INSTRUCTION MANUAL
SOGA
COOKTOP
Fashionable design
Flexible firepower
Four digits display
Ten protection functions
MANUFACTURED BY ISO 9001:2008 COMPANY
Display data
Meaning
Suggestion
E1
The voltage is below 220V
Check the voltage
E2
The voltage is higher than 240V
Check the voltage
Normal display
No pot on the plate, or the material of
the pot is not correct
Use proper pot
E4
Electric current is larger than permitted
Ensure coorect type of pot is used,
change a new one and switch on
again
E5
Inner temperature sensor not work
Send to service center for checking
E6
E7
Inner temperature is too high
Plate temperature sensor not working
Check that both the inward and
outward air vent is not blocked
Send to service center for checking
E8
The plate temperature is high
Reduce the set temperature
B． If the temperature become irregular during cooking, please check:
Is the bottom of the pot not the flat type? Or the center of the bottom is the hollow type
(or the type that is with feet)?
Cleaning & Maintenance
Cleaning & Maintenance
1. Please take off the plug before you clean the cooker. Clean only when the plate is
cooled down.
2. Please clean the surface of the crystalised plate after each use.
3. Cleaning of the Crystalised plate and Control panel:
(a) If the plate is not very dirty, use soft wet cloth to clean.
(b) If the plate is dirty with oil, please use mild cleanser with wet soft cloth to clean.
Don't use brush to avoid damage to the plate.
4. Cleaning the cooker's body:
(a) If the plastic shell is not very dirty, use soft wet cloth. If the shell is diety with oil,
please use mild cleanser with soft wet cloth to clean.
(b) For vent grill, you can use brush and also can use cleanser if there is oil.
(c) Never use gas or benzene for shell cleaning. When you clean with wet cloth it
should be wringed dry to a void the machine is affected with damp.
4
PRODUCT INTRODUCTION
PRODUCT INTRODUCTION
Our Induction cooker use electromagnetic heating method and advanced
microcomputer control technology is the ideal choice for modern family for
different cooking.
Our Induction cooker use electromagnetic heating method and advanced
microcomputer control technology is the ideal choice for modern family for
different cooking.
STRUCTURAL REPRESENTATION
STRUCTURAL REPRESENTATION
1. Vent
2. Crystalised plate
3. Control panel
1. Vent
2. Crystalised plate
3. Contr ol panel
Control panel
Control panel
Electromagnetic cooker control panel have three kinds: Basic operating keys, Function
setting keys.
1. Basic operation keys: On/Off and+/-keys.
2. Function setting key: Press the separate key, you can choose different function e.g.
Rice cooking, Soup, Boil water, Hot Milk, Congee, Stew, Barbecue, Frying, Hot Pot etc.
1. Stir Fry: suitable for high temperature cooking like frying vegetable.
The power can be adjusted by pressing (+) or (-) key, with overheating
protect function.
2. Hot pot: With dry-burn protection function, suitable for different type of soup based cooking.
And can boil the water, sue high power for heating, when the temperature reach
boiling, induction cooker reduce heating automatically and alarm several minutes
3. Boil water: use high power for heating, when the temperature reach boiling, induction cooker
reduce heating automatically.
4. Barbecue: Suitable for fry or bake cakes, deeo fry or toast the food. The temperature can be
adjusted and have overheating function.
5. Deep Fry: suitable for high temperature fast cooking.
The power can be adjusted by pressing (+) or (-) key, with overheating
protect function.
Manual cooking method
1
Display data
Meaning
Suggestion
E1
The voltage is below 220V
Check the voltage
E2
The voltage is higher than 240V
Check the voltage
Normal display
No pot on the plate, or the material of
the pot is not correct
Use proper pot
E4
Electric current is larger than permitted
Ensure coorect type of pot is used,
change a new one and switch on
again
E5
Inner temperature sensor not work
Send to service center for checking
E6
E7
Inner temperature is too high
Plate temperature sensor not working
Check that both the inward and
outward air vent is not blocked
Send to service center for checking
E8
The plate temperature is high
Reduce the set temperature
B． If the temperature become irregular during cooking, please check:
Is the bottom of the pot not the flat type? Or the center of the bottom is the hollow type
(or the type that is with feet)?
Cleaning & Maintenance
Cleaning & Maintenance
1. Please take off the plug before you clean the cooker. Clean only when the plate is
cooled down.
2. Please clean the surface of the crystalised plate after each use.
3. Cleaning of the Crystalised plate and Control panel:
(a) If the plate is not very dirty, use soft wet cloth to clean.
