EN Portable Air Conditioner
Translation of the original manual
SAC MT7013C
- 2 -
05/2021
Copyright © 2021, Fast ČR, a.s.
EN
Portable Air Conditioner
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
Important safety instructions
This symbol indicates that not adhering to instructions
may result in death or serious injuries.
WARNING:
To prevent the death or injury of the user or other persons
or damage to property, the following instructions must
be adhered to. Incorrect use as aresult of not adhering
to instructions may cause death, injuries or damage.
■ This appliance may be used by children 8 years of age and older
and by persons with physical, sensory, or mental impairments
or by persons with alack of experience or knowledge, if they
are properly supervised or have been informed about how to
use the product in asafe manner and understand the potential
dangers.
■ Cleaning and maintenance performed by the user must not be
performed by unsupervised children.
■ Children must not play with the appliance.
■ If the power cord is damaged, it must be replaced by an
authorised service centre or by another similarly qualified
person, this will prevent the creation of adangerous situation.
It is forbidden to use the appliance if it has adamaged power
cord.
■ The appliance must be stored in a manner that prevents its
mechanical damage.
■ The appliance must be stored in awell-ventilated location, where
the dimensions of the room correspond to the dimensions
- 3 -
05/2021
Copyright © 2021, Fast ČR, a.s.
specified for its operation.
■ The appliance must be stored in aroom where an open flame
is not continuously in use (e.g. running gas appliance) or where
there are not sources of ignition (e.g. running electrical heating
element).
■ Before connecting the appliance to a power socket, check
that the rated voltage on its rating label matches the electrical
voltage in the power socket.
■ Connect the appliance only to aproperly grounded socket.
■ The power socket must be freely accessible so that it is possible
to quickly disconnect the power cord from the power source if
necessary.
■ The appliance is designed for use at home, in offices and similar
types of areas. Do not use it in very dusty or humid rooms such
as laundries or bathrooms, in areas where chemical or explosive
substances are stored, in industrial surroundings or outdoors.
■ Do not place the appliance in the vicinity of an open flame or
appliances that are sources of heat.
■ Do not place the appliance on unstable surfaces such as carpets
with very long and thick fibres.
■ The appliance may only be used on adry, stable, smooth and
horizontal surface.
■ The appliance is equipped with travel wheels, so pay extra
attention when handling it so that it does not fall downstairs or
travel down from sloped areas. If necessary, secure the wheels
using the stoppers.
■ Only use original parts to assemble the appliance. Before
starting to assemble the appliance, make sure that it is turned
off and disconnected from the power socket.
■ Prior to connecting the appliance to a power socket, make
sure that the appliance is correctly assembled according to the
- 4 -
05/2021
Copyright © 2021, Fast ČR, a.s.
instructions in this user’smanual.
■ Do not touch the appliance with wet or damp hands. This
applies especially when it is connected to apower socket.
■ Do not expose the appliance to dripping or spraying water or
submerge it in water or another liquid.
■ Do not cover or insert anything into the air inlet or air outlet
openings. Otherwise, this could damage the appliance.
■ During operation there needs to be sufficient space for air
circulation of at least 30 cm on all sides of the appliance.
■ Do not expose yourself to acold air current for along time. This
could have anegative effect on your health.
■ To turn the appliance on or off, always use the appropriate
buttons on the control panel or the remote control. Do not turn
off the appliance by disconnecting the power cord from the
power socket.
■ Always turn off the appliance and disconnect it from the power
socket when leaving it without supervision, when not using it
and before moving, disassembling, or cleaning it.
■ Do not attempt to remove the outer case of the appliance.
■ Disconnect the appliance from the power socket by pulling
on the plug, never pulling on the power cord. Otherwise, this
could damage the power cord or the socket.
■ If the power cord or power plug are damaged in any way, do
not use the appliance.
■ Store the appliance in avertical position. It may be transported
in avertical position or tilted on the sided. If you have already
used the appliance, check that all the condensate has been
drained. After transporting it, wait at least 1 hour before using
the appliance.
■ Do not use the appliance if it is not working correctly if it has
been damaged or has been submerged in water. To avoid
- 5 -
05/2021
Copyright © 2021, Fast ČR, a.s.
ahazardous situation arising, do not repair the device yourself
or modify it in any way. Have all repairs or adjustments
performed at an authorised service centre. By tampering with
the appliance, you risk voiding your legal rights arising from
unsatisfactory performance or quality warranty.
