .هﺎﻴﳌا ﻊﻴﻤﲡ ﻪﻴﻓ ﻢﺘﻳو قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﺧاد دﻮﺟﻮﳌا نﺎﻜﳌا ﻲﻫ
.ﻒﻳﺮﺼﺘﻟا ﺔﺨﻀﻣو ناروﺪﻟا كﺮﺤﲟ ةﺎﻔﺼﳌا ﺔﻋﻮﻤﺠﻣ ﻞﻴﺻﻮﺗ ﻢﺘﻳ ،اﺬﻟ
٩ .ضﻮﺤﻠﻟ ﺔﻴﻣﺎﻣﻷا ﺔﻋﻮﻤا.ﻲﻣﺎﻣﻷا بﺎﺒﻠﻟ ﻲﻠﺧاﺪﻟا ءﺰﳉا ﻞﻜﺸﺗ ﺚﻴﺣ ،أﺪﺼﻠﻟ ﻞﺑﺎﻘﻟا ﺮﻴﻏ ذﻻﻮﻔﻟا ﻦﻣ ﺔﻋﻮﻨﺼﻣ ﺔﻴﻠﺧاد ﺔﺒﻠﻋ ﻦﻋ ةرﺎﺒﻋ
١٠ .ةﺪﻋﺎﻘﻟا ﺔﻋﻮﻤﺠﻣ.ﻲﻠﻔﺴﻟا ءﺰﺠﻠﻟ ﻲﺳﺎﺳﻷا ﻞﻜﻴﻬﻟا ﻞﻜﺸﻳ يﺬﻟا ﻲﻜﻴﺘﺳﻼﺒﻟا ءﺰﳉا ﻲﻫ
١١ .ﺔﻠﺴﻟا ﺔﻋﻮﻤﺠﻣ.ﺎﻤﻬﻴﻠﻋ قﺎﺒﻃﻷا ﻊﺿو ﻢﺘﻳ ﺚﻴﺣ ،ﻲﻠﻔﺴﻟاو يﻮﻠﻌﻟا نﺎﻓﺮﻟا ﻲﻫ
١٢ .ﻰﻠﻔﺴﻟا/ﻰﻄﺳﻮﻟا تﺎﻫﻮﻔﻟا.
ﹴ
لﺎﻋ ﻂﻐﻀﺑ ﺎﻬﻟ ﺺﺼا ﺮﻤﳌا لﻼﺧ ﻦﻣ ﺎﻫﺪﻳرﻮﺗ ﻢﺘﻳ ﻲﺘﻟا هﺎﻴﳌا لﺎﺧدإو ﺮﻳوﺪﺗ ﻖﻳﺮﻃ ﻦﻋ قﺎﺒﻃﻷا ﻞﺴﻏ ﻰﻠﻋ ﻞﻤﻌﺗ
١٣ .ﺔﺒﻠﻌﻟا ﺢﺒﻜﻣ
ﻢﺘﻳ يﺬﻟا ﻲﻠﺧاﺪﻟا ءاﻮﻬﻟا ﻂﻐﻀﺑ ﻲﺟرﺎﳋا ءاﻮﻬﻟا ﻂﻐﺿ ﻞﻴﺻﻮﺗ ﻖﻳﺮﻃ ﻦﻋ ءاﻮﻬﻟا ﻂﻐﺿ ﻂﺒﻀﻳ ﺮﳑ ﻦﻋ ةرﺎﺒﻋ
.ﻒﻄﺸﻟاو ﻞﺴﻐﻟا ﻲﺗرود لﻼﺧ ﺔﻴﻟﺎﻋ ةراﺮﺣ ﺔﺟرد ﺪﻨﻋ هﺪﻳﺪﲤ
١۴ .بﺎﺒﻟا ﻞﻔﻗ حﺎﺘﻔﻣ.ﺎ
ﹰ
ﺘﻗﺆﻣ ةروﺪﻟا ﻒﻗﻮﺘﺗ ،قﺎﺒﻃﻷا ﺔﻟﺎﺴﻏ ﻞﻴﻐﺸﺗ ءﺎﻨﺛأ ﻪﺤﺘﻓ لﺎﺣ ﻲﻔﻓ ؛ﺎ
ﹰ
ﻘﻠﻐﻣ وأ ﺎ
ﹰ
ﺣﻮﺘﻔﻣ بﺎﺒﻟا نﺎﻛ اذإ ﺎﻤﻋ ﻒﺸﻜﻳ
DW5500M_DD81-02437K-00_AR.indd 52DW5500M_DD81-02437K-00_AR.indd 52 2019-03-18 11:15:022019-03-18 11:15:02
ﺔﻈﺣﻼﻣ
DW5500M_DD81-02437K-00_AR.indd 53DW5500M_DD81-02437K-00_AR.indd 53 2019-03-18 11:15:022019-03-18 11:15:02
ﺔﻈﺣﻼﻣ
DW5500M_DD81-02437K-00_AR.indd 54DW5500M_DD81-02437K-00_AR.indd 54 2019-03-18 11:15:022019-03-18 11:15:02
ﺔﻈﺣﻼﻣ
DW5500M_DD81-02437K-00_AR.indd 55DW5500M_DD81-02437K-00_AR.indd 55 2019-03-18 11:15:022019-03-18 11:15:02
؟تﺎﻘﻴﻠﻌﺗ وأ ﺔﻠﺌﺳأ ﻚﻳﺪﻟ ﻞﻫ
ﺪﻠﺒﻟاﺎﻨﺑ ﻞﺼﺗاﻰﻠﻋ ﺖﻧﺮﺘﻧﻹا ﻰﻠﻋ ﺎﻨﻌﻗﻮﻣ ةرﺎﻳﺰﺑ ﻢﻗ وأ
U.A.E800-SAMSUNG (800 - 726 7864)
www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
OMAN800-SAM CS (800-72627)
KUWAIT183-CALL (183-2255)
BAHRAIN8000-GSAM (8000-4726)
QATAR 800-CALL (800-2255)
DW5500M_DD81-02437K-00_AR.indd 56DW5500M_DD81-02437K-00_AR.indd 56 2019-03-18 11:15:022019-03-18 11:15:02