(b) If the plate is dirty with oil, please use mild cleanser with wet soft cloth to clean.
Don't use brush to avoid damage to the plate.
4. Cleaning the cooker's body:
(a) If the plastic shell is not very dirty, use soft wet cloth. If the shell is diety with oil,
please use mild cleanser with soft wet cloth to clean.
(b) For vent grill, you can use brush and also can use cleanser if there is oil.
(c) Never use gas or benzene for shell cleaning. When you clean with wet cloth it
should be wringed dry to a void the machine is affected with damp.
4
PRODUCT INTRODUCTION
PRODUCT INTRODUCTION
Our Induction cooker use electromagnetic heating method and advanced
microcomputer control technology is the ideal choice for modern family for
different cooking.
Our Induction cooker use electromagnetic heating method and advanced
microcomputer control technology is the ideal choice for modern family for
different cooking.
STRUCTURAL REPRESENTATION
STRUCTURAL REPRESENTATION
1. Vent
2. Crystalised plate
3. Control panel
1. Vent
2. Crystalised plate
3. Contr ol panel
Control panel
Control panel
Electromagnetic cooker control panel have three kinds: Basic operating keys, Function
setting keys.
1. Basic operation keys: On/Off and+/-keys.
2. Function setting key: Press the separate key, you can choose different function e.g.
Rice cooking, Soup, Boil water, Hot Milk, Congee, Stew, Barbecue, Frying, Hot Pot etc.
1. Stir Fry: suitable for high temperature cooking like frying vegetable.
The power can be adjusted by pressing (+) or (-) key, with overheating
protect function.
2. Hot pot: With dry-burn protection function, suitable for different type of soup based cooking.
And can boil the water, sue high power for heating, when the temperature reach
boiling, induction cooker reduce heating automatically and alarm several minutes
3. Boil water: use high power for heating, when the temperature reach boiling, induction cooker
reduce heating automatically.
4. Barbecue: Suitable for fry or bake cakes, deeo fry or toast the food. The temperature can be
adjusted and have overheating function.
5. Deep Fry: suitable for high temperature fast cooking.
The power can be adjusted by pressing (+) or (-) key, with overheating
protect function.
Manual cooking method
1
Cauion When Using Automatic function
2
PRODUCT INTRODUCTION
PRODUCT INTRODUCTION
⚫ Please use socket more than 10A separately, do not use multi-socket or use with other
electrical appliance in one socket.
⚫ Put the induction cooker on level,10cm away from the wall
⚫ Never wash the cooker directly in water.
⚫ Do not use the cooker near the children, to avoid scalding.
⚫ Do not put any iron product on the surface of the cooker to avoid accident form happening.
⚫ For canned food, it must be opened before heating to avoid explosion of the can due to heat
expansion.
⚫ Do not use the cooker near the gas or oil oven.
⚫ Do not use cooker on the carpet or on table that is covered with a tablecloth, otherwise the air
vent might be blocked and the inside temperature of the machine cannot be reduced to
function normally.
⚫ Do not use the cooker if it is faulty or its power cord is faulty or the cooker has fallen or shows
visible damage.
⚫ If servicing is required, this cooker must be sent to the approved service centre for checking.
Do not attend to carry out repairing work by yourself.
3
Automatic cooking method
1. Soup/Congee: use medium power for heating, when the temperature approach
boiling, the heating reduce automatically. During this period, the intermittant
heating function continue to cook according to the time set. This function has
auto boiling sensor to prevent over boiling & over cooking.
2. Rice cooking: use the auto power for haeting the rice.
3. Stew: suitable for foods which need to cook slowly to keep its original delic taste,
cooking time designed in 120 minutes, and can adjust the heating ti and power
automatically during cooker.
* Timer: Adjust time for cooking
* Power consumed: Check power for heating.
1. This cooker will be switched off automatically by the sensor under the crystalised
plate the water is boiled. Hence, the time taken to boil the water vary with the
type of uten used, volume of water, thickness of the base of utensil etc.
2. As the accuracy of the automatic function is much affected by the cooker's initial
temperature, therefore plerse ensure that the cooker is in the cool state berore
using t automatic function key.
3. When the cooker is cooking under the low power situation, heating is done
intermittan this is normal.
4. For Porridge cooking, use only the flat base original pot supplied with the
cooker.