■ Installation must be performed in accordance with the
installation instructions. Incorrect installation may result in
awater leak, injury by electrical shock or fire.
■ To prevent the risk of fire or injury by electrical shock, do not
use this appliance with atimer or any another similar device
that could spontaneously start this appliance.
■ The appliance must be installed in accordance with national
electrical codes.
■ Only use this product for the purposes that are described in
this user’s manual. Otherwise, this may result in damage or
excessive noise and vibrations.
■ Use only the accessories and components that are supplied
together with the appliance and the tools explicitly intended for
its installation. The use of non-standard parts and accessories
may result in awater leak, injury by electrical shock, fire, injury,
or damage to property.
■ DO NOT ADJUST the length of the power cord of the unit and
do not use an extension cord for its power supply.
■ DO NOT CONNECT the unit to apower socket to which other
electrical appliances are already connected. The incorrect
selection of an electrical power supply may result in afire or
injury by electrical shock.
■ Do not cover the cable with a carpet. Do not place carpets,
fillets, or any other floor coverings on the power cord. Do not
locate the cable underneath furniture or appliances. Lead the
- 6 -
05/2021
Copyright © 2021, Fast ČR, a.s.
cable where nothing will ride over it and where nobody can
trip over it. If this occurs, immediately disconnect the unit from
the power socket.
■ If the unit is tipped over during use, turn it off and immediately
disconnect it from the main power supply. Visually check that
the unit has not been damaged in any way.
■ In the event of any doubts that the unit has been damaged in
any way, seek assistance from atechnician or customer service.
■ The power supply must be disconnected during athunderstorm
to prevent damage to the appliance in the event of alightning
strike.
■ Disconnect the power supply to the appliance if it makes
astrange noise or if an odour or smoke is emitted.
Read this user’smanual.
Warning:
Fire hazard.
SPECIFIC INFORMATION FOR APPLIANCES USING
REFRIGERANT GAS R290
■ Carefully study any warnings.
CAUTION:
For defrosting and cleaning, do not use any other tools
than those recommended by the manufacturer.
■ This appliance must be placed in an area without any continuous
source of ignition (for example an open fire, gas or electrical
appliances in operation).
■ Do not puncture or do not burn it.
- 7 -
05/2021
Copyright © 2021, Fast ČR, a.s.
■ Refrigerant gases may be odourless.
■ The appliance must be installed, used, and stored in an area
that is greater than 8 m
2
.
■ This appliance contains approx. 140 g of refrigerant gas R290.
■ R290 is a refrigerant gas that complies with the European
directives on the environment. Do not puncture any part of the
refrigerant circuit.
■ If the appliance is installed, used and stored in anon-ventilated
area, the room must be designed to prevent the accumulation
of refrigerant leaks resulting in arisk of fire or explosion due to
ignition of the refrigerant caused by electrical heaters, stoves,
or other sources of ignition.
■ The appliance must be stored in such a way as to prevent
mechanical failure.
■ Individuals who operate or work on the refrigerant circuit must
have the appropriate certification issued by an accredited
organisation that ensures competence in handling refrigerants
according to aspecific evaluation recognized by associations in
the industry.
■ Repairs must be performed based on the recommendations
from the manufacturing company. Maintenance and repairs
that require the assistance of other qualified personnel must
be performed under the supervision of an individual specified
in the use of flammable refrigerants.
■ Check the rating label for the type of refrigerant gas used in
your appliance.
■ Do not cover the ventilation slots.
■ Compliance with national gas regulations shall be observed.
- 8 -
05/2021
Copyright © 2021, Fast ČR, a.s.
SAC MT7013C
1
6
7
8
9
10
11
12
2
3
4
5
13
A
- 9 -
05/2021
Copyright © 2021, Fast ČR, a.s.
23
4
67
8
9
1
5
B
12 34 56
C
- 10 -
05/2021
Copyright © 2021, Fast ČR, a.s.
1
7
8
9
10
2
6
4
5
11
D E
F
G
- 11 -
05/2021
Copyright © 2021, Fast ČR, a.s.
EN
Portable Air Conditioner
User´smanual
■ Prior to using this appliance, please read the user’smanual thoroughly, even in cases,
when one has already familiarised themselves with previous use of similar types of
appliances. Only use the appliance in the manner described in this user’smanual.
Keep this user’smanual in asafe place where it can be easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for at least the
duration of the legal liability for unsatisfactory performance or quality. In the event
of transportation, we recommend that you pack the appliance in the original box
from the manufacturer.
DESCRIPTION OF THE APPLIANCE
A1 Control panel
A2 Remote control signal sensor
(located under the panel)
A3 Grille
A4 Front cover
A5 Castors
A6 Handles (located on both sides)
A7 Removable grille with filter
A8 Upper air inlet of the evaporator
A9 Upper drain outlet
A10 Air outlet to connect the flexible
hose
A11 Bottom air inlet of the condensation
unit
A12 Bottom drain outlet
A13 Power cord hold band
DESCRIPTION OF THE ACCESSORIES
B1 Remote control (batteries included)
B2 Sealing kit for roof, sash, and tilt-
open windows:
- textile protection with azip
- tape of self-adhesive velcro
B3 Plastic window set for sliding and
roof windows (screws included)
(available depending on the model)
B4 Wide flexible hot air exhaust hose
B5 Inlet hose adaptor
B6 Outlet hose adaptor
B7 Adhesive foam seal
B8 Foam seal
B9 Drain hose
Not shown
■ Remote control wall holder
DESCRIPTION OF THE CONTROL PANEL
C1 button – to select the operation
mode
C2 - button
C3 Operation mode light indicators
C4 Display
C5 + button
C6
button – to turn the air
conditioner on / off
DESCRIPTION OF THE REMOTE CONTROL
D1 Display
D2 ON / OFF button – to turn the air
conditioner on / off
D3 MODE button – to select the
operation mode
D4 FAN button – to set the fan speed
D5 TEMP button – to set the
temperature
D6 SLEEP button – to turn on the sleep
function
D7 SHORT CUT button – to set and
turn on your favourite setting
D8 TIMER ON button – to set the
automatic turn-on of the air
conditioner
D9 TIMER OFF button – to set the
automatic turn-off of the air
conditioner
D10 LED button – to turn on / off the
display illumination
D11 FOLLOW ME button – to turn on /
off the follow me function
INSTALLATION
Location of the portable air conditioner
■ Locate the portable air conditioner on an even, dry, and stable surface and within
reach of agrounded power socket.
■ For easier handling, the portable air conditioner is equipped with castors A5. Do
not use the castors A5 when you need to move the air conditioner over carpets or
similar surfaces. Avoid riding over objects.
■ To achieve optimal efficiency, maintain adistance of at least 45 cm from the wall
or other obstacles.
Warning:
Do not block the air inlet or air outlet.
Note:
Do not use the portable air conditioner to cool aroom where computer
servers, etc. are located.
Installation, adjustment, maintenance, and repairs must only be
performed by aqualified person.
Installation of flexible hose on to the portable air conditioner
■ The flexible hose B4 must be connected to the portable air conditioner and installed
into awindow in accordance with the operating modes that you wish to set. Install
the flexible hose B4 when you wish to select the operating modes: cooling and
dehumidification.
■ Extend the flexible hose B4 to the required length. Fix the inlet hose adaptor B5
on to the end of the flexible hose B4. Place it next to the air outlet A11 and fix it by
moving it towards left – see picture E.
■ Fix the outlet hose adaptor B6 on to the second end of the flexible hose B4.
Note:
Avoid excessive bending of the hose – see fig. F. To ensure the proper
operation of the portable air conditioner, it is important not to overload
the hose, or to bend it unnecessarily. Excessive loading or bending may
damage the hose.
Installation of flexible hose into aslide window
■ The window insert is designed to be compatible with the majority of sliding
windows (vertical and horizontal). Nevertheless, for certain types of slide windows it
may be necessary to modify the installation procedure described below.
■ Open the sliding window sash and place the window insert into the window. Adjust
the dimensions of the window insert to the width of the window (on a vertical
slide window) / height of the window (on ahorizontal slide window). If necessary,
cut away apart of the window insert if the window is too small. Close the sliding
window sash to the window insert. Insert the flexible hose B4 with attached outlet
hose adaptor B6 into the hole in the window insert.