We recommend 1 portion of rice to 9 portion of water and it should not exceed
80% the pot capacity. Spread the rice evenly in the pot to prevent over-flow
when the wat is boiled.
5. For Soup cooking, the initial water level should not exceed 80% of the capacity.
Please keep watch when cooking soup to prevent over-flow or boil dry.
Suitable cookerware that is compatible with induction
Please use the cookerware supplied with the cooker, try not to us other cookerware.
In case if you preter to use other cookerware, please ensure that:
1. Pot material are of iron (pig iron, stainless steel, enamelled iron)
2. The cookware must be a flat bottom type with diameter not less than 12cm, and not
more than 26cm.
3. Please take note that cookwares that are made of Aluminium, Glass, Pottery or clay
cannot be used with electromagnitic induction cooker.
Trouble Shooting
A. The cooker does not turn ON after pressing the on /off key. Please check:
1. Is the plug properly fixed?
2. No electricity?
3. Ubder keep warm situation, the cooker had reached the temperature which set previously,
the cooker will function again after a while.
4. Sometime the over-heat protector is on work, please try again after several minutrs.
Cauion When Using Automatic function
2
PRODUCT INTRODUCTION
PRODUCT INTRODUCTION
⚫ Please use socket more than 10A separately, do not use multi-socket or use with other
electrical appliance in one socket.
⚫ Put the induction cooker on level,10cm away from the wall
⚫ Never wash the cooker directly in water.
⚫ Do not use the cooker near the children, to avoid scalding.
⚫ Do not put any iron product on the surface of the cooker to avoid accident form happening.
⚫ For canned food, it must be opened before heating to avoid explosion of the can due to heat
expansion.
⚫ Do not use the cooker near the gas or oil oven.
⚫ Do not use cooker on the carpet or on table that is covered with a tablecloth, otherwise the air
vent might be blocked and the inside temperature of the machine cannot be reduced to
function normally.
⚫ Do not use the cooker if it is faulty or its power cord is faulty or the cooker has fallen or shows
visible damage.
⚫ If servicing is required, this cooker must be sent to the approved service centre for checking.
Do not attend to carry out repairing work by yourself.
3
Automatic cooking method
1. Soup/Congee: use medium power for heating, when the temperature approach
boiling, the heating reduce automatically. During this period, the intermittant
heating function continue to cook according to the time set. This function has
auto boiling sensor to prevent over boiling & over cooking.
2. Rice cooking: use the auto power for haeting the rice.
3. Stew: suitable for foods which need to cook slowly to keep its original delic taste,
cooking time designed in 120 minutes, and can adjust the heating ti and power
automatically during cooker.
* Timer: Adjust time for cooking
* Power consumed: Check power for heating.
1. This cooker will be switched off automatically by the sensor under the crystalised
plate the water is boiled. Hence, the time taken to boil the water vary with the
type of uten used, volume of water, thickness of the base of utensil etc.
2. As the accuracy of the automatic function is much affected by the cooker's initial
temperature, therefore plerse ensure that the cooker is in the cool state berore
using t automatic function key.
3. When the cooker is cooking under the low power situation, heating is done
intermittan this is normal.
4. For Porridge cooking, use only the flat base original pot supplied with the
cooker.
We recommend 1 portion of rice to 9 portion of water and it should not exceed
80% the pot capacity. Spread the rice evenly in the pot to prevent over-flow
when the wat is boiled.
5. For Soup cooking, the initial water level should not exceed 80% of the capacity.
Please keep watch when cooking soup to prevent over-flow or boil dry.
Suitable cookerware that is compatible with induction
Please use the cookerware supplied with the cooker, try not to us other cookerware.
In case if you preter to use other cookerware, please ensure that:
1. Pot material are of iron (pig iron, stainless steel, enamelled iron)
2. The cookware must be a flat bottom type with diameter not less than 12cm, and not
more than 26cm.
3. Please take note that cookwares that are made of Aluminium, Glass, Pottery or clay
cannot be used with electromagnitic induction cooker.
Trouble Shooting
A. The cooker does not turn ON after pressing the on /off key. Please check:
1. Is the plug properly fixed?
2. No electricity?
3. Ubder keep warm situation, the cooker had reached the temperature which set previously,
the cooker will function again after a while.
4. Sometime the over-heat protector is on work, please try again after several minutrs.
INSTRUCTION MANUAL
SOGA
COOKTOP
Fashionable design
Flexible firepower
Four digits display
Ten protection functions
MANUFACTURED BY ISO 9001:2008 COMPANY