Installation of flexible hose using the sealing kit
■ The sealing kit B2 is suitable for tilt-open, sash and roof windows. The textile
protection is easy to install in the window using the Velcro. Open the window
and into the created crevice install the tape of Velcro. We recommend that you
thoroughly degrease the location where you will be attaching the tape of Velcro
using an appropriate cleaning agent. Remove the protective paper strip and stick
the tape on to the window frame.
■ To be able to insert the flexible hose B4, the textile protection is fitted with an
integrated zip. Open the zip in such alocation that will enable you to easily insert
the flexible hose B4.
■ It is not necessary to remove the sealing kit B2 from the window when not using the
portable air conditioner. The window can be still closed.
OPERATION OF THE PORTABLE AIR CONDITIONER
A.CONTROL PANEL
■ Insert the power plug into apower socket. Now, the portable air conditioner sets
itself to the stand-by mode.
Turning the portable air conditioner on and off
■ To turn on the portable air conditioner, press the
button C6. Press it again to
switch the portable air conditioner to the stand-by mode.
Note:
Never turn off the portable air conditioner by pulling the power cord out
of the power socket. Turn off the portable air conditioner using the
button C6, wait afew minutes and then pull out the power cord. Wait
at least 3 minutes before restarting the operation. That is to protect the
portable air conditioner from potential damage.
OPERATING MODES
1. Cooling mode
■ Repeatedly press the
button C1 until the cooling indicator (COOL) is lit. Use the
+/- buttons to set the desired temperature. You can set the temperature in the range
from 17 to 30 °C. The set temperature is shown on the display C4.
2. Fan mode
■ Repeatedly press the
button C1 until the fan indicator (FAN) is lit. Press the FAN
D4 button on the remote control and set the fan speed in the following order: Auto
(automatic speed) - Low (low speed) – High (high speed).
■ In this mode, it is not possible to set the temperature, nor it is necessary to connect
the flexible hose B4 to the portable air conditioner.
3. Dehumidification mode
■ Ensure the flexible hose B4 is connected to the air conditioner. Repeatedly press
the
button C1 until the dehumidification indicator (DRY) is lit. In this mode, it
is not possible to set the temperature or fan speed. The fan speed is automatically
set to low speed.
B. REMOTE CONTROL
Inserting and replacing batteries
■ Slide out the battery compartment cover, which is located on the rear side of the
remote control. Place two AAA/LR03 (2× 1.5 V) alkaline batteries into the battery
compartment and close the cover.
■ When inserting the batteries ensure the correct polarity as shown in the battery
compartment.
■ When replacing the batteries, always use batteries of the same type, never combine
old and new batteries or batteries of various types.
Note:
Removing the batteries from the remote control will delete all the
settings. After new batteries are inserted the default remote control
settings as programmed by the manufacturer will be renewed.
If you do not use the remote control for longer than 2 months, remove
the batteries.
- 12 -
05/2021
Copyright © 2021, Fast ČR, a.s.
Caution:
Dispose the used batteries according to the local regulations.
Never dispose the batteries together with the household waste.
Do not use old and new batteries at the same time. Do not use
alkaline, standard, and rechargeable batteries at the same time.
Do not throw batteries into fire. They may explode or leak.
Using the remote control
■ For the remote control to work correctly, ensure that the maximum distance of the
remote control from the portable air conditioner is not greater than 8 m and that
there is no obstacle between the remote control and the portable air conditioner
that could prevent the transmission of the signal.
■ Point the remote control directly at the portable air conditioner. The transmission of
the signal is confirmed by ashort sound signal.
■ Do not expose the remote control to direct sunlight or high temperatures.
Otherwise, the signal may not be transmitted.
Turning the portable air conditioner on and off
Press the ON / OFF D2 button once to turn the portable air conditioner on. Press the
ON / OFF D2 button again to switch the portable air conditioner to the stand-by mode.
OPERATING MODES
1. Automatic mode
■ Repeatedly press the MODE D3 button until the display D1 shows “AUTO”. Use the
arrows ▲ / ▼ to set the desired temperature. You can set the temperature in the
range from 17 to 30 °C. The portable air conditioner will automatically select the
operation mode. The fan speed cannot be adjusted.
2. Cooling mode
■ Repeatedly press the MODE D3 button until the display D1 shows “COOL”. Use the
arrows ▲ / ▼ to set the desired temperature. You can set the temperature in the
range from 17 to 30 °C.
■ Press the FAN D4 button on the remote control and set the fan speed in the
following order: Auto (automatic speed) - Low (low speed) – High (high speed).
Note:
If you set the temperature of the cooling mode directly on the control
panel of the portable air conditioner, the temperature on the display D1
will differ from the temperature shown on the display C4.
3. Dehumidification mode
■ Ensure the flexible hose B4 is connected to the air conditioner.
■ Repeatedly press the MODE D3 button until the display D1 shows “DRY”.
■ It is not possible to set the temperature or fan speed. The fan speed is automatically
set.
4.Fan mode
■ Repeatedly press the MODE D3 button until the display D1 shows “FAN”.
■ Press the FAN D4 button on the remote control and set the fan speed in the
following order: Auto (automatic speed) - Low (low speed) – High (high speed).
■ In the fan mode, it is not possible to set the temperature.
FUNCTIONS OF THE PORTABLE AIR CONDITIONER
1. Sleep function
■ The sleep function is used to reduce overnight power consumption when aconstant
temperature is not necessary. The function also ensure comfort while sleeping as the
air conditioner operation is turned down and the display illumination is dimmed.
■ Select the cooling or automatic mode and set the desired temperature - see the
previous part of the manual.
■ Press the SLEEP D6 button. The display D1 will show a“moon” icon in the upper
right corner.
■ The temperature will increase by 1 °C in 30 minutes and it will increase again by
1 °C after an additional 30 minutes. This new temperature will be maintained for
7 hours and then, the portable air conditioner will return to the original selected
temperature.
■ The sleep function is not available for fan and dehumidification modes.
2. AUTOMATIC TURNON AND TURNOFF FUNCTIONS
Automatic turn-on
■ The automatic turn-on function enables to set the time after which the portable air
conditioner will turn on automatically.
■ Turn the portable air conditioner on by pressing the ON / OFF D2 button. Use the
MODE D3 button to select the desired operation mode in which you wish to turn
the portable air conditioner on.
■ The automatic turn-on function can be activated without turning on the air
conditioner. The air conditioner will operate in last selected mode.
■ Press the TIMER ON D8 button and the display D1 will show last set time and “h”.
■ Repeatedly press the TIMER ON D8 button to set the time after which the portable
air conditioner will turn on automatically. Wait about 2 seconds for the setting to be
stored in the memory.
■ You can set the time of the automatic turn-on function in the range from 0,5 up to 24
hours. You will increase the time by 30 minutes in the range from 0:30 to 10:00, and
you will increase the time by 1 hour in the range from 10:00 to 24:00.
■ The correct setting of the automatic turn-on function is indicated by lighting up the
indicator on the display C4 and “Timer On” indicator on the display D1.
■ Turn the portable air conditioner off by pressing the ON / OFF D2 button.
■ Once the set time has elapsed, the portable air conditioner will turn on automatically.
■ Automatic turn-off
■ The automatic turn-off function enables to set the time after which the portable air
conditioner will turn off automatically.
■ While the portable air conditioner is running, press the TIMER OFF D9 button and
the display D1 will show last set time and “h”.
■ Repeatedly press the TIMER OFF D9 button to set the time after which the portable
air conditioner will turn off automatically. Wait about 2 seconds for the setting to be
stored in the memory.
■ You can set the time of the automatic turn-on function in the range from 0,5 up to 24
hours. You will increase the time by 30 minutes in the range from 0:30 to 10:00, and
you will increase the time by 1 hour in the range from 10:00 to 24:00.
■ The correct setting of the automatic turn-on function is indicated by lighting up the
indicator on the display C4 and “Timer Off” indicator on the display D1.
■ Once the set time has elapsed, the portable air conditioner will turn off automatically.
Automatic turn-on and off
■ You can set the timer when the portable air conditioner should turn on and off.
■ Turn the portable air conditioner on by pressing the ON / OFF D2 button. Use the
MODE D3 button to select the desired operation mode in which you wish to turn
the portable air conditioner on.
■ The automatic turn-on function can be activated without turning on the air
conditioner. The air conditioner will operate in last selected mode.
■ Press the TIMER ON D8 button. Once the display D1 shows “h”, repeatedly press
the TIMER ON D8 button to set the time after which the portable air conditioner
will turn on automatically. Wait about 3 seconds for the setting to be stored in the
memory.
■ Afterwards, press the TIMER OFF D9 button. Once the display D1 shows “h”,
repeatedly press the TIMER OFF D9 button to set the time after which the portable
air conditioner will turn on automatically. Wait about 3 seconds for the setting to be
stored in the memory.
■ The correct setting of the automatic turn-on function is indicated by lighting up
the indicators on the display C4 and “Timer On” and “Timer Off” indicators on the
display D1.
■ Turn the portable air conditioner off by pressing the ON / OFF D2 button.
■ Once the set time for automatic tun-on has elapsed, the portable air conditioner
will turn on and start. It will be in operation until the time after which it is to turn off
automatically has elapsed.
Note:
You can turn off the automatic turn-on or turn-off, or both functions, by
setting the time to 0:00.
3. SHORT CUT function
■ SHORT CUT function enables you to save the setting you have made.
■ At first, it is necessary to select the operation mode or function. Then, long press the
SHORT CUT D7 button and the display D1 flashes shortly. That means the setting
has been stored in the memory.
■ Shortly press SHORT CUT D7 button and the air conditioner will start at the saved
setting.
4. FOLLOW ME FUNCTION
■ This function can be operated ONLY using the remote control. The remote control
serves as a remote thermostat which scan the temperature at its current location
(instead of the sensor of the portable air conditioner). At regular intervals, it then
sends a temperature signal to the portable air conditioner which then optimizes the
temperature around you, i.e., around the place where the remote control is located,
and thus ensures maximum comfort.
■ The FOLLOW ME function can only be set in automatic or cooling mode.
■ Press the FOLLOW ME D11 button and the display D1 shows the current
temperature and the symbol of the FOLLOW ME function. The remote control will
start sending the signal to the portable air conditioner every three minutes until the
function is cancelled by pressing the FOLLOW ME D11 button again.
■ If the portable air conditioner does not receive any signal within 7minutes, the
Follow me function will be automatically cancelled.
Note:
This function is not available for fan or dry mode.
AUTO RESTART
■ If the power supply is interrupted while the portable air conditioner is running, last
setting will remain stored in the internal memory. As soon as the power supply is
resumed, the portable air conditioner will automatically start.
TIPS FOR CORRECT USE
- To ensure the correct operation of the portable air conditioner, follow these
recommendations:
- Close all the windows and doors in the room where the portable air conditioner
is used. When installed the portable air conditioner semi-permanently, you can
leave the door slightly open (approx. 1cm) to guarantee correct ventilation.
- Protect the room from the direct sunshine. Close curtains or roller blinds to
ensure economy operation of the air conditioner.
- Do not block the air inlet or air outlet.
- Ensure there is no source of heat on in the room.
- Never use the portable air conditioner in very damp rooms, such as laundries.
- Never use the portable air conditioner outside.
- Ensure the portable air conditioner is located on alevel surface. Install special
travel wheel brakes if needed.
- 13 -
05/2021
Copyright © 2021, Fast ČR, a.s.
CLEANING AND MAINTAINANCE
■ Before cleaning the portable air conditioner, turn it off and wait afew minutes, and
then pull the power cord out of the power socket.
Cleaning the air filter
■ When the portable air conditioner is used regularly, it is necessary to clean the air
filter located behind the protective grille at least once in two weeks to prevent the
fan from being clogged by dust.
■ Carefully remove the protective grille and remove the filter – see fig. G . To remove
the dust, use avacuum cleaner. In the event of greater soiling, hand wash the filter
in asolution of lukewarm water (max. 40 °C) and neutral detergent. Then thoroughly
rinse under running water and allow to dry naturally. Do not dry it in aclothes dryer
or in direct sunlight. Once the filter is dry, you can install them back in their place.
Note: Do not use the portable air conditioner without the air filter
properly installed and do not use it with wet or damp air filter.
Cleaning the outer case
■ To clean the outer case, use asoft wiping cloth dipped in asolution of lukewarm
water and neutral detergent. Then wipe the surface dry.
■ When cleaning it, do not spray the portable air conditioner with water or any other
liquid, do not pour water on it or submerge it in water or in any other liquid.
■ Do not use abrasive cleaning products, solvents, petrol, etc. for cleaning.
Storing the portable air conditioner
■ In order to dry it and to prevent the formation of moulds, leave the portable air
conditioner running in awarm room in the fan mode for approximately 12 hours.
■ Disconnect the flexible hose B4 and store it in a safe place out of the reach of
children.
■ Drain all the condensate from the water tank – see chapter “Condensate water
drainage”.
■ Clean the air filter and reinstall it. Wipe the outer case of the portable air conditioner.
Remove the batteries from the remote control.
■ Store the air conditioner in acool, dry, and dark location.
CONDESATE WATER DRAINAGE
■ The portable air conditioner is provided by two drain outlets where each drains
the condensate water from adifferent part of the air conditioner. In the event of
afrequent use of the portable air conditioner, it is necessary to regularly check the
condensate water status and drain it. If the dehumidification mode is selected, it is
advised to drain the condensate water using the drain hose B9 which is connected
either to the top drain outlet or bottom drain outlet.
Note:
It is not necessary to drain the condensate water in cooling or fan modes
(provided low humidity in the room). The portable air conditioner is
designed to increase its efficiency with asmall amount of water in the
condensate tank.
Condensate water drainage from the bottom drain outlet
■ Once the water level in the tank reaches the preset level, the operation of the
portable air conditioner stops and the display C4 shows “P1” (full tank). To drain the
condensate water from the air conditioner, proceed as follows:
1. Disconnect the power plug from the power socket.
2. Carefully re-locate the portable air conditioner to alocation where the water may be
drained.
3. Underneath the drain outlet A12, place a container into which the condensate
water will flow. Carefully remove the plug of the drain outlet A12. Connect the drain
hose B9 and allow the condensate water to flow out.
4. Once the water tank is empty (condensate water has stopped flowing), disconnect
the drain hose B9 and put the plug back into the drain outlet A12.
5. Insert the power plug into apower socket and turn on the portable air conditioner.
If you need to ensure the condensate water to be continuously drained from the
portable air conditioner, it is possible to connect the drain hose B9 to awaste water
drain. Proceed as follows:
1. Disconnect the power plug from the power socket.
2. Remove the plug of the drain outlet A12. Connect the drain hose B9. If the length of
the drain hose B9 is insufficient, then it is necessary to purchase alonger hose of the
same type. Never extend the length of the drain hose B9 using extensions.
3. Connect the end of the drain hose B9 to the waste water drain.
4. Insert the power plug into apower socket and turn on the portable air conditioner.
Note:
The drain hose B9 should be installed at the same height or lower than
the drain outlet A12. Otherwise, the condensate water will not be
properly drained from the water tank.
Condensate water drainage from the top drain outlet
■ In the dehumidification mode, you can use the top drain outlet A9 for acontinuous
drainage of the condensate water.
1. Disconnect the power plug from the power socket.
2. Remove the plug of the drain outlet A9. Connect the drain hose B9. If the length of
the drain hose B9 is insufficient, then it is necessary to purchase alonger hose of the
same type. Never extend the length of the drain hose B9 using extensions.
3. Connect the end of the drain hose B9 to the waste water drain.
4. Insert the power plug into apower socket and turn on the portable air conditioner.
Note:
The drain hose B9 should be installed at the same height or lower than
the drain outlet A9. Otherwise, the condensate water will not be properly
drained from the water tank.
Putting into operation again
■ Check that the power cord and plug are not damaged and that the air filter is clean.
Insert a new set of batteries into the remote control. Proceed according to the
instructions in section “Inserting and replacing batteries”. Install the portable air
conditioner according to the instructions contained in the preceding part of this
user’smanual “Installation”.
TROUBLESHOOTING
Error message
Shown on
display
Meaning Solution
E0
EEPROM error (Electrically
Erasable Programmable
Read-Only Memory).
Contact an authorised service centre.
E1
Room temperature sensor
error
Contact an authorised service centre.
E2
Evaporator temperature
sensor error
Contact an authorised service centre.
E3
(only some
models)
Condenser temperature
sensor error
Contact an authorised service centre.
E4
Display panel
communication error
Contact an authorised service centre.
EC
(only some
models)
Refrigerant leakage
detection
Contact an authorised service centre.
P1 Full tank
Empty the condensate tank. Proceed
according to the instructions
in section “Condensate water
drainage“ described previously in this
user‘smanual.
Note:
If one of the aforementioned faults occurs, turn off the portable air
conditioner and check for the cause of the fault. Turn it on again, and if
the fault reoccurs, turn it off, disconnect the power cord from the power
socket and contact the manufacturer, an authorised service centre or
aperson with relevant qualifications and have the unit repaired.
Troubleshooting
■ Before contacting an authorised service centre, please check the appliance
according to the following instructions:
Problem Possible cause Remedy
The portable
air conditioner
did not turn
on.
P1 error was shown on the
display.
Water tank is full. Empty the tank
according to the instructions in section
“Condensate water drainage“.
Cool mode: room
temperature is lower than
set temperature.
Set lower temperature than it is in the
room.
EO error was shown on
the display.
Contact an authorised service centre.
The portable
air conditioner
does not cool
enough.
The air filter is dirty.
Turn the air conditioner off and clean the
air filter according to the instructions in
section “Cleaning the air filter “.
Exhaust hose is not
connected or is blocked.
Turn the air conditioner off, connect the
hose, or disconnect it and remove the
blocked material and reconnect the hose.
There is little refrigerant in
the air conditioner.
Turn the air conditioner off and contact
an authorised service centre.
The set temperature is
too high.
Lower the set temperature.
Windows and doors in the
room are open and hot air
flows into the room.
Make sure all windows and doors are
closed.
The room area is too large.
Check the air conditioner is suitable for
such alarge room.
There are heat sources on
in the room.
Remove the heat sources if possible.
The air
conditioner is
too noisy and
vibrates.
The air conditioner is
located on uneven surface.
Turn the air conditioner off, disconnect
from the power outlet and relocate it on
aflat and even surface.
The air filter is dirty.
Turn the air conditioner off and clean the
air filter according to the instructions in
section “Cleaning the air filter “.
The air
conditioner
makes
agurgling
sound.
The sound is caused by
the flow of the refrigerant
in the inner circuit.
This anormal phenomenon.
- 14 -
05/2021
Copyright © 2021, Fast ČR, a.s.
TECHNICAL SPECIFICATIONS
Power supply 220 – 240 V ~ / 50 Hz
Cooling power 7 kBtu/h
Power input / Cooling input 980 W / 790 W
Current consumption 3.45 A
EER cooling factor 2.6 (A)
Dehumidification capacity 1.94 l / h
Refrigerant type and weight R290/140 g
Air flow volume (high / low setting) 272 /211 m
3
/h
Noise level 62 dB (A) (high setting)
Maximum permitted value of excess operating
pressure: Suction / exhaust part of the cooling circuit
1.0 / 2.6 MPa
Dimensions of the portable air conditioner (w × d × h) 329 × 318 × 634 mm
Weight 21.5 kg (netto)
Operation temperature (cooling) 17 – 30 °C
Recommended room area (Central Europe)* 21 – 26 m2
Recommended room size (Central Europe)* 54 – 67 m
3
*It is aconversion of the value to the climatic conditions typical for the Central Europe,
for common room with aceiling of astandard height. The stated values may differ in
case of use in the divided rooms, rooms with multiple heat sources, richly glass or / and
poorly insulated rooms. If you know you are purchasing the portable air conditioner
for aroom with the above-mentioned features, choose amodel with higher power
for the given area.
The declared noise emission level of the appliance is 62 dB(A), which represents alevel
Aof sound power with respect to areference sound power of 1 pW.
Note:
The efficiency of the portable air conditioner may be reduced in the
event that it is used outside the above-mentioned operating temperature
range.
We reserve the right to change text and technical specifications.
DISPOSAL OF USED BATTERIES
Batteries contain environmentally damaging compounds and,
therefore, do not belong in standard communal waste. Hand over
used batteries for proper disposal at locations intended for their
collection.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling hand over
these appliances to determined collection points. Alternatively, in
some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources and prevents
potential negative effects on the environment and human health, which could result
from improper waste disposal. Ask your local authorities or collection facility for more
details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This product meets all the basic requirements of EU directives related to
it.
